Colzer 1556 User manual

MODEL:Colzer1556
AIR PURIFIER
Brand: colzer
Email address: colzer[email protected]
Instruction Manual
READ AND SAVE THESE INSTRUCTIONS

Important Safety Information
Product Parts
Product Features
Operation Instructions
Display Status
Replacement of Filters
Replacement of Sensor
Technical Specification
Common Problems and Solutions
Contents
Display Symbols and Meanings
Operation of buttons
Cleaning and Maintenance
1
2
3
4
6
7
7
8
9
10
11
12
Warranty Description 13
1
Important Safety Information
Please follow the safety precautions and read these instructions carefully before using it
for the first time.
Do not insert fingers or any objects into the air inlet
or air outlet.Otherwise, internal parts may be touched
and cause electric shock or damage.
Prohibition
Enforce!
Enforce! Enforce!
Enforce!
Enforce!
Enforce!
Enforce!
Enforce!
Enforce!
Enforce!
Caution
Caution Caution
CautionCaution
Caution
Enforce! Enforce!
Enforce! Enforce!
Enforce! Enforce!
Before connecting the appliance to the mains supply
please check the plug, power cord, and the product
itself.Do not use bundled wires when using this unit.
Damaged wires may cause electric shock and short
circuit or a fire accident. Prohibit cutting, refitting,
excessively twisting, twisting, screwing and wiring
wires, or installing on electrical outlets put heavy things.
Do not modify or repair the product and accessories
on your own.If there are fault in the product, disconnect
the power plug and contact customer service for repair.
This appliance is not a substitute for proper ventilation
regular vacuum cleaning or use of an ectractor hood or
fan while cooking.
Do not use this appliance when you have used indoor
smoke-type insect repellents or in places with oily
residues, burning incense or chemical fumes.
Always unplug the appliance before you clean it.
Otherwise, the air purifier may suddenly operate,
resulting in electric shock and overheating, and even
cause a fire accident.
When connecting the appliance to the mains supply,
make sure to use dry hands to hold the end of the plug.
Otherwise, electric shock may occur.
Periodically remove dust from the power plug.If dust
accumulates on the power plug, its moisture may
damage the insulation of the plug, resulting in fire
accident. Unplug the power plug and wipe it with a dry
cloth. Do not use a damp cloth!If the appliance is not
used for a Long time, it should be unplugged....
Before the air purifier is started
Please plug the plug fully into a power outlet. Failure to
fully insert the plug into the socket may result in electric
shock and overheating can even cause a fire accident.
If this air purifier causes interference to radio or television
reception,try to correct the interference by one or more
of the following measures:Reoient or relocate the receiving
antenna.Increase the distance between the unit and
radio/TV receiver. Connect the euipments into different
outlet.
For the best result, leave at least 35cm free space each
side of the appliance.
Do not use in high tempreture or humid place such as
bathrooms. Otherwise, electric leakage, electric shock,
short circuit, or fire may occur.
Do not use near flammable gases and material such as
insecticides, fregrances, and lit cigarettes, fire may occur.
When connecting the appliance to the mains supply, make
sure to use dry hands to hold the end of the plug. Do not
pull the power cord to cut off the power supply. Otherwise
electric shock, short circuit, or fire may occur.
If the air purifier is used with a heater, the room must be
ventilated. Otherwise carbon monoxide poisoning may
occur. The appliance does not remove carbon monoxide
(CO).
The warranty will be invalid the product is not used properly. Our company will not be responsible for damages caused by improper use.
Always lift or move the appliance by the handgrips at two
sides of appiance.
Unattended children and disabled people are prohibited to
use the air purifier alone. Children should not play the
steam oven as a toy.
Check if the voltage indicated on the back of the
product matches the local voltage.Use of universal
sockets or devices that exceed the specified values
may cause overheating and fire accidents.
Do not use corrosive cleansers, volatile fluids and/or
detergents when cleaning the product. Otherwise, the
air purifier may be damaged or even cause a short
circuit, resulting in an electric shock or fire accident.
Do not get wet! Failure to do so may result in electric
shock and fire due to a short circuit.
This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended
to fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact
a qualified electrician. Do not attempt to defeat this safety feature.

3
Product Features
[Note] Pre-filter,High-efficiency activated carbon and high-efficiency HEPA are incorporated in the same filter.
Integrating multiple functions
High-efficiency Purification of PM 2.5, Smog, Pollen and Other Particulate
Pollutants.
Removal of HCHO、Toluene、Dimethylbenzene、C6H6, VOC, etc.
5 - Gear Wind Speed Design
Timer Setting
Replacement of Filter Remind
Availability of Multiple Operation Modes, e.g. Manual, Auto and Sleep Mode
Sensor Detection of Indoor Temperature and Humidity
Childproof Lock Function
Real-time Display of PM2.5 Value
Efficiently filter out the particles as small as 0.01microns, e.g. PM2.5, smog, pollen, acarid
and other pollutants.
Block the hairs, fibers, big particulate matters, scurf, etc. It can be washed regularly.
Pre-filter
Pre-filter Modified activated
carbon
High Efficiency Particulate Air Filter
Unique 3 Purification Technologies
HEPA layer
①Filter Cover
②Composite filter (Carbon filter+HEPA filter)
③ Main engine
Structures and Names of Product Parts
1 set
Packing List
Composite filter 2 pieces (assembled in the appliance)
Power line 1 piece (in accessories box)
Instruction Manual 1 copy (in accessories box)
2
Product Parts
In case of discrepancy between product picture and real product, the real product will prevail.
Colzer1556
Item Quantity
Improved Activated
Carbon
High-quality modified activated carbon and catalyst are adopted, and they are modified
with special proprietary technology, and can efficiently purify methanol, benzene series,
VOC and other odorous pollutants.
1
2
3
1
2

5
Operation Instructions
Start
① Power on the appliance, and there will
have a “tinkle” sound.
② Press the power switch button to start
up the appliance.
③ The screen will light up and the appliance
start running.
⑤ Install the filters. ⑥ Install the filter covers.
4
Operation Instructions
Installation of Filters
All filters have been installed in this air purifier.
Check filters are installed properly.
Check filter handle is toward you.
③ Take out the new filters with plastic film
from the appliance.
④ Remove all packaging films on the filters.
① Place your fingers on the hand clasp position
of filter cover, and pull it outwards gently
② Move upward to remove the filter cover.
Operation Instructions
Precautions
for use
PM2.5

6
Display Status
Display Status
PM2.5 Value Status Wind Speed Status
Timed Start-up Status Timed Shutdown Status
Sleep StatusMinutes Shown When the
Remaining Time is Less
Than 1hour
7
Display Symbols and Meanings
Symbol Symbol Name
Auto mode
Sleep mode
Child lock
Timer
Meaning
Symbol lights on - childproof lock mode, and all buttons
unable to operate.
Symbol lights on - timer function is enabled. Symbol lights
off - timer function is off .
Display Symbols and Meanings
Symbol Meaning
When the machine is in standby state, touch the power switch button and the appliance
will turn on, and when it is in working state, touch such button and it will enter standby
state.
Name
Power
Child lock
Auto mode
Sleep mode
When the appliance is in working state, touch the auto mode button, and the working
mode will switch between auto and manual mode; when the appliance is in auto mode,
the wind speed will be automatically adjusted among Gear 1 “0-12”, Gear 2 “13-35”,
Gear 3 “36-55”, and Gear 4 “>55”.
Filter replacement
AUTO
If such symbol is lit on, it means auto mode is enabled, and
the wind speed will select corresponding gear automatically
according to the environmental pollution situation. If such
symbol is lit off, it means manual mode is enabled, and the
wind speed gear will be selected by user.
Symbol lights on - sleep mode, the screen all lights off, but
sleep symbol. And 10sec later, all lights off.
When the appliance is in working state, touch sleep mode button and the appliance will
enter sleep mode, and except the sleep mode icon and sleep indicator lamp, all indicator
lamps, icon signs, and numbers will be lit off. The fan will be running at Gear 1. 10sec
later, the sleep mode icon and sleep indicator lamp will be lit off. When the appliance
is in sleep mode, touch any function button to exit the sleep mode (except the button
of power switch.)
When the machine is in working state, long press child lock key (for more than 3sec)
and the machine will enter the child lock state, the child lock icon and child lock indicator
lamp will be lit on, and the functions of all operation keys will be invalid. When the
machine is in child lock state, long press child lock key (for more than 3sec) to remove
the child lock state, the child lock icon and child lock indicator lamp will be lit off, and
the functions of all operation keys will be recovered.
Usage period grid lefts one and flashes, please replace new filters and press and hold
the filter replacement button for more than 3s to reset the usage period of filter.
Usage period grids refilled.When the usage period off filter is more than 10%, it cannot
be reset.Forced to reset - If reset is required, press “Auto” and “Sleep” for more than 5
in standby state,there is “tinkle” sound, and LED flashes for six times, it is resettled.
PM2.5
Filter Life Filter Life
Symbol will reduce one grid Every time the usage period of
filter is reduced for 500 hours, and when the remaining
usage period of filter is one, such symbol will flash to remind
user to replace with a new filter.
Operation of buttons
Temperature
When the temperature over 98℉, or under 1℉,it would staying
at 99℉ or 0℉.The unit indicate the temperature from 0℉ to 99
0℉ only.

Replacement of Filters
Replacement of Filter
① Put your hand on the hand clasp position
of filter mesh cover, and pull it outwards
gently.
② Move upward to remove the filter mesh cover.
④ Remove all packaging films on filter meshes.③ Take out the new filter meshes with plastic
film in the machine.Take out the new filter
meshes with plastic film in the machine.
⑤ Assemble the new filter meshes. ⑤ Assemble the filter mesh cover and reset the
service life of filter mesh (details can be seen
on Page 10 for operation of filter mesh service
life reset key).
9
Cleaning and Maintenance
Symbol MeaningName
Timer
ECO
Speed
Cleaning and Maintenance
Standby status, press “Timer” button to set start-up time. Operating status, press
“Timer” button to set shutdown time. If the timer set as “0”, the timer function is
canceled.
Standby status, press “Speed” Button once, the wind speed gear plus +1 gear. Gear 1~5
is a cycle. When the wind speed is settled, and displayed for 3s,display switches to PM2.5
display status.In Auto mode, press the “Speed” button to switch to manual mode.
The power plug must be unplugged before maintenance of the machine.
Note: Do not scratch the appliance shell with a hard object; Please read
carefully and follow the Instruction Manual to clean the appliance
parts.
1. Cleaning of appliance body
2. Cleaning and replacement of filter
Suggestions: Clean the filter at an interval of 1 month; if the operating
environment is poor, increase the cleaning frequency.
1) Wipe off the stain with soft cloth.
2) The stubborn stain that cannot be wiped off easily can be wiped off with soft cloth dipped with an
appropriate amount of mild detergent.
1) The user will be reminded of replacement of filter by built-in program; however, the service cycle of
filter may be different according to the pollution degree of actual application environment, and the filter
can be replaced in time according to the volume of sound and odor given off by the appliance.
2) When there is dust on the surface of composite filter, remove it with dust collector, so as to extend
the usage period of filter. (It is advised to clean the filter at an interval of 1 month)
Composite
Filter
Replacement Period Condition
The filter shall be replaced at an
interval of about 6 months.
Absorb the emission amount of 3
cigarettes every day
According to the application place and use method (e.g. the family where there are many cigarette
smokers), the replacement period of filter may be shortened; in a word, please replace the filter
when the filtration effect is poor.
The used filter shall be disposed of as non-combustible refuse.
8
When the machine is in working mode, press Energy saving button, the machine will
enter the energy saving mode, and the display will be turn off. When the machine is
in energy saving mode, press the button, exit energy saving mode, and the display
will be light on.

10
Replacement of Sensor
① Pry up the sensor cover with a straight
screwdriver.
② Take down the sensor cover.
③ Pull the metal handle to pull out the sensor
module.
④ Pull out the connecting terminal from the old
sensor module and replace it with a new sensor
module.
Replacement of Sensor (sensor should be replaced by professionals)
11
⑤ Put back the sensor module into the machine
cavity, and cover it.
Technical Specification
Model Colzer1556
120V~
45W
280CFM
280CFM
280CFM
N.W. 8.5kg
G.W. 10.2kg
Product Size 290x290x565mm
Product Specification Parameters
PM2.5 value Air Quality Wind Speed
Gear
Symbol Colour
0-12
13-35
36-55
>55
Excellent
Good
Mild pollution
Heavy pollution
Green
Blue
Yellow
Red
1
2
3
4
Real-time Display of Air Quality Situation
60Hz
Rated Voltage
Rated Frequency
Rated Power
CADR(Smoke)
CADR(Dust)
CADR(Pollen)
Replacement of Sensor
① Pry up the sensor cover with a straight
screwdriver.
② Take down the sensor cover.
③ Pull the metal handle to pull out the sensor
module.
④ Pull out the connecting terminal from the old
sensor module and replace it with a new sensor
module.
Replacement of Sensor (sensor should be replaced by professionals)
⑤ Put back the sensor module into the machine
cavity, and cover it.

Warranty Description
1. This product has passed strict quality inspection.
2. In case of performance and function fault under the condition of normal use within
warranty period of the product, our company will be responsible for repairing it for free
and for replacing it if the machine cannot be repaired. In the event of failure for the fo
llowing reasons, our company will provide paid repair service:
1) Poor performance and machine fault which occurs after the warranty period expires.
2) Machine fault caused by consumer intentionally or due to negligence.
3) Fault that occurs when the machine is repaired in the sales service center or agent not
designated by our company.
4) Fault that is caused by power supply nonconformity or poor quality of power socket
(irrelevant to warranty period).
5) Product fault or defect caused by natural disaster.
Warranty Period and Warranty Period of Parts
Colzer1556
Product Warranty period Warranty period of parts
One year
(Only for home use) One year
Common Problems and Solutions
Problem Possible Causes Remedial Action
Product work
abnormally
Fresh air cannot be
delivered from air
outlet smoothly.
Poor odor removal effect
The appliance generates
abnormal sound during
running
The above table lists the common problems with this product. If you cannot find answer, please contact our after-sales service centre.
1. There is problem with
connection.
2. The filter cover is not placed
properly.
1. The plastic package of
new filter is not removed.
2. The air outlet of purified
is blocked by foreign matter.
1.Please check whether the plug is inserted
into the socket, and “On/Off” button status.
2. Re-install the filter.
1. The ambient air quality of
room is very poor.
2. The high-efficiency activated
carbon filter is in failure due
to environmental factor.
3. The room exceeds the effective
area of this product.
1. The air inlet or air outlet is blocked
by foreign matter.
2. Foreign matter falls into the air tube of
appliance.
1.Unpackage the filter plastic package.
2. Clear away the foreign matter.
1. Open the window to improve air ventilation.
2. Please replace the high-efficiency activated
carbon filter mesh.
1. Please clear the blocking object.
2. Clear the fallen foreign matter.
12 13
PM2.5 values cannot reduce
and, stay in a high values.
1. The sensor cover is very duty and
stayed a lot of dust.
2. The unit operated in a dusty
environment.
1. Clean the sensor cover.
2. Adjust the air purifier operating speed to
high speed.
