Cold Jet AERO 2 PCS 60 User manual

Original Instructions [English] 2202060730 REV D
PCS®60
Operator Manual

iii
Copyright © 2021 Cold Jet, LLC
All rights reserved. Printed in the USA.
Due to continued product development this information may change without notice. The
information and intellectual property contained herein is condential between Cold Jet and the
client and remains the exclusive property of Cold Jet. If you nd any problems in the documentation,
please report them to us in writing. Cold Jet does not warrant that this document is error-free.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any
form or by any means, electronic, mechanical, photocopying, recording or otherwise without the
prior written permission of Cold Jet.
This manual reects the product conguration as was current at the time of its writing. An item’s
display in this manual does not guarantee the item’s availability at any time in the future. Images
shown are for representation purposes only. Products may vary from the images displayed. Cold Jet
is not liable for typographical errors or changes to specications presented.
Contents
Introduction ........................................................................................................................................................1
Safety ....................................................................................................................................................................3
PCS 60 System Description.............................................................................................................................7
Operations ........................................................................................................................................................19
Cold Jet CONNECT®........................................................................................................................................37
Maintenance.....................................................................................................................................................41
Warranty ............................................................................................................................................................42
Technical Schematics......................................................................................................................................45
Contact Information........................................................................................................................................56

v
System Identication
Locate the data plate for this machine and record the information provided in the spaces below. To
view documentation for your machine, scan the QR code:
ASSEMBLY No. _____________________________________________________________________________________________________
SERIAL No. _________________________________________________________________________________________________________
ELECTRICAL No. ____________________________________________________________________________________________________
AC VOLTS ___________________________________________________________________________________________________________
PHASE _______________________________________________________________________________________________________________
FREQUENCY ________________________________________________________________________________________________________
AMPS ________________________________________________________________________________________________________________
MAX OPERATION PRESSURE ______________________________________________________________________________________
MOTOR KW _________________________________________________________________________________________________________
Mo./Yr. ______________________________________________________________________________________________________________
SCCR_________________________________________________________________________________________________________________
Supplier Responsible for the Equipment:
Cold Jet, LLC
455 Wards Corner Road
Loveland, Ohio 45140 USA
Phone: [phone]
Website: www.coldjet.com

1
Introduction
About This Manual
This manual should be kept with the machine and be readily accessible to machine operators and
maintenance personnel.
This manual contains information on the safety, transportation, operation, and maintenance of this
machine.
The graphics used in this manual may show machine details that may be dierent than the actual
machine. Components of the machine may have been removed for illustrative purposes or the
continuing improvement of the machine’s design may cause changes that are not included in this
publication.
The owner of this machine is responsible for verifying the operator of this machine is properly
trained and understands the contents of this manual.
About The PCS 60
This machine combines patented technology in a lightweight and compact design that gives the
operator unparalleled control for dry ice cleaning and other applications.
yThe Advanced Air-Flow System reduces pressure loss as the air ows straight through the
system which also decreases sublimation and loss of the dry ice particles.
yThe Blast Pressure Control System can be regulated digitally from the 7” HMI color screen on
the control panel or certain applicators.
yThe Sure Flow System with Dynamic Agitation is designed to keep warm air, moisture, and
debris out of the hopper while keeping the dry ice owing. The level of dry ice in the hopper
can be monitored from the HMI screen of the control panel or certain applicators.
yThe Advanced Direct Drive Feeding System is a two-stage feeding system that improves feed
rate consistency and maximizes dry ice particle integrity.
yThis machine includes a Particle Control SystemTM brand blast media resizer that allows the
operator to control the size of dry ice particles being blasted from 0.3 mm micro-particles
to 3.0 mm pellets. The PCS is designed to precision-cut dry ice pellets into diamond-shaped
particles.
Environmental Impact
Dry ice is a safe, clean, and non-toxic medium approved by the EPA, USDA, and FDA. The dry ice
used in this machine is made from reclaimed CO2generated from other industrial processes.

3
Safety
General Safety Guidelines
This machine is designed to comply with international design standards and the European
Machinery Directives. Therefore, using the machine does not pose a risk to the operator when the
instructions in this manual are followed carefully. However, certain precautions must be followed
during its use. To understand all the necessary precautions, the machine operator must read the
entire manual before operating or performing maintenance on the machine.
Operation and maintenance should only be performed by authorized and trained personnel. Below
are some basic safety guidelines:
yFollow local governing codes to ensure a minimum standard of safety.
yWear protective gloves, eye protection, and hearing protection.
yOperate the machine in a well-ventilated work area.
yFollow the prescribed maintenance schedule (see “Maintenance” on page <?>).
yStart up and shut down the machine according to the instructions in this manual.
yDo not operate a machine that is damaged or in disrepair.
yDo not store objects on top of machine hopper.
CO2 Safety
This machine uses dry ice (CO2 in solid form). The temperature of dry ice is -109°F (-78.9°C). Avoid
coming into direct contact with dry ice as it may cause severe tissue damage.
Study the material safety data sheet (MSDS) of dry ice (CO2) supplied with the delivery of dry ice and
follow all the recommendations and guidelines listed therein.
Operate the blaster in a well-ventilated work area with continuous CO2 -level monitoring. The eects
of CO2 are entirely independent of the eects of oxygen deciency. Therefore, CO2concentrations
at 3-5% causes headaches, fast breathing and discomfort while higher concentrations may cause
unconsciousness, suocation or respiratory arrest. The legal exposure limit set by OSHA is a 0.5%
average over an 8-hour workday and the acute (15 minute) exposure limit set is 3.0%.
Always use a CO2 monitoring/alarm system when working with machinery that emits CO2in a
conned room/space.
Electrostatic Discharge
Dry ice blasting may create electrostatic discharges. This machine is tted with eective electrostatic
dischargers to prevent injury or damage. Also, the machine must be plugged into a properly
grounded electrical outlet.
It is recommended to avoid operating the machine near explosive or ammable material. Also, use a
plastic shovel when handling dry ice to eliminate any electrostatic discharge.

4 5
Safety Labels
The symbols used on the machine were developed by the International Organization for
Standardization (ISO) and are dened below. These symbols may include yellow warnings triangles,
blue mandatory action circles, or red prohibited action circles.
Symbol Denition
General Warning
Cold Temperature Warning
Pressurized Material Ejection Hazards
Electrostatic Discharge Warning
Asphyxiation Warning
Hand Crushing Warning
Wear protective gloves.
Wear hearing protection.
Wear eye protection.
Read operator and maintenance manual.
Do not operate without Safeguard Grate/guard in place.
No foreign objects allowed inside machine.
CO2is in use.
Symbol Denition
Protective Earth/Ground
Frame/Chassis Terminal
There may be other safety labels or warning signs on the machine that contain additional
information regarding potential safety hazards not explained in this manual. Operators and
maintenance personnel should familiarize themselves with these safety labels and warning signs.
Replace any safety labels or warning signs if they become damaged, missing, or illegible.
Cautions and Warnings
Please review the following cautions and warnings before operating or performing maintenance on
the machine.
CAUTION Read the instructions before using the machine. Only qualied personnel
should operate the PCS 60.
WARNING Ensure adequate ventilation when operating this equipment to prevent the
build-up of carbon dioxide gas. If used indoors or other conned space, a CO2
detector should be used to monitor for excessive unsafe levels of CO2gas,
and provide a suitable warning. The legal exposure limit set by OSHA is a 0.5%
average over an 8-hour workday.
WARNING Ensure that expended dry ice pellet emissions are not in the vicinity of air
ventilation.
WARNING This machine has been designed for use with 3mm dry ice pellets
recommended by Cold Jet. The use of other cleaning agents or chemicals may
adversely aect the safety of the machine.
WARNING High pressure blast streams can be dangerous if subject to misuse. The blast
stream must never be directed at persons, live electrical equipment or the
machine itself.
WARNING Do not use the machine within range of persons unless they wear the
personal protective equipment. (PPE)
WARNING Do not direct the blast stream against yourself or others in order to clean
clothes or foot-wear.

6 7
PCS 60 System Description
The PCS 60 may be supplied with the Performance Kit or the Precision Kit or both depending
on what was ordered. An optional Advanced Applicator is available upon request. The standard
applicator kits are as follows:
Performance Kit
y3/4 in or 1in Performance Applicator
yPerformance nozzle
yNozzle handle
y1in Air supply hose 25 ft (7.62 meters)
y3/4 in or 1in Hybrid-Flex blast hose 20 ft (6.09 meters)
yHose carrier
yHose wrap
Precision Kit
y1/2 in Precision Applicator
y2 Precision nozzles
y1in Air supply hose 25 ft (7.62 meters)
y1/2 in Hybrid-Flex blast hose 12 ft (3.66 meters)
yHose carrier
yHose Wrap
WARNING High pressure cleaners shall not be used by children or untrained personnel.
WARNING High pressure hoses, ttings and couplings are important for the safety of the
machine. Use only hoses, ttings and couplings recommended by Cold Jet.
WARNING To ensure machine safety, use only original spare parts from Cold Jet or
approved by Cold Jet.
WARNING The applicator and applicator hose contain electrical connections. Do not
immerse in water.
WARNING Do not use the machine if a supply cord or important parts of the machine are
damaged, e.g. safety devices, high pressure hoses, applicator.
WARNING Inadequate extension cords can be dangerous. If an extension cord is used, it
shall be suitable for the environment in which it is used, if used outdoors the
connection has to be kept dry and o the ground. It is recommended that this
is accomplished by means of a cord reel which keeps the socket at least 2.4
inches (60 mm) above the ground.
WARNING Always switch o the main disconnecting switch, or unplug the blaster power
cord when leaving the machine unattended.

8 9
PCS 60 Data
Dimensions 38.75 x 18.98 x 45.03 in (984.33 x 482.21 x 1143.82 mm)
Weight 269 lb (122 kg)
Blast Medium 3 mm dry ice pellets
Hopper Capacity 60 lb (27 kg)
Power Requirement 110/220 VAC (50/60 Hz) 4.5A
Air Supply Pressure 40-145 psi (2.8-10 bar)
Air Flow 12-100 cfm at 80 psi (0.33-2.83 m3/min at 5.5 bar)
Air Flow Line ¾ in (19 mm) straight-through
Blast Pressure 20-145 psi (1.4-10 bar)
Variable Feed Rate 0-4 lb/min (0-1.8 kg/min)
Blast Particle Size 3.0 mm to 0.3 mm (Variable Particle Size Controls)
Air Hose 1in (25.4 mm) Air Supply Hose
Blast Hose
½ in (12.7 mm) Advanced combination material ex hose (low ow)
¾ in (19 mm) Advanced combination material ex hose (medium ow)
1in (25.4 mm) Advanced combination material ex hose (standard)
Applicator
½ in (12.7 mm) Precision Applicator with on/o; air only; light control
¾ in (19 mm) Performance Applicator with on/o; air only; light control
1in (25.4 mm) Performance Applicator with on/o; air only; light control
1in (25.4 mm) Advanced Applicator with on/o; air only; light control; particle
adjust and ow control
¾ in (19 mm) Advanced Applicator with on/o; air only; light control; particle
adjust and ow control, blasting pressure, and dry ice feed rate
1in (25.4 mm) Heavy Duty Applicator with on/o; air only; light control; blasting
pressure, and dry ice feed rate
Control/Display 7 in (17.7 cm) LCD screen with rotary encoder dial
Communication IoT connectivity via a cellular 3G/LTE Global and Cold Jet Connect®
Integration Automation/Integration capable with PLC controlled system (Integration
upgrade is optional)
Noise Level
Noise level 60 dB(A) up to 130 dB(A)
The PCS 60 has many features such as Nozzle selection, air pressure settings, hose sizes and
pellet size. The material or materials and surrounding environment will also be key to actual
sound pressure levels at the machine or the blast area.
PCS 60 Components
Hopper Lid
Parking Brake
Power Supply Connection
Blast Cable Connection
Blast Hose Connection
Emergency Stop
Static Ground Reel
HMI Screen
Rotary Encoder Dial
Power Button

10 11
Performance Applicator Components
Nozzle
Applicator Controls
Blast Hose Connection
Applicator Control Cable
Performance Applicator Nozzles
There are several dierent styles of nozzles, depending on the application the PCS was ordered
for. The table below can be used to help with initial settings as you set up the PCS 60 for operation.
Specialty nozzles available on request.
Low and Standard Flow Nozzles
These straight nozzles have standard air consumption rate of 100 cfm or less at 80 psi.
Nozzle Air Consumption Blast Swath Dry Ice Feed rate Length Material
106S.6 50cfm @ 80psi
1.4m3/min @ 5.5 bar
0.6 in
15 mm
1-3 lbs/min
0.5-1.4 kg/min
6 in
152 mm
Anodized
Aluminum
110S.6 50cfm @ 80psi
1.4m3/min @ 5.5 bar
0.6 in
15 mm
1-3 lbs/min
0.5-1.4 kg/min
10 in
254 mm
Anodized
Aluminum
123S.7 50cfm @ 80psi
1.4m3/min @ 5.5 bar
0.7 in
18 mm
1-3 lbs/min
0.5-1.4 kg/min
23 in
584mm
Anodized
Aluminum
310S.5 100cfm @ 80psi
2.8m3/min @ 5.5 bar
0.45 in
11mm
2-4 lbs/min
0.9-1.8 kg/min
10 in
254mm Aluminum
312S1 100cfm @ 80psi
2.8m3/min @ 5.5 bar
1 in
25mm
2-4 lbs/min
0.9-1.8 kg/min
12 in
305mm Aluminum
323S1 100cfm @ 80psi
2.8m3/min @ 5.5 bar
1”
25 mm
2-4 lbs/min
0.9-1.8 kg/min
23 in
584 mm Aluminum
312S2 100cfm @ 80psi
2.8m3/min @ 5.5 bar
1.8 in
46 mm
2-4 lbs/min
0.9-1.8 kg/min
12 in
305 mm Aluminum
308.S4 60cfm @ 80psi
1.7m3/min @ 5.5 bar
0.4 in
10 mm
1-3 lbs/min
0.5-1.4 kg/min
8 in
203 mm Aluminum
Trigger
Trigger Safety
Applicator Lights
Specialty Nozzles
These nozzles have various congurations for special applications and operation.
Nozzle Air Consumption Blast Swath Dry Ice Feed rate Length Material
112HK 70cfm @ 80psi
2.0m3/min @ 5.5 bar
0.25 in
(0.6 cm)
1-3 lbs/min
0.5-1.4 kg/min
12 x 2 in
(30.5 x 5.1 cm)
Polymer
Coated SST
114P.5 70cfm @ 80psi
2.0m3/min @ 5.5 bar
0.25 in
(0.6 cm)
1-3 lbs/min
0.5-1.4 kg/min
10.3 in
(26.2 cm) Polymer
307A135V.8 100cfm @ 80psi
2.8m3/min @ 5.5 bar
0.75 in
(1.9 cm)
2-4 lbs/min
0.9-1.8 kg/min
7.3 X 6.3 in
(18.6 x 16 cm)
Polymer
Coated SST
307A45H1 100cfm @ 80psi
2.8m3/min @ 5.5 bar
1 in
(2.5 cm)
2-4 lbs/min
0.9-1.8 kg/min
7.3 x 5 in
(18.6 x 12.7 cm)
Polymer
Coated SST
307A90H.8 100cfm @ 80psi
2.8m3/min @ 5.5 bar
0.75 in
(1.9 cm)
2-4 lbs/min
0.9-1.8 kg/min
7 x 5.3 in
(17.8 x 13.5 cm)
Polymer
Coated SST
307A90V1 100cfm @ 80psi
2.8m3/min @ 5.5 bar
1 in
(2.5 cm)
2-4 lbs/min
0.9-1.8 kg/min
7.3 x 7 in
186 x 178 mm
Polymer
Coated SST
308A45H.8 100cfm @ 80psi
2.8m3/min @ 5.5 bar
0.75 in
(1.9 cm)
2-4 lbs/min
0.9-1.8 kg/min
7.7 x 3.5 in
(19.6 x 8.9 cm)
Polymer
Coated SST
308A45V.8 100cfm @ 80psi
2.8m3/min @ 5.5 bar
0.75 in
(1.9 cm)
2-4 lbs/min
0.9-1.8 kg/min
7.7 x 3.5 in
(19.6 x 8.9 cm)
Polymer
Coated SST
309A45H.8 120cfm @ 80psi
3.4m3/min @ 5.5 bar
0.75 in
(1.9 cm)
3-5 lbs/min
1.4-2.3 kg/min
8.9 x 4 in
(22.6 x 10.2 cm) Aluminum
317A90H1 100cfm @ 80psi
2.8m3/min @ 5.5 bar
1 in
(2.5 cm)
2-4 lbs/min
0.9-1.8 kg/min
16.6 x 3.4 in
(42.2 x 8.6 cm)
Polymer
Coated SST
509C 150cfm @ 80psi
4.3m3/min @ 5.5 bar N/A 3-5 lbs/min 1.4-2.3 kg/min
9 in
(22.9 cm) Multi

12 13
Precision Applicator Components
Precision Applicator Nozzles
Nozzle Air Consumption Blast Swath Dry Ice Feed Rate Length Material
(MC13)
Yellow
12 CFM@80 psi
(0.3 m3/min 5.5 bar)
0.13 in
(.3 cm)
0.1-0.4 lbs/min
.05-0.2 kg/min
6 in
(15.2 cm) Plastic
(MC19)
White
30 CFM@80 psi
(0.8 m3/min 5.5 bar)
0.19 in
(.5 cm)
0.2-1.0 lbs/min
0.1-0.5 kg/min
6 in
(15.2 cm) Plastic
(MC31)
Blue
50 CFM@80 psi
(1.5 m3/min 5.5 bar)
0.31 in
(.8 cm)
0.5-1.2 lbs/min
0.2-0.6 kg/min
6 in
(15.2 cm) Plastic
Fan Nozzles
(MC47)
25 CFM@80 psi
(0.7 m3/min 5.5 bar)
Fan
0.47 in
(1.2 cm)
0.2-1 lbs/min
0.1-0.5 kg/min
6 in
(15.2 cm)
Plastic &
Aluminum
(MC28)
25 CFM@80 psi
(0.7 m3/min 5.5 bar)
Fan
.28 in
(.7 cm)
.2-1 lbs/min
0.1-0.5 kg/min
6 in
(15.2 cm)
Plastic &
Aluminum
(MC35)
25 CFM@80 psi
(0.7 m3/min 5.5 bar)
Fan
0.35 in
(.9 cm)
0.2-1 lbs/min
0.1-0.5 kg/min
6 in
(15.2 cm)
Plastic &
Aluminum
(MC88F)
25 CFM@80 psi
(0.7 m3/min 5.5 bar)
Fragmenting Fan
0.88 in
(2.2) cm
0.2-1 lbs/min
0.1-0.5 kg/min
5 in
(12.7 cm)
Plastic &
Aluminum
(MC88)
30 CFM@80 psi
(0.9 m3/min 5.5 bar)
Fan
0.88 in
(2.2 cm)
0.5-1.2 lbs/min
0.2-0.6 kg/min
5 in
(12.7 cm)
Plastic &
Aluminum
Nozzle Air Consumption Blast Swath Dry Ice Feed Rate Length Material
Angled Nozzles
(MC25A45) 25 CFM
0.7 m3/min
0.25 in
(.6 cm)
0.2-1 lbs/min
0.1-0.5 kg/min
6 in
(15.2
cm)
Plastic
(MC25A90) 25 CFM
0.7 m3/min
0.25 in
(.6 cm)
0.2-1 lbs/min
0.1-0.5 kg/min
6 in
(15.2
cm)
Plastic
Advanced Nozzles
(MC26M) 35 CFM
1.0 m3/min
0.26 in
(.7 cm)
0.2-1.2 lbs/min
0.1-0.6 kg/min
5 in
(12.7
cm)
Plastic &
Aluminim
(MC29MH) 50 CFM
1.5 m3/min
0.29 in
(.7 cm)
0.5-1.2 lbs/min
0.2-0.6 kg/min
6 in
(15.2
cm)
Plastic &
Aluminim
(MC50AL) 36 cfm @ 80 psi
(1.0 m3/min 5.5 bar)
0.50 in
(1.3 cm
0.2 - 1.2 lbs/min
0.1 - 0.5 kg/min
2.4 in
(6.1 cm) Aluminum
(MC31AL) 25cfm @80 psi
(0.7 m3/min 5.5 bar)
0.31 in
(.8 cm)
0.2 - 1.2 lbs/min
0.1 - 0.5 kg/min
7.0 in
(17.8
cm)
Aluminum
(MC57) 50cfm @80 psi
(1.5 m3/min 5.5 bar)
0.57 in
(1.4 cm)
0.5-1.2 lbs/min
0.2-0.6 kg/min
7.3 in
(18.5
cm)
Aluminum

14 15
Advanced Applicator Components*
Light Control
Blast Hose Connection
Increase/Decrease Particle Size
Status Light
Increase/Decrease Feed Rate
Applicator Control Cable
Increase/Decrease Pressure
Air & Dry Ice
Air Only
Lights
Trigger
Trigger Safety
Nozzle
*The following bullets are the functions of the New Advanced applicator feed rate, blast pressure, and particle size:
yIncrease/decrease feed rate – adjust in increments of 0.2 lbs. with each button click;
metric increments will be 0.5 kg
yIncrease/decrease blast pressure – adjust in increments of 10 psi ; metric increments will
be 1 bar
yParticle size – adjust in increments of 0.1 mm
Control Panel and HMI Screens
This PCS 60 uses a rotary encoder dial that allows the operator to navigate, select and adjust
settings on the control panel screen. You must rst press the rotary encoder to activate navigation.
Navigate between options by turning the rotary encoder dial left or right; this will highlight the option
in blue. Once the desired option is highlighted, simply press the dial to select it; this will highlight the
option in green. With the option selected (green), turn the rotary encoder dial left or right to adjust
the setting then press again to accept.
Some options can be adjusted directly from the home screen while other options can be found on
other screens. To access these other screens using the rotary encoder dial, navigate to the settings
screen and press to select. Continue to navigate through the screens (i.e. recipe, status, applicator,
advanced, reset, settings) and adjust the settings as needed by turning and pressing the rotary
encoder dial.
When not being used, the screen on the control panel will display a screen saver with feed rate,
particle size, air pressure, blast pressure and hopper level. Press the rotary encoder dial to bring up
the home screen.
Figure 1: Control Panel and Rotary Encoder Dial

16 17
There are two screen states for the PCS 60. A blue screen (home screen) which is the system
operating and settings screen. A black screen indicates that the PCS 60 is in the advanced settings
or the recipe screen. Changes can be made in each screen.
Figure 2: Home Screen
Figure 3: Settings Screen
Figure 4: Hopper Level Indicator
During operation, some items on the screen will indicate level or failure mode by changing colors.
Green is normal, yellow or orange is a warning and red is critical and needs attention. The above
illustration indicates the level of the dry ice in the hopper.
Figure 5: Numeric Color Indicator
Numbers change states much like the hopper levels. White is normal, orange is warning, and red is
critical.

19
Operations
Unpacking the PCS 60 System
This machine has been assembled and tested as one unit prior to shipment. Follow the steps below
to inspect and unpack the machine from the shipping container.
1. Examine the shipping container for any damages that may have occurred during transport.
2. Remove the machine, recyclable box(es) that contain accessories, and the packaging can be
recycled.
3. Examine the machine for any external damage that may have occurred during transport.
4. Remove the back housing of the machine and examine the machine for any internal damage
that may have occurred during transport.
Refer to the packing slip for a list of the components shipped with the machine. Contact Cold Jet if
any damage has occurred to the shipping container or the machine (see “Contact Information” on
page 19).
The following sections describe the unpacking, moving and transporting, and operations of the PCS
60. Read and follow all instructions prior to using the PCS 60.
WARNING Only trained and or certied personnel should operate or rig the PCS 60 for
shipment or movement.
Transport and Storage
The following instructions are for proper transport of the PCS 60. Follow all instructions as illustrated
to avoid damaging the PCS 60. It is recommended that only trained and qualied personnel use and
move the PCS 60.

20 21
To transport the PCS 60, use the methods illustrated:
Do not strap over the console as this could damage the screen and components for operating the
PCS 60. Strap the PCS 60 transversely as shown. Strapping the PCS 60 for long periods of time is not
advised.
To transport short distances using a fork lift, use the method illustrated:
Secure the PCS 60 before lifting or moving on a fork lift to prevent it from sliding or falling o. Lift the
tires a 3-5 inches (8.5-12.5 cm) o the ground to move the machine.
To lift the PCS 60, use the method illustrated:
WARNING Do not lift the PCS 60 using the front handle bar, upper handle bar, or the
lower bumper as there will be no stability which could cause damage or harm
to personnel.
To store the PCS 60 see section Shutting Down the PCS 60 on page 30.
Personal Protective Equipment (PPE)
WARNING Only trained and or certied personnel should operate the PCS 60.
WARNING Do not operate the PCS 60 without proper PPE.
Prior to operating the PCS 60, or loading dry ice into the hopper, proper PPE must be used. It is
recommended that each operator is trained on the proper use of PPE.
Wear protective gloves.
Wear hearing protection.
Wear eye protection.
Read operator and maintenance manual.

22 23
Setting Up the PCS 60
WARNING Improper installation of hoses and adapters to the PCS 60 can cause damage
to the machine or the applicators.
Do not use one wrench when tightening or replacing ttings on the PCS 60 machine or the
applicators.
Always use two wrenches to install and remove hoses and accessories on the PCS 60 or the
applicators.
CAUTION When attaching the blast hose, make sure to put a 1” wrench on the SST base
connection of the rotary union. DO NOT rely on the polymer housing to keep
it from rotating. Any connections that are frozen should be thawed by running
air only through the applicator if machine has been in operation.
Follow the instructions below to set up the PCS 60:
1. Set the parking brake by pressing down (lift to release).
2. Attach the blast hose and control cable to the PCS 60.
Figure 6: Hose Conguration
Each machine is shipped with one 20’ “applicator” hose. If additional hose is needed, a “machine”
hose needs to be added. Any additional length requires “extension” hoses.
They may also be shipped with a 12’ applicator hose if the PCS 60 is ordered with Precision Kit only.
The reason for the dierent names is due to the quick disconnects (QDCs). Specic QDCs are
required to mate hoses of dierent sizes.
The “applicator” hose includes a QDC to connect directly to a machine by default, but will not
connect to a “machine” hose. The “machine” hose includes the QDC required to connect to an
applicator hose, so a swap is necessary.
3. Attach an applicator to the blast hose and control cable using the two supplied wrenches.

24 25
WARNING Do not use the applicator body or handle for leverage when tightening the the blast
hose to the applicator. Always use two wrenches to prevent damaging the applicator and ttings.
WARNING Do not tape, tie, or bind the blast hose and the control cable. The blast hose and
control cable are designed and tested to prevent cracking and damage. Constraining the design
exibility may void the control cable and blast hose warranty.
4. Attach a nozzle to the applicator.
5. Attach the ground reel to the article that is being blasted.
a. Pull out the ground reel to the distance needed to attach to the material being
blasted.
b. Relax the ground cable and the ground line will lock into position.
c. To reel the ground line back in, pull the ground line until it begins to spool back in
without locking. Do not let go of the ground line, feed it back into the spool until the
line is completely reeled back in.
Figure 7: Static Ground Reel
6. Attach the power cord to the PCS 60 and then to an appropriate electrical outlet (see “PCS
60 Data” on page 8). (The machine will go into a calibration mode which will take 20-30
seconds)
7. Loop the whip check around the air supply hose as illustrated and attach the air supply hose
to the front of the PLT 60.
CAUTION When connecting the air supply hose to the blaster, always run the hose
through the choker of the whip check in case of accidental disconnect
Figure 8: Whip Check
8. Attach the air supply hose to the front of the PCS 60.
Maximum air supply pressure is 145 psi (10 bar)
9. Turn the air supply on and allow the air hose to pressurize.
The PCS 60 automatically bleeds pressure when the e-stop is engaged,
the safety grate is open, the unit is powered o, and/or is disconnected
from its power source
10. Once the PCS 60 is set up, go to “Starting the PCS 60” on page 27.

26 27
Compressed Air Supply
For best results while blasting, incoming air supply must be as free of oil and dirt as possible.
It is recommended that the incoming supply air— lters, oil lters, and water separators are
continuously monitored to ensure the PCS 60 receives the air your machine use is specied for. The
compressed air must have a low moisture level for optimal and continued performance. The air
quality and standards are as follows:
ISO 8573.1 (2001) Compressed Air Quality Standard
Air Quality Classes
Class
Solid Particle
Maximum number of particles m3Water
Pressure
Dewpoint °C
Oil
(Incl. Vapour)
mg/m3
0.1 - 0.5 micron 0.5 - 1 micron 1.0 - 5 micron
1 100 1 0 -70 0.01
2 100,000 1,000 10 -40 0.1
3 - 10,000 500 -20 1
4 - - 1,000 3 5
5 - - 20,000 7 -
6 - - - 10 -
Cold Jet Blasting Conditions and Minimum Recommended Air Quality Classes
(ISO 8573.1:2010(E) Pressure Dewpoint Requirement Only)
1. Manual blasting, intermittent operation, with .12 inch (3mm) pellets (any density) - Class 4 or
lower.
2. Manual blasting, intermittent operation, with .04 inch (1mm) micropellets or smaller particles
(Particle Control System) - Class 2 or lower.
3. Automated blasting, continuous blasting 1 hour or more, with .12 inch (3mm) pellets (any
density) - Class 2 or lower.
4. Automated blasting, continuous blasting for any amount of time, with .04 inch (1mm)
micropellets or smaller particles (Particle Control System) - Class 1.
The air purity classication given in this part of ISO 8573 is intended to provide a guide to the air
purity expected in the compressed air system rather than resulting from the inclusion of a single
air treatment component. It should be recognized that achieving any given air purity specication
cannot be done exclusively by a combination of equipment; the specication of the correct
lubricants/coolants and the correct control of physical parameters, such as temperature, are also
required. The correct control of such parameters as temperature has an eect on the physical
state of the liquids, which can become aerosols or vapours. To maintain the air purity within a
compressed air system, it is considered essential that suppliers’ recommendations regarding
maintenance intervals be followed.
Starting the PCS 60
WARNING Never blast the display screen area of the PCS 60 with dry ice as this will cause
permanent damage to the screen.
Follow these instructions to start the blasting job:
1. On the control panel, press the power button to turn the PCS 60 on.
Figure 9: Power Button ON Status
2. Purge the system:
Always purge the system with compressed air during start-up, after
breaks, and before loading dry ice. This will remove any accumulated
moisture, water, and ice in the system.
a. On the Performance and Precision applicator, press the air+ice button (II) to activate
(green light indicates ON and pressing the II button again will set the system to OFF).
3. Using the rotary encoder dial, navigate to the feed rate indicator on the home screen and
adjust it to the maximum setting. The maximum feed rates in the PCS 60 change on the HMI
depending on what sized particle is selected. Max dry ice feed rates per particle size:
a. 0.3 & 0.4 mm - 2.5 lbs/min (1.13 kg/min)
b. 0.5 mm - 2.7 lbs/min (1.22 kg/min)
c. 0.6 mm - 2.8 lbs/min (1.27 kg/min)
d. 0.7 mm - 2.9 lbs/min (1.31 kg/min)
e. 0.8 to 2.9 lbs/min - 3.0 lbs/min (1.31-1.36 kg/min)
f. 3 mm - 4.0 lbs/min (1.81 kg/min)
4. If no ice has been loaded into the hopper for an extended period of time (days), then press
the air + ice button (II) and pull the trigger and blast for 2 minutes.
a. If ice has recently been loaded into the hopper but a break or delay in blast periods
has occurred, then press the air button (I) and pull the trigger for 2 minutess.
b. Set the feed rate to its minimal setting.

28 29
5. Load or reload dry ice into the hopper:
a. On the Performance and Precision applicator, press the air+ice button (II) to
deactivate (green light OFF). This will also deactivate the applicator.
b. On the PCS 60, open the hopper lid leaving the Safeguard Grate in place.
Opening the safeguard grate will cause the PCS 60 to shut down
automatically. The grate is a safeguard to prevent coming into contact
with the doser at the bottom of the hopper.
Safeguard Grate
Air Connection
Hopper Lid
c. Check the hopper for the presence of any foreign material or condensate and clean
or remove as necessary.
d. Load the hopper with 3 mm dry ice pellets.
CAUTION Use only 3mm dry ice pellets for blast media. The use of any other
media will lead to loss of warranty coverage
e. Close the lid.
The SureFlow Hopper system is a feature designed into the PCS 60 that will keep the dry ice owing
in the insulated hopper and a sealed lid while the hopper is in use and idle for a short period of
time. The vibrator for the PCS 60 will intermittently operate with short bursts to ensure the dry ice
continues owing or dropping toward the bottom of the hopper. The settings for the vibrator may
be changed by the operator in the advanced menu of the PCS 60 to adjust the frequency and time
of the vibrator. The PCS 60 is equipped with a magnetic switch on the safeguard grate for safety.
Should the safeguard grate be opened while the PCS 60 is operating, it will go into idle until it is
closed, at which time normal operations may begin. There is no need to set-up the machine again.
Blasting Dry Ice Particles
For optimum performance while blast cleaning with the performance applicator or the precision
applicator:
yPosition the PCS 60 and blast hose to prevent kinking and allow for maximum
maneuverability.
yHold the nozzle perpendicular to surface being cleaned at a distance of 2-6 inches
(5-15 cm).
yTo nd the optimum feed rate, start at 0 and gradually increase until the desired cleaning
result and/or cleaning performance is achieved.
yUse a lower feed rate when the air pressure is below 50 psi (3.4 bar).
Follow the instructions below to start blasting dry ice particles:
1. On the performance or the precision applicator, press the air/ice control (II) to activate (green
light ON).
2. It is recommended to start blasting next to the target (but in a safe place) and move onto the
target.
3. Move the nozzle back and forth keeping it perpendicular to the surface being cleaned.
4. Monitor the hopper level and reload dry ice pellets as needed:
a. On the applicator, the status light will be solid red when the hopper is full and start
ashing when the hopper level is low to empty.
b. On the control panel, the hopper level is indicated by the color of the hopper icon.
Green is full, yellow is half-full, and red is empty.
5. Adjust settings or select a recipe:
a. To adjust the settings:
i. Use the rotary encoder dial to adjust the feed rate, blast pressure and particle
size.
b. To select a recipe:
i. Use the rotary encoder dial to navigate to the Settings screen then to the
Recipe screen.
ii. Use rotary encoder dial to select the recipe menu and adjust it to the desired
recipe numbered 1-9 (see “Recipes” on page 33).

30 31
Shutting Down the PCS 60
Follow the instructions below to shut down the PCS 60:
Always remove any remaining dry ice from the hopper if shutting down
the PCS 60 for more than 15 minutes to prevent the internal mechanics
and/or nozzle from freezing.
1. Using a plastic scoop, remove any unused ice from the hopper then close the lid.
CAUTION Be careful to avoid coming into contact with the doser at the bottom of the
hopper
2. On the applicator:
a. Press the air button (I) to activate (blue light on).
b. Pull the trigger to blast for 10 seconds.
c. After blasting, press the air button (I) again to deactivate (blue light o). This should
also deactivate the applicator.
d. Remove nozzle from applicator
CAUTION Do not touch nozzle with bare hands during or immediately after
use. Always wear protective gloves
3. On the control panel, press the power button to turn the PCS 60 OFF.
4. Turn o the compressed air supply. The PCS 60 will automatically bleed any remaining
pressure.
There is no need to bleed the air pressure from the PCS 60. The PCS 60
automatically bleeds air pressure during proper shut down of the PCS
60. It also automatically bleeds for approximately two seconds every 30
minutes of trigger time during operation.
5. When all the air pressure is bled o, disconnect the air supply hose from the PCS 60.
6. Unplug the power cord from the PCS 60 by depressing the tangs on the cord collar.
7. If transporting the PCS 60 to a dierent location, disconnect all cables and hoses from the
PCS 60 rst and stow them on retractable hooks.
8. If storing the PCS 60, disconnect all cables and hoses and stow them on retractable hooks.
Store the PCS 60 in a dry space free of dirt and debris. Keep out of direct sunlight.

32 33
Password
The following screens describe how to lock the screen so that the blaster settings cannot be
changed.
1. From the settings screen, select “E” using the rotary encoder dial to access the screen lock
screen.
2. Using the rotary encoder dial, select the top blank line of the password entry screen and
press the dial once.
3. Select a number and press the dial again to enter the selected number.
4. Repeat until three numbers have been populated.
5. Dial to the bottom “save icon” and press the rotary encoder dial to save the password.
6. Repeat steps 1-4 to activate the screen lock.
7. The green “lock icon” in the upper left corner will change to red.
8. If the screen has been locked, repeat steps 1-4 with existing password and the screen will
unlock.
Recipes
The following screens describe the recipe functions for the PCS 60. Recipes are useful for saving
optimal settings for the machine for dierent types of surfaces. This saves time when switching from
one type of surface to another. Below describes how to save recipes and how to recall for use.
Figure 10: Recipe Screen
1. To access the Recipe screen:
a. From the Home screen, use the rotary encoder dial to select settings then recipes.
2. To select a recipe:
a. Using the rotary encoder dial, navigate to the Recipe Menu (A).
b. Rotate the dial left or right to scroll through recipes 1-9 (B).
c. Press the dial to select the desired recipe.
3. To create a recipe:
a. Using the rotary encoder dial, navigate to and adjust the Blast Pressure (C), Particle
Size (D), and Feed Rate (E).
b. Once settings are adjusted, navigate to numbered recipe (B) and press to save.
4. Using the rotary encoder dial, navigate to the home icon (F) and press to return to the Home
screen.
