Maintenance and Service Guide Addendum
Compaq Armada 1500 Family of Personal Computers
First Edition (January 1998)
Spare Part Number 255011-001
Document Part Number 255318-001
Compaq Computer Corporation

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Addendum to Compaq Armada 1500
Maintenance and Service Guide
Addendum 255318-001 to Guide 284820-001 1
Computer Product
Description
1.1 Models and Features
The following information describes new models and features of the Compaq Armada
1500 Family of Personal Computers. Selected models include Pentium processors
with MMX technology, faster internal modem, larger hard drive, faster internal CD-
ROM drive, and mechanical enhancements to the base enclosure. A list of standard
features and supported options are provided in Chapter 1 of the Maintenance and
Service Guide, Compaq Armada 1500 Family of Personal Computers. The following
computer models are available:
Compaq Armada 1500 Family Models
Model Pentium Processor Display Hard Drive Memory Std / Max Level 2 Cache CD- ROM Modem ( Kbps ) Serial Configuration
1530D 133-MHz 12.1 STN 1.4-GB 16/80 MB 256-Kbyte 10X BRX1
1530DM 133-MHz 12.1 STN 1.4-GB 16/80 MB 256-Kbyte 10X 33.6 BRX2
1535DM 133-MHz 12.1 STN 1.4-GB 16/80 MB 256-Kbyte 12X 33.6 BRX3
1540D 150-MHz 12.1 TFT 2.1-GB 16/80 MB 256-Kbyte 20X BRX5
1540DM 150-MHz 12.1 TFT 2.1-GB 16/80 MB 256-Kbyte 20X 33.6 BRX6
1545DM 150-MHz 12.1 TFT 2.1-GB 16/80 MB 256-Kbyte 20X 56 BT61
1560 166-MHz 12.1 STN 2.1-GB 16/80 MB 256-Kbyte  BT51
1560D 166-MHz 12.1 STN 2.1-GB 16/80 MB 256-Kbyte 20X BT52
1560DM 166-MHz 12.1 STN 2.1-GB 16/80 MB 256-Kbyte 20X 56 BT53
1580DT 150-MHz 12.1 TFT 2.1-GB 16/80 MB 256-Kbyte 10X BM58
1580DMT150-MHz 12.1 TFT 2.1-GB 16/80 MB 256-Kbyte 10X 33.6 BM59
1585DMT150-MHz 12.1 TFT 2.1-GB 16/80 MB 256-Kbyte 12X 33.6 BRX4
1590DT 166-MHz 12.1 TFT 2.1-GB 16/80 MB 256-Kbyte 20X BRX7
1590DMT166-MHz 12.1 TFT 2.1-GB 16/80 MB 256-Kbyte 20X 33.6 BRX8
1592DT 233-MHz MMX 12.1 TFT 3.2-GB 32/96 MB 512-Kbyte 20X BT54
1592DMT233-MHz MMX 12.1 TFT 3.2-GB 32/96 MB 512-Kbyte 20X 56 BT55

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Addendum to Compaq Armada 1500
Maintenance and Service Guide
2Addendum 255318-001 to Guide 284820-001
1.2 Features
The following features are provided on selected models:
EDO Dynamic Random Access Memory (DRAM) system memory: 16-MB expandable to 80-
MB, or 32-MB expandable to 96-MB
1.44-GB, 2.1-GB or 3.2-GB hard drive
11.3-inch Super Twisted Neumatic (STN) or 12.1-inch Thin Film Transistors (TFT) SVGA
display
33.6Kbps integrated modem or 56Kbps internal controllerless modem. (Both are standard on
selected models and available as an option on other models.)
Internal CD-ROM Drive standard on selected models and available as an option on other
models
Universal Serial Bus (USB) connector standard on selected models
2-MB video memory
256-Kbyte L2 Cache memory, or 512-Kbyte L2 Cache memory
Two standard device slots that will accommodate two types I and II and one type III PC
Cards, PCMCIA and Bus cards; Compaq Telephony modem in the top slot and Zoomed-
Video in the bottom slot
The following features are provided on all models:
Supports Lithium Ion (Li-ion) and Nickel Metal Hydride (NiMH) modular battery packs
SoundBlaster-compatible audio controller with internal stereo speakers and internal
microphone
Full-size 101 key compatible keyboard including 12 function keys, 8 cursor control keys,
inverted-T cursor control keys and embedded numeric keypad
Four user-programmable keys
Touchpad pointing device
Operates from an internal battery pack, plus an optional battery pack in the Dualbay, or
integrated AC power that is compatible with domestic and international power sources
Power management and security features

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Addendum to Compaq Armada 1500
Maintenance and Service Guide
Addendum 255318-001 to Guide 284820-001 3
Infrared interface for wireless communications with other IrDA-compliant devices at data
rates up to 4 MB/sec
176 pin expansion connector provides the interface to the Convenience Base options
Rear-panel ports provide connections for parallel and serial, external monitor,
keyboard/mouse and IrDA compliant infrared devices
1.3 Software Fulfillment
Replacement software may be ordered directly from Compaq Computer Corporation. Both the
model and the serial number of the computer are needed to identify the specific software
available.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Addendum to Compaq Armada 1500
Maintenance and Service Guide
4Addendum 255318-001 to Guide 284820-001
1.4 External Computer Components
The following information provides new mechanical changes to the models, which are different
from earlier models
Universal Serial Bus
A Universal Serial Bus (USB) connector has been added to select models on the left side of the
computer. The connector provides an interface for USB peripheral devices.
On models without the USB connector, a plastic insert covers the connector space. The plastic
USB cover is included in spare part 254981-001, the miscellaneous spare parts kit. The kit also
ships with such items as replacement clutch covers, rubber feet, battery spacer door, etc. (See
Chapter 4 in the Maintenance and Service Guide for miscellaneous spare parts.)
Battery Spacer Door
IMPORTANT: The Battery Spacer Door, which is a component of the Dualbay compartment, has
been modified.
The new battery spacer door pushes 1pushes inward with a single motion, as compared to the
previous version 2which pulled out and pushed inward (
Figure 1-1).
NOTE: The Battery Spacer Door is included in the miscellaneous spare parts kit (spare part
254981-001).
Figure 1-1. New Battery Spacer Door

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Addendum to Compaq Armada 1500
Maintenance and Service Guide
Addendum 255318-001 to Guide 284820-001 5
Illustrated Parts for the
Computer
4.0 Illustrated Parts for the Computer
For an illustrated parts breakdown, refer to the Illustrated Parts Map. The following information
provides new spare parts descriptions and part numbers.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Addendum to Compaq Armada 1500
Maintenance and Service Guide
6Addendum 255318-001 to Guide 284820-001
The following tables are updated to include the new spare parts. For illustrations of spare parts,
refer to the Maintenance and Service Guide, Compaq Armada 1500 Personal Computers or
Illustrated Parts Map.
Table 4-1
System Unit
Description Model(s) Spare Part Number
Keyboard Assembly
US/Canada All models 254968-001
Belgian All models 254968-181
Brazilian All models 254968-035
Danish All models 254968-081
French All models 254968-051
French Canadian All models 254968-121
German All models 254968-041
Italian All models 254968-061
Japanese All models 254968-191
Korean All models 254968-033
Latin American All models 254968-161
Norwegian All models 254968-101
Portuguese All models 254968-131
Spanish All models 254968-071
Swedish/Finnish All models 254968-091
Swiss All models 254968-111
Taiwanese All models 254968-034
UK All models 254968-031
Top Cover Assembly
(keyboard cover) All models 254978-001
Speakers All models 254979-001
Base enclosure assembly 1510, 1510DM, 1520, 1520D,
1520DM, 1530D, 1530DM,
1535DM, 1550T, 1550DMT,
1575DMT, 1580DT, 1580DMT,
1590DT, 1590DMT
254969-001
Base enclosure assembly 1540D, 1540DM, 1560DT,
1560DMT, 1590DT, 1590DMT 212535-001
Display Assembly
11.3 inch STN 1510, 1510DM, 1520, 1520D,
1520DM 254966-001
12.1 inch TFT 1550T, 1550DMT, 1580DT,
1580DMT, 1585DMT, 1590DT,
1590DMT
254967-001
12.1 inch TFT 1592DT, 1592DMT 255308-001
12.1 inch STN 1530, 1530D, 1530DM,
1535DM, 1540D, 1540DM,
1560, 1560D, 1560DM
255131-001

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Addendum to Compaq Armada 1500
Maintenance and Service Guide
Addendum 255318-001 to Guide 284820-001 7
Table 4-2
Mass Storage Devices
Description Model(s) Spare Part Number
CD-ROM
10X CD-ROM Drive 1510DM. 1520D, 1520DM,
1550DMT, 1530D, 1530DM,
1580DT, 1580DMT
254974-001
20X Max CD-ROM Drive 1540D, 1540DM, 1560D,
1560DM, 1560DT, 1560DMT,
1590DT, 1590DMT, 1592DT,
1592DMT
255215-001
Hard Drive
1.08GB, 3 inch /2.5 inch 1510, 1510DM, 1520, 1520D,
1520DM 254963-001
1.44GB, 3 inch/2.5 inch 1530, 1530D, 1530DM,
1535DM, 1550T, 1550DMT 254964-001
2.1-GB 1540D, 1560, 1580DT,
1580DMT, 1585DMT, 1590DT 255130-001
3.2-GB 1560D, 1560DM, 1592DT,
1592DMT 255248-001
Diskette Drive
1.44MB Diskette Drive All models 254962-001
Battery Packs
NiMH All models 254959-001
Li-Ion All models 254960-001

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Addendum to Compaq Armada 1500
Maintenance and Service Guide
8Addendum 255318-001 to Guide 284820-001
Table 4-3
Cables and Power Cords
Description Model(s) Spare Part Number
CD-ROM Cable All models 254975-001
Modem Cable All models 165224-001
AC Adapter, internal All models 254961-001
AC Power Cord Refer to the
Maintenance &
Service Guide
Refer to the
Maintenance &
Service Guide
RTC Battery (with cable) All models 254971-001
Microphone All models 254981-001
Fan 1510,1510DM,1520, 1520D,
1520DM, 1530D, 1530DM,
1535DM, 1550T, 1550DMT,
1575DMT, 1580DT, 1580DMT,
1585DMT
254977-001
Fan 1540D, 1540DM, 1560, 1560D,
1560DM, 1590DT, 1590DMT,
1592DT,1592DMT
255194-001

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Addendum to Compaq Armada 1500
Maintenance and Service Guide
Addendum 255318-001 to Guide 284820-001 9
Table 4-4
Standard and Optional Boards
Description Model(s) Spare Part Number
LED Board
11.3 inch display LED board 1510, 1510DM, 1520, 1520D,
1520DM 254958-001
12.1 inch TFT display LED board 1550T, 1550DMT, 1580DT,
1580DMT, 1585DMT 255049-001
12.1 inch STN display LED board 1530, 1530D, 1530DM,
1535DM, 1540D, 1540DM,
1560, 1560D, 1560DM
255189-001
12.1 inch TFT display LED board 1590DT, 1590DMT,
1592DT,1592DMT 255190-001
I/O Fixture Connector All models 254956-001
DC/DC Converter Board All models (except MMX
models) 254976-001
DC/DC Converter Board,
2.5 / 2.45 / 2.9v All MMX models except as noted below 255161-001
DC/DC Converter Board, 1.8v Armada 1592 255262-001
Audio Board All models 254957-001
System CPU Board
120-MHz processor 1510, 1510DM 254949-001
133-MHz processor 1520, 1520D, 1520DM, 1550T,
1550DMT 255010-001
133-MHz processor with MMX 1530, 1530D, 1530DM,
1535DM 255129-001
150-MHz processor 1580DT, 1580DMT, 1585DMT 255071-001
150-MHz processor with MMX 1540D, 1540DM 255187-001
166-MHz processor with MMX 1560, 1560D, 1560DM 255310-001
166-MHz processor with MMX 1590DT, 1590DMT 255188-001
233-MHz MMX processor 1592DT, 1592DMT 255246-001

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Addendum to Compaq Armada 1500
Maintenance and Service Guide
10 Addendum 255318-001 to Guide 284820-001
Table 4-5
Options
Description Models Spare Part Number
Power Cord
US/Canada/Latin America/Brazil All models 246959-001
Australia/New Zealand All models 246959-011
Denmark All models 246959-081
Europe All models 246959-021
Italy All models 246959-061
Japan All models 246959-291
Korea All models 246959-AD1
Switzerland All models 246959-AG1
UK/Singapore All models 246959-031
Automobile Adapter All models 218079-001
Battery Packs
NiMH All models 254959-001
Li-Ion All models 254960-001
Battery Charger All models 950970-001

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Addendum to Compaq Armada 1500
Maintenance and Service Guide
Addendum 255318-001 to Guide 284820-001 11
Table 4-6
Miscellaneous Parts
Description Model(s) Spare Part Number
Miscellaneous Plastics Kit, includes: All models 254981-001
Left clutch cover
Microphone/display cable cover
Right clutch cover
Battery spacer door
CD-ROM access door All models with integrated
CD-ROM drives
Modem access door
Rubber feet
Display Logos All models 255013-001
Hinge and Latch Kit, includes: All models 254982-001
Display clutch retaining plate (2 each)
Display clutch (2 each)
Display latch (2 each)
Display latch spring (2 each)
Rubber screw covers (4 each)
Miscellaneous Screw Kit, includes All models 254980-001
T-8, long (50 each)
T-8, short (10 each)
T-8, with Ny-Loc (4 each)
7mm (10 each)
5 mm (10 each)
Miscellaneous Plastics Kit All models 254981-001
Maintenance and Service Guide All models 255011-001
Illustrated Parts Map All models 255012-001
Armada 1500 Software CD All models 255097-001
Quick Restore Software CD for
model 1535DM All models 255180-001
Quick Restore Software CD for
model 1585DMT All models 255181-001

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Addendum to Compaq Armada 1500
Maintenance and Service Guide
12 Addendum 255318-001 to Guide 284820-001
Table 4-7
Accessories
Description Models Spare Part Number
Power Cord
US/Canada/Latin America/Brazil All models 246959-001
Australia/New Zealand All models 246959-011
Denmark All models 246959-081
Europe All models 246959-021
Italy All models 246959-061
Japan All models 246959-291
Korea All models 246959-AD1
Switzerland All models 246959-AG1
UK/Singapore All models 246959-031
Automobile Adapter All models 218079-001
Battery Packs
NiMH 254959-001
Li-Ion 254960-001
Battery Charger 950970-001
Convenience Bases
Convenience Base Pass-Through model 254988-001
Convenience Base Ethernet model with
10BaseT 254987-001
Convenience Base BNC model with
10BaseT 254989-001
Monitor Stand 254990-001
100BaseT Ethernet Upgrade 225436-001
Modem
33.6 Data/Fax Modem with install diskette 1510DM, 1520DM,
1530DM, 1535DM,
1540DM, 1550DMT,
1580DMT, 1585DMT,
1590DMT
North America
255014-001
Japan
255014-191
Asia
255014-371
56K Voice / Fax / Data Modem
(controllerless, integrated) 1560DM, 1592DMT 255245-001
Modem Cable (RJ11) All models 165224-001
10’ AC Power Cord Extension
US All models 255135-001
Australia All models 255135-011
Denmark All models 255135-081
Europe All models 255135-021
Italy All models 255135-061
Japan All models 255135-291
Korea All models 255135-AD1
UK All models 255135-031
Singapore All models 255135-111

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Addendum to Compaq Armada 1500
Maintenance and Service Guide
Addendum 255318-001 to Guide 284820-001 13
Option Spares
Table 4-8
Accessories
Description Models Spare Part Number
Memory Expansion Board
8MB All models 272108-001
16MB All models 272110-001
32MB All models 220583-001
64MB All models 273158-001
CD-ROM Drive
10X CD-ROM Drive All models 254974-001
20X Max CD-ROM Drive All models 255215-001
56K Voice/Fax/Data Modem
(Controllerless, Integrated) All models 255245-001
33.6 Data/Fax Modem (Integrated) All models 255014-001

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Addendum to Compaq Armada 1500
Maintenance and Service Guide
14 Addendum 255318-001 to Guide 284820-001
9.0 Specifications
This chapter provides specifications on the following new components:
2.1-GB Hard Drive
3.2-GB Hard Drive
20X Max CD-ROM
12.1-inch TFT, SVGA display

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Addendum to Compaq Armada 1500
Maintenance and Service Guide
Addendum 255318-001 to Guide 284820-001 15
Table 9-1
Hard Drives
Standard Model Configurations 2.1-GB 3.2-GB
Formatted Capacity Per Drive (MB)
Physical 2.16 3.24
Logical 2.1 3.2
Drive Type 65 65
Drive Height
With drive frame (mm) 12.7mm 12.7mm
Drive Size
Inches 3.94 x 2.75 4.01 x 2.75
Millimeters 100.2 x 69.85 102 x 69.85
Transfer Rate
Media (Mb/s) 38.1 to 54.8 51.7 to 83.4
Interface (Mb/s) 16.6 33.3
Sector Interleave 1:1 1:1
Typical Seek Time (including setting)
Single Track (ms) 4 4
Average (ms) 13 13
Full Stroke (ms) 23 23
Disk Rotational Speed 4,200 4,000
Physical Configuration
Cylinders 4928 6975
Data Heads 6 5
Sectors per Track 110-180 144-240
Bytes per Sector 512 512
Logical Configuration
Cylinders 4200 6304
Data Heads 16 16
Sectors per Track 63 63
Bytes per Sector 512 512
Buffer Size 128 128

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Addendum to Compaq Armada 1500
Maintenance and Service Guide
16 Addendum 255318-001 to Guide 284820-001
Table 9-2
20X Max CD-ROM Drive
Applicable Disc CD-ROM mode 1, mode 2
CD-Digital Audio
CD-XA mode 2 (Form 1, Form 2)
CD-I mode 2 (Form 1, Form 2)
CD-I Ready
CD-Bridge
CD-WO (fixed / variable packets)
Photo CD (single / multi-session)
Center Hole Diameter 15mm
Disc Diameter 12cm, 8cm
Disc Thickness 1.2mm
Track Pitch 1.6 µm
Laser
Beam Divergence 53.5 + 1.5 degrees
Output Power 0.13 + 0.1 mw
Type Semiconductor Laser GaA1As
Wave Length 780 nm + 25 nm
Access Time
Random < 150 ms
Full Stroke < 600 ms
Audio Output Level
Line Out 0.7 Vrms
Headphone None
Cache Buffer 256 KB
Data Transfer Rate
Sustained, quad 300 MB/sec
Sustained, single 150 KB/sec
Burst 8.3 MB/sec
Startup Time < 10 seconds typical
Capacity
Mode 1, 12 cm 550 MB
Mode 2, 12 cm 640 MB
8 cm 180 MB

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Addendum to Compaq Armada 1500
Maintenance and Service Guide
Addendum 255318-001 to Guide 284820-001 17
Table 9-3
12.1-inch TFT, SVGA Display
U.S. Metric
Dimensions
Height 7.24 in. 184 mm
Width 9.7 in. 245 mm
Number of Colors 16 million 16 million
Contrast Ration Over 100:1 Over 100:1
Pixel Resolution
Pitch 0.30 x 0.30 mm 0.30 x 0.30 mm
Format 800 x 600 800 x 600
Configuration RGB Stripe RGB Stripe
Backlight 130 cd/m2130 cd/m2

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Addendum to Compaq Armada 1500
Maintenance and Service Guide
18 Addendum 255318-001 to Guide 284820-001
Appendix C
Modem Commands
This section includes modem commands for the 56Kbps internal modem. The telephony modem
is designed to operate with the preinstalled software in the computer. The modem is compatible
with Microsoft Windows 95 (and later) or Windows NT 4.0.
Table C-1
Modem Commands
Command Description
A Answer Command. A instructs the modem to go off-hook and answer an incoming call.
Bn Communication Standard Setting. Bn determines CCIT vs. Bell standard.
0: Selects CCITT V .22 mode when the modem is at 1200bits/s
1: Selects Bell 212A when the modem is at 1200bits/s (default).
2: Unselects V23 reverse channel (same as B3).
3: Unselects V23 reverse channel (same as B2).
15: Selects V.21 when the modem is at 300 bits/s
16: Selects Bell 103J when the modem isat 300 bits/s (default).
Result Codes:
OK n=0, 1, 15, 16
ERROR Otherwise
Cn Carrier Control. The modem will accept the C1 command without error in order to assure
backward compatibility with communications software that issues the C1 command.
However, this modem does not support the C0 command. The C0 command may instruct
some earlier modems (such as the Smartmodem 1200) to not send carrier (ie., it puts them
in a receive-only mode).
0: Transmit carrier always off.
1: Normal transmit carrier switching.
Result Codes:
OK n=1
ERROR Otherwise Continued
