Commax DP-SS User manual

APARTMENT HOUSE INTERCOM (ROOMSTATION) DP-SS
User Manual
•Thank you for purchasing COMMAX products.
•Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
•The company is not responsible for any safety accidents caused by abnormal operation of the product.
www.safemag.ru
www.safemag.ru

1
1. CONTROLS AND FUNCTIONS
X
Y
Z
[
①HANDSET
②HOOK S/W
③DOOR RELEASE BUTTON
④SPRING CORD
www.safemag.ru
www.safemag.ru

2
2. OPERATION INSTRUCTION
1. Hear a call sound from receiver ①When visitor press the call button on the doorstation
2. Converse with visitor after raise up handset
3. After ascertain the visitor, press the door release button ③to open door
NOTE :No need to connect extra power by reason of it’s supplied power source from doorstation
www.safemag.ru
www.safemag.ru

3
3. WIRING DIAGRAM
www.safemag.ru
www.safemag.ru

4. INSTALLATION
4
1) Please attach a bracket on the wal correctly with screw.
2) After the attachment of bracket, please Adjust the groove of the product with a Bracket and then pull it down.
www.safemag.ru
www.safemag.ru

Printed In Korea / 2011.06.105
513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea
Int’l Business Dept. : Tel.; [phone]~550 Fax.; [phone]
Web site : www.commax.com
