Coleman 5400 Series 9992-141 Application guide

9992-056 (4/8/05)
IMPORTANT!! TO AVOID UNNECESSARY PROBLEMS!!
BEFORE YOU BEGIN: Review this parts list with the parts in
your carton. If you have missing or damaged parts, call this
number IMMEDIATELY, 1-800-356-3612, for the SERVICE
CENTER nearest you.
The Coleman Company, Inc.
3600 N. Hydraulic
Wichita, KS 67219
Internet site:
www.coleman.com
1-800-356-3612
TDD: 316-832-8707
ASSEMBLER / INSTALLER:
Leave these instructions with the consumer.
CONSUMER / USER:
Read all these instructions and keep them in a
safe place for future reference.
Gas Barbecue
Replacement Parts List
5400 LP Gas Series

Gas Barbecue
Replacement Parts List
5400 LP Gas Series
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
Number
9992-6251
9990-2091
9990-4221
9990-4111
9992-4451
9992-4501
9990-4121
9990-4041
9992-4201
9992-4211
9990-4141
9990-4651
9990-4161
9990-4231
9990-4131
9990-4951
9992-4111
9992-4151
9992-0521
9990-4881
9992-4551
9990-4321
9990-4291
9990-4341
9990-4351
9990-5181
9990-5361
9990-5381
9990-5221
9990-5481
9990-5491
9990-5501
9947-6561
9990-5341
9990-5511
9992-4531
9990-5541
9990-5201
9990-5301
9990-5841
9990-5061
9990-5071
9990-5551
9992-5421
9990-5021
9990-5401
9990-5351
9990-3421
9990-3271
9992-0561
9990-4681
Description
Hood Wrapper Assembly w/heat indicator
Lid Handle Assembly w/hardware
Firebox Assembly (Black PE)
Control Panel (LP Graphics)
Left Side Burner Table Assembly (Silver Vein)
Right Side Table Assembly (Silver Vein)
Cabinet Side Panel (LH)
Cabinet Side Panel (RH)
Cabinet Front Door (LH) W/Hinge (Silver Vein)
Cabinet Front door (RH)w/Hinge (Silver Vein)
Cabinet Bottom Panel
Grease Tray
Trim Panel
Top Panel
Rear Panel
Warming Rack
Hose/Regulator Assembly
Manifold/Valve Assembly
Instruction Manual 5400 Series
Hardware Pack
Side Burner Lid (Silver Vein)
Side Burner Hinge
Side Burner Drip Tray Assembly
Side Burner Electrode
Side Burner Trivet
Cylinder Support Assembly
Electronic Module
Main Burner
Door Magnet
Locking Caster
Caster
Tool Hook
Side Burner
Main Burner Knob
Heat Tent
Back Home Select Logo Plate
Hood Hinge Pin (2 pk)
Collector Box Assembly
Side Burner Hair Pin
Side Burner Control Knob
Drip Cup
Drip Cup Hanger
Control Knob Bezel
Grate-SS Rod Cooking
Door Handle
Lead Wires (2 pk)
Ignitor Switch
Pads - Rubber Lid (2 pk)
Spacer Top Panel
Repair Parts List 5400 Series (not illustrated)
Chain - Matchstick Extension

11
21
31
3
12
22
32
4
13
23
5
14
24 34
6
15
7
16
26
8
18
27
9
25
10
29
20
30
33
41
42
43
28
40
38
44
35
136
37 48
45
19
17
46
2
39
47
49
51
