Comfee EM720CPL-PM User manual

INSTRUCTION MANUAL
MICROWAVE OVEN
EM720CPL-PM/ EM720CPL-PMB

EN-2
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
SPECIFICATIONS
10 inchTurntable Diameter:
17.3X13.0X10.2 inchExternal Dimensions:
Approx. 20.2 LbsNet Weight:
EM720CPL-PM/ EM720CPL-PMB
120V~ 60Hz
1050W
700W
0.7 cu.ft.
Parameter
Model
Rated Voltage
Rated Input Power(Microwave):
Rated Output Power(Microwave):
Oven Capacity:
Content
1. Donot attempt to operate this oven with the door open
since this can result in harmful exposure to microwave
energy. It is important not to defeat or tamper with the
safety interlocks.
2. Do not place any object between the oven front face
and the door or allow soil or cleaner residue to
accumulate on sealing surfaces.
3. Do not operate the oven if it is damaged. It is
particularly important that the oven door closes
properly and that there is no damage to the:
a. DOOR(bent)
b. HINGES AND LATCHES (broken or loosened)
c. DOOR SEALS AND SEALING SURFACE
4. The oven should not be adjusted or reparied by anyone
except properly qualified service personnel.
:

EN-3
To reduce the risk of burns, electric shock, fire, injury to
persons or exposure to excessive microwave oven energy
when using your appliance, follow basic safety precautions,
including the following:
1. Read all instructions before using the appliance.
2. Read and follow the specific: " PRECAUTIONS TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE
ENERGY " found on page 2.
3. As with most cooking appliances, close supervision is
necessary to reduce the risk of a fire in the oven cavity.
4. To reduce the risk of fire in the oven cavity:
a. Do not overcook food. Carefully attend the appliance
when paper, plastic, or other combustible materials
are placed inside the oven to facilitate cooking.
b. Remove wire twist-ties and metal handles from
paper or plastic containers/ bags before placing
them in the oven.
c. If materials inside the oven ignite, keep the oven door
closed. Turn the oven off, and unplug the appliance.
Disconnect the power cord, shut off power at the fuse
or circuit breaker panel.
d. Do not use the cavity for storage purposes. Do not
leave paper products, cooking utensils, or food in the
cavity when not in use.
IMPORTANT SAFETY INSTRUCTIONS
WARNING

EN-4
5. This oven must be grounded. Connect only to properly
grounded outlet. See "GROUNDING INSTRUCTIONS" found
on page 6.
6. Install or locate this oven only in accordance with the
installation instructions provided.
7. Some products such as whole eggs and sealed
containers-for example, closed glass jars-are able to
explode and should not be heated in the oven.
8. Use this appliance only for its intended uses as
described in this manual. Do not use corrosive
chemicals or vapors in this appliance. This oven is
specifically designed to heat or cook or dry food.
It is not designed for industrial or laboratory use.
9. As with any appliance, close supervision is necessary
when used by children.
10. Do not operate this oven if it has a damaged cord or
plug, if it is not working properly or if it has been
damaged or dropped.
11. This microwave should be serviced only by qualified
service personnel. Contact nearest authorized service
facility for examination, repair or adjustment.
12. Do not cover or block any openings on the oven.
13. Do not store or use this appliance outdoors.
14. Do not use this oven near water, for example, near a
kitchen sink, in a wetbasement, near a swimming pool,
or similar locations.
15. Do not immerse cord or plug in water.
16. Keep cord away from heated surfaces.
17. Do not let cord hang over edge of table or counter.

EN-5
18. When cleaning surfaces of door and oven that
comes together on closing the door, use only mild,
nonabrasive soaps or detergents applied with a
sponge of soft cloth.
19. This appliance is for private household use only.
20. Liquids, such as water, coffee, or tea are able to be
overheated beyond the boiling point without appearing
to be boiling. Visible bubbling or boiling when the
container is removed from the microwave oven is not
always present.
THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY
BOILING OVER WHEN THE CONTAINER IS DISTURBED OR A
SPOON OR OTHER UTENSIL IS INSERTED INTO THE LIQUID.
a. Do not overheat the liquid.
b. Stir the liquid both before and halfway through
heating it.
c. Do not use straight-sided containers with narrow
necks.
d. After heating, allow the container to stand in the
microwave oven for a short time before removing the
container.
e. Use extreme care when inserting a spoon or other
utensil into the container.
SAVE THESE INSTRUCTIONS

Electric Shock Hazard
Touching some of the internal components can cause
serious personal injury or death. Do not disassemble this
appliance.
This appliance must be grounded. In the event of an
electrical short circuit, grounding reduces the risk of
electric shock by providing an escape wire for the electric
current. To protect against electrical shock, this appliance
is equipped with a cord having a 3 prong grounding-type
plug for insertion into a proper grounding-type receptacle.
DO NOT alter the plug for use in a 2-prong receptacle.
If the plug will not fit into a receptacle, have the proper
receptacle installed by a qualified electrician.
CAUTION:
Do not insert your fingers into any gaps or holes; it may
cause injuries.
EN-6
GROUNDING INSTRUCTIONS
DANGER

WARNING
Improper use of the grounding can result in a risk of electric
shock
Consult a qualified electrician or serviceman if the
grounding instructions are not completely understood or
if doubt exists as to whether the appliance is properly
grounded. If it is necessary to use an extension cord, use
only a 3-wire extension cord that has a 3-pronged
grounding plug, and a 3-slot receptacle that will accept
the plug on the appliance.The marked rating of the
extension cord shall be equal to or greater than the
electrical rating of the appliance.
1. A short power-supply cord is provided to reduce the risks
resulting from becoming entangled in or tripping over a
longer cord.
2. Longer cord sets or extension cords are available and
may be used if care is exercised in their use.
3. If a long cord sets or extension cord is used:
a. The marked electrical rating of the cord set or extension
marked electrial rating of the cord set or extension cord
should be at least as great as the electrical rating of the
appliance.
b. The extension cord must be a grounding -type 3-wire
cord.
c. The longer cord should be arranged so that it will not
drape over the countertop or tabletop where it can be
pulled on by children or tripped over uninten-tionally.
EN-7

Operation of the microwave oven may cause interference
to your radio, TV or similar equipment.
When there is interference, it may be reduced or
eliminated by taking the following measures:
a. Clean door and sealing surface of the oven.
b. Reorient the receiving antenna of radio or television.
c. Relocate the microwave oven with respect to the
receiver.
d. Move the microwave oven away from the receiver.
e. Plug the microwave oven into a different outlet so that
microwave oven and receiver are on different branch
circuits.
RADIO INTERFERENCE
EN-8
Thisdevicecomplieswithpart18oftheFCCRules.

CAUTION
Electric Shock Hazard
Tightly-closed utensils could explode. Closed containers
should be opened and plastic pouches should be pierced
before cooking.
See the instructions on "Materials you can use in microwave
oven or to be avoided in microwave oven." There may be
SAVE THESE INSTRUCTIONS
HOUSEHOLD INDOOR USE ONLY
UTENSILS
1. Fill a microwave-safe container with 1 cup of cold water (250ml)
along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm, do not
use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
UTENSIL TEST:
EN-9
following the procedure below.
microwaving. If in doubt, you can test the utensil in question
certain non-metallic utensils that are not safe to use for

EN-10
MATERIALS YOU CAN USE IN MICROWAVE OVEN
UTENSILS REMARKS
Browning dish Follow manufacturer’s instructions. The bottom of browning
dish must be at least 3/16 inch (5mm) above the turntable.
Incorrect usage may cause the turntable to break.
Dinnerware Microwave-safe only. Follow manufacturer's instructions.
Do not use cracked or chipped dishes.
Glass jars Always remove lid. Use only to heat food until just warm.
Most glass jars are not heat resistant and may break.
Glassware Heat-resistant oven glassware only. Make sure there is no
metallic trim. Do not use cracked or chipped dishes.
Oven cooking
bags
Follow manufacturer’s instructions. Do not close with metal
tie. Make slits to allow steam to escape.
Paper plates
and cups
Use for short–term cooking/warming only. Do not leave oven
unattended while cooking.
Paper towels Use to cover food for reheating and absorbing fat. Use with
supervision for a short-term cooking only.
Parchment
paper
Use as a cover to prevent splattering or a wrap for steaming.
Plastic
Microwave-safe only. Follow the manufacturer’s instructions.
Should be labeled "Microwave Safe". Some plastic containers
soften, as the food inside gets hot. "Boiling bags" and tightly
closed plastic bags should be slit, pierced or vented as
directed by package.
Plastic wrap Microwave-safe only. Use to cover food during cooking to
retain moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.

EN-11
MATERIALS TO BE AVOIDED IN MICROWAVE OVEN
UTENSILS REMARKS
Aluminum tray May cause arcing. Transfer food into microwave-safe dish.
Food carton with
metal handleMay cause arcing. Transfer food into microwave-safe dish.
Metal twist ties May cause arcing and could cause a fire in the oven.
Paper bags May cause a fire in the oven.
Plastic foam Plastic foam may melt or contaminate the liquid inside
when exposed to high temperature.
Wood Wood will dry out when used in the microwave oven and
may split or crack.

EN-12
SETTING UP YOUR OVEN
NAMES OF OVEN PARTS AND ACCESSORIES
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
Glass tray 1
Turntable ring 1
Instruction Manual 1
A) Control panel
B) Turntable shaft
C) Turntable ring
D) Glass tray
E) Observation window
F) Oven Door
G) Safety interlock system
F
G
A
C B
ED
Hub (underside)
Glass tray
Turntable ring
a. Never place the glass tray upside down.
The glass tray should never be restricted.
b. Both glass tray and turntable ring must
always be used during cooking.
c. All food and containers of food are always
placed on the glass tray for cooking.
TURNTABLE INSTALLATION
Turntable shaft

WARNING
EN-13
COUNTERTOP INSTALLATION
Remove all packing material and accessories. Examine the oven for any
damage such as dents or broken door. Do not install if oven is damaged.
Cabinet: Remove any protective film found on the microwave oven cabinet
surface. Do not remove the light brown Mica cover that is attached to the
oven cavity to protect the magnetron.
INSTALLATION
1. Select a level surface that provide enough open space for the intake and/or
outlet vents.
A minimum clearance of 3.0 inches (7.5cm) is required between the oven
and any adjacent walls. One side must be open.
(1) Leave a minimum clearance of 12 inches (30cm) above the oven.
(2) Do not remove the legs from the bottom of the oven.
(3) Blocking the intake and/or outlet openings can damage the oven.
(4) Place the oven as far away from radios and TV as possible.
Operation of microwave oven may cause interference to your radio or
TV reception.
2. Plug your oven into a standard household outlet. Be sure the voltage and
the frequency is the same as the voltage
The accessible surface maybe
hot during operation
Do not install oven over a range cooktop or other heat-producing appli-
ance. If installed near or over a heat source, the oven could be damaged
and the warranty would be avoid.
3.0 inch(7.5cm)
3.0 inch(7.5cm)
12 inch(30cm)
OPEN

EN-14
CONTROL PANEL AND FEATURES
(7) Auto Menu (Popcorn,Potato,Pizza,Frozen Vegetable,Beverage
and Dinner Plate)
(8) Number Pads
(10) START/ +30 SEC
(2) Time Defrost
(12) Display
(5)
(6)
(11)
(1) Time Cook
(11) Memory
(10)
(12)
(3) Power Level
(4) Clock and Settings
(5) Weight Defrost
(6) Kitchen Timer
(9) Stop/Cancel
(8)
(1)
(2)
(3)
(4)
(7)
(9)

11 power levels are available.
Press "Time Cook" , "00:00" will display, then press number pads to enter the
cooking time.
Press "Power" and "PL10" will display. Then press number pads to select
adifferent power level.
In cooking state of microwave, press "Power", the current power will be
displayed for 3 seconds. Then press number pads to change a different
power level.
a. Press "Time Cook" , "00:00" will display.
b. Press "1, 5, 0, 0" in order for 15:00 to appear in the display.
c. Press "Power" , then press "5" to select 50% microwave power.
d. Press START/+30SEC. to start cooking. Buzzer sounds once. The remaining
cooking time will display.
EN-15
OPERATION
1. POWER LEVELS
When the microwave oven is plugged into an outlet, "0:00" will display.
pads to select adifferent power level.
(1) Press “Clock” once, "00:00" will appear in the display.
(2) Press the number pads to enter the current clock time. For example, if
the time is now 10:12, press " 1, 0, 1, 2 " in order.
(3) Press “Clock” to finish clock setting, " : " will flash and the numbers
will appear as a clock time in the display.
2. CLOCK SETTING
Example : To cook the food with 50% microwave power for 15 minutes.
Level
Power
Display
10
100%
PL10
9
90%
PL9
8
80%
PL8
7
70%
PL7
6
60%
PL6
5
50%
PL5
4
40%
PL4
3
30%
PL3
2
20%
PL2
1
10%
PL1
0
0%
PL0
• If the numbers entered are not within the range between 1:00 to 12:59,
the setting will not be accepted until valid numbers are entered.
• In the process of setting clock, if the " STOP/Cancel " pad is pressed or if
there is no operation within 1 minute, the display will automatically
return to the previous clock setting.
NOTE

EN-16
(1) Press "Kitchen Timer" once, "00:00" will appear in the display.
(2) Press the number pads to enter the time amount. The maximum amount
of time that can be entered is 99 minutes, 99 seconds.
(3) Press "START/+30SEC." to confirm setting, and the timer will start to count
down.
(4) When the time amount elapses, the oven will beep 5 times.
3. KITCHEN TIMER
(1) Press "Time Cook" , "00:00" will appear in the display.
(2) Press number pads to enter the cooking time. The maximum cooking time
is 99 minutes,99 seconds.
(3) Press "Power" once, PL10 will flash. Press number pads 0 through 9 to select
a different power level if desired. See the POWER LEVEL table above
(4) Press "START/+30SEC." to start cooking. The remaining cooking time will
display.
4. MICROWAVE COOK
• The Kitchen Timer setting is different from the Clock setting; it is simply
a timer.
• During the Kitchen Timer function, no cooking function can be set into
operation.
• Kitchen Timer amount cannot be increased by pressing "START/+30SEC."
• Pressing " STOP/Cancel " will cancel the Timer countdown.
NOTE
• In the process of setting, if the "STOP/Cancel” pad is pressed or if there
is no operation within 1 minute, the oven will automatically return to
display the clock.
NOTE
Example : To cook the food with 50% microwave power for 15 minutes.
a. Press "Time Cook" , "00:00" will display.
b. Press "1, 5, 0, 0" in order for 15:00 to appear in the display.
c. Press "Power" once , then press "5" to select 50% microwave power.
d. Press “ START/+30SEC." to start cooking. Buzzer sounds once. The remaining
cooking time will display.

EN-17
(1) Instant cooking at 100% power level and 1 to 6 minutes cooking time can be
started by pressing number pads 1 to 6. Press "START/+30SEC." to increase
the cooking time by 30 seconds with each press.
The maximum cooking time is 99 minutes, 99 seconds.
(2) Instant cooking at 100% power level and 30 seconds cooking time can be
started by pressing "START/+30SEC." . Each repeated press will increase
cooking time by 30 seconds. The maximum cooking time is 99 minutes, 99
seconds.
5.ONE TOUCH START
(1) Press "Time Defrost" , "dEF2" will appear in the display.
(2) Press the number pads to input the defrost time.
(3) The default microwave power is power level 3. If you want to change the
power level, level, press "Power" once, and PL3 will display; then press the
number pad for the desired power level.
(4) Press "START/+30SEC." to start defrost cooking. And the remaining defrost
time will display.
6.TIME DEFROST
(1) Press "Weight Defrost" once,"dEF1" will display.
(2) Press number pads to input weight to be defrosted.
Input the weight range between 4 to 100 Oz.
(3) If the weight input is not between 4 to 100 Oz, the input will be invalid. A beep
will sound and the unitwill not work until valid numbers are entered.
(4) Press "START/+30SEC." to start defrosting and the cooking time remaining
will be displayed.
7. WEIGHT DEFROST FUNCTION
• Time can also be added in 30 second increments by pressing "START/
+30SEC." during Microwave Cooking, Time Defrost and Multi-stage
Cooking.
• Time cannot be added by pressing "START/+30SEC." during Weight
Defrost and Kitchen Timer functions.
NOTE

EN-18
(1) Press "Popcorn" , "1.75" will appear in the display.
(2) Press "Popcorn" two more times to choose the weight, "3.0" and "3.5" will
display in order.
(3) Press "START/+30SEC." to cook. The remaining time will display.
Oven beeps 5 times when cooking finish.
8. POPCORN
(1) Press "Potato" repeatedly until the number you wish appears in the display
"1", "2", "3" will display in order.
Press Once : 1 potato (approx. 8.0 oz)
Press Twice: 2 potatoes (approx. 16.0 oz)
Press 3 Times: 3 potatoes (approx. 24.0 oz)
(2) Press "START/+30SEC." to cook. The remaining time will display.
Oven beeps 5 times when cooking finish.
9. POTATO
(1) Press "Frz. Vegetable" , "4.0" will appear in the display.
(2) Press "Frz Vegetable" two more times to choose the weight, "8.0" and
"16.0" will display in order.
(3) Press "START/+30SEC." to cook. The remaining time will display.
Oven beeps 5 times when cooking finish.
10. FROZEN VEGETABLE
(1) Press "Beverage" , "1" will appear in the display.
(2) Press "Beverage" two more times to choose the weight, "2" and "3" will
display in order. One cup is about 4.0 Oz.
(3) Press "START/+30SEC." to cook. The remaining time will display.
Oven beeps 5 times when cooking finish.
11. BEVERAGE
.

EN-19
(1) Press "Pizza" , "4.0" will appear in the display.
(2) Press "Pizza" two more times to choose the weight, "8.0" and "14.0" will
display in order.
(3) Press "START/+30SEC." to cook. The remaining time will display.
Oven beeps 5 times when cooking finish.
13. PIZZA
(1) Press "0/Memory" to program and choose up to three cooking procedures.
Each procedure will be indicated by 1, 2 or 3 in the display.
(2) Press "0/Memory" until your desired procedure number appears in the
display. Press "START/+30SEC." to begin it. A maximum of two cooking
stages can be set for each procedure.
(3) To program a procedure, follow the steps listed below.
Example: Cook food at 80% Power Level for 3 minutes and 20 seconds; save
as memory 2.
a. Press "0/Memory" twice; screen displays 2.
b. Press "Time Cook" , then press "3" , "2" and "0" in order.
c. Press "Power" once, then press "8" for "PL 8" to display.
d. Press "START/+30SEC." to save the procedure. Oven beeps once.
Or press "START/+30SEC." twice directly to save and start cooking.
e. To choose the procedure from the memory list, press " 0/Memory" twice.
Screen will display "2". Press "START/+30SEC." to run procedure.
14. MEMORY FUNCTION
(1) Press "Dinner Plate" , "9.0" will appear in the display.
(2) Press "Dinner Plate" two more times to choose the weight, "12.0" and "18.0" will
display in order.
(3) Press "START/+30SEC." to cook. The remaining time will display.
Oven beeps 5 times when cooking finish.
12. DINNER PLATE
• Auto Menu cannot be set in Memory function.
NOTE

EN-20
At most 2 stages can be set for cooking. If one stage is Defrost, it will
automatically set to be the first stage.
16.MUTI-STAGE COOKING
• press "START/+30SEC." after programming both stages.
NOTE
• Auto Menu cannot be set in Multi-stage Cooking.
EXAMPLE: 80% Power Level for 5 minutes followed by 60% Power Level for 10
minutes.
a. Press "Time Cook", then press "5" , "0" and "0" to set first stage cook time.
b. Press "Power" once, then press "8" to choose 80% first stage cooking
power.
c. Press "Time Cook" again, then press "1", "0", "0" and "0" to set second stage
cook time.
d. Press "Power" again, then press "6" to choose 60% second stage cooking
power.
e. press "START/+30SEC." to immediately start multi-stage cooking.
NOTE
It is default that the buzzer sounds is open. In waiting state, long pressing on
number 8 for 3 seconds, it sounds a long beep, turns off the sound. All the
When the sounds turn off, long pressing on 8 for 3 seconds, it sounds a long
beep and the sound turn on.
sounds is turn off too.
15. TURN ON/OFF THE BUZZER SOUND
• All models has mute function and energy-saved function.
• This function can work under lock function too.
NOTE
\buttons has no beep when they are pressed, including the ending cooking
