User’s Guide
Compaq TFT5030
Flat Panel Monitor
June 2001
Enhanced for accessibility

© 2001 Compaq Computer Corporation.
Compaq and Compaq logo Registered in U. S. Patent and Trademark
Office.
Microsoft, MS-DOS, Windows, Windows NT are trademarks of Microsoft
Corporation in the United States and other countries.
All other product names mentioned herein may be trademarks of their
respective companies.
Compaq shall not be liable for technical or editorial errors or omissions
contained herein. The information in this document is provided “as is”
without warranty of any kind and is subject to change without notice. the
warranties for Compaq products are set forth in the express limited
warranty statements accompanying such products. Nothing herein should
be construed as constituting an additional warranty.
CAUTION: Text set off in this manner indicates that failure to
follow directions could result in damage to equipment or loss of
information.
WARNING: Text set off in this manner indicates that failure to
follow directions could result in bodily harm or loss of life.
User’s Guide
Compaq TFT5030 Flat Panel Monitor
First Edition (June 2001)
Part Number: 235607-001

Product Features
The Compaq TFT5030 Flat Panel Monitor has an active matrix,
thin-film transistor (TFT), liquid crystal display (LCD). The
monitor features include:
■ 15-inch (38.1-cm) viewable area display
■ 1024 × 768 resolution, plus full-screen support for lower
resolutions
■ Wide viewing angle to allow viewing from a sitting or
standing position, or when moving side-to-side
■ Tilt and swivel capabilities
■ Removable base for flexible mounting solutions
■ Includes both VGA and DVI-D signal connectors; the DVI-
digital connection requires a special digital-compatible
graphics adapter card
■ Plug and Play capability if supported by your system
■ On-Screen Display (OSD) adjustments in six different
languages: English, Dutch, French, German, Italian, and
Spanish for ease of set-up and screen optimization
■ Programmable Sleep Timer
■ CD-ROM includes an information file (INF), Image Color
Matching file (ICM), Colorific Software package, the
Compaq LCD Display Assistant setup and configuration
utility, the Compaq Display LiteSaver utility, and product
documentation
■ Security lock slot
■ AssetControl
■ Energy Saver feature for Energy Star* compliance
Compaq TFT5030 Flat Panel Monitor User’s Guide 1

Product Features
■ Compliance with the following regulated specifications:
❏ EPA ENERGY STAR
❏ European Union CE Directives
❏ Swedish MPR II 1990
❏ Swedish TCO '99
Universal Driver Manager
This monitor may require a graphics driver (and/or .INF file) that
is compatible with your computer’s graphics adapter. The CD-
ROM included with this monitor contains an .INF file (see the
section on Information Files). Compaq has also created a
Universal Driver Manager (UDM) release that supports all
graphics adapters found on Compaq Deskpro and Compaq
Workstation products. The UDM eases graphics driver
deployment across Compaq platforms ensuring cross-
compatibility and backward-compatibility. The resulting solution
enables customers to manage and control ongoing software
maintenance costs. The UDM is available on the Compaq Support
Software CD for Compaq Desktop, Portable, and Workstation
Products and the Compaq World Wide Web site
(www.compaq.com).
2Compaq TFT5030 Flat Panel Monitor User’s Guide

Product Features
Information Files
This monitor includes a CD-ROM with two information files to
be installed onto your computer—an .INF file and an .ICM file.
■ The .INF file defines monitor resources and provides
specifications used by most operating systems to install
support software for certain hardware devices. The .INF file
ensures monitor compatibility and optimization with your
computer’s graphics adapter.
■ The .ICM file provides color matching consistency from
monitor screen to printer and is activated from within the
graphics programs that have this feature.
To install these files on your computer, follow the instructions on
the CD-ROM or on the "Configuring Your Compaq LCD
Monitor" card located in the Program License Agreement packet
along with the CD-ROM. INF file updates are downloadable by
clicking on: www.compaq.com/products/monitors/index.html
Compaq TFT5030 Flat Panel Monitor User’s Guide 3

Product Features
Setting Up the Monitor
To set up the monitor, ensure that the power is turned off to the
monitor, computer system, and other attached devices, then
follow these steps:
1. Place the monitor in a convenient, well-ventilated location
near your computer.
2. Connect the signal and power cables to the monitor 1.
3. Connect the DC connector of the AC adapter to the DC power
cable that extends from the monitor base.
4. Connect the AC cable 3 to the AC receptacle on the AC
adapter.
5. Connect the monitor signal cable 2to the appropriate video
connector on the rear panel of the computer.
6. Connect the power cable 4to an electrical wall outlet.
4Compaq TFT5030 Flat Panel Monitor User’s Guide

Product Features
Connecting the Monitor Cables
CAUTION: When connecting the monitor, be sure to use the AC
adapter supplied with the monitor. Failure to use this AC adapter
may result in damage to the monitor.
WARNING: To reduce the risk of electric shock or damage to
your equipment:
■ Do not disable the power cord grounding plug. The grounding
plug is an important safety feature.
■ Plug the power cord into a grounded (earthed) electrical
outlet that is easily accessible at all times.
■ Disconnect power from the monitor by unplugging the power
cord from the electrical outlet.
■ Do not place anything on power cords or cables. Arrange
them so that no one may accidentally step on or trip over
them. Do not pull on a cord or cable. When unplugging from
the electrical outlet, grasp the cord by the plug.
Compaq TFT5030 Flat Panel Monitor User’s Guide 5

Product Features
Note: For security purposes, this monitor has been fitted with a
slot for use with a security cable lock that can be purchased
separately at most computer stores.
Note: After you turn on the monitor, install the Compaq LCD
Display Assistant utility included on the CD-ROM. Use the on-
screen instructions to adjust the picture quality of your monitor.
To install this utility onto your computer, follow the instructions
on the "Configuring Your Compaq LCD Monitor" card located in
the Program License Agreement packet.
Important: Always activate a screen saver program, the
program-mable sleep timer, the Compaq Display LiteSaver
utility, or turn off the monitor when it is not in use for a
prolonged period of time. All LCD monitors that display the same
static image on the screen for a prolonged period of time may
exhibit screen image retention. Please note that image retention is
not a permanent condition and will fade over a period of time.
Image retention is a condition that may occur on all LCD screens.
6Compaq TFT5030 Flat Panel Monitor User’s Guide

Product Features
Connecting the Video Signal Cable
To connect the VGA analog or DVI-D (Digital Visual Interface-
Digital) cable to the corresponding connector on the back of the
monitor, you must first remove the monitor base cover.
Note: For the digital input to function, the VGA cable must be
disconnected from the monitor. If both VGA and DVI-D cables
are attached, the monitor will default to the VGA input.
WARNING: Before beginning to disassemble the monitor, be sure
the monitor is turned off and the power and signal cables are both
disconnected.
Note: The DVI-D cable supplied with this monitor is for digital
to digital connection only. Your computer must have a DVI-
compatible graphics card installed for use with this cable. When
connecting the DVI-D signal cable to the DVI connector on the
monitor, you must connect the other end of the DVI-D cable to
the DVI connector on the computer.
1. Lay the front bezel down on a soft area to prevent it from
getting scratched, defaced, or broken.
2. Remove the cover plate from the monitor base by placing
your fingers in the opening on the bottom of the base and
pulling upward, then pulling out to remove the cover.
3. Remove the back panel from the monitor by pushing the
bottom tabs upward and pulling out to remove the panel.
Compaq TFT5030 Flat Panel Monitor User’s Guide 7

Product Features
4. Connect the video cable to the corresponding connector on
the back panel of the monitor 1by threading the cable
through the neck on the monitor base to the connector, then
connect the other end of the cable 2to the appropriate video
connector on the back panel of the computer.
Connecting the Video Cable to the Monitor and Computer
5. Replace the monitor back panel and monitor base cover.
6. Reconnect the power cable and power on the monitor and
computer.
8Compaq TFT5030 Flat Panel Monitor User’s Guide

Product Features
The DVI-D connector on this monitor uses digital video
information to provide higher speed for higher display resolution.
The results are more precise video displays without manually
adjusting screen display quality.
Signal Cables Included:
■ VGA (Analog) to VGA Connector (15 pin)
■ DVI-D Cable (Digital only) to DVI Digital Connector
Removing the Monitor Base
Before you can mount the monitor onto a swing arm or other
mounting fixture, you must remove the monitor from the base.
CAUTION: Before beginning to disassemble the monitor, be sure
the monitor is turned off and the power and signal cables are both
disconnected.
To remove the monitor from the base, complete the following
steps:
1. Lay the front bezel down on a soft area to prevent it from
getting scratched, defaced, or broken.
Compaq TFT5030 Flat Panel Monitor User’s Guide 9

Product Features
2. Remove the cover plate 1from the monitor base by placing
your fingers in the opening on the bottom of the base and
pulling upward, then pulling out to remove the cover.
3. Remove the back panel 1from the monitor by pushing the
bottom tabs upward and pulling out to remove the back panel.
4. Disconnect and remove the signal and power cables from the
back of the monitor.
5. Remove the four screws 3as shown in the following
illustration.
Removing the Monitor Base
CAUTION: Ensure that the bottom of the monitor base is positioned over
a table or desktop before removing the base from the monitor.
6.Remove the monitor base 2from the monitor.
10 Compaq TFT5030 Flat Panel Monitor User’s Guide

Product Features
When the base is removed, four threaded mounting holes are
exposed on the monitor panel to be used for mounting purposes.
These mounting holes are spaced 75 mm apart and are compliant
with the Video Electronics Standards Association (VESA)
standard for mounting flat panel displays.
To mount the monitor on a swing arm or other mounting fixture,
follow the instructions included with the mounting fixture to be
used.
Operating the Monitor
Front Panel Controls
Compaq TFT5030 Flat Panel Monitor User’s Guide 11

Product Features
Front Panel Controls
No. Icon Control Function
1
Menu button 1.Launches 1st and
2nd level on-screen
menus.
2. Exits menus and
on-screen display.
2
-Minus button 1. Selects and
adjusts the
functions.
2. Activates Auto
Adjusts when
the OSD menu
is inactive.
3
+Plus button Selects and adjust
s
the functions.
4
Power switch Turns the monitor
on and off.
5
Power LED
1. Green indicates
monitor is turned
on.
2 Amber indicates
Sleep mode.
3 Blinking amber
indicates Sleep
timer*.
*Sleep Timer enables you to set a time for the monitor to power
on and power off at the same time every day. It eliminates the
need to turn off the monitor at the end of the day and conserves
energy. To set this mode, refer to the Sleep Timer in the on-screen
display.
12 Compaq TFT5030 Flat Panel Monitor User’s Guide

Product Features
On-Screen Display Settings
The adjustments for screen settings are located in the on-screen
display (OSD) and can be viewed in one of six available
languages. The following menus show the functions at each level:
Main Menu
Menu Level 1 Menu Level 2 Menu Level 3
Brightness Adjustment scale
Contrast Adjustment scale
Auto Adjustment
Advanced Menu
Exit
Advanced Menu
Brightness Adjustment scale
Contrast Adjustment scale
Image Control Auto Adjustment
Horizontal Position
Vertical Position
Custom Scaling
Sharpness
Clock
Clock Phase
Cancel
Save and Return
Adjustment scale
Adjustment scale
Fill to Screen or Fill
to Aspect Ratio
Adjustment scale
Adjustment scale
Adjustment scale
Compaq TFT5030 Flat Panel Monitor User’s Guide 13

Product Features
Main Menu
Menu Level 1 Menu Level 2 Menu Level 3
Color 9300oK
6500oK
Custom Color
Cancel
Save and Return
Color adjustment
Language Deutsch
English
Espanol
Francais
Italiano
Nederlands
Cancel
Save and Return
Management Power Saver
Power On Recall
Mode Display
Serial No.
Sleep Timer
Default Video Input
Basic Menu
Cancel
Save and Return
On/Off Selection
On/Off Selection
On/Off Selection
Displays Serial No.
Set Time and On/Off Times
Set Default Input -
Analog or Digital
Video
14 Compaq TFT5030 Flat Panel Monitor User’s Guide

Product Features
Main Menu
Menu Level 1 Menu Level 2 Menu Level 3
OSD Control Horizontal Position
Vertical Position
OSD Timeout
OSD Transparency
Cancel
Save and Return
Adjustment Scale
Adjustment Scale
Adjustment Scale
Adjustment Scale
Factory Reset Yes/No
Exit
Compaq TFT5030 Flat Panel Monitor User’s Guide 15

Product Features
How to Adjust Settings
1. Launching the on-screen display Menus:
❏To display the Basic Menu on the monitor screen: Press
the Menu button on the monitor front panel.
❏To display the Advanced Menu: Press the Menu button on
the monitor front panel to display the Basic Menu, use the
Minus or Plus buttons to scroll to and highlight the
Advance Menu selection, then press the Menu button
again.
Monitor with On-screen Display
Note: After the Advanced Menu has been selected, it remains the
default on-screen display each time the monitor is powered on
until the Basic Menu is re-selected.
16 Compaq TFT5030 Flat Panel Monitor User’s Guide

Product Features
2. To select an item from the Main Menu, scroll down and
highlight an item by pressing the Minus (-) button 2 located
on the monitor front panel. To reverse or back up, press the
Plus (+) button 3.
3. Highlight your choice and press the Menu button 1again.
4. Adjust the second-level menu displays using the same
procedures as the first level.
Note: The second-level menus for Brightness and Contrast
displays an adjustment screen. Use the Minus button to decrease
and the Plus button to increase the screen brightness and contrast.
5. Access the third level menu by selecting a function and
pressing the Menu button. Adjust the third level menu
displays using the same procedures as the second level.
6. To exit from the on-screen menu, select Exit from the
Advanced Menu. If the display is a second or third-level
menu, select Save and Return or Cancel, then select Exit from
the Advanced Menu.
The on-screen display is easy to use, just follow the instructions
on the screen.
Special OSD Messages
Special OSD messages will appear on the monitor screen when
identifying the following monitor conditions:
■ Input Signal Out of Range—Indicates the monitor is unable to
access or fully support the provided input signal. For the best
performance, set the OS display settings to 1024 x 768
resolution at 60 Hz vertical sync.
■ Going to Sleep—Indicates the screen display is entering a
sleep mode.
Compaq TFT5030 Flat Panel Monitor User’s Guide 17

Product Features
■ Check Video Cable—Indicates the video cable may not be
plugged into the computer or the computer may not be turned
on.
Sleep Timer Mode
The Sleep Timer mode is an energy-saving feature that enables
you to set a time for the monitor to power on and off at the same
time every day. This also extends the life of the backlight bulbs in
the monitor. The Sleep Timer has five settings:
■ Set Current Time
■ Set Sleep Time
■ Set On Time
■ Timer: On/Off
■ Sleep Now
To set the timer:
1. Press the Menu button on the monitor front panel to display
the Advanced Menu.
2. Scroll down and highlight Management.
3. Press the Menu button to select Management.
4. Scroll down and highlight and select Sleep Timer - Set
Current Time.
Note: You must set the current local time before you reset the
time for Sleep Time or On Time.
5. Press the Menu button once to enter the adjustment mode for
hours.
6. Press the Minus or Plus buttons to adjust the hour.
7. Press the Menu button again to enter the time for minutes.
18 Compaq TFT5030 Flat Panel Monitor User’s Guide
