QUICKSPECS
Overview
2-73 1Q1999 North America – Portables
Compaq Armada 7400
1.
Volume Button
2. Suspend Button
3. Microphone
4. Power Switch
5. Tilt Feet
6. Two Type II/One Type III PC Card Slot(s) (Zoomed
video in bottom slot); CardBus Capable7
7. Integrated Modem RJ-11 (modem models only)
8. Security Slot
9. 25-International DAA/Cellular Phone Connector
10. Headphone/Microphone/Stereo Line-In Jacks
11. Inverted-T Cursor Keys
12.
Other MultiBay devices (Diskette Drive [pictured],
second hard drive, SuperDisk LS-120 option and
DVD-ROM Drive)
13. MultiBay ships with 24X Max5 CD-ROM Drive, or
DVD-ROM6 Drive. 1.44 MB Floppy Drive ships
standard with all models
14. Suspend/Power, Batter, Hard Drive, MultiBay
status LEDs
15. Li-Ion Battery Pack
16. Pointing Device Buttons
17. EasyPoint III Pointing Stick
18. Stereo Speakers
19. Removeable SMART Hard Drive up to 10 GB1,2
20. Four User-Programmable Keys
21. 14.1 or 13.3 Color TFT Display
BENEFITS AT
A GLANCE
•IntelMobilePentium®II processor
upto 366MHz
•AGP(Accelerated Graphics Port)
implementation
–66-MHz graphics bus
–4-MB SGRAM
•Durable Magnesium alloy casing
•As light as 6.3 lbs and 1.6 inches
thick
•32- or 64-MB Synchronous DRAM
standard
–Expandable up to 256 MB
•Upto20 GB1storage in portable
withsecond 10 GB1, 2 Hard Drive
•ConvenientMultiBay design
•3 spindle support with Armada
7400/7800 External Diskette Drive
option
•Software:
–Choiceof MS Windows
9.x or MS Windows NT
Workstation 4.0(SP3)
–Intelligent Manageability
–MS Internet Browser
•CompaqServices,including a
three-year,Worldwide Limited
Warranty3with second business
day4expedited pick-up and repair
in North America

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Standard Features
2-74 1Q1999 North America – Portables
Compaq Armada 7400
Powerful Slimline Design
The Armada 7400 is optimized for performance and mobility with unprecedented desktop expansion solutions. This
durable portable’s sleek new design incorporates Compaq’s first magnesium alloy case.
Processor
Intel Mobile Pentium II processor 366 MHz
6366/T/10.0/V/M/3
6366/T/10.0/V/M/1
Intel Mobile Pentium II processor 333 MHz
6333/T/6.4/D/M/3
6333/T/6.4/D/M/1
Intel Mobile Pentium II processor 300 MHz
6300/T/6.4/D/0/3
6300/T/6.4/D/M/1
6300/T/6.4/D/0/1
Intel Mobile Pentium II processor 266 MHz
6266/T/4.0/D/0/1
Cache Memory
512-KB level 2
6300/T/6.4/D/0/3
6300/T/6.4/D/M/1
6300/T/6.4/D/0/1
6266/T/4.0/D/0/1
Integrated 256-KB L2
6366/T/10.0/V/M/3
6366/T/10.0/V/M/1
6333/T/6.4/D/M/3
6333/T/6.4/D/M/1
Memory
Standard 64 MB
Maximum 256 MB
6366/T/10.0/V/M/3
6366/T/10.0/V/M/1
6333/T/6.4/D/M/3
6333/T/6.4/D/M/1
6333/T/6.4/D/0/1
6300/T/6.4/D/M/1
6300/T/6.4/D/0/1
6300/T/6.4/D/0/3
Standard 32 MB
Maximum 256 MB
6266/T/4.0/D/0/1
MODELS
Windows NT Workstation 4.0
and Integrated Modem
6366/T/10.0/V/M/3
(14.1" Display)
387071-002
6366/T/10.0/V/M/3
(13.3" Display)
387072-002
6333/T/6.4/D/M/3
386687-002
Windows NT Workstation 4.0
Non-Modem
6300/T/6.4/D/0/3
204450-002
Windows 95 and Integrated
Modem
6366/T/10.0/V/M/1
(14.1" Display)
387070-002
6366/T/10.0/V/M/1
(13.3" Display)
387068-002
6333/T/6.4/D/M/1
341900-002
6300/T/6.4/D/M/1
204200-002
Windows 95 Non-Modem
6300/T/6.4/D/0/1
204250-002
6266/T/4.0/D/0/1
204150-002

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Standard Features
2-75 1Q1999 North America – Portables
Compaq Armada 7400
Communications
Integrated 56K8V.90 Modem
6366/T/10.0/V/M/3
6366/T/10.0/V/M/1
6333/T/6.4/D/M/3
6333/T/6.4/D/M/1
Integrated 33.6/14.4 Kb/s modem with DSVD upgradeable to K56flex9protocol, direct cellular support and protection
from power surges and digital phone lines
6300/T/6.4/D/M/1
Keyboard
101-key compatible keyboard with isolated, inverted-T cursor control keys and right-control key, four user-
programmable keys, special feature hotkeys for instant access to power conservation, QuickLock/QuickBlank,
battery charge status, brightness, mute, and toggle between internal and external, or simultaneous displays
Pointing Device
Keyboard-integrated, textured,EasyPoint III
PC Card Slots
Two Type II/One Type III PC Card Slot(s), which support both 32-bit CardBus9and 16-bit PC Cards; Zoomed Video
support in bottom slot only; telephony support in top slot only
Storage
Diskette Drives 1.44 MB
DVD-ROM Drive6
6366/T/10.0/V/M/3
6366/T/10.0/V/M/1
CD-ROM
24X Max5CD-ROM Drive
6333/T/6.4/D/M/3
6333/T/6.4/D/M/1
6300/T/6.4/D/0/3
6300/T/6.4/D/0/1
6300/T/6.4/D/M/1
6266/T/4.0/D/0/1
Hard Drives
10-GB1SMART Hard Drive
6366/T/10.0/V/M/3
6366/T/10.0/V/M/1
6.4-GB1 SMART Hard Drive
6333/T/6.4/D/M/3
6333/T/6.4/D/M/1
6300/T/6.4/D/0/3
6300/T/6.4/D/M/1
6300/T/6.4/D/0/1
4-GB1SMART Hard Drive
6266/T/4.0/D/0/1

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Standard Features
2-76 1Q1999 North America – Portables
Compaq Armada 7400
Multimedia
16-bit Compaq PremierSound™ and Hardware Wave Table for enhanced audio (16-bit Sound Blaster Pro
compatible), integrated stereo speakers and Bass Reflex speaker ports, integrated microphone, hardware and
software volume control, headphone, microphone and stereo line-in jacks, standard CD-ROM Drive or DVD Drive,
software MPEG1, software MPEG2 available
Interfaces
PC Card Two Type II/One Type III
Enhanced Parallel 1
Serial 1
External Monitor 1
External Keyboard/
Pointing Device (PS/2) 1
Convenience Base 1
Headphone/Line out 1
Stereo Line In 1
Microphone 1
AC Power 1
RJ-11 1
Infrared 1 (4 Mb/s10 support )
USB 1
Expansion Base 1
Support for Third-Party Y-
Cables (for external mouse
and keyboard)
Yes
Graphics
AGP implementation with dedicated 66-MHz graphics bus
Frame mode support
S3 ViRGE/MX™ graphics controller with 4-MB SGRAM.
Up to 100 Hz external refresh at SVGA resolution up to 16.8M colors
Simultaneous Display support in any resolution
Display
14.1 CTFT 1024 x 768 panel
6366/T/10.0/V/M/3
6366/T/10.0/C/M/1
13.3-in CTFT 1024 x 768 panel
6333/T/6.4/D/M/3
6333/T/6.4/D/M/1
6300/T/6.4/D/M/1
6300/T/6.4/D/0/3
6300/T/6.4/D/0/1
6266/T/4.0/D/0/1

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Standard Features
2-77 1Q1999 North America – Portables
Compaq Armada 7400
Software
Windows NT Workstation 4.0, Insight Management Agents, Compaq Intelligent Manageability, Security 32,
Diagnositcs for Windows NT, Compaq Power Management, Online Safety and Comfort Guide, Reference Guide and
Carbon Copy
6366/T/10.0/V/M/3
6333/T/6.4/D/M/3
Windows NT Workstation 4.0 SP3, Compaq Intelligent Manageability, Microsoft Internet Explorer and power
management
6300/T/6.4/D/0/3
Windows 95 OSR 2.5, Insight Management Agents, Compaq Intelligent Manageability, Security 32, Diagnositcs for
Windows 95, Compaq Power Management, Online Safety and Comfort Guide, Reference Guide and Carbon Copy
6366/T/10.0/V/M/1
6333/T/6.4/D/M/1
Windows 95 OSR 2.5, Compaq Intelligent Manageability, Microsoft Internet Explorer, Microsoft NetMeeting,
Microsoft PC Card Manager
6300/T/4.0/D/0/1
6266/T/4.0/D/M/1
6266/T/4.0/D/0/1
OS Support
Windows NT Workstation 4.0 SP4
Windows NT Workstation 4.0 SP3
Windows 98
Windows 95 OSR 2.5
Windows 3.1x
Intelligent Manageability
The Armada 7400 lowers total cost of ownership by providing enhanced security, asset management and fault
prediction. It also provides SMART hard drive alert, battery fault alert, thermal alert and memory alert for investment
and data protection.
Security
Cable lock support
Power-on and set-up passwords
QuickLock/QuickBlank
Ability to disable serial port
Parallel port, PC Card slots
Diskette drive
Diskette drive boot sequence
Infrared port
MultiBay and hard drive security screw
Memory door security screw (tool included)
DriveLock Security for advanced data protection
Password protection resides on the drive
Power Supply
External AC Adapter with 6-foot power cord

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Standard Features
2-78 1Q1999 North America – Portables
Compaq Armada 7400
Battery
Li-Ion Battery Pack provides up to 2.6 hours11 of battery life. Battery can be swapped when the portable is in
Standby mode. Battery QuickCheck button on battery pack provides instant visual indication of charge status. A new
enhanced battery option (standard on 333/366 MHz models) provides over 3.5 hours of battery life12.
Power Conservation
Hibernation, Instant-On via Suspend/Standby; pop-ups with three presets and one custom level of power
conservation
Service and Support
Compaq Services provides a range of services for the Armada 7400, with 7 x 24 service line at 1-800-OK-COMPAQ
(1-800-652-6672) and a three-year, Worldwide Limited Warranty3with second business day4pick-up and delivery
service from Compaq. All shipping and handling materials are supplied and arranged by Compaq.

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Options
2-79 1Q1999 North America – Portables
Compaq Armada 7400
Memory
128-MB SDRAM Memory 315177-B21
64-MB SDRAM Memory 314891-B21
32-MB SDRAM Memory 314890-B21
Monitors13
TFT8000 Flat Panel 307906-001
TFT5000 Flat Panel 325700-001
TFT450 Flat Panel 170406-001
P1610 Color14 305708-001
P110 Color14 284956-001
P75 Color 307806-001
V1000 Color 351757-001
V900 Color 303500-001
V75 Color 307710-001
V75 Color (carbon) 307710-002
V500 Color 325900-001
S900 Color14 360562-001
S700 Color 360512-001
Optical Drive
Armada 7400/7800 External Diskette
Drive 297186-B21
SuperDisk LS-120 Drive 296502-B25
DVD-ROM6Drive 314914-B25
Hard Drive
10-GB1,2 SMART Hard Drive 354230-B25
6.4-GB1 SMART Hard Drive 204220-B25
PC Cards/Communications
Compaq Microcom 420 56K PC Card 317900-001
SpeedPaq Cellular PC Card 221202-001
10/100 TX PC Card UTP Controller 335506-B21
10 T PC Card UTP Controller 292806-B21
10 2 PC Card Coax Controller 292807-B21
10/100 TX PC Card UTP Controller
Upgrade 292813-B21
100 Base TX Ethernet Upgrade 225435-001
Int’l Modem Adapter 248075-001
Int’l DAA Cables (country specific) 234407-xx3
16/4 TR PC Card IBM UTP/STP
Controller 301208-B21
For additional compatible PC Cards, view the Compaq
PC Card Solutions List on the Compaq website at
http://www.compaq.com/support/techpubs/
pcmcia/pccardlist.html.
Expansion/Convenience Bases
ArmadaStation II Expansion Base (opal) 203100-001
ArmadaStation II Expansion Base
(carbon) 112162-001
ArmadaStation Tower Stand (opal) 267863-B25
Armada 7000 Half Height
MultiBay Adapter 220681-001
Armada 7000 Hard Drive Adapter 267868-B25
Armada 7400 Hard Drive Adapter
(carbon) 267867-B25
MiniStation E Monitor Cover (opal) 319660-001
Armada MiniStation E Convenience Base
(opal) 327137-001
Power
Armada 7400 Li-Ion Battery Pack 267865-B25
Armada 7400 Enhanced Li-Ion Battery
Pack 104724-B25
Armada 7000 Battery Charger 220461-001
Auto/Aircraft adapter 296537-B21
AC Power cord 10-foot 217932-002
AC Adapter (carbon) 220841-005
Input Devices
External Infrared Transceiver 220687-002
External Enhanced III Keyboard
(opal) 294343-001
External Enhanced II Keyboard
(carbon) 104012-001
Compaq Mouse (opal) 143315-B21
Compaq Mouse (carbon) 103180-B21
Compaq/Microsoft Intellimouse 294306-B21
Other
Security Lock 294316-B21
Portable Video Conferencing Kit 296954-001
Universal Monitor Stand 294315-B21
Armada Headset with microphone 220460-001
Carrying Cases
CPQ Value Case 294260-B21
CPQ Workstation Case 294267-B21
CPQ Global Case 294268-B21
CPQ Professional Case (Nylon) 401366-B21
CPQ Professional Case (Leather) 401367-B21
For additional Compaq Brand cases, call
1-800-888-5903.

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Memory
2-80 1Q1999 North America – Portables
Compaq Armada 7400
Compaq Armada 7400 Model 6266/T/4.0/D/0/1
STANDARD MEMORY
32-MB SDRAM Memory Upgrade installed in one slot
Standard Slot
1 2
32 MB Empty
STANDARD MEMORY PLUS
OPTIONAL MEMORY
Support for up to 160 MB of 60 ns EDO RAM is available with the installation of an optional Memory
Upgrade.
Up To Slot
1 2
64 MB
160 MB
STANDARD MEMORY REPLACED
WITH OPTIONAL MEMORY
Support for up to 256 MB of SDRAM memory is available with the removal of the standard 32-MB
Memory Upgrade and the installation of optional SDRAM Memory Upgrade.
Up To Slot
1 2
128 MB Empty
192 MB
256-MB
Note: Because one memory slot is occupied on these products, the 32-MB Memory Upgrade must
be removed to reach the maximum memory of 256 MB. This chart does not represent all possible
memory configurations.
Following are memory options available from Compaq:
•128-MB SDRAM Memory Upgrade 315177-B21
•64-MB SDRAM Memory Upgrade 314891-B21
•32-MB SDRAM Memory Upgrade 314890-B21

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Memory
2-81 1Q1999 North America – Portables
Compaq Armada 7400
Compaq Armada 7400 models 6300/T/6.4/D/M/1, 6300/T/6.4/D/0/3, 6333/T/6.4/D/M/1,
6333/T/6.4/D/M/3, 6366/T/10.0/V/M/1, 6366/T/10.0/V/M/3
STANDARD MEMORY
64-MB SDRAM Memory Upgrade installed in one slot
Standard Slot
1 2
64 MB Empty
STANDARD MEMORY PLUS
OPTIONAL MEMORY
Support for up to 192 MB of SDRAM is available memory with the installation of an optional
SDRAM Memory Upgrade.
Up To Slot
1 2
96 MB
192 MB
STANDARD MEMORY REPLACED
WITH OPTIONAL MEMORY
Support for up to 256 MB of SDRAM memory is available with the removal of the standard 32-MB
Memory Upgrade and the installation of optional SDRAM Memory Upgrade.
Up To Slot
1 2
128 MB Empty
192 MB
256 MB
Note: Because one memory slot is occupied on these products, the 64-MB Memory upgrade must
be removed to reach the maximum memory of 256 MB. The memory options supported on the
Armada 7400 family are as follows. This chart does not represent all possible memory
configurations.
Following are memory options available from Compaq:
•128-MB SDRAM Memory Upgrade 315177-B21
•64-MB SDRAM Memory Upgrade 314891-B21
•32-MB SDRAM Memory Upgrade 314890-B21

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Storage
2-82 1Q1999 North America – Portables
Compaq Armada 7400
DRIVE SUPPORT Quantity
Supported Drive Bay Supported
Removeable Media
1.44-MBDiskette Drive Up to 1 MultiBay
DVD-ROM6Drive Upto 1 MultiBay
24X Max5CD-ROMDrive Up to 1 MultiBay
SuperDisk LS-120 Upto 1 MultiBay
Hard Drives
10-GB1, 2 SMART Hard Drive Up to 2 Upgradeable Hard Drive and MultiBay
6.4-GB1SMARTHard Drive Upto 2 Upgradeable Hard Drive and MultiBay
1MultiBay
2Removeable Hard Drive

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Technical Specifications
2-83 1Q1999 North America – Portables
Compaq Armada 7400
System Unit Dimensions (HxWxD) 1.6 x 12.5 x 9.6 in/4.06 x 31.75 x 24.38 cm
Weight (modem installed)
CD-ROM configured
Without AC Adapter 7 lbs/3.2 kg
With AC Adapter (total carrying weight) 7.9 lbs/3.5 kg
FDD configured
Without AC Adapter 6.7 lbs/3.0 kg
With AC Adapter (total carrying weight) 7.6 lbs/3.3 kg
Weight Saver configured
Without AC Adapter 6.4 lbs/2.8 kg
With AC Adapter (total carrying weight) 7.3 lbs/3.2 kg
Weight (no modem installed)
CD-ROM configured
Without AC Adapter 7 lbs/3.2 kg
With AC Adapter (total carrying weight) 7.9 lbs/3.4 kg
FDD configured
Without AC Adapter 6.7 lbs/2.9 kg
With AC Adapter (total carrying weight) 7.6 lbs/3.4 kg
Weight Saver configured
Without AC Adapter 6.3 lbs/2.7 kg
With AC Adapter (total carrying weight) 7.2 lbs/3.1 kg
Stand-Alone Power Requirements
Average Operating Power 20W
Peak Operating Power 28W
Power Supply
Rated Input Voltage 100 to 120/220 to 240
Rated Input Current 1.2/0.6A
Rated Frequency 50 to 60 Hz
Temperature
Operating 10°to 40°C
Non-operating –20°to 60°C
Relative Humidity
Operating 10% to 90% relative humidity, non-condensing
Non-operating 5% to 95% relative humidity, 38.7°C Maximum wet bulb
temperature
Shock
Operating 10 G, 11 ms, half-sine
Non-operating 60 G, 11 ms, half-sine
Vibration
Operating 0.25 G, 50-500 Hz sine, 1/2 octave/minute sweep
Non-operating 1 G, 50-500 Hz sine, 1/2 octave/minute sweep
Maximum Altitude
Operating 0 to 10,000 ft/3.05 km (14.7 to 10.1 psia)
Non-operating 0 to 30,000 ft/9.14 km (14.7 to 4.4 psia)

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Technical Specifications
2-84 1Q1999 North America – Portables
Compaq Armada 7400
Display LCD Dimensions 7.98 x 10.64 in/20.28 x 27.03 cm
Diagonal Size 13.3 in/33.79 cm
Mounting Internal Panel Supports
Number of Colors Up to 16.8M
Contrast Ratio 150:1
Brightness 130 cd/m2
Pixel Resolution
Pitch 0.264 x 0.264 mm
Format 1024 x 768
Configuration RGB stripe
Backlight Edge Lit
Character Display 80 x 25
Total Power Consumption (maximum) 4.2W
Hard Drives 10 GB1,2 Capacity 10 GB1
Height 1 in
Size 2.5 in
Interface ATA
Transfer Rate
Synchronous (Max) 33.3 MB
Seek Time (typical reads, including settling)
Single Track 4 ms
Average 12 ms (read)
Full-Stroke 23 ms
Rotational Speed 4200 rpm
Physical Configuration
Bytes/sector 512
Logical Blocks 1964080
Operating Temperature 5°to 55°C
6.4 GB1Capacity 6.4 GB1
Height 1 in
Size 2.5 in
Interface ATA
Transfer Rate
Synchronous (Max) 33.3 MB
Seek Time (typical reads, including settling)
Single Track 4 ms
Average 13 ms (read)
14 ms (write)
Full-Stroke 23 ms
Rotational Speed 4009 rpm
Physical Configuration
Bytes/sector 512
Logical Blocks
Operating Temperature 5°to 55°C
4 GB1Capacity 4 GB1
Height 1 in
Size 2.5 in
Interface ATA
Transfer Rate
Synchronous (Max) 33.3 MB
Seek Time (typical reads, including settling)
Single Track 4 ms
Average 13 ms (read)
14 ms (write)
Full-Stroke 23 ms
Rotational Speed 4009 rpm
Physical Configuration
Bytes/sector 512
Logical Blocks
Operating Temperature 5°to 55°C

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Technical Specifications
2-85 1Q1999 North America – Portables
Compaq Armada 7400
Diskette Drive Diskette Size 3.5 in
Light on system
Height 0.5 in/12.7 mm
Bytes per Sector 512
Sectors per track
High density 18 (1.44 MB)/15 (1.2 MB)
Low density 9
Tracks per side
High density 80 (1.44 MB)/80 (1.2 MB)
Low density 80
Read/Write heads 2
Access Times
Track-to-track (high/low) 3 ms/6 ms
Average (high/low) 94 ms/174 ms
Settling time 15 ms
Latency average 100 ms
AC Adapter Dimensions (HxWxL) 5 x 2.08 x 1.15 in/12.7 x 5.29 x 2.92 mm
Weight 0.62 lbs/0.282 kg
Power Supply Input
Nominal Voltage 120 VAC
Current 0.6/1 A
Voltage Range 90 to 265 VAC
Input Frequency 47 to 63 Hz
Power Supply (Output)
Nominal Voltage 18.85 VDC
Current 3.2 A
Temperature
Nominal Operating 77°F/25°C
Operating 41°to 104°F/5°to 40°C
Non-operating –4°to 185°F/–20°to 85°C
Relative Humidity
Operating
Non-operating The power supply withstands up to 95% relative humidity,
non-condensing both operating and non-operating without
degradation.

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Technical Specifications
2-86 1Q1999 North America – Portables
Compaq Armada 7400
Li-Ion Battery Pack Dimensions 79 x 3.46 x 5.43 in/2 x 8.8 x 13.8 cm
Weight 0.92 lbs/0.40 kg
Energy
266/300 MHz
Voltage 14.4 V
Amp-hour capacity 3.02 Ah
Watt-hour capacity 43Wh
333/366 MHz
Voltage 14.4 V
Amp-hour capacity 3.02 Ah
Watt-hour capacity 46Wh (with calibration)
Performance
266/300 MHz
Single battery life Over 2.5 hours11
333/366 MHz
Single battery life (with calibration) Over 3.5 hours12
Temperature
Operating 50°to 104°F/10°to 40°C
Non-operating recommended storage –12°to 140°F/–30°to 60°C
DVD-ROM6Drive Center Hole Diameter 0.59 in/.39 cm
Disc Diameter 12 cm, 8 cm
Disc Thickness 1.2 mm
Track Pitch 0.74 µm
Access Times (typical reads, including settling)
Random < 150 ms
Full-Stroke < 225 ms
Audio Output Level
Line Out 0.7 Vrms (typical)
Cache Buffer 128 Kb/s (minimum)
Data Transfer Rates
Sustained 1X 150 Kb/s
Sustained DVD 2760 Kb/s
Normal PIO Mode 4 (single burst) 16.6 Mb/s
Start Time < 15 sec (typical)
Stop Time < 6 sec

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Technical Specifications
2-87 1Q1999 North America – Portables
Compaq Armada 7400
24X Max5CD-ROM Drive Applicable Disc CD-ROM (Mode 1, 2 and 3), CD-XA ready (Mode 2,
Form 1 and 2), CD-I ready (Mode 2, Form 1 and 2),
CD-R (read only), CD Plus, Photo CD (Single and Multi-
session), CD Extra, Video CD, CD-WO (fixed packets only)
CD-Bridge
Center Hole Diameter 0.59 in/.39 cm
Disc Diameter 12 cm, 8 cm
Disc Thickness 1.2 mm
Track Pitch 1.6 µm
Access Times (typical reads, including settling)
Random < 150 ms
Full-Stroke < 300 ms
Audio Output Level
Line Out 0.7 Vrms
Cache Buffer 128 KB
Data Transfer Rates
Sustained 150 KB/s (sustained 1X)
Variable 1500-3600 KB/s (10X to 24X)
Start Time < 8 sec
Stop Time < 4 sec
1For Hard Drives, GB = Billion Bytes.
2When the 10-GB Hard Drive becomes available as an option in 2Q99.
3Certain restrictions and exclusions apply. Service and support programs vary by geographic regions. Consult the Compaq Customer
Service Center for details.
4Pick-up and delivery service is available in 48 contiguous US States and Canada. Eligibility for priority pick-up (second business day
return) is limited to certain geographic locations. Carry-in services available outside the US and Canada.
5Data transfer rates will vary from 150 KB/s to 3600 KB/s.
6DVD Express software is available through the Business Reply card that ships standard with the portable or optional DVD-ROM Drive.
DVD Express allows video playback of DVD movies, etc, except under Windows NT Workstation 4.0. The DVD-ROM Drive has the
capacity to store up to 7 times the capacity of a CD-ROM Drive.
7Full support in Windows 9.x.
8Designed only to allow faster downloads from 56K V.90 compliant sources. Maximum achievable download transmission rates currently
do not reach 56 KB/s, and will vary with line conditions. Modem only supports Windows 9.x and Windows NT Workstation 4.0.
9Designed only to allow faster downloads from K56flex compliant sources. Maximum achievable download transmission rates currently
do not reach 56 KB/s, and will vary with line conditions. Modem only supports Windows 9.x and Windows NT Workstation 4.0.
10 IrDA 4 MB compliant. IR performance will vary depending on performance of IR peripherals and applications used.
11 Actual results may vary with individual usage. When tested in a standard configuration, using the Ziff-Davis BatteryMark test version 2.0,
the Battery life of the Armada 7400 will range up to 2.6 hours. Standard configuration at time of announcement is considered to be a
10X7 (256 colors) panel set at 50 percent brightness, 32-MB RAM and no drives other than the hard drive active.
12 Actual results may vary with individual usage. When tested in a standard configuration, using the Ziff-Davis BatteryMark test version 2.0,
the Battery life of the Armada 7400 will range up to 3.7 hours. Standard configuration at time of announcement (1/25/99) is considered
to be a 10X7 (256 colors) 14.1″panel set at 50 percent brightness, 64-MB RAM and no drives other than the hard drive active.
13 AssetControl monitor. AssetControl features are accessible with Compaq desktops featuring Intelligent Manageability.
14 May not be compatible with the Armada Station Monitor Support Stand, the Convenience Base I, or the Convenience Base II due to
weight limitations.
