Coleman 2000000117 User manual

Propane Stove
INSTRUCTIONS FOR USE
IMPORTANT
Read this manual carefully before assembling,
using or servicing this stove. Keep this
manual for future reference.
Model 2000000117
(5434A700)
ANSI Z21.72b-CSA 11.2b (2002) Camp Stove
161495-1437739
CERTIFIED
®®

2
Contents
General Safety Information
To Set Up
To Light
To Tu r n O ff
To Store
To Clean
Things You Should Know
Parts List
Warranty
General Safety Information
If you smell gas:
1. Do not attempt to light appliance.
2. Extinguish any open flame.
3. Disconnect from fuel supply.
FOR YOUR SAFETY
Do not store or use gasoline or
other liquids with flammable vapors
in the vicinity of this or any other
appliance.
FOR YOUR SAFETY
This manual contains important information about
the assembly, operation and maintenance of these
propane stoves. General safety information is pre-
sented in these first few pages and is also located
throughout the manual. Particular attention should
be paid to information accompanied by the safety
alert symbol “ DANGER”, “ WARNING”,
“ CAUTION”.
Keep this manual for future reference and to edu-
cate new users of this product. This manual should
be read in conjunction with the labeling on the
product.
Safety precautions are essential when any
mechanical or propane fueled equipment is
involved. These precautions are necessary when
using, storing, and servicing. Using this equipment
with the respect and caution demanded will reduce
the possibilities of personal injury or property
damage.
The following symbols shown below are used
extensively throughout this manual. Always heed
these precautions, as they are essential when
using any mechanical or propane fueled equip-
ment.
CARBON MONOXIDE HAZARD
• This appliance can produce
carbon monoxide which has
no odor.
• Using it in an enclosed space
can kill you.
• Never use this appliance in an
enclosed space such as a camper,
tent, car or home.
DANGER

3
General Safety Information cont.
• EXPLOSION - FIRE HAZARD
• Never store propane near high heat, open flames, pilot lights, direct
sunlight, other ignition sources or where temperatures exceed 120
degrees F (49°C).
• Propane is heavier than air and can accumulate in low places. If you
smell gas, leave the area immediately.
• Never install or remove propane tank while outdoor stove is lighted,
near flame, pilot lights, other ignition sources or while outdoor stove is
hot to touch.
• During operation, this product can be a source of ignition. Never use
the stove in spaces that contain or may contain volatile or airborne com-
bustibles, or products such as gasoline, solvents, paint thinner, dust
particles or unknown chemicals. Minimum clearances from combustible
materials: 12 inches from the sides & 48 inches from the top.
• Provide adequate clearances around air openings into the combustion
chamber.
Not for home or recreational vehicle use.
WARNING
We cannot foresee every use which may be made of our products.
Check with your local fire safety authority if you have questions
about use.
Other standards govern the use of fuel gases and heat producing
products for specific uses.Your local authorities can advise you about these.
• Never refill disposable cylinders.
• Use the preset regulator that came with the stove. Do not attempt to
adjust.
DANGER
DANGER
DANGER indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING
WARNING indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
CAUTION indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate personal injury, or property
damage.
Failure to comply with the precautions and instructions provided with this
stove can result in death, serious bodily injury and property loss or damage
from hazards of fire, explosion, burn, asphyxiation, and/or carbon
monoxide poisoning.
Only persons who can understand and follow the instructions should use
or service this stove.
DANGER

4
General Safety Information cont.
• BURN HAZARD
• Never leave stove unattended when hot or in use.
• Keep out of reach of children.
WARNING
CALIFORNIA PROPOSITION 65:
WARNING: This fuel, and byproducts of combustion of this fuel,
contain chemicals known to the state of California to cause cancer,
birth defects, or other reproductive harm.
• SERVICE SAFETY
• Keep all connections and fittings clean. Inspect propane cylinder and
stove propane connections for damage before attaching.
• During set up, check all connections and fittings for leaks using
soapy water. Never use a flame. Bubbles indicate a leak. Check that
the connection is not cross-threaded and that it is tight. Perform
another leak check. If there is still a leak, remove the cylinder and
contact Coleman for service or repairs.
• Use as a cooking appliance only. Never alter in any way or use with
any device or part not specifically designed and sold for this product.
• Clean stove frequently to avoid grease accumulation and possible
grease fires.
CAUTION
WARNING
• This product is fueled by propane gas. Propane gas is invisible, odorless,
and flammable. An odorant is normally added to help detect leaks and can
be described as a “rotten egg” smell. The odorant can fade over time so
leaking gas is not always detectable by smell alone.
• Propane gas is heavier than air and leaking propane will sink to the lowest
level possible. It can ignite by ignition sources including matches, lighters,
sparks or open flames of any kind many feet away from the original leak.
Use only propane gas set up for vapor withdrawal.
• Propane gas should be stored or used in compliance with local ordinances
and codes or with ANSI/NFPA 58. Turn off propane when not in use.
DANGER
• CARBON MONOXIDE HAZARD
• This stove is a combustion appliance. All combustion appliances produce
carbon monoxide (CO) during the combustion process. This product is
designed to produce extremely minute, non-hazardous amounts of CO if
used and maintained in accordance with all warnings and instructions. Do
not block air flow into or out of the stove.
• Carbon Monoxide (CO) poisoning produces flu-like symptoms, watery
eyes, headaches, dizziness, fatigue and possibly death. You can't see it and
you can't smell it. It's an invisible killer. If these symptoms are present
during operation of this product get fresh air immediately!
• For outdoor use only.
• Never use inside house, camper, tent, vehicle or other unventilated or
enclosed areas. This stove consumes air (oxygen). Do not use in unven-
tilated or enclosed areas to avoid endangering your life.

5
To Set Up
DANGER
• CARBON MONOXIDE HAZARD
• For outdoor use only.
• Never use inside house, camper, tent, vehicle or other unventilated or
enclosed areas. This stove consumes air (oxygen). Do not use in unventilated or
enclosed areas to avoid endangering your life.
■Close both burner valves firmly. CAUTION
NOTE: Use 16.4 oz disposable
propane cylinders. The LP-gas
cylinder(s) used with stoves must be
constructed and marked in
accordance with the specifications for
LP-gas cylinders of the U.S.
Department of Transportation or
Transport Canada, CAN/CSA 339.
■For outdoor use only.
■Unit includes base, 10 psi
regulator, grate and four legs.
Propane tank is not included.
■Remove plastic cap from top of
propane cylinder and screw
propane cylinder into regulator
hand tight.
■Screw regulator into stove hand
tight.
■Press each leg onto the stove.
The four locations are indicated by
a slot in the case.
■Each leg covers one slot.
• SERVICE SAFETY
• Keep all connections and fittings
clean. Inspect propane cylinder and
stove propane connections for
damage before attaching.
• During set up, check all connections
and fittings for leaks using soapy
water. Bubbles indicate a leak. Never
use a flame.

6
To Light
To Light cont
WARNING
• BURN HAZARD
• Never leave stove unattended when hot or in use.
• Keep out of reach of children.
DANGER
• EXPLOSION - FIRE HAZARD
• Propane is heavier than air and can accumulate in low places. If you smell
gas, leave the area immediately.
• Always attach or detach propane source outdoors; never while stove is lighted,
near flame, pilot lights, other ignition sources or while stove is hot to touch.
• This stove is red hot during use and can ignite flammables too close to the
burners. Keep flammables at least 12 inches from the sides and 48 inches from
the top of the stove. Keep gasoline and other flammable liquids and vapors well
away from stove.
■Hold lighted match near
burner and open burner valve.
■Adjust flame with burner valves.
■Flame should be blue with hint of
yellow on tips.
To Set Up cont.
■Insert grate into stove case. ■Lay grate on stove top.

■ Close burner valves firmly.
■ Lift off grate.
■Wipe clean with soft
cloth and mild household
cleaner. Do not use
abrasives.
DANGER
• EXPLOSION - FIRE HAZARD
• Never store propane near high
heat, open flames, pilot lights, direct
sunlight, other ignition sources or
where temperatures exceed 120
degrees F (49°C).
• The cylinder must be disconnect-
ed when the stove is in storage.
To Clean
7
To Turn Off
■Unscrew regulator from stove.
To Store
■Remove propane cylinder from
regulator and replace plastic cap
on cylinder.

Things You Should Know
1. It is unsafe and illegal in some places to store
or use propane cylinders of greater than 1.14 kg
(2.5 lbs) water capacity (approximately 1 lb.
propane) in occupied enclosures.
2. Use only parts and accessories specifically
designed and sold for this product.
3. The usual storage areas for camping and
picnic equipment are the basement, attic, or
garage. To avoid the accumulation of dust,
cobwebs, etc., that is common in these areas,
place your stove in a plastic bag and seal it with
a rubber band.
2
4
3
1
Parts List
No. Part Number Description
1 5434A5401 Grate
2 5434-1721 Foot
3 5434-5651 Regulator
4 5434-1491 Knob
8

9
LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM
STATE TO STATE OR PROVINCE TO PROVINCE.
How to Obtain Warranty Service
Take the product to an authorized Coleman service center. You can find the nearest
authorized Coleman service center by visiting www.coleman.com or calling 1-800-835-
3278 or TDD 316-832-8707. If a service center is not conveniently located, attach to the
product a tag that includes your name, address, daytime telephone number and
description of the problem. Include a copy of the original sales receipt. Carefully package
the product and send either by courier or insured mail with shipping and insurance
prepaid to:
For products purchased in the United States:
The Coleman Company, Inc.
3600 North Hydraulic
Wichita, KS 67219
The costs of transporting the product to Coleman or an authorized service center for
warranty service is the responsibility of the purchaser.
Do not mail products with fuel in tanks, or with disposable propane cylinders. Remove
glass globes from lanterns and wrap separately.
DO NOT RETURN THIS PRODUCT TO THE PLACE OF PURCHASE.
If you have any questions regarding this warranty please call 1-800-835-3278 or TDD
316-832-8707.
Limited One Year Warranty
The Coleman Company, Inc. (“Coleman”) warrants that for a period of one year from the
date of original retail purchase, this product will be free from defects in material and
workmanship. Coleman, at its option, will repair or replace this product or any component
of the product found to be defective during the warranty period. Replacement will be
made with a new or remanufactured product or component. If the product is no longer
available, replacement may be made with a similar product of equal or greater value. This
is your exclusive warranty.
This warranty is valid for the original retail purchaser from the date of initial retail
purchase and is not transferable. Keep the original sales receipt. Proof of purchase is
required to obtain warranty performance. Coleman dealers, service centers, or retail
stores selling Coleman® products do not have the right to alter, modify or in any way
change the terms and conditions of this warranty.
What This Warranty Does Not Cover
This warranty does not cover normal wear of parts, parts that are not genuine
Coleman® parts, or damage resulting from any of the following: negligent use or misuse
of the product; use on improper voltage or current; commercial use of the product; use
contrary to the operating instructions; disassembly, repair or alteration by anyone other
than Coleman or an authorized service center. Further, the warranty does not cover Acts
of God, such as fire, flood, hurricanes and tornadoes. Warranty void if damage to product
results from the use of a part other than a genuine Coleman® part.
COLEMAN SHALL NOT BE LIABLE FOR DEFECTS THAT ARE CAUSED BY THE
USE OF UNAUTHORIZED PARTS OR SERVICE. COLEMAN SHALL NOT BE LIABLE
FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE BREACH
OF ANY EXPRESS OR IMPLIED WARRANTY OR CONDITIONS. EXCEPT TO THE
EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE IS LIMITED IN
DURATION TO THE DURATION OF THE ABOVE WARRANTY OR CONDITIONS.
SOME STATES, PROVINCES, OR JURISDICTIONS DO NOT ALLOW THE EXCLUSION
OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LIMITATIONS
ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATIONS OR
EXCLUSION MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC
Warranty

10
Notes:
