CONCORD Avia 60AV5E Operating instructions

A Continuing Commitment to Excellence
Owners Manual
and
Installation Instructions
60AV5E
®
Avia

2
READ AND SAVE THESE INSTRUCTIONS
Before beginning installation of your new Concord
®
ceiling fan,
read and follow these safety precautions. If you are not familiar
with national and local electrical codes and basic electrical wiring
procedures, we recommend that you have a qualified electrician
install your new ceiling fan.
Before you begin, TURN OFF THE ELECTRICITY. Determine which cir-
cuit your new fan will be using and remove the fuse or turn off the circuit
breaker at the main electrical panel.
Make sure that all wiring conforms to national and local electrical codes. If
you are in question, obtain a copy of the codes and wire the fan according-
ly. Never leave bare wires uncovered (wire connection), use wire nuts to
cap all connections. Plastic electrical tape is not recommended.
When working with electricity, never take short cuts. Follow the code in
every respect. Basic requirements for a ceiling fan installed with lights are,
120 volts AC - 60Hz, on a grounded circuit with a 15 amp breaker or fuse.
Make sure that your electrical system and choice of location meet these
requirements.
If the location where you plan to install your fan does not already have an
electrical outlet, hire a licensed electrician to run the wiring and install an
outlet box designed for ceiling fans or heavy fixtures. The outlet box
should be able to support a minimum moving weight of 50 pounds and
marked “Acceptable for Fan Support” (Plastic outlet boxes are not recom-
mended for ceiling fan installation).
If you plan to use an existing electrical location, check to make sure that the
outlet box is not PLASTIC, that it is securely attached and able to support
at least 50 pounds of moving weight and marked “Acceptable for Fan
Support”. If you have any questions, outlet boxes and support systems for
ceiling fans are available at most hardware and do-it-yourself centers. In
most cases, your
Concord
®
dealer will have all the necessary products
for the proper and safe installation of your ceiling fan.
The location you choose should have a minimum clearance of 20 inches
from any wall to the blade tip at any point in its rotation and a minimum of
7 feet from blade level to floor and 10 inches from the blades.

3
Look for Me!
I have safety Tips and
Ideas for installation
These instructions are designed for a number of similar but different ceiling fans. As you
proceed, some steps may or may not apply to the fan you purchased. Compare each step or
optional procedure to your fan and proceed accordingly.
This ceiling fan was not designed for installation in any location where it
might be exposed to moisture or high humidity. Installation in this type of
location could be UNSAFE, will most likely damage the fan and its finish...
and will VOID YOUR WARRANTY.
Every effort has been made to provide you with proper instructions for the
safe installation of this ceiling fan. You could however, encounter situa-
tions or problems not covered in this manual. Should this occur, please
refer to a do-it-yourself wiring handbook or hire a qualified electrician to
install your fan.
Never attach the blades to your ceiling fan before the fan body is properly
mounted on the ceiling.
Lubrication of your new ceiling fan is not necessary. The ball bearings have
been adequately charged with grease and permanently sealed at the factory
so that, under normal conditions, further attention is not necessary.
To reduce the risk of fire, electrical shock, or personal injury,
mount this fan to an outlet box marked “Acceptable for Fan
Support” and use the Mounting Screws provided with the outlet
box. CAUTION: Install the primary mounting means and use
only the hardware provided with the fan.
To reduce the risk of personal injury take care not to bend the
blade carriers. Be careful not to insert foreign objects into rotat-
ing fan blades.
The important safeguards and instructions appearing in this
manual are not meant to cover all possible conditions and situa-
tions that may occur. It must be understood that common sense,
caution and careful attention to detail are factors which cannot be
built into this product. These factors must be supplied by the
person or persons installing, caring for, and operating the unit.

5
Fig. 4
If you are using an extended support rod,
(longer than the one supplied with your fan)
remove the half ball from the support assem-
bly and attach it to the extended support rod
at this point. Make sure to retighten the set
screw and insert the safety pin.
Back off (loosen) the set screws (2) in the sup-
port rod coupler until the inside of the channel
is clear of the screw tip.
Remove and save the safety pin and washer on
the end of the support rod assembly.
Feed the electrical wires from the fan housing
through the support rod.
Thread the support rod into the support rod cou-
pler until the safety pin can be inserted through
the hole in both the rod and coupler.
Tighten both set screws and safety screw on the
support rod coupler.
Step 2 Attach the support assembly
Slide the ceiling canopy onto the support rod,
followed by the support rod coupler cover. (see
Fig. 4)
Insert the safety pin through the hole in the
support rod coupler and support rod then attach
washer into safety pin and the retaining clip on
the other side.
Half Ball Hanger
Ceiling
Canopy
Motor Leads
Safety Pin
Threaded end of
Support Rod
Support Rod
Set Screws
Support Rod
Coupler Cover
Retaining Clip
Washer

8
Step 6 Fan Blade and Blade Arm Assembly
Step 7 Fan Blade Assembly Installation
Remove the large screws in the face of the motor.
Discard any rubber blocks attached to these
screws. The rubber blocks are installed at the
factory to stabilize the motor during shipment.
Attach each blade to the motor face using pre-
installed screws VHHILJXUH
. Take care not to
bend the blade arms during installation. This
will cause your fan to wobble while running.
Most CONCORD fans are supplied with a
reversible blade finish. Choose the blade finish
that you prefer and attach as follow:
Attach each fan blade to a blade arm with
three 3/16” x 7.5 mm blade screws and three
3/16” fiber washers (see figure 11). DO NOT
OVER TIGHEN THESE SCREWS.
Screws should be tightened until the washers
are compressed by the screw head. Hold the
Blade Arm decorative side down and place
the blade on top with the flat side of the blade
facing down. Each screw is passed through
the washer and blade and screwed into the
blade arm.
Try mounting the blades on
opposing sides of the motor
face, This will help keep the
fan more level during blade
installation.
Fig. 11
Fig. 12
Motor Housing
Blade to Arm Screws
Blade Arm
Blade Arm to Motor screws Fan Blade
Blade to Arm Screws
Blade Arm
Fan Blade

9
Fig. 13A
Fig. 13B
Step 8 Light Fixture Installation
Each of the above connections
should be made as tight as
possible using the proper size
plastic wire nuts. Plastic elec-
trical tape is not recommended
for these connections.
Back off (loosen) the three screws on the switch
housing cover (see figure 13A)
.
Connect White wire to White wire, and Black wire
to Blue wire using wire nuts. Press together firmly.
Place light fixture onto fan, line up the 2 holes and
rotate light fixture; Insert the screws and tighten.
Place glass shades onto light fixture, Secure with
thumb screws, DO NOT over tighten (see figure
13B).
Twist bulbs into socket, DO NOT over tighten.
Depending on which model of Avia fan you are in-
stalling, you will either have the 4 light Turtle Clu-
ster (figure 13A-13B) or the Twist-on Light (figure
14) or the Bowl Light (figure 15A-15C).
Please fol-
low instruction under the correct light fixture.
Turtle Cluster:
Secure the light kit (switch housing cover) to the
switch housing by installing the three thumb scre-
ws provided in the hardware pack.
Install light bulb (Max. 60W B10 bulb * 2pcs)
into socket (see figure 14).
Twist Class:
Connect White wire to White wire, and Black wire
to Blue wire using wire nuts. Press together firmly.
Twist glass onto light fixture DO NOT over tigh-
ten.
Thumb Screws
Light Fixture Switch
(pull chain)
Light Fixture
White
Switch Housing Cover
Black
Blue
Thumb Screws
Light Fixture Switch
(pull chain)
Light Fixture
White
Switch Housing Cover
Black
Blue
Glass Shades
Bulbs
Light Fixture
Fig.14
Socket
Bulb
Twist-on Glass
Light Fixture Switch
(pull chain)
Fan Speed
Switch (pull chain)
White
Switch Housing Cover
Black
Blue

10
Fig.15B
Fig.15A
A. Install light bulb (Max. 100W halogen bulb * 1pc)
into socket (see figure 15A).
B. Install light bulb (Max. 60W B10 bulb * 2pcs) into
socket (see figure15B).
C. Install light bulb (Max. 60W B10 bulb * 3pcs) into
socket (see figure15B).
Step 9 Final Checks
Check all set screws and connections are properly
in place and tight.
Check blade clearance and rotation.
Bowl Class:
Connect White wire to White wire, and Black wire
to Blue wire using wire nuts. Press together firmly.
Back off (loosen) the three screws on the switch
housing cover.
Place bowl glass cover on light kit metal nut (rubber
side on the top), glass cap and finial provided. (see
figure 15B).
Attach the decorative pull chain tassel(s) to the light
fixture.
The light fixture pull ch-
You can now control the speeds of your ceiling fan
and the light fixture with the remote control.
With the speed pull chain located on the light fixture,
set the ceiling fan on its highest speed setting. Once
this speed and light control has been installed, the
speed control on the light fixture must be premanently
left on high speed. Failure to leave the fan speed pull
chain set on high speed will damage the fan and con-
trol and could cause a fire.
NOTE:
Light Fixture
White
Switch Housing Cover
Black
Blue
Bulb
Glass
Glass Cap
Finial
Light Fixture switch(pull chain)
Glass Shade
Bulb
White
Switch Housing Cover
Black
Blue
Light
Fixture Socket
Light Fixture Switch
(pull chain)
ain located on the light fixture should be set in the NO
position and left there also.

11
Operation Instruction
NOTE: The Remote Control Transmitter comes
with a bracket that can be mounted in any con-
venient place you choose. Next to a light switch
in the same room as the ceiling fan is a good
place.
Remote Control Operation Instruction
Attach the bracket with the two screws provided.
Remove the panel on the back of the hand control
(transmitter)and install a 12 volt battery(included).
Replace the panel.
The Remote Control Transmitter
Transmitter
Mounting Bracket
Mounting Screw
®
IVI
V
IIIVI
II
Mounting Screw
Cover Plate

12
TRANSMITTER BUTTONS
(see figure 16A)

RESETTING THE CODE WHEN USING DIMMING CONTROL
1. Turn off the AC Power for at least 30 seconds before switching it back on.
2. Press and hold the SET BUTTON for 6 seconds. NOTE: You must complete this process within 60 seconds of turning on the fan.
3. While the code pairing is in process, the fan operates at highest speed in REVERSE mode automatically for 90 seconds then,
operates in FORWARD mode for 90 seconds. The code pairing procedure is complete when fan motor stops.
RECEIVER POWER SURGE AND OBSTRUCTION PROTECTION
1. OBSTRUCTION LOCK POSITION: The Internal Receiver has a built-in safety against obstruction during operation. The
motor will turn off after 30 seconds if their is an obstruction. Once you remove the obstacles you will need to disable the power
supply to re-start the motor.
2. POWER SURGE: If the Internal Reciever detects the unit is receiving over 80 Watts the receiver will turn off the fan. To reset,
wait for 5 seconds and turn on the AC Power and restart the fan.
1. FAN SPEED CONTROL PAD: Controls six fan speeds from highest (VI) to lowest (I)
2. FAN ON/ OFF BUTTON: Turns fan motor On/Off
3. REVERSE BUTTON: Controls fan blade direction ( Clockwise Summer and Counter-Clockwise for Winter )
4. LIGHTING CONTROL BUTTON: Press to turn light on/off. Hold the button for dimming feature.
5. SET BUTTON: Perform the following steps to set remote code. (see figure 16B)
Step 1: Turn on the AC power after attaching the blades to the motor.
Step 2: Turn fan power on, press and hold SET button on back of remote for 5 seconds. The lamp blinks twice when
finishing setup. (NOTE: You must complete this Process within 60 seconds of turning on the fan)
Step 3: After the SET button is pressed, the fan will run on high speed (VI) until setup is finished. Once setup is completed
the fan will return to it’s original factory speed and will then be able to be controlled using the FAN SPEED CON-
TROL PAD BUTTONS.
D
ON
N ECE
1234
6
5
®
IVI
V
IIIVI
II
D
ON
N ECE
1234 SET
12V
2
1
3
4
Fig. 16A Fig. 16B


13
Maintenance
Your fan requires very littlemain-
tenance. Cleaning of thehousing
should be done with adamp soft
cloth, DO NOT USE CLEANING
AGENTS. Clean theblades with
a duster or dry cloth.Any moisture
could cause theblades to warp and
make the fanwobble while running.
Support Rod
Ceiling Canopy
Coulper Cover
Set Scrwer
Safety Pin
Motor Housing
Blade to Arm Screws
Blade Arm
Blade Arm to Motor screws
Switch Housing
Retaining Clip
Fan Blade

14
ATTENTION
Under the Energy Policy Act of 2005, federal regulations require
all ceiling fans with light kits manufactured or imported after
January 1, 2009, to limit the total wattage consumed by the light
kit to 190 watts.
Therefore, this product is equipped with a 190W limiting device. If
lamping exceeds 190 watts, the light kit will shut off automatically
until the proper wattage of bulbs are installed. Reset the light kit
by turning it off, replacing the bulbs with the correct wattage, and
then turning the light kit back on.
Conforms To D.O.E. EPACT Regulation
Limited Lifetime Warranty Applies To Fan Motor Only
®Concord Fans 2014
Concord Fans.
Concord Fans is a division of Luminance.
