Comtech EF Data SLM-5650C CyberLynx User manual

SLM-5650C CyberLynxTM
SLM-5650C CyberLynxTM ODU
Satellite Modem
Installation and Operation Manual
Part Number MN-SLM-5650C
Revision 1
IMPORTANT NOTE: The information contained in this document supersedes all previously published
information regarding this product. Product specifications are subject to change without prior notice.

SLM-5650C Satellite Modem
Revision 1
MN-SLM-5650C
Copyright © 2019 Comtech EF Data. All rights reserved. Printed in the USA.
Comtech EF Data, 2114 West 7th Street, Tempe, Arizona 85281 USA, 480.333.2200, FAX: [phone]
Revision History
Rev Date Description
0 Mar 2019 Initial Release.
1 May 2019
Revised operating temperature in Preface.
Added SLM-5650C-ODU features to Section 1.1.
Added LNB voltage feature to Section 1.3.
Added Section 3.3.3 for SLM-5650C-ODU Ethernet connectors.
Added Note to Table 3-6 for SLM-5650C-ODU Remote Connector (DB-9F) pinout.
Added information for SLM-5650C LNB voltage to Section 6.4.2.12 for ODU Controls.
Revised description for Item Number 5 in TableA-3 for SLM-5650C-ODU Connectors and Indicators.
Updated manual in various locations to specify information that applies to SLM-5650C, SLM-5650C-
ODU, or both units.
Updated acronyms where applicable.

SLM-5650C / SLM-5650C-ODU Satellite Modem
Revision 1
Table of Contents TOC-1
TABLE OF CONTENTS
PREFACE ...................................................................................................................................................... I
About this Manual........................................................................................................................................i
Conventions and References......................................................................................................................i
Patents and Trademarks............................................................................................................................ i
Related Documents.................................................................................................................................... i
Warnings, Cautions, Notes, and References.............................................................................................ii
Examples of Multi-Hazard Notices.............................................................................................................ii
Recommended Standard Designations ....................................................................................................iii
Safety and Compliance..............................................................................................................................iii
Electrical Safety and Compliance .............................................................................................................iii
Electrical Installation .................................................................................................................................iii
Class I Pluggable Equipment Type A-Protective Earthing........................................................................iii
Galvanic Isolator Use................................................................................................................................iii
Restricted Access Location.......................................................................................................................iv
Battery Warning.........................................................................................................................................iv
Operating Environment.............................................................................................................................iv
Product Support.........................................................................................................................................iv
Comtech EF Data Headquarters...............................................................................................................iv
Warranty Policy...........................................................................................................................................v
Limitations of Warranty.............................................................................................................................. v
Exclusive Remedies..................................................................................................................................vi
CHAPTER 1. INTRODUCTION...........................................................................................................1–1
1.1 Overview ......................................................................................................................................1–1
1.2 Functional Description ...............................................................................................................1–3
1.3 SLM-5650C / SLM-5650C-ODU Features...................................................................................1–4
1.3.1 Physical Description..................................................................................................................1–5
1.3.1.1 Dimensional Envelopes.................................................................................................1–5
1.3.2 Operational Features................................................................................................................1–7
1.3.2.1 Operating Modes...........................................................................................................1–7
1.3.2.2 Secure Management Interfaces....................................................................................1–7
1.3.2.3 Data Interfaces..............................................................................................................1–7
1.3.2.3.1 10/100/1000BASE-T (Gigabit Ethernet) ....................................................................1–7
1.3.2.4 Independent Tx and Rx Function..................................................................................1–7
1.3.2.5 Verification.....................................................................................................................1–8
1.3.2.6 Updating Modem Firmware...........................................................................................1–8
1.3.3 Interoperability ..........................................................................................................................1–8
1.3.3.1 Legacy Modems............................................................................................................1–8
1.4 Summary of Specifications........................................................................................................1–9
1.5 Performance ..............................................................................................................................1–11
1.5.1 Acquisition and Timing Performance Requirements............................................................... 1–11
1.5.2 Data Quality Performance ......................................................................................................1–12
1.6 BER Performance......................................................................................................................1–14
CHAPTER 2. INDOOR UNIT INSTALLATION....................................................................................2–1
2.1 Installation ...................................................................................................................................2–1
2.2 Connect External Cables............................................................................................................2–1
2.3 Connect Power Supply...............................................................................................................2–2
2.4 Configuration...............................................................................................................................2–2
2.5 Determine the Modem IP Address.............................................................................................2–3

SLM-5650C / SLM-5650C-ODU Satellite Modem
Revision 1
Table of Contents TOC-2
CHAPTER 3. EXTERNAL CONNECTORS AND PINOUTS .............................................................. 3–1
3.1 Overview ......................................................................................................................................3–1
3.1.1 SLM-5650C Connector Overview.............................................................................................3–1
3.1.2 SLM-5650C-ODU Connector Overview....................................................................................3–3
3.2 IF Connectors..............................................................................................................................3–4
3.2.1 SLM-5650C Tx, Rx L-Band IF Interface Connectors................................................................3–4
3.2.2 SLM-5650-ODU Tx, Rx L-Band IF Interface Connectors.........................................................3–4
3.3 Terrestrial Data Connectors.......................................................................................................3–5
3.3.1 SLM-5650C Ethernet Traffic Connector (RJ-45) ......................................................................3–5
3.3.2 SLM-5650C Ethernet Management Connector (RJ-45)...........................................................3–5
3.3.3 SLM-5650C-ODU Ethernet Connectors ...................................................................................3–5
3.4 Utility Connectors .......................................................................................................................3–6
3.4.1 SLM-5650C Remote Connector (DB9).....................................................................................3–6
3.4.2 SLM-5650C-ODU Remote Connector (DB9)............................................................................3–7
3.5 Power/Ground Connector ..........................................................................................................3–8
3.5.1 SLM-5650C DC Power Connector............................................................................................3–8
3.5.2 SLM-5650C-ODU DC Power Connector ..................................................................................3–8
CHAPTER 4. UPDATE FIRMWARE...................................................................................................4–1
4.1 Updating Firmware......................................................................................................................4–1
4.1.1 About Firmware Files, Naming, and Versions ..........................................................................4–1
4.2 Obtain Modem IPAddress............................................................................................................4–2
4.3 Bulk Firmware Update – Ethernet FTP Upload Procedure...........................................................4–2
CHAPTER 5. ETHERNET-BASED MANAGEMENT.......................................................................... 5–1
5.1 Introduction .................................................................................................................................5–1
5.2 Ethernet Management Interfaces & Protocols.........................................................................5–1
5.2.1 Secure Ethernet Management Interfaces.................................................................................5–2
5.3 HTTP/HTTPS (Web Server) Interfaces.......................................................................................5–3
5.4 SNMP Interface............................................................................................................................5–4
5.4.1 Management Information Base (MIB) Files..............................................................................5–4
5.4.2 SNMP Community Strings........................................................................................................5–5
5.4.3 SNMP Traps..............................................................................................................................5–5
5.5 Telnet Interface............................................................................................................................5–7
CHAPTER 6. MODEM CONFIGURATION .........................................................................................6–1
6.1 HTTP/HTTPS Interface................................................................................................................6–1
6.2 Modem Web Page Access..........................................................................................................6–1
6.2.1 User Login.................................................................................................................................6–1
6.2.2 Web Interface – Operational Features......................................................................................6–3
Navigation .....................................................................................................................6–3
Web Page Tabs.............................................................................................................6–3
Execution Buttons .........................................................................................................6–3
Feature Selection..........................................................................................................6–3
Text or Data Entry..........................................................................................................6–4
6.2.3 Web Interface Menu Tree .........................................................................................................6–4
6.3 HTTPS Certificate........................................................................................................................6–5
6.4 Modem Web Interface Page Descriptions ................................................................................6–6
6.4.1 Home Page...............................................................................................................................6–6
Home | Home................................................................................................................6–6
Home | Contact .............................................................................................................6–7
6.4.2 Admin Pages.............................................................................................................................6–8
Admin | Access..............................................................................................................6–8
Admin | SNMP...............................................................................................................6–9

SLM-5650C / SLM-5650C-ODU Satellite Modem
Revision 1
Table of Contents TOC-3
Admin | Time ...............................................................................................................6–10
Admin | FAST .............................................................................................................. 6–11
Admin | Upgrade .........................................................................................................6–12
6.4.3 Configuration (Modem Configuration) Pages .........................................................................6–13
Configuration | Modem................................................................................................6–13
Configuration | Utils.....................................................................................................6–16
Configuration | LoadStore ...........................................................................................6–21
Configuration | Spreading ...........................................................................................6–22
Configuration | AUPC..................................................................................................6–23
Configuration | ODU....................................................................................................6–24
Configuration | TRANSEC...........................................................................................6–25
6.4.4 Status Pages...........................................................................................................................6–27
Status | Status.............................................................................................................6–27
Status | Info .................................................................................................................6–28
Status | Event Log.......................................................................................................6–29
Status | Modem Statistics............................................................................................6–30
Status | Port Statistics.................................................................................................6–31
Status | Config Log......................................................................................................6–33
Status | Firmware........................................................................................................6–35
Status | Constellation ..................................................................................................6–36
CHAPTER 7. REMOTE CONTROL....................................................................................................7–1
7.1 Overview ......................................................................................................................................7–1
7.2 EIA-232 .........................................................................................................................................7–1
7.3 Basic Protocol.............................................................................................................................7–1
7.4 Packet Structure..........................................................................................................................7–3
7.4.1 Start of Packet ..........................................................................................................................7–3
7.4.2 Target Address..........................................................................................................................7–4
7.4.3 Address Delimiter......................................................................................................................7–4
7.4.4 Instruction Code........................................................................................................................7–4
7.4.5 Instruction Code Qualifier .........................................................................................................7–5
7.4.6 Optional Message Arguments...................................................................................................7–6
7.4.7 End Of Packet...........................................................................................................................7–6
7.5 Remote Commands / Queries....................................................................................................7–7
7.5.1 Table Indexes............................................................................................................................7–7
7.5.2 Initial Setup – Priority Commands / Queries........................................................................... 7–11
7.5.3 Modulator (Tx) Commands / Queries .....................................................................................7–12
7.5.4 Demodulator (Rx) Commands / Queries ................................................................................7–17
7.5.5 Modem, Unit Commands / Queries ........................................................................................7–23
7.5.6 Bulk Configuration Commands / Queries ...............................................................................7–31
7.5.7 Automatic Uplink Power Control (AUPC) Commands / Queries ............................................7–32
7.5.8 Gigabit Ethernet Interface Commands / Queries....................................................................7–36
7.5.9 ODU Commands / Queries.....................................................................................................7–37
CHAPTER 8. 10/100/1000BASE-T (GBE) INTERFACE...................................................................8–1
8.1 Introduction .................................................................................................................................8–1
8.2 Physical Description...................................................................................................................8–1
8.2.1 Connector Pinout......................................................................................................................8–2
8.3 General Specifications ...............................................................................................................8–2
APPENDIX A. TROUBLESHOOTING..................................................................................................A–1
A.1 Overview ..................................................................................................................................... A–1
A.2 Common Setup Issues .............................................................................................................. A–1
A.3 System Check............................................................................................................................. A–1

SLM-5650C / SLM-5650C-ODU Satellite Modem
Revision 1
Table of Contents TOC-4
A.3.1 Initial System Check .................................................................................................................A–2
A.3.1.1 SLM-5650C Status Indicators.......................................................................................A–2
A.3.1.2 SLM-5650C-ODU Status Indicators..............................................................................A–3
A.3.2 System Check Using IF Loopback and Internal BERT.............................................................A–5
A.3.2.1 Tx Waveform Check......................................................................................................A–6
A.3.2.2 Rx Waveform Check .....................................................................................................A–7
A.3.3 Modem Demodulator Constellations.........................................................................................A–8
A.4 Fault Isolation............................................................................................................................A–11
APPENDIX B. OPERATIONS REFERENCE .......................................................................................B–1
B.1 Overview ..................................................................................................................................... B–1
B.1.1 OM-73 Mode.............................................................................................................................B–2
B.1.2 MIL-STD-188-165A Mode.........................................................................................................B–2
B.1.3 MIL-STD-188-165A Mode – Sequential....................................................................................B–4
B.1.4 IESS-308 Mode – Standard Higher Rates................................................................................B–5
B.1.5 IESS-308 Mode – Extended.....................................................................................................B–8
B.1.6 IESS-309 Mode – Extended (Closed Network)......................................................................B–10
B.1.7 IESS-310 Mode – Extended Rates.........................................................................................B–11
B.1.8 Turbo Code Mode...................................................................................................................B–11
B.1.9 16-QAM Mode.........................................................................................................................B–12
B.1.10 AUPC Mode............................................................................................................................B–12
B.1.11 AUPC Mode – Sequential.......................................................................................................B–13
B.1.12 AUPC Mode – Turbo...............................................................................................................B–14
B.1.13 NON-SPREAD LDPC Mode – Ultra Low Latency (ULL)........................................................B–14
B.1.14 NON-SPREAD LDPC Mode – Low Latency (LL) ...................................................................B–15
B.1.15 NON-SPREAD LDPC Mode – High Performance (HP)..........................................................B–15
APPENDIX C. OVERHEAD AND SYMBOL RATE CALCULATIONS .................................................C–1
C.1 Overview ..................................................................................................................................... C–1
C.2 Processing Flow and Symbol Rate Calculation...................................................................... C–2
C.3 Sources of Overhead................................................................................................................. C–3
C.3.1 Framing Overhead....................................................................................................................C–3
C.3.1.1 AUPC Framing ..............................................................................................................C–3
C.3.1.2 TRANSEC Framing.......................................................................................................C–3
C.3.2 Total Framing Overhead............................................................................................................C–3
C.3.3 IP Traffic EncapsulationOverhead............................................................................................C–3
C.4 Product Support......................................................................................................................... C–4

SLM-5650C / SLM-5650C-ODU Satellite Modem
Revision 1
Table of Contents TOC-5
LIST OF TABLES
Table 1-1. SLM-5650C / SLM-5650C-ODU Physical Characteristics.......................................................1–2
Table 1-2. Summary of General Specifications.........................................................................................1–9
Table 1-3. Summary of Modulator Specifications......................................................................................1–9
Table 1-4. Summary of Demodulator Specifications...............................................................................1–10
Table 1-5. Summary of Coding Options..................................................................................................1–10
Table 1-6. Acquisition and Timing Performance Requirements.............................................................. 1–11
Table 1-7. Doppler Requirements ...........................................................................................................1–12
Table 1-8. Viterbi Decoder BER ..............................................................................................................1–14
Table 1-9. BSPK/QPSK/OQPSK Viterbi with Reed-Solomon Decoder BER Performance...................1–14
Table 1-10. 8PSK, Trellis Decoder BER Performance............................................................................1–14
Table 1-11. 8PSK, Trellis Decoder with Reed-Solomon BER Performance ..........................................1–15
Table 1-12. 16QAM, Viterbi Decoder with Reed-Solomon BER Performance ......................................1–15
Table 1-13. TPC Decoder BER Performance .........................................................................................1–15
Table 1-14. Sequential Decoding with / without Reed-Solomon BER Performance..............................1–16
Table 1-15. LDPC ULL Decoder BER Performance ...............................................................................1–16
Table 1-16. LDPC LL Decoder BER Performance..................................................................................1–17
Table 1-17. LDPC HP Decoder BER Performance.................................................................................1–17
Table 3-1. SLM-5650C Connectors...........................................................................................................3–2
Table 3-2. SLM-5650C-ODU Connectors .................................................................................................3–3
Table 3-3. Indoor Unit L-Band IF Interface Connectors ............................................................................3–4
Table 3-4. Outdoor Unit L-Band IF Interface Connectors .........................................................................3–4
Table 3-5. SLM-5650C Remote Connector (DB-9F) Pinout......................................................................3–6
Table 3-6. SLM-5650C-ODU Remote Connector (DB-9F) Pinout ............................................................3–7
Table 3-7. SLM-5650C Power Connector.................................................................................................3–8
Table 3-8. SLM-5650C-ODU Power Connector........................................................................................3–8
Table 3-9. SLM-5650C-ODU Power Connector Pinout.............................................................................3–8
Table 5-1. Alarms and Faults SNMPv1 Traps...........................................................................................5–6
Table 5-2. Alarms and Faults SNMPv2c/SNMPv3 Notification .................................................................5–6
Table 6-1. Summary of Counters for Port Statistics Pages.....................................................................6–32
Table 8-1. Connector Pinout......................................................................................................................8–2
Table 8-2. GbE Interface General Specifications......................................................................................8–2
Table A-1. SLM-5650C Connectors and Indicators...................................................................................A–2
Table A-2. SLM-5650C LED Conditions....................................................................................................A–3
Table A-3. SLM-5650C-ODU Connectors and Indicators .........................................................................A–3
Table A-4. SLM-5650C-ODU LED Conditions...........................................................................................A–4

SLM-5650C / SLM-5650C-ODU Satellite Modem
Revision 1
Table of Contents TOC-6
LIST OF FIGURES
Figure 1-1. SLM-5650C Satellite Modem (Indoor Unit) ............................................................................1–1
Figure 1-2. SLM-5650C-ODU Satellite Modem (Outdoor Unit) ................................................................1–1
Figure 1-3. SLM-5650C / SLM-5650C-ODU Block Diagram ....................................................................1–3
Figure 1-4. SLM-5650C Indoor Unit Dimensional Envelope.....................................................................1–5
Figure 1-5. SLM-5650C-ODU Dimensional Envelope ..............................................................................1–6
Figure 3-1. SLM-5650C Connectors............................................................................................................3–1
Figure 3-2. SLM-5650C-ODU Connectors...................................................................................................3–3
Figure 4-1. Firmware Naming Format.......................................................................................................4–1
Figure 5-1. Telnet Login Screen................................................................................................................5–7
Figure 5-2. Telnet Remote Control Interface.............................................................................................5–8
Figure 6-1. Browser Address Box .............................................................................................................6–1
Figure 6-2. Windows Security Screen.......................................................................................................6–2
Figure 6-3. Web Interface Home Page .....................................................................................................6–2
Figure 6-4. Navigation Tab Examples.......................................................................................................6–3
Figure 6-5. Home | Home Page................................................................................................................6–6
Figure 6-6. Home | Contact Page .............................................................................................................6–7
Figure 6-7. Admin | Access Page..............................................................................................................6–8
Figure 6-8. Admin | SNMP Page...............................................................................................................6–9
Figure 6-9. Admin | Time Page................................................................................................................6–10
Figure 6-10. Admin | FAST Page ............................................................................................................ 6–11
Figure 6-11. Admin | Upgrade Page........................................................................................................6–12
Figure 6-12. Configuration | Modem Page..............................................................................................6–13
Figure 6-13. Configuration | Utils Page...................................................................................................6–16
Figure 6-14. Configuration | LoadStore Page .........................................................................................6–21
Figure 6-15. Configuration | Spreading Page .........................................................................................6–22
Figure 6-16. Configuration | AUPC Page................................................................................................6–23
Figure 6-17. Configuration | ODU Page..................................................................................................6–24
Figure 6-18. Configuration | TRANSEC Page.........................................................................................6–25
Figure 6-19. Status | Status Page...........................................................................................................6–27
Figure 6-20. Status | Info Page...............................................................................................................6–28
Figure 6-21. Status | Event Log Page.....................................................................................................6–29
Figure 6-22. Status | Modem Statistics Page..........................................................................................6–30
Figure 6-23. Status | Port Statistics Page...............................................................................................6–31
Figure 6-24. Status | Config Log Page....................................................................................................6–33
Figure 6-25. Status | Constellation Page ................................................................................................6–36
Figure A-1. LM-5650C LED Status.............................................................................................................A–2
Figure A-2. SLM-5650C-ODU LED Status.................................................................................................A–3
Figure A-3. Status | Status Page...............................................................................................................A–5
Figure A-4. Tx Waveform ..........................................................................................................................A–6
Figure A-5. BPSK Constellation................................................................................................................A–8
Figure A-6. QPSK Constellation................................................................................................................A–8
Figure A-7. OQPSK Constellation.............................................................................................................A–9
Figure A-8. 8QAM Constellation ...............................................................................................................A–9
Figure A-9. 16QAM Constellation ...........................................................................................................A–10
Figure A-10. 8PSK Constellation ............................................................................................................A–10
Figure C-1. SLM-5650C/ SLM-5650C-ODU – Feature Block Diagram ................................................... C–2

SLM-5650C / SLM-5650C-ODU Satellite Modem
Revision 1
Table of Contents TOC-7
Acronym List
Acronym Description First Use Page Number
AGC Automatic Gain Control 3-2
AO Assignment Operator 7-5
AUPC Automatic Uplink Power Control 6-14
BER Bit Error Rate 1-4
BIT Built In Test 1-4
BUC Block Up Converter 1-4
CEFD Comtech EF Data 1-2
CLI Command Line Interface Preface ii
CRC Cyclic Redundancy Check 6-32
CW Code Word 6-14
DC Direct Current 2-1
DoD Department of Defense Preface i
DSSS Direct Sequence Spread Spectrum 1-2
Eb/No Energy per Bit (Eb) to the Spectral Noise Density (No)
EIA Electronic IndustriesAssociation Preface ii
EVM Error Vector Magnitude A-7
FCS Frame Check Sequence 6-32
FDMA Frequency Division MultipleAccess 1-2
FEC Forward Error Correction 1-2
FIFO First In First Out 6-18
FPGA Field Programmable GateArray 6-31
FTP File Transfer Protocol 4-1
GbE Gigabit Ethernet 1-7
HP High Performance 1-2
HDLC High-level Data Link Control 1-7
HTTP Hypertext Transfer Protocol 1-2
HTTPS Hypertext Transfer Protocol Secured 1-2
IBS Intelsat Business Service 6-15
IF Intermediate Frequency 1-4
LAN LocalArea Network 1-7
LDPC Low Density Parity Check 1-2
LED Light Emitting Diode 1+2
1-11

SLM-5650C / SLM-5650C-ODU Satellite Modem
Revision 1
Table of Contents TOC-8
Acronym Description First Use Page Number
LL Low Latency 1-2
LNB Low Noise Block Down Converter 1-2
LVDS Low Voltage Differential Signaling 6-14
M&C Monitor and Control 5-1
MAC MediaAccess Control 6-32
MIB Management Information Base 5-1
N/C Normally Closed 1-2
N/O Normally Open 1-2
NMS Network Management System 5-1
OID Object Identifier 5-3
PC Personal Computer 1-2
PEM Privancy-enhanced Electronic Mail 6-5
QO Query Operator 7-5
RF Radio Frequency 1-4
SLL Secure Socket Layer 5-2
SNMP Simple Network Management Protocol 1-2
SWaP Size, Weight, and Power 1-1
TEK Transmission Encryption Keys
TRANSEC Transmission Security B-1
TPC Turbo Product Coding 1-2
UART UniversalAsynchronous Receiver Transmitter 7-1
ULL Ultra Low Latency 1-2
URL Uniform Resource Locator 6-5
WAN WideArea Network 1-7
6-25

SLM-5650C / SLM-5650C-ODU Satellite Modem
Revision 1
Table of Contents TOC-9
Units of Measurement
Unit / Symbol
Definition
Ω
Ohm
A
Ampere
bps
bits per second
˚C
Celsius (degrees)
Hz
Hertz
kHz
kilo Hertz
dB
decibel
dBc
Decibels relative to the carrier
dBm
Decibel-milliwatts
˚F
Fahrenheit (degrees)
Kbps
Kilobit per second
kg
kilogram
ksps
Kilo symbols per second
lbs.
pounds
mA
Milli-amp
Mbps
Megabit per second
MHz
Megahertz
mm
millimeter
ms
millisecond
Msps
Mega symbols per second
mW
milliwatt
in.
inch
ųF
micro-farads
W
Watt
V
Volt

SLM-5650C / SLM-5650C-ODU Satellite Modem
Revision 1
Table of Contents TOC-10
BLANK PAGE

SLM-5650C / SLM-5650C-ODU Satellite Modem
Revision 1
Preface i MN-SLM-5650C
PREFACE
About this Manual
This manual describes the installation and operation procedures for the Comtech EF Data
SLM-5650C CyberLynxTM Indoor Unit and SLM-5650C CyberLynxTM Outdoor Unit Satellite
Modem. This document is intended for the persons responsible for the operation and
maintenance for both of the SLM-5650C modems.
Conventions and References
Patents and Trademarks
See all of Comtech EF Data's Patents and Patents Pending at http://patents.comtechefdata.com.
Comtech EF Data acknowledges that all trademarks are the property of the trademark owners.
Related Documents
The following documents are referenced in this manual:
•Department of Defense (DOD) MIL-STD-188-165A, Interoperability and Performance
Standards for SHF Satellite Communications PSK Modems (FDMA Operation) (dated
November 2005)

SLM-5650C / SLM-5650C-ODU Satellite Modem
Revision 1
Preface ii MN-SLM-5650C
Warnings, Cautions, Notes, and References
A WARNING indicates a potentially hazardous situation that, if not avoided,
could result in death or serious injury.
A CAUTION indicates a hazardous situation that, if not avoided, may result in
minor or moderate injury. CAUTION may also be used to indicate other
unsafe practices or risks of property damage.
A NOTE: gives you important information about a task or the equipment.
A REFERENCE directs you to important operational information or details
furnished elsewhere, either in the manual or in adjunct Comtech EF Data
publications.
Examples of Multi-Hazard Notices

SLM-5650C / SLM-5650C-ODU Satellite Modem
Revision 1
Preface iii MN-SLM-5650C
Recommended Standard Designations
The Electronic Industries Association (EIA) designations supersede the Recommended Standard
(RS) designations. References to the old designations may be shown when depicting actual text
(e.g., RS-232) displayed on front panel menus, Web Server pages, serial remote interfaces,
Telnet Command Line Interfaces (CLIs), or unit rear panels. All other references in the manual
refer to EIA designations.
Carefully review the following information.
Safety and Compliance
Electrical Safety and Compliance
The unit complies with the EN 60950 Safety of Information Technology Equipment (Including
Electrical Business Machines) safety standard.
Electrical Installation
Connect the unit to a power system that has separate ground, line and neutral
conductors. Do not connect the unit without a direct connection to ground.
Class I Pluggable Equipment Type A-Protective Earthing
The cable distribution system/telecommunication network of this product relies on protective
earthing and the integrity of the protective earthing must be ensured
In Finland:
"Laite on liitettävä suojakoskettimilla varustettuun pistorasiaan"
In Norway:
“Apparatet må tilkoples jordet stikkontakt”
In Sweden:
“Apparaten skall anslutas till jordat uttag”
Galvanic Isolator Use
Utrustning som är kopplad till skyddsjord via jordat vägguttag och/eller via annan utrustning och
samtidigt är kopplad till kabel-TV nät kan i visa fall medfőra risk főr brand. Főr att undvika detta
skall vid anslutning av utrustningen till kabel-TV nät galvanisk isolator finnas mellan utrustningen
och kabel-TV nätet.

SLM-5650C / SLM-5650C-ODU Satellite Modem
Revision 1
Preface iv MN-SLM-5650C
Restricted Access Location
In Nordic Countries, equipotential bonding should be applied using the permanently connected
ground stud by a qualified service person.
Battery Warning
Risk of explosion if battery is replaced by an incorrect type. Dispose of used
batteries according to the instructions.
Operating Environment
DO NOT OPERATE THE UNIT IN ANY OF THESE EXTREME OPERATING
CONDITIONS:
•AMBIENT TEMPERATURES LESS THAN -10°C (14°F) OR MORE THAN
50°C (122°F) FOR THE INDOOR UNIT AND LESS THAN -32°C (-26°F)
OR MORE THAN 65°C (149°F) FOR THE OUTDOOR UNIT
•PRECIPITATION, CONDENSATION, OR HUMID ATMOSPHERES OF
MORE THAN 95% RELATIVE HUMIDITY FOR THE INDOOR UNIT
•UNPRESSURIZED ALTITUDES OF MORE THAN 3000 METRES (9842
FEET)
•EXCESSIVE DUST FOR INDOOR UNIT
•FLAMMABLE GASES
•CORROSIVE OR EXPLOSIVE ATMOSPHERES
Product Support
For all product support, please call:
+1.240.243.1880
+1.866.472.3963 (toll free USA)
By email:
[e-mail]
Comtech EF Data Headquarters
http://www.comtechefdata.com
Comtech EF Data Corp.
2114 West 7th Street
Tempe, Arizona USA 85281
+1.480.333.2200

SLM-5650C / SLM-5650C-ODU Satellite Modem
Revision 1
Preface v MN-SLM-5650C
Warranty Policy
Comtech EF Data products are warranted against defects in material and workmanship for a
specific period from the date of shipment, and this period varies by product. In most cases, the
warranty period is two years. During the warranty period, Comtech EF Data will, at its option,
repair or replace products that prove to be defective. Repairs are warranted for the remainder of
the original warranty or a 90-day extended warranty, whichever is longer. Contact Comtech EF
Data for the warranty period specific to the product purchased.
For equipment under warranty, the owner is responsible for freight to Comtech EF Data and all
related customs, taxes, tariffs, insurance, etc. Comtech EF Data is responsible for the freight
charges only for return of the equipment from the factory to the owner. Comtech EF Data will
return the equipment by the same method (i.e., Air, Express, Surface) as the equipment was sent
to Comtech EF Data.
All equipment returned for warranty repair must have a valid Return Material Authorization (RMA)
number issued prior to return and be marked clearly on the return packaging. Comtech EF Data
strongly recommends all equipment be returned in its original packaging.
Comtech EF Data Corporation’s obligations under this warranty are limited to repair or
replacement of failed parts, and the return shipment to the buyer of the repaired or replaced
parts.
Limitations of Warranty
The warranty does not apply to any part of a product that has been installed, altered, repaired, or
misused in any way that, in the opinion of Comtech EF Data Corporation, would affect the
reliability or detracts from the performance of any part of the product, or is damaged as the result
of use in a way or with equipment that had not been previously approved by Comtech EF Data
Corporation.
The warranty does not apply to any product or parts thereof where the serial number or the serial
number of any of its parts has been altered, defaced, or removed.
The warranty does not cover damage or loss incurred in transportation of the product. The
warranty does not cover replacement or repair necessitated by loss or damage from any cause
beyond the control of Comtech EF Data Corporation, such as lightning or other natural and
weather related events or wartime environments.
The warranty does not cover any labor involved in the removal and or reinstallation of warranted
equipment or parts on site, or any labor required to diagnose the necessity for repair or
replacement.
The warranty excludes any responsibility by Comtech EF Data Corporation for incidental or
consequential damages arising from the use of the equipment or products, or for any inability to
use them either separate from or in combination with any other equipment or products.
A fixed charge established for each product will be imposed for all equipment returned for
warranty repair where Comtech EF Data Corporation cannot identify the cause of the reported
failure.

SLM-5650C / SLM-5650C-ODU Satellite Modem
Revision 1
Preface vi MN-SLM-5650C
Exclusive Remedies
Comtech EF Data Corporation’s warranty, as stated is in lieu of all other warranties, expressed,
implied, or statutory, including those of merchantability and fitness for a particular purpose. The
buyer shall pass on to any purchaser, lessee, or other user of Comtech EF Data Corporation’s
products, the aforementioned warranty, and shall indemnify and hold harmless Comtech EF Data
Corporation from any claims or liability of such purchaser, lessee, or user based upon allegations
that the buyer, its agents, or employees have made additional warranties or representations as to
product preference or use.
The remedies provided herein are the buyer’s sole and exclusive remedies. Comtech EF Data
shall not be liable for any direct, indirect, special, incidental, or consequential damages, whether
based on contract, tort, or any other legal theory.

SLM-5650C / SLM-5650C-ODU Satellite Modem
Revision 1
Introduction 1–1 MN-SLM-5650C
Chapter 1. INTRODUCTION
1.1 Overview
Figure 1-1. SLM-5650C Satellite Modem (Indoor Unit)
Outdoor Unit Outdoor Unit
with Caps without Caps
Figure 1-2. SLM-5650C-ODU Satellite Modem (Outdoor Unit)
The SLM-5650C CyberLynxTM Satellite Modem is offered in two unique packages:
•The SLM-5650C indoor unit (referred to as the SLM-5650C), shown in Figure 1-1, uses
conductive cooling and provides for mounting in any orientation via either the thermal
mounting rails or directly to the top or bottom surface.
•The SLM-5650C outdoor unit (referred to as the SLM-5650C-ODU), shown in Figure 1-2,
incorporates either conductive or convection cooling.

SLM-5650C / SLM-5650C-ODU Satellite Modem
Revision 1
Introduction 1–2 MN-SLM-5650C
Both modems satisfy the requirements for government and military communications system
applications that require state-of-the-art modulation and coding techniques to optimize satellite
transponder bandwidth usage, while retaining backward compatibility.
The table below provide some of the key physical characteristic of both units.
Table 1-1. SLM-5650C / SLM-5650C-ODU Physical Characteristics
Description
SLM-5650C
SLM-5650C-ODU
Dimensions 5.7” x 5.2” x 1.5” 7.7” x 5.9” x 2.8”
Volume
44.6 cubic inches
127 cubic inches
Maximum Power Consumption
27W
30W
Prime Input Power 5 VDC, 5.4 Amps
11 VDC to 33 VDC,
2.2 Amps to 0.9 Amps
Cooling Conduction Convection/Conduction
Weight 2.7 lbs. (1.2 kg) 5.5 lbs. (2.5 kg)
The SLM-5650C:
•Meets requirements for SWaP (Size, Weight, and Power) constrained applications in a
high performance but low acoustic signature package.
•Supports Direct Sequence Spread Spectrum (DSSS) waveform and Comtech EF Data
(CEFD) proprietary Low Density Parity Check (LDPC) Forward Error Correction (FEC) in
three block sizes (Ultra Low Latency (ULL), Low Latency (LL), High Performance (HP))
and Turbo Product Code (TPC) FEC (3/4, 5/16, 21/44, 17/18, and 7/8 code rates).
•Is compliant with the provisions of Department of Defense (DoD) Standard MIL-STD-188-
165A, Interoperability of SHF Satellite Communications PSK Modems (Frequency
Division Multiple Access [FDMA] Operation). NOT YET CERTIFIED.
•Can be controlled and monitored from a Personal Computer (PC) using serial remote,
Simple Network Management Protocol (SNMP), Hypertext Transfer Protocol (HTTP),
Hypertext Transfer Protocol Secured (HTTPS), and telnet.
The SLM-5650C-ODU has the same features listed above for the SLM-5650C, plus the following:
•Is IP67 rated.
•A selectable +13 or +18 VDC Low-noise Block Down Converter (LNB) voltage.
•An external TX mute capability, using the DB9 remote control connector.
•Normally Open (N/O) and Normally Closed (N/C) fault relay outputs, using the DB9
remote control connector.
•A different gender and pinout layout of the DB9 connector.
•A fault Light Emitting Diode (LED) that blinks continuously during the boot-up process.
