Coleman Powersports DT200 User manual

DT200
ASSEMBLY INSTRUCTIONS
PLEASE NOTE THAT THIS IS NOT THE OWNER’S MANUAL BUT THE
ASSEMBLY INSTRUCTIONS ONLY.
BEFORE OPERATING THIS DRIFT TRIKE, MAKE SURE THE OPERATOR
HAS READ AND UNDERSTANDS THE OWNER’S MANUAL, WARNING
LABELS AND IS FAMILIAR WITH ALL OF THE DRIFT TRIKE
CONTROLS.
FOR QUESTIONS REGARDING THE ASSEMBLY OF THIS DRIFT TRIKE,
PLEASE CALL COLEMAN POWERSPORTS 888-405-8725
POWERSPORTS
REV090117

Foot Rests
Seat
Safety Net
Frame
Owner’s
Manual
PARTS
Tool Kit

Attach frame together using
M8 x 25 Allen head Bolts
M8 lock washers
M8 Acorn Nuts
FRAME ASSEMBLY
M8 x 25 Bolts
M8 Lock Washers
M8 Acorn Nuts
Hardware
Tools
6mm Allen wrench
Torque bolts to 20 ft.lbs.

M8 x 30 bolts Tools
6mm Allen wrench
Hardware
Install handlebars using
M8 x 30 Allen head bolts and
M8 Lock washers.
HANDLEBAR ASSEMBLY
M8 x 30 bolts
M8 Lock Washers
M8 Lock Washer
Torque bolts to 10 ft.lbs

Zip Tie
Zip Tie
Zip Tie
Zip tie all cables to frame
in locations noted in
photos. Make sure no
cables are in a location
which could be smashed
or pinched by the
handlebars or seat.
Cut o󰀨 ends of Zip ties
once installed.
ZIP TIE CABLES
Zip Ties

Safety Net
assembly
SAFETY NET INSTALLATION
M8 x 30 bolts
Hardware
M8 Lock Nuts
Tools
10mm and 12mm
Wrench
Install Safety net
asssembly using
M8 x 30 Bolts and
M8 lock nuts.
Tighten Bolts snug.
M8 x 30 Bolt
M8 Lock Nut

SEAT INSTALLATION
M6 x 12 bolts
M6 x 16 bolts
M6 x 16 bolt
M6 x 12bolt
Install the seat
using M6 x 12 front
bolts and M6 x 16
rear bolts and M6
rear Lock nuts.
M6 lock nuts
10mm wrench
5mm Allen Wrench
Hardware
Tools
M6 lock nut
Tighten bolts snug

M8 x 20 bolts
Hardware
10mm wrench
Tools
M8 x 20 Bolt
Install Foot rests using
M8 x 20 bolts.
Torque Bolts 14 ft.lbs.
FOOT REST INSTALLATION

! WARNING
THIS IS NOT THE OWNER’S MANUAL, THIS IS THE
ASSSEMBLY INSTRUCTIONS ONLY.
THE OWNER’S MANUAL, INCLUDED WITH THIS DRIFT
TRIKE, HAS ALL INFORMATION REQUIRED FOR SAFETY,
ENGINE PREPERATION, PRE-RIDE INSPECTION AND
STARTING INSTRUCTIONS.
NEVER START THE ENGINE WITHOUT READING AND
FULLY UNDERSTANDING THE OWNER’S MANUAL AND
ALL WARNINGS.
IF YOU DID NOT GET AN OWNER’S MANUAL WITH THIS
DRIFT TRIKE, PLEASE CALL COLEMAN POWERSPORTS
AT 888-405-8725.
