Condair DL Series User manual

INSTALLATION MANUAL
Adiabatic air humidification system
Condair DL II
2603656-0 EN 2201
Humidication and Evaporative Cooling
READ AND SAVE THESE INSTRUCTIONS

Thank you for choosing Condair
Installation date (MM/DD/YYYY):
Commissioning date (MM/DD/YYYY):
Site:
Model:
Serial number:
Fill in data at the commissioning!
Contact
Condair Ltd.
2740 Fenton Road, Ottawa, Ontario K1T3T7
TEL: [phone], FAX: [phone]
EMAIL: [e-mail], WEBSITE: www.condair.com
Proprietary Notice
This document and the information disclosed herein are proprietary data of Condair Ltd. Neither this document, nor
the information contained herein shall be reproduced, used, or disclosed to others without the written authorization
of Condair Ltd., except to the extent required for installation or maintenance of recipient's equipment.
Liability Notice
Condair Ltd. does not accept any liability due to incorrect installation or operation of the equipment or due to the
use of parts/components/equipment that are not authorized by Condair Ltd.
Copyright Notice
© Condair Ltd., All rights reserved.
Technical modications reserved

3Contents
Contents
1 Introduction 4
1.1 General 4
1.2 Notes on the installation manual 4
2 For your safety 6
3 Important notes 8
3.1 Inspection of the delivery 8
3.2 Storing/Transportation/Packaging 8
3.3 Product designation 9
4 Mounting and installation work 10
4.1 Safety notes on mounting and installation work 10
4.2 Installation overview 11
4.3 Installation of the humidication unit 12
4.3.1 Positioning of the humidication unit 12
4.3.2 Mounting the post-evaporation unit 15
4.3.2.1 Overview frame constructions post-evaporation unit 15
4.3.2.2 Mounting procedure post-evaporation unit 16
4.3.3 Mounting the nozzle system 36
4.3.3.1 Overview frame constructions nozzle system 36
4.3.3.2 Mounting procedure nozzle system 37
4.4 Positioning and mounting the control unit and central unit mounting rack 46
4.5 Converting the spray circuit outlets from left to right 49
4.6 Mounting the central unit to the mounting rack 52
4.7 Mounting the control unit to the mounting rack 53
4.8 Water installation 54
4.8.1 Overview water installation 54
4.8.2 Notes on water installation 55
4.9 Electrical installation 57
4.9.1 Notes on electrical installation 57
4.9.2 Wiring diagram Condair DL 58
4.10 Wiring plan Condair DL 59
4.10.1 Electrical connections between central unit and control unit 60
4.10.1.1 Wiring diagram central unit - control unit 60
4.10.1.2 Installation work central unit - control unit 61
4.10.2 External electrical connections 65
4.10.2.1 Wiring diagram external electrical connections 65
4.10.2.2 Installation work external connections 66
4.10.3 Connecting options 68
5 Appendix 69
5.1 Dimensional drawing control unit 69
5.2 Dimensional drawing central unit 70

4Introduction
1 Introduction
1.1 General
We thank you for having purchased the adiabatic air humidication system Condair DL.
The humidication system Condair DL incorporates the latest technical ad van ces and meets all recog-
nized safety standards. Nevertheless, improper use of the humidication system Condair DL may result
in danger to the user or third parties and/or impairment of material assets.
To ensure a safe, proper, and economical operation of the humidication system Condair DL, please
observe and comply with all information and safety instructions contained in the present documentation
as well as in the separate documentations of the components installed in the humidication system.
If you have questions after reading this documentation, please contact your Condair representative.
They will be glad to assist you..
1.2 Notes on the installation manual
Limitation
The subject of this installation manual is the humidication system Condair DL in its different
versions. The various options and accessories are only described insofar as is necessary for proper
operation of the equipment. Further information on options and accessories can be obtained in the
respective instructions.
This installation manual is restricted to the installation of the humidication system Condair DL and is
meant for well trained personnel being sufciently qualied for their respective work.
This installation manual is supplemented by various separate items of documentation (operation manual,
spare parts list, etc.), which are included in the delivery as well. Where necessary, appropriate cross-ref-
erences are made to these publications in the installation manual.

5Introduction
Symbols used in this manual
CAUTION!
The catchword "CAUTION" used in conjunction with the caution symbol designates notes in this
installation manual that, if neglected, may cause damage and/or malfunction of the unit or other
material assets.
WARNING!
The catchword "WARNING" used in conjunction with the general caution symbol designates safety
and danger notes in this installation manual that, if neglected, may cause injury to persons.
DANGER!
The catchword "DANGER" used in conjunction with the general caution symbol designates safety and
danger notes in this installation manual that, if neglected, may lead to severe injury or even death
of persons.
Safekeeping
Please safeguard this installation manual in a safe place, where it can be immediately accessed. If the
equipment changes hands, the documentation must be passed on to the new operator.
If the documentation gets mislaid, please contact your Condair representative.
Language versions
This installation manual is available in various languages. Please contact your Condair representative
for information.

6For your safety
2 For your safety
General
Every person working with the humidication system Condair DL must have read and understood this
installation manual and the operation manual of the Condair DL before carrying out any work.
Knowing and understanding the contents of the installation manual and the operation manual is a basic
requirement for protecting the personnel against any kind of danger, to prevent faulty operation, and to
operate the unit safely and correctly.
All ideograms, signs and markings applied to the components of the humidication system Condair DL
must be observed and kept in readable state.
Qualication of personnel
All installation work described in this installation manual may only be carried out by specialists who
are well trained and adequately qualied and are authorized by the customer.
For safety and warranty reasons any action beyond the scope of this manual must be carried out only
by qualied personnel authorized by the manufacturer.
It is assumed that all persons working with the humidication system Condair DL are familiar and comply
with the appropriate regulations on work safety and the prevention of accidents.
Intended use
The humidication system Condair DL is intended exclusively for air humidication in AHU's or air
ducts within the specied operating conditions (see operation manual of the humidication system
Condair DL). Any other type of application, without the written consent of the manufacturer, is consid-
ered as not conforming with the intended purpose and may lead to the humidication system Condair
DL becoming dangerous.
Operation of the equipment in the intended manner requires that all the information contained in this
installation manual are observed (in particular the safety instructions).

7For your safety
Danger that may arise from the humidication system Condair DL
DANGER!
Danger of electric shock!
The control unit of the Condair DL and the pump motor inside the central unit (if applicable)
are mains powered. Live parts may be exposed when the control unit and/or the central unit
is/are open. Touching live parts may cause severe injury or danger to life.
Prevention: The control unit of the Condair DL must be connected to the mains only after all mounting
and installation work has been completed, all installations have been checked for correct workmanship
and all unit covers are relocated properly locked.
Important! The frequency converter in the control unit of systems with booster pump contains
capacitors. These can remain charged with a potentially deadly voltage for a certain period of
time after the control unit has been disconnected from the power supply. Therefore, wait at least
10 minutes after disconnecting the power supply. Then make sure the appropriate contacts on
the frequency converter and the terminals on the pump motor are free of voltage before starting
any work on these components!
WARNING!
Risk of injury
The ceramic plates of the post-evaporation unit are porous and have partial sharp edges. You
may injure your hands on this sharp edges or may injure your eyes by splintering ceramic parts
when handling the ceramic plates.
Prevention: when handling the ceramic plates always wear protecting gloves and goggles.
Preventing unsafe operation
All persons working with the humidication system Condair DL are obliged to report any alterations to
the unit that may affect safety to the owner without delay and to secure such systems against acci-
dental power-up.
CAUTION!
In order that the Condair DL does not remain in the error status unnoticed for a longer period of time
in the event of a malfunction, errors must be signaled via a remote error indication (e.g. via the error
relay of the remote operating and fault indication board or via the network via BACnet or Modbus).
Prohibited modications to the unit
No modications must be undertaken on the humidication system Condair DL without the express
written consent of the manufacturer.

8Important notes
3 Important notes
3.1 Inspection of the delivery
After receiving:
– Inspect shipping boxes for damage.
Any damages of the shipping boxes must be reported to the shipping company.
– Check packing slip to ensure all parts has been delivered.
All material shortages are to be reported to your Condair supplier within 48 hours after receipt of the
goods. Condair assumes no responsibility for any material shortages beyond this period.
– Unpack the parts/components and check for any damage.
If parts/components are damaged, notify the shipping company immediately.
– Check whether the components are suitable for installation on your site according to the model key
stated on the type plate (see Section 3.3).
3.2 Storing/Transportation/Packaging
Storing
Until installation store the system components in its original packaging in a protected area meeting the
following requirements:
– Room temperature: 41...104 °F (5 ... 40 °C)
– Room humidity: 10 ... 75 %rh
Transportation
For optimum protection always transport the unit in the original packaging and use an appropriate lifting/
transporting device.
WARNING!
It is the customer's responsibility to ensure that operators are trained in handling heavy goods and that
the operators comply with the appropriate regulations on work safety and the prevention of accidents.
Packaging
Keep the original packaging of the components for later use.
In case you wish to dispose of the packaging, observe the local regulations on waste disposal. Please
recycle packaging where possible.

9Important notes
Condair Group AG, Gwattstrasse 17, 8808 Pfäfkon SZ, Switzerland
Type: Condair DL Serial-No: XXXXXXX 03.16
Voltage: 200-240VAC / 50-60Hz Amps: 6.5 / max. Discon.: 15 Amps
Humidier capacity: 100 kg/h Standard Type A
Water ow pressure: 3...7 bar DL II A 1800 2000 100 R 7 75 0 5.0 21
Engineered in Switzerland, Made in Germany
3.3 Product designation
The product designation and the most important unit data are found on the rating plate xed on the right
side of the control unit and the central unit (see example below):
Device type Serial number Manufacturing date month/year
Supply voltage
Humidication capacity
Admissible water supply pressure
(yield pressure)
Certicates
Product key
Unit type
Current draw
Product key
Example: Condair DL II A 1800 2000 100 R 7 75 0 5.0 21
Device type
Device series
Type version:
A: Standard version with booster pump
B: Version without booster pump
AHU/duct inside width in mm
AHU/Duct min. inside height in mm
Humidier capacity in kg/h
Position of the water connection on the nozzle grid (view in air ow direction):
R: right
L: left
Number of control steps:
3: 3 control steps
7: 7 control steps
15: 15 control steps
31: 31 control steps
Length wall feed throughs in mm:
75: 75 mm (2.95")
125: 125 mm (4.92")
Droplet separator:
0: without droplet separator - air velocity ≤492.13 ft/min (≤2.5 m/s)
1: with droplet separator - air velocity >492.13 ft/min to max. 787.40 ft/min
(>2.5 m/s to max. 4.0 m/s)
Nozzle type:
1.5: 1.5 l/h (0.40 gal/hr)
2.0: 2.0 l/h (0.53 gal/hr)
2.5: 2.5 l/h (0.66 gal/hr)
3.0: 3.0 l/h (0.79 gal/hr)
3.5 3.5 l/h (0.92 gal/hr)
4.0 4.0 l/h (1.06 gal/hr)
4.5 4.5 l/h (1.19 gal/hr)
5.0 5.0 l/h (1.32 gal/hr)
Number of nozzles

10 Mounting and installation work
4 Mounting and installation work
4.1 Safety notes on mounting and installation work
Qualication of personnel
All mounting and installation work must be carried out only by well qualied and trained personnel
authorized by the owner. It is the owner’s responsibility to verify proper qualication of the personnel.
General notes
Prior to installation work, the ventilation system (into which the Condair DL is to be incorporated) must
be taken out of operation and secured against unintentional start-up.
It is mandatory to observe and comply with the instructions regarding the location and installation
of particular components of the Condair DL.
Observe and comply with all local regulations dealing with water and electrical installations.
Use only the mounting accessories included in the delivery for installing the various system compo-
nents. If for some special reasons an installation with the supplied installation accessories is not feasible,
choose a type of installation that is equally stable. In cases of doubt, contact your Condair distributor.
Safety
Some installation work requires removal of the unit covers of the control unit and the central unit. Please
note the following:
DANGER!
Danger of electric shock!
The control unit of the Condair DL and the pump motor inside the central unit (if applicable)
are mains powered. Live parts may be exposed when the control unit and/or the central unit
is/are open. Touching live parts may cause severe injury or danger to life.
Prevention: The control unit of the Condair DL must be connected to the mains only after all mounting
and installation work has been completed, all installations have been checked for correct workmanship
and all unit covers are relocated properly locked.
Important! The frequency converter in the control unit of systems with booster pump contains
capacitors. These can remain charged with a potentially deadly voltage for a certain period of
time after the control unit has been disconnected from the power supply. Therefore, wait at least
10 minutes after disconnecting the power supply. Then make sure the appropriate contacts on
the frequency converter and the terminals on the pump motor are free of voltage before starting
any work on these components!
CAUTION!
The electronic components inside the control unit of the Condair DL are very sensitive to
electrostatic discharge.
Prevention: To protect these components against damage caused by electrostatic discharge (ESD
protection) appropriate measures must be taken when the control unit is open for installation work.
