Coleman 2000007824 Manual

MODEL 2000007824
Main Body Pole, black, longest
Vestibule Pole, grey, long
Ridge Pole, black, short
2
1
1
5010000539
5010000539
5010000539
5010000549
5010000549
5010000549
1
2
3
5
5
Pole
Sleeve
Fig. 1
1
2
5
Fig. 3
Fig. 4
Pole
Pin
Fig. 5
Pole Clip
t Attach ridge pole to underside of rainfly with straps and insert
the tips of the ridge pole into the pockets on underside of rainfly.
(Fig. 6 & 7)
t Drape rainfly over tent. (Fig. 8)
t Connect the elastic loops with “S” hooks, (found at the rainfly
corners) to the rings found at the tent corners. (Fig. 9)
t Secure rainfly with straps located on the underside of rainfly.
(Fig. 10)
t Attach and stake out guylines. (Fig. 8)
HINT: During setup, keep door zipped to keep proper tension
on fabric.
STITCH LINE
TENT SETUP INSTRUCTIONS
2
Connect Poles to Tent
t Insert one pin into one end of the pole. (Fig. 3 and 4)
t Go to opposite end of pole and carefully insert the pin into the
other pole end. (Fig. 4)
t Repeat for all poles.
3
Attach Tent to Body Poles
Using Clips
t Attach clips along the edges of tent to body poles. (Fig. 5)
t Make any adjustments to the tent stakes, if needed.
4
Attach Rainfly
(continued on other side)
1
Layout & Positioning
of Tent and Poles
t Layout and position the tent with door facing desired
direction. (Fig. 1)
t Stake down tent corners first through the stake rings. (Fig. 2)
t Keep the floor taut.
t Stake down the remainder of the stake rings.
t Assemble all poles by unfolding and interlocking the shock-
corded pole sections.
t Insert the body poles & vestibule pole into the pole sleeves.
Before you begin
t Read all instructions before set up.
t Select a level site clear of rocks, branches, and other hard or
sharp objects, to install your tent.
WARNING: Keep clear of overhead power lines.
t Do not set up your tent under trees because of potential lightning
strikes or falling tree limbs in inclement weather.
t Secure with all stakes and guylines provided to prevent property
damage or personal injury.
t For best results in windy conditions, position narrow end of tent
into the wind.
t Enlist the help of at least one other person to assist you when it
is time to assemble the tent.
Pole Descriptions
Description Qty. Pole
Repair Kit
Pole
Replacement Kit
No.
Fig. 2
Tent
Stake
Stake Ring

4010009311 (20100612)
5
Pocket
Fig. 8
Fig. 7
Fig. 6
(Bottom View)
Rainfly
Guyline
Fig. 10
Fig. 9
Pole
Strap
Rainfly
3
“S”
Hook
1. All poles and stakes must be placed in the storage bag to prevent damage to the fabric items placed in the carry case.
2. Make sure tent is clean and dry before placing in carry case.
3. Remove rainfly, spread out on floor of tent, then unzip door & vents before taking tent down for storage.
4. Neatly fold tent to width of pole storage bag, place on tent, roll tightly, and place in carry case.
5. Store in a clean, dry area.
5
To Store
3
STITCH LINE
This tent meets the flammability requirements of CPAI-84. The
fabric may burn if left in continuous contact with any flame source.
The application of any foreign substance to the tent fabric may
render the flame-resistant properties ineffective.
WARNING: Keep all flame and heat sources away from this
tent fabric.
Things You Should Know:
t Under certain conditions (cold weather, high humidity, etc.)
condensation will form on the inside of your tent. Condensation
is caused by water vapor from your breath, perspiration, or any
wet clothing inside the tent. It is NOT LEAKAGE through the tent
fabric. It can be minimized by removing wet clothing from your
tent and by providing good ventilation through the tent.
t Tree limbs, tree sap, bird droppings, or moisture steadily dripping
off tree limbs can cause damage to the tent fabric and its coating
resulting in leaks or loss of flame-resistant properties.
t Never store tent, even for a short period of time, without drying
it thoroughly and brushing off caked dirt. Do not pack stakes or
poles inside your tent. Use a separate storage bag.
t Stakes should be removed by pulling on the stake itself. NEVER
PULL ON THE TENT TO REMOVE STAKES AS THIS COULD RESULT
IN PROPERTY DAMAGE OR PERSONAL INJURY.
t Tent poles should not be left telescoped together during storage.
t Do not leave your tent set-up for weeks at a time. Be aware that
exposure to ultraviolet rays from the sun can seriously damage
material and/or cause it to become discolored.
