Coleman 5430F Series User manual

Coleman0
IMPORTANT
Read this
manual care-
fully before
assem-
bling, using or
servicing
these stoves.
Keep this
manual for
future
refer-
ence. If you have ques-
tions about
assembly,
operation, servicing
or
repair of
these stoves,
please
call Coleman
at 1-800-835-3278 or
TDD: 316-832-8707.
In Canada
call
1-800-
387-6161.
3000000465
.NSTASTART'M
Electronic Ignition
3000000449
Standard
Ignition
® 2008
The Coleman Company,
Inc.
www.coleman.com
ANSI Z21 .72b -
CSA
11.2b
(2002) Camp Stove

Contents
General Safety Information
To
Set
Up
To
Light
To
Turn Off
To Store
To
Clean
Things You Should
Know
Parts List
Warranty
General Safety Information
FOR YOUR
SAFETY
If you smell gas:
1. Do not attempt to light appliance.
2.
Extinguish any open
flame.
3.
Disconnect from fuel
supply.
FOR YOUR
SAFETY
Do not store or
use gasoline or
other
liquids with
flammable vapors
in
the vicinity of
this
or any
other
appliance.
A DANGER
CARBON MONOXIDE HAZARD
• This appliance
can
produce
carbon monoxide which has no
odor.
•
Using it in an enclosed space
can kill
you.
• Never use
this
appliance
in an
enclosed space
such as a camp-
er, tent, car or home.
This manual contains
important information about
the
assembly, operation
and
maintenance
of
these
propane stoves.
General safety information is pre-
sented
in
these
first few pages and is also located
throughout the
manual. Particular attention should
be
paid to information accompanied by the safety
alert symbol "ADANGER", "AWARNING",
"ACAUTION".
Keep
this manual for future reference and to
educate
new
users
of
this product. This
manual
should be read in conjunction with the labeling
on
the product.
Safety precautions are essential when any
mechanical
or propane fueled equipment is
involved. These precautions
are
necessary
when
using, storing,
and
servicing. Using
this
equipment
with the respect and caution
demanded
will reduce
the possibilities
of personal injury or
property
damage.
The following symbols shown
below
are
used
extensively throughout this manual. Always heed
these precautions, as they are
essential when
using any mechanical or propane fueled
equip-
ment.

General Safety
Information coat.
DANGER indicates an
imminently hazardous
situation which, if not
avoided, will result
in death or serious injury.
WARNING indicates a
potentially hazardous
situation which, if not
avoided,
could result in
death or serious injury.
CAUTION indicates a
potentially hazardous
situation which, if not
avoided,
may result in
minor or moderate
personal injury, or property
damage.
Failure to
comply with the
precautions and instructions provided
with
these stoves
can result in death, serious
bodily injury and
property
loss
or
damage
from hazards of fire,
explosion, bum,
asphyxiation, and/or carbon
monoxide poisoning.
Only persons who can understand
and follow the
instructions should use
or
service these stoves.
If you need assistance or
information such as an
instruction manual or
labels, contact
The
Coleman
Company, Inc.
A
DANGER
~
yr
•
EXPLOSION - FIRE HAZARD
• Never
store propane
near high heat, open
flames, pilot lights, direct
sunlight, other
ignition
sources
or where
temperatures exceed 120
degrees F
(49°C).
• Propane is heavier
than air
and
can accumulate
in low places. If you
smell
gas, leave the area
immediately.
• Never install or remove propane tank while
outdoor stove is lighted,
near flame, pilot lights,
other ignition sources or while
outdoor stove is
hot to touch.
• During
lighting
and
operation,
this
product
can
be a
source of ignition.
Never use the stove
in
spaces
that contain
or
may
contain volatile
or
airborne
combustibles, or products
such
as
gasoline, solvents,
paint
thinner, dust particles
or unknown chemicals.
Minimum clearances from
combustible materials:
12
inches
from the sides & 48
inches from the top.
•
Provide
adequate clearances around
air openings into the
combustion chamber.
• Do not obstruct the
flow of combustion and
ventilation air.
A
WARNING
Not
for home or recreational vehicle
use.
We cannot foresee
every use which may be
made of our products.
Check with your
local
fire
safety authority
if
you have questions
about use.
Other
standards
govern the use
of fuel
gases and heat
producing
products
for specific uses. Your
local
authorities
can
advise
you about
these.
• Never
refill disposable cylinders. •
Use
the preset
regulator that
came with the stove.
Do not
attempt to
adjust. • Use
only Coleman®
accessories
or parts.
During stove set-up,
check all fittings for leaks
using
soapy
water.
Never use a flame.

General Safety Information coat.
A DANGER
•
CARBON MONOXIDE HAZARD
•
This
stove is
a
combustion
appliance. All
combustion
appliances produce
carbon monoxide
(CO)
during
the
combustion
process. This product is
designed to produce extremely minute, non -hazardous amounts of
CO
if
used and maintained in
accordance
with all warnings and
instructions. Do
not block air flow into or out of the stove.
• Carbon Monoxide (CO) poisoning produces flu -like symptoms, watery
eyes, headaches, dizziness, fatigue and possibly death. You can't see it and
you can't
smell
it. It's an invisible killer. If these symptoms are present dur-
ing operation of
this product get fresh air immediately!
• For outdoor
use
only.
• Never use inside
house,
camper, tent,
vehicle
or other
unventilated
or enclosed areas. This stove consumes air (oxygen). Do not
use
in
unventilated or
enclosed areas to
avoid endangering your life.
A
WARNING
•
This product is
fueled by propane gas. Propane gas is invisible,
odorless,
and
flammable. An odorant
is normally
added
to help detect
leaks and can
be
described
as
a "rotten egg"
smell. The odorant can fade over
time so
leaking
gas is not always
detectable by smell
alone.
•
Propane gas is heavier than
air
and leaking propane will sink to
the lowest
level
possible. It can
ignite by ignition
sources including matches,
lighters,
sparks
or
open
flames
of any
kind many
feet away from the original leak.
Use
only
propane
gas set up for vapor
withdrawal.
•
Propane gas should be
stored
or
used in
compliance with local
ordinances
and codes or with
ANSI/NFPA
58.
Turn
off
propane
when
not
in
use.
CALIFORNIA PROPOSITION
65:
WARNING: This
fuel,
and byproducts of combustion of
this
fuel,
contain
chemicals known to the state of
California to cause
cancer,
birth
defects, or other reproductive harm.
A
WARNING
• BURN HAZARD
• Never
leave stove
unattended
when
hot or in use.
•
Keep out
of reach of
children.
A CAUTION
• SERVICE SAFETY
•
Keep
all
connections and
fittings clean. Inspect propane cylinder and
stove propane
connections
for
damage before attaching.
• During
set up, check all
connections and fittings for leaks using
soapy water. Never
use a flame.
Bubbles indicate a leak. Check that
the connection
is not cross
-threaded and that it is tight. Perform
anoth-
er leak check.
If there is still a leak,
remove the cylinder and contact
Coleman for
service or
repairs.
•
Use as a cooking
appliance only. Never alter in any
way
or
use
with
any device or part
not expressly
approved by Coleman.
• Clean
stove frequently to
avoid grease accumulation and possible
grease fires.

Technical
Characteristics
Input:
Model
3000000449
10,000
BTU/H Per Burner
Model
3000000465
10,000
BTU/H
Per
Burner
Category: Pressure regulated propane
Fuel:
16.4 oz. disposable propane cylinders
Regulator:
5430
To Set Up
A DANGER
•
CARBON
MONOXIDE
HAZARD
•
For outdoor use only.
• Never
use
inside
house,
camper, tent, vehicle or other unventilated or
enclosed areas.
This
stove
consumes air
(oxygen).
Do not use in unventilated
or
enclosed
areas to
avoid
endangering your life.
NOTE: Use
Coleman®
16.4 oz.
disposable
propane
cylinders.
The
LP
-gas cylinder(s)
used with
stoves
must
be constructed
and
marked
in
accordance with
the specififcations
for LP -gas
cylinders
of the
U.S.
Department of
Transportation or
Transport Canada, CAN/CSA
B339.
■ Press
on
latch
to
open lid
and
position wind
baffles
as
shown.
Insert
wire clips into slots.
■ Close both burner valves
firmly.
■ Remove regulator from
storage
position under
grate
and inspect
gasket
on the
stove
connection
before use.
■ Remove
plastic cap
from
top
of propane cylinder and screw
propane
cylinder
into
regulator
hand
tight.

To
Set
Up
cons
■
Screw
regulator into
stove
hand
tight.
■ Propane
cylinder
correctly
installed.
0
A
CAUTION
•
SERVICE SAFETY
Keep all connections and fittings
clean. Inspect
propane
cylinder
and stove
propane connections for
damage before
attaching.
During
set up,
check all
connections
and fittings
for
leaks
using
soapy
water. Bubbles
indicate a
leak. Never use a flame.
■ Never operate stove
with
propane
cylinder in an inverted
position.
To
Light
A
DANGER
• EXPLOSION -
FIRE HAZARD
•
Propane
is
heavier
than air and can
accumulate in low
places.
If you
smell
gas,
leave
the
area immediately.
• Always attach or detach propane source outdoors;
never
while stove is lighted,
near flame, pilot lights, other
ignition
sources
or
while stove
is
hot to
touch.
• This stove
is red
hot during use
and
can ignite flammables
too
close to
the
burners.
Keep
flammables at
least
12 inches
from
the
sides
and 48
inches
from
the top
of
the stove. Keep
gasoline
and
other
flammable liquids and vapors
well
away
from
stove.
• The stove must
not
be exposed to flammable vapors
or
liquids during lighting.
A
CAUTION
• Make
sure
all the burners are off except for the burner
being
lighted.
INSTASTARTTM
Electronic Ignition
Stoves:
■
Set on sturdy,
flat
surface.
For
outdoor use
only.
■
Open
burner
valve
and
rotate
ignitor
knob several
times
until
burner
lights.
NOTE: If
the
burner
does
not light
in 4 seconds,
turn
the
burner
valve
to
OFF and wait 5 minutes for the
gas
to
clear
before
trying
again.
If
the
burner
does not light on the
second
try,
turn the burner valve
to OFF and wait 5
minutes
for
the gas to clear, and then try
match
-lighting
the
burner.
■
Repeat
above
steps
to
light
second burner.

To Light
cant
Standard ignition stoves:
■
Set on
sturdy, flat
surface.
For outdoor use only.
■ Hold
lighted match near
burner
and open
burner
valve.
■
Adjust flame with burner
valves.
■
Flame should
be
blue with a
hint of
yellow
on
tips.
A
WARNING
• BURN
HAZARD
• Never leave stove unattended
when hot or in use.
•
Keep out
of
reach of children.
To
Turn
Off
■ Close
burner
valves
firmly.
J
To
Store
■ Remove propane
cylinder
from
regulator and replace plastic cap on
cylinder.
0

To
Store Cont.
■
Unscrew
regulator from stove
and
place
in storage position as
shown.
To
Clean
A
DANGER
• EXPLOSION - FIRE HAZARD
• Never
store propane
near high
heat, open flames, pilot
lights, direct
sunlight, other
ignition sources or
where temperatures exceed
120
degrees
F
(49°C).
• The cylinder
must
be
disconnected
when
the
stove is
in
storage.
■ Liftoff
grate.
■ Wipe
clean
with soft cloth and
mild household
cleaner.
Do not
use abrasives.
0
Things
You Should
Know
1. It is unsafe and illegal in some places to store
or use propane cylinders
of greater than
1.14 kg
(2.5
Ibs)
water capacity
(approximately
1 lb.
propane)
in occupied enclosures.
2. The usual storage areas
for camping and picnic equipment are
the basement, attic, or
garage.
To
avoid
the
accumulation of dust,
cobwebs, etc.,
that
is common
in these areas, place your stove in a
plastic bag and seal it
with
a
rubber band.
3.
For
repair service call one
of
the numbers
on the front
cover for
location
of
your
nearest
Coleman Service
Center. If
a
service center
is not
conveniently
located,
attach to the product a
tag
that includes
your name,
address,
daytime
telephone number and description of the
problem. Carefully
package the
product
and
send either by courier or
insured mail with shipping
and
insurance prepaid to:
For
products
purchased in the United States:
The Coleman
Company,
Inc.
3600
North Hydraulic
Wichita,
KS
67219
For
products
purchased in
Canada:
Sunbeam Corporation (Canada) Limited
DBA
Jarden Consumer Solutions
20B
Hereford
Street
Brampton, ON
L6Y
0M1
4. If not
completely
satisfied
with
the performance
of
this
product,
please
call
one
of the numbers
listed
on the cover of this
manual.

Part List
No.
Standard
Ignition
Electronic
Ignition Description
1
5010000600 5010000600
Grate - Cooking
2 5010000604 5010000604 Burner
rings
w/
Cap,
Plate, & Screw (One
Set)
3 R430
-565T R430-5651 Regulator
Assembly
4 41364971 41364971 Wind
Baffle Clips
5
R413A1491 R413A149T Valve Knob
w/
Screw
(1
each)
6 N/A 413-1481 Ignitor
Knob w/ Screw
7 N/A
413-1481
Igniter Unit
8 N/A 5010000602 Electrodes
w/wires -
Left
and Right
9
5010000605
5010000605 Lid Assy
Complete
0

Warranty
Limited Three
Year
Warranty
The
Coleman Company, Inc. ("Coleman")
warrants
that
for a period
of
three years
from th e date of
original
retail purchase,
this product will be free
from
defects in material
and
workmanship.
Coleman,
at its option, will
repair
or replace this
product or any
component
of the product found to
be
defective
during
the warranty period.
Replacement
will be made
with
a
new
or
remanufactured
product
or
component. If
the
product is no
longer available, replacement may be
made with a similar product
of equal or greater
value. This
is
your
exclusive warranty.
This warranty is valid
for
the
original retail purchaser from th
e
date of
initial retail
purchase and
is
not
transferable. Keep the
original
sales receipt. Proof
of purchase is
required
to
obtain warranty performance.
Coleman
dealers,
service centers,
or
retail
stores
selling Coleman® products do not have the right to
alter, modify or in
any
way
change
the
terms and conditions
of
this warranty.
What
This
Warranty Does Not
Cover
This warranty does
not cover normal wear of parts, parts that are not
genuine
Coleman® parts, or
damage
resulting from any
of
the
following: negligent use or
misuse
of the
product; commercial use
of
the product; use
contrary
to
the operating instructions;
disassembly, repair or alteration by anyone
other
than
Coleman or
an
authorized
service
center. Further,
the
warranty does not cover Acts
of God, such as
fire, flood,
hurricanes
and
tornadoes.
Warranty
void
if
damage
to product results from
the
use
of a part
other
than a genuine
Coleman®
part.
COLEMAN SHALL
NOT BE LIABLE FOR DEFECTS
THAT ARE CAUSED BY
THE
USE
OF
UNAUTHORIZED
PARTS
OR SERVICE.
COLEMAN SHALL
NOT
BE
LIABLE FOR
ANY INCIDENTAL
OR
CONSEQUENTIAL DAMAGES
CAUSED BY
THE BREACH
OF ANY
EXPRESS
OR IMPLIED
WARRANTY
OR CONDITIONS.
EXCEPT
TO
THE
EXTENT PROHIBITED
BY
APPLICABLE
LAW, ANY
IMPLIED
WARRANTY
OF MERCHANTABILITY OR
FITNESS FOR
A PARTICULAR PURPOSE
IS LIMITED
IN DURATION
TO THE
DURATION OF
THE ABOVE WARRANTY
OR
CONDITIONS.
SOME
STATES, PROVINCES,
OR
JURISDICTIONS DO
NOT ALLOW
THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES
OR LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS, SO THE
ABOVE
LIMITATIONS
OR EXCLUSION MAY NOT
APPLY
TO
YOU. THIS
WARRANTY
GIVES
YOU
SPECIFIC
LEGAL
RIGHTS,
AND YOU MAY ALSO
HAVE OTHER RIGHTS THAT
VARY
FROM STATE
TO STATE
OR PROVINCE
TO
PROVINCE.
How
to Obtain Warranty Service
Take the product to an authorized
Coleman
service
center. You can find
th e
nearest
authorized
Coleman
service
center by visiting www.coleman.com or
calling
1-800-
835-3278
or
TDD 316-832-8707
in the United States
or 1
800
387-6161 in
Canada. If
a service center is not conveniently located, attach to
th e product
a tag that includes
your
name, address, daytime
telephone number
and
description of the problem. Include
a copy of the
original
sales receipt.
Carefully package the product and send
either
by
courier or insured mail
with shipping
and
insurance
prepaid
to:
For products
purchased
in the United States:
The
Coleman Company, Inc.
3600 North Hydraulic
Wichita,
KS 67219
For products
purchased
in Canada:
Sunbeam
Corporation
(Canada) Limited
DBA Jarden Consumer
Solutions
20B Hereford Street
Brampton,
ON L6Y
OM1
The costs of transporting
the product
to Coleman
or an
authorized
service
center for
warranty
service is the responsibility
of
the purchaser.
Do
not
mail products with fuel in tanks, or with disposable propane
cylinders.
DO
NOT RETURN
THIS
PRODUCT
TO
THE PLACE OF
PURCHASE.
If
you
have any questions regarding
this warranty please
call 1-800-835-3278
or
TDD
316-832-8707 in th e United States or
1
800 387-6161
in Canada.
0
