Component Solution Services REC02F Troubleshooting guide

- 0 -

- 1 -
Part: # REC02F
MDVR GUIDE
Mobile Digital Video Recorder
Corporate Office
P.O. Box 245 Spring Lake, MI 49456
616.414.0505
fax: [phone]
Elkhart Office/ Technical Support
574.584.3770

- 2 -
Contents
Introduction ...............................................................................................................................4
Features….................................................................................................................... ......4
Camera Placement….............................................................................................................5
In-vehicle Cameras …........................................................................................................5
Recording & Playback …........................................................................................................6
System Start-Up ..............................................................................................................6
System Shut-Down ..........................................................................................................6
Playback Options ................................................................................................................6
TV Video Output (Front and Back) ....................................................................................6
Removable Hard Drive USB Connection ...........................................................................6
Front Panel USB Connection ............................................................................................6
MDVR Layout …........................................................... ............................................................7
Front Panel ….….....................................................................................................7
Back Panel …......................................................................................................8
Installation …..............................................................................................................................9
Proper Mounting Location….......................................................................................................9
Installation Instructions…......................................................................................................10
System Power Wiring…...........................................................................................................11
IR Remote Instructions….........................................................................................................12
Menu Configuration…...............................................................................................................14
Login Page…........................................................................................................................14
Main Menu Page….................................................................................................................15
Date and Time…............................................................................................................... 16
Record …...........................................................................................................................17
General Options….......................................................................................................17
Camera Setup…...........................................................................................................19
Record Schedule….......................................................................................................20
HDD Management…...........................................................................................................21
Disk Format…...............................................................................................................22
Network….............................................................................................................................23
DVR IP Options…..........................................................................................................23
WIFI…............................................................................................................................24
3G….............................................................................................................................25
Server….........................................................................................................................26
General…............................................................................................................................27
Vehicle Startup and Shutdown…...................................................................................27
Driver & Company Info….............................................................................................28
Insert Info ….............................................................................................................. 29
Buzzer Setup…............................................................................................................20
Security…..............................................................................................................................31

- 3 -
System Level.....................................................................................................................32
Firmware Upgrade….....................................................................................................33
Reset Default….............................................................................................................35
Alarm…................................................................................................................................37
I/O Input….....................................................................................................................37
G-sensor…..................................................................................................................38
Speed Limit…....................................................................................................................39
Search…............................................................................................................................40
Log …...............................................................................................................................42
System Info ….....................................................................................................................44
Modules…................................................................................................................ 44
History…...................................................................................................................... 45
Pan/Tilt/Zoom ...........................................................................................................46
Global Positioning System.......................................................................................47

- 4 -
Introduction
This manual is intended to provide the user with the information required for proper installation,
initial setup and explanation of the individual programming options. For additional support, please
contact us or your local distributor.
Except excellent anti-vibration solution and 64G SDHC card at most, the MDVR’s compact size
& 8-48V DC input provide full possibility in various type of moving vehicles. All of our MDVR are
equipped with Rich I/Os. High definition D1 resolution can offer the clear image for travel movie or
surveillancevideos. RS232/RS485 is provided for External devices. Optional GPS (Global Position
System) allows keeping track of your vehicles in Google Map. 3-axis G-sensor helps record any
traffic accident/quick start/quick stop timely. The MDVR’s also supports RFID equipment for transit
bus, commuter bus, and school bus.
With the help of our CMS, this powerful MDVR can offer wireless live surveillance, Google map
online tracking, remote alarm, two-way voice communication and intelligence fleet management,
resume upload /download, video management, etc.
Features
H.264 video compression for high quality low storage needs and longer recording
D1 definition (720×576, NTSC, 704×576, PAL), QCIF/CIF/HD1 selectable.
4CH video and 4CH audio input, 1 video / audio output
Ultra compact extruded aluminum housing, light and vibration resistant
Embedded Linux operating system & On Screen Display menu
64G SDHC card at most( Class 4/ 6)
PC-based FAT 32 file system
Frame Rate per channel: (PAL) 1-25fps ; (NTSC) 1-30FPS
Live video & audio surveillance and tracking in Google Map
Support for 3G, GPRS & Wi-Fi for wireless transmission(optional)
4 alarm inputs with selectable pre-alarm and post-alarm recording
Interior, 3-axis, inertia trigger of video-matched motion events (for accidents)
Support for RFID, Police Detection Radar, Pan Tilt Zoom (PTZ), etc.
CMS support for video management, live tracking, large fleet management, etc.
Easy to use PC-based MDVR Player for playback andAVI output conversion
Video event search software allows intelligent searching of video based on event
8-48V DC input adaptive, 12 DC output for cameras
Broad temperature operating range: -40℃—60℃( optional heater)
Recommended Applications:
Public Transportation, School Buses, Bank Vehicles, Police Vehicles, Military Patrol Vehicles,
Coaches, Commercial Tankers, Freight, Logistics Vehicles, etc.

- 5 -
Camera Placement
Cameras can be mounted anywhere inside of the vehicle where a stable mounting platform is
available. Any selected location should be as vibration constrained as possible. For outdoor
applications, use outdoor cameras and observe the same low vibration recommendation.
Recommend placement illustrations of in vehicle cameras.
In-vehicle Cameras
Cameras for use in a vehicle are different from CCTV cameras. Below are some
recommendations:
A. For small vehicles, cars, taxis, trucks, or an SUV use a camera with 420TVL specifications.
For a bus, use 480TVL. For HD quality use 480TVL/540TVL to match with D1 resolution.
B. Mini metal (Aluminum) housings are recommended.
C. Outside of vehicle cameras need to have waterproof technology.
D. Illumination lamps should be available for night time applications.
E. Wide angel lens cameras are helpful in forward viewing situations.

- 6 -
F. Vandal proof cameras should be used in criminal or rough environment applications.
Recording & Playback
System Start-Up
To start the recording process, place the system switch in the ON position (this will be
done automatically if the system switch is connected to the ignition switch and the ignition
switch is in the ON position). Upon turning the system switch ON, MDVR will commence
recording.
System Shut-Down
To stop the recording process, place the system switch in the OFF position. If the
Shutdown Delay option is enabled, the MDVR will continue to record for the prescribed
number of minutes. When the off-delay expires, the camera and MDVR will shut off.
Playback Options
1. TV Video Outputs (Front and Back)
Using a TV Monitor and the MDVR Remote Control, user can access recorded video files
by Date and Time or by Event. After selecting the appropriate file, the user can review the
video using Play, Stop, Pause, Fast Forward, Fast Rewind, Slow Forward, Slow Rewind,
Frame Forward, and Frame Reverse. The user can select individual video channels to be
displayed full screen by pressing the numeric button on the remote corresponding to that
channel, or view all channels at the same time.
2. Removable Hard Drive USB Connection
Using MDVR Player, user can access the files by connecting the computer to the
Removable Hard Drive Module Back Panel USB port.
3. Front Panel USB Connection
Using PC based MDVR Player, the user can copy videos to the USB flash disk or USB
DVD±RW equipments to access the files by connecting the computer to the DVR Front Panel
USB port.
4. PC Network Connection
It usually connects with 3G router to get a wireless communication, then user can
access the files through CMS (Central Management Software)

- 7 -
MDVR Layout
Front Panel
HDD Slot: the removable Hard Disk Drive occupies this slot in the MDVR. It is used to record
video images,
USB: For firmware update or backup with USB DVD±RW or USB Flash Disk
IR Indicator: Infrared receiver lens for use with the MDVR Remote Control unit. NOTE: Please
ensure that the MDVR is installed where the handheld IR controller can be pointed directly at
the IR receiver lens. Point your handheld controller at the spot on the recording module allowing
the unit to respond to commands from the controller.
LOCK: When you turn the key to the vertical lock position, the MDVR can start recording.
When you turn the key toward the horizontal unlock position, the MDVR will stop recording and
the HDD, with housing, can be removed from the MDVR.
Video: Video is standard RCA output
Audio: Audio is standard RCA output.
LED Indicator and Status Display:
[ WK ] Video recording and working status: LED ON indicates recording is on for at least one
channel.
[ HD ] LED ON indicates system is reading/writing to hard disk. OFF means no recording is
taking place or being written to storage media (HDD/SSD).
[ HT ] LED ON indicates the heater is working.
[ NW]LED ON indicates that 3G or Wi-Fi has connected successfully. OFF means no 3G/Wi-Fi

- 8 -
signals are being received or launched, CMS can’t monitor the MDVR in this case.
[ CH1] ~ [ CH4 ] Video inputs : LED on indicates the camera is correctly connected.
Back Panel
All connections to the MDVR are attached to the rear of the MDVR using pre-assembled cable
bundles specifically labeled for each purpose, It includes the following 6 parts:
GPS: Connects to the GPS antenna - if you order the MDVR with GPS.
WIFI/3G: Connects 3G/Wi-Fi antennas to facilitate a good signal.
AV: audio and video input interface with power output for cameras
I/O: Sensors and RS232/485 communication connection (RFID, sensors, etc.)
NET: Network Connection port (RJ-45)
POWER IN: Power Connections
DEBUG: Use by manufacturing to checkfor any problems before delivery
Disconnecting a cable bridal does not affect the operation of remaining MDVR functions
Note: The 3G slot is in the bottom of MDVR.
Back Panel

- 9 -
Installation
WARNING
DISCONNECT VEHICLE BATTERY VOLTAGE BEFORE INSTALLING
SYSTEM WIRING
WARNING
DISCONNECT POWER TO MDVR BEFORE JUMP
STARTING VEHICLE
WARNING
INSTALL DVR HORIZONTALL Y. USE EXTERNAL SHOCK ANDVIBRATION
DAMPENING IF NEEDED
Proper Mounting Location
For proper installation of the MDVR, choose a location in the vehicle that meets the following:
Power:
It is recommended that the MDVR be connected to the vehicle ignition.
Battery power is used only when the vehicle is running.
NOTE: The MDVR could drain any vehicle battery over time if the ignition is not
turned off.
Connection:
Connect only to appropriate power supply and ensure proper grounding of
the circuit. Use crimp-on connections where possible.
Moisture:
Protect unit and connections from environmental sources of moisture and
liquid spills.
Temp:
Do not install where unit temperature will exceed F140°F (60°C) or fall below
-20°F (-28°C) or store the unit where temperatures rise above 175°F (80°C).
Avoid direct exposure to sunlight.
Ventilation
Provide sufficient ventilation with a minimum of 6 inches cooling clearance to
ensure proper operating temperaturefor the unit.

- 10 -
Vibration:
If necessary, provide additional shock mounting to prevent damage and wear
by excessive vibration.
Clearance:
Front clearance of 8 inch is required to slide the recording module from the
mounting assembly.
Wiring:
Install where mounting assembly wires have sufficient clearance and will not
be crimped or subject to wire insulation damages due to vibration.
Access:
Secure the MDVR so that passengers or drivers cannot tamper or damage
the unit, cameras, wires or other accessories. Do not mount where access to
any other vehicle component will be restricted.
Injury:
Install the unit, cameras, accessories and wires so that no injuries can be
caused through impact with equipment during vehicle operation. Ensure that
all transportation regulations are followed to avoid passenger injury should
they come in contact with the installed
Installation Instructions
Follow these guidelines when installing the MDVR:
Remove all components provided in the package.
Disconnect any power supply or device.
Locate a proper spot to install the mounting assembly and provide any additional shock
absorption if necessary. Locate a reliable electrical ground point in the vehicle.
Make all connections to the rear of the mounting assembly.
Connect power source and turn the vehicle ignition (make sure this connects with ―Signal‖)
to test the unit.
Observe completion of the unit power-up procedures as described in section labeled
―System Startup and Shutdown‖.
Maintain any labeling information required by local or state statutes for video surveillance.

- 11 -
MDVR System Power Connection
Ignition Mode: Recommend! Ignition mode allows MDVR to be Power On or Off as long as
you ignite or shutdown vehicle. You also need setup startup recording mode in
Record >>Genera as show in Page 21, then decide when the MDVR start recording.
Timer Mode: Timer Mode allow MDVR be Power On or Off following the starting time and
shutdown time you set in MDVR startup mode in Genera>>Vehicle as show in Page 31.
Then select the startup recording mode in Record>>General as shown in Page 21.
Standby Mode: This mode allows MDVR keep Power On all the time only if vehicle battery
can off enough power. Then select the startup recording mode in Record>>General as
shown in Page 21.
Battery
＋
-
DC－ Black Cable
DC＋ Red Cable
MDVR
Battery
＋
-
MDVR
Ignition
Switch
.
ACC Yellow Cable
DC＋ Red Cable
DC－ Black Cable
Battery
＋
-
MDVR
Ignition
Swith
DC－ Black Cable
DC＋ Red Cable
ACC Yellow Cable
ACC Yellow Cable

- 12 -
IR Remote Instructions
Each MDVR includes a handheld Infra-Red (IR) controller that allows the user to transmit commands
to the recording module and display on a screen control menu on a composite monitor (V1 output).
Numeric Input Keys
Use the numbers to input values in the system setup screen or switch through the channels in live
and playback. Plus and Minus is used to increase setup values one by one.
Navigation Cursors
Use the CURSOR keys to move between selections, input fields and icons. Press ENTER to select
and EXIT to cancel and return main menu. Next and previous is also used to increase or decrease
volumes when viewing live or search screens.
* Note: The Up key can delete the input character or number in case of driver information and security
setup.

- 13 -
Other Important Keys:
Regular Keys
LOGIN
Press Login key to enter the main menu, enter user ID and password to
start setup
Enter
Select, Enter, Confirm
Shift ABC/abc /123 input
EXIT
Cancel and exit
POWER
The Power button can reset the DVR into sleep mode (unit will stop
recording while in the sleep mode)
PRESET
Preset
PLAY/PAUSE
Starts/Resumes playback from any other mode (FF, RR, Frame by
Frame etc)
－
Audio volume down
＋
Audio volume up
Below are keys used only for Pan Tilt Zoom camera functions
PTZ
Start to active the PTZ function
RECALL
PTZ Mode
IRIS-
Decrease Iris
IRIS+
Increase Iris
FOCUS-
Focus in
FOCUS+
Focus out
Zoom-
Zoom out(only PTZ)
Zoom+
Zoom in (only PTZ)

- 14 -
Menu Configuration
Login Page
Press LOGIN on IR Remote to enter "LOGIN" interface. Enter your registered ID and password,
then Select 【LOG IN】to enter main menu.
Note: In order to protect privacy, users should always have a user ID and password. The default
MDVR setting is no User ID and password.
FOR SECURITY REASONS, please setup a User ID and Password for every MDVR as soon as
possible (installation time is best).
NOTE:Administrators and Clients have login rights, but Administrators can create and delete client
ID’s.

- 15 -
Main Menu Page
Select any sub-menu you want by position the Cursor over the sub-menu item and press【ENTER】
on remote controller to start the setup process.
Menu Guide
SEARCH
Search Recordings
LOG
Event Logs
CLOCK
Adjust date and time
ALARM
I/O Sensors / G-sensor/ Speed alarm input and output
GENERAL
Vehicle /Driver /Inserted Info
INFO
Modules/ History information
STORAGE
SD/HDD space status/Format
OUTPUT
PTZ Protocols
RECORD
General options/Setup/Schedule
USERS
ID and Password Management
SYSTEM
Update/ Restore system
NETWORK
Network Protocols Properties

- 16 -
SEARCH
To search for and playback any video currently on MDVR. The files are selectable (using the
arrow buttons, the numeric buttons, and the 【ENTER】on the remote control) by entering in a date
(and optionally a time) of the recorded files.
Option:
Select "SEARCH" icon with remote controller and press【ENTER】. GUI appear like below:
NOTE 1: The MDVR always records based upon the RECORD MODE settings, even when
playing back video files.
NOTE 2: Please notice the color of the date. Both yellow and red mean that a recording exists. A
blank date means that no recording exists for that date.
Search Result
In the search result list, the information about a recording, including Camera, type, time, and size are
shown:

- 17 -
P.18
After the correct date has been chosen, a list of files appears for video file selection. The size
of the video file is determined by the RECORD FILE SIZE, as shown in P.18
Use the arrow buttons and the 【ENTER】key on the remote control to select and activate a
video file to playback. The MDR always records based upon the Startup Mode settings, even when
playback video files.

- 18 -
LOG
The MDVR maintains a log file of activities and events.
Select "LOG"icon with remote controller and press【ENTER】. GUI appear like below:
NOTE 1: The MDVR always records based upon the Startup Mode settings, even when playing
back log files.
NOTE 2: Please notice the color of the date. Both yellow and red mean that a log file exists. A
blank date means that no log file is available for that date.
Search Result
In the search result list, you can see information about a log file, including Source, Time, and Type
of entry.

- 19 -
Source: press【ENTER】key on remote controller to select the type of Event;
Time: To check the time of the video files, use the number keys to input;
Type: You can see the information type.
PAGE UP /PAGE DOWN: If results are more than one pages.
Press【EXIT】icon on GUI to return to previous menu.
CLOCK (Date&Time):
Select "CLOCK" icon with remote controller and press【ENTER】. GUI appear like below:
