Condair AT Series User manual

INSTALLATION AND OPERATING
INSTRUCTIONS
Adiabatic Atomiser Humidifier
Condair ABS3
2546634-B EN 1905
Humidication and Evaporative Cooling

Thank you for choosing Condair
Installation date (MM/DD/YYYY):
Commissioning date (MM/DD/YYYY):
Site:
Model:
Serial number:
Proprietary Notice
This document and the information disclosed herein are proprietary data of Condair Group AG. Neither this docu-
ment, nor the information contained herein shall be reproduced, used, or disclosed to others without the written
authorization of Condair Group AG, except to the extent required for installation or maintenance of recipient's
equipment.
Liability Notice
Condair Group AG does not accept any liability due to incorrect installation or operation of the equipment or due
to the use of parts/components/equipment that are not authorized by Condair Group AG.
Copyright Notice
© Condair Group AG, All rights reserved.
Technical modications reserved

3Contents
Contents
1 Introduction 5
1.1 To the very beginning 5
1.2 Notes on the installation and operating instructions 5
2 For your safety 7
2.1 General 7
2.2 Qualication of personnel 7
2.3 Intended and non intended use 7
3 Product overview 9
3.1 Unit construction 9
3.2 Principle of operation 9
3.3 Identication of the unit 10
3.4 Accessories and options 10
3.5 Standard delivery 11
3.6 Storing/Transportation/Packaging 11
4 Mounting and installation work 12
4.1 Important notes for mounting and installation work 12
4.2 Mounting the unit 13
4.2.1 Notes on unit location 13
4.2.2 Wall mounting 14
4.2.3 Ceiling mounting (hanging installation) 15
4.3 Water installation 16
4.3.1 Overview water installation 16
4.3.2 Notes on water installation 17
4.4 Electric installation 18
4.4.1 Wiring diagram Condair ABS3 18
4.4.2 Notes on electric installation 19
4.4.3 Dismounting and mounting the electric connection box 20
4.4.4 Notes regarding the cabling 21
4.4.5 Conguration 22
4.4.5.1 Setting the ushing cycles 22
4.4.5.2 Setting the humidication capacity limitation 22
5 Operation 23
5.1 Setting the unit into operation 23
5.2 Inspections during operation 23
5.3 Taking the unit out of operation 24
6 Maintenance 25
6.1 Important notes on maintenance 25
6.2 Maintenance intervals 25
6.3 Maintenance work 26
6.4 Cleaning and disinfection 27

4Contents
7 Troubleshooting 28
7.1 Important notes on troubleshooting 28
7.2 Malfunction list 28
8 Taking out of service/Disposal 29
8.1 Taking out of service 29
8.2 Disposal/Recycling 29
9 Productspecications 30
9.1 Technical data 30
9.2 Dimensions 30
9.5 EC Declaration of conformity 31
10 Hygiene 32
10.1 Important notes on hygiene 32
10.2 Hygiene risk management 32
10.2.1 Guidelines to keep a clean system and prevent legionella growth 33
10.2.2 Risk Monitoring and Assessment 34

5Introduction
1 Introduction
1.1 To the very beginning
We thank you for having purchased the adiabaticatomiserhumidierCondairABS3.
The Condair ABS3 incorporates the latest technical ad van ces and meets all recognized safety stand-
ards. Nevertheless, improper use of the adiabatic air humidier Condair ABS3 may result in danger to
the user or third parties and/or impairment of material assets.
To ensure a safe, proper, and economical operation of the Condair ABS3, please observe and comply
with all information and safety instructions contained in the present installation and operating instructions
as well as in the separate documentations of the components installed in the humidication system.
If you have questions, which are not or insufciently answered in this documentation, please contact
your Condair supplier. They will be glad to assist you.
1.2 Notes on the installation and operating instructions
Limitation
Thesubjectoftheseinstallationandoperatinginstructionsistheadiabaticatomiserhumidier
Condair ABS3. The various accessories are only described insofar as this is necessary for proper opera-
tion of the equipment. Further information on accessories can be obtained in the respective instructions.
These installation and operating instructions are restricted to the installation, commissioning, opera-
tion, servicing, and trouble-shooting of the Condair ABS3 and is meant for well trained personnel
beingsufcientlyqualiedfortheirrespectivework.
The installation and operating instructions are supplemented by various separate items of documenta-
tion. Where necessary, appropriate cross-references are made to these publications in the installation
and operating instructions.

6Introduction
Symbols used in this manual
CAUTION!
The catchword “CAUTION” designates notes in this installation and operating instructions that, if ne-
glected, may cause damage and/or malfunction of the unit or other material assets.
WARNING!
The catchword “WARNING” used in conjunction with the general caution symbol designates safety
and danger notes in this installation and operating instructions that, if neglected, may cause to injury
to persons.
DANGER!
The catchword “DANGER” used in conjunction with the general caution symbol designates safety
and danger notes in this installation and operating instructions that, if neglected, may lead to severe
injury or even death of persons.
Safekeeping
Please safeguard these installation and operating instructions in a safe place, where they can be im-
mediately accessed. If the equipment changes hands, the documentation must be passed on to the
new operator.
If the documentation gets mislaid, please contact your Condair supplier.
Language versions
These installation and operating instructions are available in various languages. Please contact your
Condair supplier for information.
Copyright protection
The present installation and operating instructions is protected under the Copyright Act. Passing-on and
reproduction of the manual (or part thereof) as well as exploitation and communication of the contents
are prohibited without written permission by the manufacturer. Violation of copyright terms is subject to
legal prosecution and arises liability for indemnication.
The manufacturer reserves the right to fully exploit commercial patent rights.

7For your safety
2 For your safety
2.1 General
Every person working with the Condair ABS3 must have read and understood the installation and op-
erating instructions before carrying out any work.
Knowing and understanding the contents of the installation and operating instructions is a basic require-
ment for protecting the personnel against any kind of danger, to prevent faulty operation, and to operate
the unit safely and correctly.
All ideograms, signs and markings applied to the unit must be observed and kept in readable state.
Except for the steps mentioned in this manual, the user must not carry out further operations with the
Condair ABS3.
2.2 Qualicationofpersonnel
The Condair ABS3 must be installed, operated, serviced and repaired only by qualied persons familiar
with the equipment.
For safety and warranty reasons any action beyond the scope of this manual must be carried out only
by qualied personnel authorized by the manufacturer.
It is assumed that all persons working with the Condair ABS3 are familiar and comply with the appropri-
ate regulations on work safety and the prevention of accidents.
Condair ABS3 may not be used by persons (including children) with reduced physical, sensory or mental
abilities or persons with lacking experience and/or knowledge, unless they are supervised by a person
responsible for their safety or they received instructions on how to operate the unit.
Children must be supervised to make sure that they do not play with unit.
2.3 Intended and non intended use
Intended use
The Condair ABS3 is exclusively intended for direct room humidication under strict adherence to the
information and notes given in this manual. Any use beyond this scope is considered to be a violation
of the intended purpose and may en danger your safety or possibly cause the product to be damaged.
Any use other than the intended purpose of the Condair ABS3 is at customer’s own risk and for no
means the manufacturer or supplier will be liable for possible damage.
Operation of the Condair ABS3 in the intended manner requires that all the information contained in this
operation manual is observed (in particular the safety and hygiene instructions).
Special care must be observed to properly install, maintain, clean, and disinfect the Condair ABS3 to
preserve acceptable levels of hygiene.

8For your safety
Non intended use
TheCondairABS3isnotsuitableforhumidicationinhealth-carepremises. Due to the nature of
aerosol generating humidication units, it is not recommended to use these in environments where the
occupants or materials in the space are adversely sensitive to airborne bacteria, viruses, dust, and debris.
The Condair ABS3 must not be used in hazardous locations.
Danger that may arise from the unit
DANGER!
Danger of electric hazzard
One may get in touch with live parts when the wiring box is open. Touching live parts may cause
severe injury or danger to life.
Prevention: before carrying out any work set the Condair ABS3 out of operation as described in
chapter 5.3 (switch off the unit, disconnect it from the mains and stop the water supply) and secure
the unit against inadvertent power-up.
DANGER!
Healthriskbecauseofinadequatehygiene!
Badlymaintainedhumidierscanendangerthehealth.If the unit is insufcient maintained ill-making
germs may grow in the water reservoir and the water supply pipe of the Condair ABS3 and may can
affect the air passing through the humidier during operation.
Prevention: the Condair ABS3 must be cleaned in the prescribed intervals according to the information
given in chapter 6. The cleaning works must be carried out correctly and the air lter must be replaced
after their prescribed lifetime has elapsed.
Behaviour in case of danger
If it is suspected that safe operation is no longer possible, then the Condair ABS3 should immediately
be shut down and secured against accidental power-up according to chapter 5.3. This can be the
case under the following circumstances:
– if the Condair ABS3 is damaged
– if the Condair ABS3 is no longer operating correctly
– if connections and/or piping are not sealed
– if electrical cables are defective
– if the Condair ABS3 is no longer fastened correctly.
All persons working with the Condair ABS3 must report any alterations to the unit that may affect safety
to the owner without delay.
Prohibitedmodicationstotheunit
Nomodicationsmustbeundertaken on the Condair ABS3 without the express written consent of
the manufacturer.
For the replacement of defective components use exclusively original accessories and spare parts
available from your Condair supplier.

9Product overview
3 Product overview
3.1 Unit construction
1 Air lter (EU3/C3)
2 Electrical connection box
3 Water reservoir
4 Cone with fan
5 Atomiser disk
6 Motor
7 Discharge hood, rotatable
3.2 Principle of operation
The Condair ABS3 operates according to the atomization principle.
The water is drawn in through cone (4) from the water reservoir (3) and is hurled from the atomiser disk
(5) against the atomiser collar (8), thereby producing aerosols (fog). The level in the water reservoir is
monitored and controlled with the oat switch (10).
The fan attached to the cone draws in room air through the air lter (1) on the bottom of the base unit.
This air transports the aerosols to the atomiser outlet (7) and distributes them in the room.
The humidier is controlled via an external On/Off humidistat or an external 0-10V continuous humidity
controller which opens and closes the inlet valve. When controlled via the external continuous humidity
controller the inlet valve is opened and closed cyclically, depending on the control signal.
8 Atomiser collar
9 Water supply
10 Level switch
11 Water drain
12 Siphon
13 Unit housing
7
6
5
4
1
2
310
13
11
12
9
8

10 Product overview
Condair Group AG
CH-8808 Pfäffikon SZ
Condair ABS3 120 230V
F3003
Januar 09
Zerstäuber
Atomizer
Atomiseur
08/S01776/00001
2543376
Serial Nr.
230 V ~, 50/60 Hz, 230 W (300 W)
Type designation
Outlet angle in degrees
Unit voltage
Unit voltage/power consumption
3.3 Identicationoftheunit
The indication of the unit as well as the most important unit data are found on the type plate:
Serial number
Month/Year
3.4 Accessories and options
Accessories
Designation Code Description
Filter valve Z261 Filter valve with G 1/2" internal thread connectors for the
installation in the water supply line.
Room humidistat HSC On/Off room humidistat
Room humidistat H5 / H5V On/Off room humidistat (Note: this humidistat can be used
as a maximum humidistat).
Room humidity controller RCC 0-10 V continuous humidity controller with sensor
Options
Designation Code Description
Anti-freeze kit AFP Anti-freeze kit for the operation of the Condair ABS3 up to
a temperature of -2 °C. The anti-freeze kit consist of a heat-
ing element connected to the control board. The Condair
ABS3 is prepared for the installation of the anti-freeze kit.
The control of the heating element is established via the
temperature sensor built into the unit. The temperature
sensor switches the heating element on if the ambient
temperature drops below 1°C.
Approval symbols

11Product overview
3.5 Standard delivery
The standard delivery includes:
– Adiabatic atomiser humidier ABS3 with options according delivery note.
– Ordered accessories with operating instructions, packed separately
– Installation and operating instructions (this document).
– Fixing set for the wall mounting of the unit (1 pc. wall bracket, 4 screws with dowels ø8 mm, 1 pc.
safety screw M6x20 with washer ø6x12)
– Fixing set for the hanging installation (3 pcs. angle brackets)
– Water supply pipe (L: 1.5 m, with G 3/4" union nuts)
– Adapter G 1/2" - G 3/4"
– Water drain pipe (L: 1.5 m, internal diameter: 10 mm)
– 2 pcs. cable straps
– Spare parts list
3.6 Storing/Transportation/Packaging
Storing
Store the unit in the original packaging in a protected area meeting the following requirements:
– Room temperature: 1 ... 40 °C
– Room humidity: 10 ... 75 %rh
Transportation
For optimum protection always transport the unit in the original packaging.
If possible, always transport the unit with the help of another person.
Packaging
Keep the original packaging of the Condair ABS3 for later use.
In case you wish to dispose of the packaging, observe the local regulations on waste disposal. Never
dispose of the packaging to the environment.

12 Mounting and installation work
4 Mounting and installation work
4.1 Important notes for mounting and installation work
Qualicationofpersonnel
All mounting and installation work must be carried out only bywellqualiedpersonnel, which is familiar
with the Condair ABS3.
All work concerning the electric installation must be performed only by adequately qualied personnel
(electrician or workman with equivalent training).
Safety
The Condair ABS3 may be connected to electric mains only after all installation work has been completed.
The local regulations relating job safety must be followed and complied with for all installation and
mounting work.
General notes
All statements relating to the positioning and installation of the ABS3 as well as to the water and electri-
cal installation must be followed and complied with.
Observe and comply with all local regulations dealing with water and electrical installations.
When installing individual components use thexingmaterialssuppliedwiththeunit. If xing with
the materials supplied is not possible in your particular case, select a method of xing that is of similar
stability. In case of doubt, please contact your Condair supplier.
The connection of the water supply pipe and the water drain pipe on the unit (see chapter 4.3) as well
as the connection of the main cable and the cable of the external humidistat/humidity controller in the
unit (see chapter 4.4) can be done before the unit is mounted to the wall/ceiling.

13Mounting and installation work
4.2 Mounting the unit
4.2.1 Notes on unit location
In order to ensure the correct function of the humidier and the accessibility for maintenance, please
observe the following locating instructions:
– The Condair ABS3 humidiers are designed for wall mouting or ceiling mounting (hanging instal-
lation). Make sure that the structure (wall, pillar, ceiling, etc.) on which the unit is to be mounted has
sufcient carrying capacity and can accommodate the fastening elements.
– In order to ensure the correct function, the Condair ABS3 must be installed exactly horizontal (with
the air lter facing downward against the oor).
– Locate the unit such that the aerosol stream can spread freely. The obstruction of the aerosol stream
by objects such as tubular racks, machines, supports, etc., will result in stagnation and the formation
of turbulence which could cause condensation. Since the discharge hood of the humidier can be
turned horizontally, the aerosol stream can be directed to bypass any obstructions.
In the following table you nd the minimum distances (appoximate values), which must be main-
tained when positioning the Condair ABS3. The dimensions relate to a room temperature of 20 °C
and a relative humidity of 45%. At lower temperatures and/or higher relative humidity larger minimum
distances must be maintained
Wall mounting Ceiling mounting
E
C
D
D
B
EA A
B
C
A B C D E
Minimum distance in m ≥ 3.0 ≥ 1.0 ≥ 1.5 ≥ 1.0 ≥ 5.0
– Mount the unit such that there is sufcientroomformaintenance. Also make sure that the unit is
readily accessible and that there is no accident risk during maintenance.
– If units are to be installed facing each other, make sure that they are atleast10mapart.
– Insulate cold water piping in the vicinity of the aerosol stream (risk of condensation).
– The evaporation process extracts heat from the ambient air. Make sure, therefore, that the aerosol
stream is not directed at persons.

14 Mounting and installation work
4.2.2 Wall mounting
To x the humidier to the wall, use the wall bracket, screws and dowels provided. The wall bracket can
be used as template for the xing holes.
Mounting the wall bracket
1. Mark the xing holes on the wall using the wall bracket as template. Make sure the wall bracket is
aligned exactly horizontal before marking the holes.
2. Drill the four xing holes (ø8 mm, 45mm deep).
3. Clean the holes and insert the dowels.
4. Fix the wall bracket with four screws to the wall (position of the bracket as shown in the gure above).
Before tightening the screws align the wall bracket exactly horizontal.
Mounting the unit
1. Lift the unit above the wall bracket and swivel it slightly towards the wall.
2. Move the unit towards the wall into the wall bracket.
3. Swivel the unit to the horizontal position until both brackets are perfectly coupled.
4. Secure the unit in the wall bracket with the safety screw M6x20 and the washer ø6x12 supplied
(mandatory).
2.
1.
3.
4.
4.

15Mounting and installation work
4.2.3 Ceiling mounting (hanging installation)
Ceiling mounting is done with the angle brackets supplied as standard.
The three chains for hanging up the unit must be provided by the customer.
The chains must be xed at the ceiling exactly perpendicularly above the
three angle brackets xed to the unit. The xing points and the chains must
have a sufcient load-bearing capacity, in order to carry the weight of the unit
(see chapter 9.1).
Use chains made of steel (preferably corrosion-resistant steel). The dimen-
sion of the chain links must meet to the specications in the adjacent gure.
1. Undo the 4 screws “V”, and remove the mount-
ing plate “A” on the backside of the unit.
Note: Store the mounting plate “A” for a pos-
sible later use.
Now, you have 5 screws with washers (4 from
the just removed mounting plate and the safety
screw provided). Ret two of the screws and
washers into the xing holes “F”.
2. Fix the three angle brackets (for hanging instal-
lation) with the screws and washers to the unit,
as shown in the adjacent gure.
3. Hook the unit with the angle brackets into the chains and check again that the device hangs exactly
horizontal.

16 Mounting and installation work
4.3 Water installation
4.3.1 Overview water installation
A Water supply pipe (included in the delivery, L: 1.5 m, G 3/4")
B Stop valve (by client)
C Water lter (accessory Z261, installation recommended, by client)
D Drain pipe (included in the delivery, L: 1.5 m) with constant downward slope >10°
E Open drain funnel with siphon (by client)
Connector water supply G 3/4"
Water supply pipe
Connector
water drain ø10 mm
Drain pipe
ø12/10 mm

17Mounting and installation work
4.3.2 Notes on water installation
Water supply
The water supply is to be carried out according to the gure found in chapter 4.3.1 and the applicable
local regulations for water installations. The indicated connection specications must be observed.
– The installation of a stop valve (mandatory) and a waterlter (accessory “Z261”, installation rec-
ommended) should be made as close as possible to the unit.
– Admissible supply water pressure: 1 to 6 bar
– Admissible water temperature: 5 to max. 20 °C
– Notesonwaterquality:
– For the water supply of the Condair ABS3, use exclusively untreated tap water or fully dem-
ineralizedwaterwithamax.of150CFU/ml(nopathogens).
– The use of additives such as corrosion inhibitors, disinfectants, etc. is not allowed, since these
additives may endanger health and affect proper operation.
– The connection material must be pressure-proof and certiedforuseindrinkingwatersystems.
– Important! Before connecting the water line, the line should be well ushed out.
CAUTION!
The thread at the humidier connection is made of plastic. To avoid overtightening, the union nut
of the water pipe must be tightened by hand only.
Water drain
The water drain is to be carried out according to the gure found in chapter 4.3.1 and the applicable local
regulations for water installations. The indicated connection specications must be observed.
– Make sure that the drain line is routed with a constant downward slope >10° to the drain funnel of
the building.
Important: The drain pipe must be prevented from sagging; support with brackets, if necessary.
– Make sure that the minimum inside diameter of 10 mm is maintained throughout the entire length of
the drain pipe and that the pipe is not kinked.
– Make sure that the drain pipe is correctly xed and easily accessible for inspections and cleaning
purposes.
When operating the Condair ABS3 with fully demineralized water:
Fully demineralized water is aggressive! For this reason, use exclusively installation material made
of corrosion-resistant steel (min. DIN 1.4301) or plastic.

18 Mounting and installation work
4.4 Electric installation
4.4.1 Wiring diagram Condair ABS3
A1 Continuous humidity controller 0...10 V
A2 On/Off humidistat
A3 Maximum humidistat (not mandatory, required contact load: 230V/2A or 115V/4A)
S1 Temperature sensor (to switch the optional heating H1 on and off)
S2 Level switch
H1 Heating (option anti-freeze kit)
F1 Internal fuse transformer (315 mA, slow acting)
F2 External fuse voltage supply (2.5 A, slow acting)
M Fan motor
Q2 External service switch (with a minimum contact clearance of 3 mm)
SW1 DIP switches for setting the ushing cycles
SW2 Rotary switch for setting the power limit
Y1 Inlet valve
K1
SW1
SW2
Off On
50
0100
NL1 K2 K3
24V LEVELGND IN
24VIN
NTC
M
MIN
1.1 l/h MAX
6.5 l/h
1
2
Q2
F2
F1
115 V / 50/60Hz
230 V / 50/60Hz
S1 S2
Y1
H1
A2
A1
– +
P / PI
ON-OFF
A3
ON-OFF
24 VDC / 60 mA
internal
external

19Mounting and installation work
4.4.2 Notes on electric installation
The electric installation must be carried out according to the wiring diagram in chapter 4.4.1 and the
applicable local regulations. All information given in the wiring diagram must be followed and observed.
The electrical installation of the Condair ABS3 includes:
Installation
Power supply 230V/50-60Hzor115V/50-60Hz
Connection of power supply to terminals L1 and N according to the wiring diagram. The service switch
Q2 (disconnects all 2 wires with a minimum contact clearance of 3 mm) and the fuses F2 (2.5 A, slow
acting) are mandatory.
Cable section according to the applicable local regulations.
CAUTION!
Before connecting the power supply cable make sure the local mains voltage meet the value stated
on the rating plate of the Condair ABS3.
External humidity controller (A1) or external On/Off humidistat (A2)
Connect the external humidity controller 0...10V to terminals IN (+) and GND (–) or connect the external
On/Off humidistat to terminals IN and 24V.
Note: In locations with electromagnetic interferences use shielded connecting cables.
Maximum humidistat (A3), not mandatory
Connect the switching contact of the maximum humidistat to supply line L1 according to the wiring
diagram.
Required contact load: 230V/2A or 115V/4A
Note: In order to connect the mains cable and the cable of the external humidistat/humidity controller
to the control board, the electric connection box in the unit must be dismounted and opened. For this
purpose please observe the notes in chapter 4.4.3 and the notes regarding the cabling in chapter 4.4.4.

20 Mounting and installation work
2. Push xing clip “C” sidewards and carefully pull connection box out of the unit.
3. Undo the four screws of the connection box and remove the cover.
Now you can connect the cables on the control board or congure the control.
CAUTION!
The electronic components inside the electric connection box are very sensitive to electrostatic
discharge. When the unit is open for installation work, appropriate measures must be taken to protect
these components against damage caused by electrostatic discharge (ESD protection).
Mounting the electric connection box
1. Re-attach the cover of the connection box and x it with the four screws.
4.4.3 Dismounting and mounting the electric connection box
Dismounting the electric connection box
1. Undo the three screws at the air lter assembly and remove the air lter assembly.
2. Replace the connection box into the receptacle in the unit and x it with the xing clip.
3. Set the air lter assembly (grid-lter-grid) into the bottom of the unit an x it with the three screws.
C
