Overview
1DA-10472-01-002 — 11.29.1999
Compaq Prosignia
Notebook 170
Configured to Order
1. 14.1-in or 13.1-in TFT 1024 x 768 display
2. Microphone
3. Power Switch
4. Integrated RJ-11 Jack, 56K V.901Mini PCI modem;
Optional RJ-11 and RJ-45 Jack with Intel PRO+
Mini PCI (not shown)
5. MultiBay
6. PC Card Slots
7. Battery Power Light
8. AC Power Light
9. Microphone Jack
10. Stereo Speaker/Headphone Jack
11. Primary Battery
12. Primary Hard Drive
13. Left/Right/Third Mouse Buttons
14. 3D Point Stick
15. Stereo Speakers
16. Cable Lock Connector
17. NTSC/PAL Connector
18. Lid Switch
19. Suspend Button
20. Status LEDs
AT A
G
LANCE
•Immediate out-of-box productivity
with pre-installed software, like
Microsoft Office Small Business,
and accessto convenient
CompaqOnline Services
•8-MBVideoSDRAM
•Weight starting at 5.3 lbs
•1.1 inches thin
•Integrated 56K V.901Mini PCI
modem
•Full-size keyboard
•User removable hard drive
•Dual batterysupport
•MultiBaytechnologysupportsan
additional 6-cell Battery, Second
Hard Drive, 24X Max2CD-ROM,
4X3DVD-ROM drive, or LS-120
drive
•AGP 2XGraphics
–8-MBVideoSDRAM
–66-MHzgraphicsBUS
–Dual-view display support
–NTSC/PAL output
•Magnesium LCD display
enclosure
•Docking solutions
•CompaqServices, including a
three-year, WorldwideLimited
Warranty3 with a free one-year,
second business day4pick-up and
delivery service
CONFIGURABLE
COMPONENTS
•Choice of Intel PentiumIII 500-
or 450- or PentiumII 366-MHz
processor
•Choice of 14.1 or 13.3 TFT
1024 x 768 display
•Choice of 4-, 6-, 12- or 18-GB5
removable harddrives
•Choice of 24X Max2CD-ROM or
4X DVD-ROM6
•32 MB (PentiumII) standard
SDRAM upgradable to 288 MBor
64 MB (PentiumIII) upgradable to
320 MB
•Integrated Mini PCI V.907
data/14.4 Kb/s fax modem or
V.907 fax/modem Intel PRO+
Ethernet combination card)
•Choice of Pointing Stick or Touch
Pad
•Choice of Microsoft Office 2000
Small Business, Office 2000
Professional or Word 2000
•Other components available

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Standard Features
2 DA-10472-01-002 — 11.29.1999
Compaq Prosignia
Notebook 170
Configured to Order
Flexible Solutions Configured to Order
Order the Prosignia Notebook 170 the way the customer wants it by selecting the processor, hard drive, memory, and
more. Purchase directly from Compaq or a Compaq Authorized Agent. Configurable components and Options
change frequently. Check Q-View or www.compaq.com for the latest options available from Compaq. Please note
this website is available in English only.
Processor
Intel Pentium III processor 500 or 450 MHz
Intel Pentium II processor 366 MHz
Cache Memory
256K Integrated
Memory
Intel Pentium III
Standard 64 MB
Maximum 320 MB
Intel Pentium II
Standard 32 MB
Maximum 288 MB
Primary Storage
Diskette Drives 1.44 MB (All Models)
Hard Drives 18-, 12-, 6-, or 4-GB5Ultra ATA
MultiBay Devices
4X4DVD-ROM
24X Max3CD-ROM
SuperDisk LS-120
MultiBay Battery
Secondary Hard Drive
Communications
Integrated Mini-PCI 56K V.901modem or Mini PCI 56K V.901modem and Ethernet NIC combination
Keyboard
102-key compatible keyboard with isolated, inverted-T cursor control keys, and right-control key, special feature
hotkeys for instant access to power conservation, QuickLock/QuickBlank, toggle between internal and external,
or simultaneous displays, battery gauge, speaker volume control, brightness and contrast
Pointing Device
Touch Pad or Pointing Stick
PC Card Slots
Two Type II/One Type III PC Card Slot(s) which support both 32-bit CardBus7 and 16-bit PC Cards; zoomed video
support in both slots
MODELS
Configured to Order
Prosignia Notebook 170
Select the following to configure
your own Prosignia Desktop:
Processor
Memory
Hard Drive
Removable Storage
Optical Storage
Software
Modem
Network Interface
Controller
MODELS
Configured to Order
Prosignia Notebook 170
Select the following to configure
your own Prosignia Notebook:
Processor
Memory
Hard Drive
Removable Storage
Optical Storage
Modem or Modem/NIC
Combination Card
Software

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Standard Features
3 DA-10472-01-002 — 11.29.1999
Compaq Prosignia
Notebook 170
Configured to Order
Multimedia
Compaq Premier•Sound™ for enhanced stereo audio
Integrated 16-bit Sound Blaster Pro-compatible stereo audio
Integrated stereo speakers and microphone
Ported Speaker Enclosure
Software/hardware volume control
Headphone out jack – supports stereo out
Microphone in jack
Software MPEG1 support
DVD movie playback software (optional)
Internal 4X DVD-ROM6drive or 24X Max2CD-ROM Drive
RCA TV-out port (NSTC/PAL)
2X AGP graphics with 8-MB SDRAM
Interfaces
PC Card Two Type II/One Type III
Enhanced Parallel 1
Serial 1
TV out connector 1
External Monitor 1
External Keyboard/
Pointing Device 1
Expansion Base 1
Speaker/Headphone out 1
Microphone in 1
AC Power 1
RJ-11 1
RJ-45 1 (Withoptional Intel PRO+ Mini-PCI card)
Infrared 1 (4 Mb/s8support)
USB 1
Graphics
2X AGP implementation with dedicated 66-MHz AGP graphics bus; ATI Mobility-P™ graphics controller with 8 MB of
125 MHz SDRAM; up to 100 Hz external refresh at SVGA resolution up to 16.8M colors; supports dual-view display,
with 2 different images on two different displays at different refresh rates; NTSC & PAL TV-out support (integrated) up
to 1024 x 768 resolution
Display
14.1-inch color TFT with 1024 x 768 resolution (up to 16M colors internal)
13.3-inch color TFT with 1024 x 768 resolution (up to 16M colors internal)
Operating System
Windows 98 Second Edition
Software
Microsoft Office 2000 Small Business, or
Microsoft Office 2000 Professional, or
Microsoft Word 2000
Norton AntiVirus
WinFAX Basic
Compaq Online Services
CompuServe and AOL
Diagnostics for Windows
Compaq Power Management
Online Safety and Comfort Guide
Reference Guide

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Standard Features
4 DA-10472-01-002 — 11.29.1999
Compaq Prosignia
Notebook 170
Configured to Order
Compaq Online Services
A full suite of Internet-powered solutions that provide reliable Internet access, online office management tools, and e-
commerce capabilities – all designed to lower technology and staffing costs, and increase productivity for growing
businesses
Access the Internet
Briefcase
Backup
Courier
Delivery
Postage
All-in-One eBusiness Center
Message Center Lite
Message Center
RingMeNow
Small Business Resource Center
Online Training
Security
Configuration Control Hardware
Memory Change Alert
Ownership Tag
Setup Password
Power-On Password
DriveLock
QuickLock
QuickBlank
Power Supply
External AC adapter, 10-foot power cord included
Battery
The Prosignia Notebook 170 offers an 8-cell standard Li-Ion battery, and an optional 6-cell MultiBay battery. Typical
battery life is over two hours for the 6-cell9and over three hours for the 8-cell9, depending on the exact configuration
and usage
Power Conservation
Hibernation
Instant-on via Standby
Pop-ups with three presets
One custom level of power conservation
Service and Support
Compaq Services provides a range of services, including a Three-year, Limited Worldwide Warranty4, with 7 x 24 toll-
free service line at 1-877-456-7878 and a free one-year, second business day5pick-up and delivery service from
Compaq. All shipping and handling materials are supplied by Compaq.

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Configurable Components
5 DA-10472-01-002 — 11.29.1999
Compaq Prosignia
Notebook 170
Configured to Order
Solutions Configured to Order
Configurable components are available directly from
Compaq or through a Compaq Agent and are for first
time configurations only.
Base Unit (Choose one of the following)
All base units include Li-Ion Battery, AC Adapter,
Diskette Drive and MultiBay Weight Saver
Intel Pentium III 500-MHz processor
Intel Pentium III 450-MHz processor
Intel Pentium II 366-MHz processor
TFT Display Screen (Choose one of the
following)
14.1″Panel
13.3″Panel
Primary Hard Drives (Choose one of the
following)
18-GB5SMART Hard Drive
12-GB5SMART Hard Drive
6-GB5Hard Drive
4-GB5Hard Drive
Memory (Optional Memory upgrade)
128-MB SDRAM
64-MB SDRAM
32-MB SDRAM
MultiBay Options (Choose one of the
following)
4X - DVD-ROM6Drive with software decoder
24X Max2CD ROM Drive
MultiBay Devices (Optional)
SuperDisk LS-120
Second SMART Hard Drive (with Adapter)
Second 6-Cell Li-Ion Battery
Communications Options
Compaq Mini PCI 56K7Modem
Compaq 56K (V.90)7plus Intel PRO/100+ Mini PCI
(Modem and Ethernet NIC)
Pointing Devices (Choose one of the
following)
Touch Pad
Pointing Stick
Business Software (Choose one of the
following)
Microsoft Office 2000 Professional
Microsoft Office 2000 Small Business
Microsoft Word 2000
Software (Optional)
Norton Utilities for Windows
Symantec Act
Symantec WinFax PRO
Symantec Mobil Essentials
Carbon Copy (complete version)
PcAnywhere 32
Intuit Quicken Deluxe 98
Microsoft Project 98 Upgrade
Corel WordPerfect Suite 8 Professional Upgrade
CorelDRAW 8 Upgrade
Netscape Communicator Internet Access Edition
Nestscape Communicator Deluxe Edition
Netscape Publishing Suite
Lotus 1-2-3 97 Upgrade
Lotus SmartSuite 97 Upgrade
Microsoft Front Page 98 Upgrade
Intuit Quick Books 5.0
Adobe Pagemaker 6.5
Adobe Photoshop 5.0
Adobe Illustrator 7.0

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Options
6 DA-10472-01-002 — 11.29.1999
Compaq Prosignia
Notebook 170
Configured to Order
Enhancements
Enhancements are available through Compaq
Authorized Resellers for first time configurations or
upgrades, or directly from Compaq or a Compaq Agent
for upgrades.
Memory
128-MB Memory Upgrade 144547-B21
64-MB Memory Upgrade 144546-B21
32-MB Memory Upgrade 144545-B21
Monitors
TFT8000 Flat Panel 307906-001
TFT5000 Flat Panel 325700-001
P1610 Color 305708-001
P110 Color10 284956-001
P75 Color 307806-001
V1000 Color10 351757-001
V900 Color10 303500-001
V75 Color (carbon) 307710-002
V500 Color 325900-001
S900 Color10 360562-001
S700 Color 360512-001
MultiBay Devices
18-GB6SMART Hard Drive 153927-B21
12-GB6SMART Hard Drive 153926-B21
6-GB6SMART Hard Drive 153925-B21
4X DVD-ROM6Drive 153952-B21
24X Max2 CD-ROM 146812-B21
SuperDisk LS-120 144557-B21
Li-Ion 6-cell Battery 144558-B21
Docking Solutions
Prosignia Port Replicator 144488-004
Prosignia Convenience Base with Intel
NIC 144487-004
Convenience Base Monitor Stand 122931-B25
PC Cards/Communications/Multimedia
Wireless LAN 2 Mb/s 134711-001
Compaq M420 56K7Global Modem 317900-001
10/100 TX PC Card UTP Controller 335506-B21
10 T PC Card UTP Controller 292806-B21
10 2 PC Card Coax Controller 292807-B21
10/100 TX PC Card UTP Controller
Upgrade 292813-B21
Margi DVD-to-Go PC Card 202861-B21
16/4 TR PC Card IBM UTP/STP
Controller 301208-B21
For additional compatible PC Cards, view the Compaq
PC Card Solutions List on Compaq’s corporate website
at: http://www.compaq.com/support/techpubs/pcmcia/
pccardlist.html. Please note this website is available in
English only.
Power
Primary Battery (8-cell) 153922-B21
External Battery Charger 135555-001
AC Adapter 120765-001
AC Line Cord (4 ft) 213379-007
Auto Adapter 401043-B25
Aircraft Adapter 386504-B21
Input Devices
External Enhanced III Keyboard (carbon) 118003-008
Compaq Mouse (carbon) 103180-B21
Compaq/Microsoft Intellimouse 294306-B21
Numeric Keypad (carbon) 294317-B21
Other
Compaq Security Lock 294316-B21
Portable Video Conferencing 296954-001
Headset with Microphone 220460-001
MP1600 Microportable Projector 386202-001
Universal Monitor Stand (opal) 316246-B21
Carrying Cases
Compaq Value Case 294266-B21
Compaq Workstation Case 294267-B21
Compaq Global Case 294268-B21
Compaq Executive Case 294269-B21
Compaq Professional N Case 401366-B21
Compaq Professional L Case 401367-B21

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Memory
7 DA-10472-01-002 — 11.29.1999
Compaq Prosignia
Notebook 170
Configured to Order
Compaq Prosignia 170 Pentium II
STANDARD MEMORY
32-MB SDRAM installed on the System Board
Standard Slot
12
32 MB Empty Empty
STANDARD MEMORY PLUS
OPTIONAL MEMORY
Support for up to 288 MB of SDRAM memory is available with the installation of optional SDRAM
Memory Kits in addition to the 32-MB SDRAM on the System Board.
Up To Slot
12
288 MB
224 MB
192 MB
160 MB
128 MB
96 MB
This chart does not represent all possible memory configurations. The following memory options
are available from Compaq:
•128-MB Memory Upgrade
•64-MB Memory Upgrade
•32-MB Memory Upgrade

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Memory
8 DA-10472-01-002 — 11.29.1999
Compaq Prosignia
Notebook 170
Configured to Order
Compaq Prosignia 170 Pentium III
STANDARD MEMORY
64-MB SDRAM installed on the System Board
Standard Slot
12
64 MB Empty Empty
STANDARD MEMORY PLUS
OPTIONAL MEMORY
Support for up to 320 MB of SDRAM memory is available with the installation of optional SDRAM
Memory Kits in addition to the 64-MB SDRAM on the System Board.
Up To Slot
12
320 MB
256 MB
192 MB
160 MB
128 MB
This chart does not represent all possible memory configurations. The following memory options
are available from Compaq:
•128-MB Memory Upgrade
•64-MB Memory Upgrade
•32-MB Memory Upgrade

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Storage
9 DA-10472-01-002 — 11.29.1999
Compaq Prosignia
Notebook 170
Configured to Order
COMPAQ PROSIGNIA NOTEBOOK 170 DRIVE SUPPORT
DRIVE SUPPORT Quantity
Supported Drive Bay Supported
Removable Media
1.44-MB Diskette Drive11 Up to 1 MultiBay
24X Max2 CD-ROM Drive
4X6DVD-ROM
SuperDiskLS-120
Second HDD12
18-GB5SMART Hard Drive
12-GB5SMART Hard Drive
6-GB5SMART Hard Drive
Hard Drives
18-GB5SMART Hard Drive
12-GB5SMART Hard Drive
6-GB5SMART Hard Drive
4-GB5SMART Hard Drive
1 Dedicated hard drive bay
1MultiBay
2 Dedicated hard drive bay

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
Technical Specifications
10 DA-10472-01-002 — 11.29.1999
Compaq Prosignia
Notebook 170
Configured to Order
System Unit Dimensions (HxWxD) 12.4 x 9.8 x 1.1 in/31.4 x 24.9 x 2.8 cm
Weight 5.3 lbs/2.09 kg (minimum weight, actual weight varies with
configuration)
Stand-Alone Power Requirements
Nominal Operating Voltage (Li-Ion) 14.4V (8-cell), 10.8V (6-cell)
Average Operating Power 15W
Peak Operating Power 30W
Power Supply
Rated Input Voltage 90 to 264 VAC (auto-switching)
Rated Input Current < 60W
Rated Frequency 47 to 63 Hz
Temperature
Operating 50°to 104°F/10°to 40°C
Non-operating –4°to 140°F /–20°to 60°C
Relative Humidity (non-condensing)
Operating 10% to 90% relative humidity, non-condensing
Non-operating 5% to 95% relative humidity, 101.6°F/38.7°C Maximum
wetbulb temperature
Shock
Operating 10 G, 11 ms, half-sine
Non-operating 240 G, 2 ms, half-sine
Vibration
Operating 0.5 G zero-to-peak, 10 to 500 Hz, 0.25 oct/min
Non-operating 1.5 G, zero-to-peak, 10 to 500 Hz, 0.5 oct/min
Maximum Altitude (unpressurized)
Operating 10,000 ft/3,048 m
Non-operating 30,000 ft/9,144 m
Dimensions (HxW) 11.22 x 8.46 in/28.5 x 21.5 cm14.1-Inch Color TFT XGA
Display Diagonal Size 14.1 in/35.81 cm
Mounting Internal Panel Supports, Side Mounted
Number of Colors Up to 16.8M
Contrast Ratio 150:1
Brightness 120nt typ
Pixel Resolution
Pitch 0.264 x 0.264 mm
Format 1024 x 768
Configuration RGB stripe
Backlight Edge Lit
Character Display 80 x 25
Total Power Consumption 4.2W
