Coleman 5469 Series User manual

IMPORTANT
Read this manual carefully before assembling, using or servicing these stoves. Keep
this manual for future reference. If you have questions about assembly, operation,
servicing or repair of these stoves, please call Coleman at 1-800-835-3278 or TDD:
316-832-8707. In Canada call 1-800-387-6161.
IMPORTANT
Lisez attentivement ce manuel avant d’assembler, d’utiliser ou de réparer le réchaud
et gardez-le pour référence ultérieure. Pour toute question en ce qui concerne
l’assemblage, le fonctionnement, l’entretien ou la réparation, appelez Coleman au 1
800 835-3278 ou
ATS 316-832-8707 aux États-Unis et au 1 800 387-6161 au Canada.
IMPORTANTE
Lea este manual cuidadosamente antes de ensamblar, usar o reparar esta estufa.
Guarde este manual para uso de referencia en el futuro. Si tiene alguna pregunta acerca
del ensamblaje, uso, compostura o reparaciones a la estufa, por favor llame a Coleman
al 1-800-835-3278 o TDD: 316-832-8707. En Canada llame al 1-800-387-6161.
Propane Stoves
Réchauds à propane
Estufas de gas Propano
Instructions for use
Notice d’emploi
Instrucciones de uso
© 2008 The Coleman Company, Inc.
www.coleman.com
®®
ANSI Z21.72b - CSA 11.2b (2002)
Camp Stove
Poêle de camping
Estufa de campamento
INSTASTART™ Electronic Ignition
Allumage électronique
Encendido electrónico
Standard Ignition
Allumage standard
Encendido estándar
Patents Pending
Brevets en instance
Patentes Pendientes
5469- Series
5469A Series

English-1
If you smell gas:
1. Do not attempt to
light appliance.
2. Extinguish any
open flame.
3. Disconnect from
fuel supply.
FOR YOUR
SAFETY
Do not store or use
gasoline or other liquids
with flammable vapors in
the vicinity of this or any
other appliance.
FOR YOUR
SAFETY
CARBON MONOXIDE
HAZARD
• This appliance can pro-
duce carbon monoxide
which has no odor.
• Using it in an enclosed
space can kill you.
• Never use this appliance
in an enclosed space
such as a camper, tent,
car or home.
DANGER
WARNING
WARNING indicates a potentially hazardous
situation which, if not avoided, could result in
death or serious injury.
DANGER
DANGER indicates an imminently hazardous
situation which, if not avoided, will result in
death or serious injury.
This manual contains important information about
the assembly, operation and maintenance of this
outdoor propane appliance. General safety infor-
mation is presented on this page and is also locat-
ed throughout these instructions. Particular atten-
tion should be paid to information accompanied by
the safety alert symbol “ DANGER”,
“ WARNING”, “ CAUTION”.
Keep this manual for future reference and
to educate new users of this product. This manual
should be read in conjunction with the labeling on
the product.
Safety precautions are essential when any
mechanical or propane fueled equipment is
involved. These precautions are necessary when
using, storing, and servicing. Using this equipment
with the respect and caution demanded will reduce
the possibilities of personal injury or property damage.
The following symbols shown below are used
extensively throughout these instructions. Always
heed these precautions, as they are essential when
using any mechanical or propane fueled equipment.
CAUTION
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in
minor or moderate personal injury, or
property damage.
Failure to comply with the precautions and
instructions provided with these stoves can
result in death, serious bodily injury and proper-
ty loss or damage from hazards of fire, explo-
sion, burn, asphyxiation, and/or carbon
monoxide poisoning.
Only persons who can understand and follow
the instructions should use or service
these stoves.
If you need assistance or information such
as an instruction manual or labels, contact
The Coleman Company, Inc.
CALIFORNIA PROPOSITION 65:
WARNING: This fuel, and byproducts of com-
bustion of this fuel, contain chemicals known to the
state of California to cause cancer, birth defects,
or other reproductive harm.
DANGER

English-2
• This product is fueled by propane gas. Propane
gas is invisible, odorless, and flammable. An
odorant is normally added to help detect leaks
and can be described as a ”rotten egg” smell.
The odorant can fade over time so leaking gas
is not always detectable by smell alone.
• Propane gas is heavier than air and leaking
propane will sink to the lowest level possible. It
can ignite by ignition sources including match-
es, lighters, sparks or open flames of any kind
many feet away from the original leak. Use
only propane gas set up for vapor withdrawal.
• Propane gas should be stored or used in compli-
ance with local ordinances and codes or with
ANSI/NFPA 58. Turn off propane when not in use.
WARNING
DANGER
• EXPLOSION - FIRE HAZARD
• Never store propane near high heat, open
flames, pilot lights, direct sunlight, other
ignition sources or where temperatures exceed
120 degrees F (49°C).
• Propane is heavier than air and can
accumulate in low places. If you smell gas,
leave the area immediately.
• Never install or remove propane tank while
outdoor stove is lighted, near flame, pilot lights,
other ignition sources or while outdoor stove is
hot to touch.
• During lighting and operation, this product can
be a source of ignition. Never use the stove in
spaces that contain or may contain volatile or
airborne combustibles, or products such as
gasoline, solvents, paint thinner, dust particles
or unknown chemicals. Minimum clearances
from combustible materials: 12 inches from the
sides and 48 inches from the top.
• Provide adequate clearances around air
openings into the combustion chamber.
WARNING
Not for home or recreational vehicle use.
We cannot foresee every use which may be
made of our products.
Check with your local fire safety authority if
you have questions about use.
Other standards govern the use of fuel gases
and heat producing products for specific uses.
Your local authorities can advise you
about these.
• Never refill disposable cylinders.
• Use the preset regulator that came with the
stove. Do not attempt to adjust.
• Use only Coleman®accessories or parts.
During stove set-up, check all fittings for
leaks using soapy water. Never use a flame.
WARNING
• BURN HAZARD
• Never leave stove unattended when hot
or in use.
• Keep out of reach of children.
DANGER
• CARBON MONOXIDE HAZARD
• This stove is a combustion appliance. All
combustion appliances produce carbon
monoxide (CO) during the combustion
process. This product is designed to produce
extremely minute, non-hazardous amounts of
CO if used and maintained in accordance with
all warnings and instructions. Do not block air
flow into or out of the stove.
• Carbon Monoxide (CO) poisoning produces
flu-like symptoms, watery eyes, headaches,
dizziness, fatigue and possibly death.You
can’t see it and you can’t smell it. It’s an
invisible killer. If these symptoms are present
during operation of this product get fresh
air immediately!
• For outdoor use only.
• Never use inside house, camper, tent,
vehicle or other unventilated or enclosed
areas. This stove consumes air (oxygen).
Do not use in unventilated or enclosed
areas to avoid endangering your life.
CAUTION
• SERVICE SAFETY
• Keep all connections and fittings clean.
Inspect propane cylinder and stove propane
connections for damage before attaching.
• During set up, check all connections and
fittings for leaks using soapy water. Never use
a flame. Bubbles indicate a leak. Check that
the connection is not cross-threaded and that
it is tight. Perform another leak check. If there
is still a leak, remove the cylinder and contact
Coleman for service or repairs.
• Use as a cooking appliance only. Never alter
in any way or use with any device or part not
expressly approved by Coleman.
• Clean stove frequently to avoid grease
accumulation and possible grease fires.

English-3
To Set Up
Technical
Characteristics
Input (5469- Series): 10,000 BTU/H per burner
Input (5469A Series): 11,000 BTU/H per burner
Category: Pressure regulated propane
Fuel:
16.4 oz. disposable propane cylinders
Regulator: 5430
DANGER
• CARBON MONOXIDE HAZARD
• For outdoor use only.
• Never use inside house, camper, tent, vehicle
or other unventilated or enclosed areas. This
stove consumes air (oxygen). Do not use in
unventilated or enclosed areas to avoid
endangering your life.
■ NOTE: Use Coleman 16.4 oz. disposable
propane cylinders. The LP-gas cylinder(s) used
with stoves must be constructed and marked in
accordance with the specifications for LP-gas
cylinders of the U.S. Department of Transportation
or
Transport Canada, CAN/CSA B339 .
■ Remove components from carton. (Fig. 1)
Fig. 1
Fig. 3
■ Position windguards as desired. (Fig. 3)
Fig. 2
■ To open the lid,
press the latch
release located
above the
handle. (Fig. 2)
Fig. 4
■ Install pot support as shown. (Fig. 4)
■ Close both burner valves firmly. (Fig. 5)
Fig. 5
CAUTION
• SERVICE SAFETY
• Keep all connections and fittings clean.
Inspect propane cylinder and stove propane
connections for damage before attaching.
• During set up, check all connections and
fittings for leaks using soapy water. Bubbles
indicate a leak. Never use a flame.
Fig. 7
Fig. 6
■ Screw regulator into stove hand tight. (Fig. 6)
■ Remove plastic cap from top of propane bottle and
screw propane bottle into regulator hand tight. (Fig. 7)

English-4
Fig. 9
■ Propane cylinder correctly installed. (Fig. 8)
■ Never operate stove with propane cylinder in an
inverted position. (Fig. 9)
Fig. 8
To Light
WARNING
• Perform leak test outdoors.
• Extinguish all open flames.
• NEVER leak test when smoking.
• Do not use the outdoor stove until connection
has been leak tested and does not leak.
Leak Check
DANGER
• EXPLOSION - FIRE HAZARD
• Propane is heavier than air and can accumu-
late in low places. If you smell gas, leave the
area immediately.
• Always attach or detach propane source out-
doors; never while stove is lighted, near flame,
pilot lights, other ignition sources or while
stove is hot to touch.
• This stove is red hot during use and can ignite
flammables too close to the burners. Keep
flammables at least 12 inches from the sides
and 48 inches from the top of the stove. Keep
gasoline and other flammable liquids and
vapors well away from stove.
• The stove must not be exposed to flammable
vapors or liquids during lighting.
WARNING
• BURN HAZARD
• Never leave stove unattended when hot
or in use.
• Keep out of reach of children.
Standard ignition stoves
■ Set on sturdy, flat surface. For outdoor use only.
■ Hold lighted match near burner and open
burner valve. (Fig. 10 and Fig. 11)
Fig. 10
INSTASTART™
Electronic Ignition Stoves
■ Set on sturdy, flat surface. For outdoor use only.
■ Open burner valve to the red ignition setting
mark (Fig. 12) and push igniter button
repeatedly until burner lights (Fig. 13 and 14).
Note: If igniter fails to light stove, use match to light
burner. If the stove is wet the igniter may not spark.
Fig. 11
Fig. 13
Fig. 14
Fig. 12
Ignition
Setting

English-5
■ Adjust flame with burner valve. (Fig. 15) Flame
should be blue with a hint of yellow on tips.
Fig. 15
To Turn Off
To Clean
■ Close both burner valves firmly. (Fig. 16)
■ Make sure stove is cool.
■ Move stove away from flame (including pilot
lights) and other ignition sources.
■ Remove propane cylinder from regulator and
replace protective cap on cylinder. (Fig. 17)
■ Remove regulator from stove. (Fig. 18)
Fig. 16
Fig. 19
• MAINTENANCE
• Keep stove area clear and free from
combustible materials, gasoline and other
flammable vapors and liquids.
• Do not obstruct the flow of combustion and
ventilation air.
• A good flame should be blue with minimal
yellow tip. Some yellow tips on flames are
acceptable as long as no carbon or soot
deposits appear.
• Wipe clean with soft cloth and mild dish
detergent. Do not use abrasives. (Fig. 19)
Fig. 17 Fig. 18
DANGER
• EXPLOSION - FIRE HAZARD
• Never store propane near high heat, open
flames, pilot lights, direct sunlight, other igni-
tion sources or where temperatures exceed
120 degrees F (49°C).
• The cylinder must be disconnected when the
stove is in storage.
■ For storage or
transport,
the regulator
may be located
below the pot
support.
(Fig. 20)
To Store
Fig. 20
Fig. 21
■ To carry the stove, firmly
grasp the stove by the
handle. (Fig. 21)

Things You Should Know
1. It is unsafe and illegal in some places to store or
use propane cylinders of greater than 1.14 kg (2.5
lbs) water capacity (approximately 1 lb. propane) in
occupied enclosures.
2. The usual storage areas for camping and picnic
equipment are the basement, attic, or garage. To
avoid the accumulation of dust, cobwebs, etc., that
is common in these areas, place your stove in a
plastic bag and seal it with a rubber band.
3. For repair service call one of the numbers on
the front cover for location of your nearest
Coleman Service Center. If a service center is not
conveniently located, attach to the product a tag
that includes your name, address, daytime
telephone number and description of the problem.
Carefully package the product and send either by
courier or insured mail with shipping and insurance
prepaid to:
For products purchased in the United
States:
The Coleman Company, Inc.
3600 North Hydraulic
Wichita, KS 67219
For products purchased in Canada:
Sunbeam Corporation (Canada) Limited
DBA Jarden Consumer Solutions
20B Hereford Street
Brampton, ON L6Y 0M1
4. If not completely satisfied with the performance
of this product, please call 1-800-835-3278 in the
US or
1 800 387-6161 in Canada.
www.coleman.com
English-6
1
2
3
4
Parts List
No. Part Number Description
1 5469-5401 Grate
2 5469-5321 Burner Assembly (1 pk)
3 5430-5651 Regulator Assembly
4 5469-1511 Knob & Screw (1 pk)
Continued on English-7

4010002994 (20080116)
The Coleman Company, Inc. • 3600 N. Hydraulic • Wichita, KS 67219 U.S.A.
1-800-835-3278 • TDD: 316-832-8707
Sunbeam Corporation (Canada) Limited • DBA Jarden Consumer Solutions
20B Hereford Street • Brampton, ON L6Y 0M1 • 1 800 387-6161
© 2008 The Coleman Company, Inc. All rights reserved. Coleman®, and
are registered trademarks and INSTASTART™ is a trademark of The Coleman Company, Inc.
© 2008 The Coleman Company, Inc. Tous droits réservés. Coleman®, et
sont des marques déposées alors que INSTASTART™ est une marque de commerce de The Coleman Company, Inc.
© 2008 The Coleman Company, Inc. Todos los derechos reservados. Coleman®, y
son marcas registradas
y INSTASTART™ es una marca de la compañía The Coleman Company, Inc.
www.coleman.com
www.colemancanada.ca
