VCP7238-AHD
USER MANUAL
AHD body camera with
CVBS output

1. This installation should be made by a qualified service person and should
abide to all local codes.
2. Do not disassemble the camera - this is to prevent electronic shock
and/or malfunction. Do not loosen any screws on the camera body.
3. Do not touch the front glass directly. If necessary, use a soft cloth to wipe off
dust or debris.
4. Avoid installation on surfaces subjected to frequent vibration or shocks.
5. Do not operate the camera beyond its temperature range or power source
ratings.
6. Should any damage or suspected damage occur, shutdown the power
source, unplug and contact your service provider.
7. Do not install the camera under unstable lighting conditions. Severe
lighting change or flicker can cause the camera to work improperly.
8. Never use the camera close to a gas or oil leak.
9. Do not drop the camera or subject the unit to physical shocks.
10. Never keep the camera facing directly to strong light.
11. Do not install near devices which emit a strong electro-magnetic field.
12. Unplug the camera from the power source before maintenance.
13. Use a soft cloth only for cleaning.
14. If the camera may be exposed to weather conditions, dust particles or
moisture install in an IP rated housing suitable to the conditions.
PLEASE FOLLOW THE ABOVE CAUTIONS – FAILURE TO DO SO MAY
INVALIDATE THE WARRANTY OR CAUSE SERIOUS INJURY.
CAUTION

INSTALLATION
IMPORTANT: ENSURE ALL CAUTIONARY PROCEDURES ARE
OBSERVED DURING INSTALLATION.
It is recommended the VCP7238 is tested during the most
demanding environmental conditions such as low light or bright
sunlight to ensure continuity of effective CCTV monitoring.
Remove the camera unit carefully from the box, reserving the
accessory contents in a safe place.
Point the Camera towards the intended area to be monitored.
Check the power supply voltage and connect your power supply into
the power port on the Camera.
Attach a test monitor to the video out BNC port and adjust the lens
to give the required image
Adjust the Camera picture using the OSD menu as necessary.
TROUBLESHOOTING
Ensure all power and cable connections are correct between the
Camera, power source, monitor, telemetry devices and DVR if used

Example

CONNECTION EXAMPLE
LENS ADJUSTMENTS
PSU
Built in Lens
Top Cover
Zoom Handle
Focus Handle

OSD
OSD Controller
How to change the video:
To change the video output of the VCP7238-AHD press and hold the
OSD buttons on the rear of the camera for 4 seconds:
•Press and hold left for CVBS
•Press and hold right for AHD
•Press and hold down to switch PAL / NTSC

MAIN MENU
1. LENS
2. EXPOSURE
3. BACKLIGHT
4. WHITE BAL
5. DAY & NIGHT
6. NR
7. SPECIAL
8. ADJUST
9. EXIT
DC
OFF
AT W
EXT
SAVE&END
* Set SHARPNESS, MONITOR, LSC, VIDEO OUT
* Save & END
* ATW(Auto Tracking White Balance)
* AWC -> SET : White Balance is xed at the value when
*(enter) is pressed and keep the value
* INDOOR : White Balance is xed about 3100K
* OUTDOOR : White Balance is xed about 5100K
* Manual : Adjustable value of BLUE and RED
* AWB
* AUTO : DAY or NIGHT is setting automatically by light level
coming through lens.
DELAY TIME, D -> N and N -> D, can set in the menu
* COLOR : Color video output
* B/W : B/W video output regardless of light level
(removes IR cut lter automatically)
* EXT : Day(Color) or Night(B/W) is decided by external light
sensor(CDS sensor)
All IR LED cameras should set EXT.
* Set 2 DNR, 3 DNR
Select OFF, BLC, HSBLC
OSD

EXPOSURE
1. SHUTTER
2. AGC
3 . S E N S - U P
4. BRIGHTNESS
5. D-WDR
6. DEFOG
7. RETURN
1 / 3 0
OFF
OFF
OFF
RET
6 6
1 5
Set mounted Lens type, DC, VIDEO, MANUAL or P-IRIS.
DC Lens : * MODE : Set INDOOR or OUTDOOR
* If camera is equipped auto iris lens, recommend to set AUTO.
* In the region NTSC but 50Hz power, set to FLK(Flickerless).
In the FLK mode, sensitivity will be downed under low light.
* x2 ~ x30, SENS-UP is working at selected frame integration rate
regardless of light level.
* If set to AUTO, can set limitation of maximum integration frame
rate in the x2 ~ x30
* Higher SENS-UP rate is higher sensitivity but slower refresh rate.
* Due to long accumulation by long shutter time, some white dots
may appear.
* Usable at AUTO or 1/60(1/50) set up
* Under lowest light level, AGC is maximized by Automatic Gain Controller
* Can set AGC level 1~15
* Control Brightness level. The higher, the brighter.
* Brightness is controlled by iris of auto iris lens or shutter speed of
xed iris lens.
* This is to enhance visibility in the foggy environment but the
performance is limited.
* Can set Position / Size and Gradation, if set ON.

BLC
1. LEVEL
2. AREA
3. DEFAULT
4. RETURN
MIDDLE
RET
Select Backlight mode, BLC or HSBLC, OFF

3-2. HSBLC
HLC ON
HLC OFF

5. D & NIGHT
DAY & NIGHT
 



t


buft i1 .

5-1.AUTO
D&N AUTO


 
 





 5
 80
. . .
t


t 
ttt
t


NR
1. 2DNR
2. 3DNR
3. RETURN
MIDDLE
HIGH
RET
IR PWM
D - > N(Delay)
N - > D(Delay)
OFF
0
0
* Set IR PWM ON or OFF and set IR PWM LEVEL and AREA
* Set Day & Night
* Set Day & Night
*2D & 3D is powerful noise reduction technology at low light.
*2 DNR reduce noise with spatial frequency for each eld but too strong noise
reduction will be loss sharpness.
*3 DNR reduce noise by time based reduction with several elds but too strong
noise reduction will be have tail effect for fast moving object in the dark.

6-1. 3-DNR (ON)
DESCRIPTION
3 DNR
SMART NR
LEVEL
DEFAULT
ON
LOW
MIDDLE
HIGH
* Camera is keeping watch any motions.
* When no detect : 3 DNR is working for maximum noise
reduction automatically.
This has HDD save effect of DVR
* When detected motion : 3 DNR deactivate slow motion
capture for moving object.
* Set strength of 2D & 3 DNR.
* Higher value, higher noise reduction.
* If set too high, will be loss shaprness in 2 DNR and will be
have tail effect in 3 DNR

SPECIAL
1. CAM TITLE
2. D-EFFECT
3. MOTION
4. PRIVACY
5. LANGUAGE
6. DEFECT
7. RS485
8. RETURN
ON
ON
OFF
ENG
RET
* Can set FREEZE, MIRROR, NEG.IMAGE.
* Support 12 languages, ENG / CHI1 / CH2 / GER / FRA /
ITA / SPA / POL / RUS / POR / NED / TUR
* To change the language, push ●(SET/ENTER).
It will be taken about 4seconds to load new language fonts.

D-EFFECT
1. FREEZE
2. MIRROR
3. N.IMAGE
* OFF : normal image display
* MIRROR / V-FLIP / ROTATE(H/V FLIP)
* Can not use if FREEZE is set to ON

* Return to default

Usually image sensors have some defective pixels and they can be compensated
digitally by image signal processor.
This menu is providing correction of the defective pixels in DPC
DEFECT
1. LIVE DPC
2. WHITE DPC
3. BLACK DPC
4. RETURN
ON
ON
ON
RET
DESCRIPTION
LIVE DPC
AUTOLIVE DPC
DEFAULT
* Real time compensate the defective pixels. Higher level of
LIVE DPC can reduce Sharpness
* ON : Enable LIVE DPC and can set LEVEL
LEVEL:This is limit for white dots noise level caused
by a defect pixel. Lower level is compensating more pixels.
-AGC LEVEL: 0~255
-LEVEL: 0~100
-RETURN
* OFF : Disable LIVE DPC

* Detect the defective pixels under darkness then saving the
data for compensation.
When start detection, camera close the lens automatically and
Even though camera close the lens automatically, recommend
toclose the lens with cap strongly because some lenses are
not closed perfectly by it’s iris.
START
DPC VIEW
POS / SIZE
LEVEL
AGC
SENS-UP
0~60
(*)
0~100
(**)
0~14
ON / OFF
x2~30
*Close the Iris then Press Enter.
* Detect the defective pixels under darkness then saving
the data for compensation.
*Set Position and Size
* This is limit for white dots noise level caused by a defect
pixel.
*Set AGC level
* High SENS-UP rate will be show more defect pixels to
compensate but too high rate is cause wrong detection
for regular noise.
WHITE DPC
WHITE DPC “ON”
7-5. ② WHITE DPC
WH ITE D PC
1. POS/SIZE
2. STA RT
3. DPC VIEW
4. LEVEL
5. AGC
6. SENSE-UP
7. RETURN
★Note: (*) AHD1.0 version / (**) AHD2.0 verion

BLACK DPC “ON”
POS / SIZE
START
LEVEL
DPC VIEW
0~255
(*)
0~100
(**)
ON / OFF
*Set Position and Size
*Press Enter.
* This is limit for black dots noise level caused by
adefect pixel.
* Detect the defective pixels under darkness then saving
the data for compensation.
7-5. ③ BLACK DPC
BL ACK D PC
1.POS / SIZE
2.STA RT
3.DPC VIEW
4.LEVEL
5.RETURN
★Note: (*) AHD1.0 version / (**) AHD2.0 verion

8. ADJUST
ADJUST
1. SHARPNESS
2. MONITOR
3. LSC
4. VIDEO OUT
5. RETURN
AUTO
LCD
OFF
NTSC
RET
DESCRIPTION
ADJUST
AUTO
LCD
*Set shaprness level of pictute.
* Too high sharpnessis cause of image harsh and more noise
SHARPNESS
OFF
OFF
*Select LCD or CRT monitor.
* LCD : Adjustable GAMMA, BLUE GAIN& RED GAIN. Higher
GAMMA is increasing Contrat but loose visibility at dark srea
* CRT : Adjustable BLACK LEVEL
(*)
, BLUE GAIN & RED GAIN
*Set TV system, NTSC or PAL
* LSC(Lens shading compensation) : enhance brightness of
corners(both sides). If this is ON, may noise will be appear.
*Set Video Crop ON or OFF(scale down)
MONITOR
VIDEO OUT
LSC
CVBS
DEFAULT
SAVE&END / RESET/ NOT SAVE
9. EXIT
★ Note: (*) - AHD1.0 version
