OWNER’S MANUAL
Model: ORC13F2500R
This product is only suitable for well insulated spaces or occasional use.
OIL FILLED HEATER

1
SAFETY INSTRUCTION
1. Warning: In order to avoid overheating, do not cover the
heater.
2. If the supply cord is damaged, it must be replaced by the manufacturer
or its service agent or a similarly qualified person in order to avoid a
hazard.
3. This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
4. The heater must not be located immediately below a socket-outlet.
5. Do not use this heater in the immediate surroundings of a bath, a
shower or a swimming pool.
6. Children of less than 3 years should be kept away unless continuously
supervised.
Children aged from 3 years and less than 8 years shall only switch
on/off the appliance provided that it has been placed or installed in its
intended normal operating position and they have been given supervi-
sion or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children aged from 3 years and
less than 8 years shall not plug in, regulate and clean the appliance or
perform user maintenance.

2
7. CAUTION — Some parts of this product can
become very hot and cause burns. Particular atten-
tion has to be given where children and vulnerable
people are present.
8. This heater is filled with a precise quantity of special oil. Repairs
requiring opening of oil-container are only to be made by the manu-
facturer or his service agent who should be contacted if there is an oil
leak. When scrapping the heater, follow the regulations concerning
the disposal of oil.
9. Correct Disposal of this product
This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible harm to
the environment or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the return and collec-
tion systems or contact the retailer where the product was purchased.
They can take this product for environmental safe recycling.
10.This heater cannot achieve accurate temperature control of the
enviroment, and thus cannot be used as insulation device for storage
environment, items, animals and plants.

3
ASSEMBLY INSTRUCTIONS
WARNING: IN ORDER TO AVOID OVERHEATING,
DO NOT COVER THE HEATER.
PART FIGURE
[Installation of the caster assembly]
1.Place the heater body inversely with the
bottom upward.
2.Connect and tighten two wheel carrier
plates to the body with butterfly nuts as
shown in the figure.
3.Place the heater upward after it is
installed securely with the wheels touching
the ground.
7 fins heater caster assembling 9\11\13 fins heater caster assembling
Cord wrap Caster assembly
Radiating unit
Air Outlet
Power Indicator Light
Power Switch Knob
Termostat Knob

4
WARNING: Risk of fire. Do not operate heater without wheel assemblies
attached. Operate heater in upright position only (wheels on bottom,
controls on top). Any other position could create a hazardous situation.
Ensure that the surface beneath the heater is clean and free of any
obstructions. It is not recommended that this heater be placed on
high-pile carpeting or any other surface that impedes the flow of air
underneath the heater.
This heater include an a visual power indicator light to warn that parts of
the heater are getting excessively hot. If the power indicator light flashes,
immediately turn the heater off and inspect for any objects on or adjacent
to the heater that may cause high temperatures. DO NOT OPERATE THE
HEATER WITH THE POWER INDICATOR LIGHT FLASHING.
1. Insert the plug into the suitable wall outlet.
1) Never use the unit in place where is not even, make sure there is nothing
flammable or easy deform object within 1 meter (36 inches).
2) Insert the plug after setting the thermostat to “MIN” position and setting the
power selected switches to “OFF” position.
3) Do not cover the unit.
4) The heater is suitable for operation on an A.C. electricity supply having the
same voltage as that show on its rating label.
2. Rotate power switch to the "Max" position then turn thermostat to the "high"
position, at this moment, the unit begins to work, when the temperature rises to
which you are satisfied with, slowly turn the thermostat counter clockwise until
the power indicating light out, the room temperature can keep constant. If you
want to raise or lower the room temperature, you can either turn the thermostat
clockwise to raise the temperature or counter clockwise to lower the temperature,
or set the power switch to Low position.
3. After use, turn the power switch to the “OFF” position first, then turn the
thermostat to the “MIN” position, and pull out the power supply plug.
NOTES:
1.The pilot lamp will be on only if the temperature is below the setting value of
the thermostat.
2.The room must be sealed in good condition, if not, it will not make good result
because of the influx of heat.
3.The outlets of the control chamber must be kept ventilative, if not, undue move
of the thermostat may occur.
OPERATING INSTRUCTION

5
MAIN TECHNOLOGY SPECIFICATIONS
Power supply: AC220-240V ~ 50Hz
MODEL LO MID HI
POWER REGULATION RANGE (W)
ORC13F2500R100015002500
1. The electric heater should be cleaned regularly to wipe out the dust on the
surface of flanges. As this may influence the radiating efficiency.
2. Disconnect electricity supply and allow radiator to cool, wipe out dust with a
soft damp cloth. Do not use detergent or abrasives.
3. Do not scrap the surfaces of flanges with sharp hard tools, to avoid surfaces
getting rusty, because of damage of the paint coat.
CLEANING AND MAINTENANCE INSTRUCTION
