Coleman TCHE24 Series Quick start guide

TECHNICAL GUIDE
HORIZONTAL DISCHARGE
SPLIT SYSTEM
AIR CONDITIONERS
14 SEER – R-410A – 1 PHASE
2, 3, 4 NOMINAL TONS
MODELS: TCHE24, 36, 48
Due to continuous product improvement, specifications
are subject to change without notice.
Visit us on the web at
www.simplygettingthejobdone.com and
www.colemanac.com
Additional rating information can be found at
www.ahridirectory.org
WARRANTY SUMMARY*
Extended 10-Years limited parts warranty.
Standard 10-Years limited compressor warranty.
Extended 10-Years limited parts warranty when product is
registered online within 90 days of purchase for replacement
or closing for new home construction.
*Does not apply to 3-Phase models, or Internet sales.
See Limited Warranty certificate in User's Information Manual for details.
FOR INSTALLATION IN ALL US REGIONS AND CANADA
Installation Allowed
®
5371952-CTG-D-0320
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
DESCRIPTION
The 14 SEER TCHE Series condensing unit is the outdoor part
of a versatile system of air conditioning. Optimized for the new
14 SEER Regional Minimum Efficiency and the high EER
required in the Southwest US, these outdoor units are specifi-
cally designed to be matched with Coleman indoor coils, fur-
naces, and air handlers to provide a complete system solution.
These remarkably compact units require only minimal service
and airflow clearances, allowing them to be positioned as close
as six inches (6") from the wall. This design allows the unit to be
located virtually anywhere – on the ground, roof, balcony, or
mounted to an outside wall. When installation footprint is lim-
ited, these units can be stacked two-high using the approved
stacking kit.
FEATURES
•Performance - Optimized for the US DOE Southwest
Region and valid for installation in all US DOE Regions.
•Small Footprint - Compact “slim-line” design allows for easy
installation in tight spaces. Units can be stacked two-high
with approved stacking kit.
•WhisperDrive™ System - The combination of a swept-wing
fan, rigid base pan, isolated compressor compartment, and
quiet scroll compressor reduce sound to as low as 70 dBA.
•Low Operating Sound Levels - The swept-wing condenser
fan in blow-through configuration provides for whisper-quiet
operation by allowing air to flow smoothly and efficiently
across the fan blades.
•Quality Condenser Coils - The coil is constructed of alumi-
num microchannel tubing and enhanced aluminum fins for
compact size and increased efficiency.
•Environmentally Friendly Refrigerant - The next genera-
tion refrigerant R-410A delivers environmentally friendly per-
formance with zero ozone depletion.
•Durable Cabinet - Heavy-gauge steel cabinet and tubular
base rails provide added support.
•Aesthetic Appearance - Powder paint “Champagne” color
provides an attractive retail finish.
•Agency Listed - Safety certified by CSA to UL 1995 / CSA
22.2. Performance certified to ANSI/AHRI Standard 210/240
in accordance with the Unitary Small Equipment certification
program.
• Other Features:
– Factory installed filter drier
– High pressure and low pressure switches
– Accumulator and crankcase heater in all sizes
– Up to 200’ line set out of the box
– Zero lot line - only 6” minimum clearance from structure

5371952-CTG-D-0320
2 Johnson Controls Ducted Systems
LIST OF SECTIONS
DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
NOMENCLATURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
PHYSICAL AND ELECTRICAL DATA . . . . . . . . . . . . . . . . . . . . . . . 3
SYSTEM CHARGE FOR VARIOUS MATCHED SYSTEMS . . . . . . . 4
COOLING CAPACITY - With Air Handler Coils . . . . . . . . . . . . . . . 5
COOLING CAPACITY - Upflow, Downflow &
Horizontal Furnaces and Coils (Coil Only Ratings) . . . . . . . . . . . 6
COOLING CAPACITY - With High Efficiency Motor Furnaces . . . 6
APPLICATIONS AND ACCESSORIES . . . . . . . . . . . . . . . . . . . . . 19
SOUND POWER RATINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
MECHANICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . 20
TYPICAL INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
MOUNTING HOLE GRAPHIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
TYPICAL FIELD WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
PERFORMANCE DATA - 2 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 22
PERFORMANCE DATA - 3 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 28
PERFORMANCE DATA - 4 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 30
NOMENCLATURE
BRAND TT= Factory Branded
PRODUCT TYPE CC= Air Conditioner
(US Northern or Southeast Region)
AIRFLOW HH= Horizontal Discharge
NOMINAL
SERIES EFFICIENCY
AND STAGING EE= 14 SEER High EER
(US DOE Southwest Region)
NOMINAL
UNIT CAPACITY
(MBH) 36 24 = 2 Ton
36 = 3 Ton
48 = 4 Ton
STAGING SS = Single Stage Compressor
REFRIGERANT 44 = R-410A Refrigerant
VOLTAGE
(Voltage-Phase-Hertz) 11= 208/230-1-60
CONNECTION TYPE SS = Sweat Connect
GENERATION
(MAJOR REVISION) 11= 1st Gen
2= 2nd Gen
etc
STYLE LETTER
(MINOR REVISION)
NOT USED
FOR ORDERING
A
A= Style A
B= Style B
etc

5371952-CTG-D-0320
Johnson Controls Ducted Systems 3
.All dimensions are in inches and are subject to change without notice.
Overall height is from bottom of mounting feet to top of unit.
Overall length and width include mounting feet and screw heads.
PHYSICAL AND ELECTRICAL DATA
MODEL TCHE24S41S1 TCHE36S41S1 TCHE48S41S1
Unit Supply Voltage 208-230V, 1 60Hz
Normal Voltage Range 1
1. Rated in accordance with AHRI Standard 110-2012, utilization range “A”.
187 to 252
Minimum Circuit Ampacity 18.3 19.1 24.6
Max. Overcurrent Device Amps 2
2. Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.
30 30 40
Min. Overcurrent Device Amps 3
3. Dual element fuses or HACR circuit breaker. Minimum recommended overcurrent protection.
20 20 25
Compressor Amps Type Scroll Scroll Scroll Rated Load 13.5 14.1 18.5
Locked Rotor 58.3 72.2 124.0
Crankcase Heater Yes Yes Yes
Factory External Discharge Muffler No No No
Factory External Check Valve No No No
HS Kit Required with TXV No No No
HS Kit Part Number (S1-2SA067*****)4
4. Use S1-2SA067***** series kit. See Hard Start Kit Accessory Installation Manual.
10106 10106 10106
Fan Diameter Inches 23 23 23
Fan Motor
Rated HP 1/4 1/4 1/4
Rated Load Amps 1.3 1.3 1.3
Nominal RPM 850 850 850
Nominal CFM 3200 3200 3050
Coil Face Area Sq. Ft. 11.96 11.96 13.96 Rows Deep 1 1 1
Fins / Inch 23 23 23
Refrigerant Lines5
5. When more than 50 feet of interconnecting tubing and more than 30 feet of vertical lift is used, consult the Application Data (part number 247077).
For long-line applications, interconnecting lines over 100 feet must be installed with liquid line solenoid.
Max. Length 200 200 200
Max. Lift 65 65 65
Max. Drop 150 150 150
Liquid Line Set OD (Field Installed) 3/8 3/8 3/8
Vapor Line Set OD (Field Installed) 3/4 3/4 7/8
Unit Charge (Lbs. - Oz.) 6
6. The Unit Charge is correct for the outdoor unit, smallest matched indoor unit, and 15 feet of refrigerant tubing. For tubing lengths other than 15 feet,
add or subtract the amount of refrigerant, using the difference in length multiplied by the per foot value.
5 - 0 6 - 6 7 - 4
Charge Per Foot, Oz. 0.62 0.62 0.67
Operating Weight Lbs. 180 200 225
B
C
A
DIMENSIONS
Unit
Model
Dimensions
(Inches) Refrigerant Connection Service Valve Size
A B C Liquid Vapor
TCHE24S41S1 37-1/4 20 45 3/8 3/4
TCHE36S41S1 37-1/4 20 45
TCHE48S41S1 43-1/4 20 45 7/8

5371952-CTG-D-0320
4 Johnson Controls Ducted Systems
PROCEDURES:
1. Check the Factory Unit Charge listed on the unit nameplate to verify the refrigerant charge for the outdoor unit, the smallest matched indoor unit, and the 15 feet
of interconnecting lineset.
2. Verify the indoor metering device and additional charge required for the specific matched indoor unit in the system using the above table.
3. Add additional charge for the amount of interconnecting lineset greater than 15 feet at the rate specified in the Physical and Electrical Table.
4. For installations requiring additional charge, weigh in refrigerant for the specific matching indoor unit and actual lineset length.
5. Once the charge adders for matched indoor unit and for lineset have been weighed in, verify the system operation against the temperatures and pressures in the
Charging Chart for the outdoor unit. Locate Charging Charts on the outdoor unit and also in the Service Data Application Guide on
www.simplygettingthejobdone.com. Follow the Subcool or Superheat charging procedure in the Installation Manual according to the type of indoor metering device
in the system, and allow ten minutes after each charge adjustment for the system operation to stabilize. Record the charge adjustment made to match the Charging
Chart.
6. Permanently stamp the unit data plate with the TOTAL SYSTEM CHARGE defined as follows: TOTAL SYSTEM CHARGE = Base Charge (as shipped) + charge
adder for matched indoor unit + charge adder for actual lineset length + charge adjustments to match the Charging Chart.
SYSTEM CHARGE FOR VARIOUS MATCHED SYSTEMS
System Charge for Various Matched Systems
Outdoor Unit TCHE24S41S1 TCHE36S41S1 TCHE48S41S1
Required TXV 1,2 BA1 BA2 BA2
Indoor Unit 3,4,5Additional Charge, Oz
CF/CM/CU30(B,C,D) 0 – –
CF/CM/CU36(A,B,C,D) 7 – –
FC38C – 0 –
FC49D – – 0
AP30B 0 – –
AP36C 7 – –
AE30B 0 – –
AE36(B,C) 7 – –
AVC30B 0 – –
AVC36(B,C) 7 – –
Some of the combinations shown in the above System Charge table require Advanced Main Air Circulating Fan indoor product. For approved coil
only matches, please see the “COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils” table.
FOOTNOTES:
1. For applications requiring a TXV use S1-1TVM*** series kit.
2. ATXV kit must be used with these indoor units to obtain system performance.
3. Systems matched with furnaces or air handlers not equipped with blower-off delays may require 60 second time delay.
4. CF and FC coils cannot be used in horizontal applications.
5. Charge adders shown above do not indicate that coils are rated for every application. Refer to Performance Data Tables for actual performance for specified sys-
tem matches. Obtain certified system ratings from www.ahridirectory.org.

5371952-CTG-D-0320
Johnson Controls Ducted Systems 5
— = Not applicable.
MP ModularAir Handlers use Coil Only Ratings.
COOLING CAPACITY - With Air Handler Coils
UNIT
MODEL
AIR HANDLER COIL
MODEL1
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.
TCHE24S41S1 AE30BX21 17.5 – 900 24.00 19.50 16.00 13.00
TCHE24S41S1 AE36BX21 17.5 – 850 24.00 19.40 16.00 13.00
TCHE24S41S1 AE36CX21 21.0 – 800 24.00 18.90 16.00 13.00
TCHE24S41S1 AHE30B3X(H,T)21 17.5 – 795 24.00 18.30 15.50 12.75
TCHE24S41S1 AHE36C3X(H,T)21 21.0 – 855 24.00 18.80 15.75 13.00
TCHE24S41S1 AHV30B3X(H,T)21 17.5 – 775 24.00 18.20 15.50 12.75
TCHE24S41S1 AHV36C3X(H,T)21 21.0 – 760 24.00 17.90 15.75 13.00
TCHE24S41S1 AP30BX21 17.5 – 850 24.00 19.40 14.00 12.25
TCHE24S41S1 AVC30BX21 17.5 – 750 24.00 18.30 16.00 13.00
TCHE24S41S1 AVC36BX21 17.5 – 750 24.00 18.30 16.00 13.00
TCHE24S41S1 AVC36CX21 21.0 – 875 24.00 19.70 16.00 13.00
TCHE24S41S1 ME08BN21 17.5 CF/CM30B 800 24.00 18.70 16.00 13.00
TCHE24S41S1 ME08BN21 17.5 CF/CM36B 800 24.00 18.90 16.00 13.00
TCHE24S41S1 ME12BN21 17.5 CF/CM30B 875 24.00 19.20 16.00 13.00
TCHE24S41S1 ME12BN21 17.5 CF/CM36B 875 24.00 19.70 16.00 13.00
TCHE24S41S1 ME12CN21 21.0 CF/CM30C 850 24.00 19.30 16.00 13.00
TCHE24S41S1 ME12CN21 21.0 CF/CM36C 850 24.00 19.40 16.00 13.00
TCHE24S41S1 ME14DN21 24.5 CF/CM36D 875 24.00 19.70 16.00 13.00
TCHE24S41S1 ME16CN21 21.0 CF/CM30C 925 24.00 19.80 16.00 13.00
TCHE24S41S1 ME16CN21 21.0 CF/CM36C 925 24.00 19.80 16.00 13.00
TCHE24S41S1 MV12BN21 17.5 FC/MC35B 800 24.00 18.40 15.75 13.00
TCHE24S41S1 MV12BN21 17.5 FC/MC36B 800 24.00 18.20 15.75 13.00
TCHE24S41S1 MV12BN21 17.5 FC/MC42B 800 24.00 18.00 15.75 13.00
TCHE24S41S1 MV12BN21 17.5 FC/MC43B 800 24.00 18.20 15.75 13.00
TCHE24S41S1 MVC08BN21 17.5 CF/CM30B 800 24.00 18.70 16.00 13.00
TCHE24S41S1 MVC08BN21 17.5 CF/CM36B 800 24.00 18.90 16.00 13.00
TCHE24S41S1 MVC12BN21 17.5 CF/CM30B 875 24.00 19.20 16.00 13.00
TCHE24S41S1 MVC12BN21 17.5 CF/CM36B 875 24.00 19.60 16.00 13.00
TCHE24S41S1 MVC12CN21 21.0 CF/CM30C 875 24.00 19.30 16.00 13.00
TCHE24S41S1 MVC12CN21 21.0 CF/CM36C 875 24.00 19.70 16.00 13.00
TCHE24S41S1 MVC16CN21 21.0 CF/CM30C 925 24.00 19.80 16.00 13.00
TCHE24S41S1 MVC16CN21 21.0 CF/CM36C 925 24.00 19.80 16.00 13.00
TCHE24S41S1 MX12BN21 17.5 FC/MC35B 800 24.00 18.40 15.50 12.75
TCHE24S41S1 MX12BN21 17.5 FC/MC36B 800 24.00 18.20 15.75 13.00
TCHE24S41S1 MX12BN21 17.5 FC/MC43B 800 24.00 18.20 15.50 12.75
TCHE24S41S1 MX16CN21 21.0 FC/MC35C 800 24.00 18.40 15.25 12.75
TCHE24S41S1 MX16CN21 21.0 FC/MC36C 800 24.00 18.20 15.25 12.75
TCHE24S41S1 MX16CN21 21.0 FC/MC43C 800 24.00 18.20 15.25 12.75
TCHE36S41S1 ME16CN21 21.0 FC38C 1200 36.00 27.20 16.00 13.00
TCHE36S41S1 MVC16CN21 21.0 FC38C 1200 35.80 27.20 15.50 12.75
TCHE48S41S1 ME14DN21 24.5 FC49D 1425 46.50 34.60 15.10 12.50
TCHE48S41S1 ME20DN21 24.5 FC49D 1425 46.50 34.60 15.50 12.50
TCHE48S41S1 MVC14DN21 24.5 FC49D 1175 45.50 31.80 15.50 12.75
TCHE48S41S1 MVC20DN21 24.5 FC49D 1375 46.50 34.20 15.50 12.75
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ANSI/AHRI Standard 210/240.
Cooling MBH based on 80°F entering air temperature, 50% RH (Relative Humidity), and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTUs at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTUs during a normal annual usage period for cooling divided by the total
electric power input in watt-hours during the same period.
1. CM coils available with a factory installed horizontal drain pan. See price pages for specific model number.

5371952-CTG-D-0320
6 Johnson Controls Ducted Systems
— = Not Applicable.
MP ModularAir Handlers use Coil Only Ratings.
PSC furnaces, such as the TG8S, TGLS, and TG9S, use Coil Only Ratings.
COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils (Coil Only Ratings)
UNIT MODEL
COIL CFM RANGE
(MIN.-MAX.)
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER 1EER
TOTAL SENS.
TCHE24S41S1 CF/CM/CU30A 14.5 600 - 1000 800 24.0 18.6 14.00 12.20
TCHE24S41S1 CF/CM/CU30B 17.5 600 - 1000 800 24.0 17.5 14.00 12.20
TCHE24S41S1 CF/CM/CU36B 17.5 600 - 1000 800 24.0 18.9 14.00 12.20
TCHE24S41S1 CF/CM/CU36C 21.0 600 - 1000 800 24.0 18.9 14.00 12.20
TCHE24S41S1 CF/CM30C 21.0 600 - 1000 800 24.0 18.6 14.00 12.20
TCHE24S41S1 CF/CM36A 14.5 600 - 1000 800 24.0 18.9 14.00 12.20
TCHE24S41S1 CF/CM36D 24.5 600 - 1000 800 24.0 18.9 14.00 12.20
TCHE36S41S1 FC38C 21.0 1000 - 1400 1200 35.6 27.2 14.00 12.20
TCHE48S41S1 FC49D 21.0 1400 - 1800 1425 46.0 33.8 14.00 12.15
For rated condition information, see the footnotes below the System Capacity - Single Piece and Modular Air Handlers table.
1. Systems matched with furnaces or air handlers not equipped with blower-off delays may require 60 second time delay.
COOLING CAPACITY - With High Efficiency Motor Furnaces1
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.
TCHE24S41S1 TL8E060A12UH11 14.5 CF/CM/CU30A 650 24.0 17.4 15.50 12.75
TCHE24S41S1 TL8E060A12UH11 14.5 CF/CM/CU30B 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TL8E060A12UH11 14.5 CF/CM/CU36B 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TL8E060A12UH11 14.5 CF/CM36A 625 24.0 17.2 15.75 13.00
TCHE24S41S1 TL8E060A12UH11 14.5 CF42B 675 24.0 17.6 15.75 13.00
TCHE24S41S1 TL8E080C16UH11 21.0 CF/CM30C 950 24.0 20.0 16.00 13.00
TCHE24S41S1 TL9E060B12UH11 17.5 CF/CM/CU30B 675 24.0 17.7 15.50 12.75
TCHE24S41S1 TL9E060B12UH11 17.5 CF/CM/CU36B 650 24.0 17.6 15.75 13.00
TCHE24S41S1 TL9E060B12UH11 17.5 CF/CM/CU36C 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TL9E060B12UH11 17.5 CF/CM/CU42C 700 24.0 17.8 15.75 13.00
TCHE24S41S1 TL9E060B12UH11 17.5 CF/CM30C 700 24.0 17.9 15.50 12.75
TCHE24S41S1 TL9E060B12UH11 17.5 CF42B 675 24.0 17.7 15.75 13.00
TCHE24S41S1 TL9E080C16UH11 21.0 CF/CM/CU36C 925 24.0 19.8 16.00 13.00
TCHE24S41S1 TL9E080C16UH11 21.0 CF/CM/CU42C 925 24.0 19.7 16.00 13.00
TCHE24S41S1 TL9E080C16UH11 21.0 CF/CM30C 925 24.0 19.8 16.00 13.00
TCHE24S41S1 TL9E080C16UH11 21.0 CF/CM36D 925 24.0 19.8 16.00 13.00
TCHE24S41S1 TL9E080C16UH11 21.0 CF/CM42D 925 24.0 19.7 16.00 13.00
TCHE24S41S1 TM8E040A12MP11 14.5 CF/CM/CU30A 725 24.0 18.2 15.50 12.75
TCHE24S41S1 TM8E040A12MP11 14.5 CF/CM/CU30B 775 24.0 18.5 15.75 13.00
TCHE24S41S1 TM8E040A12MP11 14.5 CF/CM/CU36B 775 24.0 18.8 16.00 13.00
TCHE24S41S1 TM8E040A12MP11 14.5 CF/CM36A 725 24.0 18.3 15.75 13.00
TCHE24S41S1 TM8E040A12MP11 14.5 CF42B 775 24.0 18.7 16.00 13.00
TCHE24S41S1 TM8E060A12MP11 14.5 CF/CM/CU30A 725 24.0 18.2 15.50 12.75
TCHE24S41S1 TM8E060A12MP11 14.5 CF/CM/CU30B 750 24.0 18.3 15.75 13.00
TCHE24S41S1 TM8E060A12MP11 14.5 CF/CM/CU36B 825 24.0 19.1 15.75 13.00
TCHE24S41S1 TM8E060A12MP11 14.5 CF/CM36A 725 24.0 18.3 15.75 13.00
TCHE24S41S1 TM8E060A12MP11 14.5 CF42B 825 24.0 19.1 16.00 13.00
TCHE24S41S1 TM8E080B12MP11 17.5 CF/CM/CU30B 725 24.0 18.1 15.75 13.00
TCHE24S41S1 TM8E080B12MP11 17.5 CF/CM/CU36B 725 24.0 18.3 16.00 13.00
TCHE24S41S1 TM8E080B12MP11 17.5 CF/CM/CU36C 750 24.0 18.3 15.75 13.00
TCHE24S41S1 TM8E080B12MP11 17.5 CF/CM/CU42C 750 24.0 18.4 16.00 13.00
TCHE24S41S1 TM8E080B12MP11 17.5 CF/CM30C 750 24.0 18.3 15.75 13.00
TCHE24S41S1 TM8E080B12MP11 17.5 CF42B 725 24.0 18.0 16.00 13.00
TCHE24S41S1 TM8E080C16MP11 21.0 CF/CM/CU36C 825 24.0 19.1 16.00 13.00

5371952-CTG-D-0320
Johnson Controls Ducted Systems 7
TCHE24S41S1 TM8E080C16MP11 21.0 CF/CM/CU42C 825 24.0 19.2 16.00 13.00
TCHE24S41S1 TM8E080C16MP11 21.0 CF/CM30C 825 24.0 18.8 16.00 13.00
TCHE24S41S1 TM8E080C16MP11 21.0 CF/CM36D 825 24.0 19.1 16.00 13.00
TCHE24S41S1 TM8E080C16MP11 21.0 CF/CM42D 825 24.0 19.2 16.00 13.00
TCHE24S41S1 TM8E100B12MP11 17.5 CF/CM/CU30B 850 24.0 19.6 16.00 13.00
TCHE24S41S1 TM8E100B12MP11 17.5 CF/CM/CU36B 725 24.0 18.3 16.00 13.00
TCHE24S41S1 TM8E100B12MP11 17.5 CF/CM/CU36C 725 24.0 18.3 16.00 13.00
TCHE24S41S1 TM8E100B12MP11 17.5 CF/CM/CU42C 850 24.0 19.0 16.00 13.00
TCHE24S41S1 TM8E100B12MP11 17.5 CF/CM30C 850 24.0 19.6 15.75 13.00
TCHE24S41S1 TM8E100B12MP11 17.5 CF42B 825 24.0 19.1 16.00 13.00
TCHE24S41S1 TM8E100C16MP11 21.0 CF/CM/CU36C 800 24.0 18.9 16.00 13.00
TCHE24S41S1 TM8E100C16MP11 21.0 CF/CM/CU42C 800 24.0 18.8 16.00 13.00
TCHE24S41S1 TM8E100C16MP11 21.0 CF/CM30C 800 24.0 18.7 16.00 13.00
TCHE24S41S1 TM8E100C16MP11 21.0 CF/CM36D 800 24.0 18.9 16.00 13.00
TCHE24S41S1 TM8E100C16MP11 21.0 CF/CM42D 800 24.0 18.8 16.00 13.00
TCHE24S41S1 TM8E120C16MP11 21.0 CF/CM/CU36C 825 24.0 19.1 16.00 13.00
TCHE24S41S1 TM8E120C16MP11 21.0 CF/CM/CU42C 825 24.0 19.2 16.00 13.00
TCHE24S41S1 TM8E120C16MP11 21.0 CF/CM30C 800 24.0 18.7 16.00 13.00
TCHE24S41S1 TM8E120C16MP11 21.0 CF/CM36D 825 24.0 19.1 16.00 13.00
TCHE24S41S1 TM8E120C16MP11 21.0 CF/CM42D 825 24.0 19.2 16.00 13.00
TCHE24S41S1 TM8V060A12MP11C 14.5 CF/CM/CU30A 625 23.8 17.0 15.50 12.75
TCHE24S41S1 TM8V060A12MP11C 14.5 CF/CM/CU30B 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TM8V060A12MP11C 14.5 CF/CM/CU36B 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TM8V060A12MP11C 14.5 CF/CM36A 775 24.0 18.5 15.25 12.75
TCHE24S41S1 TM8V060A12MP12C 14.5 CF/CM/CU30A 625 23.8 17.0 15.50 12.75
TCHE24S41S1 TM8V060A12MP12C 14.5 CF/CM/CU30B 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TM8V060A12MP12C 14.5 CF/CM/CU36B 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TM8V060A12MP12C 14.5 CF/CM36A 725 24.0 18.3 15.50 12.75
TCHE24S41S1 TM8V080B12MP11C 17.5 CF/CM/CU30B 775 24.0 18.4 15.50 12.75
TCHE24S41S1 TM8V080B12MP11C 17.5 CF/CM/CU36B 775 24.0 18.5 15.50 12.75
TCHE24S41S1 TM8V080B12MP11C 17.5 CF/CM/CU36C 675 24.0 17.8 15.50 12.75
TCHE24S41S1 TM8V080B12MP11C 17.5 CF/CM30C 725 24.0 18.2 15.50 12.75
TCHE24S41S1 TM8V080B12MP12C 17.5 CF/CM/CU30B 675 24.0 17.6 15.50 12.75
TCHE24S41S1 TM8V080B12MP12C 17.5 CF/CM/CU36B 675 24.0 17.8 15.50 12.75
TCHE24S41S1 TM8V080B12MP12C 17.5 CF/CM/CU36C 675 24.0 17.8 15.50 12.75
TCHE24S41S1 TM8V080B12MP12C 17.5 CF/CM30C 725 24.0 18.2 15.50 12.75
TCHE24S41S1 TM8V080C16MP11C 21.0 CF/CM/CU30D 900 24.0 19.1 15.00 12.50
TCHE24S41S1 TM8V080C16MP11C 21.0 CF/CM/CU36C 875 24.0 19.4 15.25 12.75
TCHE24S41S1 TM8V080C16MP11C 21.0 CF/CM30C 875 24.0 19.2 16.00 13.00
TCHE24S41S1 TM8V080C16MP11C 21.0 CF/CM36D 875 24.0 19.6 16.00 13.00
TCHE24S41S1 TM8V080C16MP12C 21.0 CF/CM/CU30C 875 24.0 19.4 15.00 12.50
TCHE24S41S1 TM8V080C16MP12C 21.0 CF/CM/CU30D 875 24.0 19.4 15.00 12.50
TCHE24S41S1 TM8V080C16MP12C 21.0 CF/CM/CU36C 875 24.0 19.6 16.00 13.00
TCHE24S41S1 TM8V080C16MP12C 21.0 CF/CM/CU36D 875 24.0 19.4 15.25 12.75
TCHE24S41S1 TM8V080C16MP12C 21.0 CF/CM30C 875 24.0 19.2 16.00 13.00
TCHE24S41S1 TM8V080C16MP12C 21.0 CF/CM36D 875 24.0 19.6 16.00 13.00
TCHE24S41S1 TM8V100C16MP11C 21.0 CF/CM/CU30D 900 24.0 19.1 15.00 12.50
TCHE24S41S1 TM8V100C16MP11C 21.0 CF/CM/CU36C 875 24.0 19.4 15.25 12.75
TCHE24S41S1 TM8V100C16MP11C 21.0 CF/CM30C 900 24.0 19.1 15.00 12.50
TCHE24S41S1 TM8V100C16MP11C 21.0 CF/CM30C 875 24.0 19.2 16.00 13.00
TCHE24S41S1 TM8V100C16MP11C 21.0 CF/CM36D 900 24.0 19.5 15.25 12.75
TCHE24S41S1 TM8V100C16MP11C 21.0 CF/CM36D 875 24.0 19.6 16.00 13.00
TCHE24S41S1 TM8V100C16MP12C 21.0 CF/CM/CU30C 875 24.0 19.4 15.00 12.50
TCHE24S41S1 TM8V100C16MP12C 21.0 CF/CM/CU30D 875 24.0 19.4 15.00 12.50
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5371952-CTG-D-0320
8 Johnson Controls Ducted Systems
TCHE24S41S1 TM8V100C16MP12C 21.0 CF/CM/CU36C 875 24.0 19.6 16.00 13.00
TCHE24S41S1 TM8V100C16MP12C 21.0 CF/CM/CU36D 875 24.0 19.4 15.25 12.75
TCHE24S41S1 TM8V100C16MP12C 21.0 CF/CM30C 875 24.0 19.2 16.00 13.00
TCHE24S41S1 TM8V100C16MP12C 21.0 CF/CM36D 875 24.0 19.6 16.00 13.00
TCHE24S41S1 TM8X060A12MP11 14.5 CF/CM/CU30A 625 23.8 17.0 15.50 12.75
TCHE24S41S1 TM8X060A12MP11 14.5 CF/CM/CU30B 650 24.0 17.5 15.50 12.75
TCHE24S41S1 TM8X060A12MP11 14.5 CF/CM/CU36B 650 24.0 17.6 15.75 13.00
TCHE24S41S1 TM8X060A12MP11 14.5 CF/CM36A 700 24.0 18.0 15.50 12.75
TCHE24S41S1 TM8X080B12MP11 17.5 CF/CM/CU30B 775 24.0 18.5 15.75 13.00
TCHE24S41S1 TM8X080B12MP11 17.5 CF/CM/CU36B 775 24.0 18.7 15.75 13.00
TCHE24S41S1 TM8X080B12MP11 17.5 CF/CM/CU36C 700 24.0 17.9 16.00 13.00
TCHE24S41S1 TM8X080B12MP11 17.5 CF/CM30C 775 24.0 18.5 15.75 13.00
TCHE24S41S1 TM8X080C16MP11 21.0 CF/CM/CU30C 700 23.8 17.8 15.75 13.00
TCHE24S41S1 TM8X080C16MP11 21.0 CF/CM/CU30D 725 23.8 18.1 16.00 13.00
TCHE24S41S1 TM8X080C16MP11 21.0 CF/CM/CU36C 700 24.0 17.9 16.00 13.00
TCHE24S41S1 TM8X080C16MP11 21.0 CF/CM30C 700 24.0 17.9 16.00 13.00
TCHE24S41S1 TM8X080C16MP11 21.0 CF/CM36D 725 24.0 18.3 16.00 13.00
TCHE24S41S1 TM8X080C16MP11 21.0 CF/CM36D 825 24.0 19.1 16.00 13.00
TCHE24S41S1 TM8X100C16MP11 21.0 CF/CM/CU30C 700 23.8 17.8 15.75 13.00
TCHE24S41S1 TM8X100C16MP11 21.0 CF/CM/CU30D 725 23.8 18.1 16.00 13.00
TCHE24S41S1 TM8X100C16MP11 21.0 CF/CM/CU36C 700 24.0 17.9 16.00 13.00
TCHE24S41S1 TM8X100C16MP11 21.0 CF/CM30C 700 24.0 17.9 16.00 13.00
TCHE24S41S1 TM8X100C16MP11 21.0 CF/CM36D 725 24.0 18.3 16.00 13.00
TCHE24S41S1 TM8X100C16MP11 21.0 CF/CM36D 825 24.0 19.1 16.00 13.00
TCHE24S41S1 TM8X100C20MP11 21.0 CF/CM/CU30D 825 24.0 18.5 14.50 12.25
TCHE24S41S1 TM8X100C20MP11 21.0 CF/CM/CU36C 825 23.8 18.9 14.50 12.25
TCHE24S41S1 TM8X100C20MP11 21.0 CF/CM30C 825 23.8 18.3 14.50 12.25
TCHE24S41S1 TM8X100C20MP11 21.0 CF/CM36D 825 24.0 19.1 14.50 12.25
TCHE24S41S1 TM8X120C20MP11 21.0 CF/CM/CU30D 825 24.0 18.5 14.50 12.25
TCHE24S41S1 TM8X120C20MP11 21.0 CF/CM/CU36C 825 23.8 18.9 14.50 12.25
TCHE24S41S1 TM8X120C20MP11 21.0 CF/CM30C 825 23.8 18.3 14.50 12.25
TCHE24S41S1 TM8X120C20MP11 21.0 CF/CM36D 825 24.0 19.1 14.50 12.25
TCHE24S41S1 TM8Y060A12MP11 14.5 CF/CM/CU30A 625 23.8 17.0 15.50 12.75
TCHE24S41S1 TM8Y060A12MP11 14.5 CF/CM/CU30B 650 24.0 17.5 15.50 12.75
TCHE24S41S1 TM8Y060A12MP11 14.5 CF/CM/CU36B 650 24.0 17.6 15.75 13.00
TCHE24S41S1 TM8Y060A12MP11 14.5 CF/CM36A 700 24.0 18.0 15.50 12.75
TCHE24S41S1 TM8Y080B12MP11 17.5 CF/CM/CU30B 775 24.0 18.5 15.75 13.00
TCHE24S41S1 TM8Y080B12MP11 17.5 CF/CM/CU36B 775 24.0 18.7 15.75 13.00
TCHE24S41S1 TM8Y080B12MP11 17.5 CF/CM/CU36C 700 24.0 17.9 16.00 13.00
TCHE24S41S1 TM8Y080B12MP11 17.5 CF/CM30C 775 24.0 18.5 15.75 13.00
TCHE24S41S1 TM8Y080C16MP11 21.0 CF/CM/CU30C 700 23.8 17.8 15.75 13.00
TCHE24S41S1 TM8Y080C16MP11 21.0 CF/CM/CU30D 725 23.8 18.1 16.00 13.00
TCHE24S41S1 TM8Y080C16MP11 21.0 CF/CM/CU36C 700 24.0 17.9 16.00 13.00
TCHE24S41S1 TM8Y080C16MP11 21.0 CF/CM30C 700 24.0 17.9 16.00 13.00
TCHE24S41S1 TM8Y080C16MP11 21.0 CF/CM36D 725 24.0 18.3 16.00 13.00
TCHE24S41S1 TM8Y080C16MP11 21.0 CF/CM36D 825 24.0 19.1 16.00 13.00
TCHE24S41S1 TM8Y100C16MP11 21.0 CF/CM/CU30C 700 23.8 17.8 15.75 13.00
TCHE24S41S1 TM8Y100C16MP11 21.0 CF/CM/CU30D 725 23.8 18.1 16.00 13.00
TCHE24S41S1 TM8Y100C16MP11 21.0 CF/CM/CU36C 700 24.0 17.9 16.00 13.00
TCHE24S41S1 TM8Y100C16MP11 21.0 CF/CM30C 700 24.0 17.9 16.00 13.00
TCHE24S41S1 TM8Y100C16MP11 21.0 CF/CM36D 725 24.0 18.3 16.00 13.00
TCHE24S41S1 TM8Y100C16MP11 21.0 CF/CM36D 825 24.0 19.1 16.00 13.00
TCHE24S41S1 TM8Y100C20MP11 21.0 CF/CM/CU30D 825 24.0 18.5 14.50 12.25
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5371952-CTG-D-0320
Johnson Controls Ducted Systems 9
TCHE24S41S1 TM8Y100C20MP11 21.0 CF/CM/CU36C 825 23.8 18.9 14.50 12.25
TCHE24S41S1 TM8Y100C20MP11 21.0 CF/CM30C 825 23.8 18.3 14.50 12.25
TCHE24S41S1 TM8Y100C20MP11 21.0 CF/CM36D 825 24.0 19.1 14.50 12.25
TCHE24S41S1 TM8Y120C20MP11 21.0 CF/CM/CU30D 825 24.0 18.5 14.50 12.25
TCHE24S41S1 TM8Y120C20MP11 21.0 CF/CM/CU36C 825 23.8 18.9 14.50 12.25
TCHE24S41S1 TM8Y120C20MP11 21.0 CF/CM30C 825 23.8 18.3 14.50 12.25
TCHE24S41S1 TM8Y120C20MP11 21.0 CF/CM36D 825 24.0 19.1 14.50 12.25
TCHE24S41S1 TM9E040A10MP11 14.5 CF/CM/CU30A 675 23.8 17.5 14.75 12.25
TCHE24S41S1 TM9E040A10MP11 14.5 CF/CM/CU30B 700 24.0 17.9 14.75 12.50
TCHE24S41S1 TM9E040A10MP11 14.5 CF/CM/CU36B 700 24.0 18.0 15.00 12.50
TCHE24S41S1 TM9E040A10MP11 14.5 CF/CM36A 675 23.8 17.6 14.75 12.25
TCHE24S41S1 TM9E040A10MP12 14.5 CF/CM/CU30A 600 23.6 16.6 15.25 12.50
TCHE24S41S1 TM9E040A10MP12 14.5 CF/CM/CU30B 675 24.0 17.7 15.25 12.50
TCHE24S41S1 TM9E040A10MP12 14.5 CF/CM/CU36B 625 24.0 17.2 15.25 12.50
TCHE24S41S1 TM9E040A10MP12 14.5 CF/CM36A 675 24.0 17.8 15.25 12.50
TCHE24S41S1 TM9E040A10MP12 14.5 CF42B 675 24.0 17.7 15.25 12.50
TCHE24S41S1 TM9E060A10MP12 14.5 CF/CM/CU30A 675 24.0 17.7 15.25 12.50
TCHE24S41S1 TM9E060A10MP12 14.5 CF/CM/CU30B 700 24.0 18.0 15.50 12.75
TCHE24S41S1 TM9E060A10MP12 14.5 CF/CM/CU36B 700 24.0 18.0 15.50 12.75
TCHE24S41S1 TM9E060A10MP12 14.5 CF/CM36A 675 24.0 17.8 15.50 12.75
TCHE24S41S1 TM9E060A10MP12 14.5 CF42B 700 24.0 17.8 15.75 12.75
TCHE24S41S1 TM9E060B12MP11 17.5 CF/CM/CU30B 675 24.0 17.6 15.50 12.75
TCHE24S41S1 TM9E060B12MP11 17.5 CF/CM/CU36B 675 24.0 17.8 15.50 12.75
TCHE24S41S1 TM9E060B12MP11 17.5 CF/CM/CU36C 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TM9E060B12MP11 17.5 CF/CM30C 675 24.0 17.6 15.50 12.75
TCHE24S41S1 TM9E060B12MP12 17.5 CF/CM/CU30B 750 24.0 18.4 15.50 12.75
TCHE24S41S1 TM9E060B12MP12 17.5 CF/CM/CU36B 750 24.0 18.3 15.75 13.00
TCHE24S41S1 TM9E060B12MP12 17.5 CF/CM/CU36C 750 24.0 18.3 15.50 12.75
TCHE24S41S1 TM9E060B12MP12 17.5 CF/CM/CU42C 750 24.0 18.3 15.75 13.00
TCHE24S41S1 TM9E060B12MP12 17.5 CF/CM30C 750 24.0 18.4 15.50 12.75
TCHE24S41S1 TM9E060B12MP12 17.5 CF42B 725 24.0 18.1 15.75 13.00
TCHE24S41S1 TM9E080B12MP11 17.5 CF/CM/CU30B 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TM9E080B12MP11 17.5 CF/CM/CU36B 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TM9E080B12MP11 17.5 CF/CM/CU36C 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TM9E080B12MP11 17.5 CF/CM30C 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TM9E080B12MP12 17.5 CF/CM/CU30B 800 24.0 18.7 15.75 13.00
TCHE24S41S1 TM9E080B12MP12 17.5 CF/CM/CU36B 800 24.0 19.0 15.75 13.00
TCHE24S41S1 TM9E080B12MP12 17.5 CF/CM/CU36C 825 24.0 19.1 15.75 13.00
TCHE24S41S1 TM9E080B12MP12 17.5 CF/CM/CU42C 825 24.0 19.1 16.00 13.00
TCHE24S41S1 TM9E080B12MP12 17.5 CF/CM30C 825 24.0 18.8 15.75 13.00
TCHE24S41S1 TM9E080B12MP12 17.5 CF42B 775 24.0 18.7 16.00 13.00
TCHE24S41S1 TM9E080C16MP11 21.0 CF/CM/CU36C 600 23.8 16.9 15.75 13.00
TCHE24S41S1 TM9E080C16MP11 21.0 CF/CM30C 600 23.6 16.7 15.50 12.75
TCHE24S41S1 TM9E080C16MP11 21.0 CF/CM36D 600 23.8 16.9 15.75 13.00
TCHE24S41S1 TM9E080C16MP12 21.0 CF/CM/CU36C 750 24.0 18.3 16.00 13.00
TCHE24S41S1 TM9E080C16MP12 21.0 CF/CM/CU42C 750 24.0 18.4 16.00 13.00
TCHE24S41S1 TM9E080C16MP12 21.0 CF/CM30C 750 24.0 18.3 16.00 13.00
TCHE24S41S1 TM9E080C16MP12 21.0 CF/CM36D 750 24.0 18.3 16.00 13.00
TCHE24S41S1 TM9E080C16MP12 21.0 CF/CM42D 750 24.0 18.4 16.00 13.00
TCHE24S41S1 TM9E100C16MP11 21.0 CF/CM/CU30C 625 23.2 16.6 15.75 13.00
TCHE24S41S1 TM9E100C16MP11 21.0 CF/CM/CU30D 650 23.4 17.0 15.75 13.00
TCHE24S41S1 TM9E100C16MP11 21.0 CF/CM/CU36C 650 24.0 17.7 15.75 13.00
TCHE24S41S1 TM9E100C16MP11 21.0 CF/CM/CU36D 650 23.4 17.3 15.75 13.00
TCHE24S41S1 TM9E100C16MP11 21.0 CF/CM30C 625 23.8 16.9 15.75 13.00
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5371952-CTG-D-0320
10 Johnson Controls Ducted Systems
TCHE24S41S1 TM9E100C16MP11 21.0 CF/CM36D 650 24.0 17.7 15.75 13.00
TCHE24S41S1 TM9E100C16MP12 21.0 CF/CM/CU36C 800 24.0 18.9 16.00 13.00
TCHE24S41S1 TM9E100C16MP12 21.0 CF/CM/CU42C 800 24.0 18.8 16.00 13.00
TCHE24S41S1 TM9E100C16MP12 21.0 CF/CM30C 800 24.0 18.7 16.00 13.00
TCHE24S41S1 TM9E100C16MP12 21.0 CF/CM36D 800 24.0 18.9 16.00 13.00
TCHE24S41S1 TM9E100C16MP12 21.0 CF/CM42D 800 24.0 18.8 16.00 13.00
TCHE24S41S1 TM9E100C20MP11 21.0 CF/CM/CU30D 800 24.0 18.5 15.00 12.50
TCHE24S41S1 TM9E100C20MP11 21.0 CF/CM/CU36C 800 24.0 18.6 15.00 12.50
TCHE24S41S1 TM9E100C20MP11 21.0 CF/CM30C 800 24.0 18.5 15.00 12.50
TCHE24S41S1 TM9E100C20MP11 21.0 CF/CM36D 800 24.0 18.6 15.00 12.50
TCHE24S41S1 TM9E120D20MP11 24.5 CF/CM/CU30D 825 24.0 18.6 15.25 12.75
TCHE24S41S1 TM9E120D20MP11 24.5 CF/CM36D 825 24.0 19.1 15.25 12.75
TCHE24S41S1 TM9V040A10MP12C 14.5 CF/CM/CU30A 625 23.6 16.8 15.00 12.50
TCHE24S41S1 TM9V040A10MP12C 14.5 CF/CM/CU30B 625 23.8 17.0 15.00 12.50
TCHE24S41S1 TM9V040A10MP12C 14.5 CF/CM/CU36B 650 24.0 17.7 15.25 12.50
TCHE24S41S1 TM9V040A10MP12C 14.5 CF/CM36A 650 23.8 17.5 15.00 12.50
TCHE24S41S1 TM9V060B12MP11C 17.5 CF/CM/CU30B 800 24.0 18.5 15.25 12.75
TCHE24S41S1 TM9V060B12MP11C 17.5 CF/CM/CU36B 825 24.0 19.1 15.50 12.75
TCHE24S41S1 TM9V060B12MP12C 17.5 CF/CM/CU30B 700 24.0 18.0 15.50 12.75
TCHE24S41S1 TM9V060B12MP12C 17.5 CF/CM/CU36B 700 24.0 18.0 15.50 12.75
TCHE24S41S1 TM9V060B12MP12C 17.5 CF/CM/CU36C 700 24.0 17.9 15.50 12.75
TCHE24S41S1 TM9V060B12MP12C 17.5 CF/CM30C 700 24.0 17.9 15.50 12.75
TCHE24S41S1 TM9V080B12MP11C 17.5 CF/CM/CU30B 800 24.0 18.5 15.25 12.75
TCHE24S41S1 TM9V080B12MP11C 17.5 CF/CM/CU36B 825 24.0 19.1 15.50 12.75
TCHE24S41S1 TM9V080B12MP11C 17.5 CF/CM/CU36C 850 24.0 19.4 15.75 13.00
TCHE24S41S1 TM9V080B12MP11C 17.5 CF/CM30C 725 24.0 18.1 15.75 13.00
TCHE24S41S1 TM9V080B12MP12C 17.5 CF/CM/CU30B 800 24.0 18.7 15.75 13.00
TCHE24S41S1 TM9V080B12MP12C 17.5 CF/CM/CU36B 800 24.0 19.0 15.75 13.00
TCHE24S41S1 TM9V080B12MP12C 17.5 CF/CM/CU36C 850 24.0 19.4 15.75 13.00
TCHE24S41S1 TM9V080B12MP12C 17.5 CF/CM30C 725 24.0 18.1 15.75 13.00
TCHE24S41S1 TM9V080C16MP11C 21.0 CF/CM/CU30D 825 24.0 18.6 15.75 13.00
TCHE24S41S1 TM9V080C16MP11C 21.0 CF/CM/CU36C 850 24.0 19.1 15.50 12.75
TCHE24S41S1 TM9V080C16MP12C 21.0 CF/CM/CU36C 950 24.0 20.4 15.75 13.00
TCHE24S41S1 TM9V080C16MP12C 21.0 CF/CM30C 950 24.0 20.0 15.75 13.00
TCHE24S41S1 TM9V080C16MP12C 21.0 CF/CM36D 950 24.0 20.4 16.00 13.00
TCHE24S41S1 TM9V100C16MP11C 21.0 CF/CM/CU30D 825 24.0 18.6 15.75 13.00
TCHE24S41S1 TM9V100C16MP11C 21.0 CF/CM/CU36C 850 24.0 19.1 15.50 12.75
TCHE24S41S1 TM9V100C16MP11C 21.0 CF/CM30C 850 24.0 19.0 15.50 12.75
TCHE24S41S1 TM9V100C16MP11C 21.0 CF/CM30C 900 24.0 19.5 16.00 13.00
TCHE24S41S1 TM9V100C16MP11C 21.0 CF/CM36D 825 24.0 19.1 16.00 13.00
TCHE24S41S1 TM9V100C16MP11C 21.0 CF/CM36D 900 24.0 19.7 16.00 13.00
TCHE24S41S1 TM9V100C16MP12C 21.0 CF/CM/CU30C 900 24.0 19.7 15.50 12.75
TCHE24S41S1 TM9V100C16MP12C 21.0 CF/CM/CU30D 900 24.0 19.7 15.75 13.00
TCHE24S41S1 TM9V100C16MP12C 21.0 CF/CM/CU36C 900 24.0 19.7 16.00 13.00
TCHE24S41S1 TM9V100C16MP12C 21.0 CF/CM/CU36D 900 24.0 19.8 16.00 13.00
TCHE24S41S1 TM9V100C16MP12C 21.0 CF/CM30C 900 24.0 19.5 16.00 13.00
TCHE24S41S1 TM9V100C16MP12C 21.0 CF/CM36D 900 24.0 19.7 16.00 13.00
TCHE24S41S1 TM9Y040A10MP11 14.5 CF/CM/CU30A 675 23.8 17.5 14.75 12.25
TCHE24S41S1 TM9Y040A10MP11 14.5 CF/CM/CU30B 700 24.0 17.9 14.75 12.50
TCHE24S41S1 TM9Y040A10MP11 14.5 CF/CM/CU36B 700 24.0 18.0 15.00 12.50
TCHE24S41S1 TM9Y040A10MP11 14.5 CF/CM36A 675 23.8 17.6 14.75 12.25
TCHE24S41S1 TM9Y060B12MP11 17.5 CF/CM/CU30B 675 24.0 17.6 15.50 12.75
TCHE24S41S1 TM9Y060B12MP11 17.5 CF/CM/CU36B 675 24.0 17.8 15.50 12.75
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5371952-CTG-D-0320
Johnson Controls Ducted Systems 11
TCHE24S41S1 TM9Y060B12MP11 17.5 CF/CM/CU36C 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TM9Y060B12MP11 17.5 CF/CM30C 675 24.0 17.6 15.50 12.75
TCHE24S41S1 TM9Y080B12MP11 17.5 CF/CM/CU30B 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TM9Y080B12MP11 17.5 CF/CM/CU36B 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TM9Y080B12MP11 17.5 CF/CM/CU36C 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TM9Y080B12MP11 17.5 CF/CM30C 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TM9Y080C16MP11 21.0 CF/CM/CU36C 600 23.8 16.9 15.75 13.00
TCHE24S41S1 TM9Y080C16MP11 21.0 CF/CM30C 600 23.6 16.7 15.50 12.75
TCHE24S41S1 TM9Y080C16MP11 21.0 CF/CM36D 600 23.8 16.9 15.75 13.00
TCHE24S41S1 TM9Y100C16MP11 21.0 CF/CM/CU30C 625 23.2 16.6 15.75 13.00
TCHE24S41S1 TM9Y100C16MP11 21.0 CF/CM/CU30D 650 23.4 17.0 15.75 13.00
TCHE24S41S1 TM9Y100C16MP11 21.0 CF/CM/CU36C 650 24.0 17.7 15.75 13.00
TCHE24S41S1 TM9Y100C16MP11 21.0 CF/CM/CU36D 650 23.4 17.3 15.75 13.00
TCHE24S41S1 TM9Y100C16MP11 21.0 CF/CM30C 625 23.8 16.9 15.75 13.00
TCHE24S41S1 TM9Y100C16MP11 21.0 CF/CM36D 650 24.0 17.7 15.75 13.00
TCHE24S41S1 TM9Y100C20MP11 21.0 CF/CM/CU30D 800 24.0 18.5 15.00 12.50
TCHE24S41S1 TM9Y120D20MP11 24.5 CF/CM/CU30D 825 24.0 18.6 15.25 12.75
TCHE24S41S1 TMLE040A12MP11 14.5 CF/CM/CU30A 725 24.0 18.2 15.50 12.75
TCHE24S41S1 TMLE040A12MP11 14.5 CF/CM/CU30B 775 24.0 18.5 15.75 13.00
TCHE24S41S1 TMLE040A12MP11 14.5 CF/CM/CU36B 775 24.0 18.8 16.00 13.00
TCHE24S41S1 TMLE040A12MP11 14.5 CF/CM36A 725 24.0 18.3 15.75 13.00
TCHE24S41S1 TMLE040A12MP11 14.5 CF42B 775 24.0 18.7 16.00 13.00
TCHE24S41S1 TMLE060A12MP11 14.5 CF/CM/CU30A 725 24.0 18.2 15.50 12.75
TCHE24S41S1 TMLE060A12MP11 14.5 CF/CM/CU30B 750 24.0 18.3 15.75 13.00
TCHE24S41S1 TMLE060A12MP11 14.5 CF/CM/CU36B 825 24.0 19.1 15.75 13.00
TCHE24S41S1 TMLE060A12MP11 14.5 CF/CM36A 725 24.0 18.3 15.75 13.00
TCHE24S41S1 TMLE060A12MP11 14.5 CF42B 825 24.0 19.1 16.00 13.00
TCHE24S41S1 TMLE080B12MP11 17.5 CF/CM/CU30B 725 24.0 18.1 15.75 13.00
TCHE24S41S1 TMLE080B12MP11 17.5 CF/CM/CU36B 725 24.0 18.3 16.00 13.00
TCHE24S41S1 TMLE080B12MP11 17.5 CF/CM/CU36C 750 24.0 18.3 15.75 13.00
TCHE24S41S1 TMLE080B12MP11 17.5 CF/CM/CU42C 750 24.0 18.4 16.00 13.00
TCHE24S41S1 TMLE080B12MP11 17.5 CF/CM30C 750 24.0 18.3 15.75 13.00
TCHE24S41S1 TMLE080B12MP11 17.5 CF42B 725 24.0 18.0 16.00 13.00
TCHE24S41S1 TMLE080C16MP11 21.0 CF/CM/CU36C 825 24.0 19.1 16.00 13.00
TCHE24S41S1 TMLE080C16MP11 21.0 CF/CM/CU42C 825 24.0 19.2 16.00 13.00
TCHE24S41S1 TMLE080C16MP11 21.0 CF/CM30C 825 24.0 18.8 16.00 13.00
TCHE24S41S1 TMLE080C16MP11 21.0 CF/CM36D 825 24.0 19.1 16.00 13.00
TCHE24S41S1 TMLE080C16MP11 21.0 CF/CM42D 825 24.0 19.2 16.00 13.00
TCHE24S41S1 TMLE100B12MP11 17.5 CF/CM/CU30B 850 24.0 19.6 16.00 13.00
TCHE24S41S1 TMLE100B12MP11 17.5 CF/CM/CU36B 725 24.0 18.3 16.00 13.00
TCHE24S41S1 TMLE100B12MP11 17.5 CF/CM/CU36C 725 24.0 18.3 16.00 13.00
TCHE24S41S1 TMLE100B12MP11 17.5 CF/CM/CU42C 850 24.0 19.0 16.00 13.00
TCHE24S41S1 TMLE100B12MP11 17.5 CF/CM30C 850 24.0 19.6 15.75 13.00
TCHE24S41S1 TMLE100B12MP11 17.5 CF42B 825 24.0 19.1 16.00 13.00
TCHE24S41S1 TMLE100C16MP11 21.0 CF/CM/CU36C 800 24.0 18.9 16.00 13.00
TCHE24S41S1 TMLE100C16MP11 21.0 CF/CM/CU42C 800 24.0 18.8 16.00 13.00
TCHE24S41S1 TMLE100C16MP11 21.0 CF/CM30C 800 24.0 18.7 16.00 13.00
TCHE24S41S1 TMLE100C16MP11 21.0 CF/CM36D 800 24.0 18.9 16.00 13.00
TCHE24S41S1 TMLE100C16MP11 21.0 CF/CM42D 800 24.0 18.8 16.00 13.00
TCHE24S41S1 TMLE120C16MP11 21.0 CF/CM/CU36C 825 24.0 19.1 16.00 13.00
TCHE24S41S1 TMLE120C16MP11 21.0 CF/CM/CU42C 825 24.0 19.2 16.00 13.00
TCHE24S41S1 TMLE120C16MP11 21.0 CF/CM30C 800 24.0 18.7 16.00 13.00
TCHE24S41S1 TMLE120C16MP11 21.0 CF/CM36D 825 24.0 19.1 16.00 13.00
TCHE24S41S1 TMLE120C16MP11 21.0 CF/CM42D 825 24.0 19.2 16.00 13.00
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5371952-CTG-D-0320
12 Johnson Controls Ducted Systems
TCHE24S41S1 TMLV060A12MP11C 14.5 CF/CM/CU30A 625 23.8 17.0 15.50 12.75
TCHE24S41S1 TMLV060A12MP11C 14.5 CF/CM/CU30B 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TMLV060A12MP11C 14.5 CF/CM/CU36B 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TMLV060A12MP11C 14.5 CF/CM36A 775 24.0 18.5 15.25 12.75
TCHE24S41S1 TMLV060A12MP12C 14.5 CF/CM/CU30A 625 23.8 17.0 15.50 12.75
TCHE24S41S1 TMLV060A12MP12C 14.5 CF/CM/CU30B 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TMLV060A12MP12C 14.5 CF/CM/CU36B 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TMLV060A12MP12C 14.5 CF/CM36A 725 24.0 18.3 15.50 12.75
TCHE24S41S1 TMLV080B12MP11C 17.5 CF/CM/CU30B 775 24.0 18.4 15.50 12.75
TCHE24S41S1 TMLV080B12MP11C 17.5 CF/CM/CU36B 775 24.0 18.5 15.50 12.75
TCHE24S41S1 TMLV080B12MP11C 17.5 CF/CM/CU36C 675 24.0 17.8 15.50 12.75
TCHE24S41S1 TMLV080B12MP11C 17.5 CF/CM30C 725 24.0 18.2 15.50 12.75
TCHE24S41S1 TMLV080B12MP12C 17.5 CF/CM/CU30B 675 24.0 17.6 15.50 12.75
TCHE24S41S1 TMLV080B12MP12C 17.5 CF/CM/CU36B 675 24.0 17.8 15.50 12.75
TCHE24S41S1 TMLV080B12MP12C 17.5 CF/CM/CU36C 675 24.0 17.8 15.50 12.75
TCHE24S41S1 TMLV080B12MP12C 17.5 CF/CM30C 725 24.0 18.2 15.50 12.75
TCHE24S41S1 TMLV080C16MP11C 21.0 CF/CM/CU30D 900 24.0 19.1 15.00 12.50
TCHE24S41S1 TMLV080C16MP11C 21.0 CF/CM/CU36C 875 24.0 19.4 15.25 12.75
TCHE24S41S1 TMLV080C16MP11C 21.0 CF/CM30C 875 24.0 19.2 16.00 13.00
TCHE24S41S1 TMLV080C16MP11C 21.0 CF/CM36D 875 24.0 19.6 16.00 13.00
TCHE24S41S1 TMLV080C16MP12C 21.0 CF/CM/CU30C 875 24.0 19.4 15.00 12.50
TCHE24S41S1 TMLV080C16MP12C 21.0 CF/CM/CU30D 875 24.0 19.4 15.00 12.50
TCHE24S41S1 TMLV080C16MP12C 21.0 CF/CM/CU36C 875 24.0 19.6 16.00 13.00
TCHE24S41S1 TMLV080C16MP12C 21.0 CF/CM/CU36D 875 24.0 19.4 15.25 12.75
TCHE24S41S1 TMLV080C16MP12C 21.0 CF/CM30C 875 24.0 19.2 16.00 13.00
TCHE24S41S1 TMLV080C16MP12C 21.0 CF/CM36D 875 24.0 19.6 16.00 13.00
TCHE24S41S1 TMLV100C16MP11C 21.0 CF/CM/CU30D 900 24.0 19.1 15.00 12.50
TCHE24S41S1 TMLV100C16MP11C 21.0 CF/CM/CU36C 875 24.0 19.4 15.25 12.75
TCHE24S41S1 TMLV100C16MP11C 21.0 CF/CM30C 875 24.0 19.2 16.00 13.00
TCHE24S41S1 TMLV100C16MP11C 21.0 CF/CM36D 875 24.0 19.6 16.00 13.00
TCHE24S41S1 TMLV100C16MP12C 21.0 CF/CM/CU30C 875 24.0 19.4 15.00 12.50
TCHE24S41S1 TMLV100C16MP12C 21.0 CF/CM/CU30D 875 24.0 19.4 15.00 12.50
TCHE24S41S1 TMLV100C16MP12C 21.0 CF/CM/CU36C 875 24.0 19.6 16.00 13.00
TCHE24S41S1 TMLV100C16MP12C 21.0 CF/CM/CU36D 875 24.0 19.4 15.25 12.75
TCHE24S41S1 TMLV100C16MP12C 21.0 CF/CM30C 875 24.0 19.2 16.00 13.00
TCHE24S41S1 TMLV100C16MP12C 21.0 CF/CM36D 875 24.0 19.6 16.00 13.00
TCHE24S41S1 TMLX060A12MP11 14.5 CF/CM/CU30A 625 23.8 17.0 15.50 12.75
TCHE24S41S1 TMLX060A12MP11 14.5 CF/CM/CU30B 650 24.0 17.5 15.50 12.75
TCHE24S41S1 TMLX060A12MP11 14.5 CF/CM/CU36B 650 24.0 17.6 15.75 13.00
TCHE24S41S1 TMLX060A12MP11 14.5 CF/CM36A 700 24.0 18.0 15.50 12.75
TCHE24S41S1 TMLX080B12MP11 17.5 CF/CM/CU30B 775 24.0 18.5 15.75 13.00
TCHE24S41S1 TMLX080B12MP11 17.5 CF/CM/CU36B 775 24.0 18.7 15.75 13.00
TCHE24S41S1 TMLX080B12MP11 17.5 CF/CM/CU36C 700 24.0 17.9 16.00 13.00
TCHE24S41S1 TMLX080B12MP11 17.5 CF/CM30C 775 24.0 18.5 15.75 13.00
TCHE24S41S1 TMLX080C16MP11 21.0 CF/CM/CU30C 700 23.8 17.8 15.75 13.00
TCHE24S41S1 TMLX080C16MP11 21.0 CF/CM/CU30D 725 23.8 18.1 16.00 13.00
TCHE24S41S1 TMLX080C16MP11 21.0 CF/CM/CU36C 700 24.0 17.9 16.00 13.00
TCHE24S41S1 TMLX080C16MP11 21.0 CF/CM30C 700 24.0 17.9 16.00 13.00
TCHE24S41S1 TMLX080C16MP11 21.0 CF/CM36D 725 24.0 18.3 16.00 13.00
TCHE24S41S1 TMLX080C16MP11 21.0 CF/CM36D 825 24.0 19.1 16.00 13.00
TCHE24S41S1 TMLX100C16MP11 21.0 CF/CM/CU30C 700 23.8 17.8 15.75 13.00
TCHE24S41S1 TMLX100C16MP11 21.0 CF/CM/CU30D 725 23.8 18.1 16.00 13.00
TCHE24S41S1 TMLX100C16MP11 21.0 CF/CM/CU36C 700 24.0 17.9 16.00 13.00
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5371952-CTG-D-0320
Johnson Controls Ducted Systems 13
TCHE24S41S1 TMLX100C16MP11 21.0 CF/CM30C 700 24.0 17.9 16.00 13.00
TCHE24S41S1 TMLX100C16MP11 21.0 CF/CM36D 725 24.0 18.3 16.00 13.00
TCHE24S41S1 TMLX100C16MP11 21.0 CF/CM36D 825 24.0 19.1 16.00 13.00
TCHE24S41S1 TMLX100C20MP11 21.0 CF/CM/CU30D 825 24.0 18.5 14.50 12.25
TCHE24S41S1 TMLX100C20MP11 21.0 CF/CM/CU36C 825 23.8 18.9 14.50 12.25
TCHE24S41S1 TMLX100C20MP11 21.0 CF/CM30C 825 23.8 18.3 14.50 12.25
TCHE24S41S1 TMLX100C20MP11 21.0 CF/CM36D 825 24.0 19.1 14.50 12.25
TCHE24S41S1 TMLX120C20MP11 21.0 CF/CM/CU30D 825 24.0 18.5 14.50 12.25
TCHE24S41S1 TMLX120C20MP11 21.0 CF/CM/CU36C 825 23.8 18.9 14.50 12.25
TCHE24S41S1 TMLX120C20MP11 21.0 CF/CM30C 825 23.8 18.3 14.50 12.25
TCHE24S41S1 TMLX120C20MP11 21.0 CF/CM36D 825 24.0 19.1 14.50 12.25
TCHE24S41S1 TP9C060B12MP13C 17.5 CF/CM/CU30B 700 24.0 18.0 15.50 12.75
TCHE24S41S1 TP9C060B12MP13C 17.5 CF/CM/CU36B 700 24.0 18.0 15.50 12.75
TCHE24S41S1 TP9C060B12MP13C 17.5 CF/CM/CU36C 700 24.0 17.9 15.50 12.75
TCHE24S41S1 TP9C060B12MP13C 17.5 CF/CM30C 700 24.0 17.9 15.50 12.75
TCHE24S41S1 TP9C080B12MP12C 17.5 CF/CM/CU30B 800 24.0 18.5 15.25 12.75
TCHE24S41S1 TP9C080B12MP12C 17.5 CF/CM/CU36B 825 24.0 19.1 15.50 12.75
TCHE24S41S1 TP9C080B12MP12C 17.5 CF/CM/CU36C 850 24.0 19.4 15.75 13.00
TCHE24S41S1 TP9C080B12MP12C 17.5 CF/CM30C 725 24.0 18.1 15.75 13.00
TCHE24S41S1 TP9C080B12MP13C 17.5 CF/CM/CU30B 800 24.0 18.7 15.75 13.00
TCHE24S41S1 TP9C080B12MP13C 17.5 CF/CM/CU36B 800 24.0 19.0 15.75 13.00
TCHE24S41S1 TP9C080B12MP13C 17.5 CF/CM/CU36C 850 24.0 19.4 15.75 13.00
TCHE24S41S1 TP9C080B12MP13C 17.5 CF/CM30C 725 24.0 18.1 15.75 13.00
TCHE24S41S1 TP9C080C16MP12C 21.0 CF/CM/CU30D 825 24.0 18.6 15.75 13.00
TCHE24S41S1 TP9C080C16MP13C 21.0 CF/CM/CU36C 950 24.0 20.4 15.75 13.00
TCHE24S41S1 TP9C080C16MP13C 21.0 CF/CM30C 950 24.0 20.0 15.75 13.00
TCHE24S41S1 TP9C080C16MP13C 21.0 CF/CM36D 950 24.0 20.4 16.00 13.00
TCHE24S41S1 TP9C100C16MP12C 21.0 CF/CM/CU30D 825 24.0 18.6 15.75 13.00
TCHE24S41S1 TP9C100C16MP12C 21.0 CF/CM/CU36C 850 24.0 19.1 15.50 12.75
TCHE24S41S1 TP9C100C16MP12C 21.0 CF/CM30C 900 24.0 19.5 16.00 13.00
TCHE24S41S1 TP9C100C16MP12C 21.0 CF/CM36D 900 24.0 19.7 16.00 13.00
TCHE24S41S1 TP9C100C16MP13C 21.0 CF/CM/CU30C 900 24.0 19.7 15.50 12.75
TCHE24S41S1 TP9C100C16MP13C 21.0 CF/CM/CU30D 900 24.0 19.7 15.75 13.00
TCHE24S41S1 TP9C100C16MP13C 21.0 CF/CM/CU36C 900 24.0 19.7 16.00 13.00
TCHE24S41S1 TP9C100C16MP13C 21.0 CF/CM/CU36D 900 24.0 19.8 16.00 13.00
TCHE24S41S1 TP9C100C16MP13C 21.0 CF/CM30C 900 24.0 19.5 16.00 13.00
TCHE24S41S1 TP9C100C16MP13C 21.0 CF/CM36D 900 24.0 19.7 16.00 13.00
TCHE24S41S1 TPLC060A12MP12C 14.5 CF/CM/CU30A 625 23.8 17.0 15.50 12.75
TCHE24S41S1 TPLC060A12MP12C 14.5 CF/CM/CU30B 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TPLC060A12MP12C 14.5 CF/CM/CU36B 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TPLC060A12MP12C 14.5 CF/CM36A 775 24.0 18.5 15.25 12.75
TCHE24S41S1 TPLC060A12MP13C 14.5 CF/CM/CU30A 625 23.8 17.0 15.50 12.75
TCHE24S41S1 TPLC060A12MP13C 14.5 CF/CM/CU30B 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TPLC060A12MP13C 14.5 CF/CM/CU36B 700 24.0 17.9 15.75 13.00
TCHE24S41S1 TPLC060A12MP13C 14.5 CF/CM36A 725 24.0 18.3 15.50 12.75
TCHE24S41S1 TPLC080B12MP12C 17.5 CF/CM/CU30B 775 24.0 18.4 15.50 12.75
TCHE24S41S1 TPLC080B12MP12C 17.5 CF/CM/CU36B 775 24.0 18.5 15.50 12.75
TCHE24S41S1 TPLC080B12MP12C 17.5 CF/CM/CU36C 675 24.0 17.8 15.50 12.75
TCHE24S41S1 TPLC080B12MP12C 17.5 CF/CM30C 725 24.0 18.2 15.50 12.75
TCHE24S41S1 TPLC080B12MP13C 17.5 CF/CM/CU30B 675 24.0 17.6 15.50 12.75
TCHE24S41S1 TPLC080B12MP13C 17.5 CF/CM/CU36B 675 24.0 17.8 15.50 12.75
TCHE24S41S1 TPLC080B12MP13C 17.5 CF/CM/CU36C 675 24.0 17.8 15.50 12.75
TCHE24S41S1 TPLC080B12MP13C 17.5 CF/CM30C 725 24.0 18.2 15.50 12.75
TCHE24S41S1 TPLC080C16MP12C 21.0 CF/CM/CU30D 900 24.0 19.1 15.00 12.50
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5371952-CTG-D-0320
14 Johnson Controls Ducted Systems
TCHE24S41S1 TPLC080C16MP12C 21.0 CF/CM/CU36C 875 24.0 19.4 15.25 12.75
TCHE24S41S1 TPLC080C16MP12C 21.0 CF/CM30C 875 24.0 19.2 16.00 13.00
TCHE24S41S1 TPLC080C16MP12C 21.0 CF/CM36D 875 24.0 19.6 16.00 13.00
TCHE24S41S1 TPLC080C16MP13C 21.0 CF/CM/CU30C 875 24.0 19.4 15.00 12.50
TCHE24S41S1 TPLC080C16MP13C 21.0 CF/CM/CU30D 875 24.0 19.4 15.00 12.50
TCHE24S41S1 TPLC080C16MP13C 21.0 CF/CM/CU36C 875 24.0 19.6 16.00 13.00
TCHE24S41S1 TPLC080C16MP13C 21.0 CF/CM/CU36D 875 24.0 19.4 15.25 12.75
TCHE24S41S1 TPLC080C16MP13C 21.0 CF/CM30C 875 24.0 19.2 16.00 13.00
TCHE24S41S1 TPLC080C16MP13C 21.0 CF/CM36D 875 24.0 19.6 16.00 13.00
TCHE24S41S1 TPLC100C16MP12C 21.0 CF/CM/CU30D 900 24.0 19.1 15.00 12.50
TCHE24S41S1 TPLC100C16MP12C 21.0 CF/CM/CU36C 875 24.0 19.4 15.25 12.75
TCHE24S41S1 TPLC100C16MP12C 21.0 CF/CM30C 875 24.0 19.2 16.00 13.00
TCHE24S41S1 TPLC100C16MP12C 21.0 CF/CM36D 875 24.0 19.6 16.00 13.00
TCHE24S41S1 TPLC100C16MP13C 21.0 CF/CM/CU30C 875 24.0 19.4 15.00 12.50
TCHE24S41S1 TPLC100C16MP13C 21.0 CF/CM/CU30D 875 24.0 19.4 15.00 12.50
TCHE24S41S1 TPLC100C16MP13C 21.0 CF/CM/CU36C 875 24.0 19.6 16.00 13.00
TCHE24S41S1 TPLC100C16MP13C 21.0 CF/CM/CU36D 875 24.0 19.4 15.25 12.75
TCHE24S41S1 TPLC100C16MP13C 21.0 CF/CM30C 875 24.0 19.2 16.00 13.00
TCHE24S41S1 TPLC100C16MP13C 21.0 CF/CM36D 875 24.0 19.6 16.00 13.00
TCHE24S41S1 CP9C060B12MP13C 17.5 CF/CM/CU30B 700 24.0 18.0 15.50 12.75
TCHE24S41S1 CP9C060B12MP13C 17.5 CF/CM/CU36B 700 24.0 18.0 15.50 12.75
TCHE24S41S1 CP9C060B12MP13C 17.5 CF/CM/CU36C 700 24.0 17.9 15.50 12.75
TCHE24S41S1 CP9C060B12MP13C 17.5 CF/CM30C 700 24.0 17.9 15.50 12.75
TCHE24S41S1 CP9C080B12MP12C 17.5 CF/CM/CU30B 800 24.0 18.5 15.25 12.75
TCHE24S41S1 CP9C080B12MP12C 17.5 CF/CM/CU36B 825 24.0 19.1 15.50 12.75
TCHE24S41S1 CP9C080B12MP12C 17.5 CF/CM/CU36C 850 24.0 19.4 15.75 13.00
TCHE24S41S1 CP9C080B12MP12C 17.5 CF/CM30C 725 24.0 18.1 15.75 13.00
TCHE24S41S1 CP9C080B12MP13C 17.5 CF/CM/CU30B 800 24.0 18.7 15.75 13.00
TCHE24S41S1 CP9C080B12MP13C 17.5 CF/CM/CU36B 800 24.0 19.0 15.75 13.00
TCHE24S41S1 CP9C080B12MP13C 17.5 CF/CM/CU36C 850 24.0 19.4 15.75 13.00
TCHE24S41S1 CP9C080B12MP13C 17.5 CF/CM30C 725 24.0 18.1 15.75 13.00
TCHE24S41S1 CP9C080C16MP12C 21.0 CF/CM/CU30D 825 24.0 18.6 15.75 13.00
TCHE24S41S1 CP9C080C16MP13C 21.0 CF/CM/CU36C 950 24.0 20.4 15.75 13.00
TCHE24S41S1 CP9C080C16MP13C 21.0 CF/CM30C 950 24.0 20.0 15.75 13.00
TCHE24S41S1 CP9C080C16MP13C 21.0 CF/CM36D 950 24.0 20.4 16.00 13.00
TCHE24S41S1 CP9C100C16MP12C 21.0 CF/CM/CU30D 825 24.0 18.6 15.75 13.00
TCHE24S41S1 CP9C100C16MP12C 21.0 CF/CM/CU36C 850 24.0 19.1 15.50 12.75
TCHE24S41S1 CP9C100C16MP12C 21.0 CF/CM30C 900 24.0 19.5 16.00 13.00
TCHE24S41S1 CP9C100C16MP12C 21.0 CF/CM36D 900 24.0 19.7 16.00 13.00
TCHE24S41S1 CP9C100C16MP13C 21.0 CF/CM/CU30C 900 24.0 19.7 15.50 12.75
TCHE24S41S1 CP9C100C16MP13C 21.0 CF/CM/CU30D 900 24.0 19.7 15.75 13.00
TCHE24S41S1 CP9C100C16MP13C 21.0 CF/CM/CU36C 900 24.0 19.7 16.00 13.00
TCHE24S41S1 CP9C100C16MP13C 21.0 CF/CM/CU36D 900 24.0 19.8 16.00 13.00
TCHE24S41S1 CP9C100C16MP13C 21.0 CF/CM30C 900 24.0 19.5 16.00 13.00
TCHE24S41S1 CP9C100C16MP13C 21.0 CF/CM36D 900 24.0 19.7 16.00 13.00
TCHE24S41S1 CPLC060A12MP12C 14.5 CF/CM/CU30A 625 23.8 17.0 15.50 12.75
TCHE24S41S1 CPLC060A12MP12C 14.5 CF/CM/CU30B 700 24.0 17.9 15.75 13.00
TCHE24S41S1 CPLC060A12MP12C 14.5 CF/CM/CU36B 700 24.0 17.9 15.75 13.00
TCHE24S41S1 CPLC060A12MP12C 14.5 CF/CM36A 775 24.0 18.5 15.25 12.75
TCHE24S41S1 CPLC060A12MP13C 14.5 CF/CM/CU30A 625 23.8 17.0 15.50 12.75
TCHE24S41S1 CPLC060A12MP13C 14.5 CF/CM/CU30B 700 24.0 17.9 15.75 13.00
TCHE24S41S1 CPLC060A12MP13C 14.5 CF/CM/CU36B 700 24.0 17.9 15.75 13.00
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5371952-CTG-D-0320
Johnson Controls Ducted Systems 15
TCHE24S41S1 CPLC060A12MP13C 14.5 CF/CM36A 725 24.0 18.3 15.50 12.75
TCHE24S41S1 CPLC080B12MP12C 17.5 CF/CM/CU30B 775 24.0 18.4 15.50 12.75
TCHE24S41S1 CPLC080B12MP12C 17.5 CF/CM/CU36B 775 24.0 18.5 15.50 12.75
TCHE24S41S1 CPLC080B12MP12C 17.5 CF/CM/CU36C 675 24.0 17.8 15.50 12.75
TCHE24S41S1 CPLC080B12MP12C 17.5 CF/CM30C 725 24.0 18.2 15.50 12.75
TCHE24S41S1 CPLC080B12MP13C 17.5 CF/CM/CU30B 675 24.0 17.6 15.50 12.75
TCHE24S41S1 CPLC080B12MP13C 17.5 CF/CM/CU36B 675 24.0 17.8 15.50 12.75
TCHE24S41S1 CPLC080B12MP13C 17.5 CF/CM/CU36C 675 24.0 17.8 15.50 12.75
TCHE24S41S1 CPLC080B12MP13C 17.5 CF/CM30C 725 24.0 18.2 15.50 12.75
TCHE24S41S1 CPLC080C16MP12C 21.0 CF/CM/CU30D 900 24.0 19.1 15.00 12.50
TCHE24S41S1 CPLC080C16MP12C 21.0 CF/CM/CU36C 875 24.0 19.4 15.25 12.75
TCHE24S41S1 CPLC080C16MP12C 21.0 CF/CM30C 875 24.0 19.2 16.00 13.00
TCHE24S41S1 CPLC080C16MP12C 21.0 CF/CM36D 875 24.0 19.6 16.00 13.00
TCHE24S41S1 CPLC080C16MP13C 21.0 CF/CM/CU30C 875 24.0 19.4 15.00 12.50
TCHE24S41S1 CPLC080C16MP13C 21.0 CF/CM/CU30D 875 24.0 19.4 15.00 12.50
TCHE24S41S1 CPLC080C16MP13C 21.0 CF/CM/CU36C 875 24.0 19.6 16.00 13.00
TCHE24S41S1 CPLC080C16MP13C 21.0 CF/CM/CU36D 875 24.0 19.4 15.25 12.75
TCHE24S41S1 CPLC080C16MP13C 21.0 CF/CM30C 875 24.0 19.2 16.00 13.00
TCHE24S41S1 CPLC080C16MP13C 21.0 CF/CM36D 875 24.0 19.6 16.00 13.00
TCHE24S41S1 CPLC100C16MP12C 21.0 CF/CM/CU30D 900 24.0 19.1 15.00 12.50
TCHE24S41S1 CPLC100C16MP12C 21.0 CF/CM/CU36C 875 24.0 19.4 15.25 12.75
TCHE24S41S1 CPLC100C16MP12C 21.0 CF/CM30C 875 24.0 19.2 16.00 13.00
TCHE24S41S1 CPLC100C16MP12C 21.0 CF/CM36D 875 24.0 19.6 16.00 13.00
TCHE24S41S1 CPLC100C16MP13C 21.0 CF/CM/CU30C 875 24.0 19.4 15.00 12.50
TCHE24S41S1 CPLC100C16MP13C 21.0 CF/CM/CU30D 875 24.0 19.4 15.00 12.50
TCHE24S41S1 CPLC100C16MP13C 21.0 CF/CM/CU36C 875 24.0 19.6 16.00 13.00
TCHE24S41S1 CPLC100C16MP13C 21.0 CF/CM/CU36D 875 24.0 19.4 15.25 12.75
TCHE24S41S1 CPLC100C16MP13C 21.0 CF/CM30C 875 24.0 19.2 16.00 13.00
TCHE24S41S1 CPLC100C16MP13C 21.0 CF/CM36D 875 24.0 19.6 16.00 13.00
TCHE36S41S1 TL8E080C16UH11 21.0 FC38C 1125 36.0 26.8 15.75 13.00
TCHE36S41S1 TL8E100C20UH11 21.0 FC38C 1050 36.0 26.2 16.00 13.00
TCHE36S41S1 TL9E060B12UH11 17.5 FC38C 1050 35.6 26.0 15.00 12.50
TCHE36S41S1 TL9E080C16UH11 21.0 FC38C 1075 35.8 26.2 15.75 13.00
TCHE36S41S1 TL9E100C20UH11 21.0 FC38C 1125 36.0 26.8 16.00 13.00
TCHE36S41S1 TM8E080B12MP11 17.5 FC38C 1050 35.8 26.0 15.50 12.75
TCHE36S41S1 TM8E080C16MP11 21.0 FC38C 1100 36.0 26.6 16.00 13.00
TCHE36S41S1 TM8E080C20MP11 21.0 FC38C 1250 36.0 27.8 16.00 13.00
TCHE36S41S1 TM8E100B12MP11 17.5 FC38C 1100 36.0 26.6 15.50 12.75
TCHE36S41S1 TM8E100C16MP11 21.0 FC38C 1100 36.0 26.6 15.75 13.00
TCHE36S41S1 TM8E100C20MP11 21.0 FC38C 1250 36.0 27.8 16.00 13.00
TCHE36S41S1 TM8E120C16MP11 21.0 FC38C 1100 36.0 26.6 15.75 13.00
TCHE36S41S1 TM8E120C20MP11 21.0 FC38C 1275 36.0 28.0 15.75 13.00
TCHE36S41S1 TM8V080B12MP12C 17.5 FC38C 1000 34.8 25.0 15.00 12.50
TCHE36S41S1 TM8V080C16MP11C 21.0 FC38C 1200 35.6 27.0 15.10 12.50
TCHE36S41S1 TM8V080C16MP12C 21.0 FC38C 1050 35.4 25.8 15.75 13.25
TCHE36S41S1 TM8V100C16MP11C 21.0 FC38C 1200 35.6 27.0 15.10 12.50
TCHE36S41S1 TM8V100C16MP12C 21.0 FC38C 1050 35.4 25.8 15.75 13.25
TCHE36S41S1 TM8V100C20MP11C 21.0 FC38C 1150 35.8 26.8 15.50 13.00
TCHE36S41S1 TM8V100C20MP12C 21.0 FC38C 1150 36.0 27.0 16.00 13.50
TCHE36S41S1 TM8V120C20MP11C 21.0 FC38C 1150 35.8 26.8 15.50 13.00
TCHE36S41S1 TM8V120C20MP12C 21.0 FC38C 1150 36.0 27.0 16.00 13.50
TCHE36S41S1 TM8X080C16MP11 21.0 FC38C 1150 35.8 26.8 15.50 12.75
TCHE36S41S1 TM8X100C16MP11 21.0 FC38C 1150 35.8 26.8 15.50 12.75
TCHE36S41S1 TM8X100C20MP11 21.0 FC38C 1000 35.6 25.4 15.75 13.00
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5371952-CTG-D-0320
16 Johnson Controls Ducted Systems
TCHE36S41S1 TM8X120C20MP11 21.0 FC38C 1000 35.6 25.4 15.75 13.00
TCHE36S41S1 TM8Y080C16MP11 21.0 FC38C 1150 35.8 26.8 15.50 12.75
TCHE36S41S1 TM8Y100C16MP11 21.0 FC38C 1150 35.8 26.8 15.50 12.75
TCHE36S41S1 TM8Y100C20MP11 21.0 FC38C 1000 35.6 25.4 15.75 13.00
TCHE36S41S1 TM8Y120C20MP11 21.0 FC38C 1000 35.6 25.4 15.75 13.00
TCHE36S41S1 TM9E100C16MP11 21.0 FC38C 975 35.4 25.0 15.75 13.00
TCHE36S41S1 TM9E100C20MP11 21.0 FC38C 1175 35.6 26.8 15.25 12.75
TCHE36S41S1 TM9V060B12MP12C 17.5 FC38C 1100 35.4 26.0 15.00 12.50
TCHE36S41S1 TM9V080B12MP12C 17.5 FC38C 1050 35.2 25.6 15.50 13.00
TCHE36S41S1 TM9V080C16MP11C 21.0 FC38C 1175 35.8 27.0 15.50 12.75
TCHE36S41S1 TM9V080C16MP12C 21.0 FC38C 1125 35.6 26.6 15.50 13.00
TCHE36S41S1 TM9V100C16MP11C 21.0 FC38C 1175 35.8 27.0 15.50 12.75
TCHE36S41S1 TM9V100C16MP12C 21.0 FC38C 1075 35.4 26.0 16.00 13.25
TCHE36S41S1 TM9V100C20MP11C 21.0 FC38C 1200 35.6 27.0 15.25 12.75
TCHE36S41S1 TM9V100C20MP12C 21.0 FC38C 1100 35.6 26.4 15.75 13.25
TCHE36S41S1 TM9Y100C16MP11 21.0 FC38C 975 35.4 25.0 15.75 13.00
TCHE36S41S1 TM9Y100C20MP11 21.0 FC38C 1175 35.6 26.8 15.25 12.75
TCHE36S41S1 TMLE080B12MP11 17.5 FC38C 1050 35.8 26.0 15.50 12.75
TCHE36S41S1 TMLE080C16MP11 21.0 FC38C 1100 36.0 26.6 16.00 13.00
TCHE36S41S1 TMLE080C20MP11 21.0 FC38C 1250 36.0 27.8 16.00 13.00
TCHE36S41S1 TMLE100B12MP11 17.5 FC38C 1100 36.0 26.6 15.50 12.75
TCHE36S41S1 TMLE100C16MP11 21.0 FC38C 1100 36.0 26.6 15.75 13.00
TCHE36S41S1 TMLE100C20MP11 21.0 FC38C 1250 36.0 27.8 16.00 13.00
TCHE36S41S1 TMLE120C16MP11 21.0 FC38C 1100 36.0 26.6 15.75 13.00
TCHE36S41S1 TMLE120C20MP11 21.0 FC38C 1275 36.0 28.0 15.75 13.00
TCHE36S41S1 TMLV080B12MP12C 17.5 FC38C 1000 34.8 25.0 15.00 12.50
TCHE36S41S1 TMLV080C16MP11C 21.0 FC38C 1200 35.6 27.0 15.10 12.50
TCHE36S41S1 TMLV080C16MP12C 21.0 FC38C 1050 35.4 25.8 15.75 13.25
TCHE36S41S1 TMLV100C16MP11C 21.0 FC38C 1200 35.6 27.0 15.10 12.50
TCHE36S41S1 TMLV100C16MP12C 21.0 FC38C 1050 35.4 25.8 15.75 13.25
TCHE36S41S1 TMLV100C20MP11C 21.0 FC38C 1150 35.8 26.8 15.50 13.00
TCHE36S41S1 TMLV100C20MP12C 21.0 FC38C 1150 36.0 27.0 16.00 13.50
TCHE36S41S1 TMLV120C20MP11C 21.0 FC38C 1150 35.8 26.8 15.50 13.00
TCHE36S41S1 TMLV120C20MP12C 21.0 FC38C 1150 36.0 27.0 16.00 13.50
TCHE36S41S1 TMLX080C16MP11 21.0 FC38C 1150 35.8 26.8 15.50 12.75
TCHE36S41S1 TMLX100C16MP11 21.0 FC38C 1150 35.8 26.8 15.50 12.75
TCHE36S41S1 TMLX100C20MP11 21.0 FC38C 1000 35.6 25.4 15.75 13.00
TCHE36S41S1 TMLX120C20MP11 21.0 FC38C 1000 35.6 25.4 15.75 13.00
TCHE36S41S1 TP9C060B12MP13C 17.5 FC38C 1100 35.4 26.0 15.00 12.50
TCHE36S41S1 TP9C080B12MP13C 17.5 FC38C 1050 35.2 25.6 15.50 13.00
TCHE36S41S1 TP9C080C16MP12C 21.0 FC38C 1175 35.8 27.0 15.50 12.75
TCHE36S41S1 TP9C080C16MP13C 21.0 FC38C 1125 35.6 26.6 15.50 13.00
TCHE36S41S1 TP9C100C16MP12C 21.0 FC38C 1175 35.8 27.0 15.50 12.75
TCHE36S41S1 TP9C100C16MP13C 21.0 FC38C 1075 35.4 26.0 16.00 13.25
TCHE36S41S1 TP9C100C20MP12C 21.0 FC38C 1200 35.6 27.0 15.25 12.75
TCHE36S41S1 TP9C100C20MP13C 21.0 FC38C 1100 35.6 26.4 15.75 13.25
TCHE36S41S1 TPLC080B12MP13C 17.5 FC38C 1000 34.8 25.0 15.00 12.50
TCHE36S41S1 TPLC080C16MP12C 21.0 FC38C 1200 35.6 27.0 15.10 12.50
TCHE36S41S1 TPLC080C16MP13C 21.0 FC38C 1050 35.4 25.8 15.75 13.25
TCHE36S41S1 TPLC100C16MP12C 21.0 FC38C 1200 35.6 27.0 15.10 12.50
TCHE36S41S1 TPLC100C16MP13C 21.0 FC38C 1050 35.4 25.8 15.75 13.25
TCHE36S41S1 TPLC100C20MP12C 21.0 FC38C 1150 35.8 26.8 15.50 13.00
TCHE36S41S1 TPLC100C20MP13C 21.0 FC38C 1150 36.0 27.0 16.00 13.50
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5371952-CTG-D-0320
Johnson Controls Ducted Systems 17
TCHE36S41S1 TPLC120C20MP12C 21.0 FC38C 1150 35.8 26.8 15.50 13.00
TCHE36S41S1 TPLC120C20MP13C 21.0 FC38C 1150 36.0 27.0 16.00 13.50
TCHE36S41S1 CP9C060B12MP13C 17.5 FC38C 1100 35.4 26.0 15.00 12.50
TCHE36S41S1 CP9C080B12MP13C 17.5 FC38C 1050 35.2 25.6 15.50 13.00
TCHE36S41S1 CP9C080C16MP12C 21.0 FC38C 1175 35.8 27.0 15.50 12.75
TCHE36S41S1 CP9C080C16MP13C 21.0 FC38C 1125 35.6 26.6 15.50 13.00
TCHE36S41S1 CP9C100C16MP12C 21.0 FC38C 1175 35.8 27.0 15.50 12.75
TCHE36S41S1 CP9C100C16MP13C 21.0 FC38C 1075 35.4 26.0 16.00 13.25
TCHE36S41S1 CP9C100C20MP12C 21.0 FC38C 1200 35.6 27.0 15.25 12.75
TCHE36S41S1 CP9C100C20MP13C 21.0 FC38C 1100 35.6 26.4 15.75 13.25
TCHE36S41S1 CPLC080B12MP13C 17.5 FC38C 1000 34.8 25.0 15.00 12.50
TCHE36S41S1 CPLC080C16MP12C 21.0 FC38C 1200 35.6 27.0 15.10 12.50
TCHE36S41S1 CPLC080C16MP13C 21.0 FC38C 1050 35.4 25.8 15.75 13.25
TCHE36S41S1 CPLC100C16MP12C 21.0 FC38C 1200 35.6 27.0 15.10 12.50
TCHE36S41S1 CPLC100C16MP13C 21.0 FC38C 1050 35.4 25.8 15.75 13.25
TCHE36S41S1 CPLC100C20MP12C 21.0 FC38C 1150 35.8 26.8 15.50 13.00
TCHE36S41S1 CPLC100C20MP13C 21.0 FC38C 1150 36.0 27.0 16.00 13.50
TCHE36S41S1 CPLC120C20MP12C 21.0 FC38C 1150 35.8 26.8 15.50 13.00
TCHE36S41S1 CPLC120C20MP13C 21.0 FC38C 1150 36.0 27.0 16.00 13.50
TCHE48S41S1 TL8E080C16UH11 21.0 FC49D 1250 45.5 32.6 15.00 12.25
TCHE48S41S1 TL8E100C20UH11 21.0 FC49D 1225 45.5 32.4 15.25 12.50
TCHE48S41S1 TL9E080C16UH11 21.0 FC49D 1225 45.5 32.4 14.75 12.25
TCHE48S41S1 TL9E100C20UH11 21.0 FC49D 1400 46.5 34.6 15.00 12.25
TCHE48S41S1 TM8E080C16MP11 21.0 FC49D 1250 45.5 32.6 15.00 12.25
TCHE48S41S1 TM8E080C20MP11 21.0 FC49D 1225 45.5 32.4 15.00 12.50
TCHE48S41S1 TM8E100C16MP11 21.0 FC49D 1275 46.0 33.2 14.75 12.25
TCHE48S41S1 TM8E100C20MP11 21.0 FC49D 1225 45.5 32.4 15.00 12.50
TCHE48S41S1 TM8E120C16MP11 21.0 FC49D 1275 46.0 33.2 15.00 12.25
TCHE48S41S1 TM8E120C20MP11 21.0 FC49D 1250 45.5 32.6 15.00 12.50
TCHE48S41S1 TM8E130D20MP11 24.5 FC49D 1250 45.5 32.6 15.00 12.50
TCHE48S41S1 TM8V080C16MP11C 21.0 FC49D 1425 46.0 34.4 14.25 12.00
TCHE48S41S1 TM8V080C16MP12C 21.0 FC49D 1200 45.5 32.2 14.75 12.25
TCHE48S41S1 TM8V100C16MP11C 21.0 FC49D 1425 46.0 34.4 14.25 12.00
TCHE48S41S1 TM8V100C16MP12C 21.0 FC49D 1200 45.5 32.2 14.75 12.25
TCHE48S41S1 TM8V100C20MP11C 21.0 FC49D 1425 46.0 34.2 15.00 12.50
TCHE48S41S1 TM8V100C20MP12C 21.0 FC49D 1225 45.5 32.4 15.00 12.50
TCHE48S41S1 TM8V120C20MP11C 21.0 FC49D 1425 46.0 34.2 15.00 12.50
TCHE48S41S1 TM8V120C20MP12C 21.0 FC49D 1225 45.5 32.4 15.00 12.50
TCHE48S41S1 TM8X080C16MP11 21.0 FC49D 1350 46.0 33.4 14.75 12.25
TCHE48S41S1 TM8X100C16MP11 21.0 FC49D 1350 46.0 33.4 14.75 12.25
TCHE48S41S1 TM8X100C20MP11 21.0 FC49D 1350 46.5 34.0 15.10 12.50
TCHE48S41S1 TM8X120C20MP11 21.0 FC49D 1350 46.5 34.0 15.10 12.50
TCHE48S41S1 TM8Y080C16MP11 21.0 FC49D 1350 46.0 33.4 14.75 12.25
TCHE48S41S1 TM8Y100C16MP11 21.0 FC49D 1350 46.0 33.4 14.75 12.25
TCHE48S41S1 TM8Y100C20MP11 21.0 FC49D 1350 46.5 34.0 15.10 12.50
TCHE48S41S1 TM8Y120C20MP11 21.0 FC49D 1350 46.5 34.0 15.10 12.50
TCHE48S41S1 TM9E100C16MP11 21.0 FC49D 1250 45.5 32.6 14.75 12.00
TCHE48S41S1 TM9E100C20MP11 21.0 FC49D 1325 46.0 33.6 15.00 12.50
TCHE48S41S1 TM9E120D20MP11 24.5 FC49D 1200 45.5 32.0 15.10 12.50
TCHE48S41S1 TM9V100C16MP12C 21.0 FC49D 1175 45.5 32.0 15.00 12.50
TCHE48S41S1 TM9V100C20MP11C 21.0 FC49D 1350 46.0 33.6 14.75 12.25
TCHE48S41S1 TM9V100C20MP12C 21.0 FC49D 1225 45.5 32.4 14.75 12.25
TCHE48S41S1 TM9V120D20MP11C 24.5 FC49D 1375 46.0 33.8 15.10 12.50
TCHE48S41S1 TM9V120D20MP12C 24.5 FC49D 1200 45.5 32.0 15.10 12.50
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5371952-CTG-D-0320
18 Johnson Controls Ducted Systems
PSC furnaces, such as the TG8S, TGLS, and TG9S, use Coil Only Ratings.
TCHE48S41S1 TM9Y100C16MP11 21.0 FC49D 1250 45.5 32.6 14.75 12.00
TCHE48S41S1 TM9Y100C20MP11 21.0 FC49D 1325 46.0 33.6 15.00 12.50
TCHE48S41S1 TM9Y120D20MP11 24.5 FC49D 1200 45.5 32.0 15.10 12.50
TCHE48S41S1 TMLE080C16MP11 21.0 FC49D 1250 45.5 32.6 15.00 12.25
TCHE48S41S1 TMLE080C20MP11 21.0 FC49D 1225 45.5 32.4 15.00 12.50
TCHE48S41S1 TMLE100C16MP11 21.0 FC49D 1275 46.0 33.2 14.75 12.25
TCHE48S41S1 TMLE100C20MP11 21.0 FC49D 1225 45.5 32.4 15.00 12.50
TCHE48S41S1 TMLE120C16MP11 21.0 FC49D 1275 46.0 33.2 15.00 12.25
TCHE48S41S1 TMLE120C20MP11 21.0 FC49D 1250 45.5 32.6 15.00 12.50
TCHE48S41S1 TMLE130D20MP11 24.5 FC49D 1250 45.5 32.6 15.00 12.50
TCHE48S41S1 TMLV080C16MP11C 21.0 FC49D 1425 46.0 34.4 14.25 12.00
TCHE48S41S1 TMLV080C16MP12C 21.0 FC49D 1200 45.5 32.2 14.75 12.25
TCHE48S41S1 TMLV100C16MP11C 21.0 FC49D 1425 46.0 34.4 14.25 12.00
TCHE48S41S1 TMLV100C16MP12C 21.0 FC49D 1200 45.5 32.2 14.75 12.25
TCHE48S41S1 TMLV100C20MP11C 21.0 FC49D 1425 46.0 34.2 15.00 12.50
TCHE48S41S1 TMLV100C20MP12C 21.0 FC49D 1225 45.5 32.4 15.00 12.50
TCHE48S41S1 TMLV120C20MP11C 21.0 FC49D 1425 46.0 34.2 15.00 12.50
TCHE48S41S1 TMLV120C20MP12C 21.0 FC49D 1225 45.5 32.4 15.00 12.50
TCHE48S41S1 TMLX080C16MP11 21.0 FC49D 1350 46.0 33.4 14.75 12.25
TCHE48S41S1 TMLX100C16MP11 21.0 FC49D 1350 46.0 33.4 14.75 12.25
TCHE48S41S1 TMLX100C20MP11 21.0 FC49D 1350 46.5 34.0 15.10 12.50
TCHE48S41S1 TMLX120C20MP11 21.0 FC49D 1350 46.5 34.0 15.10 12.50
TCHE48S41S1 TP9C100C16MP13C 21.0 FC49D 1175 45.5 32.0 15.00 12.50
TCHE48S41S1 TP9C100C20MP12C 21.0 FC49D 1350 46.0 33.6 14.75 12.25
TCHE48S41S1 TP9C100C20MP13C 21.0 FC49D 1225 45.5 32.4 14.75 12.25
TCHE48S41S1 TP9C120D20MP12C 24.5 FC49D 1375 46.0 33.8 15.10 12.50
TCHE48S41S1 TP9C120D20MP13C 24.5 FC49D 1200 45.5 32.0 15.10 12.50
TCHE48S41S1 TPLC080C16MP12C 21.0 FC49D 1425 46.0 34.4 14.25 12.00
TCHE48S41S1 TPLC080C16MP13C 21.0 FC49D 1200 45.5 32.2 14.75 12.25
TCHE48S41S1 TPLC100C16MP12C 21.0 FC49D 1425 46.0 34.4 14.25 12.00
TCHE48S41S1 TPLC100C16MP13C 21.0 FC49D 1200 45.5 32.2 14.75 12.25
TCHE48S41S1 TPLC100C20MP12C 21.0 FC49D 1425 46.0 34.2 15.00 12.50
TCHE48S41S1 TPLC100C20MP13C 21.0 FC49D 1225 45.5 32.4 15.00 12.50
TCHE48S41S1 TPLC120C20MP12C 21.0 FC49D 1425 46.0 34.2 15.00 12.50
TCHE48S41S1 TPLC120C20MP13C 21.0 FC49D 1225 45.5 32.4 15.00 12.50
TCHE48S41S1 CP9C100C16MP13C 21.0 FC49D 1175 45.5 32.0 15.00 12.50
TCHE48S41S1 CP9C100C20MP12C 21.0 FC49D 1350 46.0 33.6 14.75 12.25
TCHE48S41S1 CP9C100C20MP13C 21.0 FC49D 1225 45.5 32.4 14.75 12.25
TCHE48S41S1 CP9C120D20MP12C 24.5 FC49D 1375 46.0 33.8 15.10 12.50
TCHE48S41S1 CP9C120D20MP13C 24.5 FC49D 1200 45.5 32.0 15.10 12.50
TCHE48S41S1 CPLC080C16MP12C 21.0 FC49D 1425 46.0 34.4 14.25 12.00
TCHE48S41S1 CPLC080C16MP13C 21.0 FC49D 1200 45.5 32.2 14.75 12.25
TCHE48S41S1 CPLC100C16MP12C 21.0 FC49D 1425 46.0 34.4 14.25 12.00
TCHE48S41S1 CPLC100C16MP13C 21.0 FC49D 1200 45.5 32.2 14.75 12.25
TCHE48S41S1 CPLC100C20MP12C 21.0 FC49D 1425 46.0 34.2 15.00 12.50
TCHE48S41S1 CPLC100C20MP13C 21.0 FC49D 1225 45.5 32.4 15.00 12.50
TCHE48S41S1 CPLC120C20MP12C 21.0 FC49D 1425 46.0 34.2 15.00 12.50
TCHE48S41S1 CPLC120C20MP13C 21.0 FC49D 1225 45.5 32.4 15.00 12.50
For rated condition information, see the footnotes below the System Capacity - Single Piece and Modular Air Handlers table.
1. High Efficiency Motor Furnaces have B.O.D (Blower Off Delay) standard.
2. CM coils available with a factory installed horizontal drain pan. See price pages for specific model number.
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5371952-CTG-D-0320
Johnson Controls Ducted Systems 19
APPLICATIONS AND ACCESSORIES
Refer to Price Manual for specific model numbers.
* For Low Ambient and/or Long Lineset Applications, please see the acces-
sories listed below.
Non-Standard Lineset Applications - For installations with
reduced diameter or long linesets, refer to the current version of
the Piping Application Guide P/N 247077, available in the Appli-
cation Bulletins section on www.simplygettingthejobdone.com.
OD Unit Anti Short Cycle Kit (10 Pack) S1-2TD08700124BK:
A time delay that prevents rapid compressor restarting as a
result of power interruption, limit switch operation, or thermostat
resetting. Not required for HP models, or for AC models with
factory electronic controls.
Standard Low Ambient Control Kit S1-2LA06700424: Allows
the use of air conditioning at low outdoor ambient temperatures
down to +20°F (-7°C). For use with all R-410A single stage AC
& HP models.
Advanced Low Ambient Control Kit S1-2LA04701024: Con-
tains the necessary components and controls to allow cooling
operation down to -20ºF (-29ºC). For use with some R-410A
single stage AC & HP models. This accessory can only be
applied to models that contain a PSC outdoor fan motor.
Low Pressure Switch Kit S1-2PS06700524: Provides field
installed low pressure (loss of charge) protection. Not required
for HP models, or for AC models with factory electronic con-
trols.
High Ambient Outdoor Fan Motor S1-FHM****HT: Class F
70°C motor to allow cooling operation up to 160ºF air entering
the outdoor coil. For use with all R-410A single stage AC & HP
models containing R-410A refrigerant only.
Outdoor Communicating Board Kit (S1-33102952310): Elec-
tronic control upgrade for standard air conditioning units to pro-
vide compatibility with the Residential Touch Screen
Communicating Control.
Start Assist Kit S1-2SA067*****: Provides increased compres-
sor starting torque for areas with low supply voltage. Required
for units with recip compressors when applied with indoor TXV,
and for all units when applied with long linesets or low ambient
kits. May be factory installed on select AC & HP units (see
Physical & Electrical Table). See Price Pages or Source1
SmartSearch for the correct kit for each application.
Compressor Crankcase Heater Kit (S1-025********): A wrap-
around electrical resistance heater that warms the compressor
sump, reducing the chance of liquid slugging on startup.
Required on all long lineset and low ambient applications. See
Price Pages or Source1 SmartSearch for the correct part for
each application.
Indoor TXV Kit S1-1TVM***: Thermal expansion valves pre-
cisely meter refrigerant for optimum performance over a wide
range of conditions. See System Charge Table, Price Pages, or
Source1 Smart Search for TXV part number for each AC & HP
model.
Cold Weather Charging Tent S1-CHGTENT01: Provides
warm environment to accurately service AC & HP systems in
ambient conditions 55ºF (13ºC) or colder.
Touch-up Paint S1-5130153****: Color matched aerosol paint
for touching up unit chassis and panels. See Price Pages or
Source1 SmartSearch for the correct color for each application.
Compressor Sound Blanket S1-01007xxx000: A field
installed dense foam cover that provides 2dBA sound level
reduction. See Price Pages or Source1 SmartSearch for the
correct blanket for each application.
Thermostat: Compatible thermostat controls are available
through accessory sourcing. For optimum performance, these
outdoor units are fully compatible with our Coleman Hx™
Touchscreen Thermostats available through Source1. For more
information, see the thermostat section of the Product Equip-
ment Catalog.
SOUND POWER RATINGS
Rated in accordance with ARI Standard 270.
Standard Application Limits*
Maximum Lineset Equivalent Length 200 Ft
Outdoor Ambient Temperature Limits
Cooling Operation Maximum DB 120°F
Minimum DB 50°F
Cooling Octave Band Sound Power Level (db re. 1-pW)
Model Number 63 125 250 500 1000 2000 4000 8000 dBA SQI
TCHE24S41S1 73 78 69 67 65 60 57 58 70 19.1
TCHE36S41S1 74 77 68 67 66 61 58 58 71 19.1
TCHE48S41S1 75 81 70 68 66 61 58 58 72 19.0

5371952-CTG-D-0320
20 Johnson Controls Ducted Systems
MECHANICAL SPECIFICATIONS
MANUFACTURE AND CERTIFICATIONS
• Units shall be manufactured in an ISO 9001 certified facility.
• Units shall be certified by CSA to UL 1995 / CSA 22.2 and
performance certified to ANSI/AHRI Standard 210/240.
• Units shall be sound tested according to ANSI/AHRI Stan-
dard 270.
• Certified matched system ratings will be available for down-
load from the AHRI online directory at www.ahridirectory.org
• Unit packaging shall be marked, “Assembled in the USA”
UNIT APPLICATION
• Units shall be approved for cooling operation between 50ºF
and 120ºF without modification.
• Units shall be approved for linesets up to 200 feet equivalent
length without modification.
• Units shall be approved for installation within 6 inches of a
flat vertical wall without modification, according to the
instructions in the technical literature.
• Units shall be certified for seismic applications in accordance
with CBC 2007 and IBC 2006.
• Units shall be designed to 72dBA or less to minimize sound
pollution.
UNIT ACCESS
• Units shall have a fan guard that can be removed inde-
pendently of the cabinet for access to the condenser coil.
• Units shall have blow-through airflow for the condensing coil.
• Units shall have a separate compartment for electrical con-
trols that can be accessed without disturbing the unit airflow.
UNIT CONSTRUCTION
• Units shall be shipped completely wired, piped and assem-
bled. Wiring pigtails shall be provided for field control wiring
connections. Service valves shall be provided for field refrig-
erant line connections.
• Units shall be factory leak checked, run tested, and shipped
with a holding charge of R-410A refrigerant.
• Unit cabinet components shall be G90 equivalent steel fin-
ished with powder-coat paint rated at a minimum of 1,000
hours under ASTM B117 testing.
• Unit base pan shall be stamped G90 equivalent steel fin-
ished with powder-coat paint rated at a minimum of 1,000
hours under ASTM B117 testing.
• Units shall have a factory installed filter drier for faster instal-
lation and improved system reliability.
• Units shall be constructed with a high pressure switch and a
low pressure switch for system protection.
UNIT COMPONENTS
• Compressor shall be hermetic with internal electrical over-
load protection and internal overpressure protection.
• Compressor shall be mounted on rubber vibration isolators
that do not require the removal of transportation clips or
brackets.
• Units shall be constructed with scroll compressors.
• Outdoor fan shall be direct drive with horizontal air dis-
charge.
• Outdoor fan shall be direct drive with swept-wing blades for
low sound levels.
• Outdoor coil shall be air cooled and constructed of zinc-
coated aluminum microchannel construction for small size
and low weight.
UNIT WARRANTIES
• Unit manufacturer shall provide a 10-Year compressor war-
ranty without a requirement for unit registration.
• Unit manufacturer shall provide a 5-Year parts warranty with-
out a requirement for unit registration.
