SSL2000 Series Library
Drive Upgrade
Reference Guide
First Edition (April 2000)
Part Number 187194-001
Compaq Computer Corporation

Compaq Confidential – Need to Know Required
Writer: Bob Young Project: Compaq StorageWorks SSL2000 Series Library Drive Upgrade Reference Guide Comments:
Part Number: 187194-001 File Name: a-frnt.doc Last Saved On: 4/6/00 7:10 PM
Notice
© 2000 Compaq Computer Corporation.
Compaq, the Compaq logo, and StorageWorks Registered in U. S. Patent and Trademark Office.
All other product names mentioned herein may be trademarks or registered trademarks of their
respective companies.
Compaq shall not be liable for technical or editorial errors or omissions contained herein. The
information in this document is subject to change without notice.
The information in this publication is subject to change without notice and is provided “AS IS”
WITHOUT WARRANTY OF ANY KIND. THE ENTIRE RISK ARISING OUT OF THE USE OF
THIS INFORMATION REMAINS WITH RECIPIENT. IN NO EVENT SHALL COMPAQ BE
LIABLE FOR ANY DIRECT, CONSEQUENTIAL, INCIDENTAL, SPECIAL, PUNITIVE OR
OTHER DAMAGES WHATSOEVER (INCLUDING WITHOUT LIMITATION, DAMAGES FOR
LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION OR LOSS OF BUSINESS
INFORMATION), EVEN IF COMPAQ HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. THE FOREGOING SHALL APPLY REGARDLESS OF THE NEGLIGENCE OR
OTHER FAULT OF EITHER PARTY AND REGARDLESS OF WHETHER SUCH LIABILITY
SOUNDS IN CONTRACT, NEGLIGENCE, TORT, OR ANY OTHER THEORY OF LEGAL
LIABILITY, AND NOTWITHSTANDING ANY FAILURE OF ESSENTIAL PURPOSE OF ANY
LIMITED REMEDY.
The limited warranties for Compaq products are exclusively set forth in the documentation
accompanying such products. Nothing herein should be construed as constituting a further or additional
warranty.
Printed in the U.S.A.
Compaq StorageWorks SSL2000 Series Library Drive Upgrade Reference Guide
First Edition (April 2000)
Part Number 187194-001

Compaq Confidential – Need to Know Required
Writer: Bob Young Project: Compaq StorageWorks SSL2000 Series Library Drive Upgrade Reference Guide Comments:
Part Number: 187194-001 File Name: a-frnt.doc Last Saved On: 4/6/00 7:10 PM
Contents
About This Guide
Symbols in Text...........................................................................................................v
Symbols on Equipment...............................................................................................vi
Cabinet Stability ........................................................................................................vii
Getting Help ..............................................................................................................vii
Compaq Technical Support ................................................................................vii
Compaq Website .............................................................................................. viii
Compaq Authorized Reseller............................................................................ viii
Adding a Second Drive
Introduction .................................................................................................................1
Removing the Outside Cover.......................................................................................2
Outside Cover Screw Locations ...........................................................................2
Outside Cover Removal Procedures.....................................................................3
Removing the Brace Plate and Upper Drive Mounting Plate ......................................4
Installing Alignment Pins ............................................................................................6
Installing the New Drive..............................................................................................7
List of Figures
Figure 1. Outside cover screw locations (tabletop version)........................................2
Figure 2. Outside cover screw locations (rackmount version)....................................3
Figure 3. Brace plate removal.....................................................................................4
Figure 4. Upper drive mounting plate removal...........................................................5
Figure 5. Alignment pin installation ...........................................................................6
Figure 6. Installing the new drive ...............................................................................7
Figure 7. Connecting the new drive............................................................................8

Compaq Confidential – Need to Know Required
Writer: Bob Young Project: Compaq StorageWorks SSL2000 Series Library Drive Upgrade Reference Guide Comments:
Part Number: 187194-001 File Name: a-frnt.doc Last Saved On: 4/6/00 7:10 PM
About This Guide
This guide is designed to be used as step-by-step instructions for installing a
second drive into a Compaq StorageWorks SSL2000 Series Library.
Symbols in Text
These symbols may be found in the text of this guide. They have the following
meanings.
WARNING: Text set off in this manner indicates that failure to follow directions
in the warning could result in bodily harm or loss of life.
CAUTION: Text set off in this manner indicates that failure to follow directions
could result in damage to equipment or loss of information.
IMPORTANT: Text set off in this manner presents clarifying information or specific
instructions.
NOTE: Text set off in this manner presents commentary, sidelights, or interesting points
of information.

vi Compaq StorageWorks SSL2000 Series Library Drive Upgrade Reference Guide
Compaq Confidential – Need to Know Required
Writer: Bob Young Project: Compaq StorageWorks SSL2000 Series Library Drive Upgrade Reference Guide Comments:
Part Number: 187194-001 File Name: a-frnt.doc Last Saved On: 4/6/00 7:10 PM
Symbols on Equipment
These icons may be located on equipment in areas where hazardous conditions
may exist.
Any surface or area of the equipment marked with these symbols
indicates the presence of electrical shock hazards. Enclosed area
contains no operator serviceable parts.
WARNING: To reduce the risk of injury from electrical shock hazards,
do not open this enclosure.
Any RJ-45 receptacle marked with these symbols indicates a Network
Interface Connection.
WARNING: To reduce the risk of electrical shock, fire, or damage to
the equipment, do not plug telephone or telecommunications
connectors into this receptacle.
Any surface or area of the equipment marked with these symbols
indicates the presence of a hot surface or hot component. If this
surface is contacted, the potential for injury exists.
WARNING: To reduce the risk of injury from a hot component, allow
the surface to cool before touching.
Power Supplies or Systems marked with these symbols
indicate the equipment is supplied by multiple sources of
power.
WARNING: To reduce the risk of injury from electrical shock,
remove all power cords to completely disconnect power from
the system.
Any product or assembly marked with these symbols indicates that
the component exceeds the recommended weight for one individual
to handle safely.
WARNING: To reduce the risk of personal injury or damage to the
equipment, observe local occupational health and safety
requirements and guidelines for manual material handling.

About This Guide vii
Compaq Confidential – Need to Know Required
Writer: Bob Young Project: Compaq StorageWorks SSL2000 Series Library Drive Upgrade Reference Guide Comments:
Part Number: 187194-001 File Name: a-frnt.doc Last Saved On: 4/6/00 7:10 PM
Cabinet Stability
WARNING: To reduce the risk of personal injury or damage to the equipment,
be sure that:
■The leveling jacks are extended to the floor.
■The full weight of the cabinet rests on the leveling jacks.
■The stabilizing feet are attached to the cabinet if it is a single cabinet
installation.
■The cabinets are coupled together in multiple cabinet installations.
■Only one component is extended at a time. A cabinet may become
unstable if more than one component is extended for any reason.
Getting Help
If you have a problem and have exhausted the information in this guide, you
can get further information and other help in the following locations.
Compaq Technical Support
In North America, call the Compaq Technical Phone Support Center at
1-800-OK-COMPAQ. This service is available 24 hours a day, 7 days a week.
For continuous quality improvement, calls may be recorded or monitored.
Outside North America, call the nearest Compaq Technical Support Phone
Center. Telephone numbers for world wide Technical Support Centers are
listed on the Compaq website. Access the Compaq website at
http://www.compaq.com.
Be sure to have the following information available before you call Compaq:
■Technical support registration number (if applicable)
■Product serial number
■Product model name and number
■Applicable error messages
■Add-on boards or hardware
■Third-party hardware or software
■Operating system type and revision level

viii Compaq StorageWorks SSL2000 Series Library Drive Upgrade Reference Guide
Compaq Confidential – Need to Know Required
Writer: Bob Young Project: Compaq StorageWorks SSL2000 Series Library Drive Upgrade Reference Guide Comments:
Part Number: 187194-001 File Name: a-frnt.doc Last Saved On: 4/6/00 7:10 PM
Compaq Website
The Compaq website has information on this product as well as the latest
drivers and Flash ROM images. You can access the Compaq website at
http://www.compaq.com.
Compaq Authorized Reseller
For the name of your nearest Compaq authorized reseller:
■In the United States, call 1-800-345-1518.
■In Canada, call 1-800-263-5868.
■Elsewhere, see the Compaq website for locations and telephone
numbers.

Compaq Confidential – Need to Know Required
Writer: Bob Young Project: Compaq StorageWorks SSL2000 Series Library Drive Upgrade Reference Guide Comments:
Part Number: 187194-001 File Name: b-ch1 Adding a Second Drive.doc Last Saved On: 4/6/00 7:12 PM
Adding a Second Drive
Introduction
This guide explains how to add a second tape drive to the Compaq
StorageWorks SSL2000 Series Library (AIT Library).
IMPORTANT: All screws that do not use lock washers, captive washers, or lock nuts
must have Loctite 222 applied when parts are reassembled in the field. If you ignore this
step, you might cause premature failure of the mechanism.
This chapter includes procedures for:
■Removing the outside cover
■Removing the brace plate and upper drive mounting plate
■Installing alignment pins
■Installing the new drive

2Compaq StorageWorks SSL2000 Series Library Drive Upgrade Reference Guide
Compaq Confidential – Need to Know Required
Writer: Bob Young Project: Compaq StorageWorks SSL2000 Series Library Drive Upgrade Reference Guide Comments:
Part Number: 187194-001 File Name: b-ch1 Adding a Second Drive.doc Last Saved On: 4/6/00 7:12 PM
Removing the Outside Cover
This section describes how to remove the outside cover from both the tabletop
and rackmount versions of the Compaq StorageWorks SSL2000 Series
Library.
Outside Cover Screw Locations
The outside cover for the tabletop version is held in place by four screws at the
sides of the unit (see Figure 1).
cc00018
Figure 1. Outside cover screw locations (tabletop version)

Adding a Second Drive 3
Compaq Confidential – Need to Know Required
Writer: Bob Young Project: Compaq StorageWorks SSL2000 Series Library Drive Upgrade Reference Guide Comments:
Part Number: 187194-001 File Name: b-ch1 Adding a Second Drive.doc Last Saved On: 4/6/00 7:12 PM
The outside cover for the rackmount version is held in place by two screws at
the top-rear of the unit (see Figure 2).
cc0019
Figure 2. Outside cover screw locations (rackmount version)
Outside Cover Removal Procedures
1. Turn off power to the AIT Library and then unplug it from the AC
power source.
2. Remove the appropriate screws that secure the outside cover to the unit.
3. Slide the outside cover toward the rear of the unit until it clears the lip
behind the front panel.
4. Lift the outside cover up and away from the unit.
5. Save the hardware for re-use.

4Compaq StorageWorks SSL2000 Series Library Drive Upgrade Reference Guide
Compaq Confidential – Need to Know Required
Writer: Bob Young Project: Compaq StorageWorks SSL2000 Series Library Drive Upgrade Reference Guide Comments:
Part Number: 187194-001 File Name: b-ch1 Adding a Second Drive.doc Last Saved On: 4/6/00 7:12 PM
Removing the Brace Plate and Upper
Drive Mounting Plate
The brace plate and upper drive mounting plate must be removed to gain
access to the drive area. To remove both plates:
1. Remove the outside cover.
2. Remove the four screws that secure the brace plate to the chassis ( 1
Figure 3).
cc0020
1
Figure 3. Brace plate removal

Adding a Second Drive 5
Compaq Confidential – Need to Know Required
Writer: Bob Young Project: Compaq StorageWorks SSL2000 Series Library Drive Upgrade Reference Guide Comments:
Part Number: 187194-001 File Name: b-ch1 Adding a Second Drive.doc Last Saved On: 4/6/00 7:12 PM
3. Remove the screws that secure the upper drive mounting plate to the
chassis (see Figure 4).
4. Lift out the upper drive mounting plate.
cc0021
Figure 4. Upper drive mounting plate removal

6Compaq StorageWorks SSL2000 Series Library Drive Upgrade Reference Guide
Compaq Confidential – Need to Know Required
Writer: Bob Young Project: Compaq StorageWorks SSL2000 Series Library Drive Upgrade Reference Guide Comments:
Part Number: 187194-001 File Name: b-ch1 Adding a Second Drive.doc Last Saved On: 4/6/00 7:12 PM
Installing Alignment Pins
Four alignment pins need be installed into the new drive prior to installation.
Each alignment pin consists of a plastic spacer (top hat) and a screw
( 1Figure 5).
To install the alignment pins:
1. Place a plastic spacer onto each of the four screws.
2. Install the alignment pins at the locations shown ( 1Figure 5).
cc0022
1
1
Figure 5. Alignment pin installation

Adding a Second Drive 7
Compaq Confidential – Need to Know Required
Writer: Bob Young Project: Compaq StorageWorks SSL2000 Series Library Drive Upgrade Reference Guide Comments:
Part Number: 187194-001 File Name: b-ch1 Adding a Second Drive.doc Last Saved On: 4/6/00 7:12 PM
Installing the New Drive
To install the new drive:
1. Align the new drive with the holes at the bottom of the chassis.
2. Lower the new drive into the chassis (see Figure 6).
cc0023
Figure 6. Installing the new drive

8Compaq StorageWorks SSL2000 Series Library Drive Upgrade Reference Guide
Compaq Confidential – Need to Know Required
Writer: Bob Young Project: Compaq StorageWorks SSL2000 Series Library Drive Upgrade Reference Guide Comments:
Part Number: 187194-001 File Name: b-ch1 Adding a Second Drive.doc Last Saved On: 4/6/00 7:12 PM
3. Connect the power cable 1, serial cable 2, and SCSI cable 3to the
new drive (see Figure 7).
cc0024
1
2
3
Figure 7. Connecting the new drive
4. Secure the upper drive mounting plate to the new drive and chassis
using the previously removed retaining screws.
5. Secure the brace place to the chassis using the previously removed
retaining screws.
6. Place the outside cover onto the chassis and then slide it forward until it
is flush with the front panel.
7. Secure the outside cover to the chassis using the previously removed
screws.
8. Connect the AIT Library to an AC power source.
9. Turn the AIT Library on and test the operation of the new drive.
