Command access ARLP88-KIT User manual

A.
#2 Phillips head screwdriver
KIT INCLUDES | TOOLS REQUIRED
A. 1- Solenoid Mount w/ 4
Screws
B. 1- Plunger Bracket
C. 1- Silcon Washer
D. 1 - Power Connector
E. 1- 8’ Lead
ARLP88-KIT
INSERT Instructions
The Command Access ARLP88-KIT is a eld-installable solenoid latch-pullback
kit for the Adams Rite 8800 series devices.
#20431_A
US customer support 1-888-622-2377 | www.commandaccess.com | CA customer support 1-855-823-3002
B. C. D.
Install VIdeo
SPECIFICATIONS
• Input Voltage: 24VDC +/- 10%
• Wire gauge: Minimum 18 gauge
• Direct wire run - no relays or access
control units in-between power
supply & module
E.

Ceiling Tile
Legend
Standard Placement
Module
GREEN
CHANNEL 1
LED
NORMALLY OPEN
DRY CONTACT FROM
ACCESS CONTROL
SYSTEM
NO VOLTAGE
LOCKING
HARDWARE
+
-
CAT
Electrified Exit Device
INSTALLATION EXAMPLE
Recommended PoweR SuPPlieS:
All Command Access exit devices & field installable kits have been thoroughly cycle
tested with Command Access power supplies at our factory.
For more information click here or go to our website
US customer support 1-888-622-2377 | www.commandaccess.com | CA customer support 1-855-823-3002

Remove Push Pad from device.
1. Start with the front of the pluger bracket & slide wings
into the exsisting grooves in the baserail.
2.
Slide plunger bracketin the middle groove back
towards the front activating arm.
3. Drop plunger bracket over the front activitaing arm. 4.
Make sure the plunger bracket slides all the way to
the back where the screw is past the tab.
5. 6. Once plunger bracket is past tab tighten screw all the
way to prevent the bracket from moving forward.
US customer support 1-888-622-2377 | www.commandaccess.com | CA customer support 1-855-823-3002
TAB
WING
WING

Press down on the solenoid mount to pop in the oth-
er side of the solenoid mount into the middle groove.
7. Behind plunger bracket, install solenoid mount by
sliding one side into the middle groove. 8.
9. Add Silicon washer to the plunger.
US customer support 1-888-622-2377 | www.commandaccess.com | CA customer support 1-855-823-3002
10.Move solenoid mount up towards plunger & install
remaining (2) screws to mount. DO NOT TIGHTEN!
11.To nd correct solenoid position, pull back on the plunger bracket & conrm starwheel is free to rotate.
Once starwheel moves freely, this is the correct position. Release plunger bracket & hold solenoid in place.

Make sure to route power wires under back
activating arm.
12. While holding solenoid in place, tighten all (4) screws
to secure mount to baserail. 13.
14. Plug into power & test. After conrming unit works
properly. Add wire tie & strain relief pad to secure
power cable.
US customer support 1-888-622-2377 | www.commandaccess.com | CA customer support 1-855-823-3002
15.
Add power connector to power wires, push them
into the connector make sure the tabs on the wire
pins are facing up. The tabs will lock pins into the
connector.
TOP
TAB
