Coleman MOSQUITO DELETO 2100 User manual

1
2
Warranty
Guarantee
Inhibitor
• Guaranteed to repel mosquitoes.
2910B051 (02/03) P.I.
Trap
• Guaranteed to trap & kill mosquitoes.
If on skin or
clothing
If in eyes
If inhaled
If swallowed
Active Ingredient:
1-Octen-3-ol* 24.5%
Other Ingredients 75.5%
Total 100.00%
*Contains 3.72 grams Octenol per lure.
EPA Reg. No. 70909-3-69269
EPA Est. No. 69269-KS-1
Keep Out of Reach of Children
CAUTION
FIRST AID
• Take off contaminated clothing.
• Rinse skin immediately with plenty of water for 15 - 20 minutes.
• Call a poison control center or doctor for treatment advice.
• Hold eye open and rinse slowly and gently with water for 15 - 20 minutes.
• Remove contact lenses, if present, after the first 5 minutes, then continue rinsing eye.
• Call a poison control center or doctor for treatment advice.
• Move person to fresh air.
• If person is not breathing, call 911 or an ambulance, then give artificial respiration,
preferably by mouth-to-mouth, if possible.
• Call a poison control center or doctor for further treatment advice.
• Call poison control center or doctor immediately for treatment advice.
• Have person sip a glass of water if able to swallow.
• Do not induce vomiting unless told to do so by the poison control center or doctor.
• Do not give anything by mouth to an unconscious person.
Have the product container or label with you when calling a poison control center or doctor, or
going for treatment.
PRECAUTIONARY STATEMENTS
Hazards to Humans and Domestic Animals
Caution: Harmful if swallowed. Wash hands before eating, drinking, chewing gum, using
tobacco or using bathroom facilities. Avoid contact of areas under foil wrapper with skin
and eyes.
Manufactured for:
The Coleman Co., Inc. • 3600 N. Hydraulic • Wichita,KS 67219
www.coleman.com
1-800-835-3278 TDD: 1-316-832-8707
Storage and Disposal:
Store this product in a cool, dry place and out of the reach of children until ready to
use. Dispose of the used attractant lure by wrapping it in several layers of newspaper
and dispose in the trash.
Mosquito DeletoTM Octenol Lure Refill
Directions for use: It is a violation of Federal law to use this product in a manner
inconsistent with its labeling.
1 Year Limited Warranty
The Coleman Company, Inc. (“Coleman“) warrants that for a period of one year from the date of
purchase, this product will be free from defects in material and workmanship. Coleman, at its option,
will repair or replace this product or any component of the product found to be defective during the
warranty period. Replacement will be made with a new or remanufactured product or component.
If the product is no longer available, replacement may be made with a similar product of equal or
greater value. This is your exclusive warranty.
This warranty is valid for the original retail purchaser from the date of initial retail purchase and is
not transferable. Keep the original sales receipt. Proof of purchase is required to obtain warranty
performance. Coleman dealers, service centers, or retail stores selling Coleman products do not
have the right to alter, modify or in any way change the terms and conditions of this warranty.
This warranty does not cover normal wear of parts, including chips, scratches, abrasions, discol-
oration or fading from use or exposure to sunlight or damage resulting from any of the following:
negligent use or misuse of the product, use on improper voltage or current, use of non-Coleman
accessories or parts, use contrary to the operating instructions or failure to follow maintenance
instructions, commercial, in profit or non-profit instructional or rental applications, disassembly,
repair or alteration by anyone other than Coleman or an authorized service center. Further, the
warranty does not cover Acts of God, such as fire, flood, hurricanes and tornadoes.
Coleman shall not be liable for any incidental or consequential damages caused by the breach
of any express or implied warranty. Except to the extent prohibited by applicable law, any implied
warranty of merchantability or fitness for a particular purpose is limited in duration to the duration
of the above warranty. Some states, provinces or jurisdictions do not allow the exclusion or
limitation of incidental or consequential damages or limitations on how long an implied warranty
lasts, so the above limitations or exclusion may not apply to you. This warranty gives you specific
legal rights, and you may also have other rights that vary from state to state or province to province.
How to Obtain Warranty Service
Take the product to an authorized Coleman service center. You can find the nearest authorized
Coleman service center by calling 1-800-835-3278 or TDD 316-832-8707. If a service center is
not conveniently located, attach a tag to the product that includes your name, address, daytime
telephone number and description of the problem. Include a copy of the original sales receipt.
Carefully package the product and send either by UPS or Parcel Post INSURED with shipping and
insurance prepaid to:
For products purchased in the United States:
The Coleman Company, Inc.
3600 North Hydraulic
Wichita, KS 67219
Do not mail products with fuel in tanks, or with disposable propane cylinders.
DO NOT RETURN THIS PRODUCT TO THE PLACE OF PURCHASE.
If you have any questions regarding this warranty please call 1-800-835-3278 or TDD 316-832-8707.
Limited 60 Day Guarantee
Thank you for purchasing a Coleman®Mosquito DeletoTM. The Coleman Company, Inc.
(“Coleman”) guarantees that this product will trap and kill mosquitoes when used as directed, during
mosquito season. If for any reason you are not completely satisfied with this product during the first
60 days after you purchase the Mosquito DeletoTM, contact Coleman for a full refund.
Proof of pur
-
chase shall be required to establish the purchase date. This warranty is validonly for the original
retail purchaser and is not transferable. Coleman does not guarantee to eliminate
mosquitoes, to trap
mosquitoes during winter months or periods of cold weather, or to prevent mosquito bites. Follow all
instructions and recommendations. If you have questions, contact Coleman at 1-800-835-3278 or
www.coleman.com.
Limited 60 Day Guarantee
Thank you for purchasing a Coleman®Mosquito DeletoTM. The Coleman Company, Inc. (“Coleman”)
guarantees that this product will repel mosquitoes when used as directed, during mosquito season.
If for any reason you are not completely satisfied with this product during the first 60 days after
you purchase the Mosquito DeletoTM, contact Coleman for a full refund. Proof of purchase shall be
required to establish the purchase date. This warranty is valid only for the original retail purchaser
and is not transferable. Coleman does not guarantee to eliminate mosquitoes, to trap mosquitoes
during winter months or periods of cold weather, or to prevent mosquito bites. Follow all instructions
and recommendations. If you have questions, contact Coleman at 1-800-835-3278 or
www.coleman.com.
1 - YEAR
The Coleman Co., Inc.
3600 N. Hydraulic
Wichita, KS 67219 U.S.A.
1-800-835-3278
TDD: 316-832-8707
www.coleman.com

Propane Cylinder
& Battery
Not Included
EPA Est. No.: 69269-KS-1
EPA Reg. No.: 70909-3-69269 (Octenol)
EPA Reg. No.: 70909-2-69269 (Linalool)
Instructions for use
Patent Nos. 5,205,064; 5,799,436;
6,055,766; D466578
U.S. and other Patents Pending
© 2002 The Coleman Company, Inc.
www.coleman.com
IMPORTANT
Read this manual carefully before assembling,
using or servicing this unit. Keep this manual for
future reference. If you have questions about
assembly, operation, servicing or repair, please
call Coleman at 1-800-835-3278 or TDD:
316-832-8707.
For Outdoor use only

Contents
Introduction 2
General Safety Information 2 & 3
System Description 3
Assembly 4, 5, & 6
Operation 6 & 7
Placement 7 & 8
Helpful Hints 8
Storage 8
Maintenance 8
Troubleshooting 9
Service 9
Mosquito Deleto
TM
Refills 9
Replacement Parts 11
Guarantees 12
Warranty 12
This manual contains important information about the assembly, opera-
tion and maintenance of this product and system. General safety informa-
tion is presented in these first few pages and is also located throughout the
manual. Particular attention should be paid to information accompanied by
the safety alert symbols: “ DANGER”, “ WARNING”, “ CAUTION” .
Keep this manual for future reference and to educate new users of this
product. This manual should be read in conjunction with the labeling on
the product.
Safety precautions are essential when any mechanical or propane fueled
equipment is involved. These precautions are necessary when using, stor-
ing, and servicing. Using this equipment with the respect and caution
demanded will reduce the possibilities of personal injury or property damage.
The following symbols shown below are used extensively throughout this
manual. Always heed these precautions, as they are essential when using
any mechanical or fueled equipment.
2
General Safety Information cont.
DANGER
DANGER indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING
WARNING
WARNING indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
CAUTION indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate personal injury, or property
damage.
Failure to comply with the precautions and instructions pro vided with
this mosquito trap can result in death, serious bodily injury and property
loss or damage from hazards of fire, explosion, burn, asphyxiation,
and/or carbon monoxide poisoning.
Only persons who can understand and follow the instructions should use
or service this mosquito trap.
If you need assistance or information such as an instruction manual or
labels, contact The Coleman Co., Inc.
DANGER
General Safety Information
Improper installation, adjustment, alteration,
service or maintenance can cause injury or prop
-
erty damage. Read the instructions thoroughly
before installing or servicing this equipment.
WARNING
WARNING: For Outdoor Use Only
• This product is fueled by propane gas. Propane gas is invisible,
odorless, and flammable. An odorant is normally added to help
detect leaks and can be described as a “rotten egg” smell. The
odorant can fade over time so leaking gas is not always detectable
by smell alone.
• Propane gas is heavier than air and leaking propane will sink to
the lowest level possible. It can be ignited by ignition sources
including matches, lighters, sparks or open flames of any kind
many feet away from the original leak. Use only propane gas set
up for vapor withdrawal.
• Propane gas should be stored or used in compliance with local
ordinances and codes or with ANSI/NFPA 58. Turn off propane
when not in use.
WARNING
Combustion by-products produced when using this product contain
chemicals known to the State of California to cause cancer, birth defects,
or other reproductive harm.
• Mosquito DeletoTM System
•No zapping
•No lotions
•No sprays
•No electrical cords
•Mosquitoes have highly developed senses for detecting humans
and animals.
Mosquitoes are attracted to three things:
• carbon dioxide from breath
• body heat
• faint odors emitted by animals and humans.
•The Mosquito DeletoTM Trap lures mosquitoes to it by emitting
heat, carbon dioxide and a special mosquito attractant called
Octenol. The Mosquito DeletoTM Inhibitor emits and circulates a
patented scent that inhibits mosquitoes’ ability to detect humans.
•The irresistible combination attracts mosquitoes to the trap where
they are captured. . .never to bother you again!
•This instruction manual will assist you in setting up your new
Mosquito DeletoTM System. Please refer to the instructions
included with the Inhibitor for details on use, storage, specifications.
Introduction

1
1
Replacement Parts
Parts List
No. PartNo. Description
12950-1421 Cap Lift Grip
22950-5601 Cap Assembly
32950-1321 Control Knob
42950-5301 Leg Assembly
52950-2621 Leg Knob
62910-0311 Ignitor Button
72910A0981 Thermometer
82950-2211 Rib (single component)
92910-2221 Regulator
1
2
3
4
5
6
7
8
9

1
0
Notes

3
General Safety Information cont.
• BURN HAZARD
• Unit is hot when being used. Use care when servicing.
• Keep out of reach of children.
• SERVICE SAFETY
• Keep connections and fittings clean. Make sure propane cylinder outlet
is clean.
• Use for mosquito control only. Never alter in any way or use with any
device or part not expressly approved by Coleman.
System Description
• CARBON MONOXIDE HAZARD
• This unit is a combustion appliance. All combustion appliances
produce carbon monoxide (CO) during the combustion process.
This product is designed to produce extremely minute, non-haz-
ardous amounts of CO if used and maintained in accordance with
all warnings and instructions.
• Carbon Monoxide (CO) poisoning produces flu-like symptoms,
watery eyes, headaches, dizziness, fatigue and possibly
death.You can’t see it and you can’t smell it. It’s an invisi -
ble killer. If these symptoms are present during opera-
tion of this product get fresh air immediately!
• For outdoor use only.
• Never use inside house, or other unventilated or enclosed
areas. This unit consumes air (oxygen). Do not use in unventi-
lated or enclosed areas to avoid endangering your life.
DANGER
Head Assembly
Mosquito
Deleto
TM
Inhibitor
Legs
Quick Tips
Sheet
Consumables Bag
Stakes
Regulator

4
Assembly
For use ONLY with a 16.4 oz.
Propane Cylinders (not included).
Do not use hose with this product.
Step 1
n Remove all components from the package.
n See package label for listing of contents for the model you purchased.
Mosquito
DeletoTM
Octenol
Lure
Refill
Mosquito
DeletoTM
Inhibitor
Mosquito
DeletoTM
Inhibitor
Refill
(Linalool)
Adhesive
Trap Stakes
n Turn unit upside
down & install
Regulator as
shown.
n Hand-tighten
Collar securely.
Step 4
n Turn unit upright and thread cylinder into the fitting on Regulator
as shown.
n Hand-tighten.
n Attach Legs as shown.
Step 2
Step 5
Battery Installation/Replacement
n Unscrew Ignitor Button.
n Insert one (1) AAA battery (not included) then replace Ignitor Button
and tighten.
IMPORTANT:
Make sure positive (+) end of battery is facing towards the front of the unit
as shown.
Positive (+) end of
battery to the front
Step 3
A
B
C
Collar
Ignitor Button
Note: Make sure
Tab is positioned
as shown.
Collar
Tab

9
Mosquito DeletoTM Inhibitor
Model # 2950-603
Mosquito DeletoTM
System Refill
Model # 2950-700
Mosquito DeletoTM
Octenol Lure Refill
Model # 2960-601
Mosquito DeletoTM
Trap Cartridge Refill
Model # 2960-602
Mosquito DeletoTM
Inhibitor Refill
Model # 2960-603
Mosquito Deleto
TM
Refills
All Mosquito DeletoTM refills
are available at
www.coleman.com
or 1-800-835-3278.
Service
•Repair to gas passages and associated components should be done only by a qualified service person.
• Owner repair & service should be limited and performed only to the following:
- Octenol Lure replacement
- Adhesive Trap replacement
- Cylinder replacement
- Listed parts replacement (see Replacement Parts List)
- Routine cleaning
Problem Possible Cause Solution
Burner won’t light Gas pressure is low Turn valve OFF and replace cylinder
Air in gas line Burner may take 30-60 seconds to light after a propane
cylinder has been connected
Low gas pressure with Cylinder Valve Cylinder is empty. Replace cylinder
fully open
Igniter fails Replace AAA Battery
Indicator broken Replace
Burner won’t stay lit Gas pressure is low Turn Cylinder valve OFF and replace cylinder
Outdoor temperature is less than 40° F Use a full cylinder
and tank is less than 1/4 full
Adhesive Panels Panels exposed to direct sunlight Move out of direct sunlight. If desired, replace.
dripping
Troubleshooting

8
Maintenance
To enjoy years of outstanding performance from your mosquito trap
perform the following maintenance activities on a regular basis:
•Keep exterior surfaces clean.
•Use warm soapy water for cleaning. Never use flammable or corrosive
cleaning agents.
•While cleaning your unit, be sure to keep the area around the burner dry
at all times.
•Air flow must be unobstructed. Keep controls, burner, and circulating air
passages clean. Signs of possible blockage include:
- Gas odor.
- Mosquito trap makes popping noises.
- Smoky exhaust.
• It is a good practice to remove leaves or trash that may collect in or near
the cage.
•Spiders and insects can nest in unit. This condition can cause malfunc-
tions. When trap is not in use, store in plastic bag or sealed box.
(See Storage Instructions.) Compressed air may help clear away small
particles.
•If unit has been left uncovered and is wet from rain, yard sprinklers, etc.,
allow to dry (at least 30 minutes prior to use).
•In a salt-air environment (such as near an ocean), corrosion
occurs more quickly than normal. Frequently check for corroded areas
and clean or repair them promptly.
Storage
Disconnect mosquito trap from propane fuel
before storage of either the cylinder or the
mosquito trap.
1. Turn cylinder valve off.
2. Remove cylinder and store.
3. Store propane cylinder in safe manner. Refer to Chapter 5 of
Standard for Storage and Handling of Liquefied Gases, ANSI/NFPA
58. Follow all local codes.
• BURN HAZARD
• Do not touch or attempt any maintenance on unit for at least one
hour after use.
• Make sure all controls are off and propane tank has been
removed before doing maintenance.
WARNING
1. Use the Mosquito DeletoTMInhibitor to push mosquitoes
away from you. . .use the Mosquito DeletoTM Trap to
attract and kill mosquitoes!
2. The Mosquito DeletoTM Inhibitor is designed for occasional
use. Turn it on when going outdoors to gently disperse the
scent that blocks the mosquitoes’ sensors. Turning the
unit off will close the vents and preserve the unit for future
How To Use Mosquito DeletoTM Products:
use.
3. The Mosquito DeletoTM
Inhibitor unit should be placed near
where people gather. If there is a gentle breeze, be sure to
place the inhibitor upwind from where people gather to be
sure the scent covers the area desired.
4. During days of gusty winds (over 20 miles an hour), you
should recheck the Mosquito DeletoTM
Trap to be sure that
the trap is operating properly.
Helpful Hints
1. Did you know that only female mosquitoes bite? Female
mosquitoes need protein to breed and lay eggs.
2. Mosquito eggs need water to hatch. Stopping adult female
mosquitoes from breeding will help to reduce your
problem with mosquitoes.
3. Mosquitoes can also be good fliers. While most mosqui-
toes do not migrate far from where they breed, some
mosquitoes can fly up to 75 miles.
4. Mosquitoes also bite primarily in the evening and morning
hours, when it is cooler. Some types of mosquitoes bite
during the day. All mosquitoes like the temperature to be
warm and generally humid, but not hot. During very hot
days, mosquitoes will hide in the brush to stay cool.
5. Mosquitoes will also take cover from winds greater than
10 miles an hour.
6. Clearing your yard of standing water will help to reduce
the number of mosquitoes breeding in your area. Remove
all standing water in buckets, tires, and plant trays. Make
sure that areas in your yard do not become flooded with
standing water. All ponds and bird baths should have
water cleaned frequently or water should be circulated to
prevent mosquitoes from breeding.
Proper Inhibitor and Trap Placement cont.
Always store propane
cylinders outdoors.
4. Remove AAA battery
from Ignitor.
5. Place mosquito trap in
plastic bag or sealed box.
6. Store mosquito trap and
base in a dry, clean, and
safe place.
7. Legs can be positioned
as shown for storage.

5
Assembly cont.
n Remove the waxed paper from
the adhesive trap.
Note: Adhesive surface must
face toward outside.
n Open lid.
n Remove Mosquito Deleto
TM
octenol lure refill from foil package.
n Install lure into unit with
holes facing center of trap.
Leak Check
WARNING
•Perform leak test outdoors.
•Extinguish all open flames.
•NEVER leak test when smoking.
•Do not use the mosquito trap until connection has been leak tested
and does not leak.
•
Make 2-3 oz. of leak check solution (one part liquid dishwashing deter-
gent and three parts water).
•
Apply several drops of solution at Cylinder Connection and Collar
Connection
If bubbles appear at connection, there is a leak.
•
Disconnect, reconnect, and perform another leak check. If you continue
to see bubbles after several attempts, cylinder or Regulator may be
defective and should be replaced.
If NO bubbles appear at connections, the connections are secure.
•
DO NOT TAMPER WITH THE REGULATOR.
Cylinder
Connection
NOTE: Whenever either gas connection is loosened or removed, you
must perform a leak test.
Step 6
n
Press stakes into
ground through holes
in plastic feet on trap.
This reduces the risk
of the trap being
knocked or blown
over.
CAUTION
Contents of octenol cartridge are harmful if swallowed. Wash hands
before eating, drinking, chewing gum, using tobacco or using bath -
room facilities. Avoid contact with inside surface of foil package.
Step 7
Collar
Connection
Cylinder Connection Collar Connection
Step 8
n Position edge of Adhesive Trap
over Tray Rails (typical both
edges).
Tray Rail
Edge of
Adhesive
Trap

6
3. Verify ignition by observing gauge:
If the needle enters
the red zone (HOT)
on the gauge immedi-
ately turn the unit off
& call Coleman at
1-800-835-3278.
Start Up 3-5 minutes (Normal)
• CARBON MONOXIDE HAZARD
• For outdoor use only. Never use inside house, or other
unventilated or enclosed areas. This unit consumes air
(oxygen). Do not use in unventilated or enclosed areas to
avoid endangering your life.
DANGER
DANGER
• EXPLOSION - FIRE HAZARD
• Never store propane near high heat, open flames, pilot lights,
direct sunlight, other ignition sources or where temperatures
exceed 120 degrees F (49°C).
• Propane is heavier than air and can accumulate in low places. If
you smell gas, leave the area immediately.
• Never install or remove propane tank while unit is operating, near
flame, pilot lights, other ignition sources or while unit is hot to
touch.
• This unit is hot during use and can ignite flammables. Keep gaso-
line and other flammable liquids and vapors well away from unit.
• The propane tank must always be stored outdoors in a well ventilat-
ed space. Never store propane tank in an enclosed area (house,
garage, etc.). If unit is to be stored indoors, disconnect the propane
tank for out door storage.
Operation
n Install one adhesive trap into back of unit and one adhesive trap into front
of unit.
Helpful Tip:
On hot days, the waxed paper will remove easily if the adhesive trays are
cool. Store traps indoors.
•Do not attempt to operate until you have read & understand all
General Safety Information in this manual and all assembly is
complete.
•
After lighting the unit for the first time it is normal to see some smoke
coming from the burner area. This smoke is the result of the burning
of residual oils from the manufacturing process. The smoke will disap-
pear within 10-15 minutes.
Lighting Instructions
1. Press and hold RED
IGNITOR BUTTON
(until ignition is verified
in Step 3 of Lighting
Instructions below).
2. Push BURNER VALVE
in slightly & turn
to ON posi-
tion. If starting
the unit for the first
time it will require 30-
60 seconds before
igniton can be verified
in Step 3 of Lighting
Instructions below.
Step 8 cont.
Back of unit Front of unit
Assembly cont. Operation cont.
Burner
Valve

Operation cont.
1. Turn BURNER VALVE
OFF.
7
Approximate Consumable Usage
• Propane: Approx. 2.3 days
• Octenol Lure Refill: 1 month
• Adhesive Trap: Approx. 2 weeks or when full
Lighting Instructions cont.
To Turn Off
4. Repeat this process for every restart of the unit.
Proper Inhibitor and Trap Placement
1. Placement of the trap – find an area of your yard or camp-
site that is shaded, cool, or well protected by brush. Refer
to the Quick Tips Sheet.
2. Mosquitoes breed in standing water or areas that become
flooded with water during rain storms. Mosquitoes will also
take cover under low lying brush to stay cool on warm days.
3. The trap should be placed in an area away from where
people gather. We recommend a distance of at least 50
feet away from people.
4. Positioning of the device is very important. If you are not
catching mosquitoes, move the unit to another area of the
yard or campsite that is protected from wind and direct sun
and is near water. Try each location for a minimum of days.
5. The Trap is designed to operate around the clock in your
yard or campsite. The Trap continuously attracts, traps,
and kills mosquitoes all day and all night.
6. Together, the Mosquito DeletoTM Inhibitor and Trap are a
strong defense against mosquitoes!
7. Place the inhibitor unit per instructions in the inhibitor
package.
Burner
Valve
