COMMATECH CommaCube RFID User manual
USER MANUAL
CommaCube RFID
Shenzhen Comma Technology Co., Ltd.
Introduction
CommaCube RFID is the star product of the comma technology family of wearable products 。This
product can achieve real wearable operation and data collection. It can read the UHF RFID tag, pre
process the data and upload it to the mobile display terminal such as smart watch through
Bluetooth 4.0 (BLE) technology. CommaCube can be integrated rapidly with Android devices by
CommaQuickConnectTM technology, so that data can be transferred seamlessly to all kinds of
information systems in the enterprise.Such as SAP®、ERP and so on.
1、About Equipment
CommaCube RFID is the star product of the comma technology family of wearable products 。This
product can achieve real wearable operation and data collection. It can read the UHF RFID tag, pre
process the data and upload it to the mobile display terminal such as smart watch through Bluetooth 4.0
(BLE) technology. CommaCube can be integrated rapidly with Android devices by
CommaQuickConnectTM technology, so that data can be transferred seamlessly to all kinds of
information systems in the enterprise.Such as SAP®、ERP and so on.
1、Introduction and functional description of the appearance
Functional interpretation of various parts of equipment
Mark
Name
Meaning
①
RFID Antenna window
The RFID Antenna is placed inside this area
②
Key button
The click key can wake up the sleeping device and perform a reading
label operation. In the working state, a click key can be read at a label.
Press the button to disconnect the current Bluetooth connection
③
Indicator light
Three color indicator lights, red, blue and green respectively, indicate
the different circumstances. Please refer to the explanation of the
meaning of the equipment light.
④
Buzzer sounding hole
Sounding holes in buzzer, prohibition of clogging
⑤
Reset Hole
With a needle like hard material for 2 seconds, will reset the device
⑥
Extension port
Used to connect the charging base and other CommaCube accessories,
as detailed in the wearable accessories
⑦
RFID Antenna Area
If the device reads the RFID tag, do not cover it
Interpretation of the meaning of equipment indicator
Indicator
light
Indicator light explain
Meaning
Red
Light
Flickering slowly
Low battery power of equipment
Always bright
The equipment is charging
Flickering one time（500ms）
Read label failure
Blue
Light
Flickering slowly
Waiting for a Bluetooth connection, there is no Bluetooth
connection in 30 seconds, stop flashing, and enter a
dormant state. The connection is successful in 30 seconds
and the blue light goes out
Green
Light
Flickering one time
（20ms，At the same time with the
buzzer）
Read the label complete
Always bright
Equipment charging completion
2、Charging description
Put the CommaCube RFID on the charging base and charge it with the standard Micro USB interface to
the charging base.
Interpretation of the meaning of charging indicator
3、Wearable accessories
The ingenious magnetic suction design can make the CommaCube connect quickly with the parts of
different forms. Users can choose the most suitable form according to their working characteristics and
operation habits, give full play to the performance of CommaCube, and improve their working efficiency
and experience.
Device name
Charging
Charging completion
CommaCube RFID
A red light is always on
A Green light is always on
CommaGlove accessories allow users to use CommaCube in the form of
gloves. The CommaGlove gloves are made of imported sheepskin with high
elasticity, durability, good air permeability and so on, so as to ensure a good user
experience. Meanwhile, for users who have already worn gloves, we also provide
splint fittings, which is convenient for users to fix CommaCube on existing
ordinary gloves quickly and conveniently.
CommaRing accessories allow users to use CommaCube in the form of a
ring. The unique way of wearing the double ring can significantly relieve the
fatigue of the fingers when they are worn for a long time. CommaRing supports
180 degrees of rotation to facilitate users to use a variety of reading positions and
reading angles in the process of use, and is compatible with the different usage
habits of the left and right hands.
CommaPalm accessories can allow users to use CommaCube to form. The
minimalist way of wearing is much easier to wear and pick. At the same time, the
tailored advanced elastic materials also guarantee the comfort of the use.
4、Product parameters
Connection performance
Bluetooth connectivity
Protocol
Bluetooth 4.0
Distance
10m
Frequency
2.4GHz-2.48GHz
Charge
Special charging base
Base using Micro USB standard interface
UHF RFID performance
Protocol standard
EPC Class1 Gen2, ISO 18000-6C
Read distance
≤1m
Write distance
≤40cm
frequency range
914.75MHz
Environmental parameters
Operating temperature
-20˚C ~+55˚C
Storage temperature
-40˚C~ +80˚C
Humidity
5%~95%（No condensation）
Battery performance
Battery type
Lithium ion polymer battery
Battery capacity
400mAh
Average use time
≥24h
5、Packing detail
Name
Qty
Use for
CommaCube RFID
1
data acquisition
Charging base
1
Equipment charging
USB data line
1
Charging the power adapter or computer to recharge
Certificate
1
Certification of equipment out of factory
Warranty card
1
Use in maintenance
User guide
1
Guide to use of equipment
2、Maintenance service
1、CommaCube The mainframe is free for 1 years. Human factors and non natural disasters are
excepted.
2、The warranty period for batteries and other accessories is half a year.
3、Maintenance period: after receiving the equipment, the maintenance is completed within 15
working days and sent back. (excluding postage time)
4、After-Sale Service Hotline：0755-26906593
3、Maintenance advice
1、The antenna window must be kept clean, and we are exempt from the warranty against the damage
caused by improper maintenance.
2、Avoid hard and rough objects to wear or scratch the reading window;
3、Please use soft cloth to remove the stains on the reading window.
4、It is forbidden to spray any liquid to the reading window.
5、It is forbidden to maliciously destroy the USB charging interface.
Disclaimer of liability:
Thank you for choosing the smart wearable device of Shenzhen comma interconnect
technology limited company. Please read carefully all the contents of this guide before you
use this product, so as to make sure you know how to use the product safely, reasonably and
effectively. After reading, please keep this guide properly in order to facilitate the next use.
Please do not disassemble the terminal or tear up the seal on the terminal, otherwise our
department will not guarantee or replace the equipment.
The pictures in this guide are for reference only, if there is any change without notice. Please
take the actual product as the criterion. For the improvement of this product, we reserve the
right to modify the guide without notice at any time.
All information contained in this guide is protected by copyright, our all rights reserved,
without written permission, any units and individuals shall not in any way or reason for any
form of copy, of all or part of the contents of this document in duplicate or bundled with
other products to use, sales.
May include my company or third party copyrighted software described in this guide product,
unless related rights permit, or any unit or individual shall not in any form of the software to
copy, distribute, modify, decompile, disassemble, excerpt, decryption, reverse engineering,
lease, transfer, can Xu and other acts of copyright infringement of software.
Shenzhen smartcomma technology Co., Ltd. has the final interpretation of this statement.
www.smartcomma.com
4：FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void
your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
RF Exposure Information
The device has been evaluated to meet general RF exposure requirement. The device can be used in por
table exposure condition without restriction.
Address : Room 1709 XiHaiMingZhu Building，No.1 Taoyuan Road,NanShan District,ShenZhen City
Web: www.smartcomma.com
Hotline：0755-26906593
