INSTALLATION AND OPERATION MANUAL
CWGE26FX2TX24MSPOE
(22) 10/100/1000 BASE-T(X) + (2) GIGABIT COMBO PORTS +
(2) 100/1000 BASE-FX WITH POWER OVER ETHERNET (POE+)
The ComNet™CWGE26FX2TX24MSPOE is an extended temperature commercial
grade Managed Ethernet Switch. It provides IEEE 802.3at PoE to twenty-four
10/100/1000BASE-T(X) two of which are also gigabit combo ports supporting
100/1000FX SFP Modules. A further two 100/1000FX SFP ports are also included.
Up to 400 watts of PoE power is available for distribution across all 24 electrical
ports. All SFP ports utilize ComNet SFPs for fiber and connector type and distance.
The CWGE26FX2TX24MSPOE is a redundant switch offering multiple Ethernet
redundancy protocols to protect your applications from network interruptions or
temporary malfunctions by redirecting transmission within the network.

INS_CWGE26FX2TX24MSPOE_REV– 5 Mar 2014 PAGE 2
INSTALLATION AND OPERATION MANUAL CWGE26FX2TX24MSPOE
TECH SUPPORT: 1.888.678.9427
Contents
About This Guide 5
Related Documentation 5
About ComNet 5
Website 5
Support 5
Safety 5
Overview 6
Introduction 6
Software Features 7
Hardware Features 8
Hardware Overview 9
Front Panel 9
Rear Panel 10
Rack mount kit assembly 10
Ethernet Cables 11
1000/100BASE-TX/10BASE-T Pin Assignments 11
SFP 13
Console Cable 13
WEB Management 15
Configuration by Web Browser 15
About Web-based Management 15
Basic Setting 18
System Information 18
Admin & Password 19
Auth Method 20
IP Setting 21
HTTPS 22
SSH 22
LLDP 23
Backup/Restore Configuration 27
Firmware Update 27

INS_CWGE26FX2TX24MSPOE_REV– 5 Mar 2014 PAGE 3
INSTALLATION AND OPERATION MANUAL CWGE26FX2TX24MSPOE
TECH SUPPORT: 1.888.678.9427
DHCP Server 27
Port Setting 29
Port Trunk 31
LACP 33
Redundancy 37
MSTP 38
STP 44
VLAN 47
VLAN Setting Example 52
SNMP 57
Traffic Prioritization 63
Multicast 77
Security 81
AAA 85
RADIUS Overview 87
Warning 98
System Warning 99
Monitor and Diag 101
Port Statistic 104
System Log Information 107
Cable Diagnostics 108
SFP Monitor 109
Ping 110
Syncronization -P TP 111
PoE Configuration 113
St atus 115
Factory Defaults 116
System Reboot
116
Command Line Interface Management 117
About CLI Management 117
Commander Groups 121
Technical Specifications 135

INS_CWGE26FX2TX24MSPOE_REV– 5 Mar 2014 PAGE 4
INSTALLATION AND OPERATION MANUAL CWGE26FX2TX24MSPOE
TECH SUPPORT: 1.888.678.9427

INS_CWGE26FX2TX24MSPOE_REV– 5 Mar 2014 PAGE 5
INSTALLATION AND OPERATION MANUAL CWGE26FX2TX24MSPOE
TECH SUPPORT: 1.888.678.9427
About This Guide
This guide is intended for different users such as engineers, integrators, developers, IT managers,
and technicians.
It assumes that users have some PC competence and are familiar with Microsoft Windows
operating systems and web browsers such as Windows Internet Explorer and Mozilla Firefox, as
well as have knowledge of the following:
»Installation of electronic equipment
»Electrical regulations and guidelines
»Knowledge of Local Area Network technology
Related Documentation
The following documentation is also available:
»CWGE26FX2TX24MSPOE Data sheet
»SFP Modules Data sheet
About ComNet
ComNet develops and markets the next generation of video solutions for the CCTV, defense, and
homeland security markets. At the core of ComNet’s solutions are a variety of high-end video
servers and the ComNet IVS software, which provide the industry with a standard platform for
analytics and security management systems enabling leading performance, compact and cost
effective solutions.
ComNet’s products are available in commercial and rugged form.
Website
For information on ComNet’s entire product line, please visit the ComNet website at
http://www.comnet.net
Support
For any questions or technical assistance, please contact your sales person ([e-mail]) or
the customer service support center ([e-mail])
Safety
»Only ComNet service personnel can service the equipment. Please contact ComNet Technical
Support.
»The equipment should be installed in locations with controlled access, or other means of
security, and controlled by persons of authority.

INS_CWGE26FX2TX24MSPOE_REV– 5 Mar 2014 PAGE 6
INSTALLATION AND OPERATION MANUAL CWGE26FX2TX24MSPOE
TECH SUPPORT: 1.888.678.9427
Overview
Introduction
The CWGE26FX2TX24MSPOE Gigabit managed redundant ring PoE Ethernet switch with
22x10/100/1000Base-T(X) IEEE802.3at PSE ports and two Gigabit combo IEEE802.3at PSE ports
and 2x100/1000Base-X SFP ports supports Ethernet Redundancy protocol, C-Ring (recovery
time < 30ms over 250 units of connection) and MSTP (RSTP/STP compatible). It can protect your
mission-critical applications from network interruptions or temporary malfunctions with its fast
recovery technology. The CWGE26FX2TX24MSPOE also supports Power over Ethernet (PoE+),
a system to transmit electrical power up to 30 watts, along with data, to remote devices over
standard twisted-pair cable in an Ethernet network.

INS_CWGE26FX2TX24MSPOE_REV– 5 Mar 2014 PAGE 7
INSTALLATION AND OPERATION MANUAL CWGE26FX2TX24MSPOE
TECH SUPPORT: 1.888.678.9427
Software Features
»C-Ring (recovery time < 30ms over 250 units of connection)
»MSTP (RSTP/STP compatible) for Ethernet Redundancy
»24 ports PSE fully compliant with IEEE802.3at standard, providing up to 30 Watts per port
»IEEE 1588v2 clock synchronization
»Provides HTTPS/SSH protocol to enhance network security
»IP-based bandwidth management
»application-based QoS management
»Device Binding security function
»IGMP v2/v3 (IGMP snooping support) for filtering multicast traffic
»SNMP v1/v2c/v3 & RMON & 802.1Q VLAN Network Management
»ACL, TACACS+ and 802.1x User Authentication for security
»9.6K Bytes Jumbo Frame
»SFP ports support DDM function
»Multiple notification for warning of unexpected event
»Web-based Telnet, Console (CLI), and Windows utility (eConsole) configuration
»LLDP Protocol
»19 inch rack mountable design

INS_CWGE26FX2TX24MSPOE_REV– 5 Mar 2014 PAGE 8
INSTALLATION AND OPERATION MANUAL CWGE26FX2TX24MSPOE
TECH SUPPORT: 1.888.678.9427
Hardware Features
»450 Watts power supply included
»Operating Temperature: –10 to 60ºC
»Storage Temperature: – 40 to 85ºC
»Operating Humidity: 5% to 95%, non-condensing
»22 × 10/100/1000Base–T(X)
»2 × 100/1000Base-X SFP & 10/100/1000Base–T(X) COMBO
»2 × 100/1000 Base-X SFP
»Console Port
»Dimensions: 43.1 × 34.2 × 4.4 cm (16.97 × 13.47 × 1.73 in)

INS_CWGE26FX2TX24MSPOE_REV– 5 Mar 2014 PAGE 9
INSTALLATION AND OPERATION MANUAL CWGE26FX2TX24MSPOE
TECH SUPPORT: 1.888.678.9427
Hardware Overview
Front Panel
The following table describes the labels on the CWGE26FX2TX24MSPOE
Port Description
Gigabit SFP ports 2 x 100/1000Base-X on SFP port
Combo Ports 2 x 100/1000Base-X SFP & 10/100/1000Base-T(X) Combo
Gigabit Ethernet Ports 22 x 10/100/1000Base–T(X)
Console Use RS-232 with DB-9 connecter to manage switch.
28 75
6
1 3 4
CWGE26FX2TX24MSPOE
1. Console port (DB-9 Female connector)
2. 10/100/1000Base-T(X) Gigabit Ethernet ports
3. LED for Odd Numbered Ethernet ports Link/Act status
4. LED for Even Numbered Ethernet ports Link/Act status
5. 100/1000Base-X SFP & 10/100/1000Base–T(X) Combo
6. PoE Status LED
7. 100/1000Base-X SFP Port
8. Front panel LED Status:
»LED for PWR The LED lights on when the power module is activated.
»LED for Fault When the fault occurs, the amber LED will be light on.
»LED for R.M. (Ring master). Indicates that the switch is the Master of the Ring.
»LED for Ring Indicates that the C-Ring is activated.

INS_CWGE26FX2TX24MSPOE_REV– 5 Mar 2014 PAGE 10
INSTALLATION AND OPERATION MANUAL CWGE26FX2TX24MSPOE
TECH SUPPORT: 1.888.678.9427
Rear Panel
1
2
The rear panel of CWGE26FX2TX24MSPOE
1. Power Switch
2. Power input for AC 100V~240V / 50~60Hz
Rack mount kit assembly
You can find the rack mount kit and the screws in the packing box. Please assembly the rack
mount kit on the switch with screws as shown below:

INS_CWGE26FX2TX24MSPOE_REV– 5 Mar 2014 PAGE 11
INSTALLATION AND OPERATION MANUAL CWGE26FX2TX24MSPOE
TECH SUPPORT: 1.888.678.9427
Ethernet Cables
The CWGE26FX2TX24MSPOE series switches have standard Ethernet ports. According to the link
type, the switches use CAT 3, 4, 5,5e UTP cables to connect to any other network device (PCs,
servers, switches, routers, or hubs). Please refer to the following table for cable specifications.
Cable Types and Specifications
Cable Type Max. Length Connector
10BASE-T Cat. 3, 4, 5 100-ohm UTP 100 m (328 ft) RJ-45
100BASE-TX Cat. 5 100-ohm UTP UTP 100 m (328 ft) RJ-45
1000BASE-TX Cat. 5/Cat. 5e 100-ohm UTP UTP 100 m (328ft) RJ-45
1000/100BASE-TX/10BASE-T Pin Assignments
With 1000/100BASE-TX/10BASE-T cable, pins 1 and 2 are used for transmitting data, and pins 3
and 6 are used for receiving data.
10/100Base-T(X) PSE RJ-45 port
Pin
Number Assignment
#1 TD+ with PoE Power input +
#2 TD – with PoE Power input +
#3 RD+ with PoE Power input –
#6 RD – with PoE Power input –
10/100 Base-T RJ-45 Pin Assignments
Pin
Number Assignment
1TD+
2TD-
3RD+
4Not used
5Not used
6RD-
7Not used
8Not used
1000Base-T PSE RJ-45 port

INS_CWGE26FX2TX24MSPOE_REV– 5 Mar 2014 PAGE 12
INSTALLATION AND OPERATION MANUAL CWGE26FX2TX24MSPOE
TECH SUPPORT: 1.888.678.9427
Pin
Number Assignment
#1 BI_DA+ with PoE Power input +
#2 BI_DA – with PoE Power input +
#3 BI_DB+ with PoE Power input –
#4 BI_DC+
#5 BI_DC-
#6 BI_DB – with PoE Power input –
#7 BI_DD+
#8 BI_DD-
1000 Base-T RJ-45 Pin Assignments
Pin
Number Assignment
1BI_DA+
2BI_DA-
3BI_DB+
4BI_DC+
5 BI_DC-
6 BI_DB-
7BI_DD+
8 BI_DD-
The CWGE26FX2TX24MSPOE Series switches support auto MDI/MDI-X operation. You can use a
straight-through cable to connect PC to switch. The following table below shows the 10BASE-T/
100BASE-TX MDI and MDI-X port pin outs.
10/100 Base-T MDI/MDI-X pins assignment
Pin
Number MDI port MDI-X port
1TD+(transmit) RD+(receive)
2TD-(transmit) RD-(receive)
3RD+(receive) TD+(transmit)
4Not used Not used
5Not used Not used
6RD-(receive) TD-(transmit)
7Not used Not used
8Not used Not used

INS_CWGE26FX2TX24MSPOE_REV– 5 Mar 2014 PAGE 13
INSTALLATION AND OPERATION MANUAL CWGE26FX2TX24MSPOE
TECH SUPPORT: 1.888.678.9427
1000 Base-T MDI/MDI-X pins assignment
Pin
Number MDI port MDI-X port
1BI_DA+ BI_DB+
2BI_DA- BI_DB-
3BI_DB+ BI_DA+
4BI_DC+ BI_DD+
5 BI_DC- BI_DD-
6 BI_DB- BI_DA-
7BI_DD+ BI_DC+
8 BI_DD- BI_DC-
Note: “+” and “-” signs represent the polarity of the wires that make up each wire pair.
SFP
The Switch has fiber optical ports with SFP connectors. The fiber optical ports are in multi-mode
(0 to 550M, 850 nm with 50/125 µm, 62.5/125 µm fiber) and single-mode with LC connector. Please
remember that the TX port of Switch A should be connected to the RX port of Switch B.
Switch A Switch B
Console Cable
CWGE26FX2TX24MSPOE Series switches can be managed via a console port located on the front
of the switch. The DB-9 cable can be found in the package. You can connect them to PC via a
RS-232 cable with DB-9 female connector and the other end (DB-9 male connector) connects to
console port of switch.

INS_CWGE26FX2TX24MSPOE_REV– 5 Mar 2014 PAGE 14
INSTALLATION AND OPERATION MANUAL CWGE26FX2TX24MSPOE
TECH SUPPORT: 1.888.678.9427
5
9
1
6
1
6
5
9
DB-9 Male DB-9 Female
PC pin out (male) assignment RS-232 with DB-9 female
connector
Pin #2 RD Pin #2 TD
Pin #3 TD Pin #3 RD
Pin #5 GD Pin #5 GD
Pin Male Connector Female Connector
1Received Line Signal Detect (Received by DTE
Device)
Received Line Signal Detect (Transmitted
from DCE Device)
2Received Data (Received by DTE Device) Transmitted Data (Transmitted from DCE
Device)
3Transmitted Data (Transmitted from DTE Device) Received Data (Received by DCE Device)
4DTE Ready (Transmitted from DTE Device) DTE Ready (Received by DCE Device)
5Signal Ground Signal Ground
6DCE Ready (Received by DTE Device) DCE Ready (Transmitted from DCE Device)
7Request to Send (Transmitted from DTE Device) Clear to Send (Received by DCE Device)
8Clear to Send (Received by DTE Device) Request to Send (Transmitted from DCE
Device)
9Ring Indicator (Received by DTE Device) Ring Indicator (Transmitted from DCE
Device)

INS_CWGE26FX2TX24MSPOE_REV– 5 Mar 2014 PAGE 15
INSTALLATION AND OPERATION MANUAL CWGE26FX2TX24MSPOE
TECH SUPPORT: 1.888.678.9427
WEB Management
Attention: While installing and upgrading firmware, please remove physical loop connection first.
DO NOT power off equipment while the firmware is upgrading!
Configuration by Web Browser
This section introduces the configuration by Web browser.
About Web-based Management
An embedded HTML web site resides in flash memory on the CPU board. It contains advanced
management features and allows you to manage the switch from anywhere on the network
through a standard web browser such as Microsoft Internet Explorer.
The Web-Based Management function supports Internet Explorer 5.0 or later. It is based on Java
Applets with an aim to reduce network bandwidth consumption, enhance access speed and
present an easy viewing screen.
Note: By default, IE5.0 or later version does not allow Java Applets to open sockets. You need
to intentionally modify the browser setting in order to enable Java Applets to use network
ports.
Preparing for Web Management
IP Address: 192.168.10.1
Subnet Mask: 255.255.255.0
Default Gateway: 192.168.10. 254
User Name: admin
Password: admin

INS_CWGE26FX2TX24MSPOE_REV– 5 Mar 2014 PAGE 16
INSTALLATION AND OPERATION MANUAL CWGE26FX2TX24MSPOE
TECH SUPPORT: 1.888.678.9427
System Login
1. Launch Internet Explorer.
2. Type http:// and the IP address of the switch. Press “Enter”.
3. The login screen appears.
Login screen
4. Key in the username and password. The default username and password is admin.
5. Press OK button, then the main interface of the Web-based management appears.

INS_CWGE26FX2TX24MSPOE_REV– 5 Mar 2014 PAGE 17
INSTALLATION AND OPERATION MANUAL CWGE26FX2TX24MSPOE
TECH SUPPORT: 1.888.678.9427
Main Interface
Main interface

INS_CWGE26FX2TX24MSPOE_REV– 5 Mar 2014 PAGE 18
INSTALLATION AND OPERATION MANUAL CWGE26FX2TX24MSPOE
TECH SUPPORT: 1.888.678.9427
Basic Setting
System Information
The switch system information is provided here.
System Information interface
Label Description
System Name An administratively assigned name for this managed node. By convention, this is the
node’s fully-qualified domain name. A domain name is a text string drawn from the
alphabet (A-Za-z), digits (0-9), minus sign (-). No space characters are permitted as
part of a name. The first character must be an alpha character. And the first or last
character must not be a minus sign. The allowed string length is 0 to 255.
System Description The device Description.
System Location The physical location of this node(e.g., telephone closet, 3rd floor). The allowed
string length is 0 to 255, and the allowed content is the ASCII characters from 32 to
126.
System Contact The textual identification of the contact person for this managed node, together
with information on how to contact this person. The allowed string length is 0 to
255, and the allowed content is the ASCII characters from 32 to 126.
Save Click to save changes.
Reset Click to undo any changes made locally and revert to previously saved values.

INS_CWGE26FX2TX24MSPOE_REV– 5 Mar 2014 PAGE 19
INSTALLATION AND OPERATION MANUAL CWGE26FX2TX24MSPOE
TECH SUPPORT: 1.888.678.9427
Admin & Password
This page allows you to configure the system password required to access the web pages or log
in from CLI.
Label Description
Old Password Enter the current system password. If this is incorrect, the new password will not be set.
New Password The system password. The allowed string length is 0 to 31, and the allowed content is
the ASCII characters from 32 to 126.
Confirm
password
Re-type the new password.
Save Click to save changes.

INS_CWGE26FX2TX24MSPOE_REV– 5 Mar 2014 PAGE 20
INSTALLATION AND OPERATION MANUAL CWGE26FX2TX24MSPOE
TECH SUPPORT: 1.888.678.9427
Auth Method
This page allows you to configure how a user is authenticated when he logs into the switch via one
of the management client interfaces.
Label Description
Client The management client for which the configuration below applies.
Authentication
Method
Authentication Method can be set to one of the following values:
none: authentication is disabled and login is not possible.
local: use the local user database on the switch for authentication.
radius: use a remote RADIUS server for authentication.
Fallback Enable fallback to local authentication by checking this box.
If none of the configured authentication servers are alive, the local user database is
used for authentication.
This is only possible if the Authentication Method is set to a value other than ‘none’ or
‘local’.
Save Click to save changes.
Reset Click to undo any changes made locally and revert to previously saved values.
