Coleman LX SERIES Quick start guide

TECHNICAL GUIDE
LX SERIES
SPLIT SYSTEM
AIR CONDITIONERS
17 SEER – R-410A – 3 PHASE
3 THRU 5 NOMINAL TONS
MODELS: TCG36 THRU 60
Due to continuous product improvement, specifications
are subject to change without notice.
Visit us on the web at
www.simplygettingthejobdone.com and
www.colemanac.com
Additional rating information can be found at
www.ahridirectory.org
WARRANTY SUMMARY*
Standard 1-Year limited parts warranty.
Standard 5-Years limited compressor warranty.
*Does not apply to R-22 models or internet sales.
See Limited Warranty certificate in User's Information Manual for details.
FOR INSTALLATION IN ALL US REGIONS AND CANADA
Installation Allowed
®
5562621-CTG-C-0320
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
DESCRIPTION
The TCG models are part of our successful LX series 17 SEER
three phase split system air conditioner lineup. The three phase
TCG units are engineered as matched systems using Cole-
man™ indoor coils, furnaces and air handlers.
FEATURES
•Small Footprint - Minimum footprint for easier handling,
transportation, and installation.
•Easier Installation - Independent panels provide quick
access for unit setup. Installation time is reduced by easy
power and control wiring access. Options are provided for
indoor piston or TXV. The factory installed filter-drier and fac-
tory charge for a 15-Ft lineset means less time spent brazing
and charging the system. The small base dimension and
reduced unit clearances make for easier retrofits.
•Accessible Information - QR code on unit provides quick
access to technical documents and warranty information.
•Durable Finish - The coated steel wire fan guard, coated
external fasteners, and pre-treated G90-equivalent galva-
nized steel chassis components resist corrosion and rust
creep. Champagne colored powdercoat paint further protects
external panels.
•Quality Coils - The high efficiency microchannel aluminum
coil is manufactured using an improved material system pro-
viding reliable performance and small unit size.
•Rugged Coil Protection - Coils are protected from mechan-
ical damage by a proven stamped steel coil guard design.
•Protected Compressor - Compressors are protected inter-
nally by a high pressure relief valve and a temperature sen-
sor, and externally by the system high pressure switch. The
liquid line filter-drier is factory installed to protect the com-
pressor against moisture and debris.
•Reliable Operation - Ball bearing fan motors provide supe-
rior performance in extreme temperatures.
•Environmentally Friendly - CFC-free R-410A refrigerant
delivers environmentally friendly performance with zero
ozone depletion.
•Top Discharge - Warm air is blown up, away from the struc-
ture and any landscaping and allows compact location on
multi-unit applications.
•Low Operating Sound Levels - Developed using CFD and
FEA tools, the sturdy cabinet and top design provides sound
performance as low as 73 dBA. Compatible accessories for
further sound reduction are also available.
•Better Service Access - Diagonal base valves with open
access for low-loss fittings, single panel access to the electri-
cal controls, swing out control box for full corner access, and
removable fan guard allow easy access for unit mainte-
nance.
•Agency Listed - Safety certified by CSA to UL 1995 / CSA
22.2. Performance certified to ANSI/AHRI Standard 210/240
in accordance with the Unitary Small Equipment certification
program.

5562621-CTG-C-0320
2 Johnson Controls Ducted Systems
LIST OF SECTIONS
DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
NOMENCLATURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
PHYSICAL AND ELECTRICAL DATA . . . . . . . . . . . . . . . . . . . . . . . 3
DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
SYSTEM CHARGE FOR VARIOUS MATCHED SYSTEMS . . . . . . . 4
COOLING CAPACITY - With Air Handler Coils . . . . . . . . . . . . . . . 5
COOLING CAPACITY - Upflow, Downflow &
Horizontal Furnaces and Coils (Coil Only Ratings) . . . . . . . . . . . 9
COOLING CAPACITY - With High Efficiency Motor Furnaces . . 10
APPLICATIONS AND ACCESSORIES . . . . . . . . . . . . . . . . . . . . . 60
SOUND POWER RATINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
MECHANICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . 61
TYPICAL INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
TYPICAL FIELD WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
ALTERNATIVE INSTALLATION CLEARANCES . . . . . . . . . . . . . . 63
PERFORMANCE DATA - 3 TON 208-230 Volt . . . . . . . . . . . . . . . 64
PERFORMANCE DATA - 3 TON 460 Volt . . . . . . . . . . . . . . . . . . . 72
PERFORMANCE DATA - 4 TON 208-230 Volt . . . . . . . . . . . . . . . 81
PERFORMANCE DATA - 4 TON 460 Volt . . . . . . . . . . . . . . . . . . . 87
PERFORMANCE DATA - 5 TON 208-230 Volt . . . . . . . . . . . . . . . 93
PERFORMANCE DATA - 5 TON 460 Volt . . . . . . . . . . . . . . . . . . . 96
NOMENCLATURE
BRAND TT= Factory Branded
PRODUCT TYPE CC= Air Conditioner
NOMINAL
SERIES EFFICIENCY
AND STAGING GG= 17 SEER / 1-Stage
NOMINAL
UNIT CAPACITY
(MBH) 36 36 = 3 Ton
48 = 4 Ton
60 = 5 Ton
REFRIGERANT BB= R-410A
VOLTAGE
(Voltage-Phase-Hertz) 33= 208/230-3-60
4= 460-3-60
GENERATION
(MAJOR REVISION) 11= 1st Gen
2= 2nd Gen
etc
FACTORY OPTION SS= Standard (No Options)
STYLE LETTER
(MINOR REVISION)
NOT USED
FOR ORDERING
AA= Style A
B= Style B
etc

5562621-CTG-C-0320
Johnson Controls Ducted Systems 3
‡ Adapter fitting must be field installed for the required 1-1/8” line set.
All dimensions are in inches and are subject to change without notice.
Overall height is from bottom of base pan to top of fan guard.
Overall length and width include screw heads.
PHYSICAL AND ELECTRICAL DATA
MODEL TCG36B31S TCG48B31S TCG60B31S TCG36B41S TCG48B41S TCG60B41S
Unit Supply Voltage 208-230V, 3, 60Hz 460V, 3, 60Hz
Normal Voltage Range 1
1. Rated in accordance with AHRI Standard 110-2012, utilization range “A”.
187 to 252 432 to 504
Minimum Circuit Ampacity 15.8 20.0 22.6 8.8 9.4 10.4
Max. Overcurrent Device Amps 2
2. Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.
25 30 35 15 15 15
Min. Overcurrent Device Amps 3
3. Dual element fuses or HACR circuit breaker. Minimum recommended overcurrent protection.
20 20 25 15 15 15
Compressor Type Scroll Scroll Scroll Scroll Scroll Scroll Rated Load 10.4 13.8 15.9 5.8 6.2 7.1
Locked Rotor 73.0 83.1 110 38.0 41.0 52.0
Crankcase Heater No No No No No No
Factory External Discharge Muffler No No No No No No
Fan Diameter Inches 24 26 26 24 26 26
Fan Motor
Type ECM ECM ECM ECM ECM ECM
Rated HP 1/3 1/3 1/3 1/3 1/3 1/3
Rated Load Amps 2.80 2.80 2.80 1.60 1.60 1.60
Nominal RPM 682 875 834 682 875 834
Nominal CFM 3000 4100 4275 3000 4100 4275
Coil Face Area Sq. Ft. 21.06 25.28 27.40 21.06 25.28 27.40 Rows Deep 111111
Fins / Inch 23 23 23 23 23 23
Liquid Line Set OD (Field Installed) 3/8 3/8 3/8 3/8 3/8 3/8
Vapor Line Set OD (Field Installed) 4
4. For applications with non-standard vapor line sizes, see the “Applications &Accessories” section of this Technical Guide.
3/4 7/8 1-1/8‡3/4 7/8 1-1/8‡
Unit Charge (Lbs. - Oz.) 5
5. The Unit Charge is correct for the outdoor unit, smallest matched indoor unit, and 15 feet of refrigerant tubing. For tubing lengths other than 15 feet, add or subtract
the amount of refrigerant, using the difference in actual lineset length (not the equivalent length) multiplied by the per foot value.
4 - 9 6 - 11 7 - 14 4 - 9 6 - 11 7 - 14
Charge Per Foot, Oz. 0.62 0.67 0.75 0.62 0.67 0.75
Operating Weight Lbs. 180 225 240 180 225 240
&
%
$
$
DIMENSIONS
Unit
Model
Dimensions
(Inches) Refrigerant Connection Service Valve Size
A B C Liquid Vapor
TCG36B(3,4)1S 36-1/4 35-1/4 31-3/4 3/8 3/4
TCG48B(3,4)1S 39-1/2 38 34-1/4 7/8
TCG60B(3,4)1S 42-3/4 38 34-1/4 7/8‡

5562621-CTG-C-0320
4 Johnson Controls Ducted Systems
CHARGING PROCEDURES:
1. Check the Factory Unit Charge listed on the unit nameplate to verify the refrigerant charge for the outdoor unit, the smallest matched indoor unit, and the 15 feet of
interconnecting lineset.
2. Verify the indoor metering device and additional charge required for the specific matched indoor unit in the system using the above table.
3. Add additional charge for the amount of interconnecting lineset tubing greater than 15 feet at the rate specified in Physical and Electrical Data Table.
4. For installations requiring additional charge, weigh in refrigerant for the specific matching indoor unit and actual lineset length.
5. Once the charge adders for matched indoor unit and for lineset have been weighed in, verify the system operation against the temperatures and pressures in the
Charging Chart for the outdoor unit. Locate Charging Charts on the outdoor unit and also in the Service Data Application Guide on
www.simplygettingthejobdone.com. Follow the Subcool or Superheat charging procedure in the Installation Manual according to the type of indoor metering device
in the system, and allow ten minutes after each charge adjustment for the system operation to stabilize. Record the charge adjustment made to match the Charging
Chart.
6. Permanently stamp the unit nameplate with the TOTAL SYSTEM CHARGE defined as follows: TOTAL SYSTEM CHARGE = Base Charge (as shipped) + charge
adder for matched indoor unit + charge adder for actual lineset length + charge adjustments to match the Charging Chart.
SYSTEM CHARGE FOR VARIOUS MATCHED SYSTEMS
Outdoor Unit TCG36B(3,4)1S TCG48B(3,4)1S TCG60B(3,4)1S
Required TXV 1,2
1. For applications requiring a TXV, use S1-1TVM*** series kit.
2. ATXV kit must be used with these indoor units to obtain system performance.
BA1 BC1 BG1
Indoor Unit 3,4,5
3. Systems matched with furnaces or air handlers not equipped with blower-off delays may require 60 second time delay.
4. CF coils cannot be used in horizontal applications.
5. Charge adders shown above do not indicate that coils are rated for every application. Refer to Performance Data Tables for actual performance for specified sys-
tem matches. Obtain certified system ratings from www.ahridirectory.org.
Additional Charge, oz
AP18B – – –
AP24B – – –
AP30B – – –
AP36B 0 – –
AP36C 2 – –
AP42C 2 – –
AP48(C,D) 6 0 –
AP60(C,D) 10 4 0
AE18B – – –
AE24B – – –
AE30B – – –
AE36(B,C) 0 – –
AE42C 6 – –
AE48(C,D) 6 0 –
AE60C 10 4 0
AE60D – 22 16
AVC18B – – –
AVC24B – – –
AVC30B – – –
AVC36(B,C) 0 – –
AVC42C 6 – –
AVC48(C,D) 6 0 –
AVC60C 10 4 0
AVC60D – 22 16
CF/CM/CU18(A,B) – – –
CF/CM/CU24(A,B) – – –
CF/CM/CU30(A,B,C) – – –
CF/CM/CU36(A,B,C,D) 0 – –
CF/CM/CU42(B,C,D) 2 – –
CF/CM/CU48(C,D) 6 0 –
CF/CM/CU60(C,D) 10 4 0
CF/CM64D – 22 16
Some of the combinations shown in the above System Charge table require Advanced Main Air Circulating Fan indoor product. For approved coil
only matches, please see the “COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils” table.
FOOTNOTES:

5562621-CTG-C-0320
Johnson Controls Ducted Systems 5
COOLING CAPACITY - With Air Handler Coils
UNIT
MODEL
AIR HANDLER COIL
MODEL1
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.
TCG36B31S AE36BX21 17.5 – 1000 34.60 23.80 16.25 13.50
TCG36B31S AE36CX21 21.0 – 1025 34.60 24.40 16.50 14.00
TCG36B31S AE42CX21 21.0 – 1000 35.40 24.40 17.00 14.00
TCG36B31S AE48CX21 21.0 – 1250 36.00 27.00 17.00 14.00
TCG36B31S AE48DX21 24.5 – 1250 36.00 27.00 17.00 14.25
TCG36B31S AE60CX21 21.0 – 1350 36.00 27.40 15.75 13.50
TCG36B31S AP36BX21 17.5 – 975 34.60 23.60 14.75 12.50
TCG36B31S AP36CX21 21.0 – 975 34.60 23.80 15.00 12.75
TCG36B31S AP42CX21 21.0 – 1150 35.40 24.60 14.75 12.50
TCG36B31S AP48CX21 21.0 – 1175 36.00 26.20 14.75 12.75
TCG36B31S AP48DX21 24.5 – 1175 36.00 26.20 14.75 12.75
TCG36B31S AP60CX21 21.0 – 1350 36.00 27.20 14.25 12.25
TCG36B31S AP60DX22 24.5 – 1225 36.00 26.00 14.50 12.50
TCG36B31S AVC36BX21 17.5 – 975 34.60 23.60 16.25 13.75
TCG36B31S AVC36CX21 21.0 – 975 34.60 23.60 16.50 14.00
TCG36B31S AVC42CX21 21.0 – 1100 35.40 25.60 17.00 14.00
TCG36B31S AVC48CX21 21.0 – 1075 36.00 25.40 17.00 14.00
TCG36B31S AVC48DX21 24.5 – 1150 36.00 26.20 17.00 14.25
TCG36B31S AVC60CX21 21.0 – 1125 36.00 25.80 17.00 14.25
TCG36B31S ME12BN21 17.5 CF/CM36B 1025 34.60 24.40 16.20 13.75
TCG36B31S ME12BN21 17.5 CF42B 975 35.40 24.20 16.25 13.50
TCG36B31S ME14DN21 24.5 CF/CM36D 1250 34.60 26.20 16.50 14.00
TCG36B31S ME14DN21 24.5 CF/CM42D 1225 35.40 25.80 17.00 14.25
TCG36B31S ME14DN21 24.5 CF/CM48D 1200 36.00 26.60 17.00 14.25
TCG36B31S ME14DN21 24.5 CF/CM60D 1050 36.00 25.20 16.00 13.75
TCG36B31S ME16CN21 21.0 CF/CM36C 1250 34.60 26.00 16.50 14.00
TCG36B31S ME16CN21 21.0 CF/CM42C 1225 35.40 25.80 17.00 14.25
TCG36B31S ME16CN21 21.0 CF/CM48C 1250 36.00 27.00 17.00 14.25
TCG36B31S ME16CN21 21.0 CF/CM60C 1250 36.00 26.80 17.00 14.25
TCG36B31S ME20DN21 24.5 CF/CM36D 1325 35.40 25.80 15.00 12.75
TCG36B31S ME20DN21 24.5 CF/CM42D 1350 36.00 27.20 16.20 13.50
TCG36B31S ME20DN21 24.5 CF/CM48D 1350 36.00 27.40 16.25 13.75
TCG36B31S ME20DN21 24.5 CF/CM60D 1350 36.00 27.40 16.50 13.75
TCG36B31S MVC08BN21 17.5 CF/CM36B 1025 36.00 25.20 15.75 13.25
TCG36B31S MVC12BN21 17.5 CF/CM36B 1000 36.00 24.80 15.75 13.25
TCG36B31S MVC12BN21 17.5 CF42B 1025 36.00 24.60 16.00 13.25
TCG36B31S MVC14DN21 24.5 CF/CM36D 1175 36.00 26.20 16.50 13.75
TCG36B31S MVC14DN21 24.5 CF/CM42D 1125 36.00 25.80 17.00 14.00
TCG36B31S MVC14DN21 24.5 CF/CM48D 1125 36.00 25.80 17.00 14.00
TCG36B31S MVC14DN21 24.5 CF/CM60D 1075 36.00 25.60 17.00 14.00
TCG36B31S MVC16CN21 21.0 CF/CM36C 1125 36.00 25.20 16.00 13.50
TCG36B31S MVC16CN21 21.0 CF/CM42C 1025 36.00 24.60 16.50 13.75
TCG36B31S MVC16CN21 21.0 CF/CM48C 1075 36.00 25.60 17.00 14.00
TCG36B31S MVC16CN21 21.0 CF/CM60C 1175 36.00 26.40 17.00 14.00
TCG36B31S MVC20DN21 24.5 CF/CM36D 1150 36.00 26.40 16.50 14.00
TCG36B31S MVC20DN21 24.5 CF/CM42D 1200 36.00 26.20 16.50 13.75
TCG36B31S MVC20DN21 24.5 CF/CM48D 1100 36.00 25.60 17.00 14.00
TCG36B31S MVC20DN21 24.5 CF/CM60D 1175 36.00 26.20 17.00 14.25
TCG36B41S AE36BX21 17.5 – 1000 34.60 23.80 16.25 13.50
TCG36B41S AE36CX21 21.0 – 1025 34.60 24.40 16.50 14.00
TCG36B41S AE42CX21 21.0 – 1000 35.40 24.40 17.00 14.00
TCG36B41S AE48CX21 21.0 – 1250 36.00 26.80 17.00 14.00
TCG36B41S AE48DX21 24.5 – 1250 36.00 26.80 17.00 14.25

5562621-CTG-C-0320
6 Johnson Controls Ducted Systems
TCG36B41S AE60CX21 21.0 – 1350 36.00 27.00 15.75 13.50
TCG36B41S AP36BX21 17.5 – 975 34.60 23.80 14.75 12.50
TCG36B41S AP36CX21 21.0 – 975 34.60 23.40 15.00 12.75
TCG36B41S AP42CX21 21.0 – 1150 35.40 24.60 14.75 12.50
TCG36B41S AP48CX21 21.0 – 1175 36.00 25.80 14.75 12.75
TCG36B41S AP48DX21 24.5 – 1175 36.00 25.80 14.75 12.75
TCG36B41S AP60CX21 21.0 – 1350 36.00 27.00 14.25 12.25
TCG36B41S AP60DX22 24.5 – 1225 36.00 26.00 14.50 12.50
TCG36B41S AVC36BX21 17.5 – 975 34.60 23.60 16.25 13.75
TCG36B41S AVC36CX21 21.0 – 975 34.60 23.60 16.50 14.00
TCG36B41S AVC42CX21 21.0 – 1100 35.40 25.60 17.00 14.00
TCG36B41S AVC48CX21 21.0 – 1075 36.00 25.40 17.00 14.00
TCG36B41S AVC48DX21 24.5 – 1150 36.00 26.00 17.00 14.25
TCG36B41S AVC60CX21 21.0 – 1125 36.00 25.80 17.00 14.25
TCG36B41S ME12BN21 17.5 CF/CM36B 1025 34.60 24.40 16.20 13.75
TCG36B41S ME12BN21 17.5 CF42B 975 35.40 24.20 16.25 13.50
TCG36B41S ME14DN21 24.5 CF/CM36D 1250 34.60 26.00 16.50 14.00
TCG36B41S ME14DN21 24.5 CF/CM42D 1225 35.40 25.80 17.00 14.25
TCG36B41S ME14DN21 24.5 CF/CM48D 1200 36.00 26.60 17.00 14.25
TCG36B41S ME14DN21 24.5 CF/CM60D 1050 36.00 25.20 16.00 13.75
TCG36B41S ME16CN21 21.0 CF/CM36C 1250 34.60 26.00 16.50 14.00
TCG36B41S ME16CN21 21.0 CF/CM42C 1225 35.40 25.80 17.00 14.25
TCG36B41S ME16CN21 21.0 CF/CM48C 1250 36.00 26.80 17.00 14.25
TCG36B41S ME16CN21 21.0 CF/CM60C 1250 36.00 27.00 17.00 14.25
TCG36B41S ME20DN21 24.5 CF/CM36D 1325 35.40 26.00 15.00 12.75
TCG36B41S ME20DN21 24.5 CF/CM42D 1350 36.00 27.40 16.20 13.50
TCG36B41S ME20DN21 24.5 CF/CM48D 1350 36.00 27.40 16.25 13.75
TCG36B41S ME20DN21 24.5 CF/CM60D 1350 36.00 27.00 16.50 13.75
TCG36B41S ME12BN41 17.5 CF/CM36B 1075 34.60 27.80 16.00 13.25
TCG36B41S ME12BN41 17.5 CF42B 1075 35.40 27.00 16.25 13.50
TCG36B41S ME12CN41 21.0 CF/CM36C 1250 36.00 29.80 16.25 13.50
TCG36B41S ME12CN41 21.0 CF/CM42C 1250 36.00 29.60 16.25 13.50
TCG36B41S ME12CN41 21.0 CF/CM48C 1250 36.00 28.60 16.25 13.50
TCG36B41S ME12CN41 21.0 CF/CM60C 1250 36.00 29.80 16.25 13.50
TCG36B41S ME14DN41 24.5 CF/CM48D 1200 36.00 28.00 17.00 14.00
TCG36B41S ME14DN41 24.5 CF/CM60D 1200 36.00 29.60 17.00 14.00
TCG36B41S ME16CN41 21.0 CF/CM36C 1100 34.60 28.00 16.50 13.75
TCG36B41S ME16CN41 21.0 CF/CM42C 1100 35.40 28.00 16.75 14.00
TCG36B41S ME16CN41 21.0 CF/CM48C 1100 36.00 28.40 16.75 14.00
TCG36B41S ME16CN41 21.0 CF/CM60C 1100 36.00 27.80 16.75 14.00
TCG36B41S ME20DN41 24.5 CF/CM36D 1250 35.40 29.80 15.50 12.75
TCG36B41S ME20DN41 24.5 CF/CM42D 1250 36.00 29.60 16.25 13.50
TCG36B41S ME20DN41 24.5 CF/CM48D 1250 36.00 30.20 16.25 13.50
TCG36B41S ME20DN41 24.5 CF/CM60D 1250 36.00 30.00 16.50 13.75
TCG36B41S MVC08BN21 17.5 CF/CM36B 1025 36.00 25.40 15.75 13.25
TCG36B41S MVC12BN21 17.5 CF/CM36B 1000 36.00 24.80 15.75 13.25
TCG36B41S MVC12BN21 17.5 CF42B 1025 36.00 24.60 16.00 13.25
TCG36B41S MVC14DN21 24.5 CF/CM36D 1175 36.00 26.60 16.50 13.75
TCG36B41S MVC14DN21 24.5 CF/CM42D 1125 36.00 25.80 17.00 14.00
TCG36B41S MVC14DN21 24.5 CF/CM48D 1125 36.00 26.00 17.00 14.00
TCG36B41S MVC14DN21 24.5 CF/CM60D 1075 36.00 25.40 17.00 14.00
TCG36B41S MVC16CN21 21.0 CF/CM36C 1125 36.00 25.20 16.00 13.50
TCG36B41S MVC16CN21 21.0 CF/CM42C 1025 36.00 24.60 16.50 13.75
COOLING CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER COIL
MODEL1
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5562621-CTG-C-0320
Johnson Controls Ducted Systems 7
TCG36B41S MVC16CN21 21.0 CF/CM48C 1075 36.00 25.40 17.00 14.00
TCG36B41S MVC16CN21 21.0 CF/CM60C 1175 36.00 26.40 17.00 14.00
TCG36B41S MVC20DN21 24.5 CF/CM36D 1150 36.00 26.40 16.50 14.00
TCG36B41S MVC20DN21 24.5 CF/CM42D 1200 36.00 26.40 16.50 13.75
TCG36B41S MVC20DN21 24.5 CF/CM48D 1100 36.00 25.60 17.00 14.00
TCG36B41S MVC20DN21 24.5 CF/CM60D 1175 36.00 26.00 17.00 14.25
TCG48B31S AE48CX21 21.0 – 1425 45.50 32.20 16.25 13.25
TCG48B31S AE48DX21 24.5 – 1425 46.00 32.20 16.50 13.75
TCG48B31S AE60CX21 21.0 – 1425 46.50 33.40 16.50 13.75
TCG48B31S AE60DX21 24.5 – 1400 47.00 33.20 17.00 14.00
TCG48B31S AP48CX21 21.0 – 1300 44.50 30.40 15.00 12.50
TCG48B31S AP48DX21 24.5 – 1400 45.00 31.60 15.25 12.50
TCG48B31S AP60CX21 21.0 – 1500 46.00 33.00 15.00 12.50
TCG48B31S AP60DX22 24.5 – 1425 46.00 33.00 15.00 12.50
TCG48B31S AVC48CX21 21.0 – 1350 45.50 31.40 16.20 13.25
TCG48B31S AVC48DX21 24.5 – 1400 46.00 32.80 16.50 13.75
TCG48B31S AVC60CX21 21.0 – 1350 46.00 32.00 16.50 13.75
TCG48B31S AVC60DX21 24.5 – 1300 46.50 32.00 16.50 13.75
TCG48B31S ME14DN21 24.5 CF/CM60D 1375 46.50 32.60 16.50 13.75
TCG48B31S ME14DN21 24.5 CF/CM64D 1450 47.50 34.00 16.50 13.50
TCG48B31S ME16CN21 21.0 CF/CM48C 1475 46.00 33.00 16.50 13.50
TCG48B31S ME16CN21 21.0 CF/CM60C 1450 46.50 33.20 16.50 13.75
TCG48B31S ME20DN21 24.5 CF/CM48D 1475 46.00 33.20 16.50 13.75
TCG48B31S ME20DN21 24.5 CF/CM60D 1450 46.50 33.40 16.50 13.75
TCG48B31S ME20DN21 24.5 CF/CM64D 1425 47.00 33.20 17.00 13.75
TCG48B31S MVC14DN21 24.5 CF/CM48D 1300 45.50 31.20 16.25 13.50
TCG48B31S MVC16CN21 21.0 CF/CM48C 1350 45.50 31.20 16.25 13.50
TCG48B31S MVC16CN21 21.0 CF/CM60C 1325 45.50 31.00 16.50 13.75
TCG48B31S MVC20DN21 24.5 CF/CM48D 1350 45.50 31.20 16.25 13.50
TCG48B31S MVC20DN21 24.5 CF/CM60D 1425 46.50 33.40 16.75 13.75
TCG48B31S MVC20DN21 24.5 CF/CM64D 1375 46.50 32.60 17.00 14.00
TCG48B41S AE48CX21 21.0 – 1425 45.50 32.00 16.25 13.25
TCG48B41S AE48DX21 24.5 – 1425 46.00 32.40 16.50 13.75
TCG48B41S AE60CX21 21.0 – 1425 46.50 33.40 16.50 13.75
TCG48B41S AE60DX21 24.5 – 1400 47.00 33.40 17.00 14.00
TCG48B41S AP48CX21 21.0 – 1300 44.50 30.40 15.00 12.50
TCG48B41S AP48DX21 24.5 – 1400 45.00 31.60 15.25 12.50
TCG48B41S AP60CX21 21.0 – 1500 46.00 33.00 15.00 12.50
TCG48B41S AP60DX22 24.5 – 1425 46.00 33.20 15.00 12.50
TCG48B41S AVC48CX21 21.0 – 1350 45.50 31.60 16.20 13.25
TCG48B41S AVC48DX21 24.5 – 1400 46.00 33.00 16.50 13.75
TCG48B41S AVC60CX21 21.0 – 1350 46.00 32.40 16.50 13.75
TCG48B41S AVC60DX21 24.5 – 1300 46.50 32.20 16.50 13.75
TCG48B41S ME14DN21 24.5 CF/CM60D 1375 46.50 32.80 16.50 13.75
TCG48B41S ME16CN21 21.0 CF/CM48C 1475 46.00 33.20 16.50 13.50
TCG48B41S ME16CN21 21.0 CF/CM60C 1450 46.50 33.40 16.50 13.75
TCG48B41S ME20DN21 24.5 CF/CM48D 1475 46.00 33.20 16.50 13.75
TCG48B41S ME20DN21 24.5 CF/CM60D 1450 46.50 33.40 16.50 13.75
TCG48B41S ME20DN21 24.5 CF/CM64D 1425 47.00 33.40 17.00 13.75
TCG48B41S ME12CN41 21.0 CF/CM48C 1300 45.50 33.40 16.00 13.00
TCG48B41S ME12CN41 21.0 CF/CM60C 1300 45.00 33.00 15.75 12.75
TCG48B41S ME14DN41 24.5 CF/CM48D 1500 46.50 33.60 15.75 13.00
TCG48B41S ME14DN41 24.5 CF/CM60D 1375 46.50 32.80 16.00 13.00
COOLING CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER COIL
MODEL1
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5562621-CTG-C-0320
8 Johnson Controls Ducted Systems
— = Not applicable.
MP ModularAir Handlers use Coil Only Ratings.
TCG48B41S ME14DN41 24.5 CF/CM64D 1350 46.50 31.80 16.00 13.00
TCG48B41S ME16CN41 21.0 CF/CM48C 1350 45.50 30.80 16.00 13.00
TCG48B41S ME20DN41 24.5 CF/CM48D 1425 46.50 33.20 16.00 13.00
TCG48B41S ME20DN41 24.5 CF/CM60D 1425 46.50 33.60 15.75 12.75
TCG48B41S ME20DN41 24.5 CF/CM64D 1425 47.50 33.80 16.00 13.00
TCG48B41S MVC14DN21 24.5 CF/CM48D 1300 45.50 30.80 16.25 13.50
TCG48B41S MVC16CN21 21.0 CF/CM48C 1350 45.50 30.80 16.25 13.50
TCG48B41S MVC16CN21 21.0 CF/CM60C 1325 45.50 31.20 16.50 13.75
TCG48B41S MVC20DN21 24.5 CF/CM48D 1350 45.50 30.80 16.25 13.50
TCG48B41S MVC20DN21 24.5 CF/CM60D 1425 46.50 33.40 16.75 13.75
TCG48B41S MVC20DN21 24.5 CF/CM64D 1375 46.50 32.80 17.00 14.00
TCG60B31S AE60CX21 21.0 – 1625 56.00 39.00 14.75 12.50
TCG60B31S AE60CX22 21.0 – 1600 55.50 40.40 14.75 12.25
TCG60B31S AE60DX21 24.5 – 1550 57.00 41.00 16.00 13.00
TCG60B31S AP60CX21 21.0 – 1600 55.50 38.50 14.25 11.75
TCG60B31S AP60DX21 24.5 – 1675 56.00 39.00 14.25 12.00
TCG60B31S AP60DX22 24.5 – 1675 56.00 39.00 14.25 12.00
TCG60B31S AVC60CX21 21.0 – 1750 56.50 40.50 14.75 12.25
TCG60B31S AVC60DX21 24.5 – 1600 57.50 41.80 15.50 12.75
TCG60B31S ME16CN21 21.0 CF/CM60C 1575 55.50 40.00 14.75 12.50
TCG60B31S ME20DN21 24.5 CF/CM60D 1700 57.00 42.60 15.75 13.00
TCG60B31S ME20DN21 24.5 CF/CM64D 1675 58.00 42.80 16.00 13.00
TCG60B31S MVC16CN21 21.0 CF/CM60C 1650 56.00 41.00 15.00 12.75
TCG60B31S MVC20DN21 24.5 CF/CM60D 1550 56.50 40.90 16.00 13.00
TCG60B31S MVC20DN21 24.5 CF/CM64D 1550 57.50 41.40 16.00 13.00
TCG60B41S AE60CX21 21.0 – 1625 56.00 39.00 14.75 12.50
TCG60B41S AE60CX22 21.0 – 1600 55.50 40.40 14.75 12.25
TCG60B41S AE60DX21 24.5 – 1550 57.00 41.00 16.00 13.00
TCG60B41S AP60CX21 21.0 – 1600 55.50 38.50 14.25 11.75
TCG60B41S AP60DX21 24.5 – 1675 56.00 39.00 14.25 12.00
TCG60B41S AP60DX22 24.5 – 1675 56.00 39.00 14.25 12.00
TCG60B41S AVC60CX21 21.0 – 1750 56.50 40.50 14.75 12.25
TCG60B41S AVC60DX21 24.5 – 1600 57.50 41.80 15.50 12.75
TCG60B41S ME16CN21 21.0 CF/CM60C 1575 55.50 40.00 14.75 12.50
TCG60B41S ME20DN21 24.5 CF/CM60D 1700 57.00 42.60 15.75 13.00
TCG60B41S ME20DN21 24.5 CF/CM64D 1675 58.00 42.80 16.00 13.00
TCG60B41S MVC16CN21 21.0 CF/CM60C 1650 56.00 41.00 15.00 12.75
TCG60B41S MVC20DN21 24.5 CF/CM60D 1550 56.50 40.90 16.00 13.00
TCG60B41S MVC20DN21 24.5 CF/CM64D 1550 57.50 41.40 16.00 13.00
TCG60B41S ME16CN41 21.0 CF/CM60C 1600 55.50 40.50 14.75 12.50
TCG60B41S ME20DN41 24.5 CF/CM60D 1650 56.50 39.50 15.50 12.75
TCG60B41S ME20DN41 24.5 CF/CM64D 1625 58.00 40.00 16.00 13.00
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ANSI/AHRI Standard 210/240.
Cooling MBH based on 80°F entering air temperature, 50% RH (Relative Humidity), and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTUs at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTUs during a normal annual usage period for cooling divided by the total
electric power input in watt-hours during the same period.
1. CM coils available with a factory installed horizontal drain pan. See price pages for specific model number.
COOLING CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER COIL
MODEL1
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5562621-CTG-C-0320
Johnson Controls Ducted Systems 9
— = Not Applicable.
MP ModularAir Handlers use Coil Only Ratings.
PSC furnaces, such as the TG8S, TGLS, and TG9S, use Coil Only Ratings.
COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils (Coil Only Ratings)
UNIT MODEL
COIL CFM RANGE
(MIN.-MAX.)
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER 1
1. Systems matched with furnaces or air handlers not equipped with blower-off delays may require 60 second time delay.
EER
TOTAL SENS.
TCG36B31S CF/CM/CU36B 17.5 1000 - 1400 1200 34.6 25.6 14.50 12.50
TCG36B31S CF/CM/CU36C 21 1000 - 1400 1200 34.6 25.6 14.50 12.50
TCG36B31S CF/CM/CU36D 24.5 1000 - 1400 1200 34.6 25.6 14.50 12.50
TCG36B31S CF/CM/CU42C 21 1000 - 1400 1200 35.4 25.6 15.00 12.50
TCG36B31S CF/CM/CU42D 24.5 1000 - 1400 1200 35.4 25.6 15.00 12.50
TCG36B31S CF/CM/CU48C 21 1000 - 1400 1200 36.0 26.2 15.50 12.75
TCG36B31S CF/CM/CU48D 24.5 1000 - 1400 1200 36.0 26.4 15.25 12.75
TCG36B31S CF/CM/CU60C 21 1000 - 1400 1200 36.0 26.0 15.25 12.75
TCG36B31S CF/CM/CU60D 24.5 1000 - 1400 1200 36.0 26.0 15.25 12.75
TCG36B31S CF42B 17.5 1000 - 1400 1200 35.4 25.6 15.00 12.50
TCG36B41S CF/CM/CU36B 17.5 1000 - 1400 1200 34.6 25.2 14.50 12.50
TCG36B41S CF/CM/CU36C 21 1000 - 1400 1200 34.6 25.2 14.50 12.50
TCG36B41S CF/CM/CU36D 24.5 1000 - 1400 1200 34.6 25.2 14.50 12.50
TCG36B41S CF/CM/CU42C 21 1000 - 1400 1200 35.4 25.6 15.00 12.50
TCG36B41S CF/CM/CU42D 24.5 1000 - 1400 1200 35.4 25.6 15.00 12.50
TCG36B41S CF/CM/CU48C 21 1000 - 1400 1200 36.0 26.4 15.50 12.75
TCG36B41S CF/CM/CU48D 24.5 1000 - 1400 1200 36.0 26.4 15.25 12.75
TCG36B41S CF/CM/CU60C 21 1000 - 1400 1200 36.0 26.0 15.25 12.75
TCG36B41S CF/CM/CU60D 24.5 1000 - 1400 1200 36.0 26.0 15.25 12.75
TCG36B41S CF42B 17.5 1000 - 1400 1200 35.4 25.6 15.00 12.50
TCG48B31S CF/CM/CU48C 21 1400 - 1800 1500 45.0 32.6 14.75 12.25
TCG48B31S CF/CM/CU48D 24.5 1400 - 1800 1500 45.0 32.6 14.75 12.25
TCG48B31S CF/CM/CU60C 21 1400 - 1800 1500 45.5 33.0 15.50 12.75
TCG48B31S CF/CM/CU60D 24.5 1400 - 1800 1500 46.0 33.4 15.25 12.75
TCG48B31S CF/CM64D 24.5 1400 - 1800 1500 47.0 33.8 15.50 13.00
TCG48B41S CF/CM/CU48C 21 1400 - 1800 1500 45.0 32.4 14.75 12.25
TCG48B41S CF/CM/CU48D 24.5 1400 - 1800 1500 45.0 32.4 14.75 12.25
TCG48B41S CF/CM/CU60C 21 1400 - 1800 1500 45.5 33.0 15.50 12.75
TCG48B41S CF/CM/CU60D 24.5 1400 - 1800 1500 46.0 33.4 15.25 12.75
TCG48B41S CF/CM64D 24.5 1400 - 1800 1500 47.0 34.0 15.50 13.00
TCG60B31S CF/CM/CU60C 21 1520 - 1920 1725 56.5 40.0 14.50 12.00
TCG60B31S CF/CM/CU60D 24.5 1520 - 1920 1725 56.5 40.0 14.50 12.00
TCG60B31S CF/CM64D 24.5 1520 - 1920 1725 57.5 40.5 15.00 12.75
TCG60B41S CF/CM/CU60C 21 1520 - 1920 1725 56.5 40.0 14.50 12.00
TCG60B41S CF/CM/CU60D 24.5 1520 - 1920 1725 56.5 40.0 14.50 12.00
TCG60B41S CF/CM64D 24.5 1520 - 1920 1725 57.5 40.5 15.00 12.75
For rated condition information, see the footnotes below the System Capacity - Single Piece and Modular Air Handlers table.

5562621-CTG-C-0320
10 Johnson Controls Ducted Systems
COOLING CAPACITY - With High Efficiency Motor Furnaces1
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.
TCG36B31S TL8E060A12UH11 14.5 CF/CM/CU36B 1025 34.6 27.0 15.50 12.75
TCG36B31S TL8E060A12UH11 14.5 CF42B 1025 35.4 26.8 16.00 13.25
TCG36B31S TL8E080C16UH11 21.0 CF/CM/CU36C 1125 34.6 28.5 16.00 13.50
TCG36B31S TL8E080C16UH11 21.0 CF/CM/CU42C 1125 35.4 28.2 16.50 13.75
TCG36B31S TL8E080C16UH11 21.0 CF/CM/CU48C 1125 36.0 28.6 16.75 13.75
TCG36B31S TL8E080C16UH11 21.0 CF/CM/CU48D 1125 36.0 28.6 16.50 13.75
TCG36B31S TL8E080C16UH11 21.0 CF/CM/CU60C 1125 36.0 28.1 16.50 13.75
TCG36B31S TL8E080C16UH11 21.0 CF/CM/CU60D 1125 36.0 28.1 16.50 13.75
TCG36B31S TL8E080C16UH11 21.0 CF/CM36D 1125 34.6 28.5 16.00 13.50
TCG36B31S TL8E080C16UH11 21.0 CF/CM42D 1125 35.4 28.2 16.50 13.75
TCG36B31S TL8E100C20UH11 21.0 CF/CM/CU36C 1050 34.6 27.3 16.25 13.50
TCG36B31S TL8E100C20UH11 21.0 CF/CM/CU42C 1050 35.4 27.5 16.75 13.75
TCG36B31S TL8E100C20UH11 21.0 CF/CM/CU48C 1050 36.0 27.5 17.00 14.00
TCG36B31S TL8E100C20UH11 21.0 CF/CM/CU48D 1050 36.0 27.5 16.75 14.00
TCG36B31S TL8E100C20UH11 21.0 CF/CM/CU60C 1050 36.0 27.2 16.75 14.00
TCG36B31S TL8E100C20UH11 21.0 CF/CM/CU60D 1075 36.0 27.6 16.75 14.00
TCG36B31S TL8E100C20UH11 21.0 CF/CM36D 1050 34.6 27.3 16.50 13.75
TCG36B31S TL8E100C20UH11 21.0 CF/CM42D 1050 35.4 27.5 16.75 14.00
TCG36B31S TL9E060B12UH11 17.5 CF/CM/CU36B 1025 34.6 27.0 15.25 12.50
TCG36B31S TL9E060B12UH11 17.5 CF/CM/CU36C 1050 34.6 27.0 15.25 12.50
TCG36B31S TL9E060B12UH11 17.5 CF/CM/CU42C 1050 35.4 27.2 15.75 13.00
TCG36B31S TL9E060B12UH11 17.5 CF/CM/CU48C 1050 36.0 27.2 15.75 13.00
TCG36B31S TL9E060B12UH11 17.5 CF/CM/CU60C 1050 36.0 26.9 15.50 12.75
TCG36B31S TL9E060B12UH11 17.5 CF42B 1025 35.4 26.7 15.50 12.75
TCG36B31S TL9E080C16UH11 21.0 CF/CM/CU36C 1075 34.6 27.7 15.75 13.00
TCG36B31S TL9E080C16UH11 21.0 CF/CM/CU42C 1075 35.4 27.8 16.25 13.50
TCG36B31S TL9E080C16UH11 21.0 CF/CM/CU48C 1075 36.0 27.8 16.50 13.75
TCG36B31S TL9E080C16UH11 21.0 CF/CM/CU48D 1100 36.0 28.2 16.50 13.50
TCG36B31S TL9E080C16UH11 21.0 CF/CM/CU60C 1075 36.0 27.5 16.25 13.50
TCG36B31S TL9E080C16UH11 21.0 CF/CM/CU60D 1100 36.0 27.6 16.25 13.50
TCG36B31S TL9E080C16UH11 21.0 CF/CM36D 1100 34.6 27.8 16.00 13.50
TCG36B31S TL9E080C16UH11 21.0 CF/CM42D 1100 35.4 27.8 16.25 13.50
TCG36B31S TL9E100C20UH11 21.0 CF/CM/CU36C 1125 34.6 28.5 16.25 13.50
TCG36B31S TL9E100C20UH11 21.0 CF/CM/CU42C 1125 35.4 28.2 16.50 13.75
TCG36B31S TL9E100C20UH11 21.0 CF/CM/CU48C 1125 36.0 28.6 16.75 14.00
TCG36B31S TL9E100C20UH11 21.0 CF/CM/CU48D 1150 36.0 28.7 16.75 14.00
TCG36B31S TL9E100C20UH11 21.0 CF/CM/CU60C 1125 36.0 28.0 16.75 13.75
TCG36B31S TL9E100C20UH11 21.0 CF/CM/CU60D 1150 36.0 28.1 16.75 13.75
TCG36B31S TL9E100C20UH11 21.0 CF/CM36D 1150 34.6 28.9 16.25 13.50
TCG36B31S TL9E100C20UH11 21.0 CF/CM42D 1150 35.4 28.7 16.75 13.75
TCG36B31S TM8E040A12MP11 14.5 CF/CM/CU36B 1025 34.6 27.1 15.75 13.00
TCG36B31S TM8E040A12MP11 14.5 CF42B 1000 35.4 26.4 16.00 13.25
TCG36B31S TM8E060A12MP11 14.5 CF/CM/CU36B 1025 34.6 27.1 15.75 13.00
TCG36B31S TM8E060A12MP11 14.5 CF42B 1000 35.4 26.4 16.00 13.25
TCG36B31S TM8E080B12MP11 17.5 CF/CM/CU36B 1025 34.6 27.1 15.75 13.00
TCG36B31S TM8E080B12MP11 17.5 CF/CM/CU36C 1050 34.6 27.2 15.75 13.00
TCG36B31S TM8E080B12MP11 17.5 CF/CM/CU42C 1050 35.4 27.3 16.00 13.50
TCG36B31S TM8E080B12MP11 17.5 CF/CM/CU48C 1050 36.0 27.3 16.25 13.50
TCG36B31S TM8E080B12MP11 17.5 CF/CM/CU60C 1050 36.0 27.0 16.00 13.25
TCG36B31S TM8E080B12MP11 17.5 CF42B 1025 35.4 26.8 16.00 13.25
TCG36B31S TM8E080C16MP11 21.0 CF/CM/CU36C 1100 34.6 28.0 16.25 13.50
TCG36B31S TM8E080C16MP11 21.0 CF/CM/CU42C 1100 35.4 27.8 16.50 13.75
TCG36B31S TM8E080C16MP11 21.0 CF/CM/CU48C 1100 36.0 28.2 16.75 13.75

5562621-CTG-C-0320
Johnson Controls Ducted Systems 11
TCG36B31S TM8E080C16MP11 21.0 CF/CM/CU48D 1100 36.0 28.2 16.50 13.75
TCG36B31S TM8E080C16MP11 21.0 CF/CM/CU60C 1275 36.0 29.7 16.25 13.50
TCG36B31S TM8E080C16MP11 21.0 CF/CM/CU60D 1125 36.0 28.0 16.50 13.75
TCG36B31S TM8E080C16MP11 21.0 CF/CM36D 1125 34.6 28.5 16.25 13.50
TCG36B31S TM8E080C16MP11 21.0 CF/CM42D 1125 35.4 28.2 16.50 13.75
TCG36B31S TM8E080C20MP11 21.0 CF/CM/CU36C 1250 34.6 29.8 16.00 13.50
TCG36B31S TM8E080C20MP11 21.0 CF/CM/CU42C 1250 35.4 29.7 16.50 13.75
TCG36B31S TM8E080C20MP11 21.0 CF/CM/CU48C 1250 36.0 29.8 16.75 13.75
TCG36B31S TM8E080C20MP11 21.0 CF/CM/CU48D 1275 36.0 30.6 16.50 13.75
TCG36B31S TM8E080C20MP11 21.0 CF/CM/CU60C 1250 36.0 29.4 16.75 13.75
TCG36B31S TM8E080C20MP11 21.0 CF/CM/CU60D 1275 36.0 30.1 16.50 13.75
TCG36B31S TM8E080C20MP11 21.0 CF/CM36D 1275 34.6 30.1 16.25 13.50
TCG36B31S TM8E080C20MP11 21.0 CF/CM42D 1275 35.4 30.3 16.75 13.75
TCG36B31S TM8E100B12MP11 17.5 CF/CM/CU36B 1075 34.6 27.7 15.75 13.00
TCG36B31S TM8E100B12MP11 17.5 CF/CM/CU36C 1100 34.6 27.8 15.75 13.00
TCG36B31S TM8E100B12MP11 17.5 CF/CM/CU42C 1100 35.4 27.6 16.00 13.50
TCG36B31S TM8E100B12MP11 17.5 CF/CM/CU48C 1100 36.0 28.3 16.25 13.50
TCG36B31S TM8E100B12MP11 17.5 CF/CM/CU60C 1100 36.0 27.4 16.00 13.25
TCG36B31S TM8E100B12MP11 17.5 CF42B 1050 35.4 27.2 16.00 13.25
TCG36B31S TM8E100C16MP11 21.0 CF/CM/CU36C 1125 34.6 28.5 16.00 13.50
TCG36B31S TM8E100C16MP11 21.0 CF/CM/CU42C 1125 35.4 28.2 16.50 13.75
TCG36B31S TM8E100C16MP11 21.0 CF/CM/CU48C 1125 36.0 28.6 16.75 13.75
TCG36B31S TM8E100C16MP11 21.0 CF/CM/CU48D 1125 36.0 28.6 16.50 13.75
TCG36B31S TM8E100C16MP11 21.0 CF/CM/CU60C 1125 36.0 28.1 16.75 13.75
TCG36B31S TM8E100C16MP11 21.0 CF/CM/CU60D 1125 36.0 28.1 16.50 13.75
TCG36B31S TM8E100C16MP11 21.0 CF/CM36D 1125 34.6 28.5 16.25 13.50
TCG36B31S TM8E100C16MP11 21.0 CF/CM42D 1125 35.4 28.2 16.50 13.75
TCG36B31S TM8E100C20MP11 21.0 CF/CM/CU36C 1250 34.6 29.8 16.00 13.50
TCG36B31S TM8E100C20MP11 21.0 CF/CM/CU42C 1250 35.4 29.7 16.50 13.75
TCG36B31S TM8E100C20MP11 21.0 CF/CM/CU48C 1250 36.0 29.8 16.75 13.75
TCG36B31S TM8E100C20MP11 21.0 CF/CM/CU48D 1275 36.0 30.6 16.50 13.75
TCG36B31S TM8E100C20MP11 21.0 CF/CM/CU60C 1250 36.0 29.4 16.50 13.75
TCG36B31S TM8E100C20MP11 21.0 CF/CM/CU60D 1275 36.0 30.1 16.50 13.75
TCG36B31S TM8E100C20MP11 21.0 CF/CM36D 1275 34.6 30.1 16.25 13.50
TCG36B31S TM8E100C20MP11 21.0 CF/CM42D 1275 35.4 30.3 16.75 13.75
TCG36B31S TM8E120C16MP11 21.0 CF/CM/CU36C 1125 34.6 28.5 16.00 13.50
TCG36B31S TM8E120C16MP11 21.0 CF/CM/CU42C 1125 35.4 28.2 16.50 13.75
TCG36B31S TM8E120C16MP11 21.0 CF/CM/CU48C 1125 36.0 28.6 16.75 13.75
TCG36B31S TM8E120C16MP11 21.0 CF/CM/CU48D 1125 36.0 28.6 16.50 13.75
TCG36B31S TM8E120C16MP11 21.0 CF/CM/CU60C 1125 36.0 28.1 16.75 13.75
TCG36B31S TM8E120C16MP11 21.0 CF/CM/CU60D 1125 36.0 28.1 16.50 13.75
TCG36B31S TM8E120C16MP11 21.0 CF/CM36D 1125 34.6 28.5 16.25 13.50
TCG36B31S TM8E120C16MP11 21.0 CF/CM42D 1125 35.4 28.2 16.50 13.75
TCG36B31S TM8E120C20MP11 21.0 CF/CM/CU36C 1275 34.6 30.1 16.00 13.25
TCG36B31S TM8E120C20MP11 21.0 CF/CM/CU42C 1275 35.4 30.3 16.50 13.75
TCG36B31S TM8E120C20MP11 21.0 CF/CM/CU48C 1300 36.0 30.6 16.75 14.00
TCG36B31S TM8E120C20MP11 21.0 CF/CM/CU48D 1300 36.0 30.6 16.50 13.75
TCG36B31S TM8E120C20MP11 21.0 CF/CM/CU60C 1275 36.0 30.2 16.50 13.75
TCG36B31S TM8E120C20MP11 21.0 CF/CM/CU60D 1325 36.0 29.2 16.50 13.75
TCG36B31S TM8E120C20MP11 21.0 CF/CM36D 1300 34.6 28.2 15.75 13.00
TCG36B31S TM8E120C20MP11 21.0 CF/CM42D 1300 35.4 30.7 16.50 13.75
TCG36B31S TM8E130D20MP11 24.5 CF/CM/CU48D 1300 36.0 30.6 16.75 14.00
TCG36B31S TM8E130D20MP11 24.5 CF/CM/CU60D 1325 36.0 29.2 16.75 14.00
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5562621-CTG-C-0320
12 Johnson Controls Ducted Systems
TCG36B31S TM8E130D20MP11 24.5 CF/CM36D 1300 34.6 28.2 15.75 13.00
TCG36B31S TM8E130D20MP11 24.5 CF/CM42D 1300 35.4 30.7 16.50 13.75
TCG36B31S TM8V080C16MP11C 21.0 CF/CM/CU36C 1050 34.6 26.0 16.20 13.50
TCG36B31S TM8V080C16MP11C 21.0 CF/CM/CU42C 1075 36.0 26.2 16.25 13.50
TCG36B31S TM8V080C16MP11C 21.0 CF/CM/CU48C 1075 36.0 26.6 16.50 13.75
TCG36B31S TM8V080C16MP11C 21.0 CF/CM/CU48D 1050 36.0 26.4 16.50 13.75
TCG36B31S TM8V080C16MP11C 21.0 CF/CM/CU60C 1075 36.0 26.4 16.50 13.75
TCG36B31S TM8V080C16MP11C 21.0 CF/CM/CU60D 1075 36.0 26.6 16.50 14.00
TCG36B31S TM8V080C16MP12C 21.0 CF/CM/CU36C 1150 34.6 28.3 16.25 13.50
TCG36B31S TM8V080C16MP12C 21.0 CF/CM/CU42C 1200 36.0 29.0 16.25 13.50
TCG36B31S TM8V080C16MP12C 21.0 CF/CM/CU48C 1150 36.0 28.2 16.50 13.75
TCG36B31S TM8V080C16MP12C 21.0 CF/CM/CU60C 1200 36.0 29.2 16.50 13.75
TCG36B31S TM8V100C16MP11C 21.0 CF/CM/CU36C 1050 34.6 26.0 16.20 13.50
TCG36B31S TM8V100C16MP11C 21.0 CF/CM/CU42C 1075 36.0 26.2 16.25 13.50
TCG36B31S TM8V100C16MP11C 21.0 CF/CM/CU48C 1075 36.0 26.6 16.50 13.75
TCG36B31S TM8V100C16MP11C 21.0 CF/CM/CU48D 1050 36.0 26.4 16.50 13.75
TCG36B31S TM8V100C16MP11C 21.0 CF/CM/CU60C 1075 36.0 26.4 16.50 13.75
TCG36B31S TM8V100C16MP11C 21.0 CF/CM/CU60D 1075 36.0 26.6 16.50 14.00
TCG36B31S TM8V100C16MP12C 21.0 CF/CM/CU36C 1150 34.6 28.3 16.25 13.50
TCG36B31S TM8V100C16MP12C 21.0 CF/CM/CU42C 1200 36.0 29.0 16.25 13.50
TCG36B31S TM8V100C16MP12C 21.0 CF/CM/CU48C 1150 36.0 28.2 16.50 13.75
TCG36B31S TM8V100C16MP12C 21.0 CF/CM/CU60C 1200 36.0 29.2 16.50 13.75
TCG36B31S TM8V100C20MP11C 21.0 CF/CM/CU36C 1150 34.6 27.2 15.75 13.50
TCG36B31S TM8V100C20MP11C 21.0 CF/CM/CU42C 1150 36.0 27.2 16.25 13.50
TCG36B31S TM8V100C20MP11C 21.0 CF/CM/CU48C 1250 36.0 28.4 16.25 13.75
TCG36B31S TM8V100C20MP11C 21.0 CF/CM/CU48D 1125 36.0 26.8 16.25 13.50
TCG36B31S TM8V100C20MP11C 21.0 CF/CM/CU60C 1225 36.0 28.2 16.50 13.75
TCG36B31S TM8V100C20MP11C 21.0 CF/CM/CU60D 1225 36.0 28.2 16.50 13.50
TCG36B31S TM8V100C20MP12C 21.0 CF/CM/CU36C 1150 34.8 28.4 16.00 13.50
TCG36B31S TM8V100C20MP12C 21.0 CF/CM/CU42C 1225 36.0 29.5 16.50 13.50
TCG36B31S TM8V100C20MP12C 21.0 CF/CM/CU48C 1150 36.0 28.3 16.50 13.75
TCG36B31S TM8V100C20MP12C 21.0 CF/CM/CU60C 1225 36.0 29.7 16.75 13.75
TCG36B31S TM8V120C20MP11C 21.0 CF/CM/CU36C 1150 34.6 27.2 15.75 13.50
TCG36B31S TM8V120C20MP11C 21.0 CF/CM/CU42C 1150 36.0 27.2 16.25 13.50
TCG36B31S TM8V120C20MP11C 21.0 CF/CM/CU48C 1250 36.0 28.4 16.25 13.75
TCG36B31S TM8V120C20MP11C 21.0 CF/CM/CU48D 1125 36.0 26.8 16.25 13.50
TCG36B31S TM8V120C20MP11C 21.0 CF/CM/CU60C 1225 36.0 28.2 16.50 13.75
TCG36B31S TM8V120C20MP11C 21.0 CF/CM/CU60D 1225 36.0 28.2 16.50 13.50
TCG36B31S TM8V120C20MP12C 21.0 CF/CM/CU36C 1150 34.8 28.4 16.00 13.50
TCG36B31S TM8V120C20MP12C 21.0 CF/CM/CU42C 1225 36.0 29.5 16.50 13.50
TCG36B31S TM8V120C20MP12C 21.0 CF/CM/CU48C 1150 36.0 28.3 16.50 13.75
TCG36B31S TM8V120C20MP12C 21.0 CF/CM/CU60C 1225 36.0 29.7 16.75 13.75
TCG36B31S TM8X060A12MP11 14.5 CF/CM36A 975 34.6 24.8 15.50 13.25
TCG36B31S TM8X080B12MP11 17.5 CF/CM/CU36B 1000 34.6 25.2 15.75 13.50
TCG36B31S TM8X080B12MP11 17.5 CF42B 1000 35.4 25.2 16.20 13.50
TCG36B31S TM8X080C16MP11 21.0 CF/CM/CU36C 1050 34.6 26.2 16.25 13.75
TCG36B31S TM8X080C16MP11 21.0 CF/CM/CU42C 1050 35.4 26.0 16.50 13.75
TCG36B31S TM8X080C16MP11 21.0 CF/CM/CU48C 1050 36.0 26.4 17.00 14.00
TCG36B31S TM8X080C16MP11 21.0 CF/CM/CU48D 1075 36.0 26.6 17.00 14.00
TCG36B31S TM8X080C16MP11 21.0 CF/CM/CU60C 1050 36.0 26.2 17.00 14.00
TCG36B31S TM8X080C16MP11 21.0 CF/CM/CU60D 1075 36.0 26.6 17.00 14.00
TCG36B31S TM8X080C16MP11 21.0 CF/CM36D 1075 34.6 26.2 16.50 13.75
TCG36B31S TM8X080C16MP11 21.0 CF/CM42D 1075 35.4 26.4 16.50 14.00
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5562621-CTG-C-0320
Johnson Controls Ducted Systems 13
TCG36B31S TM8X100C16MP11 21.0 CF/CM/CU36C 1050 34.6 26.2 16.25 13.75
TCG36B31S TM8X100C16MP11 21.0 CF/CM/CU42C 1050 35.4 26.0 16.50 13.75
TCG36B31S TM8X100C16MP11 21.0 CF/CM/CU48C 1050 36.0 26.4 17.00 14.00
TCG36B31S TM8X100C16MP11 21.0 CF/CM/CU48D 1075 36.0 26.6 17.00 14.00
TCG36B31S TM8X100C16MP11 21.0 CF/CM/CU60C 1050 36.0 26.2 17.00 14.00
TCG36B31S TM8X100C16MP11 21.0 CF/CM/CU60D 1075 36.0 26.6 17.00 14.00
TCG36B31S TM8X100C16MP11 21.0 CF/CM36D 1075 34.6 26.2 16.50 13.75
TCG36B31S TM8X100C16MP11 21.0 CF/CM42D 1075 35.4 26.4 16.50 14.00
TCG36B31S TM8X100C20MP11 21.0 CF/CM/CU36C 1075 34.6 26.2 16.25 13.75
TCG36B31S TM8X100C20MP11 21.0 CF/CM/CU42C 1075 35.4 26.4 16.50 14.00
TCG36B31S TM8X100C20MP11 21.0 CF/CM/CU48C 1075 36.0 26.6 17.00 14.00
TCG36B31S TM8X100C20MP11 21.0 CF/CM/CU48D 1100 36.0 26.8 17.00 14.00
TCG36B31S TM8X100C20MP11 21.0 CF/CM/CU60C 1075 36.0 26.6 17.00 14.25
TCG36B31S TM8X100C20MP11 21.0 CF/CM/CU60D 1075 36.0 26.6 17.00 14.25
TCG36B31S TM8X100C20MP11 21.0 CF/CM36D 1100 34.6 26.2 16.50 13.75
TCG36B31S TM8X100C20MP11 21.0 CF/CM42D 1100 35.4 26.6 16.50 14.00
TCG36B31S TM8X120C20MP11 21.0 CF/CM/CU36C 1075 34.6 26.2 16.25 13.75
TCG36B31S TM8X120C20MP11 21.0 CF/CM/CU42C 1075 35.4 26.4 16.50 14.00
TCG36B31S TM8X120C20MP11 21.0 CF/CM/CU48C 1075 36.0 26.6 17.00 14.00
TCG36B31S TM8X120C20MP11 21.0 CF/CM/CU48D 1100 36.0 26.8 17.00 14.00
TCG36B31S TM8X120C20MP11 21.0 CF/CM/CU60C 1075 36.0 26.6 17.00 14.25
TCG36B31S TM8X120C20MP11 21.0 CF/CM/CU60D 1075 36.0 26.6 17.00 14.25
TCG36B31S TM8X120C20MP11 21.0 CF/CM36D 1100 34.6 26.2 16.50 13.75
TCG36B31S TM8X120C20MP11 21.0 CF/CM42D 1100 35.4 26.6 16.50 14.00
TCG36B31S TM8Y060A12MP11 14.5 CF/CM36A 975 34.6 24.8 15.50 13.25
TCG36B31S TM8Y080B12MP11 17.5 CF/CM/CU36B 1000 34.6 25.2 15.75 13.50
TCG36B31S TM8Y080B12MP11 17.5 CF42B 1000 35.4 25.2 16.20 13.50
TCG36B31S TM8Y080C16MP11 21.0 CF/CM/CU36C 1050 34.6 26.2 16.25 13.75
TCG36B31S TM8Y080C16MP11 21.0 CF/CM/CU42C 1050 35.4 26.0 16.50 13.75
TCG36B31S TM8Y080C16MP11 21.0 CF/CM/CU48C 1050 36.0 26.4 17.00 14.00
TCG36B31S TM8Y080C16MP11 21.0 CF/CM/CU48D 1075 36.0 26.6 17.00 14.00
TCG36B31S TM8Y080C16MP11 21.0 CF/CM/CU60C 1050 36.0 26.2 17.00 14.00
TCG36B31S TM8Y080C16MP11 21.0 CF/CM/CU60D 1075 36.0 26.6 17.00 14.00
TCG36B31S TM8Y080C16MP11 21.0 CF/CM36D 1075 34.6 26.2 16.50 13.75
TCG36B31S TM8Y080C16MP11 21.0 CF/CM42D 1075 35.4 26.4 16.50 14.00
TCG36B31S TM8Y100C16MP11 21.0 CF/CM/CU36C 1050 34.6 26.2 16.25 13.75
TCG36B31S TM8Y100C16MP11 21.0 CF/CM/CU42C 1050 35.4 26.0 16.50 13.75
TCG36B31S TM8Y100C16MP11 21.0 CF/CM/CU48C 1050 36.0 26.4 17.00 14.00
TCG36B31S TM8Y100C16MP11 21.0 CF/CM/CU48D 1075 36.0 26.6 17.00 14.00
TCG36B31S TM8Y100C16MP11 21.0 CF/CM/CU60C 1050 36.0 26.2 17.00 14.00
TCG36B31S TM8Y100C16MP11 21.0 CF/CM/CU60D 1075 36.0 26.6 17.00 14.00
TCG36B31S TM8Y100C16MP11 21.0 CF/CM36D 1075 34.6 26.2 16.50 13.75
TCG36B31S TM8Y100C16MP11 21.0 CF/CM42D 1075 35.4 26.4 16.50 14.00
TCG36B31S TM8Y100C20MP11 21.0 CF/CM/CU36C 1075 34.6 26.2 16.25 13.75
TCG36B31S TM8Y100C20MP11 21.0 CF/CM/CU42C 1075 35.4 26.4 16.50 14.00
TCG36B31S TM8Y100C20MP11 21.0 CF/CM/CU48C 1075 36.0 26.6 17.00 14.00
TCG36B31S TM8Y100C20MP11 21.0 CF/CM/CU48D 1100 36.0 26.8 17.00 14.00
TCG36B31S TM8Y100C20MP11 21.0 CF/CM/CU60C 1075 36.0 26.6 17.00 14.25
TCG36B31S TM8Y100C20MP11 21.0 CF/CM/CU60D 1075 36.0 26.6 17.00 14.25
TCG36B31S TM8Y100C20MP11 21.0 CF/CM36D 1100 34.6 26.2 16.50 13.75
TCG36B31S TM8Y100C20MP11 21.0 CF/CM42D 1100 35.4 26.6 16.50 14.00
TCG36B31S TM8Y120C20MP11 21.0 CF/CM/CU36C 1075 34.6 26.2 16.25 13.75
TCG36B31S TM8Y120C20MP11 21.0 CF/CM/CU42C 1075 35.4 26.4 16.50 14.00
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5562621-CTG-C-0320
14 Johnson Controls Ducted Systems
TCG36B31S TM8Y120C20MP11 21.0 CF/CM/CU48C 1075 36.0 26.6 17.00 14.00
TCG36B31S TM8Y120C20MP11 21.0 CF/CM/CU48D 1100 36.0 26.8 17.00 14.00
TCG36B31S TM8Y120C20MP11 21.0 CF/CM/CU60C 1075 36.0 26.6 17.00 14.25
TCG36B31S TM8Y120C20MP11 21.0 CF/CM/CU60D 1075 36.0 26.6 17.00 14.25
TCG36B31S TM8Y120C20MP11 21.0 CF/CM36D 1100 34.6 26.2 16.50 13.75
TCG36B31S TM8Y120C20MP11 21.0 CF/CM42D 1100 35.4 26.6 16.50 14.00
TCG36B31S TM9E060A10MP12 14.5 CF/CM/CU36B 1025 34.6 26.8 15.00 12.50
TCG36B31S TM9E060A10MP12 14.5 CF42B 1025 35.4 26.7 15.25 12.50
TCG36B31S TM9E060B12MP11 17.5 CF/CM/CU36B 1100 34.6 27.5 15.25 12.50
TCG36B31S TM9E060B12MP11 17.5 CF/CM/CU36C 975 34.6 26.4 15.25 12.50
TCG36B31S TM9E060B12MP11 17.5 CF/CM/CU42C 975 35.4 26.1 15.50 12.75
TCG36B31S TM9E060B12MP11 17.5 CF/CM/CU48C 975 36.0 26.5 15.75 13.00
TCG36B31S TM9E060B12MP11 17.5 CF/CM/CU60C 975 36.0 25.8 15.75 13.00
TCG36B31S TM9E060B12MP11 17.5 CF42B 1100 35.4 27.5 15.50 12.75
TCG36B31S TM9E060B12MP12 17.5 CF/CM/CU36B 1075 34.6 27.6 15.00 12.50
TCG36B31S TM9E060B12MP12 17.5 CF/CM/CU36C 1100 34.6 27.7 15.25 12.50
TCG36B31S TM9E060B12MP12 17.5 CF/CM/CU42C 1100 35.4 27.5 15.50 12.75
TCG36B31S TM9E060B12MP12 17.5 CF/CM/CU48C 1100 36.0 27.9 15.75 13.00
TCG36B31S TM9E060B12MP12 17.5 CF/CM/CU60C 1100 36.0 27.3 15.50 12.75
TCG36B31S TM9E060B12MP12 17.5 CF42B 1050 35.4 27.0 15.50 12.75
TCG36B31S TM9E080B12MP11 17.5 CF/CM/CU36B 975 34.6 24.8 15.50 13.25
TCG36B31S TM9E080B12MP11 17.5 CF42B 975 35.4 25.2 16.20 13.25
TCG36B31S TM9E080B12MP12 17.5 CF/CM/CU36B 1050 34.6 27.0 15.50 12.75
TCG36B31S TM9E080B12MP12 17.5 CF/CM/CU36C 1075 34.6 27.7 15.75 13.00
TCG36B31S TM9E080B12MP12 17.5 CF/CM/CU42C 1075 35.4 27.6 16.00 13.25
TCG36B31S TM9E080B12MP12 17.5 CF/CM/CU48C 1075 36.0 27.8 16.00 13.25
TCG36B31S TM9E080B12MP12 17.5 CF/CM/CU60C 1075 36.0 27.3 16.00 13.25
TCG36B31S TM9E080B12MP12 17.5 CF42B 1025 35.4 26.8 15.75 13.00
TCG36B31S TM9E080C16MP11 21.0 CF/CM/CU36C 975 34.6 26.5 16.00 13.50
TCG36B31S TM9E080C16MP11 21.0 CF/CM/CU42C 975 35.4 26.2 16.25 13.50
TCG36B31S TM9E080C16MP11 21.0 CF/CM/CU48C 975 36.0 26.4 16.50 13.75
TCG36B31S TM9E080C16MP11 21.0 CF/CM/CU48D 975 36.0 26.4 16.50 13.75
TCG36B31S TM9E080C16MP11 21.0 CF/CM/CU60C 975 36.0 26.0 16.50 13.75
TCG36B31S TM9E080C16MP11 21.0 CF/CM/CU60D 1000 36.0 26.3 16.50 13.75
TCG36B31S TM9E080C16MP11 21.0 CF/CM36D 975 34.6 26.5 16.25 13.50
TCG36B31S TM9E080C16MP11 21.0 CF/CM42D 975 35.4 26.2 16.50 13.75
TCG36B31S TM9E080C16MP12 21.0 CF/CM/CU36C 1075 34.6 27.7 15.75 13.00
TCG36B31S TM9E080C16MP12 21.0 CF/CM/CU42C 1075 35.4 27.8 16.25 13.50
TCG36B31S TM9E080C16MP12 21.0 CF/CM/CU48C 1100 36.0 28.2 16.50 13.75
TCG36B31S TM9E080C16MP12 21.0 CF/CM/CU48D 1100 36.0 28.2 16.50 13.50
TCG36B31S TM9E080C16MP12 21.0 CF/CM/CU60C 1075 36.0 27.5 16.25 13.50
TCG36B31S TM9E080C16MP12 21.0 CF/CM/CU60D 1100 36.0 27.6 16.25 13.50
TCG36B31S TM9E080C16MP12 21.0 CF/CM36D 1100 34.6 27.8 16.00 13.50
TCG36B31S TM9E080C16MP12 21.0 CF/CM42D 1100 35.4 27.8 16.25 13.50
TCG36B31S TM9E080C20MP12 21.0 CF/CM/CU36C 1225 34.6 29.5 16.00 13.50
TCG36B31S TM9E080C20MP12 21.0 CF/CM/CU42C 1225 35.4 29.3 16.50 13.75
TCG36B31S TM9E080C20MP12 21.0 CF/CM/CU48C 1225 36.0 29.6 16.75 13.75
TCG36B31S TM9E080C20MP12 21.0 CF/CM/CU48D 1250 36.0 29.8 16.50 13.75
TCG36B31S TM9E080C20MP12 21.0 CF/CM/CU60C 1225 36.0 28.9 16.75 13.75
TCG36B31S TM9E080C20MP12 21.0 CF/CM/CU60D 1250 36.0 29.4 16.50 13.75
TCG36B31S TM9E080C20MP12 21.0 CF/CM36D 1250 34.6 29.8 16.25 13.50
TCG36B31S TM9E080C20MP12 21.0 CF/CM42D 1250 35.4 29.7 16.75 14.00
TCG36B31S TM9E100C16MP11 21.0 CF/CM/CU36C 1075 34.6 26.0 16.20 13.50
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5562621-CTG-C-0320
Johnson Controls Ducted Systems 15
TCG36B31S TM9E100C16MP11 21.0 CF/CM/CU42C 1075 35.4 26.2 16.25 13.75
TCG36B31S TM9E100C16MP11 21.0 CF/CM/CU48C 1075 36.0 26.6 16.50 13.75
TCG36B31S TM9E100C16MP11 21.0 CF/CM/CU48D 1075 36.0 26.6 16.50 14.00
TCG36B31S TM9E100C16MP11 21.0 CF/CM/CU60C 1075 36.0 26.6 16.50 14.00
TCG36B31S TM9E100C16MP11 21.0 CF/CM/CU60D 1075 36.0 26.6 16.50 14.00
TCG36B31S TM9E100C16MP11 21.0 CF/CM36D 1075 34.6 26.2 16.25 13.50
TCG36B31S TM9E100C16MP11 21.0 CF/CM42D 1075 35.4 26.2 16.50 13.75
TCG36B31S TM9E100C16MP12 21.0 CF/CM/CU36C 1075 34.6 27.9 16.00 13.50
TCG36B31S TM9E100C16MP12 21.0 CF/CM/CU42C 1075 35.4 27.8 16.50 13.75
TCG36B31S TM9E100C16MP12 21.0 CF/CM/CU48C 1075 36.0 28.0 16.75 13.75
TCG36B31S TM9E100C16MP12 21.0 CF/CM/CU48D 1075 36.0 28.0 16.50 13.75
TCG36B31S TM9E100C16MP12 21.0 CF/CM/CU60C 1075 36.0 27.4 16.50 13.75
TCG36B31S TM9E100C16MP12 21.0 CF/CM/CU60D 1075 36.0 27.4 16.25 13.50
TCG36B31S TM9E100C16MP12 21.0 CF/CM36D 1075 34.6 27.9 16.00 13.50
TCG36B31S TM9E100C16MP12 21.0 CF/CM42D 1075 35.4 27.7 16.50 13.75
TCG36B31S TM9E100C20MP11 21.0 CF/CM/CU36C 975 34.6 25.2 16.25 13.75
TCG36B31S TM9E100C20MP11 21.0 CF/CM/CU42C 975 35.4 25.4 16.50 13.75
TCG36B31S TM9E100C20MP11 21.0 CF/CM/CU48C 975 36.0 25.4 17.00 14.00
TCG36B31S TM9E100C20MP11 21.0 CF/CM/CU48D 1000 36.0 25.4 17.00 14.00
TCG36B31S TM9E100C20MP11 21.0 CF/CM/CU60C 1250 36.0 28.4 16.50 14.00
TCG36B31S TM9E100C20MP11 21.0 CF/CM/CU60D 975 36.0 25.6 17.00 14.00
TCG36B31S TM9E100C20MP11 21.0 CF/CM36D 975 34.6 25.2 16.25 13.75
TCG36B31S TM9E100C20MP11 21.0 CF/CM42D 975 35.4 25.4 16.50 13.75
TCG36B31S TM9E100C20MP12 21.0 CF/CM/CU36C 1200 34.6 29.2 16.00 13.50
TCG36B31S TM9E100C20MP12 21.0 CF/CM/CU42C 1225 35.4 29.2 16.50 13.75
TCG36B31S TM9E100C20MP12 21.0 CF/CM/CU48C 1225 36.0 29.6 16.75 13.75
TCG36B31S TM9E100C20MP12 21.0 CF/CM/CU48D 1225 36.0 29.6 16.50 13.75
TCG36B31S TM9E100C20MP12 21.0 CF/CM/CU60C 1225 36.0 28.9 16.75 14.00
TCG36B31S TM9E100C20MP12 21.0 CF/CM/CU60D 1250 36.0 29.9 16.50 13.75
TCG36B31S TM9E100C20MP12 21.0 CF/CM36D 1225 34.6 29.7 16.25 13.50
TCG36B31S TM9E100C20MP12 21.0 CF/CM42D 1225 35.4 29.2 16.50 13.75
TCG36B31S TM9E120D20MP11 24.5 CF/CM/CU48D 1000 36.0 25.4 17.00 14.00
TCG36B31S TM9E120D20MP11 24.5 CF/CM/CU60D 975 36.0 25.6 17.00 14.25
TCG36B31S TM9E120D20MP11 24.5 CF/CM36D 975 34.6 25.2 16.50 14.00
TCG36B31S TM9E120D20MP11 24.5 CF/CM42D 975 35.4 25.4 16.50 14.00
TCG36B31S TM9E120D20MP12 24.5 CF/CM/CU48D 1250 36.0 29.8 16.75 13.75
TCG36B31S TM9E120D20MP12 24.5 CF/CM/CU60D 1250 36.0 29.4 16.50 13.75
TCG36B31S TM9E120D20MP12 24.5 CF/CM36D 1250 34.6 29.8 16.00 13.50
TCG36B31S TM9E120D20MP12 24.5 CF/CM42D 1250 35.4 29.7 16.50 13.75
TCG36B31S TM9V060B12MP11C 17.5 CF/CM/CU36B 1050 34.6 26.0 15.75 13.25
TCG36B31S TM9V060B12MP11C 17.5 CF/CM/CU36C 1000 34.6 26.4 15.25 12.50
TCG36B31S TM9V060B12MP11C 17.5 CF/CM/CU42C 1000 35.4 26.4 15.75 13.00
TCG36B31S TM9V060B12MP11C 17.5 CF/CM/CU48C 1000 36.0 26.7 15.75 13.00
TCG36B31S TM9V060B12MP11C 17.5 CF/CM/CU60C 1000 36.0 26.2 15.75 13.00
TCG36B31S TM9V060B12MP11C 17.5 CF42B 1050 35.4 25.8 16.20 13.50
TCG36B31S TM9V060B12MP12C 17.5 CF/CM/CU36B 1000 34.6 26.2 15.50 12.75
TCG36B31S TM9V060B12MP12C 17.5 CF/CM/CU36C 1000 34.6 26.4 15.25 12.50
TCG36B31S TM9V060B12MP12C 17.5 CF/CM/CU42C 1000 35.4 26.4 15.75 13.00
TCG36B31S TM9V060B12MP12C 17.5 CF/CM/CU48C 1000 36.0 26.7 15.75 13.00
TCG36B31S TM9V060B12MP12C 17.5 CF/CM/CU60C 1000 36.0 26.2 15.75 13.00
TCG36B31S TM9V060B12MP12C 17.5 CF42B 1000 35.4 26.3 15.75 13.00
TCG36B31S TM9V080B12MP11C 17.5 CF/CM/CU36B 1050 34.6 26.0 15.75 13.25
TCG36B31S TM9V080B12MP11C 17.5 CF42B 1050 35.4 25.8 16.20 13.50
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5562621-CTG-C-0320
16 Johnson Controls Ducted Systems
TCG36B31S TM9V080B12MP12C 17.5 CF/CM/CU36B 1175 35.0 28.8 15.75 13.25
TCG36B31S TM9V080B12MP12C 17.5 CF42B 1075 35.4 26.4 16.00 13.25
TCG36B31S TM9V080C16MP11C 21.0 CF/CM/CU36C 1000 34.6 25.4 16.20 13.75
TCG36B31S TM9V080C16MP11C 21.0 CF/CM/CU42C 1000 35.4 25.2 16.50 13.75
TCG36B31S TM9V080C16MP11C 21.0 CF/CM/CU48C 1250 36.0 28.4 16.25 13.50
TCG36B31S TM9V080C16MP11C 21.0 CF/CM/CU48D 1200 36.0 27.8 16.50 14.00
TCG36B31S TM9V080C16MP11C 21.0 CF/CM/CU60C 1200 36.0 27.8 16.50 14.00
TCG36B31S TM9V080C16MP11C 21.0 CF/CM/CU60D 1050 36.0 26.2 16.50 14.00
TCG36B31S TM9V100C16MP11C 21.0 CF/CM/CU36C 1000 34.6 25.4 16.20 13.75
TCG36B31S TM9V100C16MP11C 21.0 CF/CM/CU42C 1000 35.4 25.2 16.50 13.75
TCG36B31S TM9V100C16MP11C 21.0 CF/CM/CU48C 1250 36.0 28.4 16.25 13.50
TCG36B31S TM9V100C16MP11C 21.0 CF/CM/CU48D 1200 36.0 27.8 16.50 14.00
TCG36B31S TM9V100C16MP11C 21.0 CF/CM/CU60C 1200 36.0 27.8 16.50 14.00
TCG36B31S TM9V100C16MP11C 21.0 CF/CM/CU60D 1050 36.0 26.2 16.50 14.00
TCG36B31S TM9V100C16MP12C 21.0 CF/CM/CU36C 1175 35.6 29.1 16.25 13.75
TCG36B31S TM9V100C16MP12C 21.0 CF/CM/CU42C 1175 36.0 28.7 16.50 13.75
TCG36B31S TM9V100C16MP12C 21.0 CF/CM/CU48C 1175 36.0 28.8 16.50 13.75
TCG36B31S TM9V100C16MP12C 21.0 CF/CM/CU60C 1175 36.0 28.8 16.50 14.00
TCG36B31S TM9V100C20MP11C 21.0 CF/CM/CU36C 1075 34.6 26.0 15.75 13.50
TCG36B31S TM9V100C20MP11C 21.0 CF/CM/CU42C 1250 35.4 28.0 15.75 13.25
TCG36B31S TM9V100C20MP11C 21.0 CF/CM/CU48C 1175 36.0 27.4 16.25 13.50
TCG36B31S TM9V100C20MP11C 21.0 CF/CM/CU48D 1250 36.0 28.4 16.25 13.50
TCG36B31S TM9V100C20MP11C 21.0 CF/CM/CU60C 1175 36.0 27.6 16.25 13.50
TCG36B31S TM9V100C20MP11C 21.0 CF/CM/CU60D 1175 36.0 27.6 16.50 13.75
TCG36B31S TM9V100C20MP12C 21.0 CF/CM/CU36C 1225 35.2 29.4 15.75 13.50
TCG36B31S TM9V100C20MP12C 21.0 CF/CM/CU42C 1225 35.4 29.4 16.25 13.50
TCG36B31S TM9V100C20MP12C 21.0 CF/CM/CU48C 1225 36.0 29.6 16.25 13.50
TCG36B31S TM9V100C20MP12C 21.0 CF/CM/CU60C 1225 36.0 29.8 16.50 13.50
TCG36B31S TM9V120D20MP11C 24.5 CF/CM/CU48D 1225 36.0 28.0 16.50 13.75
TCG36B31S TM9V120D20MP11C 24.5 CF/CM/CU60D 1250 36.0 28.6 16.50 14.00
TCG36B31S TM9V120D20MP11C 24.5 CF/CM36D 1125 34.6 26.2 16.50 14.00
TCG36B31S TM9V120D20MP11C 24.5 CF/CM42D 1125 35.4 27.0 16.50 13.75
TCG36B31S TM9V120D20MP12C 24.5 CF/CM/CU36D 1200 34.6 29.1 16.50 14.25
TCG36B31S TM9V120D20MP12C 24.5 CF/CM/CU42D 1200 35.8 29.0 16.75 13.75
TCG36B31S TM9V120D20MP12C 24.5 CF/CM/CU48D 1200 36.0 29.4 16.75 13.75
TCG36B31S TM9V120D20MP12C 24.5 CF/CM/CU60D 1200 36.0 29.6 16.75 14.00
TCG36B31S TM9Y060B12MP11 17.5 CF/CM/CU36B 1100 34.6 27.5 15.25 12.50
TCG36B31S TM9Y060B12MP11 17.5 CF/CM/CU36C 975 34.6 26.4 15.25 12.50
TCG36B31S TM9Y060B12MP11 17.5 CF/CM/CU42C 975 35.4 26.1 15.50 12.75
TCG36B31S TM9Y060B12MP11 17.5 CF/CM/CU48C 975 36.0 26.5 15.75 13.00
TCG36B31S TM9Y060B12MP11 17.5 CF/CM/CU60C 975 36.0 25.8 15.75 13.00
TCG36B31S TM9Y060B12MP11 17.5 CF42B 1100 35.4 27.5 15.50 12.75
TCG36B31S TM9Y080B12MP11 17.5 CF/CM/CU36B 975 34.6 24.8 15.50 13.25
TCG36B31S TM9Y080B12MP11 17.5 CF42B 975 35.4 25.2 16.20 13.25
TCG36B31S TM9Y080C16MP11 21.0 CF/CM/CU36C 975 34.6 26.5 16.00 13.50
TCG36B31S TM9Y080C16MP11 21.0 CF/CM/CU42C 975 35.4 26.2 16.25 13.50
TCG36B31S TM9Y080C16MP11 21.0 CF/CM/CU48C 975 36.0 26.4 16.50 13.75
TCG36B31S TM9Y080C16MP11 21.0 CF/CM/CU48D 975 36.0 26.4 16.50 13.75
TCG36B31S TM9Y080C16MP11 21.0 CF/CM/CU60C 975 36.0 26.0 16.50 13.75
TCG36B31S TM9Y080C16MP11 21.0 CF/CM/CU60D 1000 36.0 26.3 16.50 13.75
TCG36B31S TM9Y080C16MP11 21.0 CF/CM36D 975 34.6 26.5 16.25 13.50
TCG36B31S TM9Y080C16MP11 21.0 CF/CM42D 975 35.4 26.2 16.50 13.75
TCG36B31S TM9Y100C16MP11 21.0 CF/CM/CU36C 1075 34.6 26.0 16.20 13.50
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5562621-CTG-C-0320
Johnson Controls Ducted Systems 17
TCG36B31S TM9Y100C16MP11 21.0 CF/CM/CU42C 1075 35.4 26.2 16.25 13.75
TCG36B31S TM9Y100C16MP11 21.0 CF/CM/CU48C 1075 36.0 26.6 16.50 13.75
TCG36B31S TM9Y100C16MP11 21.0 CF/CM/CU48D 1075 36.0 26.6 16.50 14.00
TCG36B31S TM9Y100C16MP11 21.0 CF/CM/CU60C 1075 36.0 26.6 16.50 14.00
TCG36B31S TM9Y100C16MP11 21.0 CF/CM/CU60D 1075 36.0 26.6 16.50 14.00
TCG36B31S TM9Y100C16MP11 21.0 CF/CM36D 1075 34.6 26.2 16.25 13.50
TCG36B31S TM9Y100C16MP11 21.0 CF/CM42D 1075 35.4 26.2 16.50 13.75
TCG36B31S TM9Y100C20MP11 21.0 CF/CM/CU36C 975 34.6 25.2 16.25 13.75
TCG36B31S TM9Y100C20MP11 21.0 CF/CM/CU42C 975 35.4 25.4 16.50 13.75
TCG36B31S TM9Y100C20MP11 21.0 CF/CM/CU48C 975 36.0 25.4 17.00 14.00
TCG36B31S TM9Y100C20MP11 21.0 CF/CM/CU48D 1000 36.0 25.4 17.00 14.00
TCG36B31S TM9Y100C20MP11 21.0 CF/CM/CU60C 1250 36.0 28.4 16.50 14.00
TCG36B31S TM9Y100C20MP11 21.0 CF/CM/CU60D 975 36.0 25.6 17.00 14.00
TCG36B31S TM9Y100C20MP11 21.0 CF/CM36D 975 34.6 25.2 16.25 13.75
TCG36B31S TM9Y100C20MP11 21.0 CF/CM42D 975 35.4 25.4 16.50 13.75
TCG36B31S TM9Y120D20MP11 24.5 CF/CM/CU48D 1000 36.0 25.4 17.00 14.00
TCG36B31S TM9Y120D20MP11 24.5 CF/CM/CU60D 975 36.0 25.6 17.00 14.25
TCG36B31S TM9Y120D20MP11 24.5 CF/CM36D 975 34.6 25.2 16.50 14.00
TCG36B31S TM9Y120D20MP11 24.5 CF/CM42D 975 35.4 25.4 16.50 14.00
TCG36B31S TMLE040A12MP11 14.5 CF/CM/CU36B 1025 34.6 27.1 15.75 13.00
TCG36B31S TMLE040A12MP11 14.5 CF42B 1000 35.4 26.4 16.00 13.25
TCG36B31S TMLE060A12MP11 14.5 CF/CM/CU36B 1025 34.6 27.1 15.75 13.00
TCG36B31S TMLE060A12MP11 14.5 CF42B 1000 35.4 26.4 16.00 13.25
TCG36B31S TMLE080B12MP11 17.5 CF/CM/CU36B 1025 34.6 27.1 15.75 13.00
TCG36B31S TMLE080B12MP11 17.5 CF/CM/CU36C 1050 34.6 27.2 15.75 13.00
TCG36B31S TMLE080B12MP11 17.5 CF/CM/CU42C 1050 35.4 27.3 16.00 13.50
TCG36B31S TMLE080B12MP11 17.5 CF/CM/CU48C 1050 36.0 27.3 16.25 13.50
TCG36B31S TMLE080B12MP11 17.5 CF/CM/CU60C 1050 36.0 27.0 16.00 13.25
TCG36B31S TMLE080B12MP11 17.5 CF42B 1025 35.4 26.8 16.00 13.25
TCG36B31S TMLE080C16MP11 21.0 CF/CM/CU36C 1100 34.6 28.0 16.25 13.50
TCG36B31S TMLE080C16MP11 21.0 CF/CM/CU42C 1100 35.4 27.8 16.50 13.75
TCG36B31S TMLE080C16MP11 21.0 CF/CM/CU48C 1100 36.0 28.2 16.75 13.75
TCG36B31S TMLE080C16MP11 21.0 CF/CM/CU48D 1100 36.0 28.2 16.50 13.75
TCG36B31S TMLE080C16MP11 21.0 CF/CM/CU60C 1275 36.0 29.7 16.25 13.50
TCG36B31S TMLE080C16MP11 21.0 CF/CM/CU60D 1125 36.0 28.0 16.50 13.75
TCG36B31S TMLE080C16MP11 21.0 CF/CM36D 1125 34.6 28.5 16.25 13.50
TCG36B31S TMLE080C16MP11 21.0 CF/CM42D 1125 35.4 28.2 16.50 13.75
TCG36B31S TMLE080C20MP11 21.0 CF/CM/CU36C 1250 34.6 29.8 16.00 13.50
TCG36B31S TMLE080C20MP11 21.0 CF/CM/CU42C 1250 35.4 29.7 16.50 13.75
TCG36B31S TMLE080C20MP11 21.0 CF/CM/CU48C 1250 36.0 29.8 16.75 13.75
TCG36B31S TMLE080C20MP11 21.0 CF/CM/CU48D 1275 36.0 30.6 16.50 13.75
TCG36B31S TMLE080C20MP11 21.0 CF/CM/CU60C 1250 36.0 29.4 16.75 13.75
TCG36B31S TMLE080C20MP11 21.0 CF/CM/CU60D 1275 36.0 30.1 16.50 13.75
TCG36B31S TMLE080C20MP11 21.0 CF/CM36D 1275 34.6 30.1 16.25 13.50
TCG36B31S TMLE080C20MP11 21.0 CF/CM42D 1275 35.4 30.3 16.75 13.75
TCG36B31S TMLE100B12MP11 17.5 CF/CM/CU36B 1075 34.6 27.7 15.75 13.00
TCG36B31S TMLE100B12MP11 17.5 CF/CM/CU36C 1100 34.6 27.8 15.75 13.00
TCG36B31S TMLE100B12MP11 17.5 CF/CM/CU42C 1100 35.4 27.6 16.00 13.50
TCG36B31S TMLE100B12MP11 17.5 CF/CM/CU48C 1100 36.0 28.3 16.25 13.50
TCG36B31S TMLE100B12MP11 17.5 CF/CM/CU60C 1100 36.0 27.4 16.00 13.25
TCG36B31S TMLE100B12MP11 17.5 CF42B 1050 35.4 27.2 16.00 13.25
TCG36B31S TMLE100C16MP11 21.0 CF/CM/CU36C 1125 34.6 28.5 16.00 13.50
TCG36B31S TMLE100C16MP11 21.0 CF/CM/CU42C 1125 35.4 28.2 16.50 13.75
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5562621-CTG-C-0320
18 Johnson Controls Ducted Systems
TCG36B31S TMLE100C16MP11 21.0 CF/CM/CU48C 1125 36.0 28.6 16.75 13.75
TCG36B31S TMLE100C16MP11 21.0 CF/CM/CU48D 1125 36.0 28.6 16.50 13.75
TCG36B31S TMLE100C16MP11 21.0 CF/CM/CU60C 1125 36.0 28.1 16.75 13.75
TCG36B31S TMLE100C16MP11 21.0 CF/CM/CU60D 1125 36.0 28.1 16.50 13.75
TCG36B31S TMLE100C16MP11 21.0 CF/CM36D 1125 34.6 28.5 16.25 13.50
TCG36B31S TMLE100C16MP11 21.0 CF/CM42D 1125 35.4 28.2 16.50 13.75
TCG36B31S TMLE100C20MP11 21.0 CF/CM/CU36C 1250 34.6 29.8 16.00 13.50
TCG36B31S TMLE100C20MP11 21.0 CF/CM/CU42C 1250 35.4 29.7 16.50 13.75
TCG36B31S TMLE100C20MP11 21.0 CF/CM/CU48C 1250 36.0 29.8 16.75 13.75
TCG36B31S TMLE100C20MP11 21.0 CF/CM/CU48D 1275 36.0 30.6 16.50 13.75
TCG36B31S TMLE100C20MP11 21.0 CF/CM/CU60C 1250 36.0 29.4 16.50 13.75
TCG36B31S TMLE100C20MP11 21.0 CF/CM/CU60D 1275 36.0 30.1 16.50 13.75
TCG36B31S TMLE100C20MP11 21.0 CF/CM36D 1275 34.6 30.1 16.25 13.50
TCG36B31S TMLE100C20MP11 21.0 CF/CM42D 1275 35.4 30.3 16.75 13.75
TCG36B31S TMLE120C16MP11 21.0 CF/CM/CU36C 1125 34.6 28.5 16.00 13.50
TCG36B31S TMLE120C16MP11 21.0 CF/CM/CU42C 1125 35.4 28.2 16.50 13.75
TCG36B31S TMLE120C16MP11 21.0 CF/CM/CU48C 1125 36.0 28.6 16.75 13.75
TCG36B31S TMLE120C16MP11 21.0 CF/CM/CU48D 1125 36.0 28.6 16.50 13.75
TCG36B31S TMLE120C16MP11 21.0 CF/CM/CU60C 1125 36.0 28.1 16.75 13.75
TCG36B31S TMLE120C16MP11 21.0 CF/CM/CU60D 1125 36.0 28.1 16.50 13.75
TCG36B31S TMLE120C16MP11 21.0 CF/CM36D 1125 34.6 28.5 16.25 13.50
TCG36B31S TMLE120C16MP11 21.0 CF/CM42D 1125 35.4 28.2 16.50 13.75
TCG36B31S TMLE120C20MP11 21.0 CF/CM/CU36C 1275 34.6 30.1 16.00 13.25
TCG36B31S TMLE120C20MP11 21.0 CF/CM/CU42C 1275 35.4 30.3 16.50 13.75
TCG36B31S TMLE120C20MP11 21.0 CF/CM/CU48C 1300 36.0 30.6 16.75 14.00
TCG36B31S TMLE120C20MP11 21.0 CF/CM/CU48D 1300 36.0 30.6 16.50 13.75
TCG36B31S TMLE120C20MP11 21.0 CF/CM/CU60C 1275 36.0 30.2 16.50 13.75
TCG36B31S TMLE120C20MP11 21.0 CF/CM/CU60D 1325 36.0 29.2 16.50 13.75
TCG36B31S TMLE120C20MP11 21.0 CF/CM36D 1300 34.6 28.2 15.75 13.00
TCG36B31S TMLE120C20MP11 21.0 CF/CM42D 1300 35.4 30.7 16.50 13.75
TCG36B31S TMLE130D20MP11 24.5 CF/CM/CU48D 1300 36.0 30.6 16.75 14.00
TCG36B31S TMLE130D20MP11 24.5 CF/CM/CU60D 1325 36.0 29.2 16.75 14.00
TCG36B31S TMLE130D20MP11 24.5 CF/CM36D 1300 34.6 28.2 15.75 13.00
TCG36B31S TMLE130D20MP11 24.5 CF/CM42D 1300 35.4 30.7 16.50 13.75
TCG36B31S TMLV080C16MP11C 21.0 CF/CM/CU36C 1050 34.6 26.0 16.20 13.50
TCG36B31S TMLV080C16MP11C 21.0 CF/CM/CU42C 1075 36.0 26.2 16.25 13.50
TCG36B31S TMLV080C16MP11C 21.0 CF/CM/CU48C 1075 36.0 26.6 16.50 13.75
TCG36B31S TMLV080C16MP11C 21.0 CF/CM/CU48D 1050 36.0 26.4 16.50 13.75
TCG36B31S TMLV080C16MP11C 21.0 CF/CM/CU60C 1075 36.0 26.4 16.50 13.75
TCG36B31S TMLV080C16MP11C 21.0 CF/CM/CU60D 1075 36.0 26.6 16.50 14.00
TCG36B31S TMLV080C16MP12C 21.0 CF/CM/CU36C 1150 34.6 28.3 16.25 13.50
TCG36B31S TMLV080C16MP12C 21.0 CF/CM/CU42C 1200 36.0 29.0 16.25 13.50
TCG36B31S TMLV080C16MP12C 21.0 CF/CM/CU48C 1150 36.0 28.2 16.50 13.75
TCG36B31S TMLV080C16MP12C 21.0 CF/CM/CU60C 1200 36.0 29.2 16.50 13.75
TCG36B31S TMLV100C16MP11C 21.0 CF/CM/CU36C 1050 34.6 26.0 16.20 13.50
TCG36B31S TMLV100C16MP11C 21.0 CF/CM/CU42C 1075 36.0 26.2 16.25 13.50
TCG36B31S TMLV100C16MP11C 21.0 CF/CM/CU48C 1075 36.0 26.6 16.50 13.75
TCG36B31S TMLV100C16MP11C 21.0 CF/CM/CU48D 1050 36.0 26.4 16.50 13.75
TCG36B31S TMLV100C16MP11C 21.0 CF/CM/CU60C 1075 36.0 26.4 16.50 13.75
TCG36B31S TMLV100C16MP11C 21.0 CF/CM/CU60D 1075 36.0 26.6 16.50 14.00
TCG36B31S TMLV100C16MP12C 21.0 CF/CM/CU36C 1150 34.6 28.3 16.25 13.50
TCG36B31S TMLV100C16MP12C 21.0 CF/CM/CU42C 1200 36.0 29.0 16.25 13.50
TCG36B31S TMLV100C16MP12C 21.0 CF/CM/CU48C 1150 36.0 28.2 16.50 13.75
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5562621-CTG-C-0320
Johnson Controls Ducted Systems 19
TCG36B31S TMLV100C16MP12C 21.0 CF/CM/CU60C 1200 36.0 29.2 16.50 13.75
TCG36B31S TMLV100C20MP11C 21.0 CF/CM/CU36C 1150 34.6 27.2 15.75 13.50
TCG36B31S TMLV100C20MP11C 21.0 CF/CM/CU42C 1150 36.0 27.2 16.25 13.50
TCG36B31S TMLV100C20MP11C 21.0 CF/CM/CU48C 1250 36.0 28.4 16.25 13.75
TCG36B31S TMLV100C20MP11C 21.0 CF/CM/CU48D 1125 36.0 26.8 16.25 13.50
TCG36B31S TMLV100C20MP11C 21.0 CF/CM/CU60C 1225 36.0 28.2 16.50 13.75
TCG36B31S TMLV100C20MP11C 21.0 CF/CM/CU60D 1225 36.0 28.2 16.50 13.50
TCG36B31S TMLV100C20MP12C 21.0 CF/CM/CU36C 1150 34.8 28.4 16.00 13.50
TCG36B31S TMLV100C20MP12C 21.0 CF/CM/CU42C 1225 36.0 29.5 16.50 13.50
TCG36B31S TMLV100C20MP12C 21.0 CF/CM/CU48C 1150 36.0 28.3 16.50 13.75
TCG36B31S TMLV100C20MP12C 21.0 CF/CM/CU60C 1225 36.0 29.7 16.75 13.75
TCG36B31S TMLV120C20MP11C 21.0 CF/CM/CU36C 1150 34.6 27.2 15.75 13.50
TCG36B31S TMLV120C20MP11C 21.0 CF/CM/CU42C 1150 36.0 27.2 16.25 13.50
TCG36B31S TMLV120C20MP11C 21.0 CF/CM/CU48C 1250 36.0 28.4 16.25 13.75
TCG36B31S TMLV120C20MP11C 21.0 CF/CM/CU48D 1125 36.0 26.8 16.25 13.50
TCG36B31S TMLV120C20MP11C 21.0 CF/CM/CU60C 1225 36.0 28.2 16.50 13.75
TCG36B31S TMLV120C20MP11C 21.0 CF/CM/CU60D 1225 36.0 28.2 16.50 13.50
TCG36B31S TMLV120C20MP12C 21.0 CF/CM/CU36C 1150 34.8 28.4 16.00 13.50
TCG36B31S TMLV120C20MP12C 21.0 CF/CM/CU42C 1225 36.0 29.5 16.50 13.50
TCG36B31S TMLV120C20MP12C 21.0 CF/CM/CU48C 1150 36.0 28.3 16.50 13.75
TCG36B31S TMLV120C20MP12C 21.0 CF/CM/CU60C 1225 36.0 29.7 16.75 13.75
TCG36B31S TMLX060A12MP11 14.5 CF/CM36A 975 34.6 24.8 15.50 13.25
TCG36B31S TMLX080B12MP11 17.5 CF/CM/CU36B 1000 34.6 25.2 15.75 13.50
TCG36B31S TMLX080B12MP11 17.5 CF42B 1000 35.4 25.2 16.20 13.50
TCG36B31S TMLX080C16MP11 21.0 CF/CM/CU36C 1050 34.6 26.2 16.25 13.75
TCG36B31S TMLX080C16MP11 21.0 CF/CM/CU42C 1050 35.4 26.0 16.50 13.75
TCG36B31S TMLX080C16MP11 21.0 CF/CM/CU48C 1050 36.0 26.4 17.00 14.00
TCG36B31S TMLX080C16MP11 21.0 CF/CM/CU48D 1075 36.0 26.6 17.00 14.00
TCG36B31S TMLX080C16MP11 21.0 CF/CM/CU60C 1050 36.0 26.2 17.00 14.00
TCG36B31S TMLX080C16MP11 21.0 CF/CM/CU60D 1075 36.0 26.6 17.00 14.00
TCG36B31S TMLX080C16MP11 21.0 CF/CM36D 1075 34.6 26.2 16.50 13.75
TCG36B31S TMLX080C16MP11 21.0 CF/CM42D 1075 35.4 26.4 16.50 14.00
TCG36B31S TMLX100C16MP11 21.0 CF/CM/CU36C 1050 34.6 26.2 16.25 13.75
TCG36B31S TMLX100C16MP11 21.0 CF/CM/CU42C 1050 35.4 26.0 16.50 13.75
TCG36B31S TMLX100C16MP11 21.0 CF/CM/CU48C 1050 36.0 26.4 17.00 14.00
TCG36B31S TMLX100C16MP11 21.0 CF/CM/CU48D 1075 36.0 26.6 17.00 14.00
TCG36B31S TMLX100C16MP11 21.0 CF/CM/CU60C 1050 36.0 26.2 17.00 14.00
TCG36B31S TMLX100C16MP11 21.0 CF/CM/CU60D 1075 36.0 26.6 17.00 14.00
TCG36B31S TMLX100C16MP11 21.0 CF/CM36D 1075 34.6 26.2 16.50 13.75
TCG36B31S TMLX100C16MP11 21.0 CF/CM42D 1075 35.4 26.4 16.50 14.00
TCG36B31S TMLX100C20MP11 21.0 CF/CM/CU36C 1075 34.6 26.2 16.25 13.75
TCG36B31S TMLX100C20MP11 21.0 CF/CM/CU42C 1075 35.4 26.4 16.50 14.00
TCG36B31S TMLX100C20MP11 21.0 CF/CM/CU48C 1075 36.0 26.6 17.00 14.00
TCG36B31S TMLX100C20MP11 21.0 CF/CM/CU48D 1100 36.0 26.8 17.00 14.00
TCG36B31S TMLX100C20MP11 21.0 CF/CM/CU60C 1075 36.0 26.6 17.00 14.25
TCG36B31S TMLX100C20MP11 21.0 CF/CM/CU60D 1075 36.0 26.6 17.00 14.25
TCG36B31S TMLX100C20MP11 21.0 CF/CM36D 1100 34.6 26.2 16.50 13.75
TCG36B31S TMLX100C20MP11 21.0 CF/CM42D 1100 35.4 26.6 16.50 14.00
TCG36B31S TMLX120C20MP11 21.0 CF/CM/CU36C 1075 34.6 26.2 16.25 13.75
TCG36B31S TMLX120C20MP11 21.0 CF/CM/CU42C 1075 35.4 26.4 16.50 14.00
TCG36B31S TMLX120C20MP11 21.0 CF/CM/CU48C 1075 36.0 26.6 17.00 14.00
TCG36B31S TMLX120C20MP11 21.0 CF/CM/CU48D 1100 36.0 26.8 17.00 14.00
TCG36B31S TMLX120C20MP11 21.0 CF/CM/CU60C 1075 36.0 26.6 17.00 14.25
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5562621-CTG-C-0320
20 Johnson Controls Ducted Systems
TCG36B31S TMLX120C20MP11 21.0 CF/CM/CU60D 1075 36.0 26.6 17.00 14.25
TCG36B31S TMLX120C20MP11 21.0 CF/CM36D 1100 34.6 26.2 16.50 13.75
TCG36B31S TMLX120C20MP11 21.0 CF/CM42D 1100 35.4 26.6 16.50 14.00
TCG36B31S TP9C060B12MP12C 17.5 CF/CM/CU36B 1050 34.6 26.0 15.75 13.25
TCG36B31S TP9C060B12MP12C 17.5 CF42B 1050 35.4 25.8 16.20 13.50
TCG36B31S TP9C060B12MP13C 17.5 CF/CM/CU36B 1000 34.6 26.2 15.50 12.75
TCG36B31S TP9C060B12MP13C 17.5 CF/CM/CU36C 1000 34.6 26.4 15.25 12.50
TCG36B31S TP9C060B12MP13C 17.5 CF/CM/CU42C 1000 35.4 26.4 15.75 13.00
TCG36B31S TP9C060B12MP13C 17.5 CF/CM/CU48C 1000 36.0 26.7 15.75 13.00
TCG36B31S TP9C060B12MP13C 17.5 CF/CM/CU60C 1000 36.0 26.2 15.75 13.00
TCG36B31S TP9C060B12MP13C 17.5 CF42B 1000 35.4 26.3 15.75 13.00
TCG36B31S TP9C080B12MP12C 17.5 CF/CM/CU36B 1050 34.6 26.0 15.75 13.25
TCG36B31S TP9C080B12MP12C 17.5 CF42B 1050 35.4 25.8 16.20 13.50
TCG36B31S TP9C080B12MP13C 17.5 CF/CM/CU36B 1175 35.0 28.8 15.75 13.25
TCG36B31S TP9C080B12MP13C 17.5 CF42B 1075 35.4 26.4 16.00 13.25
TCG36B31S TP9C080C16MP12C 21.0 CF/CM/CU36C 1000 34.6 25.4 16.20 13.75
TCG36B31S TP9C080C16MP12C 21.0 CF/CM/CU42C 1000 35.4 25.2 16.50 13.75
TCG36B31S TP9C080C16MP12C 21.0 CF/CM/CU48C 1250 36.0 28.4 16.25 13.50
TCG36B31S TP9C080C16MP12C 21.0 CF/CM/CU48D 1200 36.0 27.8 16.50 14.00
TCG36B31S TP9C080C16MP12C 21.0 CF/CM/CU60C 1200 36.0 27.8 16.50 14.00
TCG36B31S TP9C080C16MP12C 21.0 CF/CM/CU60D 1050 36.0 26.2 16.50 14.00
TCG36B31S TP9C100C16MP12C 21.0 CF/CM/CU36C 1000 34.6 25.4 16.20 13.75
TCG36B31S TP9C100C16MP12C 21.0 CF/CM/CU42C 1000 35.4 25.2 16.50 13.75
TCG36B31S TP9C100C16MP12C 21.0 CF/CM/CU48C 1250 36.0 28.4 16.25 13.50
TCG36B31S TP9C100C16MP12C 21.0 CF/CM/CU48D 1200 36.0 27.8 16.50 14.00
TCG36B31S TP9C100C16MP12C 21.0 CF/CM/CU60C 1200 36.0 27.8 16.50 14.00
TCG36B31S TP9C100C16MP12C 21.0 CF/CM/CU60D 1050 36.0 26.2 16.50 14.00
TCG36B31S TP9C100C16MP13C 21.0 CF/CM/CU36C 1175 35.6 29.1 16.25 13.75
TCG36B31S TP9C100C16MP13C 21.0 CF/CM/CU42C 1175 36.0 28.7 16.50 13.75
TCG36B31S TP9C100C16MP13C 21.0 CF/CM/CU48C 1175 36.0 28.8 16.50 13.75
TCG36B31S TP9C100C16MP13C 21.0 CF/CM/CU60C 1175 36.0 28.8 16.50 14.00
TCG36B31S TP9C100C20MP12C 21.0 CF/CM/CU36C 1075 34.6 26.0 15.75 13.50
TCG36B31S TP9C100C20MP12C 21.0 CF/CM/CU42C 1250 35.4 28.0 15.75 13.25
TCG36B31S TP9C100C20MP12C 21.0 CF/CM/CU48C 1175 36.0 27.4 16.25 13.50
TCG36B31S TP9C100C20MP12C 21.0 CF/CM/CU48D 1250 36.0 28.4 16.25 13.50
TCG36B31S TP9C100C20MP12C 21.0 CF/CM/CU60C 1175 36.0 27.6 16.25 13.50
TCG36B31S TP9C100C20MP12C 21.0 CF/CM/CU60D 1175 36.0 27.6 16.50 13.75
TCG36B31S TP9C100C20MP13C 21.0 CF/CM/CU36C 1225 35.2 29.4 15.75 13.50
TCG36B31S TP9C100C20MP13C 21.0 CF/CM/CU42C 1225 35.4 29.4 16.25 13.50
TCG36B31S TP9C100C20MP13C 21.0 CF/CM/CU48C 1225 36.0 29.6 16.25 13.50
TCG36B31S TP9C100C20MP13C 21.0 CF/CM/CU60C 1225 36.0 29.8 16.50 13.50
TCG36B31S TP9C120D20MP12C 24.5 CF/CM/CU48D 1225 36.0 28.0 16.50 13.75
TCG36B31S TP9C120D20MP12C 24.5 CF/CM/CU60D 1250 36.0 28.6 16.50 14.00
TCG36B31S TP9C120D20MP12C 24.5 CF/CM36D 1125 34.6 26.2 16.50 14.00
TCG36B31S TP9C120D20MP12C 24.5 CF/CM42D 1125 35.4 27.0 16.50 13.75
TCG36B31S TP9C120D20MP13C 24.5 CF/CM/CU36D 1200 34.6 29.1 16.50 14.25
TCG36B31S TP9C120D20MP13C 24.5 CF/CM/CU42D 1200 35.8 29.0 16.75 13.75
TCG36B31S TP9C120D20MP13C 24.5 CF/CM/CU48D 1200 36.0 29.4 16.75 13.75
TCG36B31S TP9C120D20MP13C 24.5 CF/CM/CU60D 1200 36.0 29.6 16.75 14.00
TCG36B31S TPLC080C16MP12C 21.0 CF/CM/CU36C 1050 34.6 26.0 16.20 13.50
TCG36B31S TPLC080C16MP12C 21.0 CF/CM/CU42C 1075 36.0 26.2 16.25 13.50
TCG36B31S TPLC080C16MP12C 21.0 CF/CM/CU48C 1075 36.0 26.6 16.50 13.75
TCG36B31S TPLC080C16MP12C 21.0 CF/CM/CU48D 1050 36.0 26.4 16.50 13.75
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.
