Coleman®Fuel Stove
Instructions for use
Poêle Fuel Coleman®
Notice d’emploi
CSA B140.9.2
Portable Pressurized Type
Liquid Petroleum Fuelled
Camp Stove
533 Series
Naphtha 533
CSA B140.9.2
Réchaud de camping portatif
alimenté par du gaz liquide
pressurisé
IMPORTANT
Read this manual carefully before assembling, using or servicing these
stoves. Keep this manual for future reference. If you have questions
about assembly, operation, servicing or repair of these stoves, please
call Coleman in the United States at 1-800-835-3278 or
TDD: 1-316-832-8707 and in Canada at 1-800-387-6161.
IMPORTANT
Lisez attentivement ce manuel avant d’assembler, d’utiliser ou de
réparer le réchaud et gardez-le pour référence ultérieure. Pour toute
question en ce qui concerne l’assemblage, le fonctionnement,
l’entretien ou la réparation, appelez Coleman au 1-800-835-3278 ou
ATS 1-316-832-8707 aux États-Unis et au 1-800-387-6161 au Canada.
© 2014 The Coleman Company, Inc.
www.coleman.com

English - 1
DANGER
DANGER indicates an imminently hazardous
situation which, if not avoided, will result in
death or serious injury.
This manual contains important information
about the assembly, operation and
maintenance of this outdoor liquid fueled
appliance. General safety information is
presented on this page and is also located
throughout these instructions. Particular
attention should be paid to information
accompanied by the safety alert symbol “
DANGER”, “ WARNING”, “ CAUTION”.
Keep this manual for future reference
and to educate new users of this product.
This manual should be read in conjunction
with the labeling on the product.
Safety precautions are essential when any
Coleman
®
fueled equipment is involved.
These precautions are necessary when using,
storing, and servicing. Using this equipment
with the respect and caution demanded will
reduce the possibilities of personal injury or
property damage.
The following symbols shown below are used
extensively throughout these instructions.
Always heed these precautions, as they are
essential when using any Coleman
®
fueled
equipment.
CALIFORNIA PROPOSITION 65:
WARNING: This fuel, and by products of
combustion of this fuel, contain chemicals known
to the state of California to cause cancer, birth
defects, or other reproductive harm.
CAUTION
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in
minor or moderate personal injury, or
property damage.
Failure to comply with the precautions and
instructions provided with these stoves can
result in death, serious bodily injury and
property loss or damage from hazards of fire,
explosion, burn, asphyxiation, and/or carbon
monoxide poisoning.
Only persons who can understand and follow
the instructions should use or service
these stoves.
If you need assistance or information such
as an instruction manual or labels, contact
The Coleman Company, Inc.
DANGER
If you smell gas:
1. Do not attempt to
light appliance.
2. Extinguish any
open flame.
3. Disconnect from
fuel supply.
FOR YOUR
SAFETY
Do not store or use
gasoline or other liquids
with flammable vapors
in the vicinity of this or
any other appliance.
FOR YOUR
SAFETY
WARNING indicates a potentially hazardous
situation which, if not avoided, could result in
death or serious injury.
WARNING
CARBON MONOXIDE
HAZARD
• Thisappliancecan
produce carbon
monoxide which has
no odor.
• Usingitinanenclosed
space can kill you.
• Neverusethis
appliance in an
enclosed space such
as a camper, tent, car
or home.
DANGER

English - 2
WARNING
DANGER
•EXPLOSION-FIREHAZARD
• Duringlightingandoperation,thisproductcan
be a source of ignition. Never use the stove in
spaces that contain or may contain volatile or
airborne combustibles, or products such as
gasoline, solvents, paint thinner, dust particles
or unknown chemicals.
• Minimumclearancesfromcombustible
materials: 24 inches from the sides and 48
inches from the top.
• Provideadequateclearancesaroundair
openings into the combustion chamber.
• Coleman®Liquid Fuel and gasoline are
extremely flammable; handle with care. Fuel
vapors are invisible, explosive, and can be
ignited by ignition sources may feet away.
• Alwaysfilloutdoors.
• NeveropenapressurizedColeman®fuel tank
or fill fuel tank near flame (including pilot lights),
or other ignition sources. It is normal for a
pressurized fuel tank to vent a small amount
of fuel mist when unscrewing the fuel cap. Be
sure stove has no flame before unscrewing the
fuel cap.
WARNING
Not for home or recreational vehicle use.
We cannot foresee every use which may
be made of our products.
Check with your local fire safety authority
if you have questions about use.
Other standards govern the use of fuel
and heat producing products for
specific uses.
Your local authorities can advise you
about these.
• UseonlyColeman®accessories or parts.
• Duringstoveset-up,checkallfittingsfor
leaks using soapy water. Never use a flame.
WARNING
•BURNHAZARD
• Neverleavestoveunattended
when hot or in use.
• Keepoutofreachofchildren.
This appliance may be fueled by Coleman
®
Liquid Fuel.
• Neverusekeroseneorautomotivefuel.
• Storefuelinaclean,properlymarked
container away from flame (including pilot
lights), other sources of ignition, or
excessive heat.
DANGER
•CARBONMONOXIDEHAZARD
• Thisstoveisacombustionappliance.All
combustion appliances produce carbon
monoxide (CO) during the combustion
process. This product is designed to produce
extremely minute, non-hazardous amounts of
CO if used and maintained in accordance with
all warnings and instructions. Do not block air
flow into or out of the stove.
• CarbonMonoxide(CO)poisoningproduces
flu-like symptoms, watery eyes, headaches,
dizziness, fatigue and possibly death. You
can’t see it and you can’t smell it. It’s an
invisible killer. If these symptoms are present
during operation of this product get fresh
air immediately!
• Foroutdooruseonly.
• Neveruseinsidehouse,camper,tent,
vehicle or other unventilated or enclosed
areas. This stove consumes air (oxygen).
Do not use in unventilated or enclosed
areas to avoid endangering your life.
CAUTION
•SERVICESAFETY
• Keepallconnectionsandfittingsclean.Inspect
fuel cap for dirt or damage after refilling the
fuel tank. Wipe up any spilled fuel and dispose
of in a safe place.
• Useasacookingapplianceonly.Neveralter
in any way or use with any device or part not
expressly approved by Coleman.
• Cleanstovefrequentlytoavoidgrease
accumulation and possible grease fires.
• Checkallconnectionsforleaks.Liquid fuel
present at connections indicates a leak.

English - 3
WARNING
Technical
Characteristics
Input: 9,500 BTU/HR Coleman®
Liquid Fuel.
Category: Portable, pressurized-type,
liquid-petroleum-fuelled camp stove.
Fuel: Coleman®Liquid Fuel.
To Set Up
DANGER
•CARBONMONOXIDEHAZARD
• Foroutdooruseonly.
• Neveruseinsidehouse,camper,tent,vehicle
or other unventilated or enclosed areas. This
lantern consumes air (oxygen). Do not use
in unventilated or enclosed areas to avoid
endangering your life.
Thank you for purchasing our new
Coleman®liquid fuel stove. We
recommend operating your new stove
in a safe location outside your home to
familiarize yourself with its liquid fuel
operation before your next
outdoor experience.
Helpful Hints
• Coleman®Liquid Fuel is recommended
when using the stove in temperatures
below 40 °F or in high elevation.
•Forbestresults,alwaysuse
Coleman
®
Filter/Funnel Part No.
5103A700T.
• Donotusekeroseneorautomotive
fuel in this stove.
Filling the tank
Always fill outdoors. Never fill tank,
loosen or remove fuel cap near flame
(including pilot lights), or other ignition
sources.
n With stove on level surface, move red
fuel lever to off position. (Fig. 1)
Fig. 1
1. Coleman
®
Liquid Fuel is extremely
flammable, handle with extreme
care. Fuel vapors are invisible,
explosive, and can be ignited by
ignition sources many feet away.
2. Always fill outdoors. Never
open or fill fuel tank near flame
(including pilot lights), or other
ignition sources. It is normal for
a pressurized fuel tank to vent a
small amount of fuel mist when
unscrewing the fuel cap.
3. Always light and use stove
outdoors; never inside house,
camper, tent, or other unventilated
or enclosed areas.
4. This stove consumes air
(oxygen). Do not use in
unventilated or enclosed areas to
avoid endangering your life.
5. This stove is designed to use
Coleman
®
Liquid Fuel.
6. Store fuel in a clean, properly
marked container away from flame
(including pilot lights), other sources
of ignition, or excessive heat.
7. Use for cooking only. Never alter
in any way or use with any device
or part not expressly approved
by Coleman. Never use as a
space heater. Never leave stove
unattended while burning.
8. Keep stove away from flammables.
Never allow fabric, clothing, or any
flammable material come within 48
inches of the top and 24 inches of
all sides of the stove.
9. When stove is in use, all metal
parts of the stove assembly and
generator become extremely hot.
DO NOT TOUCH.
10. Never place heavy or large
capacity utensils on stove.
11. When using Coleman fuel never
attempt to operate stove if any
plastic tubing on the black pump
assembly is out of place, missing
or damaged.
12. Keep out of reach of children.

English - 4
n Close pump knob firmly. (Fig. 2)
Leak Check
• Performleaktestoutdoors.
• Extinguishallopenflames.
• NEVERleaktestwhensmoking.
• Donotusetheoutdoorstoveuntilconnection
has been leak tested and does not leak.
• Thestoveshallnotbeexposedtoflammable
vapors or liquids during lighting and operation.
WARNING
Fig. 2
n Remove FUEL CAP. Using a funnel
or suitable filling device, fill with
clean, fresh fuel (Fig. 3). Do not tip
stove.
n Replace FUEL CAP on fuel container.
Tighten firmly. Move fuel container
away from stove. WIPE UP ANY
SPILLED FUEL AND DISPOSE OF IN
A SAFE PLACE.
Fig. 3
Pumping
Be sure RED FUEL LEVER is in off
position. (Fig. 4)
n Open PUMP KNOB one full turn.
(Fig. 5)
Fig. 4 Fig. 5
n With thumb over hole in PUMP
KNOB, pump 30 full strokes. (Fig. 6)
n Close PUMP KNOB. (Fig. 7)
Fig. 6
Fig. 7
WARNING
•BURNHAZARD
• Neverleavestoveunattendedwhenhotor
in use.
• Keepoutofreachofchildren.
To Light
n Make sure FUEL VALVE is fully “OFF”.
n CHECK FOR LEAKS in one or more
ways. Look for fuel mist or a wet
appearance of fuel on surfaces.
Listen for hiss of escaping gas. Smell
for fuel odor. Never use a flame. Do
not use if leaking. (Fig. 8)
CHECK
FOR
LEAKS
CHECK
FOR
LEAKS
CHECK
FOR
LEAKS
Fig. 8

English - 5
n Close PUMP KNOB. (Fig. 12)
To Turn Off
Fig. 12
n CAUTION: If fuel or flames appear
below BURNER, immediately turn
RED FUEL LEVER off. Allow stove
to cool. Turn stove upside down
to empty any fuel accumulated
in burner and wipe dry. Review
instructions then relight stove.
n Adjust flame to desired heat with
RED FUEL LEVER. (Fig. 13)
Fig. 14
n Additional pumping may be required
for full heat output. (Fig. 14)
Fig. 13
n Move RED FUEL VALVE from off to
“high” several times. (Fig. 15)
NEVERFILLORLIGHTSTOVEINSIDE
HOUSE,CAMPER,ORTENT.
n Hold lit match at BURNER, then turn
RED FUEL LEVER to high position.
(Fig. 9)
Fig. 9
n After burner lights, open pump one
turn (Fig. 10) and pump additional 30
full strokes. (Fig. 11)
Fig. 11Fig. 10
Fig. 15
n Be sure flame is extinguished. Flame
will linger on burner for 1-2 minutes
after fuel valve is “OFF”.
Fig. 16
n Latch Red FUEL VALVE in off
position. (Fig. 16)
WARNING
•Alwaysturnfuelvalveoffbefore
unscrewing fuel cap from fuel tank.
Never remove fuel cap near ignition
sources, while stove is lit, or hot
to touch.

English - 6
To Store
To Transport
n Make sure stove is cool.
n Move stove away from flame
(including pilot lights) and other
ignition sources.
n Allow to cool completely before
transporting. Transport in an
upright position.
•MAINTENANCE
•Keepstoveareaclearandfree
from combustible materials,
gasoline and other flammable
vapors and liquids.
•Donotobstructtheflowof
combustion and ventilation air.
•Agoodflameshouldbebluewith
minimal yellow tip. Some yellow
tips on flames are acceptable as
long as no carbon or soot
deposits appear.
•Wipecleanwithsoftclothand
mild dish detergent. Do not
use abrasives.

English - 7
Troubleshooting
Symptom
Burner will not
light or flame self-
extinguished.
Burner will not
light or flame is
low or flame self-
extinguished.
Burner self-
extinguishes
during one minute
warm-up.
Yellow flame.
Low heat.
Low heat.
Persistent small
yellow flame.
Persistent high
yellow flame.
Yellow smokey
flame.
Pump does
not pressurize
the liquid fuel
canister.
Intermittent
yellow flame after
extended use on
low heat setting.
Problem
Fuel tank empty.
Little or no pressure in
fuel tank.
Generator is not fully
warmed up.
Excess fuel in burner.
Generator tip plugged.
Faulty generator.
Faulty generator.
Failure in the fuel delivery
system.
Spider webs, insects, or
other obstruction in the
burner and air tube.
Pump seals are dry or
worn.
Flame requires adjustment.
Solution
Refill fuel tank with clean and
fresh Coleman®Liquid Fuel.
Check that fuel cap is tight and
pump 30 strokes.
Attempt to relight burner following
instructions provided for initial
lighting.
A yellow flame is normal until the
generator warms up. If yellow
flame persists, turn off stove,
allow flame to self-extinguish and
the stove to cool. If necessary,
invert stove to remove excess
liquid fuel from the burner. Follow
lighting instructions.
Turn red fuel lever back and forth
several times to clean generator
tip. Be sure to use only fresh and
clean fuel.
Replace with a new generator.
This is a normal periodic
maintenance procedure. The
generator life is dependent on
the type of fuel used. Generator
life is extended by using clean
Coleman®Liquid Fuel.
Replace with a new generator.
May need to replace pump
assembly. Please contact
Consumer Service (see page 9).
Remove burner to inspect and
clean the burner and air tube.
Squirt a few drops of oil in the
OIL HOLE in the pump cap. This
will keep the pump functioning
properly (Fig. 19). If this does not
correct the problem, replace the
pump seals or purchase a new
pump assembly.
Adjust the flame to a slightly
higher level with the red fuel
lever.

English - 8
Parts List
No. Part No. Description
1 220C1401 Fuel Cap
2 220A6201 Pump Repair Kit
3 533-5891 Generator
4 508A5571 Valve Assembly
5 400-3451 Burner Ring Set
6 413C3021 Burner Bowl
7 400-5401 Grate
8 639-1091 Pump Cup & Nut
9 400-5261 Burner Box Assembly
10 400A1261 Generator Bracket
11 400-0601 Screw Pkg. (6)
12 200-6381 Check Valve & Stem Assy.
13 400B5151 Valve Stem Assy.
13
8
10
7
3
11 9
12
2
5
6
4
1
