4. Insert one end of each black pole
into pins in front corners of tent.
(Fig. 2)
5. Go to opposite end of each pole
and gradually apply pressure to
the pole forming an arch. Insert
the pin into the pole end at the
corners of tent. (Fig. 3)
6. Attach frame clips along edges
of tent to black main poles.
(Fig. 3A)
7. Stretch corners and sides of tent until floor is
taut then hammer stakes through loops to
secure. (Fig. 3B)
STITCH LINE
HOLIDAY DOME TENT 12’ X 10’
MODEL 2000001080
Before you begin
Read all instructions before set up.
• Select a level campsite clear of rocks, branches, and other hard
or sharp objects, to install your tent.
WARNING: Keep clear of overhead power lines.
• Do not set up your tent under trees.
• For best results in windy conditions, position end of tent into
the wind.
• Enlist the help of at least one other person to assist you when
it is time to assemble the tent.
Fig. 2
To Set Up Tent
1. Unfold tent and spread out on a clean, level surface
with the door facing the desired direction. (Fig. 1)
2. Assemble two main tent poles by interlocking the
longer, black shock-corded, poles.
3. Insert both, long, black poles through sleeves in top
of tent as shown. (Fig. 1)
Fig. 3
Parts and Components
Description Part Number
Main Poles, Long, Black (2) 5010000364
Rainfly Awning Pole, Thin, Black (1) 5010000365
Rainfly 5010000366
1. Assemble longer interlocking shock-corded rainfly pole.
2. Unfold rainfly. Locate the sleeve, along front edge, and the hook & loop fasteners on the underside of rainfly.
3. Drape rainfly over tent. Make sure the sleeve is centered over the door and the hook & loop fasteners, on the underside of the rain
fly, are positioned over the black
main poles.
4. Clip hooks on elastic cords, on the
back corners of rainfly, onto metal
loops at back corners of tent.
(Fig. 4A)
5. Slide rainfly pole through sleeve at
front of the flap. (Fig. 4)
To Attach Rainfly
(continued on other side)
Fig. 1
Door
Fig. 4
Rainfly
Awning Pole
Sleeve on
Front of
Rainfly
Long, Black,
Shock-corded
Main Poles
3A
Door
3A
3B

The Coleman Company, Inc. • 3600 N. Hydraulic • Wichita, Kansas 67219
1-800-835-3278 • www.coleman.com
MADE IN CHINA • PRINTED IN CHINA
© 2007 The Coleman Company, Inc.
Coleman®and are registered trademarks of The Coleman Company, Inc.
STITCH LINE
To Attach Rainfly continued
To Store
1. All metal poles and stakes must to be placed in the storage
bag to prevent damage to the fabric items placed in the
carry case.
2. Make sure tent is clean and dry before placing in carry case.
3. Remove rainfly, spread out on floor of tent, then unzip
door & vents before taking tent down for storage.
4. Neatly fold tent to width of pole storage bag, place on tent,
roll tightly, and place in carry case.
5. Store in a clean, dry area.
11/07
6. Insert one end of each black rainfly
awning pole into remaining pin in front
corner of tent (Fig. 5A). Gradually apply
pressure to other end of pole to form
an arch & insert into other front pin.
(Fig. 5)
7. Attach hook & loop fasteners,
located on underside of the
rainfly, around black main
poles to secure. (Fig. 5B)
8. Clip hooks on elastic cords,
on the front corners of rainfly,
onto metal loops at front corners
of tent. (Fig. 5C)
9. Tie guylines through loops on web
straps on the rainfly. (Fig. 5D)
10. Stretch guylines until taut, then secure
with stakes.
Things You Should Know:
• Under certain conditions (cold weather, high humidity, etc.) condensa-
tion will form on the inside of your tent. Condensation is caused by
water vapor from your breath, perspiration, or any wet clothing inside
the tent. It is NOT LEAKAGE through the tent fabric. It can be minimized
by removing wet clothing from your tent and by providing good ventila-
tion through the tent.
• Never store tent, even for a short period of time, without drying it
thoroughly and brushing off caked dirt. Do not pack stakes or poles
inside your tent. Use a separate storage bag.
• STAKES SHOULD BE REMOVED BY PULLING ON THE STAKE ITSELF.
NEVER PULL ON THE TENT TO REMOVE STAKE.
• TENT POLES SHOULD NOT BE LEFT TELESCOPED TOGETHER
DURING STORAGE.
• Do not leave your tent set-up for weeks at a time. Be aware that exposure
to ultraviolet rays from the sun can seriously damage material and/or
cause it to become discolored.
WARNING: Keep all flame and heat sources away
from this tent fabric.
This tent meets the flammability requirements of CPAI-84. The
fabric may burn if left in continuous contact with any flame source.
The application of any foreign substance to the tent fabric may
render the flame-resistant properties ineffective.
Electrical Cord Access
1. Unzip access panel in the lower
right corner of tent and bring in
electrical cord. Use only UL approved
cords that are rated for outdoor
usage. (Fig. 8)
Fig. 8
Fig. 5
Cooler Access
The smaller zippered opening at the
rear of the tent is designed for added
ventilation and easy access to your
beverage cooler.
1. To use as a vent, unzip flap to
expose screen. (Fig.6)
2. To use as a cooler access, unzip
other flap to make an avenue to
bring beverages into the tent.
(Fig.7)
Fig. 6
Fig. 7
5D
5A
5B
Black Main
Pole
5C
