QUICKSPECS
1DA-10589-00A-006 — 04.05.2000
Compaq Corporate Value
V900 Color Monitor
SPECIFICATIONS
V900 Color Monitor
Note: AssetControl monitor. AssetControl features are accessible with Compaq desktops featuring Intelligent
Manageability.
Type Color multi-scan with Invar Shadow Mask
Picture Tube (diagonal) 19-in Flat Square Short Neck CRT
Viewable (diagonal) 18 in
Horizontal Dot Pitch 0.22 mm
Trio Dot Pitch 0.26 mm
Max Refresh/Preset Graphic Modes 1800 x 1440 1600 x 1200 1280 x 1024
Note: All modes are non-interlaced unless
specified otherwise. 76Hz/60 and 75
Hz 89 Hz/60, 75 and 85 Hz
1024 x 768 800 x 600 640 x 480 640 x 350
118 Hz/60, 75
and 85 Hz 152 Hz/60, 75 and 85 Hz 160 Hz/60, 75 and 85 Hz 160 Hz/70 and 85 Hz
Text Mode 720 x 400
70 and 85 Hz
Mac Compatible Modes 1152 x 870 832 x 624
Note: Adapter required. 75 Hz 74.5 Hz
User-Programmable/Preset Graphic
Modes 15
Anti-Glare/Anti-Static Yes/Yes
Plug and Play Yes
Agency Approvals/Certifications
UL Approval Yes
ISO9241-3 VOT Guidelines Approval Yes
MPR-II Compliant Yes
FCC Approval Yes
Energy Star Compliant Yes
TCO 95 Compliant Yes
On-Screen Controls Yes
Language Selection
English Yes
German Yes
French Yes
Spanish Yes
Italian Yes
Dutch Yes
Tilt Base (up/down) 15°up/5°down
Swivel ±90°of center
User Controls
Brightness, Contrast Yes
Size and Positioning Yes
Pincushion (barrel) Yes
Trapezoid Yes
Tilt (rotation) Yes
Color temperature Yes
Parallelogram Yes
Pincushion Balance Yes
Individual color control Yes
Moiré Cancellation Yes
Convergence Yes
Overscan Yes
Serial Number Display Yes
Power Saver (on/off) Yes
Display Mode Yes
Degauss Yes
Factory Reset Yes
MODELS
V900 Color Monitor
303500-001
Note: AssetControl monitor.
AssetControl features are
accessible with Compaq
desktops featuring Intelligent
Manageability.

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
2 DA-10589-00A-006 — 04.05.2000
Compaq Corporate Value
V900 Color Monitor
SPECIFICATIONS (continued)
V900 Color Monitor (continued)
Note: AssetControl monitor. AssetControl features are accessible with Compaq desktops featuring Intelligent
Manageability.
Intelligent Manageability
AssetControl Yes
Note: When used with Compaq Intelligent
Manageability CPUs and appropriate
network software.
USB Capabilities Yes
Pixel Clock Speed 202.5 MHz
Input Impedance 75 ohms ±2%
Horizontal Frequency 30 to 96 kHz
Vertical Frequency 48 to 160 Hz
Power Supply ALS Universal/Auto-Sensing
Maximum Power Rating 150 Watts
Power Consumption < 15W/< 8W
Synch Input TTL separate synch
Signal Cable 15-pin miniature D-sub
Dimensions (HxWxD) 18 x 17 x 18.1 in/ 45.8 x 43.2 x 46.1 cm
Weight 57.31 lbs/26 kg
Operating Temperature 50°to 95°F/10°to 35°C
Operating Humidity
(non-condensing) 20% to 80%
48 Hour Direct Replacement If this monitor fails during the parts warranty, Compaq
guarantees that a new, or like-new monitor replacement will be
delivered within 48 hours.
Note: Certain restrictions and exclusions apply.
Consult the Compaq Customer Service
Support Center for details.
Limited Warranty Three-year parts, first-year labor on-site
Note: Certain restrictions and exclusions apply.
Consult the Compaq Customer Service
Support Center for details.
COMPATIBILITY
Portables
Compaq Armada 7800
Compaq Armada 7400
Compaq Armada 6500
Compaq Armada 3500
Compaq Armada 1750
Compaq Armada 1700
Compaq Armada 1500c
Desktops
Compaq Deskpro EN Series Desktop
Compaq Deskpro EN Series Minitower
Compaq Deskpro EN Series Small Form Factor
Compaq Deskpro EP Series
Workstations
Compaq Professional Workstation XP1000
Compaq Professional Workstation AP500

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
3 DA-10589-00A-006 — 04.05.2000
Compaq Corporate Value
V900 Color Monitor
COMPATIBILITY (continued)
Servers
Compaq ProLiant 7000 Xeon™
Compaq ProLiant 6500 Xeon
Compaq ProLiant 6000 Xeon
Compaq ProLiant 5500 Xeon
Compaq ProLiant 3000 Pentium®III
Compaq ProLiant 3000 6/450
Compaq ProLiant 1600 6/500
Compaq ProLiant 1600 (100 MHz)
Compaq ProLiant 800 (500 MHz)
SMB
Compaq Prosignia Notebook Family of Personal Computers
Compaq Prosignia Desktop Family of Personal Computers
Compaq Prosignia 740
Compaq Prosignia 720
