Comica CVM-WS50H User manual

FOR SMARTPHONE
CVM-WS50
USER MANUAL
Multi-channels Smartphone Wireless Microphone

Specification
6
520.00MHz ~ 526.00MHz
15dBm
Channels
Wireless Frequency
Transmitting Power
Lavalier Transmitter (TX) :
6
520.00MHz ~ 526.00MHz
15dBm
Channels
Wireless Frequency
Transmitting Power
6
520.00MHz ~ 526.00MHz
Channels
Wireless Frequency
Receiver:
Hand-held Transmitter (HTX) :

Foreword
Thank you for purchasing Comica WS50 multi-channels smartphone wireless
microphone.
WS50 is a creative wireless microphone for smartphone with built-in mobile phones
holders. With built-in lithium polymer batteries, it uses UHF wireless technology and
high-resolution LCD code screen, stepless adjustable volume at receiving end, and
integrated into power monitoring, audio dynamic display bar, real-time monitoring and
other functions; the working distance is up to 60 meters (30 meters in barrier area), it
can assist your phone for video recording and achieve professional sound effects.
To ensure the smooth use and safety of the products, please read this user manual
carefully before using and properly assemble and operate.
1

Main Features
. Working Distance Up to 60m (In Open Area, 30m in Barrier Area) ；
. Built-in Metal Material Smartphone Holder；
. LCD Screen for Displaying Channels and Audio Status；
. Stepless Volume Adjustment；
. Real-time Audio Monitor；
. Extendable for Connection with LED Light, Grip, Tripod, Cold-shoe, etc；
. Built-in Rechargeable Lithium Batteries；
. Portable and Light；
Working Distance
Up to 60m
Built-in
Smartphone Holder
Stepless Volume
Adjustment
Real-time
Audio Monitor
Lithium Batteries LCD Screen
60M
2

. This product is compatible with both IOS and Android system, and when used with the
iphone 7 or above, you need to use the original adapter cable;
. For smart phones with IOS system (Iphones), this Mic works well either in Audio or
Video mode;
. For the smart phones with Android system, this Mic works well in audio mode, it may not
be compatible with partial smart phones in video mode (Then we suggest you to try the
3rd party APP);
. To avoid signal interference during usage, please set the phone to flight mode;
. The working distance will be affected by the surrounding environment. In the process,
please try to make sure the environment is barrier free and turn off the WIFI of your
smart phone;
. During usage, the receiver should not be close to other UHF transmitters, radio stations
and other devices which may cause interference;
. Please keep this product in dry environment;
. Do not expose the device in rain or humid environment, or there will be a danger of
short circuit;
Notice
3

Packing List
Main Body:
Accessories:
Lavalier Transmitter (TX)
WS50(A)=
WS50(B)=
WS50(C)=
WS50(H)=
ReceiverHand-held Transmitter (HTX) Ordinary GripElectronic Grip Tripod on Table
1. 3.5mm Audio Mic
2.TRRS Audio Output Cable
3. USB Charging Cable
4. Belt Clip
5. Wind Muff
6. Portable Case
7. User Manual
8. Warranty Card
1
1 2 3 4 5 6
1 3 4
2 3 4
5 6 7 8
FORSMARTPHONE
CVM-WS50
USER MANUAL
Multi-channels Smartphone Wireless Microphone
+
1 3 5
+
1 3 6
+
2 3 5
+
+
+
+
+
4

Components
Lavalier Transmitter(TX)
1.Set Button for Channel Selection
2.On-off/Muting Button
3.Working Status Indicator Light
4.Mic / LINE Input Socket/ Reset Hole
5.Micro USB Charging Socket
6.Belt Clip Hole
7.1/4 Thread at the Back
Components and Instruction
2
1
3
4
5
7
6
The function of reset hole：When function
program of the product is disorganized and
unable to make normal adjustment or even
shutdown, you can use an appropriate
taper tool to insert the reset hole to realize
the function reset.
5

Hand-held Transmitter(HTX)
1. Microphone
2. LCD Display
3. Power /CH Setting Button
4. ‘Low Cut/Normal’ Audio Switch
5. AA Battery Holder
1
2
3
5
4
6

3
4
5
67
1
2
9
8
10
11
Receiver
1.Set Button for Channel Selection
2.Adjusting Screw
3.On/Off Button
4.Working Status Indicator Light
5.3.5mm Audio Output Socket/ Reset Hole
6.Micro USB Charging Socket
7.3.5mm Monitoring Socket
8.Smartphone Clamp
9.1/4 Thread at the bottom
10.1/4 Thread at the top
11.Volume Adjusting Button
External light and other equipment can be
used on 1/4 thread at the top; Grip can be
used for 1/4 thread at the bottom.
The function of reset hole：When function
program of the product is disorganized and
unable to make normal adjustment or even
shutdown, you can use an appropriate
taper tool to insert the reset hole to realize
the function reset.
7

1
2
Ordinary Grip
1. 1/4 Screw Thread
2. 1/4 Thread at the Bottom
8

Electronic Grip
1. 1/4 Screw Thread
2. Adjustable Screw
3. 1/4 Thread at the Bottom
4. Bluetooth Remote Controller
5. On-off/Function Button of the Remote Controller
1
2
3
4
5
The bluetooth remote controller can be taken down for remote control；
Bluetooth remote controller supports both IOS and Android system；
9

1
2
4
3
Tripod on Table
1. 1/4 Screw Thread
2. Adjustable Screw
3. Stretchable Tripods
4. Direction Control Switch
10

Screen Display Instruction
Lavalier Transmitter(TX):
Normal Recording
Muting Power Indication
Channel
Audio Dynamic Display Bar
Hand-held Transmitter:
Normal Recording Power Indication
Channel
11

Receiver:
Normal recording Power Indication
Channel
Audio Dynamic Display Bar
12

Function Button Instruction
Insert the Mic line for audio recording /
Insert a small object like a pin for reset
Channel Selection
（Take effect when the screen is lighted up）
Audio Recording /
Reset
Lavalier
Transmitter
On-off//Muting Button
Long Press
Short Press
Short Press
Power On/Off
Muting Mode (Take effect when the screen is
lighted up）
Set Button
MIC / LINE Reset
MIC/LINE Input /
Reset Hole
Long Press
Short Press
Left
Right
Power On/Off
Channel Sequence Switch
Low-cut
Normal
Power /CH Setting Button
“Low Cut/ Normal” Audio
Switch
Hand-held
Transmitter
13

Dial the wheel to
the left/ right Volume Adjustment
Insert the Mic line for audio output /
Insert a small object like a pin for reset
Short Press
Power On/Off
Channel Selection
(Take effect when the screen is lighted up)
Audio Output /
Reset
Long PressOn-off Button
Set Button
OUTPUT Reset
Audio Output /
Reset Hole
Volume Adjustment Wheel
Receiver
Long Press for 2
Seconds
Long Press for 6
Seconds
10 minutes later
In photo mode, press for photo shooting; In
video recording mode, first press to start,
press again to finish
Continuous Capture for 3 Seconds
Reset to default, can be matched with
different smartphone
Auto Power-Off
Long Press for 2
Seconds
Short Press
Power On
On-off Button
Matched with the Smartphone
No Operation
Electronic
Grip
14

Indicator Light Instruction
Lavalier
Transmitter
Green Light Keeps On
Receiver
Electronic Grip
Red Light Keeps On
Red Light Flickers
Green Light Flickers
Green Light Keeps On
Red Light Flickers
Blue Light Flickers
(After the grip turned on)
Green Light Flickers
Normal Working Status
Muting Mode
Low-power reminder
Channel doesn’t match with the transmitter
Channels matches
Low-power reminder
Grip doesn’t match with the smartphone
Taking pictures/Video Recording
15

1.Connect the belt clip to the connection hole
2.Long press the power button to turn on the Lavalier Transmitter
According to different environment you could short
press ‘Power/Muting Button’ to enter the MUTE mode.
Installation and Usage
Lavalier Transmitter(TX):
Power / Muting Button
16

Audio Dynamic Display Bar
3.Insert the 3.5mm audio input line into the “Mic”socket
4.Target the Mic to the audio source and check whether the Lavalier Transmitter is
working properly according to the audio display bar on the screen
“Mic”socket
17

Channel
5. Short press set button to select the channel
“set”button
18
