Comfort Glow S26PT Quick start guide

Save this manual for future reference.
OWNER’S OPERATION AND INSTALLATION MANUAL
VENT-FREE PROPANE/LP GAS FREESTANDING
PEDESTAL STOVE SYSTEM
®
S26PT
20,000 to 26,000 Btu/Hr
Thermostatically
Controlled
Thisappliancemaybeinstalledinanaftermarket*manufactured(mobile)home,wherenotprohibitedbystate
or local codes.
*Aftermarket:Completion of sale,not for purposeof resale, fromthe manufacturer. (I.E.Installation of thisproduct is permittedafter the
manufactured (mobile) home is sited)
WARNING: If the information in this manual is not
followedexactly,afireorexplosionmayresultcaus-
ing property damage, personal injury, or loss of life.
— Donotstoreorusegasolineorotherflammable
vapors and liquids in the vicinity of this or any
other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call the
fire department.
— Installation and service must be performed by
a qualified installer, service agency, or the gas
supplier.
WARNING:Improperinstallation,
adjustment, alteration, service,
ormaintenancecancauseinjury
orpropertydamage.Refertothis
manual for correct installation
andoperationalprocedures.For
assistance or additional infor-
mation consult a qualified in-
staller, service agency, or the
gas supplier.
WARNING: This is an unvented
gas-firedheater.Itusesair(oxy-
gen)fromtheroominwhichitis
installed. Provisions for ad-
equatecombustionandventila-
tion air must be provided. Refer
to Air for Combustion and Ven-
tilation sectiononpage4ofthis
manual.
Patent Pending

2
105684
VENT-FREE PROPANE/LP PEDESTAL STOVE
1. This appliance is only for use with the
typeof gas indicated on the ratingplate.
Thisapplianceis not convertible for use
with other gases.
2. Do not place propane/LP supply tank(s)
inside any structure. Locate propane/
LP supply tank(s) outdoors.
DANGER: Carbon monoxide
poisoning may lead to death!
SAFETY
INFORMATION
Carbon Monoxide Poisoning: Early
signs of carbon monoxide poisoning re-
semble the flu, with headaches, dizziness,
ornausea.Ifyouhavethesesigns,theheater
maynot be working properly.Getfreshair
atonce!Haveheaterserviced.Somepeople
are more affected by carbon monoxide than
others. These include pregnant women,
peoplewithheartorlungdisease oranemia,
those under the influence of alcohol, and
those at high altitudes.
Propane/LP Gas: Propane/LP gas is odor-
less. An odor-making agent is added to pro-
pane/LP gas. The odor helps you detect a
propane/LPgasleak.However,theodoradded
to propane/LP gas can fade. Propane/LP gas
may be present even though no odor exists.
Make certain you read and understand all
Warnings. Keep this manual for reference.
It is your guide to safe and proper operation
of this heater.
WARNING ICON G 001
WARNINGS
IMPORTANT: Read this owner’s
manual carefully and completely
before trying to assemble, oper-
ate, or service this heater. Im-
proper use of this heater can
causeseriousinjuryordeathfrom
burns, fire, explosion, electrical
shock, and carbon monoxide
poisoning.
WARNING: Any change to
this heater or its controls can be
dangerous.
3. If you smell gas
• shut off gas supply
• do not try to light any appliance
• do not touch any electrical switch; do
not use any phone in your building
• immediately call your gas supplier
from a neighbor’s phone. Follow the
gas supplier’s instructions
• ifyou cannot reach your gassupplier,
call the fire department
4. This heater shall not be installed in a
bedroom or bathroom.
5. Never install the heater
• in a recreational vehicle.
• wherecurtains, furniture, clothing, or
otherflammable objects areless than
42inches from the front, top, or sides
of the heater.
• as a heater insert.
• in high traffic areas.
• in windy or drafty areas.
6. Do not use this heater as a wood-burn-
ing heater. Use only the logs provided
with the heater.
7. Do not add extra logs or ornaments
suchas pine cones,vermiculite, or rock
wool. Using these added items can
cause sooting. Do not add lava rock
aroundbase. Rock and debris could fall
into the control area of heater. After
servicing, always replace screen before
operating heater.
8. You must operate this heater with the
heaterscreenin place. Make sure heater
screenis in place before running heater.
9. This heater is designed to be smoke-
less. If logs ever appear to smoke, turn
off heater and call a qualified service
person. Note: During initial operation,
slight smoking could occur due to log
curing and heater burning manufactur-
ing residues.
10. To prevent the creation of soot, follow
the instructions in Cleaning and Main-
tenance, page 13.
11. Do not allow fans to blow directly into
the heater. Avoid any drafts that alter
burner flame patterns. Ceiling fans can
create drafts that alter burner flame
patterns. Altered burner patterns can
cause sooting.
12. Before using furniturepolish, wax, car-
pet cleaner, or similar products, turn
heater off. If heated, the vapors from
theseproducts may createa white pow-
der residue within burner box or on
adjacent walls or furniture.
13. This heater needs fresh air ventilation
to run properly. This heater has an oxy-
gen depletion sensor (ODS) pilot light
safetysystem.The ODS shuts downthe
heater if not enough fresh air is avail-
able. See Air for Combustion andVen-
tilation, pages 4 through 6. If heater
keeps shutting off, see Troubleshoot-
ing, pages 14 through 16.
14. Do not run heater
• where flammable liquids or vapors
are used or stored.
• under dusty conditions.
15. Do not use this heater to cook food or
burn paper or other objects.
16. Do not place clothing or other flam-
mablematerialonor near the appliance.
Never place any objects in the heater
or on logs.
17. Heater becomesveryhot when running.
Keepchildrenandadults away from hot
surfaces to avoid burns or clothing ig-
nition.Heater will remain hotfor a time
after shutdown.Allow surfaces to cool
before touching.
18. Carefullysuperviseyoungchildrenwhen
they are in same room with heater.
19. Do not use heater if any part has been
under water. Immediately call a quali-
fied service technician to inspect the
room heater and to replace any part of
the control system and any gas control
which has been under water.
20. Turn off and unplug heater and let cool
before servicing. Only a qualified ser-
vice person should service and repair
heater.
21. Operating heater above elevations of
4,500 feet could cause pilot outage.
22. Do not use a blower insert, heat ex-
changer insert, or other accessory not
approved for use with this heater.
23. Do not operate heater if any log is bro-
ken. Do not operate heater if a log is
chipped (dime-sized or larger).
24. To prevent performance problems, do
not use propane/LP fuel tank of less
than 100 lbs. capacity.

3
105684
OWNER’S MANUAL
PRODUCT
IDENTIFICATION
LOCAL CODES
Install and use heater with care. Follow all
local codes. In the absence of local codes, use
the latest edition of The National Fuel Gas
CodeANS Z223.1, also known asNFPA 54*.
*Available from:
American National Standards Institute, Inc.
1430 Broadway
New York, NY 10018
National Fire Protection Association, Inc.
Batterymarch Park
Quincy, MA 02269
This heater is designed for vent-free opera-
tion. State and local codes in some areas
prohibit the use of vent-free heaters.
Figure 1 - Vent-Free Propane/LP Gas Stove
UNPACKING
1. Remove top inner pack.
2. Tilt carton so that stove is upright.
3. Remove protective side packaging.
4. Slide stove out of carton.
5. Remove protective plastic wrap.
6. Remove screen by liftingand then pull-
ing forward.
7. Remove log set by cutting plastic ties.
8. Carefully unwrap log.
9. Check for any shipping damage. If
stove or log is damaged, promptly in-
form dealer where you bought stove.
PRODUCT
FEATURES
SAFETY PILOT
ThisheaterhasapilotwithanOxygenDeple-
tionSensorShutoffSystem(ODS).TheODS/
pilot is a required feature for vent-free room
heaters.TheODS/pilotshuts off the heater if
there is not enough fresh air.
PIEZO IGNITION SYSTEM
This heater has a piezo ignitor. This system
requires no matches, batteries, or other
sources to light heater.
Heater Controls
(Inside Door)
Screen
Logs
Stove
Cabinet

4
105684
VENT-FREE PROPANE/LP PEDESTAL STOVE
Today’s homes are built more energy effi-
cient than ever. New materials, increased
insulation, and new construction methods
help reduce heat loss in homes. Home
owners weather strip and caulk around
windowsanddoorsto keep the cold air out
andthewarmairin.Duringheatingmonths,
home owners want their homes as airtight
as possible.
Whileitisgoodtomakeyourhomeenergy
efficient,yourhomeneedstobreathe.Fresh
airmust enter your home.Allfuel-burning
appliances need fresh air for proper com-
bustion and ventilation.
Exhaust fans, heaters, clothes dryers, and
fuel burning appliances draw air from the
house to operate. You must provide ad-
equate fresh air for these appliances. This
will insure proper venting of vented fuel-
burning appliances.
Confined and Unconfined Space
The National Fuel Gas Code (ANS Z223.1,
1992 Section 5.3) defines a confined space
as a space whose volume is less than 50
cubicfeetper1,000Btuperhour(4.8m3per
kw) of the aggregate input rating of all
appliances installed in that space and an
unconfiningspaceasaspacewhosevolume
is not less than 50 cubic feet per 1,000 Btu
per hour (4.8 m3per kw) of the aggregate
inputratingofallappliancesinstalledinthat
space.Rooms communicatingdirectlywith
the space in which the appliances are in-
stalled*, through openings not furnished
with doors, are considered a part of the
unconfined space.
This heater shall not be installed in a con-
fined space or unusually tight construction
unlessprovisionsare provided for adequate
combustion and ventilation air.
*Adjoiningroomsarecommunicatingonly
iftherearedoorlesspassagewaysorventila-
tion grills between them.
WARNING: This heater shall
notbeinstalledinaconfinedspace
or unusually tight construction
unless provisions are provided
foradequatecombustionandven-
tilation air. Read the following in-
structions to insure proper fresh
air for this and other fuel-burning
appliances in your home.
PROVIDING ADEQUATE
VENTILATION
The following are excerpts from National
Fuel Gas Code. NFPA 54/ANS Z223.1, Sec-
tion5.3,AirforCombustionandVentilation.
Allspacesinhomesfallintooneofthethree
following ventilation classifications:
1. Unusually Tight Construction
2. Unconfined Space
3. Confined Space
The information on pages 4 through 6 will
help you classify your space and provide
adequate ventilation.
Unusually Tight Construction
The air that leaks around doors and win-
dows may provide enough fresh air for
combustion and ventilation. However, in
buildings of unusually tight construction,
you must provide additional fresh air.
Unusually tight construction is de-
fined as construction where:
a. walls and ceilings exposed to the
outside atmosphere have a con-
tinuous water vapor retarder with
a rating of one perm (6 x 10-11 kg
per pa-sec-m2) or less with open-
ings gasketed or sealed and
b. weather stripping has been
added on openable windows and
doors and
c. caulking or sealants are applied
to areas such as joints around
window and door frames, be-
tween sole plates and floors,be-
tween wall-ceiling joints, be-
tween wall panels, at penetra-
tionsfor plumbing,electrical,and
gas lines, and at other openings.
If your home meets all of the three
criteria above, you must provide ad-
ditional fresh air. See Ventilation Air
From Outdoors , page 6 .
If your home does not meet all of the
threecriteria above,proceed to Deter-
mining Fresh-Air Flow For Heater
Location, page 5 .
AIR FOR
COMBUSTION AND
VENTILATION

5
105684
OWNER’S MANUAL
DETERMINING FRESH-AIR FLOW FOR HEATER LOCATION
Determining if You Have a Confined or Unconfined Space
Use this worksheet to determine if you have a confined or unconfined space.
Space:Includestheroominwhichyouwillinstallheaterplusanyadjoiningroomswithdoorlesspassagewaysorventilationgrillsbetween
the rooms.
1. Determine the volume of the space (length x width x height).
Length x Width x Height = ____________________ cu. ft. (volume of space)
Example: Space size 20 ft. (length) x 16 ft. (width) x 8 ft. (ceiling height) = 2560 cu. ft. (volume of space)
If additional ventilation to adjoining room is supplied with grills or openings, add the volume of these rooms to the total volume of
the space.
2. Divide the space volume by 50 cubic feet to determine the maximum Btu/Hr the space can support.
_________________ (volume of space) ÷50 cu. ft. = (Maximum Btu/Hr the space can support)
Example: 2560 cu. ft. (volume of space) ÷50 cu. ft. = 51.2 or 51,200 (maximum Btu/Hr the space can support)
3. Add the Btu/Hr of all fuel burning appliances in the space.
Vent-free heater _________________Btu/Hr
Gas water heater* _________________Btu/Hr
Gas furnace _________________Btu/Hr
Vented gas heater _________________Btu/Hr
Gas heater logs _________________Btu/Hr
Other gas appliances* +_________________Btu/Hr
Total =_________________Btu/Hr
* Do not include direct-vent gas appliances. Direct-vent draws combustion air from the outdoors and vents to the outdoors.
4. Compare the maximum Btu/Hr the space can support with the actual amount of Btu/Hr used.
_________________ Btu/Hr (maximum the space can support)
_________________ Btu/Hr (actual amount of Btu/Hr used)
Example: 51,200 Btu/Hr (maximum the space can support)
56,000 Btu/Hr (actual amount of Btu/Hr used)
ThespaceintheaboveexampleisaconfinedspacebecausetheactualBtu/HrusedismorethanthemaximumBtu/Hrthespacecansupport.
You must provide additional fresh air. Your options are as follows:
A. Rework worksheet, adding the space of an adjoining room. If the extra space provides an unconfined space, remove door to adjoining
room or add ventilation grills between rooms. See Ventilation Air From Inside Building, page 6.
B. Vent room directly to the outdoors. See Ventilation Air From Outdoors, page 6.
C. Install a lower Btu/Hr heater, if lower Btu/Hr size makes room unconfined.
If the actual Btu/Hr used is less than the maximum Btu/Hr the space can support, the space is an unconfined space. You will need no
additional fresh air ventilation.
WARNING:Iftheareainwhichtheheatermaybeoperatedissmallerthanthatdefinedasanunconfinedspace
or if the building is of unusually tight construction, provide adequate combustion and ventilation air by one of
the methods described in the National Fuel Gas Code, ANS Z223.1, 1992, Section 5.3 or applicable local codes.
AIR FOR
COMBUSTION AND
VENTILATION
Continued
Example:
Gas water heater 30,000 Btu/Hr
Vent-free heater +26,000 Btu/Hr
Total = 56,000 Btu/Hr
Continued

6
105684
VENT-FREE PROPANE/LP PEDESTAL STOVE
AIR FOR
COMBUSTION AND
VENTILATION
Continued
Figure 3 - Ventilation Air from Outdoors
Ventilation Air From Outdoors
Provide extra fresh air by using ventilation
grills or ducts. You must provide two per-
manent openings: one within 12" of the
ceiling and one within 12" of the floor.
Connecttheseitemsdirectlytotheoutdoors
orspacesopentotheoutdoors.Thesespaces
include attics and crawl spaces. Follow the
National Fuel Gas Code NFPA 54/ANS
Z223.1,Section5.3,AirforCombustionand
Ventilation for required size of ventilation
grills or ducts.
IMPORTANT: Do not provide openings
for inlet or outlet air into attic if attic has
a thermostat-controlled power vent.
Heated air entering the attic will activate
the power vent.
Figure 2 - Ventilation Air from Inside Building
VENTILATION AIR
Ventilation Air From Inside
Building
Thisfreshairwouldcomefromanadjoining
unconfined space. When ventilating to an
adjoining unconfined space, you must pro-
vide two permanent openings: one within
12" of the ceiling and one within 12" of the
floor on the wall connecting the two spaces
(seeoptions1and2,Figure2).Youcanalso
remove door into adjoining room (see op-
tion 3, Figure 2). Follow the National Fuel
Gas Code NFPA 54/ANS Z223.1, Section
5.3, Air for Combustion and Ventilation for
required size of ventilation grills or ducts.
Outlet
Air Ventilated
Attic
Outlet
Air
Inlet
Air
Inlet Air Ventilated
Crawl Space
To
Crawl
Space
To Attic
Or
Remove
Door into
Adjoining
Room,
Option
3
Ventilation Grills
Into Adjoining Room,
Option 2
Ventilation
Grills
Into Adjoining
Room,
Option 1
12"
12"
WARNING: Rework work-
sheet, adding the space of the
adjoiningunconfinedspace.The
combined spaces must have
enough fresh air to supply all
appliances in both spaces.

7
105684
OWNER’S MANUAL
WARNING: Never install the
heater
• in a bedroom or bathroom
• in a recreational vehicle
• where curtains, furniture,
clothing, or other flammable
objectsarelessthan42inches
from the front, top, or sides of
the heater
• in high traffic areas
• in windy or drafty areas
INSTALLATION
WARNING: A qualified ser-
vice person must install heater.
Follow all local codes.
CAUTION: This heater cre-
ates warm air currents. These
currents move heat to wall sur-
faces next to heater. Installing
heater next to vinyl or cloth wall
coverings or operating heater
where impurities (such as to-
bacco smoke, aromatic candles,
cleaning fluids, oil or kerosene
lamps, etc.) in the air exist, may
discolor walls.
CHECK GAS TYPE
Useonlypropane/LPgas.Ifyourgassupply
is not propane/LP gas, do not install heater.
Call dealer where you bought heater for
proper type heater.
IMPORTANT: Vent-freeheatersaddmois-
ture to the air. Although this is beneficial,
installing heater in rooms without enough
ventilation air may cause mildew to form
from too much moisture. See Air for Com-
bustion and Ventilation, pages 4 through 6.
CLEARANCES TO
COMBUSTIBLES
(Vent-Free Operation Only)
WARNING:Maintainthemini-
mum clearances. If you can, pro-
vide greater clearances from
floor, ceiling, and adjoining side
and back walls.
Carefullyfollowtheinstructionsbelow.This
stove is a freestanding unit designed to set
directly on the floor. IMPORTANT: You
must maintain minimum wall and ceiling
clearances during installation. The mini-
mum clearances are shown in Figure 4.
Measure from outermost point of stove top.
Minimum Wall and Ceiling
Clearances (see Figure 4)
A. Clearances from outermost point of
stove top to any combustible side wall
should not be less than 12 inches.
B. Clearances from outermost point of
stove top to any combustible back wall
should not be less than 6 inches (In-
cludes corner installations).
C. Clearances from the stove top to the
ceiling should not be less than 48
inches.
NOTICE: This heater is intended
foruseassupplementalheat.Use
this heater along with your pri-
mary heating system. Do not in-
stall this heater as your primary
heatsource. Ifyou havea central
heating system, you may run
system’scirculatingblowerwhile
usingheater.Thiswillhelpcircu-
late the heat throughout the
house. In the event of a power
outage, you can use this heater
as your primary heat source.
Figure 4 - Minimum Clearance to Walls and Ceiling
Front View
Top View
Side View
Front of
Stove Unit
Continued
12"
Minimum 12" Minimum
48"
Minimum
Ceiling
Side Wall Side Wall
Back Wall
Side Wall Side Wall
12 "
Minimum 12
"
Minimum
6
"
Minimum
6"
Minimum
48"
Minimum
Ceiling
Floor
Back Wall
Corner
Wall
Wall
6 "
Minimum
6
"
Minimum

8
105684
VENT-FREE PROPANE/LP PEDESTAL STOVE
Tee
Joint
Pipe
Nipple
Cap
3" Minimum
Sediment
Trap Gas
Regulator
of Heater
From External
Regulator (11"
W.C.** to 14"
W.C. Pressure)
A.G.A. Design-Certified
Manual Shutoff Valve
With 1/8" NPT Tap* Approved Flexible
Gas Hose (if allowed
by local codes)
Figure 7 - Gas Connection
* Purchase the optional A.G.A. design-certified manual shutoff valve from your dealer.
See Accessories, page 21.
**Minimum inlet pressure for purpose of input adjustment.
CAUTION: Avoid damage to
regulator.Holdgasregulatorwith
wrenchwhenconnectingittogas
piping and/or fittings.
CAUTION: Use only new,
black iron or steel pipe. Inter-
nally-tinned copper tubing may
be used in certain areas. Check
yourlocalcodes.Usepipeof1/2"
diameter or greater to allow
proper gas volume to heater. If
pipe is too small, undue loss of
pressure will occur.
Installation must include a manual shutoff
valve, union, and plugged 1/8" NPT tap.
Locate NPT tap within reach for test gauge
hook up. NPT tap must be upstream from
heater (see Figure 7).
Apply pipe joint sealant lightly to male
threads. This will prevent excess sealant
fromgoinginto pipe. Excess sealant in pipe
could result in clogged heater valves.
WARNING: Never connect
heater to private (non-utility) gas
wells. This gas is commonly
known as wellhead gas.
CAUTION:Usepipejointseal-
ant that is resistant to liquid pe-
troleum (LP) gas.
Installsedimenttrapinsupplylineasshown
inFigure 7. Locate sedimenttrapwhereitis
within reach for cleaning. Locate sediment
trap where trapped matter is not likely to
freeze. A sediment trap traps moisture and
contaminants. This keeps them from going
into heater controls. If sediment trap is not
installed or is installed wrong, heater may
not run properly.
INSTALLATION
Continued
CONNECTING TO GAS
SUPPLY
WARNING:A qualifiedservice
personmustconnectheatertogas
supply. Follow all local codes.
Installation Items Needed
Beforeinstallingheater,makesureyouhave
the items listed below.
• piping (check local codes)
• sealant (resistant to propane/LP gas)
• manual shutoff valve *
• test gauge connection *
• sediment trap
• tee joint
• pipe wrench
* AnA.G.A.design-certifiedmanualshutoff
valve with 1/8" NPT tap is an acceptable
alternative to test gauge connection. Pur-
chase the optional A.G.A. design-certified
manual shutoff valve from your dealer. See
Accessories, page 21.
The installer must supply an external regu-
lator. The external regulator will reduce
incoming gas pressure. You must reduce
incominggaspressuretobetween11and14
inchesofwater.Ifyoudonotreduceincom-
ing gas pressure, heater regulator damage
could occur. Install external regulator with
the vent pointing down as shown in Figure
6. Pointing the vent down protects it from
freezing rain or sleet.
Figure 5 - Gas Regulator Location and
Gas Line Access Into Stove Cabinet
Front
of
Stove
Unit Gas Regulator
Inlet Connection
Back View
Side View
CAUTION: Never connect
heaterdirectlyto thepropane/LP
supply. This heater requires an
externalregulator(notsupplied).
Install the external regulator be-
tweentheheaterandpropane/LP
supply.
Figure 6 - External Regulator With Vent
Pointing Down
Propane/LP
Supply Tank External
Regulator
Vent
Pointing
Down

9
105684
OWNER’S MANUAL
INSTALLATION
Continued
WARNING:Neveruseanopen
flame to check for a leak. Apply a
mixture of liquid soap and water
toalljoints.Bubblesformingshow
a leak. Correct all leaks at once.
WARNING: Test all gas pip-
ing and connections for leaks
after installing or servicing. Cor-
rect all leaks at once.
CHECKING GAS
CONNECTIONS
Pressure Testing Gas Supply
Piping System
TestPressuresInExcessOf1/2PSIG
1. Disconnect heater and its individual
manual shutoff valve from gas supply
piping system. Pressures in excess of
1/2 psig will damage heater regulator.
2. Cap off open end of gas pipe where
manual shutoff valve was connected.
3. Pressurize supply piping system by ei-
ther using compressed air or opening
propane/LP supply tank valve.
4. Check all joints of gas supply piping
system. Apply mixture of liquid soap
and water to gas joints. Bubbles form-
ing show a leak.
5. Correct all leaks at once.
6. Reconnect heater and manual shutoff
valve to gas supply. Check reconnected
fittings for leaks.
CAUTION: Make sure exter-
nal regulator has been installed
between propane/LP supply and
heater.Seeguidelinesunder Con-
necting to Gas Supply , page 8.
TestPressuresEqualToorLessThan
1/2 PSIG
1. Close manual shutoff valve (see Fig-
ure 8).
2. Pressurizesupply piping system byeither
usingcompressedairoropeningpropane/
LP supply tank valve.
3. Checkalljointsfromgasmetertomanual
shutoff valve (see Figure 9). Apply mix-
tureofliquidsoapandwaterto gasjoints.
Bubbles forming show a leak.
4. Correct all leaks at once.
O
N
POSI
T
O
PO
S
Figure 8- Manual Shutoff Valve
Closed
Manual
Shutoff
Valve
Open
Figure 9 - Checking Gas Joints
Pressure Testing Heater Gas
Connections
1. Open manual shutoff valve (see Fig-
ure 8).
2. Open propane/LP supply tank valve.
3. Make sure control knob of heater is in
the OFF position.
4. Check all joints from manual shutoff
valve to control valve (see Figure 9).
Apply mixture of liquid soap and wa-
ter to gas joints. Bubbles forming show
a leak.
5. Correct all leaks at once.
6. Light heater (see Operating Heater,
pages 11 and 12). Check all other in-
ternal joints for leaks.
7. Turn off heater (see To Turn Off Gas to
Appliance, page 12).
Control Valve Location
Propane/LP
Supply Tank
Manual Shutoff Valve
Continued

10
105684
VENT-FREE PROPANE/LP PEDESTAL STOVE
O
F
F
P
I
L O
T
O
N
H
I
L
O
WARNING:Failuretoposition
thepartsinaccordancewiththese
diagrams or failure to use only
parts specifically approved with
this heater may result in property
damage or personal injury.
INSTALLING LOGS
Itisveryimportanttoinstallthelogsexactly
as instructed. Do not modify logs. Only use
logs supplied with heater.
Place one-piece log set on grate to fit as
illustrated in Figure 10. Make sure log sits
flat on firebox floor (see Figure 10).
IMPORTANT: Makesurelogdoesnotcover
any burner ports (see Figure 11).
CAUTION:Afterinstallationand
periodicallythereafter,checktoen-
surethatnoflamecomesincontact
with any log. With the heater set to
High,checktoseeifflamescontact
any log. If so, reposition logs ac-
cording to the log installation in-
structions in this manual. Flames
contacting logs will create soot.
Figure 10 - Installing One-Piece Log Set
One Piece
Log Set
Firebox Floor
Figure 11 - Installing One-Piece Log set
(Top View)
One Piece Log Set
Burner Ports
INSTALLATION
Continued
INSTALLING BLOWER
ACCESSORY - GA3750
Tools required: Phillips screwdriver
NOTICE:Shutoffgasheaterduring
the following blower installation.
1. Remove top panel of stove by remov-
ing three screws from under top lip on
each side of stove (see Figure 12).
2. Facing front of stove, carefully slidetop
panel forward until it is completely re-
moved from stove (see Figure 12).
3. Disconnectpowercordwiresfromblower
motor (if connected) (see Figure 13).
4. Disconnect green ground wire from
blower housing (if connected) by re-
moving screw holding wire terminal
(see Figure 13).
Figure 12 - Removing Stove Top Panel
5. Install one plastic bushing provided in
blower kit into the 1 1/2" hole in the left
rear of firebox floor. Access hole
through the rectangular opening in the
rear panel (see Figure 14).
6. Remove the two blower mounting
brackets from the rear panel by remov-
ing two screws each (see Figure 15).
7. Attach the two mounting brackets to
blower housing using four screws pro-
vided in blower kit (2 for each bracket)
(see Figure 15). Tighten screws se-
curely. Place blower assembly tempo-
rarily on top of firebox.
8. Working from the rear of the stove,
place entire power cord, including
speed control housing, in lower control
compartment.
9. Route ends of 3-wire power cord up
from the lower control compartment
through the plastic bushing, then up to
theuppercavity of stove (see Figure 16,
page 11).
10. Attach the terminal ends of the white
and black power cord wires to the ter-
minals on the blower motor (see Fig-
ure 13). Push firmly.
11. Attach the terminal end of the green
power cord wire to the front tab of the
blower housing using screw provided
(see Figure 13).
12. Using the four screws previously re-
moved, mount blower assembly to
stove by reattaching blower brackets to
rear panel (see Figure 15). Tighten
Figure 13 - Removing Wires from Blower
Figure 14 - Installing Bushing
Screw
Green
Ground Wire
White Powercord Wire
Figure 15 - Removing Blower Brackets
from Stove and Attaching to Blower
Blower
Blower
Bracket
Firebox Top
Black Powercord Wire

11
105684
OWNER’S MANUAL
INSTALLATION
Continued
OPERATING HEATER
FOR YOUR SAFETY
READ BEFORE
LIGHTING
WARNING: If you do not fol-
low these instructions exactly, a
fireorexplosionmayresultcaus-
ing property damage, personal
injury or loss of life.
A. Thisappliancehasapilot which must
belightedbyhand.Whenlightingthe
pilot,followthese instructionsexactly.
B. BEFORE LIGHTING smell all
aroundthe appliance areaforgas. Be
sureto smell nextto the floorbecause
some gas is heavier than air and will
settle on the floor.
WHATTODOIFYOUSMELLGAS
• Do not try to light any appliance.
• Donottouchany electric switch; do
notuseany phoneinyourbuilding.
• Immediatelycallyourgas supplier
from a neighbor’s phone. Follow
the gas supplier’s instructions.
• If you cannot reach your gas sup-
plier, call the fire department.
C. Useonlyyourhand to pushinorturn
thegascontrolknob. Neverusetools.
If the knob will not push in or turn
by hand, don’t try to repair it, call a
qualified service technician or gas
supplier. Force or attempted repair
may result in a fire or explosion.
D. Do not use this appliance if any part
hasbeenunderwater.Immediatelycall
aqualifiedservicetechniciantoinspect
the appliance and to replace any part
of the control system and any gas con-
trol which has been under water.
1. STOP! Read the safety information,
column 2.
2. Make sure manual shutoff valve is
fully open.
3. Turncontrolknobclockwise
Clockwise
to the OFF position.
Figure 18 - Control Knob and Ignitor
Button Location
4. Wait five(5) minutes to clear outany
gas. Then smell for gas, including
near the floor. If you smell gas,
STOP! Follow “B” in the safety in-
formation, column 2. If you don’t
smell gas, go to the next step.
5. Turn control knob counterclockwise
C-clockwise
to the PILOT position.
Press in control knob for five (5) sec-
onds (see Figure 18).
Note: You may be running this
heater for the first time after hook-
ing up to gas supply. If so, the con-
trol knob may need to be pressed in
for30seconds or less.This will allow
air to bleed from the gas system.
6. With control knob pressed in, press
and release ignitor button. This will
lightpilot.The pilot isattachedtothe
front burner. If needed, keep press-
ing ignitor button until pilot lights.
Note: If pilot does not stay lit, con-
tact a qualified service person or gas
supplierforrepairs.Untilrepairsare
made,lightpilot with match.Tolight
pilot with match, see Manual Light-
ing Procedure, page 12.
LIGHTING
INSTRUCTIONS
NOTICE: During initial operation
of new heater, burning logs will
give off a paper-burning smell.
Orange flame will also be present.
Opena windowtoventsmell.This
will only last a few hours.
Control Knob
Ignitor Button
screws securely.
13. Install plastic control knob onto output
shaftof speed controlhousing (see Fig-
ure 16). Place speed control housing
just inside control compartment door
in front of stove (see Figure 17).
14. Using two screws provided in blower
kit, mount blower speed control hous-
ingto mounting tabin left sideof lower
control compartment (see Figure 17).
15. Checkto make sure that the power cordis
completelyclearofblowerwheelandthere
are no foreign objects in blower wheel.
16. Carefully replace stovetop panel.Align
holesand replace six screws removedin
step 1, page 10.
17. Plugpowercordintoaconvenient3-prong
grounded wall receptacle near the stove.
18. Using speed control knob, turn blower
on and check for operation.
19. All remaining parts from blower kit
may be discarded.
Figure17-InstallingBlowerControlHousing
Power
Cord
Speed Control
Housing
Control
Knob
Figure 16 - Routing Power Cord
Blower Speed
Control Housing
Continued

12
105684
VENT-FREE PROPANE/LP PEDESTAL STOVE
Figure 19 - Pilot
7. Keep control knob pressed in for 30
seconds after lighting pilot.After 30
seconds, release control knob.
• Ifcontrolknobdoesnotpopoutwhen
released, contact a qualified service
person or gas supplier for repairs.
Note: If pilot goes out, repeat steps 3
through7.Thisheaterhasasafetyinter-
locksystem.Waitone(1)minuteforsys-
tem to reset before lighting pilot again.
8. Turn control knob counterclockwise
C-clockwise
to desired heating level. The
burnersshouldlight.Setcontrolknob
to any heat level between HI and LO.
TO TURN OFF GAS
TO APPLIANCE
1. Followsteps 1 through5under Light-
ing Instructions, page 11.
2. Depress control knob and light pilot
with match.
3. Keep control knob pressed in for 30
seconds after lighting pilot.After 30
seconds, release control knob. Now
follow step 8 in column 1.
Shutting Off Heater
Turn control knob clockwise
Clockwise
to
the OFF position.
Shutting Off Burners Only (pilot
stays lit)
Turn control knob clockwise
Clockwise
to
the PILOT position.
THERMOSTAT CONTROL
OPERATION
The thermostat control knob can be set to
any comfort level between Hi and Lo. The
thermostatwillgraduallymodulatetheheat
output and flame height from higher to
lowersettings, or pilot, in orderto maintain
the comfort level you select. The ideal com-
fort setting will vary by household depend-
ing upon the amount of space to be heated,
theoutputofthecentralheatingsystem,etc.
Note: Selecting the Hi setting with the
control knob will cause the burners to
remainfullyon,withoutmodulatingdown
in most cases.
MANUAL LIGHTING
PROCEDURE
Thermocouple
Pilot Burner
OPERATING
HEATER
Continued
INSPECTING
BURNERS
Check pilot flame pattern and burner flame
patterns often.
PILOT FLAME PATTERN
Figure 20 shows a correct pilot flame pat-
tern.Figure21showsanincorrectpilotflame
pattern.Theincorrectpilotflameisnottouch-
ing the thermocouple. This will cause the
thermocouple to cool. When the thermo-
couple cools, the heater will shut down.
If pilot flame pattern is incorrect, as shown
in Figure 21
• turn heater off (see To Turn Off Gas to
Appliance)
• seeTroubleshooting, pages 14 through16
Figure 20 - Correct Pilot Flame Pattern
Figure 21 - Incorrect Pilot Flame Pattern
Thermocouple
Pilot Burner
Pilot Burner
Thermocouple
CAUTION:Donottrytoadjust
heating levels by using the
manual shutoff valve.

13
105684
OWNER’S MANUAL
CLEANING AND
MAINTENANCE
WARNING: Turn off heater
and let cool before cleaning.
CAUTION:You mustkeep con-
trol areas, burner, and circulating
air passageways of heater clean.
Inspect these areas of heater be-
fore each use. Have heater in-
spected yearly by a qualified ser-
viceperson.Heatermayneedmore
frequentcleaningduetoexcessive
lint from carpeting, pet hair, etc.
CABINET
Air Passageways
• Use a vacuum cleaner or pressurized air
to clean.
Exterior
• Use a soft cloth dampened with a mild
soap and water mixture. Wipe the cabi-
net to remove dust.
LOGS
• If you remove logs for cleaning, refer to
Installing Logs, page 10, to properly re-
place logs.
• Replace log(s) if broken or chipped
(dime-sized or larger).
REPLACEMENT
PARTS
Note: Use only original replacement parts.
This will protect your warranty coverage
for parts replaced under warranty.
PARTS UNDER WARRANTY
Contact authorized dealers of this product.
If they can’t supply original replacement
part(s)callDESAInternational’sTechnical
Service Department at 1-800-323-5190 for
referral information.
WhencallingDESAInternational,haveready
• your name
• your address
• model and serial numbers of your heater
• how heater was malfunctioning
• typeofgasused(propane/LPornaturalgas)
• purchase date
Usually,wewillaskyoutoreturnthedefec-
tive part to the factory.
PARTS NOT UNDER
WARRANTY
Contact authorized dealers of this product
or Parts Central (see page 17). If they can’t
supply original replacement part(s) call
DESA International’s Parts Department at
1-800-972-7879 for referral information.
WhencallingDESAInternational,haveready
• model number of your heater
• the replacement part number
CLEANING BURNER
INJECTOR HOLDER AND
PILOT AIR INLET HOLE
The primary air inlet holes allow the proper
amount of air to mix with the gas. This
provides a clean burning flame. Keep these
holesclearofdust,dirt,andlint.Cleanthese
air inlet holes prior to each heating season.
Blocked air holes will create soot. We rec-
ommendthat you clean theunitevery2,500
hours of operation or every three months.
Wealsorecommendthatyoukeeptheburner
tubeandpilotassemblycleanandfreeofdust
anddirt.Toclean these parts we recommend
usingcompressed air no greater than 30 PSI.
Yourlocalcomputerstore,hardwarestore,or
home center may carry compressed air in a
can. You can use a vacuum cleaner in the
blow position. If using compressed air in a
can, please follow the directions on the can.
Ifyoudon'tfollowdirectionsonthecan, you
could damage the pilot assembly.
1. Shut off the unit, including the pilot.
Allow the unit to cool for at least thirty
minutes.
2. Inspect burner, pilot, and primary air
inlet holes on injector holder for dust
and dirt (see Figure 22).
3. Blow air through the ports/slots and
holes in the burner.
4. Check the injector holder located at the
endof the burnertubeagain.Removeany
largeparticlesofdust,dirt,lint,orpethairs
withasoftclothorvacuumcleanernozzle.
Figure 22 - Injector Holder On Outlet
Burner Tube
5. Blow air into the primary air holes on
the injector holder.
6. In case any large clumps of dust have
now been pushed into the burner repeat
steps 3 and 4.
Clean the pilot assembly also. A yellow tip on
thepilotflameindicatesdustanddirtinthepilot
assembly. There is a small pilot air inlet hole
about two inches from where the pilot flame
comesoutofthepilotassembly(seeFigure23).
Withtheunitoff,lightlyblowairthroughtheair
inlet hole. You may blow through a drinking
straw if compressed air is not available.
Burner
Tube Injector Holder
(May Be Brass
or Aluminum
Depending on
Model)
Primary Air Inlet
Holes (Shape of
Holes May Vary
by Model)
Figure 23 - Pilot Inlet Air Hole
Burner
Tube
Pilot
Assembly
Pilot Air
Inlet
Hole
Ports/Slots
MAIN BURNER
Periodically inspect all burner flame holes
with the heater running. All slotted burner
flame holes should be open with yellow
flame present. All round burner flame holes
should be open with a small blue flame
present. Some burner flame holes may be-
comeblockedbydebrisorrust,withnoflame
present. If so, turn off heater and let cool.
Either remove blockage or replace burner.
Blocked burner flame holes will create soot.
Reviewyourvideoincludedwithyourheater
for additional cleaning instructions.

14
105684
VENT-FREE PROPANE/LP PEDESTAL STOVE
TROUBLESHOOTING WARNING: Turn off heater
andletcoolbeforeservicing.Only
aqualifiedservicepersonshould
service and repair heater.
CAUTION: Never use a wire,
needle, or similar object to clean
ODS/pilot.ThiscandamageODS/
pilot unit.
POSSIBLE CAUSE
1. Ignitor electrode not connected to igni-
tor cable
2. Ignitor cable pinched or wet
3. Piezo ignitor nut is loose
4. Broken ignitor cable
5. Bad piezo ignitor
6. Ignitor electrode broken
7. Ignitor electrode positioned wrong
1. Gas supply turned off or manual shutoff
valve closed
2. Control knob not in PILOT position
3. Control knob not pressed in while in
PILOT position
4. Air in gas lines when installed
5. Depleted gas supply
6. ODS/pilot is clogged
7. Gas regulator setting is not correct
1. Control knob not fully pressed in
2. Control knob not pressedin long enough
3. Manual shutoff valve not fully open
4. Pilot flame not touching thermocouple,
which allows thermocouple to cool,
causing pilot flame to go out. This prob-
lem could be caused by one or both of
the following:
A) Low gas pressure
B) Dirty or partially clogged ODS/pilot
5. Thermocouple connection loose at con-
trol valve
6. Thermocouple damaged
7. Control valve damaged
REMEDY
1. Reconnect ignitor cable
2. Free ignitor cable if pinched by any
metal or tubing. Keep ignitor cable dry
3. Tighten nut holding piezo ignitor to base
panel of log set. Nut is located behind
base panel
4. Replace ignitor cable
5. Replace piezo ignitor
6. Replace piezo ignitor
7. Replace piezo ignitor
1. Turn on gas supply or open manual
shutoff valve
2. Turn control knob to PILOT position
3. Press in control knob while in PILOT
position
4. Continue holding down control knob.
Repeat igniting operation until air is re-
moved
5. Contact local propane/LP gas company
6. Clean ODS/pilot (see Cleaning and
Maintenance, page 13) or replace ODS/
pilot assembly
7. Replace gas control
1. Press in control knob fully
2. After ODS/pilot lights, keep control
knob pressed in 30 seconds
3. Fully open manual shut-off valve
4. A)Contact localpropane/LPgascompany
B) Clean ODS/pilot (see Cleaning and
Maintenance, page 13) or replace ODS/
pilot assembly
5. Hand tighten until snug, then tighten 1/4
turn more
6. Replace thermocouple
7. Replace control valve
OBSERVED PROBLEM
When ignitor button is pressed, there is no
spark at ODS/pilot
When ignitor button is pressed, there is
spark at ODS/pilot but no ignition
ODS/pilot lights but flame goes out when
control knob is released
Note: For additional help, visit DESA
International’s Technical Service web
site at www.desatech.com.
Note: Alltroubleshootingitemsarelistedin
order of operation.
www.desatech.com

15
105684
OWNER’S MANUAL
TROUBLESHOOTING
Continued
OBSERVED PROBLEM
Burner does not light after ODS/pilot is lit
Delayed ignition burner
Burner backfiring during combustion
Slight smoke or odor during initial operation
Moisture/condensation noticed on windows
Heater produces a whistling noise when
burner is lit
Dark residue on logs or inside of fireplace
Whitepowderresidueformingwithinburner
box or on adjacent walls or furniture
REMEDY
1. Clean burner (see Cleaning and Mainte-
nance, page 13) or replace burner orifice
2. Contact local propane/LP gas company
3. Replace burner orifice
4. Reconnect leads (see wiring diagram)
5. Replacebatteryin transmitter and receiver
1. Contact local propane/LP gas company
2. Clean burner (see Cleaning and Mainte-
nance, page 13) or replace burner orifice
1. Clean burner (see Cleaning and Mainte-
nance, page 13) or replace burner orifice
2. Replace damaged burner
3. Replace gas control
1. Check burner for dirt and debris. If found,
clean burner (see Cleaning and Mainte-
nance, page 13)
2. Replace gas control
3. Problem will stop after a few hours of
operation
1. Refer to Air for Combustion andVentila-
tion requirements (page 4)
1. Turn control knob to LO position and let
warm up for a minute
2. Operate burner until air is removed from
line. Have gas line checked by local pro-
pane/LP gas company
3. Observe minimum installation clearances
(see pages 7 through 9)
4. Clean burner (see Cleaning and Mainte-
nance, page 13) or replace burner orifice
1. Properly locate logs (see Installing Logs,
page 10)
2. Eliminate source of drafts around heater
3. Clean out air holes at burner inlet. Peri-
odically repeat as needed
4. Remove blockage or replace burner
1. Turn heater off when using furniture pol-
ish, wax, carpet cleaners, or similar
products
POSSIBLE CAUSE
1. Burner orifice clogged
2. Inlet gas pressure is too low
3. Burner orifice diameter is too small
4. Thermopile leads disconnected or im-
properly connected
5. Burnerswillnot comeoninremoteposition
1. Manifold pressure is too low
2. Burner orifice clogged
1. Burner orifice is clogged or damaged
2. Damaged burner
3. Gas regulator defective
1. Not enough air
2. Gas regulator defective
3. Residues from manufacturing processes
and logs curing
1. Not enough combustion/ventilation air
1. Turning control knob to HI position when
burner is cold
2. Air in gas line
3. Air passageways on heater blocked
4. Dirty or partially clogged burner orifice
1. Improper log placement
2. Drafts or other air currents affecting
flame pattern
3. Air holes at burner inlet blocked
4. Burner flame holes blocked
1. When heated, vapors from furniture pol-
ish, wax, carpet cleaners, etc. turn into
white powder residue
www.desatech.com Continued

16
105684
VENT-FREE PROPANE/LP PEDESTAL STOVE
WARNING: If you smell gas
• Shut off gas supply.
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your
building.
• Immediatelycallyourgassupplierfromaneighbor’sphone.Followthe
gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire department.
POSSIBLE CAUSE
1. Metal expanding while heating or con-
tracting while cooling
1. Heater burning vapors from paint, hair
spray, glues, cleaners, chemicals, new
carpet, etc. (See IMPORTANT state-
ment above)
2. Gas leak. SeeWarning statement at
top of page
1. Not enough fresh air is available
2. Low line pressure
3. ODS/pilot is partially clogged
1. Gas leak. SeeWarning statement at
top of page
2. Control valve defective
1. Foreign matter between control valve
and burner
2. Gas leak. SeeWarning statement at
top of page
OBSERVED PROBLEM
Heater produces a clicking/ticking noise
just after burner is lit or shut off
Heater produces unwanted odors
Heater shuts off in use (ODS operates)
Gas odor even when control knob is in OFF
position
Gas odor during combustion
REMEDY
1. This is common with most heaters. If
noise is excessive, contact qualified ser-
vice person
1. Open window and ventilate room. Stop
usingodorcausing products while heater
is running
2. Locate and correct all leaks (see Check-
ing Gas Connections, page 9)
1. Open window and/or door for ventilation
2. Contact local propane/LP gas company
3. Clean ODS/pilot (see Cleaning and
Maintenance, page 13)
1. Locate and correct all leaks (see Check-
ing Gas Connections, page 9)
2. Replace control valve
1. Take apart gas tubing and remove for-
eign matter
2. Locate and correct all leaks (see Check-
ing Gas Connections, page 9)
IMPORTANT: Operating heater where impurities in air exist may create odors. Cleaning
supplies, paint, paint remover, cigarette smoke, cements and glues, new carpet or textiles,
etc.,createfumes.Thesefumesmaymixwithcombustionairandcreateodors.Theseodors
will disappear over time.
TROUBLESHOOTING
Continued
www.desatech.com

17
105684
OWNER’S MANUAL
TECHNICAL
SERVICE
You may have further questions about in-
stallation, operation, or troubleshooting.
If so, contact DESA International’s Techni-
calServiceDepartmentat1-800-DESALOG
(1-800-337-2564).
You can also visit DESA International’s
Technical Services web site at
www.desatech.com.
SPECIFICATIONS
When Gas Pressure Is Too Low
• pilot will not stay lit
• burners will have delayed ignition
• heater will not produce specified heat
• propane/LP gas supply may be low
When Gas Quality Is Bad
• pilot will not stay lit
• burners will produce flames and soot
• heater will backfire when lit
Youmayfeelyourgaspressureistoolowor
gas quality is bad. If so, contact your local
propane/LP gas supplier.
SERVICE HINTS
PARTS CENTRALS Tarantin Tank Co.
P.O. Box 6129
Freehold, NJ 07728-6129
908-780-9340
1-800-922-0724
Parts Department
Heater & Heater Store
1922 N Route 9
Cape May Court, NJ 08210-1110
609-624-0678
Parts Department
Dayton Hardware
P.O. Box 275
North Dayton Station
Dayton, OH 45404-0275
All States
937-258-3721
Parts Department
1-800-762-3426
Halco Enterprises
208 Carter Drive, Unit 21
West Chester, PA 19382-4500
610-430-7717
1-800-368-0803
Parts Department
LaPorte’s Parts & Service
2444 North 5th Street
Hartsville, SC 29550-7704
803-332-0191
Parts Department
Cans Unlimited, Inc.
P.O. Box 645
Taylor, SC 29687-0013
All States
803-879-3009
1-800-845-5301
Parts Department
Baltimore Electric
1348 Dixwell Avenue
Hamden, CT 06514-0322
1-800-397-7553
203-248-7553
Parts Department
Portable Heater Parts
342 N. County Rd. 400 East
Valparaiso, IN 46383-9704
All States
219-462-7441
1-800-362-6951
Parts Department
FBD
1349 Adams St.
Bowling Green, KY 42103-3413
502-846-1199
1-800-654-8534
Fax: [phone]
Four Flags Power Products
1115 Stateline Road
Niles, MI 49120-4728
616-684-2697
1-800-268-4983
Parts Only
Master Parts Distributors
1251 Mound Ave. NW
Grand Rapids, MI 49504-3458
616-791-0505
Fax: [phone]
Parts Department
1-800-446-1446
Washer Equipment Co.
1715 Main Street
Kansas City, MO 64108-2195
KS, MO, AR
816-842-3911
Parts Department
East Coast Energy Products
707 Broadway
W. Long Branch, NJ 07764-1542
732-870-8809
1-800-755-8809
Parts Department
These Parts Centrals are privately owned
businesses.Theyhaveagreedtosupportour
customer’s needs by providing original re-
placement parts and accessories.
Btu (Variable) 20,000/26,000
Type Gas Propane/LP Only
Ignition Piezo
Manifold Pressure 8" W.C.
Inlet Gas Pressure
(in. of water) *
Maximum 14"
Minimum 11"
Dimensions, Inches (H x W x D)
Stove 24 x 27 1/4x 17 1/4
Carton 22 x 31 x 31 1/2
Weight, pounds
Stove 66 lbs.
Shipping 80 lbs.
* For purposes of input adjustment

18
105684
VENT-FREE PROPANE/LP PEDESTAL STOVE
ILLUSTRATED
PARTS
BREAKDOWN
S26PT
5
7
6
9
4
10 3
2
1
13
14
12 11
10
8

19
105684
OWNER’S MANUAL
PARTS LIST
S26PT
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts on page 13 of this manual.
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 105441-01 Log Set 1
2 L98310-01 ODS Pilot (LP) 1
3 098249-01 ODS Nut 2
4 105973-01 Burner Outlet Tube 1
5 105737-02 Injector Holder 1
6 102843-01 Burner Clip 1
7 099056-28 Burner Orifice Injector 1
8 101329-26 Gas Control Valve 1
9 L98305-01 Burner 1
10 099387-09 Pilot Tube 1
11 098271-07 Ignitor Cable 1
12 L98300-01 Piezo Ignitor and Cover 1
13 L98303-02 Regulator 1
14 105972-01 Inlet Tube 1
PARTS AVAILABLE — NOT SHOWN
100563-01 Warning Plate 1
101054-01 Lighting Instructions Plate 1

20
105684
VENT-FREE PROPANE/LP PEDESTAL STOVE
ILLUSTRATED
PARTS
BREAKDOWN
S26PT
1
4
13
3
2
14
7
16
15
11
18
10
5
6
9
8
17
12
