INSTALLATION INSTRUCTIONS
VLP-UL-M-KIT
The Command Access VLP-UL-M-KIT is a eld-installable motorized latch-pullback kit for the Von Duprin
33/35 & 98/99 series devices.
Visit our website for more details
www.CommandAccess.com
U.S. Customer Support
1-888-622-2377
Canada Customer Support
1-855-823-3002
Kit Includes
A. 1 - MM3 Module
B. 2 - Phillips head screws
C. 1 - Replacement Shock Absorber
D. 1 - 6’ Lead
E. 1 - Motor Bracket
F. 1 - Acme Thread Block
G. 1 - Dogging Hole Cap
H. 1 - #30 Drill Bit
I. 1 - Hex Screw (installed in F.)
J. 1 - Hex Screw w/ set pin 10/32
K. 1 - Hex Wrench 3/32”
A.
B.
C.
D.
H.
G.
E.
F.
j.
i.
Tools Required
• Drill
• Hammer & Pin Punch(recommend) or 3/16 drill bit
• Pliers/Vise grips (recommend) or Hacksaw
• 5/16 Nut driver (recommended) or Flat head
screwdriver
• Phillips head screwdriver
Doc # 20059
K.

Page 2
STEP 1 - Disassemble Exit Device
Head cover
Bracket
Screws
Case
Push pad
Remove head coverA.
Remove (2) screws attaching bracket to
baserail with 5/16 nut drive or at head
screw driver.
C.
Remove push pad by pulling pad guides
up than moving push pad forward & then
upward.
E.
Remove mounting bracket.B.
Remove case for device.D.

Page 3
STEP 2 - Change out shock absorber
Activating arm
Shock absorber housing
Shock absorber
**Note if you have the old style shock absorber
(prior to Feb/Mar 2014) or the new style (after
Nov 2014) you will skip step 2.***
Now your device should have all nished parts
removed.
A.
Gently push up on shock absorber housing
than push down on activating arm.
B.
Remove shock absorber & replace with shock absorber
provided.
C.
Old Style New Style

Page 4
Cylinder
Locking pieceTabs
STEP 3- Removing Dogging
Rivets
If using a hacksaw cut here
*If you have a re-rated
device skip to step 4
Dogging tail
Remove Cylinder by pulling up.A.
Using Hammer & Pin Punch knock rivets
out.
C.
Using Pliers or Vise grips to attach onto at
part of dogging tail piece closest to where
it connects to metal rod.
E.
Push tabs in & pull up on locking
piece.
B.
Or drill rivets out using 3/16 drill
bit.
D.
Rotate towards than away from you
until you hear the part snap than
remove.
F.

Page 5
STEP 4- Installing Kit
Stop
Metal Rod
Acme thread block
Activating Arm Base
Second hole
Turcite
Acme thread
Push Acme thread block onto metal
rod. Push until block stop hits base of
activating arm.
A.
Using #30 drill bit provided, drill into
metal rod using second hole as a
bushing.
C.
Slide Motor Bracket onto baseplate going
into existing grooves in baseplate.
E.
Using Hex screw (I.) install into rst
hole on block using Allen wrench
provided.
B.
Install Hex screw (J.) into second hole
using Allen wrench.
D.
While sliding motor bracket into
position, feed acme thread into Turcite.
F.

Page 6
STEP 4- Continued ...
Screw holes
STEP 5 - Reassemble Exit Device
Push pad
Case
Bracket
Screws
Bracket
Head cover
1
4
2
3
Next plug in MM3 module to motor & if
available power. We recommend to test
unit. See last page for MM3 details
H.Once bracket lines up with screw
holes install (2) Phillips head screws (B)
provided.
G.
Replace bracket & attach (2)
screws with 5/16 nut drive or
at head screw driver.
C.
Replace push pad by placing over
activating arms & pushing down than
back towards end of the device
A. Slide baseplate back into case being
careful of motor wires.
B.
Replace mounting
bracket.
D. Replace head cover &
(4) head cover screws
if present.
E.

Page 7
Visit our website for more details
www.CommandAccess.com
U.S. Customer Support
1-888-622-2377
Canada Customer Support
1-855-823-3002
Technical Information
• Input Voltage: 24VDC +/- 10%
• Current Peak: 1 Amp
• Current Hold: 125 mA
• Wire gauge: X 20 ga
Doc # 20059
2 Beeps
3 Beeps
5 Beeps
6 Beeps
7 Beeps
Beeps Explanation Solution
Over Voltage
Under Voltage
Forced Release
Switch wires not making contact
Over-travel or mechanical obstruction
Check voltage & adjust to 24 V.
Check voltage & adjust to 24 V.
Device will automatically re-engage within 5 seconds.
Check to make sure there are no loose wires or bad connections
on MM3. After connection is repaired re-power & set adjustment.
Remove obstruction & push pad down until beeping stops &
release.
Step 1-Press the device push pad to the desired setting. (this can be fully
depressed or less than fully depressed).
Step 2-While depressing the push pad, apply power. (i.e. presenting the credential
to the reader).
Step 3-Continue to keep pad depressed, the device will beep 6 times. After the
beeps have stopped, release the pad and now the adjustment is complete.
If not to your liking repeat the three steps. That’s all there is to it.
Troubleshooting & Diagnostics
Setting MM3
Specications
Scan or Click
Installation Video Wiring Code
