Command access VLP-UL-M KIT User manual

A.
E. F.D.B. C.
Kit Includes Tools Required
A.
B.
C.
D.
E.
1- 60343 Motor Mount w/ MM5 series module
2- 40002 8/32 X 1/4” Phillips head screws
1- 50030 8’ Lead w/ VD Connector
1- 50944 Molex Pigtail
1- 40144 Dogging Hole Cap
• Cordless Drill
• Hammer & Pin Punch(recommend)
• 3/16 & 3/32 drill bit
• 5/16 Nut driver (recommended)
• #2 Phillips head screwdriver
vLP-UL-M KIT
INSERT Instructions
The Command Access VLP-UL-M-KIT is a Field-installable motorized latch-pullback kit for the Von Duprin 99/98 & 35/33 series
devices.
#20453_c
US customer support 1-888-622-2377 | www.commandaccess.com | CA customer support 1-855-823-3002
SPECIFICATIONS: • Input Voltage: 24VDC +/- 10%
• Average Latch Retraction Current: 900mA
• Average Holding Current: 200mA
• Wire Gauge: Minimum 18 gauge
• Direct wire run - no relays or access control units in-between power supply & module
Recommended Power Supplies:
All Command Access exit devices & field installable kits have been thoroughly cycle tested with Command Access power supplies at our factory. If you
plan on using a non-Command power supply it must be a filtered & regulated linear power supply.
G.
Fire rated dogging kit
1- 50872- Fire Rated Drilling Template (Old Devices)
1- Replacement Dogging Tail Piece (40006 + 40800 + 50872)
F.
G.

Step 1 - To enter PTS mode: Depress MM5 button & apply power. The device will emit 1 SHORT beep. The
device is now in PTS mode.
Step 2 - While depressing the push pad, apply power. (i.e. presenting the credential to the reader).
Step 3 - Continue to keep pad depressed, the device will emit 1 LONG Beep. After the beep has stopped,
release the pad and now the adjustment is complete. test the new location, If not to your liking
repeat the 3 steps.
Setting PTS
2 Beeps
3 Beeps
5 Beeps
Beeps Explanation Solution
Over Voltage
Under Voltage
Retraction or dogging failure
> 30V unit will shut down. Check voltage & adjust to 24 V.
< 20V unit will shut down. Check voltage & adjust to 24 V.
After 1st fail: 5 beeps then immediately attempts to retract again.
After 2nd fail: 5 beeps with pause in-between for 30 seconds then device attempts to retract
again.
After 3rd fail: 5 beeps every 7 minutes, device will not attempt to retract.
To Reset: Depress bar for 5 seconds at any time.
PUSH TO SET Device is ready to record its new position.
Troubleshooting & Diagnostics
4 Beeps Failed Sensor Verify all 3 sensor wires are installed correctly. Replace sensor if problem persists by
contacting office.
**Important Info**
Make sure to set PTS before finishing installation
Technical Information
US customer support 1-888-622-2377 | www.commandaccess.com | CA customer support 1-855-823-3002
Ceiling Tile
Legend
Standard Placement
Module
GREEN
CHANNEL 1
LED
NORMALLY OPEN
DRY CONTACT FROM
ACCESS CONTROL
SYSTEM
NO VOLTAGE
LOCKING
HARDWARE
+
-
CAT Install video
MM5 BUTTON
POWER PTS
MM5
1 LONG Beep PUSH TO SET Device has recorded it’s new position.
1 SHORT Beep

Remove all (4) screws & head cover.
1. Remove (2) screws securing mounting bracket to housing. 2.
Installation Instructions
Pins
Slide housing off push pad & baserail.
3. Remove Push Pad from baserail. 4.
5. If your device has dogging, flip baserail over & remove (2) screws securing dogging assembly to rail. If you have an older device with rivets, you will
need to drill them out or use a pin punch to knock them out.
US customer support 1-888-622-2377 | www.commandaccess.com | CA customer support 1-855-823-3002

Use replacement dogging tail (50872) provided, & insert into
connection rod.
6. Line up holes a and b, insert pin and secure it with
the clip provided. If you have an older device
without hole b, please scan the qr code for a
video on how to use the provided dogging kit.
7.
Installation Instructions
Pins
Grab your motor and insert attaching bracket at slight angle through the window on the dogging tail.
8.
9. Straighten kit, depress back activating bracket, & gently pull back on the motor to slide mounting bracket
UNDERNEATH baserail.
US customer support 1-888-622-2377 | www.commandaccess.com | CA customer support 1-855-823-3002
Fire rated devices Only - nOn-rated devices skip tO step 8
a
b

Secure motor kit to baserail by installing (2) screws provided.
10.
Test motor kit on baserail to confirm it is
functioning properly.
11.
Installation Instructions
Slide housing back onto baserail & push pad. Make sure the baserail & the black push pad guides are in the
correct channel.
13.
US customer support 1-888-622-2377 | www.commandaccess.com | CA customer support 1-855-823-3002
Re-install push pad onto baserail.
12.
Re-install (2) screws into mounting bracket & housing.
14.

Now, with device reassembled set the PTS by pressing the red button & applying power. You will hear one quick beep to
let you know it is now in programming mode.
15.
Next, depress the push pad to the location you want the device to retract to & hold it there. Apply power & you will hear one
LONG beep. The device has now learned that location.
16.
Installation Instructions
Fire off the device a few times to ensure the location is correct. after installing the device on the door, recheck to verify
the pushpad is retracting to the desired location. If not, repeat steps 15-16.
17.
US customer support 1-888-622-2377 | www.commandaccess.com | CA customer support 1-855-823-3002
PTS Button
Step 1 - To enter PTS mode: Depress MM5 button & apply power. The device will emit 1 SHORT beep. The
device is now in PTS mode.
Step 2 - While depressing the push pad, apply power. (i.e. presenting the credential to the reader).
Step 3 - Continue to keep pad depressed, the device will emit 1 LONG Beep. After the beep has stopped,
release the pad and now the adjustment is complete. test the new location, If not to your liking
repeat the 3 steps.
Setting PTS
**Important Info**
Make sure to set PTS before finishing installation
MM5 BUTTON
POWER PTS
MM5
