Collomix TINTA 16 User manual

.colorTEC
Translation of the Original Operating Instructions
English
TINTA
Color Dispenser
Make sure to read the operating instructions prior to initial use!
Always follow safety warnings!
Please keep for future reference!
This documentation is not subject to change management!
September – 2017-02

Information
TINTA – Color Dispenser – Operating Instructions Page 2
These operating instructions constitute a part of the technical documentation of the
machine in accordance with the EC Machinery Directive.
These operating instructions correspond to the "Directive 2006/42/EC of the European
Parliament and the Council for the Approximation of the Legal and Administrative
Regulations of Member States for Machinery" (Machinery Directive), Appendix I, item
1.7.4.
These Operating Instructions are provided for the person in charge who must pass them
on to the personnel responsible for connection, use, and maintenance of the machine.
The plant manager must ensure that the information contained in these operating
instructions and in the accompanying documents has been read and understood.
The operating instructions must be kept at a known place that is easy to reach, and they
must be consulted if there is the slightest doubt.
The manufacturer is not liable for injury to personnel, pets or damage to property or to
the machine itself arising from improper/unauthorised use or as a result of disregarding or
ignoring the safety criteria contained in these operating instructions or by altering the
machine or by using unsuitable spare parts.
The copyright for the operating instructions lies solely with
Collomix GmbH
Daimlerstraße 9
85080 Gaimersheim
GERMANY
or its legal successor.
The content of the user information is the intellectual property of Collomix GmbH
Collomix GmbH expressly reserves the right of ownership to and copyright of the
information in the user information.
Reprinting and reproduction, even in part, are permitted only with the written permission
of Collomix GmbH.
Dated: September – 2017

Table of contents
TINTA – Color Dispenser – Operating Instructions Page 3
1Information about the document....................................................................... 6
1.1 Structure of the warnings ................................................................................................................... 6
1.2 Signal words and signal colors............................................................................................................. 6
1.3 Symbols ............................................................................................................................................... 7
1.3.1 Mandatory action symbols.................................................................................................................. 7
1.3.2 Warnings ............................................................................................................................................. 7
1.3.3 Prohibitory signs.................................................................................................................................. 8
2Identification and notices .................................................................................. 9
2.1 Machine description............................................................................................................................ 9
2.2 Manufacturer ...................................................................................................................................... 9
2.3 Intended use ....................................................................................................................................... 9
2.3.1 Service life of the machine .................................................................................................................. 10
2.4 Reasonably foreseeable misuse .......................................................................................................... 10
2.5 General information............................................................................................................................ 11
2.5.1 Liability and Warranty......................................................................................................................... 11
2.5.2 Objectives of the Operating Instructions ............................................................................................ 12
2.5.3 Target Group of the Operating Instructions........................................................................................ 12
3Safety information............................................................................................. 13
3.1 Obligations .......................................................................................................................................... 13
3.1.1 User obligations .................................................................................................................................. 14
3.1.2 Obligations of the personnel............................................................................................................... 14
3.2 Safety devices...................................................................................................................................... 15
3.3 Dangers caused by forms of energy .................................................................................................... 15
3.3.1 Dangers caused by electrical energy................................................................................................... 15
3.3.2 Dangers due to laser radiation............................................................................................................ 15
3.4 Dangers due to operating materials.................................................................................................... 16
3.5 Residualrisk ......................................................................................................................................... 16
3.6 Additional information ........................................................................................................................ 17
4Design and function........................................................................................... 18
4.1 Technical data ..................................................................................................................................... 18
4.2 Complete diagram – overview ............................................................................................................ 19
4.2.1 Tasks of the operating personnel........................................................................................................ 20
4.3 Structure and function of the machine............................................................................................... 20
4.3.1 Components of the machine............................................................................................................... 20
4.3.2 Functional description......................................................................................................................... 20
4.3.2.1 TintONE ............................................................................................................................................... 21
4.3.2.2 LidDetection ........................................................................................................................................ 22
4.3.2.3 CoolNOZ dispensing head ................................................................................................................... 23
4.3.2.4 MoveNOZ ............................................................................................................................................ 24

Table of contents
TINTA – Color Dispenser – Operating Instructions Page 4
4.4 Design and function of the safety devices .......................................................................................... 24
4.5 Components – Electrical system / Controller...................................................................................... 25
4.5.1 Machine lighting.................................................................................................................................. 25
5Transport........................................................................................................... 26
5.1 Warning notices for transport............................................................................................................. 26
5.2 Transport procedure ........................................................................................................................... 26
5.2.1 Unloading the machine ....................................................................................................................... 27
5.2.2 Disposal of transport and warehouse packaging ................................................................................ 28
5.3 Operating conditions........................................................................................................................... 29
6Commissioning .................................................................................................. 30
6.1 Warning notices for commissioning.................................................................................................... 30
6.2 Erecting the machine .......................................................................................................................... 30
6.3 Setting up and aligning the machine................................................................................................... 31
6.3.1 Erecting the machine .......................................................................................................................... 31
6.4 Connecting the machine (energy supplies) ......................................................................................... 32
6.4.1 Switching the machine on ................................................................................................................... 32
6.5 Filling the TintONE modules for the first time/replenishing ............................................................... 33
7Operation.......................................................................................................... 35
7.1 Warning notices for operation ............................................................................................................ 35
7.1.1 Operating the machine ....................................................................................................................... 35
7.2 Control panel....................................................................................................................................... 35
7.2.1 Stop button / repeat button ............................................................................................................... 36
7.2.2 Function of the control panel (optional)............................................................................................. 37
7.2.3 Color .................................................................................................................................................... 38
7.2.4 Refill/Purge.......................................................................................................................................... 38
7.2.5 Statistics .............................................................................................................................................. 39
7.2.6 Diagnostics .......................................................................................................................................... 39
7.2.7 Settings................................................................................................................................................ 40
7.2.8 Users.................................................................................................................................................... 40
7.3 Loading the container ......................................................................................................................... 41
7.4 Faults and error displays ..................................................................................................................... 43
7.4.1 Fault and operating status messages.................................................................................................. 43
7.4.2 Fault elimination ................................................................................................................................. 43
7.4.2.1 Machine-related faults ........................................................................................................................ 43
8Tool change ....................................................................................................... 44
8.1 General information............................................................................................................................ 44
8.2 Tooling/Retooling................................................................................................................................ 45
8.2.1 Adjusting the container shelf .............................................................................................................. 45
8.2.2 Replacing the TintOne......................................................................................................................... 45

Table of contents
TINTA – Color Dispenser – Operating Instructions Page 5
8.3 Technical support................................................................................................................................ 45
9Maintenance and servicing ................................................................................ 46
9.1 Warning notices for maintenance and servicing................................................................................. 46
9.2 General ................................................................................................................................................ 47
9.3 Maintenance instructions ................................................................................................................... 47
9.3.1 Cleaning............................................................................................................................................... 47
9.3.2 Electrical equipment ........................................................................................................................... 48
9.4 Maintenance lists ................................................................................................................................ 48
9.4.1 Maintenance skills of the operating personnel................................................................................... 49
9.5 Information on defective components ............................................................................................... 50
9.5.1 Disassembly......................................................................................................................................... 50
9.5.2 Recycling.............................................................................................................................................. 50
9.5.3 Disposal ............................................................................................................................................... 50
10 Decommissioning .............................................................................................. 51
10.1 Switching the machine off................................................................................................................... 51
10.2 Shutting down the machine (long period) / putting the machine into storage .................................. 51
10.3 Storing the machine ............................................................................................................................ 52
10.4 Disposing of the machine .................................................................................................................... 52
11 Appendix........................................................................................................... 53
11.1 Index of tables..................................................................................................................................... 53
11.2 Index of figures.................................................................................................................................... 53

Identification and notices
TINTA – Color Dispenser – Operating Instructions Page 6
1 Information about the document
1.1 Structure of the warnings
The combination of a signal with an icon classifies the respective warning. The symbol can vary
depending on the type of danger.
THE WARNING IS PLACED UNDER A SIGNAL WORD WHICH INDICATES THE
EXTENT OF THE DANGER.
The first line after the signal word describes the type and source of the potential danger.
The next section describes the consequences of failure to adopt measures to avert the danger.
The last paragraph describes the actions to take in order to avoid the danger.
1.2 Signal words and signal colors
The following signal words are based on DIN EN 82079-1 and ANSI Z 535.4 and are used in this
documentation. The safety colors were taken from the
ISO 3864-1 standard.
Signal word Usage Explanation
DANGER Warning notice indicates a dangerous situation, which if ignored,
results in death or severe injuries.
WARNING Warning notice indicates a dangerous situation, which, if ignored may
result in injuries and damage to property
CAUTION Warning notice indicates a dangerous situation, which, if ignored may
result in minor injuries and damage to property
IMPORTANT Notice indicates ease of operation and cross-references. It
excludes danger of liability damages or risk of injuries.
SAFETY INSTRUCTION Safety instruction Refers to certain safety-related instructions or
procedures.

Identification and notices
TINTA – Color Dispenser – Operating Instructions Page 7
1.3 Symbols
Some of the following special safety symbols in accordance with DIN EN ISO 7010: 2011 are used at the
corresponding passages in the text of these operating instructions and require special attention
depending on the combination of signal word and symbol:
Symbol Usage Explanation
Notice
Important information for
understanding of the device and
for optimised operating
procedures.
Table 1 Icons
1.3.1 Mandatory action symbols
Symbol Explanation Symbol Explanation
Wear safety goggles
Observe and follow the
manual
Use gloves Wear a safety helmet
Table 2 Mandatory action symbols
1.3.2 Warnings
Symbol Explanation Symbol Explanation
General warning sign
Warning - dangerous
electrical voltage
Warning - danger of
slipping
Warning - hot surfaces
Warning - falling loads Warning - lasers
Table 3 Warning

Identification and notices
TINTA – Color Dispenser – Operating Instructions Page 8
1.3.3 Prohibitory signs
Symbol Explanation Symbol Explanation
General prohibition sign Smoking prohibited
Eating and drinking
prohibited
Table 4 Prohibition signs

Identification and notices
TINTA – Color Dispenser – Operating Instructions Page 9
2 Identification and notices
2.1 Machine description
TINTA Color Dispenser
Country of origin: Germany
2.2 Manufacturer
Collomix GmbH
Daimlerstraße 9
85080 Gaimersheim
GERMANY
Email: [e-mail]
Tel.: [phone]
Fax: [phone]
2.3 Intended use
This automated tinting machine is used to dispense dyes from one or more TintOne modules into a
container that is pre-filled with color paste to produce lacquers, paints, dyes etc. in a color that is
selected using the control program linked to the machine.
Any other use of the machine or use beyond its intended purpose is considered to be unintended use
and therefore improper. In this case, the safety and protective mechanisms of the machine may be
compromised.
Collomix GmbH is not liable for damages resulting from such uses.
Intended use also includes the following:
following all the operating instructions
compliance with all warnings
compliance with the maintenance intervals

Identification and notices
TINTA – Color Dispenser – Operating Instructions Page 10
2.3.1 Service life of the machine
The service life of the machine depends on the following factors:
Ambient conditions of use
Intensity of utilisation
Compliance with the maintenance intervals specified by the manufacturer.
2.4 Reasonably foreseeable misuse
Reasonably foreseeable misuse, which could pose a danger to the user, third parties or the machine
applicable to all operating modes, include:
Filling the machine with the incorrect color paste (incorrect color, incorrect type)
Replenishing the color paste without a paper funnel
Filling the machine with the incorrect liquids
Overfilling the TintONE canisters
Disconnecting the equipment from the mains supply causing the nozzles to dry out
Installing the equipment in an overly cold environment causing the color paste to become too
viscous
Using incorrect dispensing parameters resulting in unsatisfactory dispensing results
A container beneath the dispensing head that has been overlooked
Adding components that have shapes deviating from those intended for the machine
Operating the system contrary to the specifications provided in the operating instructions with
respect to warning notices, installation, operation, maintenance and servicing, set-up and faults.
WARNING
Danger of injury due to unauthorised modifications
Unauthorised modifications to the machine and the use of spare parts from external manufacturers
(no original spare parts) may cause dangerous situations to arise.
Do not allow any unauthorised or other modifications to the machine without prior approval of
Collomix GmbH.

Identification and notices
TINTA – Color Dispenser – Operating Instructions Page 11
2.5 General information
2.5.1 Liability and Warranty
The "General Terms and Conditions of Sale and Delivery" of Collomix GmbH shall apply. Your rights in
the event of any essential improvements can be found in our general terms of delivery. You can find
them on our website www.collomix.de. We are happy to send you our general terms of delivery on
request.
Warranty and liability claims in the event of personal injury or property damage are excluded if they
arise from one or more of the following causes:
Improper use of the machine
Improper assembly, commissioning, operation and maintenance of the machine
Operating the machine with defective safety equipment
Disregarding the information in the operating instructions
Unauthorised modifications to the construction near the machine
Deficiencies in doing the maintenance work prescribed
Disasters caused by external influence or force majeure conditions
Read the operating instructions carefully before initial start-up or using the machine. The operating
instructions should familiarize the user with the handling of the machine and instructs the user in the
details regarding the function and maintenance.
The operating instructions must be made accessible to the personnel at all times and must be kept
ready at hand near the machine. The instructions provided in the operating instructions on maintenance
and operational safety must be observed and followed. For further questions that go beyond the scope
of this operating manual, please contact Collomix GmbH at any time.

Identification and notices
TINTA – Color Dispenser – Operating Instructions Page 12
2.5.2 Objectives of the Operating Instructions
These operating instructions serve as an aid and contain all necessary instructions that must be followed
for general safety, transport, installation, operation, set-up, maintenance, storage and disposal.
These operating instructions with all warning notices (as well as all additional documents relating to the
assemblies provided by external suppliers) must be:
followed, read and understood by all persons working on the machine; this is especially true of the
warning notices
freely available to all personnel
consulted in case of slightest doubt (safety)
Objectives:
Preventing accidents
Increasing the service life and reliability of the machine
Reducing the costs of production downtime
2.5.3 Target Group of the Operating Instructions
At different life cycles of the machine, personnel with varied competences comes into contact with the
machine.
Tasks Operating personnel External technical personnel
Transport
X
Commissioning
X
X
Operation
X
X
Cleaning / maintenance
X
X
Repair
X
Decommissioning
X
X
Table 5 Target group
Trained operating personnel:
A person who has been trained by a specialist in the tasks assigned to him, the possible dangers of
improper behaviour and the required safeguards and safety measures
Trained sales personnel at the building supplies store
External qualified personnel (Collomix GmbH)
The external technical personnel is specially trained with the products of the manufacturer and familiar
with each phase of the machine's life cycle. The external technical personnel usually completes phases
like transport and transfer to the operator.

Safety information
TINTA – Color Dispenser – Operating Instructions Page 13
3 Safety information
WARNING
Danger of injury or damage to property
Ignoring the operating instructions and all safety instructions it contains could result in dangerous
situations.
Read the operating instructions carefully before start-up. Meet and observe the required safety
conditions. Observe the general warning notices as well as special warning notices in the other
sections.
The machine has been constructed according to state-of-the-art technology and recognized safety
regulations. To prevent any risk to life and limb of the operator or third parties, or damage to the
machine, the machine must be used only according to its intended purpose and in an evidently safe and
fault-free condition.
Property damage and personal injury resulting from non-compliance with the instructions specified in
the operating instructions are the responsibility of the company operating the machine or the persons
assigned by the same.
3.1 Obligations
WARNING
Danger of injury due to negligence
Despite protective devices, dangers may arise in connection with the machine due to negligent
behaviour/working methods.
Always work with great care and caution on the machine. Disregarding or ignoring warning notices
results in loss of any compensation claims for damages.
The following circumstances could increase the potential hazards of the machine:
Failure of important functions of the machine
Errors in prescribed maintenance and repair methods
Endangering of persons through mechanical influences
Faults that may impair the safety during operation
SAFETY INSTRUCTION If faults are identified that may impair safety while operating the machine,
the machine operation must be interrupted immediately and the faults identified must be eliminated.
Resume operation of the machine only if the faults identified have been eliminated, safe operation of
the machine is possible and the protective and safety devices are once again completely intact.

Safety information
TINTA – Color Dispenser – Operating Instructions Page 14
3.1.1 User obligations
SAFETY INSTRUCTIONS All persons working in the area of the machine have an obligation to
contribute to safety and health protection at the workplace. They must be conversant with the use of
and the operating conditions of the machine.
The machine must be in a safe condition and used safely to ensure safe operation. For this reason, the
company operating the system is obligated to ensure that the following points are adhered to:
Ensure that the machine is only operated by authorised personnel.
Forbid unsafe and/or dangerous work procedures. If necessary, check the actions of personnel.
Ensure that a copy of the complete operating instructions is always kept close to hand near the
machine.
Check the operating instructions regularly for completeness and legibility.
Pay attention to the safety instructions and hazard notices placed near the machine and ensure
that they are kept in a legible or recognisable condition.
WARNING
Danger of injury caused by ignoring the instructions
There are risks posed by unauthorized actions on the machine.
Observe and follow all instructions and warning notices provided. Do not carry out any activities for
which there is no authorization available. Contact the appropriate qualified personnel with any
questions.
3.1.2 Obligations of the personnel
SAFETY INSTRUCTIONS All persons working in the area of the machine have an obligation to
contribute to safety and health protection at the workplace.
WARNING
Danger of injury caused by ignoring the instructions
There are risks posed by unauthorized actions on the machine.
Observe and follow all instructions and warning notices provided. Do not carry out any activities for
which there is no authorization available. Contact the appropriate qualified personnel with any
questions.

Safety information
TINTA – Color Dispenser – Operating Instructions Page 15
3.2 Safety devices
The machine is equipped with various safety devices (e.g. protective enclosure). These devices serve to
protect individuals working on the machine from any danger to life and limb arising from electrical and
mechanical actions and to limit material damage to the machine.
3.3 Dangers caused by forms of energy
3.3.1 Dangers caused by electrical energy
DANGER
Danger to life due to dangerous voltage
There are risks posed by electrical residual energy remaining in lines, equipment and devices after the
machine is switched off.
Only allow qualified electricians to work on the electrical supply system.
Disconnect the machine from the mains supply before working on the electrical components of the
machine. Secure the main switch against being switched on without authorization with a lock. Keep the
key at a safe place. Keep the control cabinet locked at all times. Access is permitted only to authorized
personnel.
Check the electrical equipment of the machine regularly. Inspect all moving cables for damage
regularly in the course of the repair and maintenance work. Replace singed or defective cables. Tighten
loose connections.
SAFETY INSTRUCTION Inform all operating personnel about the hazards posed by electrical
energy.
3.3.2 Dangers due to laser radiation
WARNING
Dangers due to class 2 laser radiation
The accessible laser beams are dangerous to the eye when the duration of exposure to the radiation is
significant (more than 0.25 sec.).
Do not look at the beam itself or the reflected beam. If a laser beam makes contact with your eye,
close your eyes and move your head away from the beam immediately. Making changes to the
direction of the laser is not permitted. Do not aim the beam in the direction of other persons, or areas
where other persons may be present. Do not remove the protective covers of the laser. Maintenance
work should be carried out exclusively by trained and authorized personnel. Comply with the operating
manual of the laser.

Safety information
TINTA – Color Dispenser – Operating Instructions Page 16
3.4 Dangers due to operating materials
The operating personnel must protect themselves against materials that are hazardous to health. With
this in mind, the manufacturer’s safety data sheets relating to the individual color pastes must be made
available at the machine.
WARNING
Notes/instructions for safe handling
Eating, drinking and smoking are prohibited at the machine and when handling equipment. Provide
adequate ventilation at the machine.
Do not inhale fumes. Avoid skin and eye contact.
Protect yourself using personal protective equipment PPE (gloves, respiratory protection).
SAFETY INSTRUCTION It is imperative that the manufacturer's information and safety data sheet /
specification of the utility are followed before it is used.
3.5 Residualrisk
Despite taking all precautions, there may still be residual risks that are not immediately apparent.
You can reduce the existing residual risks by observing and following the warning notices and intended
use of the machine.
DANGER
Danger to life due to dangerous voltage
There are risks posed by electrical residual energy remaining in lines, equipment and devices after the
machine is switched off.
Only allow qualified electricians to work on the electrical supply system.
Disconnect the machine from the mains supply before working on the electrical components of the
machine. Secure the main switch against being switched on without authorization with a lock. Keep the
key at a safe place. Keep the control cabinet locked at all times. Access is permitted only to authorized
personnel.
Check the electrical equipment of the machine regularly. Inspect all moving cables for damage
regularly in the course of the repair and maintenance work. Replace singed or defective cables. Tighten
loose connections.

Safety information
TINTA – Color Dispenser – Operating Instructions Page 17
3.6 Additional information
As a matter of principle, the provisions of the accident prevention regulations of the employer's liability
insurance association are applicable to all forms of work on the machine.
In addition, observe and follow the
applicable and binding accident-prevention regulations
applicable and binding regulations at the place of use
recognized technical regulations for safe and professional working methods
existing environmental protection regulations
other applicable regulations
The employees must receive training concerning the dangers and the suitable protective measures at
regular intervals - at least once a year.
Occupational health and safety requires operating instructions to be prepared by the operating
company.
These instructions for use, in addition to the operating instructions, must be followed in full by the
operating personnel.

Design and function
TINTA – Color Dispenser – Operating Instructions Page 18
4 Design and function
4.1 Technical data
Technical data of the machine
Name:
TINTA Color Dispenser
Mains connection:
100 – 240 V
Tolerated voltage fluctuations:
up to 10 %
Frequency:
50 / 60 Hz
Permissible frequency variations:
up to 1 %
Mass:
TINTA 16: 134 kg
TINTA 24: 142 kg
TINTA 32: 150 kg
Machine dimensions
(excluding the protective / service area / screen):
TINTA 16: 1080 x 805 x 1255 mm
TINTA 24: 1235 x 805 x 1255 mm
TINTA 32: 1220 x 925 x 1255 mm
Width x depth x height
Height of the filling port:
1220 mm
Dispensing flow:
Simultaneous
Pumps:
3 oz piston pumps
Pastes:
Water-based
Canister:
POM
Canister volume:
2.5 l (optional: 5 l)
Cycles:
1 … 32 cycles
Housing:
16 / 24 / 32 canisters
Valves:
Ceramic shim valves
Minimum dispensing volume:
1/768 fl. oz. (0.04 ml)
Dispensing head:
CoolNOZ
Container handling:
MoveNOZ,
Dispensing head is routed to container
Maximum container height:
450 mm
Maximum
container diameter:
380 mm
Height of the filling port:
1220 mm
Electromagnetic compatibility:
In accordance with the EMC guidelines and the
valid EMC standards for use in industrial
applications
Table 6 Technical machine data

Design and function
TINTA – Color Dispenser – Operating Instructions Page 19
4.2 Complete diagram – overview
Figure 1 Complete diagram
1
Screen
6
Container sensor
2
STOP button
7
Container shelf
3
MoveNOZ (height-adjustable dispensing
head unit)
8
Machine base (height-adjustable)
4
Handle for height adjustment
9
Transport castors
5
CoolNOZ (dispensing head) with positioning
laser
10
TintOne (canister unit)
1
2
7
8
1 0
3
4
5
9
6

Design and function
TINTA – Color Dispenser – Operating Instructions Page 20
4.2.1 Tasks of the operating personnel
The following activities must be carried out by the operating personnel during automatic operation in
order to guarantee a smooth, error-free operating process:
Positioning and removing the container
Setting the desired color and selecting the process
Identifying faults and notifying service personnel as needed
4.3 Structure and function of the machine
4.3.1 Components of the machine
The machine consists of the following components:
Welded base frame with four height-adjustable feet
Control panel with stop button
TintONE module (canister unit)
CoolNOZ (dispensing unit)
MoveNOZ (height adjustment for dispensing unit)
4.3.2 Functional description
The operator places a container (e.g. paint pot) on the container shelf. Next, the operator must adjust
the height of the dispensing head unit to suit the height of the container. The dispensing process can be
started as soon as the height sensor has detected the container. The desired composition can be
selected on the control panel. Once the operator has pressed the start button, the color pastes are
dispensed in accordance with the program. The color pastes are dispensed simultaneously because each
color paste or TintOne has its own dispensing nozzle.
Figure 2 All required color pastes are dispensed simultaneously
Once the dispensing process is complete, the operator pulls the dispensing head unit up and then
removes the container.
