Coffee Queen Future TT Combi automat User manual

Rev. 061201
U/GB
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
Yourretaildealer
...............................................................................
...............................................................................
Future TT
Combiautomat
Usermanual

1. Table (list) of contents.
:
1. Table of contents sid. 2
2. Generally 3
3. Overview of components, membran switch 4
3. Overview of components, front 5
3. Overview of components mixing system 6
4. SERVICE; Installation and start 7-8
Locate the brewer
Connectings: Electricity/Water
Starting up machine
Fill canisters
5. DRIFT
Brewing of coffee in cup, , 9
Brewing of jug 10
6. Cleaning program
Automatic cleaning of brew mechanism 11-12
Automatic cleaning of mixing bowl 13
Automatic cleaning of In/Outlet valves 14
Rotate brew mechanism without water or ingredients 15
7. Weekly cleaning
dismantle mixer system 16
wash these parts 16
assemble mixer system 17
8. Cleaning and maintenance
dismantling exchange and cleaning of coffee filter 18
outward cleaning 19
9. Cup counter and Easy access 20
10. Safety functions 21
11. Failure messages 21
12. Storage / Transport. 21
13. Dimension sketch 22
14. Circuit diagram. 23
2.

2. Generally. Future TT
We congratulateto yourchoice ofa CoffeeQueen Combiautomat.
Please read through this manual before you take the machine into operation
for the first time.
Themanualcontents importantinstructionsfor asafe and properusage of themachine.
Alwayskeepthis manualwithinreach forthe user!
Future TT Combi automat
- Makingcoffee cupby cup
- Jugfacilitywith key switch
- 8 choices of drinks,
- 3ingredients canisters,
- Brewingmechanismwith coffeefilter
- Electronicallytemperaturecontrolled
- Adjustablecoffeestrenght
- Lightedcup while brewing
- Clockfunctions
Facts: Future TT
Height 780mm
Width 420 mm
Depth 550 mm
Weight 35kg(emballage cá 4kg)
Tankage 2.4 litre
Electricity 230V/2200W
Waterconnection ½”outsidethread
Capacity:
Cups of coffee 200cups/filling
Ingredientscanisters 3st.(coffee, chocolate,topping).
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
3.

3. Overview of components , membranswitch. Future TT
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
4.
Drink 1 Drink 5
Drink 2 Drink 6
Drink 3 Drink 7
Drink 4 Drink 8
Membranswitch

Water outlet
(warm and chilled
drinks)
Drip tray
(withdrainage function)
Display
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
5.
3. Overview of components , front Future TT
Key switch
(cup and jug choice)
Membran switch
8 choices of
drinks
Door lock
Strenght of
drinks ++ / - -
Drip tray insert

Chute
Mixer bowls
Ingredients-
canister
Ingredients-
canister
Ingredients-
canister
Brewing
mechanism
3. Overview of components , mixer system Future TT
Eminence
1234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789
0
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789
0
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789
0
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789
0
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789
0
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789
0
1234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
6.
FUSE holder
ON/OFF-
switch
Detail; Ingredients; Width; Height; Volume/litre; Amount/unit
Canister; coffee 160 250 5,3 ´ 1
Canister; choco 80 250 2,55 1
Canister; topping 80 250 2,55 1
Outlet

12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
4. Service. Installation and start Future TT
1. Locatethe machine ona flat leveland waterproofsurface.
Connectthe electricalplug toa separate
grounded wall socket 230V 10A.
OBSERVE! Make sure there is a space
behindthe machine for free flowof air.(minimum10cm).
2. Connect attachedwater tubeto cold water with an R 1/2”.
Makesurethat thewater hose notare kinked anywherewhen machine ispushed
intoplace.
Pleaseflush the watertube before connectingto machine,thisto avoidany
particlestodestroy the inletvalve.
3. Openthewaterinlet.
4. Turnontheswitch insidethedoor.
Water is been filled into the tank
automatically with 2,4 litres of water.
Theheatingwill notstartbefore the water
levelreachesthelevelsensor.
Set temperature is approx. 97ºC.
5. Close door.
7.
4.

12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
8.
4. Service. Installation and start Future TT
6. Fill canisters with ingredients.
Take out(thisto avoid unnecessery
spillagein the machine)ingredient
canistersandfill themwithingredients.
7. When placing the ingredient canisters;
Makesure that theoutlet pipeson the ingredientcanisters aretouching the
steamtraps (B)and that thecoffee powderwill fallinto thecentre of thebrew
mechanism(A).
Whenthe water isheated uptoright temperature
thetext ”please wait” will disappearand ”please wait”
the machine is ready to use.
(B).
(A).

12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
Brewing of coffe etc. in a cup
1. Placea cupin thecentre ofthe cupholder.
2. The strenght has a standard setting,
if you wish to increase or decrease it, do as
follows, ifnot continue to point3.
Stronger drink;
Increase by pushing + or ++ for 5% or 10%
alternative
Weaker drink;
Decrease by pushing - or -- for 5% or 10%
(theindication lampwill goup ordown
dependingof choice).
3. Choosedrink by pushingon the
buttontothe right ofeachmenu
Thedisplaywill show;”Pleasewait”,
andthelight on thecup will lightup.
4. Waituntilthelight oncupandthe text
”Pleasewait” has beenturned off
beforeyoutake your cup.
5. Enjoyyourdrink.
9.
5. DRIFT; Brewing of coffee in cup Future TT
2.
1.

5. DRIFT; Brewing of coffee into jug. Future TT
Brewing of jug.
1. Placea jugin thecentre ofdrip tray. (For jug1,8Ldismantle driptray).
Serving pot1, 8L: Serving pot 1,2L: art.nr. 1103091
art.nr.110001 Thermos pot 1L : art.nr. 1103251
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
10.
1.
2. Turnonthekey withjugsymboleclockwise.
3. 6cups ofbrewing is standard settings,
Changeamountof cupsbypushing + or-button.
Optionalup to12 cups or down to1 cupbrewing.
4. Push button for drink 1.
5. Waituntil the lightand text”Pleasewait” hasbeen
turnedoffbefore you takeoutthe jug.
6. Servea jugwith goodcoffee.
2.
3.
4.

1. Turn the key slowly ninety degress and back again.
2. Push button for drink 1 in 6 seconds.
After 4 seconds a signal will go faster.
3. After 6 seconds The display shows; ”Open door”
”load detergent”.
4. Fill 25gr detergent (one portion bag) in to the brew
mechanism. (Detergent will be supplied from your
retaildealer)
The display shows; ”Close door”
The display shows; ” When ready press key”
Place a jug into the drip tray.
5. Push button for drink 1
The display shows; ”Cleaning mixer” (2....)
The display shows: ”Rinsing coffee” ”Soak time:”
The machine start to count down from 300 seconds.
The display shows. ”Brewer cycle” the machine is counting down.
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
11.
Automatic cleaning of brew mechanism, mixing bowl:
Shall been done every week.
The brewmechanism can easily be cleaned with the key switch in ”cup” (normal) position.
6. Cleaning program CLEANING Future TT
6. Push ”+” button in 6 seconds
The display shows: ”Change paper/Rotate” ”Push E/ +”
7. Push button for drink 2.
The display shows; ”Preparing paperload”.
8. The machine will rotate in position.
The display shows,”Change paper”
9. Open door, dismantle, clean and reassemble brew house.
page 12.
10. Close door.
11. Machine is ready to use again.
12. Take out a cup of coffee and waste it, just to make sure
that there is nothing left of detergent.
IMPORTANT! Dismantling and cleaning/washing brew house:
After the automatic cleaning program is finished. Clean brew house! This must be done, to make sure
that you will remove residual detergents and coffee remnants! Do as follow in paragraph 10- 19.
(See fig. 1,2,3,4 page11).
If machine not will go
back in start position.
Restart machine.
B.
1.
5.
6.
7.
2.
To stop cleaning process: push ”Stop” button.The brew mechanism will go back to start position.
NOTE! Dont stop the process when detergent has been loaded. Then the cleaning must be finished.

12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
12.
6. Cleaning program CLEANING Future TT
Dismantling and cleaning/washing brew house:
Dismantle brew house:
1. 2.
4. Reassemble brew house.
NOTE! When reassemble brew house
make sure that (B) wiper are
between (A) arms.
3. Flush brew house!
To removedetergentand coffeeremnants.

Themixer bowls caneasily becleaned with thekey
switchin”cup” (normal)position.
By cleaning means that water is flushed and whipper motor rotates.
1234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789
0
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789
0
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789
0
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789
0
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789
0
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789
0
1234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
13.
6. Cleaning program. CLEANING Future TT
1. Place a jug under the outlet..
(dismantledriptray).
2. Turnthekey(2)slowly ninety degreesand
back again.
3. Push button for drink 3 in 6 seconds.
After4 secondsa signal willgo faster.
After6 seconds the mixer bowl starts to be
cleanedin 10seconds.
The display shows: ”Cleaning mixer 2”.
Automatic cleaning of mixing bowl.
If you only wish to clean the mixer bowl ; Follow these instructions:
1.
3.
2.

12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
14.
6. Cleaning program CLEANING Future TT
Automatic cleaning of In/Outlet valves:
The In/Outlet valves can easily be cleaned with the key switch in ”cup” (normal)
position.
1.
5.
2. Turn thekeyslowly ninety degreesandback
again.
3. Push buttons for drinks 1 and 2 at the same
time in 6 seconds.
Keep buttons down.
1. Place a jug under the outlet.
(dismantledriptray).
4. AllIn/Outletvalveswill now starttoopenandclose
with2 pulses/secondin 10seconds orso longyou
pushedthebuttons.
Thedisplayshows:”Cleaningvalves”.
5. Push button for drink 1 for making a brew
cycleandflush remainingwaterand scalefrom
thecleaning.
By cleaning is meant that valves
”knocks” away eventual scale and other
particles which has been attached in the
cylinders and that they are flushed away
with the water.
3.
2.
3.

12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
15.
6. Cleaning program CLEANING Future TT
1. Push ”+” button in 6 seconds
After 4 seconds a signal will go faster.
Thedisplay shows:”Changepaper/Rotate”
”PushE/+”
2. Push + button.
Thedisplayshows:”Rotatecyclewithoutwater”.
3. Push button for drink 1.
Thedisplayshows:”Rotate”
Thebrewmechanismrotate oneturnwithoutwater and
ingredientsand themechanism fallsinto positionif it has
beendismounted.
Observe! The push rod shall be in position
”8 o clock”
If not take out again and repeat the procedure.
Eight (8) o clock.
Rotate brew mechanism without water or ingredients:
The brew mechanism can be rotatedwithout water and ingredients with the key
switch in ”cup” (normal) position. To be used when brew mechanism has been
dismounted forwashing and shall be remounted.
2.
1.
3.

12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
16.
7. CLEANING: Weekly cleaning Future TT
(D)
Dismantle : Mixer system
1.
Loosenoutlethose (A) and
turnlockknob (B)
anti-clockwise.
3.
Loosenwhipper (D) pull
whipper straight out fromthe
machine.
(E)
(A)
(B) (C)
Cleaning
Wash these parts:
.6.
A. Mixerbowl
B. Steam trap
C. Whipper
D. Assemblyplate
Make sure this parts are dry
before use
2.
Loosenmixer bowl.
Pullapart (C).
4.
Turnlockknobanti-
clockwise.(E) untilit stops
5.Clean with a wet ragand
droughtdrily.

12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
17.
7. CLEANING: Weekly cleaning Future TT
REASSEMBLE: Mixer system
7.
Reassembletheassembly plateby turning
lock knob (F) clockwise. INSPECT gaskets.
pil (G).
9.
Assemblewhipper, pulluntil
youhear aclicking noise.(H).
10.
Assemble mixerbowl and steam
trap(J) see picture.
11.
Easilypushthe mixerbowl
towards,according to(K) andlock
withlockknob(L).Connect outlet
hose(M).
(NOTE!make surethat allwater
hoseare connectedat rightplace
(H)
(J)
(J)
(J)
(K)
(M)
(L)
(G)
F F
F
8.
Makesure that themotor whippersplane side
willbe inaccordance with the whippers plane
side.see next(G) and picture (H).
INSPECT
INSPECT

5. Remountthescreen assembly andclosethe door.Thenthe
machinewill return tostart positionand the machineis
readyforuse.
Ifmachine notwill go back in startposition. Restartmachine!
6. Take out acup ofcoffeeand waste it just to makesure that
thereisnothing leftofdetergent.
1234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789
0
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789
0
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789
0
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789
0
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789
0
1
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789
0
1234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
18.
8. Cleaning and maintenance. Cleaning Future TT
Dismantling; Cleaning or exchanging coffee filter.
A Tool dismantling coffee filter, following machine.
4. Soakthe screenassembly ina solutionof 25gr.
bleachin 3dlwater for amaximum of10 minutes.
Prolonged contact with bleachmay damagethe screenassembly.Once thisis
done,thescreen shouldthenbe thoroughlyrinsed with dishsoap and warmwater to
removeanyleftoverresidu
4.
1. Push ”+ button” in 6 seconds.
After6 secondsthe displayshows; ”Changepaper/
Rotate” ”PushE/+”.
2. Push button for drink 2.
The display shows; ”Preparing paperload”.
3. Themachine will rotatein position.
Display shows,”Change paper”
openthedoor andinsertthe extractor toolthrough
thebrewer spout allthe wayto theback of the
cylinder,then slideitup untilcontactismade withthe
screenassembly. Pushupon therear of thescreen
assemblyuntilit popsout of thecylinder.
.10 minutes
.3 dl water
97º Celsius
Cleaning agent: (brew mechanism) CoffeeQueen artikelnr 1104161
Filter: (brew mechanism) Coffee Queenartikelnr 47200211
Tool: (dismantling filter) CoffeeQueen artikel nr 4720090
1.
2.
Cleaning of coffee filter
Dismantling coffee filter

Outside cleaning; use a soft rag
and liquid cleaning agent which
not scratch.
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
19.
8. Cleaning and maintenance CLEANING Future TT
Outside cleaning;

12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890
1
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012123456789012345678901
20.
9. Cup counter -Easy Access Future TT
1. Push ”-” button in 6 seconds.
After 4 seconds a signal will go faster.
The display shows: ”Total xxx cups”
2. Push button for drink 2.
display shows: ”Choise 1 free xxx cups”
3. Push button for drink 2.
display shows ”Choise 1 coin xxx cups”
4. Push button for drink 2.
display shows ”Choise 1 xxx cups in can”
5. Push”+” buttonto reachto ”choise2” etc.
6. Push button for drink 3 ,to reset the
counter.
7. Push”Stop” button to goback touser mode.
Cup counter:
The machine has an in built cup
counter which is available to
see and reset with the key switch in
”cup” (normal) position.
Easy Access:
Water and ingredient amount can be
adjusted with±15% with the key switch
in ”cup” (normal) position.
1. Push ”+” and ”-” button at the same time.
After 4 secondsa signal will go faster.
The display shows: ”Easy access” ”Conc 1
100%”
2. Gotoright button(choise whichyouwant to
changeby pushing”+”or ”-” button.
3. Push button for drink 2.
Thedisplay shows:for example.
Volyme 4 and” Blinking 100%”
4. Changebypushing ”+” or”-”button.
5. Push button for drink 2, for entering the
change.
6. Press ”stop” to quit.
7.
5.
6. 1.
2. 3. 4. 3. 5. 1.
6.
