Comica CVM-VM20 User manual

CVM-VM20
Multi-Functional Super Cardioid Condenser Shotgun Microphone
USER MANUAL

Foreword
Main Features
Thanks for purchasing COMICA CVM-VM20 Super Cardioid Condenser
Microphone.
To ensure bring you a good using experience, please read this manual book
carefully before using and correctly install and operate.
. 75/150Hz Two Low-cut Filter Modes
. Adjustable Stepless Gain Control
. OLED Visualized Power
. Universal for Devices with 3.5mm TRS/TRRS and XLR Interface
. USB-C Rechargeable Built-in Lithium Battery, Support Working while Charging
. Full Metal Material Construction, Super Shielding, Stable and Durable
Notice
When it needs to be used for a long time, it can be connected to the external
power to realize charging while using. AC/DC power is not supported to avoid
noise problem
Do not use this equipment in the vicinity of heat source or interference source
This product belongs to high-precision instruments, please avoid falling,
collision or pounding
Do not use the equipment in rain or in a damp environment to avoid
short-circuit danger
After using, please pay attention to turn off the device for storage
1

Packing List
1. Microphone
2. Shock Mount
3. Windscreen
4. Wind Muff
5. 3.5mm TRS-TRS Audio Cable
6. 3.5mm TRS-TRRS Audio Cable
7. Charging Cable
8. Carry Case
9. User Manual
10. Warranty Card
① ② ③
④
⑧ ⑨ ⑩
⑤ ⑥ ⑦
CVM-VM20
Multi-Functional Super Cardioid Condenser Shotgun Microphone
USER MANUAL
2

Components Introduction
①
②
⑧
⑨
⑥
⑦
③④
⑤
Microphone
1. Mic Capsule
2. Low Cut Filter Button
3. Power Button
4. Battery Level Display Screen
5. Gain Control Knob
6. Low Cut Filter Indicator Light
7. Power Indicator Light
8. USB-C Charging Port
9. 3.5mm TRS Audio Output Port
3

Installation and Operation
1. Work with Camera
1.1 Install the Microphone to Shock Mount
1.2 Connect the Shock Mount to hot shoe of camera through cold shoe of Shock Mount
Cold Shoe
Hot Shoe
4

1.3 Connect microphone and camera through 3.5mm TRS - TRS Audio Cable
When work with camcorder with XLR interface, please purchase
3.5mm TRS-XLR audio cable by yourself
5

2. Work with Phone
2.1 Install the Microphone to Shock Mount; connect the Shock Mount to cold
shoe extension ( Please prepare the grip kit by yourself )
2.2 Connect microphone and smartphone through 3.5mm TRS - TRRS Audio
Cable; 3.5mm TRS plug is for microphone, 3.5mm TRRS plug is for
smartphone
Cold Shoe
Cold Shoe Extension
TRS Plug
TRRS Plug
6

Function and Usage
1. Power Button
2. Low Cut Filter Button
3. Battery Level Display Screen
4. Gain Control Knob
5. USB-C Charging Port
6. 3.5mm TRS Audio Output Port
Short press for On/Off; the Power Indicator Light is blue when turn on it, the
light is red when low battery
Short press for switching Low Cut Filter. There are turn off, 75Hz, 150Hz three
levels for switching. The Low Cut Filter Indicator Light is blue when choosing
75Hz or 150Hz level
It will display the battery status of microphone
Rotate Gain Control Knob to adjust the gain of microphone
Connect external power supply to charge the microphone through USB-C
Charging port; support working while charging for extending the working time
85%
It can be inserted with 3.5mm TRS audio cable for audio output
7

Polar Pattern
Frequency Response
Low-cut
Sensitivity Range
S/N
Maximum SPL
Output Form
Power
Size
Net Weight
Operating Temperature
Storage Temperature
Super Cardioid
20Hz ~ 20KHz
75Hz / 150Hz
-43dB ~ -23dB
>75dB
>105dB
3.5mm TRS
Li-ion Battery 3.7V 300mAh
Φ22mm x L 177mm
84g
0℃~ 50℃
-10℃~ 60℃
Specification
8

CVM-VM20
多功能超心型电容枪式麦克风
用户使用手册

前 言
产品主要功能
感谢您购买科唛COMICA CVM-VM20超心型指向电容式麦克风。
使用前请认真阅读此使用说明书，本产品在出厂时已进行精密校准，请勿自行组
装拆卸零部件，否则不予保修！
.75Hz/150Hz两档低切模式
.无级增益可调
.OLED可视化电量
.通用于3.5mmTRS/TRRS,卡侬接口的设备
.USB-C可充电内置锂电池，支持边充边用
.全金属结构，超强屏蔽，稳固耐用
注意事项
当需要长时间使用时，可连接外部移动电源实现边充边用；不支持AC/DC电源
供电，否则会产生噪音
使用时请远离热源或干扰源
使用时请避免掉落，碰撞或重击
请勿在下雨或潮湿环境中使用，否则会有短路的危险
使用完成后，请注意关机后再进行存放
1

包装清单
1. 麦克风主体
2. 支架
3. 防风棉
4. 防风毛
5. 3.5mm TRS-TRS音频线
6. 3.5mm TRS-TRRS音频线
7. 充电线
8. 便携包
9. 说明书
10. 保修卡
① ② ③
④
⑧ ⑨ ⑩
⑤ ⑥ ⑦
CVM-VM20
Multi-Functional Super Cardioid Condenser Shotgun Microphone
USER MANUAL
2

部件介绍及说明
①
②
⑧
⑨
⑥
⑦
③④
⑤
麦克风主体
1. 拾音头
2. 低切选择开关
3. 电源键
4. 电量显示屏
5. 增益调节旋钮
6. 低切指示灯
7. 电源指示灯
8. USB-C充电插口
9. 3.5mm TRS音频输出插口
3

安装方法
1.搭配相机安装方法
1.1 把麦克风主体装到支架上
1.2 通过冷靴座把支架装到相机热靴上
冷靴座 热靴
4

1.3 通过3.5mm TRS-TRS音频线连接麦克风与相机
当用作XLR接口的摄像机时，请单独购买
3.5mm TRS-XLR音频线即可使用 5

2.搭配手机安装方法
2.1 参照前面的方法把麦克风主体装到支架上，再通过冷靴座把支
架装到手柄冷靴上（手柄套装请自行配备）
2.2 通过3.5mm TRS-TRRS音频线连接麦克风与手机，注意TRS插头
连接麦克风，TRRS插头连接手机
冷靴座
手柄冷靴
TRS插头
TRRS插头
6
