3.0 Product Information
3.1 Incoming Inspection
WARNING – To avoid possibility of electrical shock, do not apply power to the
Com-Power AM-741R Active Monopole Antenna if there is any evidence of
shipping damage. If shipping damage to the product or any of its accessories is
suspected, or if the package contents are not complete, contact Com-Power or
your Com-Power distributor.
Please check the contents of the shipment against the package inventory in
section 3.2 to ensure that you have received all applicable items.
3.2 Package Inventory
STANDARD ITEMS:
9AM-741R Active Monopole Antenna
96 VDC (unregulated), 500 mA Battery Charger / AC Power Adapter
9Calibration Certificate and Associated Data
OTIONAL ITEMS:
9RAI-100 Remote Antenna Interface
9Fiber Optic Cable
96 VDC (unregulated), 500 mA, AC Power Adapter for RAI-100
9AMS-741 Grounding Kit
9AMC-10pF Calibration Capacitor

Page 7 of 24
INSTRUCTION MANUAL
AM-741R ACTIVE MONOPOLE ANTENNA

19121 El Toro Rd ●Silverado, California 92676 ●[phone] ●com-power.com
REV112216
3.3 Product Safety Information
3.3.1 Product Hazard Symbols Definitions
The hazard symbols appearing on the product exterior are defined below.
The yellow triangle with an exclamation mark indicates the presence of
important operating and/or maintenance (servicing) instructions in the
literature accompanying the product.
3.3.2 Product Warning/Caution Statements
CAUTION: Use only the charger supplied by Com-Power. Other chargers may damage the
battery.
3.3.3 General Safety Instructions
The following safety instructions have been included in compliance with safety standard
regulations. Please read them carefully.
• READ AND RETAIN INSTRUCTIONS - Read all safety and operating instructions before
operating the instrument. Retain all instructions for future reference.
• HEED WARNINGS - Adhere to all warnings on the instrument and operating instructions.
• FOLLOW INSTRUCTIONS - Follow all operating and use instructions.
• WATER AND MOISTURE - Do not use the instrument near water.
• WALL OR CEILING MOUNTING - Do not mount the instrument on a wall or ceiling.
• HEAT - The instrument should be situated away from heat sources such as heat registers or
other instruments which produce heat.
• POWER SOURCES - Connect the instrument only to the type of power source described in
the operating instructions or as marked on the instrument.
• POWER CORD PROTECTION - Place power supply cords so that they are not likely to be
walked on or pinched by items placed on them or against them.
• CLEANING – Clean the instrument only as recommended by the manufacturer.
• DEFECTS AND ABNORMAL STRESS - Whenever it is likely that the normal operation has been
impaired, make the equipment inoperable and secure it against further operation.
• DAMAGE REQUIRING SERVICE - Instrument should be serviced by qualified personnel when:
9The power supply cord or the plug has been damaged.
9Objects have fallen or liquid has been spilled into the instrument.
9The instrument has been exposed to rain.
9The instrument does not appear to operate normally.
9The instrument has been dropped, or the enclosure has been damaged.
• SITTING OR CLIMBING - Do not sit or climb upon the instrument or use it as a step or ladder.

Page 8 of 24
INSTRUCTION MANUAL
AM-741R ACTIVE MONOPOLE ANTENNA

19121 El Toro Rd ●Silverado, California 92676 ●[phone] ●com-power.com
REV112216
3.4 Product Connections/Controls/Indicators
FIGURE 1 - AM-741R Connections/Controls/Indicators - Front Panel
Counterpoisse
1
Metallic ground plane affixed to top surface of amplifier housing
Main Power Switch and LED Indicator
2
Activate all Monopole antenna interface/control circuits.
(antenna is in standby mode until RF output is enabled via RF Output ON/OFF toggle switch
-- see item 3)
RF Output ON/OFF Toggle Switch
3
Turns on/off Monopole antenna amplifier circuit
Remote Access Port
4
Fiber optic port for connection to RAI-100 Remote Antenna Interface
Monopole Element Connector
5
Type N-female connector for connection of telescoping monopole element, or 10 pF
capacitor during calibration
Remote Link LED Indicator
6
Indicates active connection with RAI-100 Remote Antenna Interface
RF Output On LED Indicator
7
Indicates that RF amplifier circuit is active
Saturation LED Indicator
8
Indicates that the amplifier is in saturation
Battery Low Indicator
9
Indicates that the battery level is getting low, and will soon require charging
Antenna Output Port
10
50 ohm, Type N-female coaxial port for connection to measuring instrument
Power Input Port
11
Power input port for connection of provided battery charger / AC adapter
Battery Charging Indicator
12
Indicates that the internal battery pack is being charged
AM-741R ACTIVE MONOPOLE ANTENNA
9 kHz to 60 MHz
ON/OFF
BATTERY LOW OUTPUT 50Ω
RF OUTPUT ON SATURATION CHARGING
RF OUTPUT REMOTE ACCESS
POWER REMOTE LINK
6 VDC, 500 mA
-
+
TX RX
2345
7 8 9 10 11 12
16

Page 9 of 24
INSTRUCTION MANUAL
AM-741R ACTIVE MONOPOLE ANTENNA

19121 El Toro Rd ●Silverado, California 92676 ●[phone] ●com-power.com
REV112216
FIGURE 2 - AM-741R Connections/Controls/Indicators – Rear Panel
Fuse Mounting Assembly
13
Provides access to input power fuse
Battery Access Panel
14
Provides access to internal battery pack
FIGURE 3 - AM-741R Connections/Controls/Indicators - Bottom Panel
Antenna Mounting Hole (¼” x 20 threads per inch)
15
For mounting Monopole antenna to tripod or other mounting structure
13 14
www.com-power.com
250V, 200 mA
BATTERY:
(6V, 2.0 Ah), NiMH
CAUTION:
Use only the charger supplied
by Com-Power. Other chargers
may damage the battery.
15

Page 10 of 24
INSTRUCTION MANUAL
AM-741R ACTIVE MONOPOLE ANTENNA

19121 El Toro Rd ●Silverado, California 92676 ●[phone] ●com-power.com
REV112216
FIGURE 4 - RAI-100 Connections/Controls Indicators
RF Output ON/OFF Toggle Switch
1
Turns on/off Monopole antenna amplifier circuit
RF Output On LED Indicator
2
Indicates that monopole RF amplifier circuit is active
Power On LED indicator
3
Indicates that the AM-741R interface/control circuitry is powered (stand-by mode)
Battery Low Indicator
4
Indicates that the AM-741R battery level is getting low, and will soon require charging
Saturation LED Indicator
5
Indicates that the AM-741R amplifier is in saturation
Remote Access Port
6
Fiber optic port for connection to AM-741R Monopole Antenna
Remote Link LED Indicator
7
Indicates active connection with AM-741R Monopole Antenna
Power Input Port
8
Power input port for connection of provided AC adapter
REMOTE ACCESS REMOTE LINK
TX RX
RF OUTPUT
ON/OFF
RAI-100 REMOTE ANTENNA INTERFACE
BATTERY LOW
RF OUTPUT ON SATURATION
POWER ON
6 VDC, 500 mA
-
+
67
543
2
1
8
TOP VIEW
REAR SIDE VIEW RIGHT
SIDE VIEW

Page 11 of 24
INSTRUCTION MANUAL
AM-741R ACTIVE MONOPOLE ANTENNA

19121 El Toro Rd ●Silverado, California 92676 ●[phone] ●com-power.com
REV112216
3.5 Product Specifications
Technical
Product Active Monopole Antenna w/Remote Interface
Frequency Range 9 kHz to 30 MHz (usable up to 60 MHz)
Standard(s) MIL-STD 461, CISPR 25, Bellcore 1089, etc.
Output Impedance 50Ω(nominal)
Active Antenna Factors -1.4 to -0.3 (average: -0.5) dB/m
(
9 kHz to 30 MHz – t
yp
ical
)
Dynamic Range 103 dB @ 1 MHz [1 kHz bandwidth]
Saturation Level >350 mV/m / >120 dBμV/m
VSWR (output port) 1.01 to 1.329 (average: 1.06) :1 (typical)
Return Loss (output port) 17 to 41.1 (average: 33.1) :1 (typical)
Electrical
DC Power Input 6 VDC
AC to DC Power Adapter 6 VDC (unregulated), 500 mA
Fuse Type 250V, 200 mA, Type T
Battery Pack 6 VDC 2.0 Ah, NiMH (rechargeable)
Typical Battery Life 10-12 hours (new, fully charged battery)
RF Connectors
Antenna Port Connector N-type (female)
Power Input Port 5.5/2.5 mm Power Jack
Fiber Optic Connector Avago Duplex Latching POF jack
Mechanical
Dimensions (H)x(W)x(D) 2.75” x 23.8” x 23.8” (7 x 60.5 x 60.5 cm)
(Not including telescoping monopole element)
Weight 9.5 lbs (4.3 kg)
Environmental
Operating Temperature 40°F to 104°F (5°C to 40°C)

Page 12 of 24
INSTRUCTION MANUAL
AM-741R ACTIVE MONOPOLE ANTENNA

19121 El Toro Rd ●Silverado, California 92676 ●[phone] ●com-power.com
REV112216
FIGURE 5 - AM-741R Active Monopole Antenna Dimensions
FIGURE 6 - RAI-100 Remote Antenna Interface Dimensions
(H) 2.75”
(7 cm)
(W/D)
23.8” (60.5 cm)
(H) 2.75”
(7 cm)
7.4”
(18.8 cm)
16.3”
(41.4 cm)
AM-741R ACTIVE MONOPOLE ANTENNA
9 kHz to 60 MHz
ON/OFF
BATTERY LOW OUTPUT 50Ω
RF OUTPUT ON SATURATION CHARGING
RF OUTPUT REMOTE ACCESS
POWER REMOTE LINK
6 VDC, 500 mA
-
+
TX RX
RF OUTPUT
ON/OFF
RAI-100 REMOTE ANTENNA INTERFACE
BATTERY LOW
RF OUTPUT ON SATURATION
POWER ON
REMOTE ACCESS REMOTE LINK
TX RX
TOP VIEW
REAR SIDE VIEW RIGHT
SIDE VIEW
6 VDC, 500 mA
-
+
(W) 4.41”
(11.2 cm)
(D) 2.56”
(6.5 cm)
(D)
2.56”
(6.5 cm)
(H)
2.68”
(6.8 cm)

Page 13 of 24
INSTRUCTION MANUAL
AM-741R ACTIVE MONOPOLE ANTENNA

19121 El Toro Rd ●Silverado, California 92676 ●[phone] ●com-power.com
REV112216
4.0 Measurement Correction Factors
Anyone familiar with EMI radiated emissions measurements understands that
‘uncorrected’ values measured on your spectrum analyzer or EMI receiver are essentially
meaningless without the appropriate ‘correction’ factors for the individual components
of your measurement system.
A typical radiated emissions measurement system can include any combination of the
following components, all of which have a quantifiable effect on the measured voltage;
and therefore must be accounted for to accurately ‘correct’ your reading:
•Receiving antenna(s)
•Preamplifier(s)
•Coaxial measurement cable(s)
•Attenuation Pad(s)
•Connecting Adapter(s)
•Low-Pass, High-Pass or Notch Filter(s)
•DC Block(s)
•Other similar measurement components
We can separate the factors associated with the above components into three basic
categories:
1) Antenna (or transducer) Factors,
2) Gain Factors (for preamplifiers); and,
the cables, attenuators, adapters, filters, etc., can all be lumped into one general
category…
3) Insertion Loss Factors
These three categories of correction factors are discussed in the following sections.
Most of today’s spectrum analyzers and EMI receivers allow entry of these factors directly
into the instrument. You can then group the factors into factor sets. This makes things
very convenient, and allows the instrument to display/output test results as the corrected
values, with no further correction necessary. These newer instruments will also allow you
to enter the specification limits, so that PASS/FAIL can be determined instantaneously.
Older instruments, however, do not have this capability, so manual correction, or
correction through data acquisition PC software (or other means) is needed.
Whatever the case may be, applying the CORRECT correction factors is obviously key to
achieving accurate results. A simple typo when entering factors into your instrument or
PC software will give you incorrect data every time a test is performed until such time
that you notice the mistake, or until you recalibrate and enter the new factors. It is a
good idea to double-check your entries.

Page 14 of 24
INSTRUCTION MANUAL
AM-741R ACTIVE MONOPOLE ANTENNA

19121 El Toro Rd ●Silverado, California 92676 ●[phone] ●com-power.com
REV112216
4.1 Antenna Factors
Your AM-741R Active Monopole Antenna is provided with frequency-specific
antenna factors, which must be added to the measured value to determine the
field strength value.
Meter Reading (dBuV) + Active Ant. Factor (dB/m) = Electric Field Strength (dBuV/m)
4.2 Preamplifier Gain Factors
Our second category of correction factors are gain factors for preamplifiers.
Preamplifiers are used to increase measurement sensitivity by increasing signal to
noise ratio. This is necessary when measuring low signal levels which would
otherwise be buried below the inherent noise floor of the measuring instrument,
typically a spectrum analyzer or EMI receiver. Ideally, input signals levels are
increased proportionate to the preamp’s gain, without significantly increasing the
overall system noise level.
The AM-741R is an Active Monopole Antenna, and contains an internal
preamplifier, so additional signal amplification should not be needed.
Additionally, the preamplifier gain values are included in the antenna factor, so
no additional measurement correction is necessary.
4.3 Insertion Loss Factors
As discussed previously, our third category of correction factors is insertion loss
factors. These factors can include the insertion loss values of coaxial cables,
band-pass or notch filters, attenuation pads, connecting adapters, etc. Basically,
it includes any measurement system component (cable, adapter, combiner,
divider or any other device) installed in-line with your measurement path having
inherent insertion loss over the frequency range of the measurements,
intentionally or unintentionally, beyond that which is considered to be negligible.
If the exact insertion loss factors (or values) are unknown for one or more
component(s) of your measurement system, refer to section 4.3.1.
Insertion loss factors (or values) must be added to the measured values in order to
obtain the ‘corrected’ values.

Page 15 of 24
INSTRUCTION MANUAL
AM-741R ACTIVE MONOPOLE ANTENNA

19121 El Toro Rd ●Silverado, California 92676 ●[phone] ●com-power.com
REV112216
4.3.1 Insertion Loss Measurement
Insertion Loss values for coaxial cables and most measurement system
components having a single coaxial input and output, such as
attenuators, filters, dc blocks, etc., can be easily determined through a
simple calibration process.
All that is typically needed is the following:
9(2) short coaxial cables and ‘barrel’ adapter to connect them together;
and,
either:
9a network analyzer or measuring instrument (spectrum analyzer or EMI
receiver) with tracking generator;
or:
9a measuring instrument (spectrum analyzer or EMI receiver); and,
9a stable signal source with the appropriate frequency capabilities, such as
a signal generator, function generator, or even a Com-Power Comb
Generator.
4.3.1.1 Insertion Loss Measurement Procedure
1) REFERENCE MEASUREMENTS (R) - With the equipment set up as
shown in Figure 3, measure and record the signal level (in dBμV)
at several frequencies over the frequency range to be
calibrated.
FIGURE 7 - Setup for Reference Measurements (R)
2) INSERTION LOSS MEASUREMENTS (I) – Without changing any
equipment settings, and with the equipment set up as shown in
Figure 4, measure and record the signal level (in dBμV) at the
same frequencies used in Step 1.
FIGURE 8 - Setup for Insertion Loss Measurements (I)
3) Calculate the insertion loss factor (in dB) for each frequency
using the following formula:
Insertion Loss Factor = (R) minus (I)
Signal Source
Measuring
Instrument
coaxial cables
‘barrel’ adapter
Signal Source
Measuring
Instrument
coaxial cables
system component
to be calibrated
X

Page 16 of 24
INSTRUCTION MANUAL
AM-741R ACTIVE MONOPOLE ANTENNA

19121 El Toro Rd ●Silverado, California 92676 ●[phone] ●com-power.com
REV112216
5.0 Using your AM-741R Monopole Antenna
5.1 Field Strength Measurement Calculations
As discussed in section 4, the measured values must be corrected for preamplifier
gain and any losses incurred along the measurement path.
FIGURE 9 - Typical measurement system for AM-741R
In the following example, we will convert an uncorrected voltage measurement
into a electric field strength for comparison to the MIL-STD 461, RE101 limit of 24
dBuV/m @ 1 meter.
AM-741RACTIVE MONOPOLE ANTENNA
9kHz to 60 MHz
ON/OFF
BATTERYLOW OUTPUT50Ω
RFOUTPUT ON SATURATION CHARGING
RFOUTPUT REMOTEACCESS
POWER REMOTELINK
6VDC, 500 mA
-
+
TX RX
REMOTEACCESS REMOTELINK
TX RX
RFOUTPUT
ON/OFF
BATTERYLOW
RFOUTPUTON SATURATION
POWERON
RAI-100REMOTEANTENNA INTERFACE

Page 17 of 24
INSTRUCTION MANUAL
AM-741R ACTIVE MONOPOLE ANTENNA

19121 El Toro Rd ●Silverado, California 92676 ●[phone] ●com-power.com
REV112216
EXAMPLE:
We’ll use the measurement system shown in Figure 9, and assume a 1-
meter separation distance between the source and the antenna. We
observe a signal at 30 MHz using the spectrum analyzer, and its
[uncorrected] amplitude is exactly 20 dBμV.
For the system shown above, there are two (2) correction factors needed:
1) The AM-741R Active Antenna Factor
2) The Insertion Loss Factor for the cable connecting the AM-741R to
the measuring instrument.
We’ll assume that the insertion loss of the cable at 30 MHz is 2 dB. And, by
referring to the typical antenna factor tables in Section 8, we see that the
Active Antenna Factor is -1.35 dB/m (in practice, you will use your actual
calibrated factors rather than the typical factors).
Measured amplitude @ 30 MHz = 20 dBμV
Active E-Field Antenna Factor @ 30 MHz = -1.35 dB/m
Insertion Loss of Coaxial Cable @ 30 MHz = 2 dB
Measured Amplitude + Active Antenna Factor
+ Insertion Loss of Cable=
20.65 dBμV/m
MIL-STD 461 Field Strength Limit @ 1 meter = 24 dBμV/m
Limit Δ= -3.35 dB

Page 18 of 24
INSTRUCTION MANUAL
AM-741R ACTIVE MONOPOLE ANTENNA

19121 El Toro Rd ●Silverado, California 92676 ●[phone] ●com-power.com
REV112216
5.2 Antenna Positioning
The two most common arrangements for tests performed using a monopole
antenna are illustrated in the following figures. Shown in Figure 10 is the
arrangement described in the most recent editiions of MIL-STD 461. Figure 11
shows the “classic” arrangement required by older editions of MIL-STD 461 and
RTCA DO-160, as well as CISPR 25.
Refer to the standard to which you are performing tests for exact details on the
measurement arrangement.
FIGURE 10 - Test Arrangement for MIL-STD 461 (recent editions)
120 cm
center point
of antenna
104 cm
to measurement
equipment
1 meter
EQUIPMENT
UNDER TEST
(EUT)
AMS-741
Grounding Kit

Page 19 of 24
INSTRUCTION MANUAL
AM-741R ACTIVE MONOPOLE ANTENNA

19121 El Toro Rd ●Silverado, California 92676 ●[phone] ●com-power.com
REV112216
FIGURE 11 - “Classic” Test Arrangement
height
specied
within
standard
to measurement
equipment
104 cm
1 meter
EQUIPMENT
UNDER TEST
(EUT)
counterpoisse
extention
(foil or sheet metal)

Page 20 of 24
INSTRUCTION MANUAL
AM-741R ACTIVE MONOPOLE ANTENNA

19121 El Toro Rd ●Silverado, California 92676 ●[phone] ●com-power.com
REV112216
5.3 Using RAI-100 Remote Antenna Interface Unit
Locate the RAI-100 Remote Antenna Interface in a convenient, conspicuous
location near the measurement equipment. Connect the supplied
AC adapter to an appropriate power source, and connect the plug
end of its cord into the RAI-100.
Secure the AM-741R Monopole Antenna into position for the
measurements. Connect the AM-741R to the RAI-100 Remote
Interface Unit using the supplied fiber optic cable as shown in Figure 12.
FIGURE 12 - Fiber Optic Connection from AM-741R to RAI-100
Once connected, the link will be established automatically. Once the link has
been established, the green REMOTE LINK LED indicator on both the RAI-100 and
AM-741R should be lit.
Now, turn on the Active Antenna’s RF Output by
pushing the RF OUTPUT ON/OFF pushbutton on the
RAI-100 (or on the AM-741R). As long as the RF
OUTPUT ON LED Indicator is lit, and the red
SATURATION LED indicator is NOT lit, your Monopole
antenna is ready to measure. If the SATURATION
LED indicator turns on during the test, the magnitude of the field is outside of the
antenna’s dynamic range, which can cause measurement inaccuracies due to
unintended, non-linear operation. Avoid making measurements whenever
possible when the SATURATION indicator is lit.
6 VDC, 500 mA
-
+
RAI-100 REMOTE ANTENNA INTERFACE
BATTERY LOW
RF OUTPUT ON SATURATION
POWER ON
RF OUTPUT
ON/OFF
AM-741RACTIVE MONOPOLE ANTENNA
9kHz to 60 MHz
ON/OFF
BATTERYLOW OUTPUT50Ω
RFOUTPUT ON SATURATION CHARGING
RFOUTPUT REMOTE ACCESS
POWER REMOTELINK
6VDC, 500 mA
-
+
TX RX
REMOTEACCESS REMOTE LINK
TX RX
RFOUTPUT
ON/OFF
BATTERYLOW
RFOUTPUTON SATURATION
POWERON
RAI-100REMOTEANTENNA INTERFACE
