Commax DRC-40KA User manual

Color Door Camera DRC-40KA
User Manual
•Thank you for purchasing COMMAX products.
•Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
•The company is not responsible for any safety accidents caused by abnormal operation of the product.

1
1. Introduction.........................................................................2
2. Important Safeguard...........................................................3
3. Overview ............................................................................4
4. Package contents...............................................................6
5. Wiring and Installation........................................................7
6. Specification......................................................................9
Contents

2
Your unit is designed so it can be flush mounted on the or used. When flush mounted on the wall, the stand permils you to the
unit for an gular of unit view. The model number is located on the bottom and record the serial number in the space provided
below(available). Refer to these numbers whenever you call upon your COMMAX dealer regarding this product.
Model No. Serial No.
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
This symbol is intended to alert the use to the presence of uninsulated
“
“dangerous Voltage” ”
within the product’s enclose that
may be of sufficient magnitude to constitute a risk of electric shock to persons.
This symbol is intended to alert the use to the presence of important operating and maintemance(servicing) instructions in the
literature accompanying the appliance
1. Introduction
CAUTION : To reduce the risk of electric shock, do not remove cover(or back) no user-serviceable
part inside refer servicing to qualified service personnel
caution
Risk of electric shock
do not open

3
▲
Damage Requiring Service: This equipment from the power source and source and refer servicing to qualified service per-
sonnel under the following conditions:
ⓐwhen the power is damaged.
ⓑif liquid has been spilled or objects have fallen into the unit
ⓒif the equipment has been exposed to rain or water.
ⓓif the equipment has been dropped or otherwise damaged.
ⓔwhen the equipment exhibits a distinct change in performance- this indicates a need for service.
▲ Water and Moisture: Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink, or laundry
tub, in a wet basement, or near a swimming pool, and the like.
▲ Accessories: The product may fall, causing serious injury to a child or adult, and serious damage to the appliance. Any
mounting of the manufacture’s instructions, and should use a mounting accessory recommended by the manu-
facturer.
▲ Object and Liquid Entry: Never push objects of any kind into this product through openings as they may touch dangerous
voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any
kind on the product.
▲ Lightning: For added protection for this product before a lightning storm, or when it is left un attached and un used for long
periods of time, unplug it from the wall out it and disconnect the other system. This will prevent damage to the
product due to lightning and power-line surges. If you live in an area heavily prone to lightning storms, it is recom-
mended that you invest in power-line, telephone-line, RFcable and actuator/ polarization surge protectors to protect
your appliance system from possible damage
2. Important Safeguards

4
3. Overview

5
①White LED & Illumination Sensor : Offer clear image at night
②Microphone : Deliver voice signal from a visitor
③Camera Lens : Transfer image
* Make sure the lens is always kept clean
④Speaker : Deliver voice signal to a visitor
⑤Call Button : Pressed to call to a household
⑥Angle Adjustment Lever : Adjust lens angle
⑦Volume Adjuster : Adjust speaker volume
⑧Monitor Connection Terminal (Polarity with care)
⑨Door Release Connection Line
Note
CDV-72UM only if they work with the product.
This power is always supplied to the camera, you can use the motion detection feature.

6
4. Package contents
(DRC-40KA)

5. Wiring and Installation
7
1. Match the fix the whole in the wall and the fixing bracket [FIG.1]
2. Match and connect monitor line as shown below [FIG.2]
(#1: Audio, #2: GND, #3: DC12V, #4: Video)
3. Adjust camera location on the wall by checking the image on monitor screen and
fix its location
4. Connect the Door Release Connection Line as shown below [FIG.2]
5. Tighten a screw at the bottom side of the camera [FIG.1]
#1
#2
#3
#4
#1
MONITOR
#2
#3
#4
Audio
GND
DC12V
Video
Door Release Cable
Door Release
[FIG-1] [FIG-2]
SCREW M3X8 (1EA)
SCREW T4X18 (2EA)
[FIG.1] [FIG.2]
(Note)
If you want to work with only CDV-72UM products,
You can use the motion detection feature.
CDV-72UM

8
UU
▶Installation place
• Do not install the product where direct lays of the sun reach the camera lens.
• Adjust the position by using the angle adjustor (in the back).
• Install a separate lighting at night for better picture quality.
▶Cautions at a time of installation
1. Do not install where there is much dust, waste or humidity.
2. Make sure to connect accurately.
3. Make sure to fix it tightly so that it does not come off due to vibration.
4. Avoid places where there are direct lays of the sun or where it rains a lot.
5. Take good care of it to prevent dust or cracks on the window of the door camera lens.
▶Position of camera

6. Specification
DRC-40KA
DC 12V (Supplied from monitor)
4wires to a monitor (polarity)
2 wires to the door release (non-polarity)
CMOS IMAGE SENSOR
NTSC or PAL STANDARD.
Simultaneous communication
0.1 Lux (within 300mm)
Embedded night LED (activated at night)
Horizontal 75°, Vertical 55°
Up, down 12 Degrees
-10 ℃(tested up to -40°C) ~ +40 ℃
400g
96(W) x 155(H) x 32.5(D)
Diameter (pie)
Diameter (meter)
Model No.
Rated Voltage / Power Consumption
Sensor Type
Video Transmission Standard
Communication
Minimum Illumination
LED
Effective Viewing Angle
Angle Adjustment
Operating Temperature
Weight (g)
Dimension (mm)
Distance between a door
camera and monitor
Wiring (Main Unit / Door Release)
0.5 0.65 0.8
28m 50m 70m
