Makita CL070D Series Manual

PRODUCT
P 1/ 6
T
ECHNICAL INFORMATION
7.2
1.0
10.8
1.3
1.2
1.8
[180mmH2O]
Li-ion
Models No.
Description
CONCEPT AND MAIN APPLICATIONS
Specification
Standard equipment
Optional accessories
CL070D, CL100D
Cordless Cleaner
Max. sealed suction: kPa [Column of water]
Max. air flow: m3/minute
Battery
Dust capacity: mL
Cell
Voltage: V
Capacity: Ah
Continuous use (approx.): minute 128
600
Suction power: W 14
Models CL070D and CL100D are handy cordless cleaners of
cloth filtration type powered by Makita Li-ion battery;
CL070D by 7.2V/1.0Ah battery BL7010,
CL100D by 10.8V/1.3Ah battery BL1013.
0.81 (1.8)*20.88 (1.9)*3
Net weight*1: kg (lbs)
Note: The standard equipment for the tool shown above may vary by country.
Nozzle assembly (T-nozzle) ........ 1
Pipe (Extension pipe) .................. 1
Sash nozzle ..................... 1
Sash nozzle holder .......... 1
Nozzle assembly (for rug/carpet)
Shelf brush
Flexible hose
Round brush
Battery BL7010 (CL070D only)
Battery BL1013 (CL100D only)
Charger DC07SA (CL070D only)
Charger DC10WA
Filter
Pre-filter
Filter (factory-mounted) ............... 1
Pre-filter (factory-mounted) ......... 1
Dimensions: mm (")
Width (W)
Height (H)
Length (L2) 966 (38)
Length (L1) 454 (17-7/8)
103 (4-1/16)
142 (5-5/8) 150 (5-7/8)
CL070D CL100D
L1: without T-nozzle and Extension pipe
L2: with T-nozzle and Extension pipe
These products are available in the following variations.
L2
L1
H
W
The models also includes the accessories listed below
in "Standard equipment".
CL070DS
CL070DZ
DC07SA
Model No. type quantity Charger
1
BL7010
(Li-ion 1.0Ah)
NoNo
Battery
CL070DZX
Ivory
Ivory
Makita-blue
Housing
color
CL070D
CL100D
CL100DW
CL100DZ
DC10WA
Model No. type quantity Charger
1
BL1013
(Li-ion 1.3Ah)
NoNo
Battery
CL100DZX
Ivory
Ivory
Makita-blue
Housing
color
Specification Model CL070D CL100D
*1 Weight according to EPTA-Procedure 01/2003
*2 with Battery BL7010, without T-nozzle and Extension pipe
*3 with Battery BL1013, without T-nozzle and Extension pipe

P 2/ 6
Repair
CAUTION: Remove the battery cartridge from the machine for safety before repair/
maintenance in accordance with the instruction manual!
[3] DISASSEMBLY/ASSEMBLY
[3]-1. Capsule Section
DISASSEMBLING
ASSEMBLING
Do the reverse of the disassembly steps. (Fig. 1)
2) Separate Capsule from Housing by pulling it
in the direction of the arrow.
3) Remove 4x18 Tapping screw and Flat washer 4.
Valve can now be disassembled from Capsule.
4x18 Tapping screw
Flat washer 4
Valve
Capsule
Pre-filter
Capsule section can be disassembled as illustrated in Fig. 1.
Capsule Housing
Mark
1) Align the Mark of Capsule with
that of Housing by turning Capsule
clockwise or counterclockwise.
Fig. 1
Capsule
Housing

P 3/ 6
Repair
[3] DISASSEMBLY/ASSEMBLY
[3] -2. Motor Assembly
DISASSEMBLING
1) Separate Capsule from Housing as illustrated in Fig. 1.
2) Motor assembly can be disassembled from Housing as illustrated in Figs. 2, 3.
3. Remove seven 4x16 Tapping screws. 4. Remove Housing (R) and Stay.
Housing (R)
Stay
Switch
DC Motor Fan 82
Terminal
Fig. 3
1. While turning Pre-filter clockwise
or counterclockwise, pull it off
from Housing, then remove Filter.
Filter
Pre-filter
Housing
2. While bending the both legs of Hanger inwards,
remove it from Housing.
Fig. 2
Hanger
5. Disconnect these receptacles.
DC Motor can now be removed from Housing (L).
Motor assembly

P 4/ 6
Repair
[3] DISASSEMBLY/ASSEMBLY
[3] -2. Motor Assembly
ASSEMBLING
1) Assemble Motor assembly to Housing set (L) as illustrated in Fig. 4.
2) Assemble Switch lever to Housing (L) as illustrated in Fig. 5.
3) Assemble Housing (R) to Housing (L), then assemble Hanger to Housing (Fig. 6)
Fitting the protrusion of Housing (L)
in the notch of DC Motor, mount Motor
assembly to Housing (L).
Then connect Lead wires of DC Motor
with Switch and Terminal.
Fig. 4
Fig. 5
notch
protrusion
Housing (L)
DC Motor
Fan 82
Motor assembly
2. Assemble Hanger to Housing
as illustrated below.
Hanger
1. Assemble Housing (R) to Housing (L)
by tightening seven 3x16 Tapping screws.
Housing (R) Housing (L)
Fig. 6
1. Mount Compression spring 4
to Switch lever.
2. While securely fitting Compression spring 4
in the rib of Housing (L), assemble Switch lever
as illustrated to right.
Compression spring 4
Switch lever
Housing (L)
rib

P 5/ 6
Repair
[3] DISASSEMBLY/ASSEMBLY
[3] -2. Motor Assembly
ASSEMBLING
4) Assemble Stay to Housing (Fig. 7)
Fig. 7
When Housing is disassembled, clean up the inside of the machine by blowing off the dust
that settles on DC Motor, Fan, Housing, etc. with air duster for longer tool life. (Fig. 8)
[4] MAINTENANCE
Fig. 8
While fitting the protrusion of Housing (L) in the notch of Stay,
assemble Stay to Housing.
notch of Stay
Protrusion of
Housing set (L)
protrusion of
Housing set (L)
Stay

Circuit diagram
P 6/ 6
Terminal
Fig. D-1
Fig. D-2
Red
White
Color index of lead wires' sheath
Black
Wiring diagram
Wiring of DC Motor
Connect the Receptacle of white Lead wire to the plus terminal
of DC Motor; the plus terminal is indicated by a red dot.
Connect the Receptacle of black Lead wire to the other terminal
(the minus terminal) of DC Motor.
Then assemble DC Motor to Housing (L) with the red dot on
the Grip side (top side) so that the wire connecting portions of
the two Receptacles face Housing (L) side.
Red dot indicating
Plus terminal
Receptacle
Receptacle Housing (L)
Connect the six Receptacles of Lead wires to the electrical parts (DC Motor, Terminal, Switch)
with all wire connecting portions of the Receptacles positioned on Housing (L) side.
Failure to follow this instruction will result in pinching of Lead wires between Housing (L) and
Housing (R).
Terminal
Switch
DC Motor
Wiring in Housing (L)
Receptacle
DC Motor
Switch
COM
NO
= Wire connecting portion of Receptacle
