FLOOR MOUNTED WASH STATIONS
Operating Manual for Four-Person Floor Mounted Wash Stations
Models 58FFL and 58FFL-0.5
1
Columbia does not recommend use with harsh chemicals.
NSF/ANSI Standard 2 - Food Equipment and NSF/ANSI 372 low-lead.

COLUMBIA SPECIFICATIONS
©2019 Columbia Products
FLOOR MOUNTED WASH STATIONS 2
1622 Browning Irvine, CA 92606-4809 Phone: [phone] Toll Free: 800.626.2117 Fax: [phone] www.columbiasinks.com email: [e-mail]
Tools Required
Tape Measure
Adjustable Wrench
Drill Motor and Drill Bits
Pipe Wrench
Level
Safety Glasses
Screw Drivers: 1 Phillips & 1 Standard
Pencil
Socket Wrench
Installation Instructions
Step 1
1. Assemble legs for the 54 and 56 series. For series 58, 510 and 512 the legs are pre-
assembled.
2. Place wash station sink on the leg assembly. Secure legs to bowl with hardware provided.
3. Place Wash Station Sink at the desired location.
4. Mark the floor where the mounting holes are at the base of the legs. See illustration A.
5. Drill holes as required for mounting hardware. Hardware Not Included.
Step 2
1. Install Faucet to the sink using faucet mounting kit provided.
2. Install Strainer assembly to the drain hole.
3. Connect hot and cold water supply lines (not included) to the back of faucets.
Step 3
1. Position wash station sinks to pre-drilled holes and secure sink to the floor.
2. Connect waste line or drain pipe to the strainer assembly. Not included.
3. Connect water supply lines (Hot and Cold) to the water source. Not included.
4. Remove aerator from the spout and flush the water system.
5. Replace aerator to the spout.
6. Check for leaks and tighten connections if necessary.
Step 4
1. Seal gap between bowl and leg assembly as shown in illustration B.
2. When mounting against wall, it is recommended sealing the top of the backsplash to wall as
shown on illustration C.
Trouble Shooting Guide
Problem Possible Cause To Diagnose Remedy
Water drips
from the spout
or from under
the lever.
1. Seat washer
is worn
2. Seat is worn
3. O-rings are
worn
Shut cold water source
off. See if water still leaks
from the spout. If leaks
continues repair hot side
if not repair cold side.
Recommend installing
hot or cold faucet repair
kit.
Parts List
(1) Floor mount wash station
(1) Leg assembly set
(6) Washers and nuts for connection sink to leg assembly set
(4) 8” on center faucet
(4) Faucet mounting kit
(2) Strainer assembly with basket
WARNING: This product can expose you to chemicals including Chromium (hexavalent compounds),
Lead, and Phthalates (DEHP) which are known to the State of California to cause cancer and birth defects
or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
NOTE: Lead content originates from Brass components in valves and faucets and is certied under
NSF/ANSI 372 as containing less than 0.25% lead in wetted surfaces.
Notice for California Consumers
Illustration A
Illustration B
Illustration C

COLUMBIA SPECIFICATIONS
©2019 Columbia Products
FLOOR MOUNTED WASH STATIONS 3
1622 Browning Irvine, CA 92606-4809 Phone: [phone] Toll Free: 800.626.2117 Fax: [phone] www.columbiasinks.com email: [e-mail]
1.5” (38mm)
58 Floor
10.25”
(267 mm) 10.25” (267 mm)
80” (1524mm)
20” (508mm) 20” (508mm)
77” (1956mm)
20”
(508mm)
2” drain hole
16.5”
(407mm)
10”
(254mm)
8” (203mm)
1.5” (38mm)
2” (51mm)
1.5” (38mm)
2” drain holes,(1.5” strainer)
.875” (22mm)
dia. holes (8)
Hole Configurations
Front Side
Top
7”
(178mm)
7”
(178mm)
8”
(203mm)
8”
(203mm)
8”
(203mm)
8”
(203mm)
10”
(254mm)
10”
(254mm)
14”
(356mm)
27” (686mm)
35” (889mm)
floor to rim
height
20” (508mm)
2” (51mm)
7.5” (191mm)
45º
2.875” (73.02mm)
.75” (20mm)
6.75” (171mm)
.5” R
(12.7mm)
.5” R
(12.7mm)
36.9375” (938.2125mm) 36.9375” (938.2125mm)
Floor Mounting Detail
.5” dia.
Floor
Mounting
Holes
10.5” on
Center
1.5” Leg
Thickness
.75” From
Edge of Leg
to First Hole
Back Splash
Supply Line Detail
1/2” Male NPT
Hot
from Wall
Cold
from Wall

COLUMBIA SPECIFICATIONS
©2019 Columbia Products
FLOOR MOUNTED WASH STATIONS 4
1622 Browning Irvine, CA 92606-4809 Phone: [phone] Toll Free: 800.626.2117 Fax: [phone] www.columbiasinks.com email: [e-mail]
Leg Assembly
x 12
