Compass Model Atom 500 User manual

Fly at your own risk !
Assembly Manual
Version 2.0
Created : 10/26/2009
Features :
- Best 3D Performance
- Precision ECCPM 120° Metal Swashplate
- Easy Maintenance
- 80% Preassembled
- Low Parts Count
- Wear Resistant Parts
Equipped with extra Strong Frames, Aluminum Rotor Head, Aluminum Tail Rotor and a
Metal Swashplate the Atom 500 not only looks great but is long lasting.
Copyright Compass Model 2008
As we continue to improve our products; this manual may not reflect all recent product amendments.
For more information, please refer to www.compassmodel.com

Academy of Model Aeronautics
5151 East Memorial Drive
Muncie, IN47302
Introduction
Warning
Warranty
AMA Information
The warranty covers defects in material or workmanship or missing components to the original purchaser for 30 days from
the date of purchase. Compass Model Ltd will replace or repair, at our discretion, the defective or missing component.
Defective components must be returned to our Distributor prior to replacement.
Any part, which has been improperly installed, abused, crash damaged or altered by unauthorized agencies is not covered.
Under no circumstances will the buyer be entitled to consequential or incidental damages. The components used in this kit
are made from special materials designed for special applications and design strengths. We recommend that all replacement
parts be original parts manufactured by Compass Model Ltd to ensure proper and safe operation of your model. Any part
used which was manufactured by any firm other than Compass Model Ltd VOIDS all warranties of this product by Compass
Model Ltd.
We strongly encourage all prospective and current R/C aircraft pilots to join theAcademy of ModelAeronautics. TheAMAis
a non-profit organization that provides services to model aircraft pilots. As an AMA member, you will receive a monthly
magazine entitled Model Aviation, as well as liability insurance plan to cover against possible accident or injury. All AMA
charter aircraft clubs require individuals to hold a current AMA sporting license prior to operation of their models. For
further information, you can contact theAMAat:
Congratulations on your purchase of the Compass Model Atom 500 Electric Powered Helicopter.This model has been
designed using the latest in state-of-the-art design technology. To achieve the best performance and reliability from this
model, please read through these instructions carefully so you become familiar with the contents of this kit before assembly.
Warranty Procedures
Mail all warranty information within 15 days of original purchase date. If service is required, send the component in
question (if not missing) together with a photocopy of your bill of sale and an accurate description of the problem and part.
Ship components fully insured and prepaid. Compass Model Ltd is not responsible for any shipping damages. We will, at our
discretion, notify you of any costs involved, or ship it COD. You are required to pay all postage, shipping and insurance
charges.
R/C Helicopter Safety
A model helicopter must be built exactly in accordance with the assembly instructions. Compass Model Ltd has spent much
time and efforts refining this product to make it reliable in operation and easy to build. Vibration and stress levels are high and
all fasteners and attachments must be secure for safe operation. Safe operation is the responsibility of the builder/flyer and
starts with careful construction and continues with selection and installation of reliable radio equipment and motor/engine.
The need for safety is nowhere greater than at the flying field. A number of guidelines for safe flight have been developed by
experienced flyers and are set down here. It is urged that they be read, understood and followed.
each country has his own security application which cannot be laid down here so prior to any flight request the
rules to apply in your country/Flying field.
Attention:
The radio-controlled model helicopter contained in this kit is not a toy, but a sophisticated piece of equipment. This product
is not recommended for use by children. Radio-controlled models such as this are capable of causing both property damage
and/or bodily harm to both the operator/assembler and/or spectator if not properly assembled and operated. Compass
Model Ltd. assumes no liability for damage that could occur from the assembly and/or use/misuse of this product.Although
theAtom 500 is powered by a quiet, smooth-running electric motor, it should be assembled and operated with the same care
as its larger glow engine counterparts.When operating yourAtom 500, please exercise caution and safety.

• Fly only at approved flying fields and obey field regulations.
• Follow frequency control procedures. Interference can be dangerous to all.
• Obtain assistance from experienced pilots.
• The Guidance provided by experienced pilots is valuable and sometimes necessary.
• Know your radio. Check all transmitter functions before each flight.
• Be aware that rotating blades are very dangerous and can cause serious injury.
• Never fly near or above spectators or other modelers.
• Do not fly r/c helicopter models near buildings, high voltage cables, trees or other obstacles.
• If a beginner, get help trimming the model first and flight training later.
• Don’t “track” the main blades by holding the tail boom. This is a temptation to builders who cannot hover yet and is very dangerous.
• Follow all recommended maintenance procedures for model, radio and motor.
• Only turn off the radio after the engine is shut down.
Length: up to 430mm
Necessary Items
Bearing Retainer
6 channel or up radio and receiver.
3 mini servos.
1 gyro with rudder servo.
6S LiPo battery 2100mah~3300mah.
or 2 pack 3s LiPo battery with same capacity.
Mini Servos
Grease
Needle Nose Pliers Screw Driver
Hex Wrench Set
(1.5mm,2mm,2.5mm,3mm) Cutter Knife
Main Rotor
Pitch Gauge Ball Link Sizing Tool Ball Plier
When first opening your Atom kit, you will notice that all of the parts are packaged and numbered to coordinate with the
assembly step numbers of this instruction manual. All small hardware (nuts, bolts, washers, etc.) for each step are packaged
separately within the main parts bags. When beginning a section, you will need to open only the bag with the corresponding
number to the section you are about to start. It is suggested that you place all of the hardware in an open container (e.g., servo
case) during assembly so as not to lose any of the small parts. It may also be helpful to familiarize yourself with the various
sizes of screws, bolts, nuts, etc., as illustrated in the appropriate assembly section before you begin assembly. In most cases, at
the end of each assembly section, there should be no parts remaining. Great care has been taken in filling the bags with the
correct quantity of parts and hardware for each section. However, occasional mistakes happen. In the event that you find a
parts shortage or are in need of technical assistance, please contact your local Compass Model parts dealer.
Preassembly Information
In order to operate this model, you need to purchase the following items not kit-included.
Swash Plate Tool
Guidelines for Safe R/C Helicopter Flight
Threadlock

In The Box
This model is packed according to assembling steps. Do not open all the bags at one time.
Open only one bag for each step of assemply when building.
Atom 500
Use AB Glue
A
B
Use Blue Threadlock
Use Grease
Failure to follow these instructions may result in damage, personal injury or danger.
Symbols & assembling
* Always apply blue Threadlock when fixing Bolts on Metal parts.
* Always apply green retainer where bearings have to be fit into metal parts.
* Do not over-tighten self tapping screws into plastic parts or you will strip the threads!
G
Use Bearing Retainer
Atom 500R Differences
Step 1 Step 2 Step 3 Long Items Tail Assembly
Step 4 Step 5 Rotor Head Assembly Step 7 Step 10
Carbon Frame Set 60A ESC Compass Carbon Blades
G10 Frame Set 40A ESC Compass FG Blades Step 3
Step 5 (With Flybar Weight)

010 20 30 40
1Servo
Servo Nut
M2.5x16 Self
Tapping Bolt
2.5mm Washer
Standard Size
Rudder Servo
M2.5x16 Self Tapping
Bolt X 4
2.5mm Washer X 16
M2.5x8 Self-Tapping Bolt
Mini Servo
2.5mm Washer
Hole for
Mini Rudder Servo
Plastic Spacer M2.5x10 Self Tapping Bolt
M2.5x8 Self Tapping
Bolt X 8
M2.5x10 Self Tapping
Bolt X 4
Plastic Spacer x 4
Servo Nut x 2
010 20 30 40
Use AB Glue
M3x10 Self Tapping Bolt
M3x5 Set Screw
2Landing Gear
Landing Gear Struts
Skid Cap
Landing Gear Skid
A
B
M3 x10 Self Tapping
Bolt X 4
M3x5 Set Screw X 4
A
B
A
B
The 4 Plastic Spacers are used to
bring the Elevator Servo Arm in
Line with the Swashplate Link Ball.
Tip: Do not over tighten the four 3 x 5mm
set screws as it can damage the landing
struts.
The Servo installation is done without
the supplied Servo Rubbers.
The Swashplate Servos are installed
in between the 2 frames. The Self
Tapping Bolts are screwed from the
inside, while the Self Tapping Bolts
for the Rudder Servo are screwed
from the out side. The supplied Servo
Nuts are only used for the Rudder
Servo.

010 20 30 40
3Boom & Tail Rotor
M3x40 Cap Head Bolt x4
Crimping Belt damages the Tensile Cords
and will result in premature failure.
M3 Washer x2
M3 Nylon Lock Nut x6
M2.5x6 Cap Head Bolt x2
Use Threadlock
M3x40 Cap
Head Bolt
M3 Nylon Nut
Slide the Tail Boom through the
Tail Boom Mount. Twist the Tail
Belt 90° to the right before
inserting it to the Idler Pulleys.
M2.5x8 Self Tapping Bolt
M2.5 x8 Self Tapping
Bolt X 2
Bearing Retainer
M3x25 Cap
Head Bolt
M3 Nylon
Nut
Vertical Fin Mount
M3 Washer
M2.5x6 Cap
Head Bolt
Insert the Tail Boom
fully into the Tail Gear
Case before tightening
the 2.5x6mm Bolts.
Be careful not to over tighten the
Bolts when attaching the Tail Rotor
Blades. TheTail Blades should be
able to move with a slight amount
of resistance within the Tail Blade
Holders.
Tail Set
These Bolts are only used to
compress the boom, please do
not screw them the whole way in.
See Page Team Tips!

010 20 30 40
Main Gear
4
To adjust the correct backlash between
the Motor Pinion and the Main Gear
loose the 4 Motor Mount Bolts, then fix
them tightly with Threadlock.
M2.5x18 Shanked
Bolt
Main Shaft
M2.5x10 Cap
Head Bolt
Mast Collar
2.5mm Nylon
Lock Nut
M2.5 Nylon Lock Nut x1
M2.5x10 Cap Head Bolt x1
M2.5x18 Shanked Bolt x1
Use Threadlock
Gear BacklashAdjustment:
For smooth operation and
performance, it is necessary to adjust
the Gear Backlash properly. Excess
Gear Backlash can cause premature
Gear Wear and damage. Insufficient
Gear Backlash can cause vibration,
as well as overheating of the Motor
and Speed Controller.Adjust the Gear
Backlash by placing one piece of
paper between the Gears to set the
distance. When the Bolts are secure,
remove the paper and test the Gear
Backlash to insure that there is a
slight amount of free movement
between the gears.
Check the correct rotation of the
Tail Rotor Blades. The Blade on
the Top moves to the rear. If the
Tail Rotor rotates incorrectly,
simply pull out the main shaft and
twist the Belt in the other
direction.
Lift the Main Shaft Collar upwards and
secure to the Main Shaft by slightly
tighten the Lock Screw. It is necessary
to align the Lock Screw through the
hole in the side of the Main Frame.
While securing the Lock Screw, make
sure that you are pushing down on the
Main Shaft so that there will be no
up/down play in the Main Shaft once
the collar is secured.
See Page Team Tips!

Adjust so that each side has exactly the same length
M2.5x16 Shanked
Bolt x1
Use Threadlock
M2.5 x8 Self Tapping
Bolt X 4
M3x3 Set Screw x8
2.5mm Nut x1
Paddle
Main Shaft
M3x3 Set Screw
M2.5x16
Shanked Bolt 2.5mm Nut
M2.5 x8 Self Tapping Bolt
Paddle Insert
Washout Link
Thread
Flybar Thread
Thread
Paddle Insert
010 20 30 40
5Rotor,Washout & Swashplate
PushtheFlybarin
Be sure to note the correct
direction of the Flybar Paddles
as shown in the diagram. It is
very important to insure that the
Paddles are in parallel to each
other, as well as to the Flybar
ControlArmAssembly.
In this step, push the Flybar trough the
Flybar Collar, Flybar Holder and the
Flybar ControlArms using the 3x3mm
set screws to fix theArms and Collars
onto the Flybar, care that both sides of
the Flybar are of equal length.
M3x3 Set Screw
M3x3
Set Screw
See Page Team Tips!
See Page Team Tips!

010 20 30 40
6Equipment illustration
Esc
Velcro Tape
Pitch
Receiver
6S Battery
Aileron
Elevator
Rudder
ESC
00 10 20 30 40 00
7Linkage
19mmx2
26mmx2
29mm
4.5mm
4.5mm
BEC power line
Ch6
To Motor
Please cut away 4.5mm
from each Ball Link.
Please cut away 4.5mm
from each Ball Link.
The following Linkage lengths indications are basic values. PLEASE BEAWARE THAT THEYCOULD VARY
depend on used Servos andArms. Some fine adjustments are still needed in following setup steps.

Servo Arm
Servo Screw
For Sport Flying
For 3D Flying
39.5mmx2 40.5mm
45.5mm
2x6mm Cap Head
Bolt
Stainless Balls
Do not apply plier to resize Ball Links. Pliers could
cause hidden damage to Ball Links and result in
failure when operation.
00 10 20 30 40 00
8Setup
Pitch
General Flight
Throttle Pitch
5100% 13 deg
485%
370% 4~5 deg
235%
10% -4 deg
3D Style
Throttle Pitch
5100% 13 deg
4100% 6.5 deg
3100% 0 deg
2100% -6.5 deg
1100% -13 deg
0%
20%
40%
60%
80%
100%
12345
0%
20%
40%
60%
80%
100%
12345
Throttle Curve
Throttle Curve
JR Futaba
Swash Type SWH
S3 120 SR3
Aile Elev Pitch
45% 50% 45%
Swash Type Setting
Timing: 22.5 deg
No Brakes
Very Soft Start
Esc Setup
Compass Model Ball Links are build up on
the tight side this allows you to adjust them
to your personal needs. For this we suggest
to use a Ball Link sizing tool.
The Atom 500 total pitch range is
about 26°. If you set the pitch too high
than flight time will be shortened.

Parallel
Make sure that the Flybar ControlArms and Paddles are in line as shown in the diagram.
Horizontal
Horizontal
Attention:
WashoutArm
Horizontal 06 0501SwashplateTool-
Swashplate
Horizontal
0 Pitch°
MixingArm
5°
A
Turn on the Transmitter, set the Throttle Stick into center position for 0 ° Pitch. Use the Subtrim menu to
adjust the 3 Swash ServoArms to level.
B
To do all Basic Setups first UNPLUG
ESC from the receiver then use a 4.8V
Receiver Battery for the setup.
Level the Swashplate by adjusting the links from the ServoArms to the Swashplate. Use a
Compass Swashplate Tool as guide. Then set level the WashoutArms.
C
By adjusting the Links between Swashplate and MixingArms set the MixingArms to a 5° downward position.
Adjust the Links between the MixingArms and the Main Blade Holder to set the Main Blade Pitch to 0°.
D

With Rudder Stick in middle position, set the Rudder Servo Arm at 90° to the Tail Control Link. Set the Tail
Blades to 7° Pitch.
90°
7°
Use this Hole for Tail Link Ball
Aileron Check
Mod 1 Mod 2 Swashplate Reaction
Tilt Left
Elevator Check
Tilt Forward
Tilt Right
Tilt Backward
Rudder Check
Tail Pitch Plate
Slide left Slide Right
Pitch Check
Swash Plate
Ascent
Descent
00 10 20 30 40 00
9Servo Direction Check
Turn the Transmitter on, your position has to be right behind the helicopters Tail. Make sure that the Swashplate
Mode is set to CCPM 120°. Move the Sticks according to the drawings and check the reaction of the Swashplate
and the Tail Pitch Plate. Check as well your Throttle settings. Adjust your Transmitter settings accordingly.
13mm
E

M2.5x6 Self
Tapping Bolt
Canopy
Canopy Insert
Use AB Glue
A
B
M2.5x6 Self Tapping
Bolt X 2
Drill a 6.5mm D
Hole here
A
B
A
B
A
B
00 10 20 30 40 00
10 Canopy
00 10 20 30 40 00
11 Rotor Direction
5. Check that main blades, paddles and tail blades are installed in the right direction.
6. Check that there are no missing or damaged parts, never fly with any damaged parts.
7. Make sure all electronic devices are firmly fastened and connected.
8. Before starting the motor, make sure the IDLE switch is OFF and throttle stick is in the low position.
9. Only turn off the transmitter after turning off the receiver.
1. Ensure that receiver & transmitter battery are fully charged.
2 Check all bolts and screws are tight..
3 Repeat step 9 to check all servo functions are correct..
4 Ensure tail and gyro direction are correctly set..
00 10 20 30 40 00
12 Pre Flight Check
Place the Canopy onto the Frames and mark
the right position of the Canopy Inserts. Apply
AB Glue to fix the Canopy Insert onto the
canopy.
When the Rotor spins clockwise the Tail Blades should turn
clockwise as well watching the Tail Rotor from the Tail Fin side.
If not Belt is installed the wrong way and has to be corrected.

Main Grip
Apply Grease Here
Larger ID
(IN) Smaller ID
(OUT)
Thrust Bearing Direction
Main grips are factory preassembled; in case of reassembling
make absolutely sure you use the correct “ID” ring at the correct
position. Place the large ID Towards the Main Shaft and the
small I.D. Towards the Blades during assembly.
Team Tips
General:
Step 3
Step 4
Step 5
TheBallLinks ontheAtom needtobe resized.These Ball LinkswillNOTbreakin overtime.they
willstaytight andwillcauseunwanted interactions.
Itisvery importanttoresizethe BallLinksfor smooth travel,especiallyon thetail;becauseissues
liketailwag, sluggishtail,orinconsistent Piro-ratewilloccur.
Itisvital nottoovertighten theMainGear Bolt, oritcan causetheAutorotation Geartoslightly
warp.This cancausea prematureBeltfailure,or reducethelifetimeof theBelt.
:
To improve '3D' Tail Rotor authority we suggest doing the “Tail Blade Grip Flip”. The result is
a increased stability in 3D flying.
:
:
LeaveAbout 0.1mm space between the Flybar Collar and the Flybar Holder, this avoids the
Flybar to snap when flying.

Parts List
Atom 500
Version 2.5/2009
How to order your parts!
1. Check part number on the drawing
2. Use the part number to find the ORDER number on the list
3. Only use ORDER number for your parts order
CopyrightCompassModel 2009
Aswecontinue to improve ourproducts,thispart list may notreflectallrecent product amendmends.
Formoreinformation, please refer towww.compassmodel.com

02-0701
80-0322S
06-0109
80-2516
06-0102
06-0106N
79-0306
82-621003
06-0114
91-0003
80-0206
60-6124
06-0108
80-2506 06-0101
63-61245
60-6124
82-4101
79-0408
91-0025
61-3062
97-0715
06-5101
06-8104
61-2562
81-0303
80-0206S
02-0701
06-0507
06-0513 06-0505
80-2512
06-0504
06-0512
81-0303
06-0510
06-0511
06-0507
02-0701
61-2562
82-2540
06-0508
60-2562
81-0304
06-0514
80-0206S
81-0303
81-0303
Main Grip
Apply Grease Here
Larger ID
(IN) Smaller ID
(OUT)
Thrust Bearing Direction
Main grips are factory preassembled; in
case of reassembling make absolutely
sure you use the correct “ID” ring at the
correct position. Place the large ID
Towards the Main Shaft and the small I.D.
Towards the Blades during assembly.

Part No. Part Description Order No. Order Description Remark
02-0701 Stainless Link Ball 02-0701 Stainless Link Balls 10 pcs/bag
06-0101 Main Blade Holder 06-5101 Main Blade Holder set (Atom 500) 1 set/bag
06-0102 Rotor Hub Washer 06-0106Z Rotor Hub set (Atom 500) 1 set/bag
06-0106N Rotor Hub 06-0106Z Rotor Hub set (Atom 500) 1 set/bag
06-0108 Main Blade Holder Arm 06-0108S Main Blade Holder Arm set (Atom 500) 2 set/bag
06-0109 Delrin Dampner 06-0109 Delrin Dampner (Atom 500) 2 pcs/bag
06-0114 Spindle Shaft 06-0114 Spindle Shaft set (Atom 500) 3 pcs/bag
06-0504 Flybar Holder 06-0504 Flybar Holder w. Bearings (Atom 500) 1 set/bag
06-0505 Mixing Arm 06-0505Z Mixing Arm set (Atom 500) 2 set/bag
06-0507 Flybar Control Arm 06-0507 Flybar Control Arm set (Atom 500) 2 pcs/bag
06-0508 Mixing Arm Collar 06-0505Z Mixing Arm set (Atom 500) 2 pcs/bag
06-0510 Flybar 06-0510 Flybar set (Atom 500) 3 pcs/bag
06-0511 Flybar Collar 06-0511 Flybar Collar set (Atom 500) 1 set/bag
Paddle 11gr (default) 06-0512H Paddle set 11g default (Atom 500) 1 set/bag
Paddle 7gr (3D) 06-0512L Paddle 7gr 3D (Atom 500) 1 set/bag
06-0513 Paddle Insert 06-0512H Paddle Insert set (Atom 500) 1 set/bag
06-0514 Flybar Weight (Atom 500R) 06-0514S Flybar Weight set (Atom 500R) 1 set/bag
06-5101 Main Blade Holder complete 06-5101 Main Blade Holder complete set (Atom 500) 1 set/bag
06-8104 Rotor Complete 06-8104 Rotor set complete w. Flybarholder (Atom 500) 1 set/bag
60-2562 Ball Bearing 2.5x6x2.5 60-2562 Ball Bearings 2.5x6x2.5 2 pcs/bag
60-6124 Ball Bearing 6x12x4 60-6124 Ball Bearings 6x12x4 2 pcs/bag
61-2562 Flanged Bearing 2.5x6x2.6 61-2562 Flanged Bearings 2.5x6x2.6 4 set/bag
61-3062 Flanged Bearing 3x6x2 61-3062 Flanged Bearings 3x6x2 4 set/bag
63-61245 Thrust Bearing 6x12x4.5 63-61245 Thrust Bearings 6x12x4.5 2 pcs/bag
79-0306 Button Head Bolt M3x6 79-0306 Button Head Bolts M3x6 10 pcs/bag
79-0408 Button Head Bolt M4x8 79-0408 Button Head Bolts M4x8 10 pcs/bag
80-0206S Cap Head Bolt 2x6 (Link Balls) 80-0206S Cap Head Bolts 2x6 (Link Balls) 10 pcs/bag
80-0322S Cap Head Bolt M3x22 (shanked) 80-0322s Cap Head Bolts M3x22 (shanked) 2 pcs/bag
80-2506 Cap Head Bolt M2.5x6 80-2506 Cap Head Bolts M2.5x6 10 pcs/bag
80-2512 Cap Head Bolt M2.5x12 80-2512 Cap Head Bolts M2.5x12 10 pcs/bag
80-2516 Cap Head Bolt M2.5x16 80-2516 Cap Head Bolts M2.5x16 2 pcs/bag
81-0303 Set Screw M3x3 81-0303 Set Screws M3x3 10 pcs/bag
81-0304 Set Screw M3x4 81-0304 Set Screws M3x4 10 pcs/bag
82-2540 Washer 2.5x4.1x0.2 82-2540 Washers 2.5x4.1x0.2 10 pcs/bag
82-4101 Washer 4.1x10x1 82-4101 Washers 4.1x10x1 10 pcs/bag
82-621003 Washer 6.2x10x0.3 (spindle) 82-621003 Washers 6.2x10x0.3 (spindle) 10 pcs/bag
91-0003 Nylon Nut M3 91-0003 Nylon Nuts M3 10 pcs/bag
97-0715 Rubber O-Ring 10x7x1.5 97-0715 Rubber O-Ring set10x7x1.5 4 pcs/bag
06-0512

80-0206S
06-0503
06-0518
61-2562
80-0205
61-2052
82-2540
82-2540
80-2510
61-2562
06-0520
02-0701
61-2052
06 8502-
06-0607
06-8421
06-4502
80-2508
06-4603
60-10153
62-101412
06-0603
06-0605
06-0608
80-2518
80-2510
6 -101053
06 8602-
91 0025-
80 0206-
06 0410S-

Part No. Part Description Order No. Order Description Remark
02-0701 Stainless Link Ball 02-0701 Stainless Link Balls 10 pcs/bag
06-0410S Swashplate Pin 06-0410S Swashplate Pin Set (Atom 500) 1 set/bag
06-0503 Washout Base 06-0503S Washout Base set (Atom 500) 1 set/bag
06-0518 Washout Link 06-0518 Washout Links (Atom 500) 2 pcs/bag
06-0520 Washout Control Arm 06-0520Z Washout Control Arm set (Atom 500) 1 set/bag
06-0603 Autorotation Hub 06-0603Z Autorotation Hub w. Bearing (Atom 500) 1 set/bag
06-0605 Autorotation Sleeve 06-0605 Autorotation Sleeve (Atom 500) 1 pcs/bag
06-0607 Main Shaft (Ø 8mm) 06-0607 Main Shaft (Atom 500 Ø 8mm) 1 pcs/bag
06-0608 Main Shaft Lock Clamp (Ø 8mm) 06-0608S Main Shaft Lock Clamp set (Atom 500 Ø 8mm) 1 set/bag
06-4502 Main Pulley 06-4502 Main Pulley (Atom 500) 1 pcs/bag
06-4603 Main Gear 06-4603 Main Gear (Atom 500) 1 pcs/bag
06-8421 Swashplate 06-8421 Swashplate complete (Atom 500) 1 set/bag
06-8502 Washout complete 06-8502 Washout set complete (Atom 500) 1 set/bag
06-8602 Main Gear w. Pulley Assembly 06-8602 Main Gear w. Pulley Assembly (Atom 500) 1 set/bag
60-10153 Ball Bearing 10x15x3 60-10153 Ball Bearings 10x15x3 2 pcs/bag
61-2052 Flanged Bearing 2x5x2.5 61-2052 Flanged Bearings 2x5x2.5 4 pcs/bag
61-2562 Flanged Bearing 2.5x6x2.6 61-2562 Flanged Bearings 2.5x6x2.6 4 pcs/bag
62-101412 One Way Bearing 10x14x12 62-101412 One Way Bearing 10x14x12 1 set/bag
80-0205 Cap Head Bolt M2x5 80-0205 Cap Head Bolts M2x5 10 pcs/bag
80-0206S Cap Head Bolt 2x6 (Link Balls) 80-0206S Cap Head Bolts 2x6 (Link Balls) 10 pcs/bag
80-2508 Cap Head Bolt M2.5x8 80-2508 Cap Head Bolts M2.5x8 10 pcs/bag
80-2510 Cap Head Bolt M2.5x10 80-2510 Cap Head Bolts M2.5x10 10 pcs/bag
80-2518 Cap Head Bolt M2.5x18 80-2518 Cap Head Bolts M2.5x18 2 pcs/bag
82-2540 Washer 2.5x4.1x0.2 82-2540 Washers 2.5x4.1x0.2 10 pcs/bag
91-0025 Nylon Nut M2.5 91-0025 Nylon Nuts M2.5 10 pcs/bag

C5016
78 0308-
06 0830R-
06 0822-
06 0606-
06 0905-
06 0843-
02 825-1
02 0845-
02 0849-
06 0302-
02 1805-
06 0811-
06 4309-
60 8165-
(- )06 4308
(- )06 4310
80 0306-
02 0805-
07 0818-
80 0314-
61 3084-
06 0828-
61 3084-
82 3- 504
06-8203
81 0316-
06 0822-
06 8203
-
06 0305-
06 0830L-
80 0340-
06 0812-
80 2506-
95 2508-
95 0310-
80 0308-
82 3201-
a
a
a
a
a
a
a
a
a:
b
b
b:
c:
c
c
d:
d
d
e:
e
e
e
e
e
e
ee
f: 80 0306-
f
f
9 00031-
06 0827-
06 0818-
81 0305-
02 0820-
