Coleman 2000007829 Manual

STITCH LINE
SHELTER SETUP INSTRUCTIONS
Before you begin
• Read all instructions before set up.
• Select a level site clear of rocks, branches, and other hard or
sharp objects, to install your shelter.
WARNING: Keep clear of overhead power lines.
• Do not set up your shelter under trees because of potential
lightning strikes or falling tree limbs in inclement weather.
• Secure with all stakes and guylines provided to prevent property
damage or personal injury.
• For best results in windy conditions, position narrow end of
shelter into the wind.
• Do not drop shelter.
• Do not bounce shelter bag on its end to remove shelter, as these
actions may damage the frame.
• THIS RECREATIONAL PRODUCT REQUIRES A MINIMUM OF TWO
PEOPLE TO ASSEMBLE.
• Under no circumstances should this product be used to cover
automobiles, marine products or similar items.
CAUTION: Avoid pinch points when opening and closing the
shelter frame.
(continued on other side)
Extend the Shelter Frame
Set up the Shelter
• With two persons standing at diagonal corners of the
structure, grab the leg, and pull out to unfold
frame. (Fig. 1)
NOTE: Do not unfold frame completely. This will allow
easier fit for draping shelter top over frame.
• Drape shelter top over frame. (Fig. 2)
• Attach hook and loop fasteners, located on corners of
shelter top, to four corners of frame post. (Fig. 2A)
• Pull up sliding bracket located
on upper portion of leg until
push button snaps into place.
(Fig. 3) This will ensure top of
frame is fully extended.
• Secure shelter top to frame with hook & loop fasteners provided.
(Fig. 4 & 5)
1
2
4
HANDY TIP: To fully engage the
push button, grip the top and
bottom frame members and
squeeze as shown in Fig. 3A. Be
careful to avoid pinch points.
Stake the Shelter
• Secure shelter by driving stakes through the holes in the
base of each frame post. (Fig. 8)
Adjust the Height
• Adjust desired height until push button locks into place,
making sure all four posts are level. (Fig. 6 & 7)
3
Push
Button
Upper
Portion
of Leg
Push
Button
Push Button
2A
Fig. 2
5
MODEL 2000007829
Fig. 1
Fig. 8
Fig. 7
Fig. 6
Fig. 5
Fig. 3A
Fig. 4
Fig. 3
2B
• Secure shelter top to frame by attaching clips to frame
post. (Fig. 2B)

STITCH LINE
This tent meets the flammability requirements of CPAI-84. The
fabric may burn if left in continuous contact with any flame source.
The application of any foreign substance to the tent fabric may
render the flame-resistant properties ineffective.
WARNING: KEEP ALL FLAME AND HEAT SOURCES AWAY FROM
THIS TENT FABRIC.
Things You Should Know:
• Under certain conditions (cold weather, high humidity,
etc.) condensation will form on the inside of your shelter.
Condensation is caused by water vapor from your breath,
perspiration, or any wet clothing inside the shelter. It is NOT
LEAKAGE through the shelter fabric.
• Tree limbs, tree sap, bird droppings, or moisture steadily dripping
off tree limbs can cause damage to the shelter fabric and its
coating resulting in leaks or loss of flame-resistant properties.
• Never store shelter, even for a short period of time, without drying
it thoroughly and brushing off caked dirt. Do not pack stakes
inside your shelter. Use a separate storage bag.
• Stakes should be removed by pulling on the stake itself. NEVER
PULL ON THE SHELTER TO REMOVE STAKES AS THIS COULD
RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY.
• Do not leave your shelter set-up for weeks at a time. Be aware
that exposure to ultraviolet rays from the sun can seriously
damage material and/or cause it to become discolored.
• This product is not intended to be used during heavy rain, wind,
hail, snow or other inclement weather. Excess water build-up
can cause the frame system to be come unstable, and possibly
collapse, causing injury.
Secure the Guylines
• Attach and stake out guylines. (Fig. 9)
5
1. Place the Energy Pack in its carry case.
2. All stakes must be placed in the storage bag to prevent
damage to the fabric items placed in the carry case.
3. Make sure all components are clean and dry before
placing in carry case.
4. Store in a clean, dry area.
8
To Store
• The shelter top, screen, and sun wall (if included) should be
carefully removed during windy conditions to avoid damage to
product or personal injury.
• DO NOT use gas or flame sources under or near this product.
TheColemanCompany,Inc.•3600NorthHydraulic•Wichita,Kansas67219U.S.A.
1-800-835-3278•www.coleman.com
MADE IN CHINA
©2010TheColemanCompany,Inc.Allrightsreserved.
Coleman®, , and are registered trademarks of
The Coleman Company, Inc.
5
Fig. 9 Guyline
4010009477(ECN20014620-02)
6
Install the Shelter Lighting
Energy Pack
• Align tabs on the Energy Pack with the shelter leg, and
attachtheEnergyPacktotheshelterleg.(Fig.10)
• Remove power cord plug from its holder, and plug it into
the Energy Pack. (Fig. 11)
• Rotate the switch on the Energy Pack to adjust the
lighting. (Fig. 12)
Note: Additional details concerning the shelter lighting
system can be found in the instruction sheet packed with
the Energy Pack.
Disassembly
7
• Remove the power cord plug from Energy Pack and detach
Energy Pack from the shelter leg.
• Wrap the power cord around the power cord holder and
secure the plug. (Fig. 11)
• Remove stakes and guylines.
• Lower the frame one post at a time by pressing the push
button locks located on lower portion of posts. (Fig. 13)
• Remove the shelter top from frame and fold for storage.
• Press the push buttons found at upper corners of the
frame. (Fig. 14) Collapse shelter frame and store in
carry case.
Push
Button
Push
Button
Fig. 13 Fig. 14
C
P
X
6
C
O
M
P
A
T
I
B
L
E
Tabs
Energy
Pack Fig. 10
Fig. 10
Power
Cord
Plug
Power
Cord
Holder
Fig. 11
Energy
Pack
Switch
Power
Cord
Fig. 12
