QUICKSPECS
1DA-10121-01-003 — 01.24.2000
Compaq Remote Insight
Remote Console
Remote Console provides a remote connection to managed servers, allowing a remote PC to display all phases of
server activity (including post sequences and OS load) without loss of connection.
Remote Insight provides Remote Graphical Console capabilities for Windows NT servers utilizing standard graphics
based terminal emulation software tools such as Carbon Copy and pcAnywhere 32.
Remote Reboot
Allows the remote administrator to reboot the server on demand; when the system is functioning properly, the system
performs a graceful shutdown prior to reset; when the system is not responding, a cold reboot will be issued in order
to bring the server back on-line.
On-board Modem
Integrated 14.4 Kb/s modem, interchangeable Data Access Arrangement (DAA) localizes support to country-specific
telecommunications requirements.
Battery Backup
Integrated, user-replaceable battery provides at least 30 minutes of operation to guarantee alert delivery in the event
of a server power failure.
Reset and Failure Sequence Replay
Captures and stores server video text to assist in locating startup problems and causes of failure; information is
available for replay on demand.
Compaq Insight Manager Integration
Fully integrates with Compaq Insight Manager under key operating environments, providing hardware-based
asynchronous server manageability; supports full out-of-band SNMP management
Remote Insight Console Application
Remote Insight functionality can be accessed through a text-based console application residing locally on the board,
using standard ANSI terminal emulation packages. This increases flexibility in the event that Insight Manager may not
be available.
Browser Accessible
Remote Insight is accessible with NetScape Navigator or Microsoft Internet Explorer for performing remote
management tasks.
Integrated with Compaq Survey
Utilizing industry-standard browsers, users can access the Compaq Survey configuration file providing the latest
server configuration information to assist in the diagnostic process.
User Administration
Supports up to 12 users with customizable access rights, each with individual log in and password protection to
ensure security
Alert Administration
Provides support for alphanumeric or numeric paging, as well as alerts delivery to an Insight Manager console
Event Log
Includes a detailed event log, which is easily accessible through the Remote Insight Console or through Compaq
Insight Manager
Integration with SmartStart
Fully configurable through the SmartStart interview process
MODELS
Remote Insight
199748-001
Highly-intelligent remote
management board providing
continuous out-of-band
communication and critical alert
delivery

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
2DA-10121-01-003 — 01.24.2000
Compaq Remote Insight
Option Kit Contents
Remote Insight Board
Serial cable
Phone cable
Keyboard adapter cable
Compaq Management CD
Compaq SmartStart and Support Software CD
Compaq Systems Reference Library CD
Remote Insight User Guide
Compaq Insight Manager Installation poster
Compaq Insight Manager Asynchronous User Guide
Warranty
One-year, limited warranty1
SPECIFICATIONS
Architecture 32-bit EISA-based remote management board
Processor Intel 386EX embedded processor
Upgradability Board firmware upgradable via flash ROM
Video Support Onboard VGA, 640 x 480 x 256, 1024 x 768 x 16
Standard Interfaces One keyboard input/output, one serial, one video output
Modem 14.4 Kb onboard with localized Data Access Arrangement, v.42bis,
MNP5, backlist support
Memory 1-MB flash ROM, 1-MB RAM, 512-KB video RAM
Battery System Rechargeable, user-replaceable
Paging Support Alphanumeric or Numeric (TAP and DTMF protocol support)
Remote Insight Operating System
Support Supported Operating Systems:
Windows NT 3.51 or later,
Novell Netware 3.12, Netware 4.x, NetWare 5
SCO UnixWare 2.x and 7
SCO OpenServer 5
IBM OS/2 Warp Connect 3 & Warp Server 4

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
3DA-10121-01-003 — 01.24.2000
Compaq Remote Insight
COMPATIBILITY
Desktops
Compaq Deskpro EN Series Desktop
Compaq Deskpro EN Series Minitower
Compaq Deskpro EN Series Small Form Factor
Workstations
Compaq Professional Workstation XP1000
Compaq Professional Workstation 6000
Servers
Compaq ProLiant 7000 Xeon™
Compaq ProLiant 6500 Xeon
Compaq ProLiant 6000 Xeon
Compaq ProLiant 5500R Xeon
Compaq ProLiant 5500 Xeon
Compaq ProLiant 3000R 6/450
Compaq ProLiant 3000 6/450
Compaq ProLiant 1850R
Compaq ProLiant 1600R (100 MHz)
Compaq ProLiant 1600 (100 MHz)
Compaq ProLiant 800 6/350E, 6/400, 6/450 MHz
Compaq ProLiant 400
SMB
Compaq Prosignia 740
1Certain restrictions and exclusions apply. Consult the Compaq Customer Support Center at 1-800-OK-COMPAQ for details. In Canada,
consult the Product Information Center at 1-800-567-1616 for details.
2Banyan software support provided independent of Insight Manager at initial release.
