QUICKSPECS
7-67 1Q1999 North America – Networking Products
Compaq 5708TX
Dual-Speed Ethernet and
5708FX Fast Ethernet Switches
Value Leader
The Compaq 5708 switches combine high-performance switching and aggressive pricing. High-end Ethernet and
Fast Ethernet switching are finally affordable for companies with medium to large networks.
Performance By Design
The Compaq 5708 switches’ non-blocking, cross-bar matrix architecture provides high-end performance for
departmental and workgroup environments at a fraction of the cost of similar devices. Typically, this type of
architecture is found only in high-end switches, designed to handle huge corporate networks. This architecture is
ideal for the 5708 switches because performance is becoming just as critical at departmental and workgroup levels.
The Compaq 5708 switches’ internal design provides an impressive 1.6 GB/s of aggregate throughput. In addition,
the 5708 switches’ ports automatically negotiate to full or half duplex and store-and-forward, fragment-free, adaptive
and cut-through frame forwarding modes, depending on network performance. This helps ensure peak performance
and reliability at all times.
Migration and Flexibility
The Compaq 5708 switches are available in an 8-port 10/100Base-TX version (5708TX) and an 8-port 100Base-FX
version (5708FX with SC-type connector) providing flexibility in network design and switch placement. The Compaq
5708TX switch automatically adapts to either 10 or 100MB/s on each port. With this type of flexibility, migration from
10 MB/s to 100 MB/s can be implemented segment by segment, rather than the entire network at once. The 5708FX
switch is ideal for installations that require long cable runs (up to 2Km) or electrically noisy environments.
Manageability
Both Compaq 5708 switches provide SNMP, VT-100, Telnet and VLAN as standard management features. Firmware
is upgraded easily via TFTP, and IP addresses can be established through standard BootP services. Compaq
Management Software (CMS) is included, so the user can immediately configure the switch, get detailed port-level
information and graph performance statistics without having to purchase expensive management software. The
Compaq 5708 switches can also be managed with any SNMP MIB II compliant management application.
World Class Compaq Reliability
Designed with quality and investment protection in mind, the Compaq 5708 switches meet all of Compaq’s
demanding design and manufacturing standards. Surface-mounttechnology, ASIC-based hardware, state-of-the-art
manufacturing facilities, a top-notch quality inspection and testing provide the reliability and quality that are expected
from a Compaq product.
Warranty
Compaq supports this product with a three-year limited warranty1, one of the longest in the industry. Technical
support is available at your fingertips 7 x 24.
Top to Bottom Solutions
Compaq can provide the end-to-end solution, from the lightweight laptop computer to the multi-terabyte, fault-tolerant
server and all the high-speed networking and communications in between. Compaq solutions are geared to provide
flexibility and performance at reasonable prices. A single point of support ensures quick and efficient resolution.
MODELS
Compaq 5708TX 8-port Dual-
Speed Ethernet Switch
167050-001
(US Model)
167052-B31
(International Model)
Compaq 5708FX 8-port Fast
Ethernet Switch
167000-001
(US Model)
167002-B31
(International Model)
The Compaq 5708 switches
provide high-end performance
for departmental and workgroup
environments at a lower cost
than similar devices.
The 5708TX Dual-Speed
Ethernet Switch is an excellent
tool for the evolution of your
network from 10Base-T to
100Base-TX.
The 5708FX Fast Ethernet
Switch provides a high-density
fiber solution for users who need
to run fiber over long distances
or who need fiber for electrically
noisy environments.
.

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
7-68 1Q1999 North America – Networking Products
Compaq 5708TX
Dual-Speed Ethernet and
5708FX Fast Ethernet Switches
SPECIFICATIONS
Features
10/100Base-TX Ports 8 (5708TX only)
100Base-FX Ports 8 (5708FX only)
MAC Address Table 4096 Entries
Forwarding Modes Store and Forward
Cut-through
Adaptive
Fragment-Free
Buffer Memory 256 KB per port
Flow Control Yes, enabled per port
Duplex Support Auto-negotiate full/half duplex on a per-port basis and user selectable.
Management SNMP, Telnet, VT-100, and VLAN
802.1d Spanning Tree Yes
ASIC Architecture Non-blocking, high-speed, cross-bar matrix
LEDs Link
Activity
Collision
Port transmission speed
Port duplex mode
Bandwidth utilization %
Filtering rate %
Forwarding rate %
Supported RFCs
RFC 1213 MIB II
RFC 1215 Traps
RFC 1493 Bridge MIB (Partial)
RFC 1643 Ethernet
RFC 854-859 TELNET
RFC 1350 TFTP
RFC 1542 BootP, XMODEM
RFC 826, 925 ARP
RFC 792, 1256 ICMP
RFC 791 IP
Emission FCC part 15, Class B
EN55022/CISPR22 Class B
VCCI Class 2
Immunity IEC 801-2 (Electrostatic Discharge)
IEC 801-3 (Radiated)
IEC 801-4 (Electrical Fast Transient/Burst)
EN55022 (CISPR22) (Radio Frequency Interference)
EN50082-1 (Electromagnetic)
EN55101-4 (Conducted)
EN60950 (IEC950) (Product Safety)
Safety UL 1950, Second Edition (UL’s Standard for Information Technology
Equipment)
CAN/CSA C22.2 No. 950-M93
TÜV Product Services
EN 60950/1988+A1/1990 + A2/1992
CE 89/336/EEC (EMC Directive)
Supported Cabling 5708TX–CAT5 UTP
5708FX–Multi-Mode 50/125 or
62.5/125–Micron fiber optic cabling
distance for half-duplex maximum 412 meters, full-duplex 2Km

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
7-69 1Q1999 North America – Networking Products
Compaq 5708TX
Dual-Speed Ethernet and
5708FX Fast Ethernet Switches
SPECIFICATIONS (continued)
Operating Environment
Temperature
Humidity
Altitude
32°to 122°F/0°to 50°C
5% to 95% (non-condensing)
0 to 10,000 ft/0 to 3 km
Storage Environment
Temperature
Humidity
Altitude
32°to 151°F/0°to 66°C
5% to 95% (non-condensing)
0 to 30,000 ft/0 to 9 km
Power Consumption
Power Supply
Wattage 120 - 240 VAC/50 - 60 Hz 57W; BTU/hr = 195
Weight
Unit
Shipping 5 lbs/2.27 kg 9 lbs/4.08 kg
Dimensions (HxWxD)
Unit
Shipping 1.75 x 17 x 8.4 in/4.5 x 43.6 x 21.5 cm
4.75 x 20.5 x 12 in/12.2 x 52.6 x 30.8 cm
RELATED PRODUCTS
5226A 24-Port Ethernet Switch
(International) 322900-001
322902-B31
1Certain restrictions and exclusions apply. Contact the Compaq Customer Support Center at 1-800-345-1518.
