LED PAR 64 USER MANUAL
Thank you for choosing the ColorKey DMX LED Par64. This lamp’s ultra bright RGB LED’s can mix
and combine to create more than 16.7 million soft color effects which can be applied in various
professional lighting applications from Stages, Dance Halls, and Clubs, to Houses of Worship.
Operation Instructions
Master/Slave
The Master/Slave mode will allow you to link up as many units as you want in a daisy chain fashion.
In this mode, the first unit in the daisy chain will control the following units.
1) Connect all units in a daisy chain with DMX signal 3pin cables.
2) For master unit in Auto mode: Set all dip switches 1-10 to OFF after power up.
3) For Slave mode: set dip switches 1 & 10 to ON and all others to OFF, then the Slave units will run
after the Master unit simultaneously.
Stand-Alone Mode (Color change --- Color fade)
You can run the fixtures in an automatic stand-alone mode by simply setting all fixtures to run as master
units. In stand-alone mode, it runs from color change to color fade. Set dip switches 1-10 to OFF and it
will run in low speed, to run in medium speed set dip switch 7to ON, for fast speed set dip switches 7 &
8to ON.
Slow: 1-10 to OFF
Medium: 7to ON
Fast: 7 & 8 to ON
Daisy Chain Connection
1) Connect the (male) 3 pin connector side of the DMX cable to the output (female) 3 pin connector of the
first fixture.
2) Connect the end of the cable coming from the first fixture which will have a (female) 3 pin connector to
the input connector of the next fixture consisting of a (male) 3 pin connector. Proceed to connect from
the output as stated above to the input of the following fixture and so on.
Color Selection
You can have any combination of switches 1, 2, & 3 set to ON to obtain static color mixing.
Red: 1 to ON
Green: 2 to ON
Blue: 3 to ON
Sound Activation
For the master unit to be in Sound Activation mode, set dip switch 9 to ON and all others to OFF.

LED Par 64 (10mm) Manual
www.ColorKeyLED.com Copyright 2008 3
Flashing Mode
Once you have selected a static color you can make it flash by using dip switches 4, 5, & 6. Set dip
switch 4 to ON for a slow flash rate. Set dip switches 4 & 5to ON for a medium flash rate and set dip
switches 4, 5, & 6 to ON for a fast flash rate. For example if you wish to obtain a purple wash with a
medium speed flash you would set dip switches 1and 3(red & blue) to ON to obtain purple, and then
dip switches 4 & 5to ON to obtain a medium speed flash. Set all the dip switches to OFF to activate an
internal slow color mixing, change and fade program.
Slow: 4to ON
Medium: 4 & 5to ON
Fast: 4, 5, & 6 to ON
Blackout Mode
Set only dipswitch 10 to ON for blackout.
DMX Control Mode
Operating in a DMX control mode environment gives the user the greatest flexibility when it comes to
customizing or creating a show. In this mode you will be able to control each individual trait of the fixture
and each fixture independently. The LED Par 64 uses 4 channels of control. Enable the DMX control by
setting dipswitch 10 to the ON position. Use dip switches 1- 9to address each fixture accordingly.
DMX Value/Function
Setting the DMX address
The DMX mode enables the use of a universal DMX controller. Each fixture requires a “starting address”
from 1-511. A fixture requiring one or more channels for control begins to read the data on the channel
indicated by the starting address. For example, a fixture that occupies or uses 4 channels of DMX and
was addressed to start on DMX channel 100, would read data from channels: 100 (CH1), 101 (CH2),
102 (CH3), and 103 (CH4). For the next fixture, choose a starting address so that the channels used do
not overlap, the next unit in the chain would then start at 104.
Channel Value Function
1 0-255 Red
0% 100%
2 0-255 Green
0% 100%
3 0-255 Blue
0% 100%
000-000 BLACKOUT
001-189 DIMMER
190-250 FLASH
CH4
251-255 FULL ON

LED Par 64 (10mm) Manual
www.ColorKeyLED.com Copyright 2008 4
DMX Dip Switch Quick Reference Chart

LED Par 64 (10mm) Manual
www.ColorKeyLED.com Copyright 2008 5
Specifications
Specifications
# LED's 183 (60 Red, 60 Green, 63 Blue)
Beam Angle 30°
Colors 16.7 Million
Foot Candles 18.5
Lux 199
LED Life Hours 100,000 Hours
Signal Protocol DMX-512
DMX Channels 4
Programming Modes Auto mode, DMX mode, Master / Slave mode, Sound Activation
mode
Sound Activated Yes
Built in Programs Strobing and Color Fading with Fading Speed Variations
DMX Address Interface Dip Switch
Power Consumption 28 Watts
Power AC110V-250V. 60Hz-50Hz
Amps Can run 25 units on a 20 Amp Circuit
Weight 7 lbs
Dimensions of Unit 29 x 23 x 22cm (11.4 x 9.1 x 8.7 Inches)
Housing Black or Silver
