Colzer KJ800 User manual
Model No.: KJ800
AIR PURIFIER
User Manual
Thank you for using the machine.
Please read this instruction carefully and keep it for future reference.
Please refer to the actual product, the image in the instruction is for reference only.
Registe Warranty Service: colzersmart.com/vip
PM2.5
This product should only be used in accordance with the specifications outlined in this manual.
Usage other than what has been specified here may result in serious injury. While using electronic
appliances, basic precautions should always be followed to reduce the risk of fire, electric shock
and body injury including the following:
Before Use
● WARNING: To Reduce The Risk Of Fire or Electric Shock, Do Not Use This Fan With Any Solid-State
Speed Control Device
● Please connect the product power supply with the adapter corresponding to the voltage.
● To avoid any electric shocks or fair disasters caused by circuit,please clench the plug, do not pull the
power cord.
● To avoid any damage of power cord, electric shocks or fire disasters, please do not pull, bend, warp,
destroy of the power cord intentionally.
● Please do not use the device if the power cord/plug/socket has been damaged, and ask the
manufacturer or repairer to replace it.
● To avoid any electric shocks or fire disasters caused by damage of power cord, please do not put the
weights on power cord.
● Please do not touch the power plug with wet hands.
In Use
● Please remove the plastic layer of the filter, also do not use the device without filters.
● Never drop or insert any object into any openings.
● Please do not clog up air inlet or outlet.
● Please do not close to hot objects (like stoves or any place have fire gases) .
● Please pull the plug immediately if any malfunction happen like smoking, smelling, etc.
● To ensure the natural flow by air and efficiency of purification, please remain enough space of air
purifier from the surrounding.
Restrictions On Use
● Please do not use the device in the place which have fire and flammable chemicals.
● To avoid any electric shock, fire or any other damages, please do not use the device in any place
which with propane, gas, natural gas, or any other flammable.
● Please do not use the device when you use bug spray.
● To avoid any electric shock, fire disaster or any other damages, please do not use the device in any
dump, unstable places or high temperature, wet places, such as bathroom, etc.
READ AND SAVE THE INSTRUCTION
IMPORTANT SAFETY NOTES
Notice of Cleaning
● Please do not clean and reuse the composite filter; please do not clean the device with corrosive
chemical cleanser.
● To avoid any damage or malfunction of sensors, please clean the device with soft cloth.
● To avoid any damage, electric shock or fire, please do not clean the device with ethyl alcohol or
organic solvent.
● To avoid any electric shock or fire, please power off and clean the foreign matters of plug when clean
the device or not use the device.
Storage
● Please keep the device stored in dry places.
● Please keep the device away from flammable and combustible places.
● Please cover the protection bag.
Tips
● Not suitable for disabled, perceptual disturbance, dysgnosia users, or children self-operated.
● Please do not set, lean on or scream up to the device to avoid any injury.
● Please pull off the plug when move the device.
● If the supply cord or any machine parts damaged, it must be replace by the manufacturer, its service
agent or similarly qualified person in order to avoid a hazard.
● Please do not use the device and contact the supplier to replace the filter if the device genera tor
peculiar smell when running on.
● The cord, wires and/or cables supplied with this product contain chemicals, including lead or lead
compounds, know to the state of California to cause cancer and birth defects or other reproductive
harm. Wash hands after using. (California code of regulation Proposition 65 )
Common Problems
Technical Specifications
Product Parts
Catalog
5
3-4
2
1
6
7
User Instructions
Operating Instructions
Cleaning and Maintenance
Product Parts
Product Panel Description
Purification Principle
PM2.5
PM2.5
Sensor
Power Line
Port
Casters
Left Handle
Left Clasp
Control Area Top Cover
Front Shell
Display Area
Including status indicator
and numerical display
Right Handle
Right Clasp
Right Air Inlet
Air Outlet
User Instructions
Filter Replacement
Shut down and power off the main unit. (Figure 1)
Open the door cover, catch the button position of the door cover, and pull
it out. (Figure 2)
Remove the filter in turn and wrap the waste filter with a garbage bag to
prevent the pollutants on the filter from falling into the room. (Figure 3)
Grab the door cover buckle, align the bottom of the door cover with the
groove at the bottom of the main unit, then close the door cover and plug
in the power to run. (Figure 4)
Please reset the filter reminder after the filter is replaced. (For details,
please refer to the detailed description on page 5.)
Figure 1 Figure 2 Figure 3 Figure 4
Initial Effect Filter Composite Filter
Note:
a. Dispose of the used filter as non-burnable waste.
b. The primary filter can be used repeatedly. Please clean it and dry it.
Note:
1. Please read the filter replacement operation in detail to ensure the purification
effect of the air purifier.
2. Before cleaning the air purifier system, unplug the power cord and cut off the
power to the air purifier system.
3. Keep the inside of the air purifier dry to prevent damage to the circuit.
Operating Instructions
“ON/OFF” Button
Connect the power to enter the standby configuration, the power indicator lights up.
Press “ON/OFF” button to turn on/off the device.
“AUTO” Button
Press “AUTO” button, on/off the auto mode.
When under auto mode, the device will be adjustment the fan speed (1-4speeds)
automatically according to the air quality.
“SPEED” Button
Press “SPEED” button to adjust the fan speed.
a.The device is start running by auto mode.
b.Press “SPEED” button 1 time to off the auto mode when under auto mode.
“SLEEP” Button
Press “SLEEP” button on/off the sleep mode.
a.Press any button to turn off the sleep mode when under sleep mode.
When sleep mode, only “SLEEP” button light, other buttons are off light.
“TIMER” Button
Press “TIMER” button to set the timer on/off the device, cyclic setting as
0-12 hours.
“CHILD LOCK” Button
Press “CHILD LOCK” button 3s to on/off the child lock mode.
a.When under child lock mode, other buttons are not working.
Operating Instructions
Operating Instructions
Dumping and Opening Safety Protection
a.The device will stop working automatically for safety protection when open the right &
left door or slop over 30 degree.
b.The device will re-work normally when close the right&left door or turn back to horizontal
position.
“WIFI” Button
+
+
Please download "Smart Life" APP and follow the instructions to control
COLZER KJ800 Air Purifier.
“SLEEP”+”TIMER”=”LIGHT” Button
When under auto mode, press “SLEEP” and “TIMER” button 3s, on/off the
light mode.
a.When turn on the light mode, after 30s, the device will only adjust the mode
between sleep or auto mode automatically according to the current ambient
light, when light is brightness, turn on auto mode, when darkness, turn on
sleep mode.
b.The device is starting running as light function is off.
c.Under light mode, press “SLEEP”+ “TIMER” button to turn off the light mode,
or reboot the device to off the light mode.
“SPEED”+”AUTO”= “FILTER RESET” Button
When the filter life is out, the “ON/OFF” button will shining and with “di di di”
sound to reminder users to replace the new filter.
a.When filter life is out of time, press “SPEED”+ “AUTO” button 3s to reset the
filter life, the “ON/OFF” button will stop shining and sound after reset the
filter life.
b.When filter life is not out of time, press “SPEED”+ “AUTO” button 10s to
force to reset the filter life.
c.The device filter life is setting as 3000 hours, record by each hour.
Cleaning & Maintenance
Note: Do not scratch the machine casing with hard objects during maintenance.
When removing the front cover, please follow the instructions and do not
damage the machine parts.
Please unplug the machine if not being used.
1. Clean the body
1) Use a soft cloth to remove the stain.
2) Stubborn stains that cannot be easily erased can be wiped with a moderate amount of
neutral detergent on a soft
2. Cleaning and replacement of the filter
1) The filter replacement is reminded by the built-in program. However, due to the
different degree of pollution in the actual application environment, the use cycle of the
filter will be different, and it can be replaced in time according to the size and smell of
the sound generated by the machine.
2) When the surface of the composite filter is dusty, use a vacuum cleaner to clean the
surface dust to extend the filter's life expectancy. (It is recommended to clean every
1 month)
Depending on the place of use and the method of use (for example, households with
a large number of smokers), the cycle of filter replacement may be shortened. If the
effect is not good, please replace it in time.
Composite Filter
Replace time
Replace it approximately
6 to 12 months
Condition
Absorption of 6 cigarettes
per day
Please use the used filter as non-burnable waste.
Common Problem
Fault phenomenon Possible causes and solutions
The machine does
not start
1.The power plug is not plugged in; replug the power plug.
2.Check if the front cover is in place.
1. The bag of the filter is not removed; remove the bag and
reinstall the filter.
2. There is a foreign object blocking the air inlet or outlet;
remove the blockage.
3. The filter is dirty; clean or replace the filter.
The outlet is very small
1. The machine is not equipped with a filter; install a filter.
2. The window or door of the room is often opened. In a
room with slow air flow, it takes longer to purify the
indoor air due to the entry of external dirty air.
3. The machine is placed in a small place or there are
obstacles nearby, which affects the purification effect.
4. the filter is dirty, affecting the purification effect: clean
or replace the filter.
Dust removal and purification
effect is not significant, air
quality is not significantly
improved
1. In the room, due to the smoking or barbecue of many
people, a large amount of odor is generated; it is
recommended to ventilate the room.
2. the filter has been seriously dirty; replace the new filter
There is smell in the air outlet
Note: If you can't solve the problem after the above inspection, please contact the service
network or technical service center provided by our customer service center. Do not
disassemble and repair it yourself to avoid danger and damage to the machine.
Common Problem
Technical Specifications
Product name
Color Air Quality Digital
Green Excellence 0-50
Blue Good 51-100
Rated voltage
Rated input power
CADR (particles) 470 CFM
Unit size
Net weight 27.33 lb Gross weight 32.18 lb
17*17*30.9 inch
Air purifier
100~120V
80W
Model name
Rated frequency
Noise
KJ800
60Hz
≤66dB(A)
The Main Technical Parameters
Yellow Normal 101-150
Red Bad 151+
Speed Noise Power
Sleep 39.62 dB（A） 5W
13W
Speed 1 43.76 dB（A）
Speed 2 49.29 dB（A） 18W
Speed 3 55.70 dB（A） 26W
Speed 4 60.75 dB（A） 39W
Speed 5 64.64 dB（A） 62W
Air Quality Indicator
Speed Noise & Power
Item name Quantity Item name Quantity
Air purifier 1 user manual 1
Packing List
