INSTRUCTION MANUAL
Air Purifier
Model：AP009
Please read the instruction booklet carefully before using
and save it for future reference.
Customer Service Email: [e-mail]

With proper care and use, this air purifier will give you fresh,
clean air for many years.
NOTE: Before reading these instructions, please view the
corresponding illustrations.
The power adapter and the filter are in a plastic bag.
Remember to remove the plastic bag before using the air
purifier.
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS.
01

Safety Precaution
Carefully read and retain all instructions before using the air purifier.
• Check if the voltage indicated on the appliance corresponds to the local
main voltage before you connect the appliance.
• To avoid fire hazard, never put the cord under rugs, or near any heat
source.
• Carefully discard any plastic wrapping that was used for the packaging.
• Do not use the air purifier outside.
• Do not place the unit near any heat source or in direct sunlight.
• Always unplug the air purifier before removing the grill, changing the
filters, cleaning the air purifier or whenever it is not in use.
• Do not use in or around water or any other liquids. Do not attempt to
wash the unit under running water.
• Use appliance only for intended household use as described in this
manual.
• Ensure that all air openings are not restricted or covered in any way.
• Do not place anything on top of the unit.
• Never insert any object into any openings.
• Do not use the air purifier if any part is missing or damaged in any way.
• If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a hazard.
• Should the air purifier stop working, first check the fuse/circuit breaker at
the distribution board is operating, before contacting the place of purchase.
0102

The appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children unless they are older
than 8 and supervised.
• Keep the appliance and its cord out of reach of children less than 8 years.
CAUTION: To prevent risk of electric shock, remove cord plug from outlet
before opening appliance. To prevent risk of fire, inspect and clean
equipment regularly as noted in this manual.
WARNING: This unit is not a toy!
This appliance should only work on a counter, table or similar position.
03

Introduction
The air purifier has a three-stage filter system that removes
pollen from ragweed, grass pollen, tree pollen, household
dust, dust mite debris, pet dander, smoke and odors, and
more.
Air Outlet
Control Button
Air Quality
Indicator Light
Sensor
Air Inlet
04

Specification
Product Name
Model NO.
Input Voltage
Output
Rated Power
Noise Level
HEPA level
Size
Filter Replacement Indicator
Air Purifier
AP009
100-240V
12V/1A
12W
＜45dB
H13
230*250*320mm
Yes
Pre-operating instructions
1. Carefully unpack your air purifier.
2. Select a firm level place where there are no obstructions to the air inlet
or filtered air outlet.
3. Open the bottom cover and take out the HEPA.
4. Detach the HEPA filter and remove the PE bag carefully.
5. Replace the HEPA filter back in position, make sure that the primarily
efficient filter shall be pointed outwards.
6. Screw back the bottom cover in position.
Important:
• Remove all PE bags from filters before use.
• Do not point air outlet towards wall.
05

Operation guide
1H
2H 4H
8H Sleep Mode 23
4
TIMER BUTTON SPEED BUTTON
ON/OFF BUTTON
AIR QUALITY INDICATOR LIGHT
Power Button
Press the "Power" button to turn on/off the unit.
Fans Speed
Press Speed button to set fan speed at S 2 3 4.
S = SLEEP mode.In Sleep mode,the unit will turn to low,and unit
will not make a sound.
Timer
Press Timer button to set timer at 1 2 4 8 hours,the LEDs will be
on accordingly.
Air Quality Light
The air purifier has sensor and LED color to indicate air quailty
level.The product will automatically detect the indoor air quailty.
06

To operate your air purifier:
1.Plug into a 120V electrical outlet, One beep “Di” can be heard.
2.Press down the ON/OFF switch 2 seconds, one beep “Di” can be heard
and its corresponding LED turns on, the air purifier starts to run under the
sleep mode. If you want to select other settings, you can press “ Speed
control button” to select your desired speed setting (High setting and Sleep
mode). After select, its corresponding LED will turn on.
Note: It is suggested to make the air purifier run under the sleep mode if it
is needed to be run continuously. For quieter operation (such as in a
bedroom), keep the sleep mode. When in an environment with polluted air,
it is suggested to select High setting to quicken the air circulation.
3.You can activate the timer after turn on the air purifier and select your
required speed setting by following the operation as below: press down
“Timer” button on the control panel, one beep “Di” can be heard. There are
4 settings including 1H, 2H, 4H and 8H. After select your required timing,
its corresponding LED turns on. When the timer expires, the air purifier will
power off automatically and the LED will extinguish.
4.The air quality indicator light will be in green color. The yellow lights will
be shown when the environment air quality is poor. The red lights will be
shown when the environment air quality is very poor. Once the yellow or
red lights turn on it will auto change to the highest speed. Once the
environment air quality is improved then the speed will be auto returned to
the previous speed .
07

Indicator light of air quality LED color
Green
Yellow
Red
Good
Average
Poor
Air quality
5.If the timer working indicator lights all turn on and you will hear three beeps
“Di-Di-Di” every 3 mins, that means the HEPA needs to be replaced.
Please open the bottom cover and replace with a new HEPA. Press timer
and on/off switch together for 2 seconds and one beep “Di” can be heard
and timer working indicator lights turn off. The HEPA is reset successfully.
6.If you want to make the air purifier stop running, you just need to press
“ Power switch” 2 seconds. The air purifier will stop working after one beep
“Di” sound.
08

1. Turn off,open the bottom cover and
remove the filter.
2. Remove the plastic bag of the filter.
3. Replace with a new filter and secure the
bottom cover.
Filter Reset
Plug in the power adapter，press timer and on/off swith together
for 2 seconds and one beep "Di" can be heard and timer working
indicator lights turn off. The HEPA is reset successfully.
09

CLEANING AND MAINTENANCE
1. Turn the air purifier off and unplug it before cleaning.
2. The outside of the air purifier can be cleaned with a soft, clean
dampened cloth.
3.The filtered air outlet and air inlet grill on the unit can be cleaned of
dust with a small, soft brush.
4. If you wish to clean the inside of the air purifier, please only use a dry,
soft cloth to wipe it down.
5. Do not wash the HEPA filter.
WARNING: Do not allow moisture to come in contact with the main
housing of the air purifier.
FILTER REPLACEMENT INSTRUCTIONS
1.On average, HEPA filter and activated carbon filter need to be replaced
every 3-6 months. Filter life will vary depending on air quality and usage.
2. Turn off and unplug the air purifier before attempting to replace the filters.
3. Open the bottom cover and take out the old HEPA.
4. To replace the HEPA filter,discard the old HEPA filter. Do not attempt to
clean. And then install a new HEPA filter well in position, make sure that
the primarily efficient filter shall be pointed outwards.
5. Screw back the bottom cover in position.
10

Problem
• Unit will not operate.
• Decreased air flow.
ENVIRONMENT FRIENDLY DISPOSAL
Check to make sure the unit is plugged in.
Check to make sure the unit is on.
Make sure the filter is properly installed
Check condition of the filter and replace if
necessary.
Check to ensure nothing is blocking the air
inlet and filtered air outlet.
Please replace the HEPA filter if they have
been operated for more than one year.
Be sure the plastic bag has been removed
from the filter.
You can help protect the environment!
Please remember to respect the local
regulations: hand in the non-working
electrical equipment to an appropriate
waste disposal center.
Solution
11
Troubleshooting
