ComAp InteliVision 13Touch User manual

Copyright © 2020 ComAp a.s.
Written by ComAp a.s.
Prague, Czech Republic
ComAp a.s., U Uranie 1612/14a,
170 00 Prague 7, Czech Republic
Tel: [phone]
E-mail: [e-mail], www.comap-control.com Global Guide
InteliVision
13Touch
13.3" display unit for ComAp
controllers
SW version 1.0
1 Document information 4
2 System overview 8
3 Installation and wiring 10
4 Display Unit Settings 15
5 InteliVision 13Touch connection possibilities 16
6 Automatic SCADA start and connecting to the system 22
7 Creating a SCADA diagram 23

InteliVision 13Touch Global Guide 2
Table of contents
1 Document information 4
1.1 Clarification of notation 4
1.2 About this guide 4
1.3 Legal notice 4
1.4 Certifications 6
1.5 Document history 7
1.6 Related products 7
2 System overview 8
2.1 General description 8
3 Installation and wiring 10
3.1 Front panel description 10
3.2 Rear panel description 11
3.2.1 Rear panel 11
3.3 Dimensions drawings 12
3.4 Mounting 12
3.5 Power 13
3.6 Ethernet (LAN) Ports 14
3.6.1 LAN Ports 14
4 Display Unit Settings 15
4.1 Touchscreen settings 15
4.2 On-Screen Keyboard (OSK) settings 15
5 InteliVision 13Touch connection possibilities 16
5.1 InteliVision 13Touch connection to a Single gen-set 16
5.1.1 Ethernet (direct) connection 16
5.1.2 USB connection 17
5.2 InteliVision 13Touch connection to a Multiple gen-set 18
5.2.1 Multiple Ethernet Connection 18
5.2.2 Ethernet (Internet) connection via InternetBridge-NT 20
6 Automatic SCADA start and connecting to the system 22
7 Creating a SCADA diagram 23
7.1 Automatic SCADA generating 23
7.2 User-defined SCADA layout 25
7.2.1 Preparing SCADA archives 25

InteliVision 13Touch Global Guide 3
7.2.2 Creating SCADA on another PC 26

InteliVision 13Touch Global Guide 4
1 Document information
1.1 Clarification of notation 4
1.2 About this guide 4
1.3 Legal notice 4
1.4 Certifications 6
1.5 Document history 7
1.6 Related products 7
6back to Table of contents
1.1 Clarification of notation
Note: This type of paragraph calls readers attention to a notice or related theme.
IMPORTANT: This type of paragraph highlights a procedure, adjustment etc., which can cause a
damage or improper function of the equipment if not performed correctly and may not be clear at
first sight.
Example: This type of paragraph contains information that is used to illustrate how a specific function
works.
1.2 About this guide
This manual contains important instructions about InteliVision 13Touch display unit that shall be fullfilled during
the installation and maintenance.
This manual provides general information how to install and use InteliVision 13Touch display unit.
1.3 Legal notice
This End User's Guide/Manual as part of the Documentation is an inseparable part of ComAp’s Product and
may be used exclusively according to the conditions defined in the “END USER or Distributor LICENSE
AGREEMENT CONDITIONS – COMAP CONTROL SYSTEMS SOFTWARE” (License Agreement) and/or in
the “ComAp a.s. Global terms and conditions for sale of Products and provision of Services” (Terms) and/or in
the “Standardní podmínky projektů komplexního řešení ke smlouvě o dílo, Standard Conditions for Supply of
Complete Solutions” (Conditions) as applicable.
ComAp’s License Agreement is governed by the Czech Civil Code 89/2012 Col., by the Authorship Act
121/2000 Col., by international treaties and by other relevant legal documents regulating protection of the
intellectual properties (TRIPS).
The End User and/or ComAp’s Distributor shall only be permitted to use this End User's Guide/Manual with
ComAp Control System Registered Products. The Documentation is not intended and applicable for any other
purpose.
Official version of the ComAp’s End User's Guide/Manual is the version published in English. ComAp reserves
the right to update this End User's Guide/Manual at any time. ComAp does not assume any responsibility for its
use outside of the scope of the Terms or the Conditions and the License Agreement.

InteliVision 13Touch Global Guide 5
Licensed End User is entitled to make only necessary number of copies of the End User's Guide/Manual. Any
translation of this End User's Guide/Manual without the prior written consent of ComAp is expressly prohibited!
Even if the prior written consent from ComAp is acquired, ComAp does not take any responsibility for the
content, trustworthiness and quality of any such translation. ComAp will deem a translation equal to this End
User's Guide/Manual only if it agrees to verify such translation. The terms and conditions of such verification
must be agreed in the written form and in advance.
For more details relating to the Ownership, Extent of Permitted Reproductions Term of Use of the
Documentation and to the Confidentiality rules please review and comply with the ComAp’s License
Agreement, Terms and Conditions available on www.comap-control.com.
Security Risk Disclaimer
Pay attention to the following recommendations and measures to increase the level of security of ComAp
products and services.
Please note that possible cyber-attacks cannot be fully avoided by the below mentioned recommendations and
set of measures already performed by ComAp, but by following them the cyber-attacks can be considerably
reduced and thereby to reduce the risk of damage. ComAp does not take any responsibility for the actions of
persons responsible for cyber-attacks, nor for any damage caused by the cyber-attack. However, ComAp is
prepared to provide technical support to resolve problems arising from such actions, including but not limited to
restoring settings prior to the cyber-attacks, backing up data, recommending other preventive measures against
any further attacks.
Warning: Some forms of technical support may be provided against payment. There is no legal or factual
entitlement for technical services provided in connection to resolving problems arising from cyber-attack or
other unauthorized accesses to ComAp's Products or Services.
General security recommendations and set of measures
1. AccessCode
• Change the AccessCode BEFORE the device is connected to a network.
• Use a secure AccessCode – ideally a random string of 8 characters containing lowercase, uppercase letters
and digits.
• For each device use a different AccessCode.
2. Password
• Change the password BEFORE the device enters a regular operation.
• Do not leave displays or PC tools unattended if an user, especially administrator, is logged in.
3. Controller Web interface
• The controller web interface at port TCP/80 is based on http, not https, and thus it is intended to be used only
in closed private network infrastructures.
• Avoid exposing the port TCP/80 to the public Internet.
4. MODBUS/TCP
• The MODBUS/TCP protocol (port TCP/502) is an instrumentation protocol designed to exchange data
between locally connected devices like sensors, I/O modules, controllers etc. From it’s nature it does not
contain any kind of security – neither encryption nor authentication. Thus it is intended to be used only in closed
private network infrastructures.
• Avoid exposing the port TCP/502 to the public Internet.
5. SNMP

InteliVision 13Touch Global Guide 6
• The SNMP protocol (port UDP/161) version 1,2 is not encrypted. Thus it is intended to be used only in closed
private network infrastructures.
• Avoid exposing the port UDP/161 to the public Internet.
1.4 Certifications
Declaration of Conformity
The product(s) described in this manual complies with all applicable European
Union (CE) directives if it has a CE marking. For computer systems to remain CE
compliant, only CE-compliant parts may be used. Maintaining CE compliance
also requires proper cable and cabling techniques.
RoHS
This device complies with conditions known as “RoHS compliance” and
conforms to the requirements of the European Union’s Restrictions on the Use of
Certain Hazardous Substances in Electrical and Electronic Equipment (“RoHS”)
Directive, 2015/863/EU. RoHS restricts the use of Lead (Pb) < 0.1% or
1,000ppm, Mercury (Hg) < 0.1% or 1,000ppm, Cadmium (Cd) < 0.01% or
100ppm, Hexavalent Chromium (Cr6+) < 0.1% or 1,000ppm, Polybrominated
biphenyls (PBB) < 0.1% or 1,000ppm, Polybrominated diphenyl Ethers (PBDE) <
0.1% or 1,000ppm, Bis(2-Ethylhexyl) phthalate (DEHP) < 0.1% or 1,000ppm,
Benzyl butyl phthalate (BBP) < 0.1% or 1,000ppm, Dibutyl phthalate (DBP) <
0.1% or 1,000ppm, and Diisobutyl phthalate (DIBP) < 0.1% or 1,000ppm.
FCC
This product complies with FCC 47 CFR Part 15, Subpart B, Class A. This
equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.
EU RO MR
Marine certification stands for European Union Recognised Organisation Mutual
Recognition Type Approval Certification. It is a Marine certification recognized by
the EU RO MR group members. Nowadays (March 2020) EU RO MR group
members are: American Bureau of Shipping ("ABS"), Bureau Veritas Marine &
Offshore SAS ("BV"), China Classification Society ("CCS"), Croatian Register of
Shipping ("CRS"), DNV GL AS ("DNV GL"), Indian Register of Shipping ("IRS"),
Korean Register ("KR"), Lloyd's Register Group Ltd. ("LR"), Nippon Kaiji Kyokai
General Incorporated Foundation ("NK" or "ClassNK"), Polski Rejestr Statkow
S.A. ("PRS"), RINA Services S.p.A. ("RINA"), Russian Maritime Register of
Shipping ("RS"). When using the InteliVision 13Touch EU RO MR certificate it is
necessary to enclose also Statement of Similarity for RD1IV13TBME also
available for download.
EUROMR

InteliVision 13Touch Global Guide 7
1.5 Document history
Revision number Related sw. version Date Author
1 IV13T_image_version_1.0.0 1.5.2020 ComAp a.s.
1.6 Related products
Product Description Order code
InteliSys Gas Industrial grade controller for gas gen-set based CHPs and power generation
applications I2GASXXBAB
InteliSysNTC BaseBox Premium Parallel Gen-set Controller IS-NTC-BB
InteliGenNTC BaseBox Complex Parallel Gen-set Controller IG-NTC-BB
InteliMainsNTC
BaseBox Mains Supervision Controller Base Unit IM-NTC-BB
InteliGenNT Complex Parallel Gen-set Controller IG-NT GC
InteliSysNTC Hybrid Hybrid system controller IS-NTC HYBRID
InteliMainsNT Mains Supervision Controller IM-NT GC
InteliDrive DCU Marine Modular Certified Engine Controller for Marine Applications ID-DCU MARINE
InteliGenNTBaseBox Complex Parallel Gen-set Controller with Detachable Colour Display IG-NT-BB
InteliLiteNT Manual Remote Start (MRS) Gen-set Controller IL-NT MRS15
InteliCompactNT Genset Controller for Gensets in Multiple Parallel Applications IC-NT MINT
InteliLite New generation of the most advanced Auto Mains Failure (AMF) gen-set controller IL3AMF25BAA
InteliGen 200 New Generation of Parallel Gen-set Controller IG3200XXBAA
InteliGen 500 Advanced paralleling gen-set controller with 5” colour display IG3500XXBAA

InteliVision 13Touch Global Guide 8
2 System overview
2.1 General description 8
6back to Table of contents
2.1 General description
The new InteliVision 13Touch is a high-quality easy-to-use 13.3" Marine certified Panel PC with multi-controller
support and buttons for brightness regulation on its front face. Even though the software allows to configure up
to 32 controllers the hardware is designed for simultaneous monitoring and control of up to 4 controllers only.
Compatible controllers should be connected via Ethernet, in some cases with use of InternetBridge-NT. USB
ports are recommended not to be used for monitoring.
InteliVision 13Touch is mainly dsigned to communicate over Ethernet interface. InteliVision 13Touch comes
with PC SCADA software enabling users to freely configure their screen with different types of items such as
meters, bar graphs, numeric values, control buttons, pictures, etc. The software allows users to check the
history of multiple controllers and change setpoints from a single location. IGS-LOG software is also
preinstalled at no extra cost for continuous logging of desired parameters. InteliVision 13Touch is designed to
mount on a panel.
Technical data
Power Supply Range 10 - 31 V DC
Power supply
Operating Temperature -15 °C to 55 °C
Storage Temperature -20 °C to 60 °C
Vibration On engine 4grms
Humidity Up to 95% relative humidity
(non-condensing)
Operating conditions
Rear I/O
2 × USB 2.0
2 × USB 3.0
Ethernet: 2 × RJ45, 10/100/1000 Base-Tx
Interfaces
CPU Intel Atom® x5-E3930 Processor, 2 MB Cache,
1.30 GHz / 1.80 GHz
Memory 4GB RAM
Storage Device 32 GB eMMC
240GB SSD
System
LCD panel 13.3" TFT-LCD
Resolution 1920 × 1080 px (FHD)
Luminance 600 cd/m2
LCD specification

InteliVision 13Touch Global Guide 9
Contrast Ratio 600 : 1
Viewing Angle 85 deg. (up/down/left/right) (typical)
Backlight LED
Type P-Cap
(Projected Capacitive Touch)
Touchscreen
Housing IP66 front, IP20 rear (EN60529)
Weight approx: 3.0 kg / 6.6 lbs
Dimensions (W × H × D) 355.00 [13.98''] × 248.50 [9.78''] × 69.00 [2.72''] mm [inch]
Mechanical
OS Windows® 10 IoT Enterprise 2019 LTSC (64bit)
Operating system

InteliVision 13Touch Global Guide 10
3 Installation and wiring
3.1 Front panel description 10
3.2 Rear panel description 11
3.3 Dimensions drawings 12
3.4 Mounting 12
3.5 Power 13
3.6 Ethernet (LAN) Ports 14
6back to Table of contents
3.1 Front panel description
Image 3.1 Front panel overview
Title Description
LED indication Status RGB LED
Brightness settings Brightness setting using buttons plus/minus
Power ON/OFF Power ON/OFF of the device

InteliVision 13Touch Global Guide 11
3.2 Rear panel description
3.2.1 Rear panel
Image 3.2 Rear bottom panel description
Number Title Description
1 USB 3.0 Type A (Host) 2 x 9-pin USB Type A
2 USB 2.0 Type A (Host) 2 x 4-pin USB Type A
3,4 Ethernet RJ45 2 x 8-pin RJ45 10/100/1000Mbps LAN/Ethernet
5 DC Power Input 1 x 2-pin Termin Block 5.08 - DC Power Input
6 External Fan Connector Not used.
7 Earthing Earthing screw connector.
IMPORTANT: It is strictly recommended to use earthing in any circumstances.

InteliVision 13Touch Global Guide 12
3.3 Dimensions drawings
Image 3.3 Dimensions of the InteliVision 13Touch
Note: Dimensions are in mm (inches)
3.4 Mounting
InteliVision 13Touch is designed to mount on a panel. InteliVision 13Touch has an external bracket mounting
system. Clips are included in the package. The recommended cutout size for panel mounting is 343,00 mm
(width) x 236,50 mm (height). Insert InteliVision 13Touch into the cut area and from the rear side install the
attached mounting clips and fix them with a screwdriver.

InteliVision 13Touch Global Guide 13
InteliVision 13Touch is a fanless system – no fan cooling system is installed inside the InteliVision 13Touch.
For proper operation, install InteliVision 13Touch in a cabinet or rack with enough space around it and away from
any strong source of heat. The operating temperature range of the InteliVision 13Touch is from -15 °C to 55 °C.
InteliVision 13Touch front frame sealing is included in the box. The installation of the front frame sealing is a
must to fulfill IP66 protection standard.
IMPORTANT: Do not overtighten the screws to prevent damaging the Panel PC.
IMPORTANT: The installation of the front frame sealing (included in the box) is a must to fulfill
IP66 protection standard.
3.5 Power
Use the proper power cable. The power supply range is from a 10–31V DC. Use the proper fuse (maximum 3A)
when powered from an onsite DC source. The max input current is 3 A at 10 V. Ensure correct polarity when
connecting the DC power supply.
PIN Definition
1DC+ (Positive supply voltage)
2DC- (Negative supply voltage)
Table 3.1 Description of Power connector

InteliVision 13Touch Global Guide 14
3.6 Ethernet (LAN) Ports
3.6.1 LAN Ports
Connector type: RJ45 port with LEDs
Pin Mark Definition
1 D0P+ Differential Pair 0 (Positive)
2 D0N- Differential Pair 0 (Negative)
3 D1P+ Differential Pair 1 (Positive)
4 D2P+ Differential Pair 2 (Positive)
5 D2N- Differential Pair 2 (Negative)
6 D1N- Differential Pair 1 (Negative)
7 D3P+ Differential Pair 3 (Positive)
8 D3N- Differential Pair 3 (Negative)
Table 3.2 Pin description of LAN1 Port on InteliVision 13Touch

InteliVision 13Touch Global Guide 15
4 Display Unit Settings
4.1 Touchscreen settings 15
4.2 On-Screen Keyboard (OSK) settings 15
6back to Table of contents
As the operating system Windows® 10 IoT Enterprise 2019 LTSC (64bit) is installed on the IV13T, you can use
standard settings such as the screensaver (the ComAp Screensaver is preinstalled), power off the display or
the whole unit after a set period of time, etc.
Only one user, ‘User’, is predefined with no password set. You can restrict users by setting passwords and/or
creating new users with limited rights. For more details, use Windows help.
4.1 Touchscreen settings
It is possible to calibrate touch sensor using the standard Windows® 10 IoT Enterprise 2019 LTSC (64bit)
functions.
1. Navigate to Start - Control Panel - Tablet PC Settings - Calibration
2. Perform the calibration
3. Save the calibrate data
4. Done
4.2 On-Screen Keyboard (OSK) settings
The On-Screen Keyboard (OSK) is a part of Windows® 10 IoT Enterprise 2019 LTSC (64bit) operating system.
OSK is pined to the Windows taskbar by default.
6back to Display Unit Settings

InteliVision 13Touch Global Guide 16
5 InteliVision 13Touch connection
possibilities
5.1 InteliVision 13Touch connection to a Single gen-set 16
5.2 InteliVision 13Touch connection to a Multiple gen-set 18
See chapter related products for more information about compatible ComAp controllers.
6back to Table of contents
5.1 InteliVision 13Touch connection to a Single gen-
set
5.1.1 Ethernet (direct) connection
Many different kinds of Ethernet topologies exist. A basic point to point Ethernet connection can be made by a
direct or cross Ethernet cable. In addition, it is also possible to monitor more than one controller in a site through
a switch (TCP/IP protocol-based network). Another possibility is establishing a connection through the internet
network, but for this a public IP address is necessary (or AirGate ComAp technology without a need for a public
IP address). The physical configuration of such a network can be a small Ethernet LAN or also through the
internet.
Image 5.1 Point to point Ethernet connection
IV13T settings Controller settings
2 x 10/100/1000 TX ports.
IP settings necessary. See the Controller manual for the specific help.
Table 5.1 Communication settings for the IV13T and controller

InteliVision 13Touch Global Guide 17
Note: Ethernet connection is available for all controllers mentioned in chapter related products via
InternetBridge-NT (See the chapter Multiple Ethernet connection). You can also use InternetBridge-NT without
the need for a public IP address (find details on our AirGate technology on our website www.comap-
control.com)
Using a web browser
An Ethernet connection to the controller allows one to use any web browser for basic monitoring and
configuration. Simply enter the IP address of the module into the address bar of your web browser, e.g.
http://192.168.1.254 and then enter the access code. When connecting through a web browser,
there is 5-minute timeout period after closing the browser window. After that, the client is automatically
logged out.
Ethernet connection settings
Settings can be edited via any type of connection (USB or Ethernet). Setup is provided via InteliMonitor.
For the Ethernet connection, set the following options in the Comms Settings group:
Image 5.2 Controller IP settings
Note: The IP addresses of the controllers must be accessible from the IV13T. If the IV13T is connected to
another LAN segment than the gen-sets are, there must be a gateway (router) that enables direct traffic
between the segments. If the IV13T is connected via the Internet, then the internet gateway of the LAN where
the gen-sets are connected must have a public IP address, must allow incoming traffic and must provide port
forwarding from the external public IP address to the various internal gen-set IPs according to the port used.
5.1.2 USB connection
IMPORTANT: USB ports are not suitable to be used for monitoring purposes. USB ports should be
used for configuration only. This recommendation is valid not only for InteliVision 13Touch, it is
valid in general. When using InteliVision 13Touch for monitoring, its Ethernet ports should be
used.

InteliVision 13Touch Global Guide 18
Image 5.3 Point to point USB connection
IV13T settings Controller settings
2 x USB 2.0 serial ports
2 x USB 3.0 serial ports
No special settings required
No special settings required.
Some controllers only via ext. bridge.
Table 5.2 Communication settings for the IV13T and controller
Note: Direct USB connection is not possible for some controllers. However, USB connection is available for all
above-mentioned controllers via InternetBridge-NT
5.2 InteliVision 13Touch connection to a Multiple
gen-set
5.2.1 Multiple Ethernet Connection
Even though the software allows to configure up to 32 controllers the hardware is designed for simultaneous
monitoring and control of up to 4 controllers only. Many different kinds of Ethernet topology exist. The
basic point to point Ethernet connection can be made by a direct or cross Ethernet cable. In addition it is also
possible to monitor more than one controller in a site through a switch (TCP/IP protocol-based network).
Another possibility is establishing a connection through the internet network, but for this a public IP address is
necessary (or AirGate ComAp technology, see our website www.comap-control.com for more information). The
physical configuration of such a network can be a small Ethernet LAN or also over the internet.

InteliVision 13Touch Global Guide 19
Image 5.4 Multiple Ethernet connection example
IV13T settings Controller settings
2 x 10/100/1000 TX ports
IP setting necessary. See the Controller manual for the specific help.
Table 5.3 Communication settings of IV13T and controller
Note: Ethernet connection is also available for all above-mentioned controllers via IntermetBridge-NT (See the
chapter Ethernet connection via IB-NT). You can also use InternetBridge-NT without the need for a Public IP
address (find more information about our AirGate technology on our website www.comap-control.com).
Using a web browser
An Ethernet connection to the controller allows one to use any web browser for basic monitoring and
adjustment of the controller. Simply enter the IP address of the module into the address bar of your web
browser, e.g. http://192.168.1.254 and then enter the access code. When connecting from a web
browser, there is a 5-minute timeout after closing the browser window. After that, the client is
automatically logged out.
Ethernet connection settings
Settings can be edited via any type of connection (USB, RS232/422/485, Ethernet). Setup is provided
via InteliMonitor. For an Ethernet connection, set the following options in the Comms Settings group:

InteliVision 13Touch Global Guide 20
Image 5.5 Controller IP settings
Note: IP addresses of the controllers must be accessible from the IV13T. If the IV13T is connected to another
LAN segment than the gen-sets are, there must be a gateway (router) that enables direct traffic between the
segments. If the IV13T is connected via the Internet, then the internet gateway of the LAN where gen-sets are
connected must have public IP address, must allow incoming traffic and must provide port forwarding from the
external public IP to the various internal gen-set IPs according to the port used.
Image 5.6 Internet gateway (router) configuration example
5.2.2 Ethernet (Internet) connection via InternetBridge-NT
Even though the software allows to configure up to 32 controllers the hardware is designed for simultaneous
monitoring and control of up to 4 controllers only. The response time of a system with this type of
connection depends on the number of controllers. The higher the number of controllers, the slower the system
response time. It is also possible to interconnect IV13T and controllers locally via InternetBridge-NT as a local
bridge from the Ethernet network to the CAN fieldbus or RS-485 interface.
Image 5.7 IB-NT connection example
